OULAD MOOC Dropout and Result Prediction using Ensemble,
Deep Learning and Regression Techniques
Nikhil Indrashekhar Jha
1
, Ioana Ghergulescu
2
a
and Arghir-Nicolae Moldovan
1
b
1
School of Computing, National College of Ireland, Dublin, Ireland
2
Adaptemy, Dublin, Ireland
Keywords: Dropout Prediction, MOOC, Learning Analytics, Machine Learning, OULAD Dataset.
Abstract: Massive Open Online Courses (MOOCs) have become increasingly popular since their start in the year 2008.
Universities known worldwide for their traditional confined classroom education are also changing their
practices by hosting MOOCs. These are Internet-based courses where students can learn at their own pace
and follow their own schedule. Study materials and videos are provided that can be used in a blended learning
program. Despite its many advantages, it suffers from problems such as high dropout and failure rates.
Previous studies have mostly focused on predicting student dropout. This paper contributes to the body of
research by investigating both student dropout and result prediction performance of machine learning models
built based on different types of attributes such as demographic info, assessment info and interaction with the
VLE. An analysis on the OULAD dataset showed that models based on student
achieved the high performance in terms of AUC, of up to 0.91 for dropout prediction and 0.93 for result
prediction in case of Gradient Boosting Machine.
1 INTRODUCTION
Massive Open Online Courses (MOOCs) have been
increasingly adopted and successful since their
beginning in 2008. A course that was started by
Sebastian Thrun and other members of the Stanford
on Artificial Intelligence in the year 2011 attracted
1.6 million participants from more than 190 countries.
According to Tan & Shao (2015) American
universities or colleges that started some online
course between 2008 and 2012, have maintained a
steady growth of 10-20% every year. This has
allowed them to reach the students that could not
make it to college due to geographical boundaries or
other limitations. Top universities such as MIT,
Stanford and US Berkley have opened their online
courses to a wide audience through MOOC platforms
such as edX and Coursera. According to recent
statistics by Class Central, in 2018 there were over
101 million students enrolled in more than 11400
online courses provided by over 900 universities
(Shah, 2018). The number only increases with every
passing day due to the self-paced learning scheme.
a
https://orcid.org/0000-0003-3099-4221
b
https://orcid.org/0000-0003-4151-1432
Coursera is one the most popular MOOC platform
with more than 37 million students joining courses.
Although MOOCs have become very popular in a
short time span, they also experience problems with
high student dropout and failure rates, as well as lack
of support for struggling students. The free nature of
MOOCs has resulted in many students dropping out
from the course or not being able to obtain good
grades. The dropout rate is typically 20% higher for
students who are enrolled in online courses, while for
some online courses from universities like Open
University UK and China the dropout rate was even
as high as 78% and 40% respectively (Tan & Shao,
2015). Xing & Du (2018) indicated that the dropout
rate reached up to 90% for MOOC courses, which is
considerably higher when compared to traditional
campus courses.
This paper investigates ensemble methods, deep
learning and regression techniques for predicting
student dropout and final result in MOOCs. The
analysis is done on the Open University Learning
Analytics dataset (OULAD) (Kuzilek, Hlosta, &
Zdrahal, 2017), a large complex dataset that requires
154
Jha, N., Ghergulescu, I. and Moldovan, A.
OULAD MOOC Dropout and Result Prediction using Ensemble, Deep Learning and Regression Techniques.
DOI: 10.5220/0007767901540164
In Proceedings of the 11th International Conference on Computer Supported Education (CSEDU 2019), pages 154-164
ISBN: 978-989-758-367-4
Copyright
c
2019 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
significant pre-processing and feature extraction that
was not thoroughly investigated by previous research.
The rest of the paper is organized as follows.
Section 2 presents related work on MOOC datasets
and prediction. Section 3 presents the research
methodology. Section 4 presents the evaluation
results. Section 5 concludes the paper and presents
future work directions.
2 RELATED WORK
Nowadays, many universities are using an analytical
approach to help improve the online learning,
teaching and assessment process. This section
overviews some existing MOOC datasets and
presents previous research works on MOOC learning
analytics.
2.1 MOOC Datasets
Table 1 presents a summary of existing datasets from
various MOOC platforms that were made available to
researchers and used in different learning analytics
research studies. Harvard and MIT are among main
universities that are hosting various online courses
using the edX platform and have made data available
freely to enable learning analytics research. Several
other universities such as George Mason University
and NYU Stern School of Business have also
published anonymised data to researcher for valuable
knowledge discovery.
Open University UK is the largest academic
institution in UK with around 170000 students
enrolled in different programmes. Study materials
related to the course are delivered through a VLE.
