Indirect Data Representation Via Offset Vectoring:

A Code-integrity-driven In-memory Data Regeneration Scheme

Erik Sonnleitner, Marc Kurz and Alexander Palmanshofer

Department for Mobility & Energy, University of Applied Sciences Upper Austria,

Campus Hagenberg, Austria

Keywords:

Code Security, Credential Storage, Steganography, Information Hiding.

Abstract:

A common problem in software development is how to handle sensitive information required for appropriate

process execution, especially when requesting user input like passwords or -phrases for proper encryption

is not applicable due to I/O, UI or UX limitations. This often leads to such information being either stored

directly in the source code of the application, or as plaintext in a separate ﬁle. We therefore propose an

experimental scheme for dynamically recovering arbitrary chunks of information based on the integrity of

the text-segment of a running process, without the information being easily extractible from either an on-

disk binary, memory dump or the memory map of a running process. Implementing an algorithm we call

offset vectoring, this method can help dealing with sensitive information and enhancing the resistance against

attacks which aim at extracting such data as well as attempts towards modifying an application, e.g. for the

purposes of cracking software.

1 INTRODUCTION

1.1 Handling Sensitive Data

In many cases, sensitive information (e.g. authentica-

tion credentials, cryptographic keys, etc.) is stored

directly in an application’s source code. Although

bad practice, this happens very often and even for

major brands Netgear (e.g. PSV-2018-0099), Cisco

(e.g. CVE-2018-0222, CVE-2018-0268, CVE-2018-

0271), Lenovo (e.g. CVE-2016-1491), HP (e.g.

CVE-2015-2903) and numerous others.

This may be the case either if an application needs

to authenticate to another service via a ﬁxed key, or as

a way to validate a given key or secret.

This makes it easy for an attacker to extract such

information without even running the application,

simply by analyzing the corresponding binaries us-

ing most simple and fundamental tools provided by

most Unix-like operating systems like strings(1) or

objdump(1).

Moreover, tools like Gitrob (Henriksen, 2015)

were created, being speciﬁcally designed for crawl-

ing through source-code platforms in order to search

for sensitive information like hard-coded passwords

and cryptographic private keys.

1.2 Memory Forensics

However, even in cases where strong cryptography is

used to encrypt such information, there may be sit-

uations in which implementations will show security

defects under certain conditions.

In order to given an illustrative example, con-

sider a password manager as application. A security-

aware password management software will strongly

rely on using cryptography for securing password in-

formation, in most cases based on a user-provided

passphrase, representing the master password for de-

crypting the password database.

Most of the time, e.g. in current implementations

of major browsers like Mozilla Firefox, the master

password will be asked for either upon start of pro-

cess execution or the ﬁrst time a stored password is

requested. If no additional precautions are met (e.g.

using browser extensions like Master password time-

out

), the master password will be stored in-memory

in plain-text upon decryption, and remain there until

the application is terminated (Naaktgeboren, 2015).

Subsequently, if an attacker manages to acquire

a snapshot of the current main memory process

space, it’s easily possible to extract the master pass-

See https://addons.mozilla.org/en-us/ﬁrefox/addon/

master-password-timeout/

Sonnleitner, E., Kurz, M. and Palmanshofer, A.

Indirect Data Representation Via Offset Vectoring: A Code-integrity-driven In-memor y Data Regeneration Scheme.

DOI: 10.5220/0007786703330340

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 333-340

ISBN: 978-989-758-378-0

333

word and hence all others using methods of mem-

ory forensics (Ligh et al., 2014). Acquiring mem-

ory snapshots has proven not to be too difﬁcult af-

ter all, e.g. via accessing the main memory through

/proc/kcore, accessing the process memory space

through /proc/<pid>/mem, creating software plug-

ins, forcing the application to dump core for fur-

ther analisis, or via more exotic methods like side-

channel attacks (Samyde et al., 2002) or (Zhenghong

and Ruby, 2007).

1.3 Terminology

The terminology used throughout the entire document

is listed in Table 1. In addition, whenever a new sym-

bol is introduced, it is also explicitly outlined in the

text of the corresponding section.

Table 1: Terminology.

