Enriching Threat Intelligence Platforms Capabilities

Mario Faiella

, Gustavo Gonzalez-Granadillo

, Ib

eria Medeiros

Rui Azevedo

and Susana Gonzalez-Zarzosa

Atos Research & Innovation, Cybersecurity Laboratory, Spain

LASIGE, Faculty of Sciences, University of Lisboa, Portugal

Keywords:

Threat Intelligence Platforms, Open Source Intelligence (OSINT), Data Enrichment, MISP, Threat Score.

Abstract:

One of the weakest points in actual security detection and monitoring systems is the data retrieval from Open

Source Intelligence (OSINT), as well as how this kind of information should be processed and normalized,

considering their unstructured nature. This cybersecurity related information (e.g., Indicator of Compromise -

IoC) is obtained from diverse and different sources and collected by Threat Intelligence Platforms (TIPs). In

order to improve its quality, such information should be correlated with real-time data coming from the moni-

tored infrastructure, before being further analyzed and shared. In this way, it could be prioritized, allowing a

faster incident detection and response. This paper presents an Enriched Threat Intelligence Platform as a way

to extend import, quality assessment processes, and information sharing capabilities in current TIPs. The plat-

form receives structured cyber threat information from multiple sources, and performs the correlation among

them with both static and dynamic data coming from the monitored infrastructure. This allows the evaluation

of a threat score through heuristic-based analysis, used for enriching the information received from OSINT

and other sources. The ﬁnal result, expressed in a well deﬁned format, is sent to external entities, which is

further used for monitoring and detecting incidents (e.g., SIEMs), or for more in-depth analysis, and shared

with trusted organizations.

1 INTRODUCTION

The number and the impact of cyber attacks has dras-

tically increased during the last years, as revealed by

reports written by governments and companies, espe-

cially in terms of how much these threats could harm

them from an economical point of view. The Council

of the Economic Advisers of the United States

esti-

mated that malicious cyber activity had an economic

impact in the U.S. economy between 57 billion and

109 billion dollars in 2016 (CEA, 2018). Cyberse-

curity Ventures

identiﬁed cyber crime as the ”great-

est threat to every company in the world”, predicting

that it will cost the world more than six trillion dol-

lars annually by 2021 (Ventures, 2017). Moreover,

the global management consulting ﬁrm Accenture

during a study conducted in 2017 (Accenture, 2017),

afﬁrmed that cyber crime, on an annual average, is

costing organizations 11.7 million dollars, more or

less 23 percent more than the previous year. These

https://whitehouse.gov/cea/

https://cybersecurityventures.com/

https://www.accenture.com/

successful incursions potentially allow groups of at-

tackers to acquire valuable intellectual properties and

secrets. With the aim of facing these menaces, it is

crucial to have timely access to relevant, accurate in-

formation about them, for protecting precious internal

and sensitive data as well as critical assets.

Collecting and processing Open Source Intelli-

gence (OSINT) information is becoming a fundamen-

tal approach for obtaining cybersecurity threat aware-

ness. Recently, the research community has demon-

strated that useful information and Indicators of Com-

promise (IoC) can be obtained from OSINT (Liao

et al., 2016; Sabottke et al., 2015). Besides the re-

search oriented efforts, all Security Operation Centre

(SOC) analysts get updated about new threats against

their IT infrastructures by collecting and analyzing

cybersecurity OSINT data. Nevertheless, skimming

through various news feeds is a time-consuming task

for any security analyst.

Furthermore, analysts are not guaranteed to ﬁnd

news relevant to the IT infrastructure they oversee.

Tools are therefore required, not only to collect OS-

INT, but also to process it, aiming at enhancing the

Faiella, M., Gonzalez-Granadillo, G., Medeiros, I., Azevedo, R. and Gonzalez-Zarzosa, S.

Enriching Threat Intelligence Platforms Capabilities.

DOI: 10.5220/0007830400370048

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 37-48

ISBN: 978-989-758-378-0

quality of the information carried on OSINT to SOC

analysts, for instance, to beneﬁt from the potential

they have. In addition, such tools must ﬁlter only the

relevant parts for the SOC analysts, thus decreasing

the amount of information and consequently, the time

required to analyze it and act upon. When appropri-

ate, the ﬁltered information must be further processed

to extract IoCs.

Moreover, a proper quality assessment is needed,

to check if gathered data can be considered as valu-

able Threat Intelligence (denoted as TI). Sillaber et al.

(Sillaber et al., 2016) identiﬁed TI quality evaluation

as one of the main challenges in actual cybersecurity

information sharing scenarios, mainly caused by the

limitation of existing TI sharing tools, as well as the

lack of suitable and globally recognized standards and

ontologies (Mavroeidis and Bromander, 2017). These

assessment processes can provide more insights for

inferring the impact that some cyber attacks could

have with respect to internal assets and resources, pri-

oritizing threat detection and incident response.