The OULAD dataset contains data from 32,592
students and 22 module-presentations, and contains
various data such as student demographic info,
assessment dates and scores, and clickstream data of
their interaction with the VLE. Other datasets such as
such as KDD Cup and XuetangX only contain data
related to the MOOC platform, but do not contain
student demographic information.
2.2 MOOC Predictions
Table 2 provides a summary of previous research
works that attempted to predict the result of the
student at the end of the course (i.e. whether the
student will pass or fail), or whether the student will
drop out or complete the course. The table
summarizes some of the machine learning models
used by the researchers and relevant evaluation
parameters provided by them.
Breslow et al. (2013) have devised a method that
uses prior knowledge, skills, and activities such as the
use of Virtual Learning Environment (VLE) and
activities of the candidate to predict the end-of-
MOOC performance of the candidate. Ashenafi,
Riccardi, & Ronchetti (2015) have used data from the
forum where students ask questions and rate answers.
Data from the peer-assessment system was also used
for predicting the result of the student.
Haiyang, Wang, Benachour, & Tubman, (2018)
have used the OULAD dataset. The data contains
records of 32593 students and the logs of their
interaction with the Virtual Learning Environment
(VLE). The clickstream data of the VLE environment
was extracted on a daily basis and time series data
frames were constructed for each of the modules. The
VLE interaction log contains more than 10 million
entries. The authors have used Time Series Forest to
predict the dropout of students. Demographic
information of the candidate was omitted from the
model to avoid ethical issues. Open University (OU)
provides resources like video lectures and some
material that a student should read in course.
Hlosta, Zdrahal, & Zendulka (2017) have made
use of the data about assignments that are submitted
by the students. The authors point out that students
who do not submit assignments have a 90% chance of
dropping out from the course. The authors have also
stressed on the previous educational background of
the student. Haiyang et al. (2018) have extracted
features form the VLE environment from the
OULAD dataset, while Hlosta et al. (2017) has used
existing features such as assignments, number of
consecutive days the student is active, average
median clicks and number of materials visited per
day. The authors also point out the specificity
problem of the OULAD dataset, which deals with the
fact that the two groups of minority and majority
students (i.e., submitting and not submitting
assessments) change over time. Hong, Wei, & Yang
(2017) pointed out that if we move back in time from
the cut-off date of an assignment, the number of
students who withdrew their enrolments
outnumbered the students submitting assignments.
Alshabandar, Hussain, Keight, Laws, & Baker
(2018) made used of assignments deadlines and the
VLE database. The authors applied a probabilistic
model which predicts at-risk students who may drop
out from the course. For feature extraction, various
VLE types are used for each student in some time
interval and combined into a single value. Other
features such as dynamic behavioural features,
OULAD MOOC Dropout and Result Prediction using Ensemble, Deep Learning and Regression Techniques
155
Table 1: Summary of existing MOOC datasets.
Citation
Dataset / MOOC
Data Description
(Haiyang et al., 2018)
OULAD
32,592 students, over 10 million rows for VLE data,
22 different courses, data available as 7 CSV files
(Hlosta et al., 2017)
(Alshabandar et al., 2018)
(Piech et al., 2015)
Khan Academy
1.4 million exercises completed by 47495 students, 69
different types of exercises
(Hong et al., 2017)
XuetangX
(OpenEdx)
course content, student enrolment, learning access log datasets
used and combined them, 120,542 samples from 39 courses
(Xing & Du, 2018)
KDD Cup 2015
39 Courses, 7 csv data files
(Qiu et al., 2016)
XuetangX
11 Completed courses of Fall 2013 and Spring 2014.
Computer Science and Electronics Engineering and non-
science courses, 56,800,000 time-stamped records
(Al-Shabandar et al., 2017)
Dataset used
from Harvard and
MIT MOOC
courses
597692 participants, 15 courses, 800,000-log file
(Liang, Li, & Zheng, 2016)
edX
39 courses
Cobos, Wilde, & Zaluska
(2017)
8 in edX and 14 in FutureLearn, total of 22 courses,
8935 enrolled learners
(Balakrishnan & Coetzee,
2013)
29882 students, 4 assignments,4 exam grades data
(Chaplot, Rhim, & Kim, 2015)
Coursera
3 Million students, 5000 forum posts
(Tan & Shao, 2015)
Open University
China
62375 students in three semesters of Fall 2010 and Fall 2011
demographic features, and different assignments
feature were used. The prediction is made through
Gaussian Finite Mixture model.
Heuer & Breiter, (2018) have also used time-
based data of OULAD dataset for predicting whether
the student will pass or fail a module. The authors
pointed out that the daily activity of the student can
be easily anonymized. According to the authors, a
binary information about a student if he/she was
active on a given day can be as meaningful as using
the sensitive private data like gender, disability, and
highest education. The authors have categorized
students based on their daily use of VLE. All different
types of activities of the VLE environment were
combined into a single metric. The metric had
dimensions equal to the number of days in a module.