Symbol Deﬁnition

,π

Start/end pointer in .text

segment of the process

Pointer to current byte in segment

iteration loop

[π

] Dereferencing the π

pointer

Byte for XORing π

contents

ν, |ν| Offset byte-vector & its size

σ Key byte-vector

Offset calculation for π

in σ

θ Initial offset added to π

Optional array of initialization

bytes (initialization vector)

2 RELATED RESEARCH

A related technique which tries to resemble certain

information is used in the area of application ex-

ploitation, and is called return-oriented programming

(Prandini and Ramilli, 2012) (ROP). The ROP ap-

proach was introduced after all major operating sys-

tems and CPU manufacturers started to enforce the

well known WˆX approach, shortly outlined in sec-

tion 3.1. Hereby, memory pages are either writable

or executable, but never both. In early days, when

stack and heap were both writable and executable, the

primary approach to acquire malicious code execu-

tion was to store shell code on the respective memory

areas, and redirect function return addresses to some-

where near the shell code. Even if that address isn’t

known exactly, techniques like NOP sleds can dimin-

ish such shortcomings.

As a result of WˆX, this isn’t possible anymore.

The ROP approach on the other hand, searches the

.text section of a binary to ﬁnd gadgets, short blocks

of machine code with the last assembly operation be-

ing a ret statement. Using this technique, an attacker

can search for multiple gadgets he or she needs for

executing whatever needed, e.g. to prepare registers

for a system() or execve() function call.

Regarding the use of credential information in ap-

plications, the CERN Computer Security Team has

published guidelines how to deal with such situations

(CERN Computer Security Team, 2015). In short,

the best way is always to encrypt such information,

in cases where a key is already present or can be ac-

quired. However, if this is not possible, useful alter-

natives are sparse. Hereby, CERN recommends to ex-

ternalize credentials to a separate ﬁle or a database.

Both options might not ﬁt well for certain situations,

especially if the credentials are needed prior to con-

necting to a database, or if the credentials should not

be stored in a plain-text ﬁle on the device. Even then,

these strategies would not hinder an attacker to an-

alyze externally stored information, often with even

less effort.

The offset vectoring scheme presented in this pa-

per uses the essential concept of the well-known ROP

technique and utilizes it in order to recreate sensitive

data based on such gadgets.

3 PREREQUISITES

In order to explain our proposed concept, some of

the fundamental core concepts of how Linux handles

process memory and how common modern memory

protection techniques interfere with or modify these

concepts need to be outlined, since they have a great

impact on the implementation and inner workings of

our proposal. Therefore, the following sections 3.1

to 3.3 discuss relevant prerequisites concerning (i)

process memory layout, (ii) addressing memory pro-

tection schemes, and (iii) determining .text section

start and end addresses.

3.1 Process Memory Layout

The memory layout of a running process under Linux

consists of multiple sections or segments. Most no-

tably, these sections are .text for actual machine

code, .data for initialized global or static vari-

ables, .bss for non-initialized global or static data,

.heap for dynamically run-time allocated memory,

and .stack for local variables (Erickson, 2007).

Only heap and stack are dynamic in size. More-

over, most modern operating systems enforce the

SECRYPT 2019 - 16th International Conference on Security and Cryptography

334

WˆX approach: Any section is either writable or ex-

ecutable, but never both. Depending on the operat-

ing system, this technique may also be called Data

Execution Prevention (DEP) or Stack NX/Heap NX,

and was introduced for memory protection in order to

prevent exploits from executing previously introduced

shell code on either stack or heap.

3.2 Addressing Memory Protection

Schemes

During the last decade, numerous memory protec-

tion schemes have been developed and integrated into

Linux, in order to make exploitation harder. Most

importantly for our purposes, Address Space Layout

Randomization (ASLR) was integrated (though, in a

weak form) in kernel 2.6.12 in 2005 (Gisbert and

Ripoll, 2014).

On most Linux systems nowadays, ASLR

is enabled by default. This feature can be

switched on or off at runtime, using the /proc

kernel interface. Speciﬁcally, the pseudo-ﬁle

/proc/sys/kernel/randomize va space may be

set to three possible values (Oracle Corp., 2014) to

either (i) completely disable ASLR, (ii) to randomize

the position of the stack, the virtual dynamic shared

object page (VDSO) and shared memory regions, or

to use (iii) Full-ASLR which additionally randomizes

the position of the data segment.

