Evaluation and Comparison of Dynamic Call Graph Generators for

JavaScript

Zolt

an Herczeg and G

abor L

oki

Department of Software Engineering, University of Szeged, Dugonics t

er 13, 6720, Szeged, Hungary

Keywords:

JavaScript, Call graph, Node.js, Comparison, Security, Complexity

Abstract:

JavaScript is the most popular programming language these days and it is also the core language of the node.js

environment. Sharing code is a simple task in this environment and the shared code can be easily reused as

building blocks to create new applications. This vibrant and ever growing environment is not perfect though.

Due to the large amount of reused code, even simple applications can have a lot of indirect dependencies.

Developers may not even be aware of the fact that some of these dependencies could contain malware, since

harmful code can be hidden relatively easily due to the dynamic nature of JavaScript. Dynamic software

analysis is one way of detecting suspicious activities. Call graphs can reveal the internal workings of an

application and they have been used successfully for malware detection. In node.js, no tool has been available

for directly generating JavaScript call graphs before. In this paper, we are going to introduce three tools that

can be used to generate call graphs for further analysis. We show that call graphs contain a signiﬁcant amount

of engine-speciﬁc information but ﬁlters can be used to reduce such differences.

1 INTRODUCTION

The trend of the past years is unbroken, JavaScript

is the most popular (StackOverﬂow, 2018) program-

ming language nowadays. JavaScript has been de-

signed to extend static Web documents with interac-

tive features, but eventually it appeared in other ar-

eas, such as server side scripting and embedded sys-

tems

. Although the syntax of the language is the

same on all systems, the application programming in-

terfaces (APIs) provided by each environment can be

quite different. From a security perspective, many of

these APIs provide access to system resources, such

as ﬁle systems, network connections, cameras, or pri-

vate user data, therefore, these resources must be pro-

tected from harmful uses and direct attacks.

Detecting malicious behaviour of JavaScript code

is among the key areas of protecting users and com-

puter systems. Many solutions (Yu et al., 2007;

Guarnieri and Livshits, 2009; Bielova, 2013) that

have been developed already are focusing on enforc-

ing security policies. Besides strengthening poli-

cies, a more promising approach can be the anal-

ysis of JavaScript code in order to detect harmful

actions especially on software ecosystems where a

http://jerryscript.net

large amount of JavaScript code is downloaded and

executed from unveriﬁed sources. An example for

such an ecosystem is the npm

software registry of

node.js

modules where anybody can upload their

own JavaScript modules without any security checks.

Injecting a vulnerability, into a potentially transitive

and less rigorously tested dependency module, can

cause security threats at unexpected points higher in

the dependency chain.

A fundamental area of detecting harmful be-

haviour is analysing the function calls of a software.

One form of call information are call graphs and these

graphs were used successfully for malware detection

on both mobile (Gascon et al., 2013) and non-mobile

systems (Elhadi et al., 2012) to detect both known and

unknown harmful code.

A call graph (Ryder, 1979) is a directed graph,

in which nodes are the functions of a program and

edges represent direct function calls between them,

and where the direction of an edge points toward the

callee. A call graph can be constructed statically, i.e.,

without executing the program, or dynamically, dur-

ing the execution. The static analysis of JavaScript

programs – helping, among others, call graphs con-

https://www.npmjs.com

https://nodejs.org

472

Herczeg, Z. and Lóki, G.

Evaluation and Comparison of Dynamic Call Graph Generators for JavaScript.

DOI: 10.5220/0007752904720479

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 472-479

ISBN: 978-989-758-375-9

struction – is a well-researched topic (Jensen et al.,

2009; Fink and Dolby, 2012; Madsen et al., 2013;

Feldthaus et al., 2013). However, in this paper we are

focusing on the less studied dynamic approach to pave

the way of dynamic security analysis of JavaScript

programs.

Regarding dynamic call graph construction for

node.js, we raise the following questions:

RQ1: Are there any dynamic call graph generator

tools for node.js modules?

