An Architectural Blueprint for a Multi-purpose Anomaly Detection on

Data Streams

Christoph Augenstein

, Norman Spangenberg

and Bogdan Franczyk

1,2

University of Leipzig, Information Systems Institute, Grimmaische Straße 12, Leipzig, Germany

Wroclaw University of Economics, ul. Komandorska 118/120, Wroclaw, Poland

Keywords:

Neuronal Nets, Deep Learning, Anomaly Detection, Architecture, Data Processing.

Abstract:

Anomaly detection means a hypernym for all kinds of applications ﬁnding unusual patterns or not expected be-

haviour like identifying process patterns, network intrusions or identifying utterances with different meanings

in texts. Out of different algorithms artiﬁcial neuronal nets, and deep learning approaches in particular, tend

to perform best in detecting such anomalies. A current drawback is the amount of data needed to train such

net-based models. Moreover, data streams make situation even more complex, as streams cannot be directly

fed into a neuronal net and the challenge to produce stable model quality remains due to the nature of data

streams to be potentially inﬁnite. In this setting of data streams and deep learning-based anomaly detection

we propose an architecture and present how to implement essential components in order to process raw input

data into high quality information in a constant manner.

1 INTRODUCTION

Threats, anomalies and outliers are growing chal-

lenges for almost all companies. Since they occur in

every corner of operations, like in their sensor and

computer networks, or in business processes, com-

panies have to be aware of intrusions and other ab-

normal or malicious activities on many different lev-

els. According to the Oxford dictionary, anomalies

are deviations from what is regarded as normal, or

more speciﬁcally, describe events or measurements

that are extraordinary, whether they are exceptional

or not (Oxford Dictionaries, 2019). In data mining,

the term describes data objects that are not compli-

ant with the general behaviour or model of the data

(Han et al., 2011). Anomalies occur in all areas of

life, whether biology or business. Even for the latter,

there is a multitude of use cases, that are dependent

on the detection of anomalies in the behaviour of run-

ning operations. In this work we present an architec-

ture with examples from two use cases from different

areas: Operating Room (OR) Management and Net-

work Intrusion Detection. In the OR area it is nec-

essary for decision makers to know about the current

states of running interventions and possible deviations

in duration and surgical task order. For cybersecurity

e.g. in corporate networks it is important to identify

abnormal network trafﬁc to prevent attacks like denial

of services or hijacking of clients or servers. In addi-

tion, in all these – and other – cases of application,

business operations increasingly become faster with

higher demands on latest information about anoma-

lies and deviations. Hence, data streams are essential

to fulﬁl these requirements but are accompanied with

additional challenges in real-time data processing. In

these use cases, anomaly detection systems are used

to detect such deviations, each with speciﬁc character-

istics and peculiarities in terms of system components

and detection methods.

The relevance and contribution of this work for in-

formation systems research are twofold: An architec-

ture usable for a set of anomaly detection problems is

important to generate synergies in terms of functional

and technical components as well as in know-how to

ease the realization of anomaly detection applications.

This work postulates an architecture approach that is

applicable in several use cases, providing a frame-

work and set of components for multi-purpose deep

learning (DL)-based anomaly detection applications.

The corresponding research question is: How should

a generic architecture for DL-based anomaly detec-

tion be designed to support different use cases?

The reminder of this paper is structured as fol-

lows: After this introduction, section 2 provides a

brief overview of related work concerning DL-based

anomaly detection systems as well as of approaches

470

Augenstein, C., Spangenberg, N. and Franczyk, B.

An Architectural Blueprint for a Multi-purpose Anomaly Detection on Data Streams.

DOI: 10.5220/0007760404700476

In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 470-476

ISBN: 978-989-758-372-8

that try to place these approaches in architectures.

Sections 3 and 4 contain the description of our solu-

tion approach, including an architecture model as well

as implications for the realization of the approach.

This is followed by an evaluation of the artefact as

well as a discussion of the results. The paper closes

with a conclusion featuring limitations, implications

and an outlook on future research.