Randomization of memory section offsets is used

to make it harder for exploits to work, since impor-

tant memory addresses (like a function’s return ad-

dress on the stack) cannot be easily calculated in ad-

vance. However, the .text segment on which the

offset-vector technique proposed in section 4 relies,

is not affected by ASLR.

.text segment randomization cannot be gener-

ally enforced on Linux. The reason for this lies in the

creation process of ELF binaries. In order to support

ASLR with .text randomization, a program has to be

compiled as Position independent executable (PIE),

which must therefore be done at compile time. How-

ever, PIE is not used on the majority of binaries on

the most widely used Linux distributions for a variety

of reasons, explained in detail in (Gisbert and Ripoll,

2014) and does therefore not interfere with the pro-

posed technique in the ﬁrst place.

If, however, an operating system is conﬁgured to

enable full-ASLR while the ﬁnal executable is PIE-

enabled, it is possible to randomize the .text section

of running processes. Even in such a situation, we can

make use of run-time methods in order to acquire the

starting address of the .text section, using dynamic

code-offset calculation (as done in the proof of con-

cept prototype), outlined in the next section.

3.3 Determining .text Section

Start- and End-Addresses

Without further protective measures, the starting ad-

dress of the .text section is static, since it always

resides in the lowest addresses of the virtual memory

space, using a ﬁxed offset (e.g. 0x4000).

With ASLR and PIE enabled, this offset is ran-

domized. On Linux systems, we can take advantage

from the almost exclusively used GNU binutils.

Therein, the GNU linker ld takes care of exporting

a global variable

executable start, which deter-

mines the very beginning of the .text section (The

GNU Project, 2015).

The downside of using this approach, how-

ever, is limited portability and probably will not

work with other compilers and linkers, since

executable start does not comply to POSIX or

ANSI. It is still possible to acquire the start of the

.text section manually, e.g. by using C inline as-

sembly to get the EIP value at the start of the main()

function. Note, that in most executables the main()

function does not mark the actual start of .text, since

other code often precedes main(), like the .init sec-

tion or the Procedure Linking Table (PLT). However,

as long as the reference point in the code remains the

same (points to the same instruction), it is valid for

our purposes.

4 PROPOSED METHODOLOGY

4.1 A Word of Caution

We would like to propose a method suitable for situa-

tions as described in Section 1, speciﬁcally for situa-

tions where either

• user-input for using strong cryptography is not

practical for any reason, or

• developers want to make it considerably harder

for attackers to extract sensitive information, ei-

ther via analyzing process memory dumps or per-

forming reverse engineering of application bina-

ries, or

• developers want to make it harder for attackers to

modify software, e.g. in order to bypass serial

number veriﬁcation routines.

Note: The proposed mechanism is far from cryp-

tographically secure, and we are well aware that it

Indirect Data Representation Via Offset Vectoring: A Code-integrity-driven In-memory Data Regeneration Scheme

335

still can be exploited. However, the process of mem-

ory exploitation should become considerably harder.

The very same applies for many advancements in

computer security in general and memory protec-

tion schemes in particular: For instance, the intro-

duction of memory protections like ASLR, DEP/NX,

ASCII-Armoring and Memory Cookies during the

last decade have complicated things for attackers,

but do by no means provide unconditional security

and exploit prevention. Such schemes simply further

complicate attempts towards successful exploitation,

and require more specialized, complex and, in parts,

error-prone techniques (due to the use of methods like

address brute-forcing or heap-spraying to overcome

randomization).

4.2 Offset Vectoring

The proposed scheme is built upon the idea of model-

ing portions of sensitive data, or information required

for successful process execution (e.g. credentials,

passwords, keys, etc.), by referencing existing ma-

chine code byte values already present in the .text

section of a process, rather than storing it in a regu-

lar variable or memory space in the .data or .bss

sections.

For example, many software projects contain in-

formation like credentials, database passwords, API

keys, etc. Very often, these elements are hard-coded

in or directly referenced from the source-code for a

variety of reasons. Although this is considered bad

programming style, there may be cases where appli-

cable and usable alternatives are sparse. Using off-

set vectoring, a developer could get rid of plain-text

passwords in the source code, by not using a string or

character array which holds the password bytes, but

by referencing bytes already present in memory upon

process execution. The most simple approach to do

so, would be to crawl through the process-readable

memory and create a list of memory references, point-

ing to the respective byte representations of the pass-

word characters.