RQ2: How do dynamic call graph generators in-

ﬂuence the generated graphs of a JavaScript module?

In this paper we investigate the differences of dy-

namic call graphs constructed by various call graph

generators. The rest of the paper is organized as fol-

lows. In Section 2, we introduce three essentially

different approaches that can generate dynamic call

graphs for node.js applications and modules. In Sec-

tion 3, we validate and compare the generated call

graphs on a popular JavaScript benchmark, while in

Section 4, we compare the call graphs of popular

node.js modules. In Section 5, we review related

work, and ﬁnally, conclusions and future works are

discussed in Section 6.

2 CALL GRAPH TOOLS

Strictly speaking, there are no publicly available tools

whose output is a dynamic call graph for node.js ap-

plications. On the other hand, there are tools which

can be extended to construct call information for fur-

ther processing. In the following sections, we intro-

duce three tools that employ essentially different ap-

proaches for generating call graphs.

2.1 Jalangi2 Framework

The ﬁrst tool uses the Jalangi2 (Sen et al., 2015)

framework – an improved version of Jalangi (Sen

et al., 2013) – which allows dynamic analysis of

ECMAScript 5.1 (Ecma International, 2011) code,

and supports node.js and several web browsers. EC-

MAScript is the standard which deﬁnes the different

revisions of JavaScript and its version 5.1 was re-

leased in 2011.

Internally, Jalangi2 uses an instrumentation

framework, which can extend an ECMAScript 5.1

source code with event notiﬁcations without changing

its observable behaviour. Variable assignments, ex-

pression evaluation, entering to, or exiting from func-

tions are among the events which can be captured by

Jalangi2. These events are processed by JavaScript

applications called Jalangi2 analyses. We have cre-

ated such an analysis (L

oki and Herczeg, 2019) for

dynamic call graph construction, which registers han-

dlers for function entry/exit events to collect the nodes

and edges of a call graph.

Unlike other tools in this section, Jalangi2 is a

pure JavaScript-based framework that modiﬁes the

source code of a JavaScript application, and the mod-

iﬁed code is executed by node.js.

2.2 Nodeprof.js Framework

The second tool is nodeprof.js (Sun et al., 2018),

which is a dynamic program analysis tool for node.js

applications. Nodeprof.js is built on top of the

Graal-nodejs project. Graal-nodejs is a port of

node.js which employs the Graal.js engine for run-

ning JavaScript. The Graal.js is an EcmaScript 2017

compatible engine which translates JavaScript source

code into a generic abstract syntax tree (AST) repre-

sentation, and this AST is executed by the GraalVM

virtual machine.

Similar to Jalangi2, nodeprof.js also adds event

notiﬁcations to JavaScript programs. However, in-

stead of instrumenting the source code, the events

are linked to the AST representation of the program

and modiﬁcations required for reporting events are

also applied to the AST. To accelerate its adoptation,

nodeprof.js supports Jalangi2 analyses for processing

events, although the interface is not fully compatible.

Fortunately, we were able to reuse our call graph gen-

erator analysis (L

oki and Herczeg, 2019) with minor

modiﬁcations.

Unlike other tools in this section, nodeprof.js is a

Java-based framework which modiﬁes the GraalVM

AST representation of a JavaScript source code, and

the modiﬁed AST is executed by GraalVM.

2.3 Nodejs-cg: A Modiﬁed Node.js

Finally, as the third tool, we have customized node.js

itself to create a variant called nodejs-cg (L

oki and

Herczeg, 2019). The default JavaScript engine of

node.js is the V8

JavaScript engine, which supports

execution tracing. The default behaviour of the built-

in tracing is to print information about functions

where the execution is entered or exited. We have

replaced this tracing mechanism with our own call

graph generator.

This call graph generator collects all nodes and

edges when a node.js application is executed and

dumps the whole graph when node.js terminates. All

https://developers.google.com/v8

Evaluation and Comparison of Dynamic Call Graph Generators for JavaScript

473

Table 1: Running time and disk space consumed by express.

nodejs with nodejs-cg

tracing enabled

running time 48 s 5 s

disk space 161 MB 0.9 MB

Jalangi2

nodeprof.js nodejs-cg

199

272

581

Figure 1: Number of call graph edges on SunSpider.

the information is stored in memory in order to in-

ﬂuence the performance of JavaScript execution with

printing as little as possible.