2 RELATED WORK

In accordance with the exploding advances in the ma-

chine learning and artiﬁcial intelligence area, a recent

trend for anomaly detection is to use DL methods to

model abnormal behaviour in data. The rise of power-

ful graphics hardware, with its ability to perform fast

matrix multiplications is a technological advancement

that brought many theoretical approaches into prac-

tice. Artiﬁcial neuronal networks (ANN) outperform

other machine learning approaches in several fash-

ions. For instance, even perceptrons, a simple type

of ANN, is capable of identifying non-linear relation-

ships in a dataset (Sadegh, 1993). Deeper nets or

DL approaches respectively, i.e. nets that have many

hidden layers are even more powerful (LeCun et al.,

2015), but used to be impractical. Another interesting

feature relevant for anomaly detection is the so called

”course of dimensionality” (Goodfellow et al., 2016,

p. 151), at which DL can tackle high dimensional data

much better than other algorithms.

Speciﬁcally in the ﬁeld of anomaly detection there

are plenty of examples also using DL like (Zhou and

Paffenroth, 2017) (deep auto encoders for feature en-

gineering), (Revathi and Kumar, 2017) (anomalies in

videos) or (Paula et al., 2016) (fraud detection). Spe-

ciﬁc to our use cases, several approaches for utilizing

ANNs were recently presented to identify relevant in-

formation for OR management. (Bodenstedt et al.,

2018) analyse multimodal sensor data of laparoscopic

surgeries to identify their states and durations with

the help of recurrent Convolutional Neural Networks

(CNN). As well, (Twinanda et al., 2018) use CNN for

surgical phase recognition based on video data.

In the intrusion detection systems area (IDS), the

disadvantages of conventional machine learning ap-

proaches are the lack of automatic feature engineer-

ing, low detection rate, and incapability of detecting

small mutations of existing attacks and zero-day at-

tacks (Diro and Chilamkurti, 2018). Thus, (Elsherif,

2018) build a DL-based IDS system using Recurrent

Neural Networks (RNN) and Long-Short term memo-

ries neural networks (LSTM). In addition, they use bi-

directional techniques to avoid sequence dependen-

cies by considering forward and backward order of

request sequences. (Doshi et al., 2018) develop a DL

pipeline that performs data collection, feature extrac-

tion, and binary classiﬁcation for DDoS detection in

IoT trafﬁc. As well, they describe a high-level attack

detection architecture for fog networks.

In strongly business process-oriented research ar-

eas like process mining, ANNs become also more

popular for anomaly detection. Especially LSTMs are

a focal point for research, e.g. (Tax et al., 2017) cre-

ate generalizable predictive process monitoring appli-

cations for remaining cycle times and future states in

running process instances with LSTMs. Others ex-

tend these methods with Natural Language Process-

ing (NLP) methods and RNN to predict future events

based on activity sequences (Hinkka et al., 2018) or

in business processes without using explicit process

models (Evermann et al., 2017). Finally, (Nolle et al.,

2018) present an autoencoder approach that works

without prior knowledge about considered processes

and anomalies to classify business events.

Since, most of these approaches in different do-

mains provide novel concepts for speciﬁc anomaly

detection systems, but lack in describing the frame-

work to embed their results in automated and pro-

ductive environments. Indeed, there are also ap-

proaches that embed architectural decisions like (Lar-

rinaga et al., 2018) for condition-based maintenance

in cyber-physical systems or (Caselli et al., 2015) for

describing a general architecture for IDS in indus-

trial settings. But most of the work in the context of

ANN’s is about architecture of the ANN’s themselves.

