ShinyAnonymizer: A Tool for Anonymizing Health Data

Marios Vardalachakis

1,2

, Haridimos Kondylakis

1,2 a

, Lefteris Koumakis

1,2 b

Angelina Kouroubali

1 c

and Dimitrios G. Katehakis

1,3 d

Computational Biomedicine Laboratory, FORTH-ICS, Heraklion, Crete, Greece

Department of Informatics Engineering, Technological Educational Institute of Crete, Greece

Center for eHealth Applications and Services, FORTH-ICS, Heraklion, Crete, Greece

Keywords: Personal Health Data, Security, Privacy, Data Anonymization.

Abstract: Processing and managing sensitive health data requires a high standard of security and privacy measures to

ensure that all ethical and legal requirements are respected. Data anonymization is one of the key technologies

to this purpose. However, the plethora and the complexity of the available anonymization techniques make it

difficult for a non-expert to select and apply the appropriate technique. In this paper, we report on Shiny

Database Anonymizer, a tool enabling the easy and flexible anonymization of available health data, providing

access to state of the art anonymization techniques, incorporating also multiple data analysis visualization

paradigms. In addition, a number of encryption and hashing techniques are presented.

1 INTRODUCTION

In recent years, various health and medical

institutions have collected a large quantity of medical

data through their Electronic Health Records (EHRs)

(Katehakis et al, 2011). If used effectively, these data

can help acquire new knowledge for disease

prevention, enabling also optimal decision-making

(Schaller et al., 2016). Distributed health care systems

consist of patient data and knowledge from health

care institutions. Meaningful knowledge can be

extracted from medical data which can be shared with

other institutions to achieve knowledge

interoperability among different heterogeneous

health care systems (Kouroubali et al, 1997;

Katehakis et al, 2017).

To this direction, data availability and sharing

have become core elements in biomedical and

healthcare research (Kondylakis et al., 2015d;

Maniadi et al., 2013). However, patient data usually

include sensitive information about personal history,

diagnoses and medications (Kondylakis et al., 2015a).

Multiple regulations and laws have been established

worldwide in order to protect the privacy of

https://orcid.org/0000-0002-9917-4486

https://orcid.org/0000-0002-8442-4630

https://orcid.org/0000-0002-3023-8242

https://orcid.org/0000-0002-3763-191X

individuals. A recent example in the European Union

is the General Data Protection Regulation (GDPR)

that came into force in 25 May 2018. The GDPR

regulates sensitive data access and establishes

measures for ensuring the privacy of patients when

sharing medical data. A key technology to ensure data

privacy is data anonymization using available

anonymization techniques. Anonymization of data is

needed in order for third parties to use patient

information without compromising confidentiality.

The information is anonymized in such a way that the

characteristics of the data remain while the anonymity

of personal identify of the person is preserved. A

typical use case is the knowledge extraction from

medical data (Berman, 2002) and the corresponding

secondary usage (Kondylakis et al, 2016). The first

and most important step of clinical data mining is the

seamless data integration (Potamias et al., 2005) in a

way that privacy is preserved (Aggarwal and Philip,

2008).

While anonymization is an important process for

protecting privacy, the available tools allowing non-

expert users to anonymize available data are limited.

These tools are often not user-friendly enough while

Vardalachakis, M., Kondylakis, H., Koumakis, L., Kouroubali, A. and Katehakis, D.

ShinyAnonymizer: A Tool for Anonymizing Health Data.

DOI: 10.5220/0007798603250332

In Proceedings of the 5th International Conference on Information and Communication Technologies for Ageing Well and e-Health (ICT4AWE 2019), pages 325-332

ISBN: 978-989-758-368-1

325

they require a deep understanding of the

corresponding algorithms. These facts limit their

practical application. This paper focuses on current

research activities related to the implementation of a

tool for Anonymizing Health Data called

ShinyAnonymizer. ShinyAnonymizer is able to

connect to various databases, enabling non-expert

users to easily select data from remote databases and

then by using a point and click graphical interface, to

anonymize the data with a plethora of available

methods.