Table 1 shows that our approach can be 10 times

faster and can take 100 times less space than post-

processing the tracing output.

Unlike other tools in this section, the call graph is

directly generated by the JavaScript engine of nodejs-

cg. The source code or the intermediate representa-

tion are not modiﬁed by the generator tool.

3 SUNSPIDER CALL GRAPHS

In this section we compare the call graphs generated

from the widely used SunSpider

benchmark suite in

order to examine the basic characteristics of the gen-

erated call graphs. Version 1.0.2 of the suite con-

tains 26 programs which are executed one-by-one by

a driver application. The source code of SunSpi-

der is EcmaScript 5.1 compatible so all three tools

(Jalangi2, nodeprof.js, and nodejs-cg) are able to run

it.

3.1 Node Identiﬁcation

To compare multiple call graphs of the same program,

the same nodes need to be identiﬁed in all call graphs.

This identiﬁcation can be done by assigning a unique

identiﬁer to each node which is independent from the

current execution of the program. Such identiﬁer can

be created from the absolute path of the source ﬁle

where the function is deﬁned and the location of the

function start. With this identiﬁcation mechanism all

https://webkit.org/perf/sunspider/sunspider.html

function repl a c eCa l l bac k () {

return " X " ;

}

function myReplace ( str ) {

return str . replace (/ b / g ,

rep l a ceC a l lba c k );

}

var str = m y R e p lace ( ’ a bcba ’);

Figure 2: An example for using the replace() method.

the mentioned call graph generators found the same

set of nodes in SunSpider.

We have to note that JavaScript supports dynamic

script evaluation where scripts are not in ﬁles, but are

strings constructed at run-time. As a result, they have

no path information. Some heuristics can be designed

which try to add unique id for these strings, but the

identiﬁcation of an element in such a dynamic code

is a complex task. Currently, all of these scripts are

assigned to a single <eval> node.

3.2 Comparison of Found Edges

After we have implemented the same node identiﬁ-

cation method in each tool, we measured and com-

pared the results. Figure 1 shows the Venn diagram

of all call graph edges encountered during the exe-

cution of the SunSpider benchmark suite. The set of

edges found by each generator tool is shown inside a

circle corresponding to each tool. The intersections

of the circles contain the number of edges which are

collected by multiple tools. These edges are called

common edges in the following sections. By con-

trast, unique edges that are found only by a single

tool are shown in the non-intersected regions of the

circles. If the call graphs generated by the three tools

had been the same, only the intersection of the three

circles would have contained a non-zero value. How-

ever, we found several edges which were found only

by one or two tools and the reason for these differ-

ences will be discussed in the next subsections.

3.3 Jalangi2 and Nodejs-cg

The six edges found by both Jalangi2 and nodejs-

cg but not found by nodeprof.js are all related to the

built-in replace() method of JavaScript strings. This

method constructs a new string from an existing string

where substrings of the original string that matches to

a pattern are replaced by another substring. The ex-

ample shown in Figure 2 uses a regular expression for

the pattern and a callback function for generating re-

placement strings.

A JavaScript engine may implement a built-in

function (Ecma International, 2011, section 15) as a

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

474

myReplace()

replaceCallback()

Jalangi2 & nodejs-cg

myReplace()

∗<built-in>()

replaceCallback()

nodeprof.js

Figure 3: Subgraphs from Figure 2 example.

JavaScript function or as a native function. Native

functions are non-JavaScript functions which can be

called from JavaScript. They are usually compiled as

part of the JavaScript engine and stored in the same

binary executable ﬁle. JavaScript engines may imple-

ment the replace() function as a native function, and

they often cannot track the entry/exit of such func-

tions.