By contrast, we also focus on architectural aspects in

order to come up with a complete architectural solu-

tion for anomaly detection, including data ingestion,

preprocessing and model building. For instance, (Pa-

pazoglou et al., 2015) provide much more details for a

reference architecture that also includes anomaly de-

tection. For our work we do not provide a reference

architecture but one that is reusable in multiple similar

scenarios in the context of anomaly detection. Com-

parable approaches often adopted the microservice

paradigm as a basic principle in their architecture. Re-

search in the mentioned use cases provides for ex-

ample microservice-based architectures for an end-

to-end IoT architecture that is usable for IDS (Datta

and Bonnet, 2018). (Thramboulidis et al., 2018) cre-

ated cyber-physical microservices, that are reusable in

many settings in manufacturing. Additionally, (Car-

rasco et al., 2018) provide an overview of best prac-

tices and architectural hints while (Cerny et al., 2018)

compare microservices with service-oriented archi-

tectures and also emphasize the possibility of inde-

pendent deployments. Finally, (Steffens et al., 2018)

An Architectural Blueprint for a Multi-purpose Anomaly Detection on Data Streams

471

provide a solution for continuous integration & devel-

opment (CI / CD) with microservices, which is also

part of our solution approach.

3 ARCHITECTURE &

INFRASTRUCTURE

In this section we describe a multi-purpose architec-

ture for anomaly detection with focus on data streams.

The main purpose for developing such an architecture

is to process raw input data into high quality infor-

mation in a constant manner in different contexts. As

we especially focus on using ANNs and mostly DL,

there is still a high demand for training data and thus

for comfortable methods to process them. But the

same is true for many machine learning approaches

(e.g. random forest).

For this, we extracted necessary components out

of several use cases and identiﬁed abstract patterns

how to combine them. The use cases described in sec-

tion 1 vary in terms of domain, data structure, amount

and velocity of data and purpose of modelling. On

a more abstract level, it can be stated that all these

use cases can be approached using same or similar

strategies and methodologies. Thus, our purpose is

to build an architecture based on common compo-

nents and infrastructure that replaces only speciﬁc el-

ements for a certain use case. For a single use case

this might seem too much effort but data processing

pipelines are needed anyway and remain the same for

each one in principle. Thus, a multi-purpose architec-

ture allows to quickly adapt to new use cases. Based

on the use cases and by using the separation of con-

cerns paradigm (Parnas, 1972), which allows to de-

compose the overall architecture in building blocks,

four essential generic building blocks were obtained:

data (pre-) processing, model building, user interac-

tion and cross-cutting (cf. ﬁgure 1).

Cross-cutting concerns are necessary to support

managing and maintaining other components (Con-

tinuous Integration/Continuous Development), gain

access to the system (Authentication), provide Stor-

age for user-speciﬁc and use case-speciﬁc data and

allow for an abstraction of the underlying hardware

and system resources (resource management). User

interaction concerns are components, where users of

the system interact with system components. Espe-

cially, this is about Monitoring training phases and

about prediction Evaluation of the trained algorithms.

Aside from that, the module for Interactive Data

Analysis allows users to gain insights on small sub-

sets of data for experimenting with algorithms and

thus for evaluating (hyper-)parameters prior to train-

Distribution

Storage

Model Inference

Model Management

Authentication

CI / CD

Collection

Aggregation

Resource

Management

Model Training

Monitoring

Workflow

Management

Interactive Data

Analysis

Evaluation

Transformation

Figure 1: separation of concerns.

ing. Finally, the Workﬂow Management components

allows users to develop and manage data processing

pipelines based on available processing components.

Data (pre-)processing concerns include components

helping to prepare raw data in a way that they can

be fed into selected algorithms. For instance, compo-

nents such as load data from disk or interface with ex-

ternal sources (Collection), components that integrate

data from various sources, handle null values, etc.

(Aggregation) and components that provide Transfor-

mations (e.g. format conversions, decoding, cropping

or augmentations) on (raw) data. The Distribution

component acts as a kind of middleware and is re-

sponsible for ingesting data into other processing and

model building components. In particular, distribu-

tion is responsible for handling data streams within

the architecture and as such is also a special kind of

collection component. The last and most important

concern is about the model building itself. The three

components Model Training, Model Management and

Model Inference provide frameworks for training al-

gorithms, allow to store, choose and update existing

models and to put existing models into practice.