ShinyAnonymizer offers a wide range of available

algorithms, explained for non-expert users in a non-

technical language using examples, ensuring the

usage of state of the art confidentiality models that

mitigate attacks and privacy breaches. More

specifically, ShinyAnonymizer supports a

combination of the following privacy models:

 Anonymization privacy models (removing

information, suppression, generalization,

bottom and top coding)

 Hashing privacy models (md5, crc32, sha512,

xxhash64)

 Encryption privacy models (Des, X-Des, Aes-

512, blowfish)

In addition to multiple methods for privacy, the

system also provides multiple data analysis

visualization paradigms and statistics such as pie

charts, bar charts, area charts, histograms and scatter

plots.

ShinyAnonymizer uses well known and high

productive anonymization algorithms and

implements a carefully selected set of techniques that

can handle a large spectrum of data anonymization

tasks while being productive and easy to understand.

Finally, ShinyAnonymizer provides a stand-alone

software library that can be easilty integrated and

used into other systems. In addition, it is extendable

to many more algorithms, is well-tested and carefully

documented. Therefore, ShinyAnonymizer provides

a robust environment for developing novel privacy

models.

The whole platform has been developed in the

context of iManageCancer EU project

(http://imanagecancer.eu/) for empowering cancer

patients. The project aims to build an advanced,

standards-based and scalable semantic integration

environment (Kondylakis, et al., 2017), enabling

seamless, secure and consistent bi-directional linking

of clinical research and clinical care systems, which

among others, will empower patients to extract the

relevant data out of the overwhelmingly large

amounts of heterogeneous data and treatment

information (Kondylakis, et al, 2015b; Kondylakis et

al, 2015c). For enabling research organization to

analyze health data of the patients willing to share

their anonymized data, by signing the necessary

consent form (Kondylakis, et al, 2017) the

ShinyAnonymizer is used to preprocess the available

data before enabling data analysis on them

(Koumakis, et al, 2018). Fields like name, surname

and address and other fields that could lead to leakage

of personal information by reasonable means are

anonymized, whereas data transmission among the

various components of the framework are encrypted

before being transferred.

The rest of this paper is structured as follows:

Section 2 presents the ShinyAnonymizer workflow

and architecture, describing in detail also the

available components, and section 3 provides a

walkthrough of the tool. A comparison with related

tools is presented in Section 4. Finally, Section 5

concludes this paper and presents directions for future

work.

2 SHINYANONYMIZER

WORKFLOW AND SYSTEM

ARCHITECTURE

2.1 Workflow

ShinyAnonymizer is targeted for domain experts who

will anonymize data with the help of an IT person.

The workflow consists of four steps as shown in

Figure 1. The figure shows the process of

anonymization and its alternatives. Our work aims at

making data anonymization attractive to a broad

range of end-users that might not have expertise in

anonymization techniques. We decided to implement

different algorithms that are intuitive to non-expert

users and that can be easily configured.

Figure 1: System Workflow.

The first step of the workflow involves

connection, retrieval and visualization of already

existing data stored in external databases, excel and

ICT4AWE 2019 - 5th International Conference on Information and Communication Technologies for Ageing Well and e-Health

326

CSV files and others. ShinyAnonymizer supports the

connection to most of the existing relational databases

and file formats, accessible using various scripts of

the R programming language. In each case, only the

appropriate connection parameters should be defined

and then the ShinyAnonymizer is able to connect to

the appropriate data source in order to retrieve and

process the available data.

The second step is to visualize the available data,

enabling the active exploration of the available

information. The users can select the fields to be

further processed and can experiment with the

available privacy models.

In the third step, the users can select among many

different algorithms for encryption, hashing and

anonymization.

Finally in the fourth step, the users are able to

perform several analytic tasks in order to check the

information available after the application of the

various privacy models.

2.2 System Architecture

In order for the aforementioned workflow to be

executed, a three-layered architecture has been

designed and implemented, consisting of the

Graphical User Interface (GUI), the Privacy models

and the Data Source Application Programming

Interfaces (APIs), as depicted in Figure 2. Detailed

description of each one of those layers is provided

below.