Figure 3 shows two different subgraphs which

connect the nodes of the myReplace() and replace-

Callback() function declared in Figure 2. The sub-

graph on the left is part of the call graphs generated by

Jalangi2 and nodejs-cg. In this case, there is no node

assigned to the replace() method, because Jalangi2

cannot instrument any built-in functions, and nodejs-

cg cannot detect native function calls. Hence, when

the replace() method calls its callback function, an

edge is created which directly connects the myRe-

place() and replaceCallback() functions.

Unlike the other two tools, nodeprof.js captures

the built-in function calls, although it assigns the

same node called ∗<built-in>() to all of them, which

makes impossible to tell which particular built-in

function is called. The subgraph including the

∗<built-in>() node is visible on the right side of Fig-

ure 3.

3.4 Unique Jalangi2 Edges

Twenty-seven edges – out of the thirty edges found

only by Jalangi2 in Figure 1 – are related to mod-

ule loading. In node.js, every JavaScript input ﬁle is

loaded as a module. First, the source code loaded

from a ﬁle is wrapped into a new JavaScript func-

tion as shown in Figure 4. The wrapped source code

is then evaluated by the JavaScript engine of node.js

which returns with a JavaScript function if no syn-

tax error is found. Then the returned function is

called from the module loader with the appropriate

arguments. This explains why we consider node.js

modules as functions: because their source code is

wrapped into a JavaScript function ﬁrst.

console . log ( ’a. js loaded ’ ) ;

(a) Original source code

(function( exp orts , . ..) {

console . log ( ’a. js loa d e d ’);

})

(b) Wrapped source code

Figure 4: Example for source code wrapping.

function f () { eva l ( " " ) }

Object.prototype.g = function() {}

f () ;

Figure 5: Invalid edges by Jalangi2.

The module loading in node.js is mostly per-

formed by JavaScript helper functions. This process

is clearly visible on the call graphs generated by node-

prof.js and nodejs-cg. However, Jalangi2 does not

track the internal JavaScript function calls of node.js,

and it adds a direct edge between two modules if one

of them loads the other. Since the SunSpider driver

loads twenty-six programs, it is represented by the

same amount of edges between the driver and the

loaded programs. The driver itself is loaded as a mod-

ule and the edge between a virtual entry node and the

driver is the twenty-seventh edge.

The string-tagcloud.js SunSpider program per-

forms a sort operation on an Array object. This op-

eration is done by calling the sort() built-in method,

which has a callback argument similar to the replace()

method. Since Jalangi2 only detects the calling of

the callback function, a direct edge is added between

the caller of sort() method and the callback function.

As for nodejs-cg, the sort() method is implemented

in JavaScript and the appropriate nodes and edges

are added to the call graph. nodeprof.js assigns the

∗<built-in>() node for the sort() method similar to

replace().

The last two unique Jalangi2 edges out of the

thirty are invalid. Figure 5 shows a simpliﬁed exam-

ple for creating such invalid edges. A new function

property called g is assigned to the Object.prototype

built-in object. This function should never be called

by the f function according to the ECMAScript stan-

dard but it does happen when this source code is ex-

ecuted in a Jalangi2 environment. Jalangi2 captures

the calling of the built-in eval function which allows

dynamic evaluation of JavaScript source code and re-

places the source code passed to the eval function

with an instrumented one. During the instrumenta-

tion, the properties of an object, which inherits the

properties of Object.prototype, are enumerated and

these properties are called as functions. Since the in-

strumented g function is called as well, the generator

adds a new edge between f and g functions. Simi-

Evaluation and Comparison of Dynamic Call Graph Generators for JavaScript

475

Table 2: Call graph edge groups by nodeprof.js.

group name number of edges

common 199 (42.3%)

node.js init 107 (22.7%)

JS built-ins 99 (21.0%)

module loading 66 (14.0%)

total 471 (100.0%)

Table 3: Call graph edge groups by nodejs-cg.

group name number of edges

common 199 (25.3%)

common Jalangi2 6 (0.8%)

nodejs init 491 (62.5%)

JS built-ins 22 (2.7%)

module loading 68 (8.7%)

total 786 (100.0%)

lar invalid edges appear in the actual call graph after

the string-tagcloud.js program adds a function prop-

erty to Object.prototype. This issue shows the imple-

mentation challenge of JavaScript-based instrumen-

tation tools: they need to avoid interacting with the

JavaScript environment.