The architecture depicted in Fig. 2 provides a

high level overview of the necessary components, al-

ready described as part of the different concerns and

additionally essential data and control ﬂows between

them. There is no predeﬁned order for using the com-

ponents but basically data enters the system either by

pushing or pulling it, passes through a variety of pre-

processing steps before it is ingested into mass stor-

age and is injected into the training engine. Trained

algorithms are then checked into the model server or

directly passed to the inference engine to deliver in-

sights into the data. Things get interesting on a more

use case and technology speciﬁc view.

Each component addresses a speciﬁc piece of

functionality required by a use case pipeline. Collec-

tion, aggregation and transformation functionalities

have to be designed for these speciﬁc requirements

and thus have to be independent from each other.

The only way they are able to interact is by push-

ing data into the distribution component and the mass

storage respectively. Thus, our solution to handle

data streams is to consequently build the architecture

around streaming functionality (cf. the Kappa archi-

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

472

Mass

Storage

User

Storage

Interactive Data

Analysis

Workflow

Management

Data

Transformation

Data AggregationData Collection

Monitoring &

Evaluation

Model Server Inference Engine

Training Engine

Data Distribution

CI / CD

Authentication

Resource

Management

Data Processing

Model building

Cross

-cutting

User interaction

Use Case specific

Components

Common

Component

Dataflow

Control

flow

System border

Legend

Figure 2: architectural blueprint.

tecture (Kreps, 2014)). Unfortunately, there are some

drawbacks regarding ANN’s, which we will discuss in

section 4.2. To enforce independence of the compo-

nents we make use of the microservice paradigm and

package implemented functionality into distinct ser-

vices with a common interface. In our architecture we

use a JSON-based intermediate exchange format for

this and to annotate data with metadata. JSON is used

due to its widespread dissemination and most pro-

gramming languages already have parsers and other

utilities to easily work with it. Aside from an ar-

chitectural approach, the underlying infrastructure as

well as efﬁcient possibilities of utilizing restricted re-

sources is as important as developing necessary com-

ponents. To enable a microservice-based approach we

restrict implementation of the architecture to use a vir-

tualization based on Docker and Kubernetes. These

infrastructural components are necessary (enforcing

and leveraging microservices) but also provide ben-

eﬁts. In practice, we are able to dynamically assign

resources to dedicated components, e.g. for resource-

intensive transformation steps, while other compo-

nents can spare remaining resources. Especially, Ku-

bernetes allows us to assign specialized hardware like

graphics to dedicated components (e.g. model train-

ing). Moreover, we can beneﬁt from container reg-

istries to manage already existing preprocessing com-

ponents. To sum up, isolated components on the one

hand and a ﬂexible infrastructure allowing to quickly

adapt to resource demands on the other, enable the

realization of dynamic pipelines.

4 FROM DATA TO MODEL TO

INFORMATION

4.1 Data Processing Pipelines

By the use of these architectural components, we

describe in this section how to build processing

pipelines and hence how to apply the proposed ar-

chitecture. Processing pipelines are built with se-

lected frameworks. Currently, the implementation

supports Apache Spark and Apache Flink in the Ku-

bernetes environment. For both, one master and some

worker nodes were deployed, whereby the number

of workers is dynamically adjustable according to

the requirements. Both frameworks can be used by

implemented clients or within the interactive, batch-

oriented data analysis component or their dedicated

streaming functionalities. Apache Kafka in conjunc-

tion with Apache Zookeeper is also deployed in Ku-

bernetes and serves as the primary streaming compo-

nent. As such, it is also focal element in every pro-

cessing pipeline and helps to move data through a

pipeline with a publish-subscribe pattern. Each col-

lection, aggregation and transformation component is

derived from a basic Docker image that incorporates

client libraries and conﬁgurations for Spark, Flink or

Kafka Streams. For instance, in order to build a Flink-

based transformation component the corresponding

base image is taken and use case speciﬁc code is

added prior to the build process. The resulting image

or container respectively can then be deployed and is

An Architectural Blueprint for a Multi-purpose Anomaly Detection on Data Streams

473

added to the registry for further usage.