2.2.1 The GUI

The top layer of the ShinyAnonymizer system is the

graphical user interface which is the front-end of the

Figure 2: System Architecture.

whole system. It is a web application using multiple

graphs and visualization techniques for enabling data

exploration and for visualizing the result of the

various privacy models that are applied to the data.

This layer has been implemented using HTML,

JavaScript and CSS over the Shiny R package (Team,

2014). A screenshot of the GUI is shown in Figure 3.

After configuring the connection to an external data

source, the data are transformed and stored in an

internal PostgreSQL database. Then the user is

presented with a tabular view of the data which enable

the active exploration of the various data fields and

the identification of the data to be anonymized,

encrypted or hashed.

Figure 3: The GUI of the system.

Before and after the application of the various

privacy models, data exploration is available in

tabular format and in the following visualization

charts:

 Pie Chart: The pie chart shows the data as

sectors from a circle and is accordingly useful

for displaying data as total parts. Pie charts are

separated into sections to present the values of

different sizes.

 Bar Chart: The Bar chart displays the data

differences in length according to their value.

Usually it shows a comparison between several

sets of data.

 Histogram: The histogram chart usually

describes the data as continuous lines that pass

through points defined by their items and

values. As the histogram uses colors to desplay

different areas, it is useful for emphasizing

changes in values from several sets of similar

data. A colored background helps visualize the

differences clearly.

 Area Chart: Area charts are also called space

graphs and are used to show graphical

ShinyAnonymizer: A Tool for Anonymizing Health Data

327

representation of quantitative data. They

display data in leap Areas.

 Scatter Plot: The scatter plot chart displays the

data as points with coordinates and size

determined by their item values. A bubble chart

is useful for visualizing different scientific

relationships.

Summary statistics are also presented to the user

summarizing data ranges and diversity of the various

columns, offering useful insights on the quality and

the size of the available data.

2.2.2 The Privacy Models

In this layer, multiple algorithms are available for

hashing encryption and anonymization. All

algorithms have been implemented in R. Encryption

is a technique of scrambling the data in order to

remove sensitive information. The available

encryption methods in our system are the following:

 DES: It is one of the most widely accepted

publicly available cryptographic systems

today. It uses a 56-bit key to encrypt the 64 bit

block size data. It processes 64-bit inputs into

64-bit cipher-text and algorithm performs 16

iterations (Kaur et al, 2016).

 X-DES: is similar to DES. Its power can be

increased using the Galois Fields. By

increasing the size of the data structure and the

length of the encryption key at least two times

we can stop simple cryptographic attacks like

brute force attacks etc. (Luminita et al, 2017).

 AES-512: has been one of the more powerful

security protocols. This is because it uses

higher length key sizes such as 128,192,256

and now 512 bits for encryption. This makes

the algorithm more powerful to avoid

cryptographic attacks and also it is faster than

other state of the art algorithms available

(Abidalrahman et al, 2011).

 Blowfish: As DES and Extended DES need

significant processing power for execution,

they have been replaced by the Blowfish

algorithm. Blowfish algorithm is one of the

fastest block ciphers in general use, except

when changing keys. Each new key requires

preprocessing equivalent to encrypting 4

kilobytes of text which is very slow compared

to other block ciphers (Schneier, 1993).

Besides encrypting the available data, there are

also methods for data anonymization. An

anonymization algorithm use special operations to

appropriately hide the personal identity of the

available data. Multiple techniques have been

implemented to this direction as well.

 Fake Data: This technique is used to derive

massive amounts of fake data in the appropriate

fields. Multiple functions are employed able to

generate names, addresses, email, various

dates, coordinates, telephone numbers etc. The

end-user is able to select the specific field and

the type of the random data to be generated.

 Replace Characters by Random Letters and

Numbers: This technique is used with the

purpose to protect selected fields by replacing

factor and character fields by a combination of

random sampled letters and numbers. Numeric

columns can be transformed as well. The

implemented algorithm generates 5-digits long

character string by default for a selected

column but it can be configured to generate

larger codes as well.