Each row denotes whether the student was active on
the given day or not. The four target variables were
then limited to two for binary classification as to
whether the candidate will pass or fail. The authors
then used k-means clustering technique to group data
points which were similar. Different machine
learning models were then used to predict the result
of the candidate.
Kennedy, Coffrin, de Barba, & Corrin (2015)
have used the previous educational background of the
student as well as prior knowledge of the course and
their engagement with the VLE to predict end-of-
MOOC performance. The dataset was acquired from
the Coursera platform and courses were hosted by the
University of Melbourne. Different techniques such
as knapsack and graph colouring were used. Different
Knapsack points were derived which tested the prior
knowledge of the participants. Graph colouring tested
the problem solving related to computer science. Both
were graded between 0 to 60. Apart from these
different assignments, the number of days taken to
complete the assignment and total points scored were
used as parameters to prepare the model.
Dalipi, Imran, & Kastrati (2018) in their review
paper have mentioned that machine learning is the
easy part of the process. The key and the difficult part
is the feature selection from the huge amount of data
that is made available by the MOOC platform.
Different platforms offer data in different ways which
makes it sparse and thus has a lot of features. The
authors have studied two different MOOC datasets
and categorized them into two parts based on the
types of features available. One is student related and
the other is MOOC related. In the student related
dataset, the features are generally related to the
behavioural aspect of the student while the MOOC
related dataset has features that describe the course
and the modules. The authors also argue that even
though a lot of data is available, it still lacks features
that can accurately point out not only dropout
students but also the result of the candidates.
CSEDU 2019 - 11th International Conference on Computer Supported Education
156
Table 2: Summary of MOOC prediction research studies.
Citation
Algorithms
AUC
Accuracy
Test Split
Class Values
(Haiyang et al., 2018)
TSF
-
0.93
-
Dropout /
No Dropout
(Hlosta et al., 2017)
SVM
0.779
-
-
Dropout /
No Dropout
NB
0.678
-
XGB
0.744
-
LR
0.756
-
(Alshabandar et al.,
2018)
EDDA
0.954
0.920
-
Dropout /
No Dropout
KNN
0.951
0.911
LR
0.949
0.893
(Hong et al., 2017)
SVM
0.795
0.861
20%
Dropout /
No Dropout
RF
0.852
0.865
MLR
0.855
0.861
SVM-C
0.909
0.904
C-RF
0.932
0.927
C-MLR
0.916
0.910
(Xing & Du, 2018)
KNN
0.947
0.966
30%
Dropout /
No Dropout
SVM
0.976
0.944
DT
0.876
0.982
DL
0.984
0.974
(Li et al., 2016)
KNN
0.947
0.966
20%
Certificate
Attainment and
Grade Prediction
SVM
0.976
0.944
DT
0.876
0.982
DL
0.984
0.974
(Qiu et al., 2016)
LRC
0.809
-
From 80%
to 10%
Dropout /
No Dropout
SVM
0.709
-
FM
0.903
-
LadFG
0.962
-
(Al-Shabandar et al.,
2017)
DT
0.998
0.973
30%
Grades Prediction
RF
0.997
0.985
SVM
0.991
0.973
SOM
0.956
0.956
NB
0.987
0.962
NN
0.994
0.972
LR
0.988
0.954
LDA
0.986
0.954
(Liang et al., 2016)
GBDT
-
0.879
40%
Dropout /
No Dropout
(Cobos et al., 2017)
GBM
-
0.83
-
Dropout /
No Dropout
kNN
-
0.79
LogitBoost
-
0.81
XGB
-
0.82
(Tan & Shao, 2015)
ANN
-
0.940
30%
Dropout /
No Dropout
DT
-
0.946
BN
-
0.940
Legend: BKT Bayesian Knowledge Tracing, BLR Boosted Logistic Regression, DL Deep Learning, DRSA Dominance
Based Rough Set Approach, DT Decision Tree, EDDA - Eigenvalue Decomposition Discriminant Analysis, GBRM
Generalized Boosted Regression Model, GDBT Gradient Boosting Decision Tree, HMM Hidden Markov Model, KNN K-
nearest Neighbour, LadFG Latent Dynamic Factor Graph, LDA Linear Discriminant Analysis, LR Logistic Regression,
LSTM Long Short Term Memory, NB Naïve Bayes, NN Neural Network, RF Random Forest, RNN Recurrent Neural
Network, SOM Self-Organized Map, SVM Support Vector Machine, TSF Time Series Forest, WKNN Weighted K-Nearest
Neighbour, XGB Extreme Gradient Boosting.