However, this approach has major defects. Firstly,

memory should be considered to be volatile. Writable

memory regions cannot be assumed to remain con-

stant during execution. Moreover, established tech-

niques for memory protection like ASLR will of-

ten place certain data on different memory addresses,

which renders referencing them for sensitive data un-

usable. Also, it can not be assured that all byte values

required for deconstructing a password (or, even more

problematic, a binary bitstring of a key) are actually

found in the current process memory space.

We therefore restrict memory referencing to the

.text segment of a running process only. The .text

segment is in most cases not affected by ASLR and

will remain static, even when a process is stopped and

restarted (Oracle Corp., 2014).

Beginning and end addresses of the .text section

are known either at compile time (without ASLR) or

at execution time (with full-ASLR and PIE). For fu-

ture reference, we will use the letter π for any kind

of pointer variables, while π

is referred to as the

start of the text segment, and π

as the end of the

text segment. During generation/encoding and regen-

eration/decoding phases, this segment is iterated byte-

wise from π

to π

, and started over once the end has

been reached. A pointer π

refers to the currently ad-

dressed byte during .text segment iteration, and a

variable β is used to temporarily store its content.

While π

is iterating every byte in the .text seg-

ment in a circular manner starting with π

, its value is

XOR-ed with the contents of β. Moreover, β may or

may not be initialized with one or multiple XOR-ed

values from an initialization vector to start from (both

variants are discussed in subsection 5.3).

On every iteration, the value of β is XOR-ed with

the byte π

is referencing during the current iteration.

The key σ we want to encode (e.g. a cryptographic

key, a password or any other byte vector) is split into

bytes which are processed in strict sequential order.

Once a particular byte σ

from the key vector has

been found (is equal to β after the XOR operation),

the search continues for σ

i+1

The number of iterations and XOR operations

needed to calculate the current σ

is temporarily

stored as unsigned integer in ω and added to the off-

set vector ν once found. When all elements in σ

have been processed, |σ| = |ν| and ν is returned to

the caller.

The process of creating the offset vector ν is given

in pseudo-code in Algorithm 1, the corresponding key

regeneration code is found in Algorithm 2.

The code listings of Algorithm 1 and 2 represent

the most basic form of the offset-vector technique.

More advanced features discussed in Section 5 - like

the introduction of dynamically adapted initialization

vectors - are omitted for readability, but have been

included in the proof of concept implementation pre-

sented in Section 6.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

336

Algorithm 1: Calculation of the offset vector ν.

Data: key vector σ, start offset θ

Result: offset vector ν

← start of .text section;

← end of .text section;

← π

+ θ;

β ← 0, ω ← 0;

ν ← (0);

while σ.length > 0 do

β ← β ⊕ [π

];

← π

+ 1;

if π

= π

then

← π

+ θ;

end

if β 6= σ.cur then

ω ← ω + 1;

next;

end

ν.push ω;

σ.pop;

ω ← 0;

end

Algorithm 2: Regeneration of the key vector σ.

Data: offset vector ν,

start offset θ

Result: key vector σ

← start of .text section;

← end of .text section;

← π

+ θ;

β ← 0;

while ν.length > 0 do

for i ← 0 to ν.pop do

β ← β ⊕ [π

];

← π

+ 1;

if π

= π

then

← π

+ θ;

end

σ.push β;

end

5 DISCUSSION & RESULTS

5.1 Limitations

The proposed schemes are neither intended to replace

proper handling of key or credentials, nor should they

be seen as encouragement to actually store such data

in source-code or anywhere else without proper uti-

lization of cryptographic operations.

It is intended solely for scenarios where this is not

easily possible, e.g. when requesting decryption keys

from the user is no option, or when I/O is generally

limited. Without introducing further enhancements

(as suggested in the upcoming subsection), the tech-

nique can, nonwithstandingly but with considerably

higher effort, be reverse engineered.

Also, it increases complexity in deployment and

maintenance strategies, as outlined below. Solid inte-

gration in the build process is highly recommended.

However, once integrated, the entire process can be

easily automated with no further human intervention

whatsoever.