3.5 Nodeprof.js and Nodejs-cg Edges

Edges of the call graph generated by nodeprof.js can

be divided into four groups. Table 2 shows these

groups and the number of edges for each group. The

value of the common group is the same as the value

inside the intersection of the three circles in Figure 1.

Although this group is the largest, only less than half

of the edges belong here. The remaining three groups

contain those 272 edges which were found only by

nodeprof.js.

The edges of the node.js init group are recorded

during node.js initialization. So, they are part of ev-

ery call graph generated by nodeprof.js regardless of

the application run by node.js. The JS built-ins group

contains those edges that involve internal functions

provided by the JavaScript interpreter, e.g., calling

JavaScript built-ins or calling other functions by these

built-ins. We should emphasize that node.js speciﬁc

helpers are not part of this group, they belong to the

last group, which is called module loading. SunSpider

does not use any features of node.js except the driver

program, which loads the other programs as modules.

Hence, the edges in this group are all related to mod-

ule loading.

To put the values of Table 2 in context, a similar

grouping is shown for nodejs-cg in Table 3. The only

difference is an extra group called common Jalangi2,

which contains those six edges that are found only by

Jalangi2 and nodejs-cg. These six edges have been

discussed before. Compared to nodeprof.js, the num-

ber of edges in node.js init group is 4.5 times big-

ger and this difference has two reasons. First, the

JavaScript engine of node.js has its own initialization

process, where several scripts written in JavaScript

are executed. The other reason is that nodeprof.js does

not record anything before an analysis is loaded and

node.js is partly initialized by this time. The num-

ber of JS built-ins edges are lower than in nodeprof.js,

since several built-in functions are implemented as

native functions in node.js. The edges representing

these native function calls are not part of the call

graph. The module loading group has the lowest dif-

ference between nodejs-cg and nodeprof.js because

this group depends only on node.js internals. The rea-

son for this slight change is that the tools use a differ-

ent version of node.js.

Although the number of edges in the common

group is the same for nodejs-cg and nodeprof.js, only

twenty-ﬁve percent of the edges belong here from the

call graph generated by nodejs-cg. This ratio is even

lower than nodeprof.js, where it was around forty per-

cent. The rest of the edges are engine speciﬁc and

they reveal information about the internal workings

of an engine rather than how SunSpider works.

4 CALL GRAPHS OF

APPLICATIONS

In the previous section, we compared the edges of

multiple call graphs generated from the SunSpider

benchmark suite. We found that some call graphs

have a large amount of unique edges, e.g., seventy-

ﬁve percent of the edges are unique in the call graph

generated by nodejs-cg. However, SunSpider is a rel-

atively small benchmark suite, so it would be bene-

ﬁcial if additional investigation was done with other

applications before drawing conclusions.

In this section, we compare the call graphs gen-

erated from seven popular node.js modules (Gyimesi

et al., 2019) from GitHub. Each module has a test-

ing system which runs on top of node.js and spawns

other node.js instances to do the testing. The previ-

ously discussed call graph generators can run as these

instances since they are drop-in replacements for a

node.js executable. The only difference is that be-

sides running tests, the generators also produce call

graphs. After the testing is completed, a ﬁnal call

graph, which is the union of the produced call graphs,

is created. The ﬁnal call graph contains all function

calls that happened during testing , including the func-

tion calls of test drivers, test cases, engine internals,

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

476

Table 4: Number of call graph edges found by nodeprof.js and nodejs-cg.