OULAD MOOC Dropout and Result Prediction using Ensemble, Deep Learning and Regression Techniques
157
To overcome this Nagrecha, Dillon, & Chawla,
(2017) has used certain VLE features that are
extracted while the student was watching the course
videos. A pattern such as play, pause, rewind, forward
is observed to generate clickstream data. These VLE
recorded data was then used to extract patterns and
through visualizations, dropout of the student was
predicted on a weekly basis.
Liu & Li (2017) have taken a hybrid approach
where they used clusters to make groups of active and
non-active participants using the k-means algorithm.
Association rules are then discovered using the
Apriori algorithm. The rules discovered were then
used to predict the dropouts from the course with 80%
accuracy.
Wang, Yu, & Miao (2017) have also built a hybrid
model that combines Convolution Neural Network
and Recurrent Neural Network to predict the outcome
of the student in the course. The model is divided in
two layers. The bottom layer does the job of
convolution and pooling to extract the features in
different time periods. The upper layer then receives
the selected features and combines the information
for prediction.
Boyer & Veeramachaneni (2015) categorised
students based on the courses. The authors pointed
out that the behaviour of the participants that were
enrolled in a course in the past can be used to predict
if they will drop out in the future if they participate in
the same course as before or will go on to complete
the course. It estimates the distribution of the weights
beforehand by splitting data in 10 samples prepared
randomly from the main dataset. Then for each
sample, Logistic Regression is applied to predict the
drop out of the student.
Chaplot et al. (2015) in his work has used
clickstream data from the Coursera platform. The
data consists of three million students VLE data from
5000 forum posts. Most of the features related to
     
Sentiment analysis from the student forum platform
was used to carry out the sentiment analysis. The
score of these sentiments was extracted. The
sentiment score was marked 1 if the student is
predicted to drop out from the course or 0 otherwise.
The model was built using Artificial Neural
Networks. The downside was that the model cannot
be interpreted as it is a black box method. Moderate
results were obtained as the data was highly
imbalanced.
1
https://analyse.kmi.open.ac.uk/open_dataset
2.3 Research Gaps
In this research work, we decided to use the OULAD
dataset provided by the Open University UK. Thus,
we keep this discussion to the papers that used this
dataset in their work. Haiyang et al. (2018) in his
work has made use of time series forest, based on
three categorical values of the activity_type attribute
from the studentVle dataset. However, there are 17
more different values for that attribute that represent
different resources available. These resources were
not used in their work. It also does not use any data
from the assessment dataset.
Hlosta et al. (2017) have used both demographic
information and student interaction with the VLE
which is also used in our work. However, their work
does not use the assessment scores, and instead they
use whether the student has submitted the assessment
or not. From the data, it can be inferred that there are
18042 students who have not submitted at least one
assessment and did not dropout from the course.
Similarly, Alshabandar et al. (2018) have also
considered behavioural data of the students and
submitted assessments but not their score.
This research work complements previous studies
by investigating the performance of ensemble, deep
learning and regression techniques to predict student
dropout and result based on different groups of
attributes, specifically demographic info, assessment
scores and VLE interaction information.
3 METHODOLOGY
This research followed the Knowledge Discovery in
Databases (KDD) methodology.
3.1 Dataset Selection and Description
Table 1 presented a summary of datasets reviewed
during the data selection step. Following the review,
the decision was to use the OULA
1
dataset from Open
University UK. According to Kuzilek et al. (2017) the
type of information can be divided in three parts:
demographic, assessment, and VLE interaction. It
includes the result of the assessments submitted by
the students, while the detailed VLE clickstream data
enables researchers to engineer various features and
build     
performance during the course.
CSEDU 2019 - 11th International Conference on Computer Supported Education
158
Table 3 provides a summary of the OULAD
dataset. The dataset comes as 7 separate csv files and
requires significant processing and transformation to
extract features before building prediction models. A
student demographic information is linked with other
information segments of assessments and VLE
interactions.
3.2 Pre-processing and Transformation
This subsection details the data pre-processing and
transformation carried out before building predictive
models. Table 4 provides a summary of the dataset
after the feature extraction. Features from different
files were extracted based on three main keys that
identify a student uniquely in the entire database:
id_student, course_module, module_presentation.
The assessments data consisted of different types
of assessments submitted by students: teacher marked
assessments (TMA), computer marked assessments
(CMA) and Exam. However, only the average
assessment scores were used as predictors, while the
Exam results were excluded from the analysis.
The VLE data has information about 20 different
types of online resources. New features such as the
sum of clicks and number of visits were created for
each unique resource type based on the studentVle
data. The approach is different of previous works.
Haiyang et al. (2018) aggregated the clickstream data
for each day of the course, thus if the course was over
279 days they added 279 new features for every
student. Alshabandar et al. (2018) have also used the
sum of clicks but not for all resource types.
Table 3: Summary of the OULAD dataset before feature engineering.