In addition, the ability to share OSINT informa-

tion is often not enough. TI must be expressed, and

then, shared using speciﬁc standards, allowing in-

volved parties to speed up processing and analysis

phases of received information, achieving interoper-

ability among them.

In this paper we propose an Enriched Threat Intel-

ligence Platform, (hereinafter denoted as ETIP), aim-

ing at extending import and information sharing capa-

bilities of internal detection and monitoring systems

(e.g., SIEMs) improving also quality assessment of

received cybersecurity events.

The ﬁnal objective is to integrate the relevant se-

curity data coming from public sources (e.g., social

networks), after going through a quality information

enhancing process, with data gathered from the in-

frastructure through speciﬁc detection and monitor-

ing systems (e.g., SIEMs, IDS, IPS), to anticipate and

improve threat detection and incident response. This

integration has been deﬁned as a crucial activity in

order to produce real and valuable TI (Skopik et al.,

2016).

In this context, on one hand, it arises the need of a

component that relates and aggregates collected OS-

INT data, generating thus new enriched data. On the

other hand, it also requires a component that consid-

ers potential security issues in the monitored infras-

tructure, to be correlated with the received OSINT

data, providing a threat score for the latter that helps

to identify its relevance and priority.

This threat score will complement the usage of

static information about the monitored infrastructure

with dynamic and real-time threat information re-

ported from inside the own monitored infrastructure

in the way of IoCs. This dynamic evaluation is based

on heuristic analysis which allows determining the

priority of the incoming OSINT data, by assigning

a threat score to it. The produced object integrating

the information received from OSINT data sources

through its calculated threat score is sent directly to

other security systems and tools (e.g., SIEMs) for vi-

sualization, storage, processing, or feedback and, op-

tionally, could also be shared with external trusted or-

ganizations.

The remainder of this paper is structured as fol-

lows: Section 2 presents related works, while Section

3 introduces and compares threat intelligence plat-

forms. Section 4 describes the architecture of our pro-

posed Enriched Threat Intelligence Platform (ETIP).

Section 5 details the Threat Score Evaluation process

and Section 6 illustrates the applicability of our ap-

proach with a use case scenario and preliminary re-

sults. Finally, conclusions and perspective for future

work are presented in Section 7.

2 RELATED WORK

Several standard formats have been proposed to fa-

cilitate cyber intelligence sharing among platforms.

Examples of such formats are the Open Indicators

of Compromise (OpenIoC

), Structured Threat Infor-

mation eXpression (STIX

), Trusted Automated eX-

change of Indicator Information (TAXII

Few studies of existing threat intelligence plat-

forms (TIPs) have been identiﬁed. Tounsi and Rais

(Tounsi and Rais, 2018) provides a survey about open

source threat intelligence platforms, including the

Malware Information Sharing Platform (MISP)

, the

Collective Intelligence Framework (CIF)

, the Col-

laborative Research Into Threats (CRITs)

, and Soltra

Edge

. Sauerwein et al. (Sauerwein et al., 2017),

provide an exploratory study of software vendors and

research perspectives of threat intelligence sharing

platform, and conclude that the market for threat in-

telligence sharing is still developing. Moreover, also

https://www.darknet.org.uk/2016/06/openioc-sharing-

threat-intelligence/

https://oasis-open.github.io/cti-

documentation/stix/intro

https://oasis-open.github.io/cti-

documentation/taxii/intro

http://www.misp-project.org

https://csirtgadgets.com/collective-intelligence-

framework

https://crits.github.io/

https://www.soltra.com/en/

SECRYPT 2019 - 16th International Conference on Security and Cryptography

ENISA provides an updated report about opportuni-

ties and limitations of actual TIPs (ENISA, 2017),

suggesting various guidelines that should be followed

for overcoming them.

Owen (Owen, 2015) proposes Moat, a powerful

tool that covers known bad actors and consume data

from multiple sources such as vulnerability systems

and port scanners. Moat has been integrated with

SIEMs using STIX and XML formats for sharing pur-

poses but it is not yet deﬁned for other well-known

standards such as TAXII.

Some commercial SIEMs (e.g., LogRhythm

)

have added security intelligence to its SIEMs and

analytic platforms. Their approach uses rich con-

text enabled by threat intelligence from STIX/TAXII-

compliant providers, commercial and open-source

feeds, as well as internal honeypots. As a result, the

platform uses these data to reduce false-positives, de-

tect hidden threats, and prioritize concerning alarms.