Besides encrypting and anonymizing data, in

many cases, it is important to guarantee that data

reach their destination in their original form as sent

by the sender or that they are coming from an

authenticated/trusted source. Hashing functions are

commonly used to this purpose. They can also be

used as special mathematical functions that convert a

numerical value into another compressed numerical

value. The input to the hash function is an arbitrary

length but the output is always of a fixed length. In

addition an additional input is usually added to the

plain message before hashing also known as salting

to enhance the quality of the output. Values returned

by a hash function are called message digest or simply

hash values. Using a hash function, the input cannot

be deciphered by knowing the hash function and the

output, unless every possible input is tried. For this

reason, it is considered a safe method for data

protection. The available hashing methods in our

system are the following:

 MD5: Generates a message digest of fixed 128

bits and it takes 64 rounds. It was created in

1992.The goal of MD5 is to produce digest that

seems to be random. It is ordinarily used to

audit the integrity of data and it is also

introduced as a 32-digit hexadecimal number.

Finally, it provides a fingerprint of a message

of arbitrary length (RFC 1231, 1992).

 SHA512: MD5 is recent and common. That

means that there exist a lot of methods for

attacking MD5 (e.g. rainbow table attacks).

SHA512 is similar to MD5 with one difference:

SHA512 is better for security and has relative

fewer attacks than MD5 (SHA-2, 2018).

ICT4AWE 2019 - 5th International Conference on Information and Communication Technologies for Ageing Well and e-Health

328

 CRC32: CRC32 uses a fewer bits and can

correct one bit errors. This is considered as an

advantage against other algorithms for better

protection of the data. Finally, the usage of

systematical circular codes encodes the

message by adding a fixed length check value

for the scope of error detection (Peterson and

Brown, 1961).

 XXHASH64: It is a fast hashing algorithm but

writes only a few bytes (Templ et al, 2015).

It is important to note that the system is easily

extensible to use more encryption, anonymization and

hashing algorithms. It is only a matter of providing a

new function call for enabling the usage of a new

privacy model.

Besides hashing the available data, there are also

methods for data anonymization. An anonymization

algorithm uses special operations to appropriately

hide the personal identity of the available data.

Multiple techniques have been implemented to this

direction as well.

 Suppression: It replaces a quality value with

the special symbol "*".

 Removing Information: A quality value is

replaced with a sequence of numbers that

ranges for example from 1 to 469 (total number

of observations).

 Generalization: This technique replaces

quality values with semantically unvarying less

special values hiding the details of attributes.

 Bottom Coding: It is an exposure constraint

technique that includes limiting the minimum

worth of a variable allowed on the file to

prevent exposure of individuals or other units

with extreme values in a delivery.

2.2.3 Data Source APIs

This layer includes multiple APIs foe enabling

connection to external data sources such as relational

databases and CSV and excels files. In addition, the

appropriate REST function calls and the

corresponding API are available for

programmatically retrieving data from external data

sources and applying multiple encryption,

anonymization and hashing functions.

3 A WALKTHROUGH TO THE

SHINYANONYMIZER

SΑ has been used for applying privacy models to

iManageCancer patient data to properly anonymize

them. However, for building the system and for

demonstration purposes we are using a chimerical

patient database found online (EmrBots, 2018) that

consists of 100 patients, 372 admissions and 111,483

lab observations. These data are available as CSV

file. By selecting the file location, automatically the

data are imported into a PostgreSQL database and the

different privacy models can now be applied and

configured.

The GUI consists of six tabs that can be navigated

using the top navigation bar. Table 1 gives an

overview and description of the tabs in the GUI.

Table 1: Overview of screen tabs in the ShinyAnonymizer

Application.

Tab

Functionality

Raw Data

Load and prepare the dataset

Encrypted Data

Encryption Methods

Anonymized Data

Anonymized Methods

Hashing Data

Hashing Methods

Visualized Data

Visualized techniques

Statistics Data

Statistics

The Raw Data tab provides basic information of

the available data, showing the various tables and

fields available and enabling a basic search over the

data.

After loading the data, the user can navigate to the

Encrypted Data tab to select the encryption methods

to be applied. There are specific tabs for each one of

the implemented algorithm (Blowfish, AES-512,

DES and X-DES) and the user can select the column

for the corresponding algorithm to be applied. The

application for each algorithm has been

preconfigured, however, the user can set further

parameters (e.g. for the Blowfish Algorithm). For

each case, short explanations are provided for the

non-expert user, when clicking to the corresponding

algorithm name. Through the Anonymized Data tab,

the user is able to apply anonymization algorithms

(fake data, random letters and numbers).