Data File
No of
Records
Description
Attributes
courses
22
Information about the
courses
code_module, code_presentation,
module_presentation_length
studentInfo
32593
Contains demographic
information about the student
code_module, code_presentation, id_student,
gender, region, highest_education, imd_band,
age_band, num_of_prev_attempts,
studied_credits, disability, final_result
studentRegistration
32593
Registration of the student
for a course presentation
code_module, code_presentation, id_student,
date_registration, date_unregistration
assessments
196
Assessments for every course
presentation
code_module, code_presentation,
id_assessment, assessment_type, date, weight
studentAssessments
173740
Assessments submitted by
the students
id_assessment, id_student, date_submitted,
is_banked, score
vle
6365
Online learning resources
and materials
id_site, code_module, code_presentation,
activity_type, week_from, week_to
studentVle
1048575
Student interaction with the
VLE resources
code_module, code_presentation, id_student,
id_site, date, sum_click
Table 4: Summary of the dataset after feature engineering.
Attributes Category
Number
Attributes
Attributes
Type
Student Registration
Information
3
Student_Id, Code_module, CodePresentation
Categorical
Student Demographic
Information
6
Gender, Region, Highest_Education, IMD_Band, Age_Band,
Diability
Categorical
2
Studied_Credits, Number_of_Previous_Attempts
Numeric
Assessments
Information
3
Avg_TMA_Score, Avg_CMA_Score, Exam_Score
Numeric
Sum of clicks for each
VLE activity_type
20
Sum_Clicks_{resources, oucontent, url, homepage, subpage,
glossary, forumng, oucollaborate, dataplus, quiz, ouelluminate,
sharedsubpage, questionnaire, page, externalquiz, ouwiki,
dualpane, repeatactivity, folder, htmlactivity}
Numeric
Number of visits for
each VLE
activity_type
20
Count_Visits_{resources, oucontent, , htmlactivity}
Numeric
OULAD MOOC Dropout and Result Prediction using Ensemble, Deep Learning and Regression Techniques
159
3.3 Data Mining and Evaluation
This research work aims to investigate the
performance of the student in the course. The research
question was then broken down in two parts:
to predict whether a student will drop out from the
course.
to predict whether a student that does not drop out
will pass or fail the course.
The following machine learning classification
algorithms were considered for predicting the dropout
and final result:
Distributed Random Forest (DRF) is one of the
powerful classifications and regression
alghoritms that can be used for both multi and
binary classification types accurately. It uses an
ensemble method for learning that generates a
multitude of trees that is collectively referred to as
forest. Each of the trees in the forest is a weak
learner that is built on a different part of the
dataset provided. By combining the strengths of
different trees, the random forest algorithm can
achieve increased performance.
Gradient Boosting Machine (GBM) is used for
regression and classification problems. It also
uses an ensemble method to predict the outcome
of the variable. For classification problems it
makes use of logarithm loss function. Its strength
lies in making use of the residual patterns and use
them to train itself. These patterns in residuals
strengthen models with weak predictions.
Deep Learning (DL) is a method of training
artificial neural networks with more than two non-
output layers. It implements techniques for
learning data representations and create new
features from raw data which replaces in part the
need for feature engineering. The Deep Learning
model with feedforward neural network that is
trained with gradient descent using back-
propagation was used.
Generalized Linear Model (GLM) is a
generalization of other models that includes linear
regression, logistic regression, ANOVA, Poisson
regression, ordinal regression, log-linear models,
etc. It assumes that the outcome variable follows
an exponential distribution. GLM can be used for
different regression and classification problems.
Two approaches were used for evaluating the
performance of the machine learning models. The
first approach was 10-fold cross validation, while the
second approach was holdout method with 75% of
2
https://www.microsoft.com/en-us/sql-server/
3
https://www.r-project.org/
data used for training and 20% for validation. The
AUC (Area under the Receiver Operating
Characteristics Curve) was used to measure the model
performance. AUC captures the ability of a binary
classifier to separate between classes as the
discrimination threshold is varied, and as such it is a
more comprehensive metric as compared to accuracy
that can take different value at different threshold.
3.4 Implementation
Figure 1 illustrates the methodology from an
implementation perspective. The original dataset was
retrieved as one compressed zip from the OULAD.
The 7 csv files that comprise the raw data were
brought into the staging area of the database. SQL
Server
2
was used for data pre-processing and
transformation due to the vle file containing more
than 10 million records. Some additional tables were
created to store intermediate transformations. Data
pre-processing, transformation, and final dataset
preparation were conducted by making use of SQL
Server Management Studio (SSMS) and SQL Server
Integration Service (SSIS).
Figure 1: Implementation architecture.
The transformed dataset was imported in R
3
for
further post-processing such as feature selection. The
post-processed data is then imported in the H20
4
framework for training and validation of the machine
learning models. The performance data is extracted
and processed for visualization and presentation.