5.2 On Effectiveness and Purpose

The main advantage of the proposed concept is, that

any chunk of information can be represented by work-

ing with data already present in the code section

mapped into memory. It is therefore not necessary

to store the corresponding offset vector in the source-

code of the executable and can alternatively be stored

or shipped externally, e.g. in text ﬁles, key stores or

in a database.

Using this technique ensures, that no modiﬁca-

tions have been made to the original on-disk binary

executable. In such a case, an attempt to decode and

reconstruct the informational chunk will almost cer-

tainly result in the data being scrambled and therefore

unusable.

Modifying an executable can be considered com-

mon practice among cracker scenes, aiming at remov-

ing, destroying or carefully modifying copy protec-

tion measures introduced by the original developers

and companies of the applications in question. In

its most careful and code-integrity-preserving form,

such a copy protection bypassing mechanism can be

accomplished by locating the machine code instruc-

tions responsible for checking the software’s validity

(e.g. a serial number), further locating the exact con-

ditional taking care thereof, and replacing this very

je assembly instruction to a jne or vice versa. Many

techniques exist accomplishing this goal, but most of

them conclude in changing the actual machine op-

codes present in the executable.

Changing one single byte will inevitably destroy

the integrity of the to-be reconstructed information,

since even small changes in a single byte value will

result in an avalanche effect for all succeeding bytes,

similar to the concept of Cipher block chaining (Bel-

lare et al., 1994) or hashing algorithms in cryptogra-

phy.

The nature of this concept also implies, that ev-

ery particular version of an executable (e.g. a build,

Indirect Data Representation Via Offset Vectoring: A Code-integrity-driven In-memory Data Regeneration Scheme

337

patch-level, etc.) must coercively use a dedicated off-

set vector in order to work purposefully. This strongly

suggests, that when using offset vectoring, it should

be integrated directly into the software build process

to automatically perform vector calculation.

5.3 Security & Usage

The offset-vector technique can be used for any kind

of data, and stored at any place, just like any other

data handled during software development. Examples

for storing the offset-vector would be in-source, in an

external text ﬁle or in a database tuple. The best lo-

cation strongly depends on the speciﬁc purpose, the

security precautions necessary, and the type of infor-

mation the technique is applied onto.

For credential keys, it is still not recommended to

store the offset-vector directly in the source-code of

the application. It will, however, signiﬁcantly exac-

erbate the effort necessary to extract the obfuscated

information. For example, deobfuscation does require

actual reverse engineering of the executable assembly,

and is not possible anymore with basic approaches

for credential and/or key extraction (e.g. string ex-

traction, determining and reading variable locations,

etc.).

In cases where user-input is applicable, it is also

possible to make use of an initialization vector for

the β variable. Although β is only of C data type

unsigned char and therefore 8 bits long on almost

all architectures and platforms, an initialization vector

may hold multiple bytes which will be XOR-ed se-

quentially before starting the actual regeneration pro-

cess by reading bytes from π

+θ. Hereby, the initial-

ization vector can represent a user- or authentication-

server-provided key necessary for successful regener-

ation.

Moreover, in order to enhance resistance to mem-

ory forensics, the regeneration function (shown in Al-

gorithm 2) should be called immediately before the

resulting, regenerated portion of information is re-

quired during process execution. It is also of high-

est importance, to securely wipe the memory space

where the deobfuscated information has been placed

temporarily – otherwise, the key vector may still re-

side somewhere in memory.

Even in cases where sensitive information is al-

ready externalized to an on-disk ﬁle and subsequently

encrypted with a user-provided passphrase, offset

vectoring can still be used with code-integrity protec-

tion in mind, as outlined above.

Moreover, the technique allows choosing an ar-

bitrary starting offset θ, which will be added to

& executable start. Depending on the size of the

.text section, θ can therefore be used as additional

(possibly secret) value necessary for successful com-

puation.