All call graph edges Non-builtin call graph edges Module call graph edges

Name nodeprof.js common nodejs-cg nodeprof.js common nodejs-cg nodeprof.js common nodejs-cg

bower 11821 10273 10422 8063 11967 8545 133 18455 82

doctrine 2778 2333 2692 1644 2786 2053 17 3567 6

express 6633 8413 6028 3842 9990 4306 6 11452 6

hessian 3344 2064 3206 2205 2518 2667 5 3441 6

jshint 2979 1957 2763 1945 2249 2373 5 3184 6

pencilblue 7779 5579 7089 5123 6852 5659 16 9989 24

request 8359 3639 7517 5875 4674 6316 22 7607 24

0% 20% 40% 60% 80% 100%

request

pencilblue

jshint

hessian

express

doctrine

bower

nodeprof.js common nodejs-cg

0% 20% 40% 60% 80% 100% 0% 1% 99% 100%

Figure 6: Distribution of call graph edges found by nodeprof.js and nodejs-cg.

and helper modules. Checking helper modules is im-

portant from a security perspective, since any of them

may contain malware. In this section, we focus on

nodeprof.js and nodejs-cg only, and exclude Jalangi2

because all applications require ECMAScript 2015

support for testing but Jalangi2 is ECMAScript 5.1

compatible only.

4.1 Overview of the Comparison

Results

Table 4 shows three subtables separated by vertical

lines, and Figure 6 shows the visual representation of

these tables in the same order. Each line in these ta-

bles contains three numbers that represent the num-

ber of call graph edges recorded by nodeprof.js and

nodejs-cg during the testing of a module. The ﬁrst

and last numbers show the unique edges collected by

nodeprof.js and nodejs-cg respectively, and the com-

mon column shows those edges that were found by

both tools. The name of the module whose call graph

information is presented in a given line is shown in

the leftmost column before the ﬁrst subtable.

The ﬁrst subtable in Table 4 shows the number

of all edges which are captured by nodeprof.js and

nodejs-cg. This table reveals that there are consid-

erable differences between the call graphs. For ex-

ample, the number of unique edges for the request

program is more than twice as big as the common

edges. The large number of unique edges makes the

comparison difﬁcult. To simplify the comparison,

we applied run-time ﬁlters to eliminate certain differ-

ences observed during the comparison of SunSpider

call graphs.

The ﬁrst ﬁlter ignores the built-in functions of the

JavaScript interpreter. The effect of this ﬁlter is sim-

ilar to inlining the code of a built-in function into its

caller function. Subgraphs – similar to the one above

at the nodeprof.js label in Figure 3 – are simpliﬁed to

the one above the jalangi2 & nodejs.cg label. The re-

sults after applying this ﬁlter are shown in the middle

subtable of Table 4. Although the number of unique

edges have decreased, their number is still high.

The previous ﬁlter was extended to ignore those

node.js core modules which are embedded into the

node.js executable as well. The source codes of these

modules are different since the two tools use different

versions of node.js. The rightmost subtable in Table 4

shows the edges that remained after applying the new

ﬁlter. Since the number of unique edges is quite low

in this table, we can conclude that the majority of dif-

ferences are caused by node.js and JavaScript engine

internal functions.

4.2 Remaining Differences

The unique edges at the rightmost table in Table 4

were checked by hand, and they fall into one of the

following two categories.

Evaluation and Comparison of Dynamic Call Graph Generators for JavaScript

477

The ﬁrst category is related to the class language

construct which supports explicit and implicit con-

structors. When a class is instantiated, nodejs-cg cap-

tures explicit constructor calls only. However, node-

prof.js captures both constructor calls, and the ﬁrst

character of the class keyword is identiﬁed as the lo-

cation of constructors. Since the location of a function

is part of the unique identiﬁer, the nodes assigned to

constructors cannot be paired in the two call graphs.

The second category is test result differences. Be-

cause the versions of node.js used by the two tools

are different, a few tests have run-time issues. E.g.,

one test may fail with one version of the execution

environment but pass with the other. Obviously, the

function calls of a test after a fail are missing from

the corresponding call graph, but new function calls

are often added as well by the error recovery system

of the testing environment. Furthermore, some tests

are skipped on certain versions of node.js.