4
https://www.h2o.ai/
OULAD
Repository
Raw Data
Data
Pre-processing &
Transformation
Data
Post-processing
Machine Learning
7
CSEDU 2019 - 11th International Conference on Computer Supported Education
160
4 RESULTS
This paper investigates the performance of various
machine learning algorithms to predict whether a
student will dropout from the course, and for students
that do not dropout weather they pass or fail the
course. Table 5 summarises the number of instances
used for the two cases.
Table 5: Number of instances.
Classification
Type
Train / Cross
Validation
Instances
Validation
Instances
Dropout
24445
8149
Result
16828
5609
Four different experiments were conducted for
both dropout and result classification to assess the
prediction performance of machine learning models
built based on different categories of predictors,
specifically: demographic info, assessments scores,
VLE interactions, and all attributes. The id_student,
code_module, module_presentation and exam_score
were excluded and not used as predictors.
Table 6: Summary of evaluation experiments used for
dropout and final result prediction.
Experiment
Predictors
Category
Number Predictor
Attributes
1
Demographics
8
2
Assessment
Scores
2
3
VLE
Interactions
40
4
All Attributes
50
4.1 Dropout Prediction
Figure 2 presents the AUC performance results for
the dropout classification models. The results show
that the models created based on demographics
information achieved between 0.61 and 0.64 AUC on
the validation set. GBM and DL models have slightly
higher performance, but they tend to overfit to the
training data and more hyperparameter tuning would
be required to optimise them. As compared GLM and
DRF models had slightly lower but more stable
performance and were faster to train.
The models created based on the assessment
scores achieved over 0.82 AUC, and as high as 0.84
for GBM. The models offered stable performance for
training, validation and cross-validation.
The models based on VLE interaction features
achieved around 0.88 AUC for GLM, and 0.90 for
DL, GBM and DRF on the validation data.
The results also show that the models based on all
attributes (i.e., demographic, assessments and VLE
interactions), only achieved about 0.01 higher AUC
than the models based on the VLE interactions only.
Comparing the results to those of previous
research works that used the OULAD dataset, our
results are better than the results achieved by (Hlosta
et al., 2017), but lower than those achieved by
(Alshabandar et al., 2018). However, both of those
previous works have used temporal features and
looked at the performance of the algorithms on
various days or intervals.
4.2 Result Prediction
Figure 2 also presents the AUC performance results
for the result classification models. The results show
that the models created based on demographics
information achieved between 0.62 and 0.65 AUC on
the validation data. The GLM model had the highest
and stable performance, while the GBM and DL
models achieved the highest training AUC but would
require further optimisation.
The models created based on the assessment
scores achieved an AUC performance ranging from
0.79 in case of DRF and 0.82 for GBM, on the
validation set.
The models based on VLE interaction features
achieved around 0.90 AUC on the validation data and
offer stable performance. Moreover, the models
based on all attributes, only achieved about 0.01
higher AUC than the models based on the VLE
interactions alone.
5 CONCLUSIONS
While MOOCs have become increasingly popular
over the past decade they are facing high dropout and
failure rates. Most previous research have focused on
dropout prediction. This research investigated the
performance of ensemble, deep learning and
regression techniques to predict student dropout, as
well as if students that do not drop out will pass or fail
the course. Various models were built on different
categories of attributes (i.e., demographic info,
assessment scores, and VLE interaction data). The
analysis was conducted on the recent OULAD dataset
that was not thoroughly investigated. The results
showed that machine learning models based on
 interaction with the VLE achieved high
OULAD MOOC Dropout and Result Prediction using Ensemble, Deep Learning and Regression Techniques
161
Figure 2: AUC performance results for binary dropout (yes/no) and result (pass/fail) classification models.
0.621
0.687
0.641
0.665
0.616
0.640
0.628
0.634
0.622
0.647
0.637
0.639
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Dropout - Demographics
Cross Validation Validation Training
0.620
0.704
0.661
0.695
0.623
0.643
0.650
0.627
0.624
0.648
0.656
0.642
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Pass/Fail - Demographics
Cross Validation Validation Training
0.822
0.845
0.822
0.830
0.822
0.838
0.821
0.826
0.824
0.834
0.821
0.823
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Dropout - Assessments
Cross Validation Validation Training
0.787
0.835
0.801
0.808
0.792
0.824
0.798
0.806
0.788
0.823
0.801
0.806
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Pass/Fail - Assessments
Cross Validation Validation Training
0.896
0.914
0.883
0.910
0.898
0.899
0.881
0.900
0.899
0.901
0.882
0.895
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Dropout - VLE Interactions
Cross Validation Validation Training
0.890
0.924
0.889
0.903
0.904
0.903
0.885
0.897
0.898
0.900
0.887
0.897
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Pass/Fail - VLE Interactions
Cross Validation Validation Training
0.908
0.931
0.899
0.943
0.913
0.912
0.894
0.907
0.914
0.916
0.897
0.908
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Dropout - All Attributes
Cross Validation Validation Training
0.918
0.952
0.909
0.966
0.926
0.929
0.902
0.918
0.926
0.932
0.906
0.920
0.50 0.60 0.70 0.80 0.90 1.00
DRF
GBM
GLM
DL
AUC Pass/Fail - All Attributes
Cross Validation Validation Training
CSEDU 2019 - 11th International Conference on Computer Supported Education
162
performance in terms of AUC, of up to 0.91 for
dropout prediction and 0.93 for result prediction in
case of Gradient Boosting Machine. The results also
showed that considering student demographics info
and assessment scores along with the VLE
interactions leads to a small 0.01 increase in AUC.