To enhance secrecy of the information obfus-

cated using the offset-vector technique, using it in

combination with Shamir’s Secret Sharing Scheme

(SSSS) (Shamir, 1979) technique could be beneﬁ-

cial, where the offset-vector obfuscated information

is only one share needed to reconstruct the secret in-

formation. Other shares could be, among others, a

BIOS/UEFI or peripheral serial number, MAC ad-

dress, or a share provided by a remote server. Since

BIOS/UEFI and other hardware serial numbers en-

code vendors and usually also target market a de-

ployment package could target, e.g., a speciﬁc com-

bination of HW and group of users. A remote server

could also generate a secret share based on the request

origin, e.g., using its IP address, making such exe-

cutable valid only for certain locations. A potential

attacker would need to invest much more effort to re-

construct a matching environment in order to retrieve

the secret. We are planning to explore this direction

further in our future work, where a secret rest-share

is computed given a secret and a set of pre-existing

shares. Only the pre-existing shares together with the

rest-share should be able to reconstruct the secret in

the same way as SSSS describes. This would sig-

niﬁcantly improve the secrecy and difﬁculty of unau-

thorized access and use of such package and actually

provide some cryptographic properties, even though

the secret-shares would be publicly reconstructible at

some point.

6 PROOF OF CONCEPT

The proposed offset-vector technique has been fully

implemented in the C programming language, ac-

cording to the speciﬁcations given during the previ-

ous sections. It has been tested on 32- and 64-bit

Linux systems, with and without memory protections

schemes which may interfere with the correct regen-

eration of the offset vector.

The source-code for the proof of concept imple-

mentation has been licensed under the General Public

License version 2, and is planned for public release

shortly. The code contains representative functions

for both, creating an offset vector for a particular, ar-

bitrarily sized, given chunk of information on the one

hand, and recreating that very information based on

a given offset vector θ and an optional initialization

vector.

Considering production environments, it is recom-

mended not to include both, the obfuscation and the

SECRYPT 2019 - 16th International Conference on Security and Cryptography

338

regeneration algorithm into one executable. The most

direct way would be to generally include the regener-

ation function into the software using it, and use the

obfuscation mechanism only during the build process

in order to create the offset vector. It’s in the responsi-

bility of the developers to decide, how the offset vec-

tor itself, once created, is handled and stored.

The implementation uses dynamic code-offset

calculation as described above, providing support for

full-ASLR and PIE.

Experiments have been made with multiple dif-

ferent binaries, ranging from very small .text sec-

tions (almost exclusively containing the regeneration

code, about 2200 bytes of machine code) to rather

large .text sections (e.g. the Evince PDF viewer

with about half a million bytes of machine code in

memory) with no signiﬁcant impact on runtime. The

average value of ω (π

increments per byte in σ) was

272.89, just above the maximum number of values a

byte can represent. This difference is due to certain

bytes occurring in machine code very often, while

other bytes are potentially sparse.

./ text - off set - xor create " MY S E C R ET "

[ INFO ] PIE : 1 , DEP : 1 , ASLR : 2 ( f u ll )

[ INFO ] . text starts at 0 x55f8 6 2 e7 7 6 b 0

[ INFO ] . text ends at 0 x55 f 8 62e 7 8 9c5

[ DEBUG ] [#0001 = 0 x4d @ 2612]

[ DEBUG ] [#0002 = 0 x59 @ 223]

[...]

[ DEBUG ] [#0007 = 0 x45 @ 120]

[ DEBUG ] [#0008 = 0 x54 @ 1060]

[ INFO ] O f f s e t map : 8 , 2612 , 223 , 98 ,

168 , 143 , 66 , 120 , 1060.

Listing 1: The calculation of an offset vector from an exe-

cutable.

Listing 1 provides the calculation of the correct

offset vector for a given binary and a given secret to

embed. The secret is given directly via the command

line is not necessarily restricted to be an ASCII string.

After generating the offset vector, it can either be

embedded into the binary in order to be able to recre-

ate the secret by itself (implicit vector inclusion), or

stored somewhere else and provided only after certain

conditions are met.

./ text - offset - xor r e g e n

[ INFO ] PIE : 1 , DEP : 1 , ASLR : 2 ( f u ll )

[ DEBUG ] Rec o v e r ed b yte : 4d

[ DEBUG ] Rec o v e r ed b yte : 59

[...]

[ DEBUG ] Rec o v e r ed b yte : 54

Rec o n str u c ted ASCII ke y : < MYSECRE T >

Listing 2: Reregenating a previously embedded secret with

implicit offset vector inclusion.

Listing 2 regenerates the secret using the previ-

ously embedded offset vector directly from the exe-

cutable itself. In this prototype, the offset vector is

created based on the offset vector calculation binary

itself. It can, of course, be also caculated for any other

executable.