Hashing Algorithms can be used by selecting the

Hashing Data tab. By selecting the Visualized Data

tab, the available functions for data exploration, are

available. As such pie charts, histograms, mosaic

plots and some summary statistics can be used.

Finally, a summary of the available data is

presented through various statistics on each field such

as the number of patients, the min, median, mean and

max for various fields, the types of the various fields

etc.

ShinyAnonymizer: A Tool for Anonymizing Health Data

329

4 COMPARISON WITH

EXISTING WORKS

There are already many approaches providing data

anonymization as open source tools. To our

knowledge, the most well-known ones are the

Sdcmicro, the Anonymizer and the ARX. These are

described below.

Sdcmicro (Templ, et al., 2015) aims to protect the

data from unauthorized users. It focuses on

anonymizing data from statistical agencies and other

institutions that are mostly confidential and can be

used for the production of anonymized (micro) data,

i.e. for the construction of public- and scientific-use

files. In addition, various risk assessment methods are

included. Sdcmicro borrows techniques from other

fields. For example multivariate statistics are used to

change or affect constant variables and to quantify

information loss. In addition to the anonymization

methods implemented in the Sdcmicro package, an

inclusive set of risk and utility measures are also

provided. Finally, it includes functions to measure,

visualize and compare risk and utility throughout the

anonymization process.

Another anonymization software, called

Anonymizer (Hendricks, 2015) mostly permits users

to rapidly and easily anonymize data containing

Personally Identifiable Information (PII) through

“convenience functions”, i.e. using a combination of

salting and hashing.

Table 2: The main characteristics of the open source

anonymization tools.

Anonymization

Methods

Hashing

Methods

Encryption

Methods

SDCMicro

K-anonymity

I-Diversity

Randomization

Adding noise

Rank swapping

recording

The

Anonymizer

Fake data

SHA256

CRC32

ARX

K-anonymity

I-diversity

t-closeness

differential

privacy

Shiny

Anonymizer

Fake Data

Randomization

SHA512

MD5

CRC32

XXHASH64

DES

X-DES

AES-512

BLOWFISH

Yet another system for data anonymization is

ARX (Abidalrahman, et al. 2011) aiming at providing

scalability and usability. It supports also various

anonymization techniques, methods for analyzing

data quality and re-identification risks. In addition, it

supports well-known anonymization methods such as

k-anonymity, I-diversity, t-closeness and differential

privacy. Table 2 elaborates on the key characteristics

of those tools.

Similar to the aforementioned systems, we argue

that multiple anonymization techniques should be

combined and used as a single technique is not always

optimal for a specific scenario. Anonymization,

hashing and encryption models can be effectively and

efficiently combined to ensure protection of the data

from unauthorized usage. However when combining

multiple state of the art algorithms, an optimal

workflow should be provided with explanations and

guidelines showing also examples of each

transformation to the available data. Furthermore they

should be complemented by at least a basic analytics

framework enabling the active exploration of the

available data. To the best of our knowledge

ShinyAnonymizer (Shiny Anonymizer) is the only

system enabling non-expert access to multiple

privacy models, in a user-friendly manner, combining

privacy with data exploration, offering multiple

exploration options through a rich set of data analysis

graphs.

5 DISCUSSION & CONCLUSION

This paper focused on the implementation of a tool

called ShinyAnonymizer (Shiny Anonymizer) which

offers multiple privacy models that can be applied on

existing data, by non-expert users. The most well-

known encryption, hashing and anonymization

techniques have been implemented.

In addition, preliminary usage of the system

within the iManageCancer project has shown that the

system is reliable and can provide a vast amount of

options to experts that are able to quickly select the

appropriate fields to be anonymized. The tool is going

to be released soon as open source in order to enable

further real life usage.

However, having a tool like the one proposed

might create a false sense of privacy, as eventually the

domain experts should be trained and select the

appropriate fields to be anonymized. To this task we

envision that an IT expert will guide the domain

expert at least the first times that the tool is used,

explaining him the data view and the various options

available.