This research has focused on aggregate features
and did not made use of the date attribute available
for student assessments and VLE interactions. Future
work directions would focus on feature selection and
engineering, including time based metrics related to
assessments and student interactions to improve the
dropout and result prediction performance.
REFERENCES
Alshabandar, R., Hussain, A., Keight, R., Laws, A., and
Baker, T. (2018). The Application of Gaussian Mixture
Models for the Identification of At-Risk Learners in
Massive Open Online Courses. In 2018 IEEE Congress
on Evolutionary Computation (CEC) (pp. 18).
https://doi.org/10.1109/CEC.2018.8477770
Al-Shabandar, R., Hussain, A., Laws, A., Keight, R., Lunn,
J., and Radi, N. (2017). Machine learning approaches to
predict learning outcomes in Massive open online
courses. In 2017 International Joint Conference on
Neural Networks (IJCNN) (pp. 713720).
https://doi.org/10.1109/IJCNN.2017.7965922
Ashenafi, M. M., Riccardi, G., and Ronchetti, M. (2015).

activities. In 2015 IEEE Frontiers in Education
Conference (FIE) (pp. 19). https://doi.org/10.1109/
FIE.2015.7344081
Balakrishnan, G., and Coetzee, D. (2013). Predicting
student retention in massive open online courses using
hidden markov models (No. UCB/EECS-2013-109).
Electrical Engineering and Computer Sciences
University of California at Berkeley. Retrieved from
https://www2.
eecs.berkeley.edu/Pubs/TechRpts/2013/EECS-2013-1
09.pdf
Boyer, S., and Veeramachaneni, K. (2015). Transfer
Learning for Predictive Models in Massive Open
Online Courses. In C. Conati, N. Heffernan, A.
Mitrovic, and M. F. Verdejo (Eds.), Artificial
Intelligence in Education (AIED 2015) (pp. 5463).
Springer International Publishing.
Breslow, L., Pritchard, D. E., DeBoer, J., Stump, G. S., Ho,
A. D., and Seaton, D. T. (2013). Studying Learning in
      
MOOC. Research & Practice in Assessment, 8, 1325.
Chaplot, D. S., Rhim, E., and Kim, J. (2015). Predicting
Student Attrition in MOOCs using Sentiment Analysis
and Neural Networks. In Proceedings of the Workshops
at the 17th International Conference on Artificial
Intelligence in Education AIED 2015; Volume 3:
Fourth Workshop on Intelligent Support for Learning
in Groups (ISLG) (pp. 712). Madrid, Spain. Retrieved
from http://ceur-ws.org/Vol-1432/islg_pap2.pdf
Cobos, R., Wilde, A., and Zaluska, E. (2017). Predicting
attrition from massive open online courses in
FutureLearn and edX. In Joint MOOCs workshops from
the Learning Analytics and Knowledge (LAK)
Conference 2017 (pp. 7493). Simon Fraser University,
Vancouver, BC, Canada. Retrieved from http://ceur-
ws.org/Vol-1967/FLMOOCS_Paper5.pdf
Dalipi, F., Imran, A. S., and Kastrati, Z. (2018). MOOC
dropout prediction using machine learning techniques:
Review and research challenges. In 2018 IEEE Global
Engineering Education Conference (EDUCON) (pp.
10071014). https://doi.org/10.1109/EDUCON.2018.
8363340
Haiyang, L., Wang, Z., Benachour, P., and Tubman, P.
(2018). A Time Series Classification Method for
Behaviour-Based Dropout Prediction. In 2018 IEEE
18th International Conference on Advanced Learning
Technologies (ICALT) (pp. 191195). https://doi.org/
10.1109/ICALT.2018.00052
Heuer, H., and Breiter, A. (2018). Student Success
Prediction and the Trade-Off between Big Data and
Data Minimization. In D. Krömker and U. Schroeder
(Eds.), DeLFI 2018 - Die 16. E-Learning Fachtagung
Informatik. Bonn, Germany: Gesellschaft für
Informatik e.V. Retrieved from http://dl.gi.de/handle
/20.500.12116/16955
Hlosta, M., Zdrahal, Z., and Zendulka, J. (2017).