7 CONCLUSION AND FUTURE

WORK

We have presented a scheme for generating pre-

deﬁned chunks of arbitrary information of variable

length via the actual machine code of a running pro-

cess using an offset vector. While offset vectoring is

no silver bullet for the common key-storage problem

of applications, it can be used under certain situations

to improve exploitability resistance, hide the informa-

tion in question from appearing in an executable and,

if applied correctly, the process memory map.

It does not interfere with modern memory pro-

tection techniques, can be easily automated and in-

tegrated in an existing build process, and can help to

ensure the integrity of shipped binaries. This can also

enhance the resistance against attempts to crack soft-

ware, or extract valuable information thereof.

Augmenting the existing prototype with an imple-

mentation of Shamir’s secret sharing scheme (Shamir,

1979) could enable a multi-part architecture where

the recoverable secret is only one of several different

parts needed.

Moreover, the offset vector itself does not nece-

sarrily need to be included in the executable directly.

It can also be utilized as an authentication vector only

given to the client once certaion conditions are met

(e.g. payment has been successfully done).

Another approach would be to scatter multiple off-

set vectors across different binaries (executables and

software libraries) of a given software product in or-

der to generate the ﬁnal secret whereas the integrity of

all different ﬁles must therefore be intact. Once again,

considering this approach, the Shamir secret sharing

scheme would be suitable in such a way that a certain

number of binaries must be present and unaltered in

order to regenerate a secret.

The given implementation has only been devel-

oped to work on x86 systems using the Linux oper-

ating system. Other than that, future work may in-

clude an implementation for several other architec-

tures, whereas especially ARM and MIPS seem of in-

terest due to the high number of devices being built

on these architectures on the one hand, and the fact

that many of them show limits regarding user interac-

tion (e.g. home routers and WiFi access points). Fur-

Indirect Data Representation Via Offset Vectoring: A Code-integrity-driven In-memory Data Regeneration Scheme

339

ther development regarding other operating systems

is also considered to be a favorable goal in the near

future.

Considering multiple binaries running simula-

neously and communicating with each other over a

network connection, a valid offset vector and rere-

genated secret could be used as starting point for mu-

tual trust without user interaction.

ACKNOWLEDGEMENTS

This research paper and all corresponding source code

developments are a result of the Research Group for

Secure and Intelligent Mobile Systems (SIMS).

REFERENCES

Bellare, M., Kilian, J., and Rogaway, P. (1994). The secu-

rity of cipher block chaining. In Annual International

Cryptology Conference, pages 341–358. Springer.

CERN Computer Security Team (2015). How to keep

secrets secret. alternatives to hardcoding passwords.

CERN.

Erickson, J. (2007). Hacking - the art of exploitation 2nd

ed. No Starch Press.

Gisbert, H. and Ripoll, I. (2014). On the effectiveness of

full-aslr on 64-bit linux. International In-Depth Secu-

rity Conference Europe (DeepSeC), Vienna.

Henriksen, M. (2015). Gitrob: Putting the Open Source in

OSINT. xx.

Ligh, M., Case, A., Levy, L., and Walters, A. (2014). The art

of memory forensics: Detecting malware and threats

in Windows, Linux, and Mac memory. John Wiley &

Sons.

Naaktgeboren, A. (2015). Change the expiration of mas-

ter password probes to never expire. Mozilla Firefox

Source Code, changeset edd395471638.

Oracle Corp. (2014). Oracle linux security guide for release

6 – conﬁguring and using kernel security mechanisms.

Oracle.

Prandini, M. and Ramilli, M. (2012). Return-oriented pro-

gramming. IEEE Computing Society, Journal for Se-

curity & Privacy, Vol. 10, No. 6.

Samyde, D., Skorobogatov, S., Anderson, R., and J., Q.

(2002). On a new way to read data from memory. First

International IEEE Security in Storage Workshop.

Shamir, A. (1979). How to share a secret. Commun. ACM,

Vol. 22, No. 11, pp. 612–613.

The GNU Project (2015). Gnu linker ld documentation (gnu

binutils) version 2.25. GNU.

Zhenghong, W. and Ruby, B. (2007). New cache designs for

thwarting software cache-based side channel attacks.

Proceedings of the 34th Annual International Sympo-

sium on Computer Architecture, New York.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

340