ICT4AWE 2019 - 5th International Conference on Information and Communication Technologies for Ageing Well and e-Health

330

As more technologies emerge like the block-

chain, the internet of things and the artificial

intelligent technologies, anonymization and

encryption of data become more important than ever.

Future work will aim on further development of the

tool implementing new anonymization algorithms,

testing different types of data, comparing the

effectiveness of each implemented algorithm and

linking the anonymization tool with the analytics

framework (Koumakis, et al., 2018).

ACKNOWLEDGEMENTS

Work reported in this chapter was partially supported

by the European Union’s Horizon 2020 research and

innovation programme under projects

iManageCancer (“Empowering patients and

strengthening self-management in cancer diseases”,

grant agreement No 643529, http://imanagecancer.eu

), Bounce (“Predicting Effective Adaptation to Breast

Cancer to Help Women to BOUNCE Back”, grant

agreement No 777167, https://www.bounce-

project.eu), and MyPal (“Fostering Palliative Care of

Adults and Children with Cancer through Advanced

Patient Reported Outcome Systems”, grant

agreement No 825872, http://mypal-project.eu/).

REFERENCES

Abidalrahman, M., Jararweh, Y., Tawalbeh, L. (2011) AES-

512: 512-bit Advanced Encryption Standard algorithm

design and evaluation.Information Assurance and

Security (IAS).

Aggarwal, C. C., & Philip, S. Y. (2008). A general survey

of privacy-preserving data mining models and

algorithms. In Privacy-preserving data mining (pp. 11-

52). Springer, Boston, MA.

Berman, J. J. (2002). Confidentiality issues for medical data

miners. Artificial Intelligence in Medicine, 26(1-2), 25-

36.

EmrBots.Org (2018) Experiment with artificial large

medical data-sets without worrying about privacy,

http://www.emrbots.org/ [Online; accessed August

2018].

Hendricks, P. (2015) Anonymizer: Anonymize Data

Containing Personally Identifiable Information. R

package version 0.2.0. https://github.com/

paulhendricks/anonymizer [Online; accessed August

2018].

Katehakis, D. G., Halkiotis, S., & Kouroubali, A. (2011).

Materialization of Regional Health Information

Networks in Greece: Electronic Health Record Barriers

& Enablers. Journal of Healthcare Engineering, 2(3),

389-403.

Katehakis, D. G., Kondylakis, H., Koumakis, L.,

Kouroubali, A., & Marias, K. (2017). Integrated Care

Solutions for the Citizen: Personal Health Record

Functional Models to Support Interoperability. EJBI,

13(1), 41-56.

Kaur, N., Sodhi, S. (2016) Data Encryption Standard

Algorithm (DES) for Secure Data Transmission.

International Conference on Advances in Emerging

Technology (ICAET).

Kondylakis, H., Bucur, A., Dong, F., Renzi, C., Manfrinati,

A., Graf, N., Hoffman, S., Koumakis, L., Pravettoni, G.,

Marias, K. and Tsiknakis, M., (2017, June).

iManageCancer: Developing a platform for Empowering

patients and strengthening self-management in cancer

diseases. In 2017 IEEE 30th International Symposium on

Computer-Based Medical Systems (CBMS) (pp. 755-

760). IEEE.

Kondylakis, H., Claerhout, B., Keyur, M., Koumakis, L.,

van Leeuwen, J., Marias, K., Perez-Rey, D., De

Schepper, K., Tsiknakis, M., Bucur, A. (2016). The

INTEGRATE project: Delivering solutions for efficient

multi-centric clinical research and trials. Journal of

biomedical informatics, 62, 32-47.

Kondylakis, H., Flouris, G., Fundulaki, I., Papakonstantinou,

V., & Tsiknakis, M. (2015a). Flexible access to patient

data through e-Consent. In Proceedings of the 5th EAI

International Conference on Wireless Mobile

Communication and Healthcare, pp. 263-266.

Kondylakis, H., Koumakis, L., Hänold, S., Nwankwo, I.,

Forgó, N., Marias, K., Tsiknakis, M. and Graf, N., (2017).