Aside from programmatically deﬁning data pro-

cessing pipelines, e.g. by implementing ﬁxed routes

with Kafka, the workﬂow management component in

the user interaction concern is a viable alternative for

deploying complete processing pipelines. At present,

Apache Airﬂow is evaluated for the management

component, but is subject to further investigations and

discussions. The idea behind is that, in this case,

pipelines are conﬁgured by declaring a workﬂow on

an abstract level. Airﬂow uses directed acyclic graphs

for pipeline deﬁnitions and makes use of a special Ku-

bernetes operator that is capable of starting Docker

images with a speciﬁed command. Hence, we can use

the same components as described before but the ex-

change of data happens based on mass storage, e.g.

HDFS or databases. Such a pipeline deﬁnition also

offers the ability to execute the pipeline based on a

schedule. The drawback with workﬂow management

is the current lack of support for streaming function-

ality, i.e. data streams have to be continually split into

chunks and ingested into storage.

4.2 Model Building & Management

Having deﬁned and operated processing pipelines,

use case speciﬁc data is well prepared to train the

desired models. For working with ANNs our im-

plementation at present provides Tensorﬂow, Keras,

TFLearn and to a certain extend PyTorch. Addition-

ally, we also use the implemented machine learning

algorithms from Spark and Flink. Development of net

architectures and parameterisation of algorithms like

random forests is also supported in the interactive data

analysis component so that running training jobs can

be tested in advance for error pruning. By means of

available data, a training job is triggered e.g. every

night, depending on size of dataset and complexity of

the desired model. When it is trained we deploy the

model for the speciﬁc uses case, e.g. in form of a

container (Spark or Flink) or with the help of the in-

ference engine (Tensorﬂow). As a result, we currently

obtain a use case speciﬁc model for anomaly detec-

tion, i.e. we develop distinct models based on con-

crete use case requirements. In future research this is

also subject to discussion (cf. section 6).

From a technical point of view, handling of data

streams is easy if Spark- or Flink-based models are

used because they have distinct APIs for data streams.

But, for the moment, to train ANNs, data streams

have to be broken into chunks and be fed into with

(micro-)batches. Major problems arise from typical

big data characteristics (cf. (Augenstein et al., 2017))

whereas data streams can be regarded as potentially

indeﬁnitely and thus represent big data at high ve-

locity. Although there are approaches to tackle big

data related problems, e.g. concept drift, class im-

balance or non-linearity can have a lasting effect on

model quality. Thus, we use for the approach contin-

uous monitoring and deﬁne thresholds (e.g. for accu-

racy) to spot decreasing model quality by leveraging

the monitoring and evaluation components. With this,

we have a pragmatic possibility at hand to gain infor-

mation about the quality of the models and to control

already trained models in order to adapt the model to

new or changing data.

5 EVALUATION STRATEGY

The evaluation of the proposed approach is an ongo-

ing work. For a proper evaluation, a twofold strategy

is planned, which follows the principles of design sci-

ence research artefact evaluation (Peffers et al., 2012;

Venable et al., 2016). Hence, technical experiments

will be conducted to evaluate the approach’s perfor-

mance in addition to more formative evaluation meth-

ods. As a ﬁrst step, the architecture model is mapped

on the two use cases described in section 1 to imple-

ment the components necessary to fulﬁl their func-

tional needs.