4.3 Comparison Findings

We found that a large percentage of call graph edges

may be engine speciﬁc. Applications performing

high level analysis of JavaScript software should be

aware of this fact and may want to adjust their anal-

ysis strategy accordingly. Call graph generators may

also help improving certain analyses by ﬁltering un-

wanted edges. For example, ﬁltering out engine spe-

ciﬁc nodes simpliﬁes the comparison of call graphs,

which can be useful for ﬁnding the same malware

even if the call graph is produced by a newer version

of node.js extended with the same call graph genera-

tor.

5 RELATED WORKS

Call graphs can be constructed statically or dynam-

ically. There are several tools for generating static

call graphs from JavaScript code (Jensen et al., 2009;

Fink and Dolby, 2012; Madsen et al., 2013; Feldthaus

et al., 2013). Their strength is that they can pro-

cess JavaScript code regardless of the execution en-

vironment (web browser, node.js, etc.). Their weak-

ness is their precision. JavaScript is a highly dynamic

language where all functions are objects constructed

from a source code and a lexical environment, and

it is difﬁcult to predict which particular function ob-

ject is used by a function call. Some tools try to im-

prove these call graphs when well-known APIs are

used. For example, the formalized event emitter API

of node.js can be used to register listener functions,

and these calls can be detected by a static, event-based

call graphs analysis (Madsen et al., 2015).

Dynamic call graph generators for web browsers

are available (Toma and Islam, 2014; Nguyen et al.,

2014). The aim of these tools is to provide run-

time feedback to integrated development environ-

ments (IDEs) and ultimately to developers about the

execution of their own code in a web browser. Unlike

our tools, these tools do not support node.js.

6 SUMMARY

In this paper, we have introduced three new call graph

generator tools which are based on Jalangi2, node-

prof.js, and node.js, and are developed to ﬁll the miss-

ing dynamic call graph gap in the ﬁeld of node.js ap-

plications. In their original form, none of them were

capable of generating call graphs. We have shown that

these tools can be extended to extract call graph infor-

mation. Hence, the answer to the ﬁrst research ques-

tion (RQ1) – if there are any dynamic call graph gen-

erator tools for JavaScript modules – is that there are

such tools available now (L

oki and Herczeg, 2019).

To answer the second research question (RQ2) –

how dynamic call graph generators inﬂuence the gen-

erated graphs of a JavaScript module – we have com-

pared the call graphs generated by our three tools and

noticed that the call graphs of our test programs have

many unique edges. These edges are related to the

different handling of built-in functions, ECMAScript

classes, and different versions of node.js. Further-

more, we found some invalid edges which has re-

vealed an issue in the instrumentation framework of

Jalangi2. Thus, our conclusion is that the internal op-

eration of dynamic call graph generators can signiﬁ-

cantly inﬂuence generated call graphs. However, we

also presented that these differences can be eliminated

by proper ﬁltering mechanisms that may improve the

efﬁciency of further dynamic analyses.

Our future plan is to extend this research by gen-

erating more detailed call information. We aim at in-

vestigating call paths (call chains). We also plan to

analyse how such information can be utilized to de-

tect unusual program activity.

ACKNOWLEDGMENTS

This research was partially supported by the Hun-

garian Government and the European Regional De-

velopment Fund grant GINOP-2.3.2-15-2016-00037

(“Internet of Living Things”) and by the Min-

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

478

istry of Human Capacities, Hungary grant 20391-

3/2018/FEKUSTRAT.

REFERENCES

Bielova, N. (2013). Survey on JavaScript security policies

and their enforcement mechanisms in a web browser.

The Journal of Logic and Algebraic Programming,

82(8):243 – 262.

Ecma International (2011). Ecmascript language

speciﬁcation 5.1 edition. http://www.ecma-

international.org/ecma-262/5.1.

Elhadi, A., Maarof, M., and Hamza Osman, A. (2012). Mal-

ware detection based on hybrid signature behaviour

application programming interface call graph. Ameri-

can Journal of Applied Sciences, 9:283–288.