Ouroboros: Early Identification of At-risk Students
Without Models Based on Legacy Data. In Proceedings
of the Seventh International Learning Analytics &
Knowledge Conference (pp. 615). New York, NY,
USA: ACM. https://doi.org/10.1145/3027385.3027449
Hong, B., Wei, Z., and Yang, Y. (2017). Discovering
learning behavior patterns to predict dropout in MOOC.
In 2017 12th International Conference on Computer
Science and Education (ICCSE) (pp. 700704).
Houston, TX, USA.
https://doi.org/10.1109/ICCSE.2017.8085583
Kennedy, G., Coffrin, C., de Barba, P., and Corrin, L.
(2015).     
Knowledge, Skills and Activities Predict MOOC
Performance. In Proceedings of the Fifth International
Conference on Learning Analytics And Knowledge (pp.
136140). New York, NY, USA: ACM.
https://doi.org/10.1145/ 2723576.2723593
Kuzilek, J., Hlosta, M., and Zdrahal, Z. (2017). Open
University Learning Analytics dataset. Scientific Data,
4, 170171. https://doi.org/10.1038/sdata.2017.171
Li, W., Gao, M., Li, H., Xiong, Q., Wen, J., and Wu, Z.
(2016). Dropout prediction in MOOCs using behavior
features and multi-view semi-supervised learning. In
2016 International Joint Conference on Neural
Networks (IJCNN) (pp. 31303137). Vancouver, BC,
Canada. https://doi.org/10.1109/IJCNN.2016.7727598
Liang, J., Li, C., and Zheng, L. (2016). Machine learning
application in MOOCs: Dropout prediction. In 2016
11th International Conference on Computer Science
OULAD MOOC Dropout and Result Prediction using Ensemble, Deep Learning and Regression Techniques
163
Education (ICCSE) (pp. 5257). Nagoya, Japan.
https://doi.org/10.1109/ICCSE.2016.7581554
Liu, T., and Li, X. (2017). Finding out Reasons for Low
Completion in MOOC Environment: An Explicable
Approach Using Hybrid Data Mining Methods. In 2017
International Conference on Modern Education and
Information Technology (MEIT 2017) (pp. 376384).
Chongqing, China. https://doi.org/10.12783/dtssehs/
meit2017/12893
Nagrecha, S., Dillon, J. Z., and Chawla, N. V. (2017).
MOOC Dropout Prediction: Lessons Learned from
Making Pipelines Interpretable. In Proceedings of the
26th International Conference on World Wide Web
Companion (pp. 351359). Geneva, Switzerland:
International World Wide Web Conferences Steering
Committee. https://doi.org/10.1145/3041021.3054162
Piech, C., Bassen, J., Huang, J., Ganguli, S., Sahami, M.,
Guibas, L. J., and Sohl-Dickstein, J. (2015). Deep
Knowledge Tracing. In C. Cortes, N. D. Lawrence, D.
D. Lee, M. Sugiyama, and R. Garnett (Eds.), Advances
in Neural Information Processing Systems 28 (pp. 505
513). Curran Associates, Inc. Retrieved from
http://papers.nips.cc/paper/5654-deep-knowledge-
tracing.pdf
Qiu, J., Tang, J., Liu, T. X., Gong, J., Zhang, C., Zhang, Q.,
and Xue, Y. (2016). Modeling and Predicting Learning
Behavior in MOOCs. In Proceedings of the Ninth ACM
International Conference on Web Search and Data
Mining (pp. 93102). New York, NY, USA: ACM.
https://doi.org/10.1145/2835776.2835842
Shah, D. (2018, December 11). By The Numbers: MOOCs
in 2018 - Class Central. Retrieved March 18, 2019, from
https://www.class-central.com/report/mooc-stats-2018/
Tan, M., and Shao, P. (2015). Prediction of student dropout
in e-learning program through the use of machine
learning method. International Journal of Emerging
Technologies in Learning (IJET), 10(1), 1117.
Wang, W., Yu, H., and Miao, C. (2017). Deep Model for
Dropout Prediction in MOOCs. In Proceedings of the
2Nd International Conference on Crowd Science and
Engineering (pp. 2632). New York, NY, USA: ACM.
https://doi.org/10.1145/3126973.3126990
Xing, W., and Du, D. (2018). Dropout Prediction in
MOOCs: Using Deep Learning for Personalized
Intervention. Journal of Educational Computing
Research, 0735633118757015.
https://doi.org/10.1177/07356331 18757015
CSEDU 2019 - 11th International Conference on Computer Supported Education
164