For the planning and optimization tasks in Online

Surgery Scheduling of OR management, the architec-

ture approach described in section 3 is utilized as fol-

lows. In this use case, functionalities for data distribu-

tion and storage layer are needed, which are realized

by components of Data Collection, Data Transfor-

mation and Data Distribution. The previously used

Complex Event Processing-based (cf. (Spangenberg

et al., 2017a) component for anomaly detection is re-

placed by the Model Server and the Training respec-

tively Inference Engine. These building blocks al-

low a highly automatized approach relying on ANNs

(see (Spangenberg et al., 2017b)) which reduces the

need of expert knowledge for deﬁning a hard rule-

set to identify current surgical phases as well as re-

maining intervention times. By using Spark, based

on its Kubernetes version, and an implementation of

a Multilayer Perceptron Regression algorithm (Span-

genberg et al., 2017b), a processing pipeline and a

DL-model training approach for anomaly detection

in surgical interventions was realized. The inference

component uses Kafka Streams for loading the per-

sisted DL-model from ﬁle system and processes each

detected surgical phase to infer a remaining interven-

tion time prediction based on the model. An ongoing

challenge at the moment is to ﬁnd an appropriate cy-

cle for model recomputation to avoid streaming-based

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

474

problems (cf. section 4.2).

Besides, we utilized an existing IDS approach

(Radford et al., 2018) that uses a LSTM to detect

abnormal activities and intruders in network traf-

ﬁc. The necessary transformation functionality that

extracts features from the generated network trafﬁc

maps to the Data Transformation component of the

architecture blueprint. With the help of the Interac-

tive Data Analysis component it is possible to succes-

sively identify details of the dataset and the problem.

The resulting Tensorﬂow model of the DL application

is mapped to the Training Engine to train a valid clas-

siﬁcation model for anomaly detection. This model

is ﬁnally utilized by the Inference Engine to realize

anomaly detection on network data streams in a real-

time fashion. This approach uses Word2Vec, an al-

gorithm used in NLP to create word embeddings to

classify text anomalies, as part of the preprocessing.

Based on these implementations, public datasets

for IDS (Sharafaldin et al., 2018) and artiﬁcial

datasets for OR management (Spangenberg et al.,

2017a) have been utilized and scaled to benchmark

the approach in different settings and loads. Further,

formative methods will be utilized that focus on the

outcome of the artefact for the described problems.

The resulting artefacts and implementations will be

demonstrated to domain experts to assess diverse cri-

teria for Information Systems artefacts (Prat et al.,

2015) like operational feasibility, usefulness or adapt-

ability on other contexts. The reason for this is to

identify potential consequences for further anomaly

detection use cases, e.g. to derive additional compo-

nents as architectures building blocks.

6 CONCLUSION

In this paper we presented a novel solution approach

for a multi-purpose architecture for anomaly detec-

tion. The novelty of this approach lies in a holistic

view on the overall processing of data beginning with

pushing or pulling it from source and ending with a

common representation being fed into ANNs or ma-

chine learning based algorithms. A general applica-

bility of this architectural approach is given because

of the restriction to anomaly detection and the focus

on ﬁnding a common representation of data over sev-

eral use cases. For future work our focus will be on an

exhaustive approach that also encompasses the model

learning, i.e. we also want to produce a neuronal net

architecture that is capable of uniformly handling data

from different uses cases. For this, we choose multi-

task learning (cf. (Caruana, 1997)) as a starting point.

It has already been shown that ANNs trained with dif-

ferent data for the same reason tend to provide even

better results than training multiple nets (e.g. (Yang

et al., 2018) (image captions), (Kong et al., 2018)

(sparse data), (Luo et al., 2018) (multiple domains,

text processing). For instance, transferred to our sce-

nario, we have multiple classiﬁcation problems (tasks,

one per use case) and train with different datasets in

order to receive a good classiﬁcation per use case. Be-

ing able to apply such a multi-task learner, we are still

confronted with the draw backs of (big) data streams.

A major question arises from the problems of con-

tinuous model updates. Updates usually force (re-

)training of the underlying model which might not be

applicable at all hours, so the question remains how

to adapt to fast changing data.

ACKNOWLEDGMENTS

This research was funded by the European Social

Fond ESF and the Federal State of Saxony, Germany

(100341518).

REFERENCES

Augenstein, C., Spangenberg, N., and Franczyk, B. (2017).