Feldthaus, A., Sch

afer, M., Sridharan, M., Dolby, J., and

Tip, F. (2013). Efﬁcient Construction of Approximate

Call Graphs for JavaScript IDE Services. In Proceed-

ings of the 2013 International Conference on Software

Engineering, ICSE ’13, pages 752–761. IEEE Press.

Fink, S. and Dolby, J. (2012). WALA-The TJ Watson Li-

braries for Analysis. http://wala.sourceforge.net.

Gascon, H., Yamaguchi, F., Arp, D., and Rieck, K. (2013).

Structural detection of Android malware using em-

bedded call graphs. In Proceedings of the 2013

ACM Workshop on Artiﬁcial Intelligence and Security,

AISec ’13, pages 45–54. ACM.

Guarnieri, S. and Livshits, V. B. (2009). Gatekeeper:

Mostly static enforcement of security and reliability

policies for JavaScript code. In USENIX Security Sym-

posium, volume 10, pages 78–85.

Gyimesi, P., Vancsics, B., Stocco, A., Mazinanian, D.,

Besz

edes,

A., Ferenc, R., and Mesbah, A. (2019).

BugsJS: a benchmark of JavaScript bugs. 12th IEEE

International Conference on Software Testing, Veriﬁ-

cation and Validation. https://github.com/bugsjs.

Jensen, S. H., Møller, A., and Thiemann, P. (2009). Type

Analysis for JavaScript. In International Static Anal-

ysis Symposium, pages 238–255. Springer.

oki, G. and Herczeg, Z. (2019). Dynamic call graph gener-

ators for JavaScript. https://github.com/szeged/js-call-

graphs/tree/call-graphs.

Madsen, M., Livshits, B., and Fanning, M. (2013). Prac-

tical Static Analysis of JavaScript Applications in the

Presence of Frameworks and Libraries. In Proceed-

ings of the 2013 9th Joint Meeting on Foundations of

Software Engineering, pages 499–509. ACM.

Madsen, M., Tip, F., and Lhot

ak, O. (2015). Static analysis

of event-driven node.js JavaScript applications. SIG-

PLAN Not., 50(10):505–519.

Nguyen, H. V., K

astner, C., and Nguyen, T. N. (2014).

Building call graphs for embedded client-side code

in dynamic web applications. In Proceedings of

the 22Nd ACM SIGSOFT International Symposium

on Foundations of Software Engineering, FSE 2014,

pages 518–529. ACM.

Ryder, B. (1979). Constructing the call graph of a program.

IEEE Transactions on Software Engineering, 5:216–

226.

Sen, K., Kalasapur, S., Brutch, T., and Gibbs, S. (2013).

Jalangi: A selective record-replay and dynamic anal-

ysis framework for JavaScript. In Proceedings of the

2013 9th Joint Meeting on Foundations of Software

Engineering, ESEC/FSE 2013, pages 488–498. ACM.

Sen, K., Sridharan, M., and Adamsen, C. Q. (2015).

Jalangi2 dynamic analyses framework for JavaScript.

https://github.com/Samsung/jalangi2.

StackOverﬂow (2018). Stack Over-

ﬂow annual developer survey.

https://insights.stackoverﬂow.com/survey/2018.

Sun, H., Bonetta, D., Humer, C., and Binder, W. (2018). Ef-

ﬁcient dynamic analysis for node.js. In Proceedings of

the 27th International Conference on Compiler Con-

struction, CC 2018, pages 196–206. ACM.

Toma, T. R. and Islam, M. S. (2014). An efﬁcient mecha-

nism of generating call graph for JavaScript using dy-

namic analysis in web application. In 2014 Interna-

tional Conference on Informatics, Electronics Vision,

pages 1–6.

Yu, D., Chander, A., Islam, N., and Serikov, I. (2007).

JavaScript instrumentation for browser security. SIG-

PLAN Not., 42(1):237–249.

Evaluation and Comparison of Dynamic Call Graph Generators for JavaScript

479