Donor’s support tool: Enabling informed secondary use of

patient’s biomaterial and personal data. International

journal of medical informatics, 97, pp.282-292.

Kondylakis, H., Koumakis, L., Kazantzaki, E., Chatzimina,

M., Psaraki, M., Marias, K., Tsiknakis, M., (2015b).

Patient Empowerment through Personal Medical

Recommendations. MedInfo, 1117

Kondylakis, H., Koumakis, L., Psaraki, M., Troullinou, G.,

Chatzimina, M., Kazantzaki, E., ... & Tsiknakis, M.

(2015c). Semantically-enabled Personal Medical

Information Recommender. In International Semantic

Web Conference (Posters & Demos).

Kondylakis, H., Spanakis, E. G., Sfakianakis, S., Sakkalis,

V., Tsiknakis, M., Marias, K., ... & Dong, F. (2015d).

Digital patient: personalized and translational data

management through the MyHealthAvatar EU project.

IEEE EMBC, pp. 1397-1400.

Koumakis, L., Kondylakis, H., Katehakis, D. G., Iatraki, G.,

Argyropaidas, P., Hatzimina, M., & Marias, K. (2018).

A content-aware analytics framework for open health

data. In Precision Medicine Powered by pHealth and

Connected Health (pp. 59-64). Springer, Singapore.

Kouroubali, A., Starren, J., Barrows Jr, R. C., & Clayton, P.

D. (1997). Practical lessons in remote connectivity. In

Proceedings of the AMIA Annual Fall Symposium (p.

335). American Medical Informatics Association.

Luminiţa, S.,Mătăsaru, P.,Diaconu, F. (2017) Extended

DES algorithm to Galois Fields. IEEE Signals, Circuits

and Systems (ISSCS).

ShinyAnonymizer: A Tool for Anonymizing Health Data

331

Maniadi, E., Kondylakis, H., Spanakis, E. G., Spanakis, M.,

Tsiknakis, M., Marias, K., & Dong, F. (2013,

November). Designing a digital patient avatar in the

context of the MyHealthAvatar project initiative. In

13th IEEE international conference on BioInformatics

and BioEngineering, pp. 1-4).

Peterson, W. W.; Brown, D. T. (1961) Cyclic Codes for

Error Detection. Proceedings of the IRE. 49 (1): 228–

235. doi:10.1109/JRPROC.1961.287814.

Potamias, G., Koumakis, L., &Moustakis, V. (2005).

Mining XML Clinical Data: the HealthObs System.

Ingénierie des systèmesd'information, 10(1), 59-79.

Prasser, F., et al. (2014) Arx-a comprehensive tool for

anonymizing biomedical data. AMIA Annual

Symposium Proceedings. Vol. 2014.pp. 984–993.

RFC 1321, (1992) The MD5 Message-Digest Algorithm.

Schaller, S., Marinova-Schmidt, V., Setzer, M.,

Kondylakis, H., Griebel, L., Sedlmayr, M., ... &

Kolominsky-Rabas, P. L. (2016). Usefulness of a

tailored ehealth service for informal caregivers and

professionals in the dementia treatment and care

setting: the eHealthMonitor Dementia Portal. JMIR

research protocols, 5(2).

Schneier, B. (1993) Description of a new variable-length

key, 64-bit block cipher (Blowfish). International

Workshop on Fast Software Encryption. Springer,

Berlin, Heidelberg.

SHA-2. https://en.wikipedia.org/wiki/SHA-2 [Online;

accessed August 2018].

Team, R. C. (2014). R: A language and environment for

statistical computing. R Foundation for Statistical

Computing, Vienna, Austria. 2013.

Templ, M., Kowarik, A., Meindl, B. (2015) Statistical

Disclosure Control for Micro-Data Using the R

Package sdcMicro,Journal of Statistical Software, Vol.

67 No.4, pp.1-36.

Collet, Y (2016) xxHash - Extremeley fast hash algorithm.

https://github.com/Cyan4973/xxHash, [Online; accessed

August 2018].

ICT4AWE 2019 - 5th International Conference on Information and Communication Technologies for Ageing Well and e-Health

332