Applying machine learning to big data streams : An

overview of challenges. In IEEE 4th International

Conference on Soft Computing and Machine Intelli-

gence (lSCMI 2017), pages 25–29.

Bodenstedt, S., Wagner, M., M

undermann, L., Kenngott,

H., M

uller-Stich, B., Mees, S. T., Weitz, J., and

Speidel, S. (2018). Prediction of laparoscopic pro-

cedure duration using unlabeled, multimodal sensor

data. arXiv preprint arXiv:1811.03384.

Carrasco, A., van Bladel, B., and Demeyer, S. (2018).

Migrating towards microservices: migration and ar-

chitecture smells. In Ouni, A., Kessentini, M., and

Cinn

eide, M.

O., editors, Proceedings of the 2nd Inter-

national Workshop on Refactoring - IWoR 2018, pages

1–6, New York, New York, USA. ACM Press.

Caruana, R. (1997). Multitask learning. Machine Learning,

28(1):41–75.

Caselli, M., Zambon, E., and Kargl, F. (2015). Sequence-

aware intrusion detection in industrial control sys-

tems. Proceedings of the 1st ACM Workshop on

Cyber-Physical System Security.

Cerny, T., Donahoo, M. J., and Trnka, M. (2018). Contex-

tual understanding of microservice architecture. ACM

SIGAPP Applied Computing Review, 17(4):29–45.

Datta, S. K. and Bonnet, C. (2018). Next-generation, data

centric and end-to-end iot architecture based on mi-

croservices. In IEEE International Conference on

Consumer Electronics, pages 206–212. IEEE.

Diro, A. A. and Chilamkurti, N. (2018). Deep learning:

The frontier for distributed attack detection in fog-to-

An Architectural Blueprint for a Multi-purpose Anomaly Detection on Data Streams

475

things computing. IEEE Communications Magazine,

56(2):169–175.

Doshi, R., Apthorpe, N., and Feamster, N. (2018). Ma-

chine learning ddos detection for consumer internet of

things devices. pages 29–35.

Elsherif, A. (2018). Automatic intrusion detection sys-

tem using deep recurrent neural network paradigm.

Journal of Information Security and Cybercrimes Re-

search (JISCR), 1(1).

Evermann, J., Rehse, J.-R., and Fettke, P. (2017). Predict-

ing process behaviour using deep learning. Decision

Support Systems, 100:129–140.

Goodfellow, I., Bengio, Y., and Courville, A. (2016). Deep

learning. MIT Press, Cambridge, Massachusetts and

London, England.

Han, J., Pei, J., and Kamber, M. (2011). Data mining: con-

cepts and techniques. Elsevier.

Hinkka, M., Lehto, T., Heljanko, K., and Jung, A. (2018).

Classifying process instances using recurrent neural

networks. arXiv preprint arXiv:1809.05896.

Kong, Y., Shao, M., Li, K., and Fu, Y. (2018). Probabilis-

tic low-rank multitask learning. IEEE transactions

on neural networks and learning systems, 29(3):670–

680.

Kreps, J. (2014). Questioning the lambda architecture: The

lambda architecture has its merits, but alternatives are

worth exploring.

Larrinaga, F., Fernandez, J., Zugasti, E., Zurutuza, U.,

Anasagasti, M., and Mondragon, M. (2018). Imple-

mentation of a reference architecture for cyber physi-

cal systems to support condition based maintenance.

5th International Conference on Control, Decision

and Information Technologies, pages 773–778.

LeCun, Y., Bengio, Y., and Hinton, G. (2015). Deep learn-

ing. Nature, 521(7553):436–444.

Luo, Y., Wen, Y., and Tao, D. (2018). Heterogeneous mul-

titask metric learning across multiple domains. IEEE

transactions on neural networks and learning systems,

29(9):4051–4064.

Nolle, T., Luettgen, S., Seeliger, A., and M

uhlh

auser, M.

(2018). Analyzing business process anomalies using

autoencoders. Machine Learning, pages 1–19.

Oxford Dictionaries (2019). anomaly.

Papazoglou, M., van den Heuvel, W.-J., and Mascolo, J.

(2015). Reference architecture and knowledge-based

structures for smart manufacturing networks. IEEE

Software.

Parnas, D. L. (1972). On the criteria to be used in decom-

posing systems into modules. Communications of the

ACM, 15(12):1053–1058.

Paula, E., Ladeira, M., Carvalho, R., and Marzagao, T.

(2016). Deep learning anomaly detection as sup-

port fraud investigation in brazilian exports and anti-

money laundering. In 15th IEEE International Con-

ference on Machine Learning and Applications, pages

954–960. IEEE.

Peffers, K., Rothenberger, M., Tuunanen, T., and Vaezi, R.

(2012). Design science research evaluation. Design

Science Research in Information Systems. Advances

in Theory and Practice, pages 398–410.

Prat, N., Comyn-Wattiau, I., and Akoka, J. (2015). A tax-

onomy of evaluation methods for information systems

artifacts. Journal of Management Information Sys-

tems, 32(3):229–267.

Radford, B. J., Richardson, B. D., and Davis, S. E. (2018).

Sequence aggregation rules for anomaly detection in

computer network trafﬁc. CoRR, abs/1805.03735.

Revathi, A. R. and Kumar, D. (2017). An efﬁcient system

for anomaly detection using deep learning classiﬁer.

Signal, Image and Video Processing, 11(2):291–299.

Sadegh, N. (1993). A perceptron network for functional

identiﬁcation and control of nonlinear systems. IEEE

transactions on neural networks, 4(6):982–988.

Sharafaldin, I., Lashkari, A. H., and Ghorbani, A. A.

(2018). Toward generating a new intrusion detec-

tion dataset and intrusion trafﬁc characterization. In

ICISSP, pages 108–116.

Spangenberg, N., Augenstein, C., Franczyk, B., Wagner,

M., Apitz, M., and Kenngott, H. (2017a). Method for

intra-surgical phase detection by using real-time med-

ical device data. IEEE 30th International Symposium

on Computer-Based Medical Systems, pages 254–259.

Spangenberg, N., Wilke, M., Augenstein, C., and Franczyk,

B. (2017b). A big data architecture for intra-surgical

remaining time predictions. Procedia Computer Sci-

ence, 113:310–317.

Steffens, A., Lichter, H., and D

oring, J. S. (2018). De-

signing a next-generation continuous software deliv-

ery system: Concepts and architecture. 2018 IEEE 4th

International Workshop on Rapid Continuous Soft-

ware Engineering, pages 1–7.

Tax, N., Verenich, I., La Rosa, M., and Dumas, M. (2017).

Predictive business process monitoring with lstm neu-

ral networks. International Conference on Advanced

Information Systems Engineering.

Thramboulidis, K., Vachtsevanou, D. C., and Solanos, A.

(2018). Cyber-physical microservices: An iot-based

framework for manufacturing systems. In IEEE In-

dustrial Cyber-Physical Systems (ICPS), pages 232–

239. IEEE.

Twinanda, A. P., Yengera, G., Mutter, D., Marescaux, J.,

and Padoy, N. (2018). Rsdnet: Learning to pre-

dict remaining surgery duration from laparoscopic

videos without manual annotations. arXiv preprint

arXiv:1802.03243.

Venable, J., Pries-Heje, J., and Baskerville, R. (2016). Feds:

a framework for evaluation in design science research.

European Jour. of Information Systems, 25(1):77–89.

Yang, M., Zhao, W., Xu, W., Feng, Y., Zhao, Z., Chen,

X., and Lei, K. (2018). Multitask learning for cross-

domain image captioning. IEEE Transactions on Mul-

timedia, page 1.

Zhou, C. and Paffenroth, R. C. (2017). Anomaly detection

with robust deep autoencoders. In Matwin, S., Yu,

S., and Farooq, F., editors, KDD2017, pages 665–674,

New York, NY. ACM.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

476