To the best of our knowledge, more research is

needed about threat intelligence sharing platforms,

and their integration with other security tools. Our

approach suggests the use of a platform for collect-

ing and aggregating cyber security related informa-

tion from OSINT, relying on MISP for storing and

managing the resultant IoCs, which will be further

enriched with a threat score, for prioritizing possible

defence actions. The outcome of this platform will

feed systems, like SIEMs and IDS, with actionable

information that will improve the detection of cyber

threats, and could also be shared, in an automated

way, with internal SOCs and CSIRTs, as well as with

other trusted organizations.

3 THREAT INTELLIGENCE

PLATFORMS

Many companies started relying on Threat Intelli-

gence Platforms (TIPs) for overcoming gaps and lim-

itations of actual detection and monitoring systems,

especially SIEMs (ThreatConnect, 2018). They are in

charge of retrieving structured and unstructured data

from diverse external sources, and perform various

complex operations, such as ﬁltering, aggregation,

normalization, detection, analysis and enrichment, as

well as the injection of results into SIEMs. However,

their implementation and usage are still in their in-

fancy and, as stated in (Sauerwein et al., 2017), many

drawbacks have to be addressed, for instance, in terms

of dynamic trust assessment of external sources and

advanced analysis capabilities, where manual work is

https://logrhythm.com

still needed, especially for making the retrieved infor-

mation effectively actionable.

TIPs are ideal tools for data collection, storage,

sharing, and for integration with external entities, that

could be other security platforms and tools, as well

as speciﬁc groups for handling incident response and

threat management (e.g., SOC, CSIRTs). Several

TIPs are available in the market (most of them under

commercial license). In terms of open-source solu-

tions, we have identiﬁed the following:

1. The Malware Information Sharing Platform

(MISP),

2. The Collective Intelligence Framework (CIF),

3. The Collaborative Research Into Threats (CRITs),

and

4. SoltraEdge (SE), but only a limited version is

available with this kind of license.

The comparison among them is summarized in Ta-

ble 1, and has been performed taking into account

the following criteria, mainly based on the study con-

ducted by Tounsi et al. (Tounsi and Rais, 2018), to-

gether with some personal considerations, especially

about hardware requirements:

• Import/Export Format: MISP and CRITs are

able to work with a great number of formats

(e.g., PDF, doc, xls, txt, JSON, XML, STIX).

MISP supports an ad-hoc standard for represent-

ing Threat Intelligence (a customized JSON

format), and basic built-in capabilities for STIX

v.2.0

conversion. It also allows adding modules

for ad-hoc importing/exporting without modify-

ing the core functionalities. CIF is not as ﬂex-

ible as the previous two TIPs, especially if spe-

ciﬁc standards (e.g., STIX) will be considered,

while the free and limited version of SoltraEdge

presents some limitations when dealing with non-

STIX data.

• Integration with/Export to Standard Security

Tools: MISP allows an easy interaction with In-

trusion Detection Systems (IDSs) and SIEMs, and

contains ﬂexible REST APIs for integrating inter-

nal solutions with the platform. CIF is also a vi-

able platform to integrate with IDS and SIEMs,

although less ﬂexible than MISP. CRITs is a huge

repository of TI, not speciﬁcally built for interact-

ing with systems such as SIEMs and IDS, how-

ever its ﬂexibility allows building ad-hoc solu-

tions for these purposes. The free SoltraEdge ver-

JavaScript Object Notation, https://www.json.org

https://oasis-open.github.io/cti-

documentation/stix/intro

Enriching Threat Intelligence Platforms Capabilities

sion has many limitations, especially in terms of

API support for interacting with other platforms.

• Support of Collaboration: MISP allows cen-

tralized support, by sharing the same instance

among a trusted community; and decentralized

support, when multiple instances interact in a

peer-to-peer way. CIF allows the usage of a pri-

vate instance and the implementation of a shared

instance through a centralized service. CRITs and

SoltraEdge allow the usage of a private instance,

or a shared one in the context of a trusted com-

munity. However, CRITs has very poor built-in

sharing capabilities.

• Data Exchange Standards: MISP and CRITs

are able to deal with many different standards, in-

cluding STIX and TAXII. The limited version of

Soltra-Edge has very poor capabilities to deal with

standards different to STIX and TAXII. CIF, has

been designed to work with other CIF instances

using private solutions for meeting high perfor-

mance requirements with partial or no support on

standards such as STIX and TAXII.

• Analysis Capabilities: high analysis capabilities

is a weakness for all current TIPs (Sauerwein

et al., 2017). CRITs and SoltraEdge are huge cen-

tral repositories for collaborating analysis rather

than pure sharing platforms. They have better

built-in analysis capabilities compared to MISP

and CIF. However, this advantage is partially lost

with the limited version of SoltraEdge.

Table 1: Comparison of Threat Intelligence Platforms.

Evaluated Criteria MISP CIF CRITs SE

Import/Export Format • ◦ • −

Integration Capabilities • • ◦ ◦

Data Exchange Std. • ◦ ◦ ◦

Support of Collaboration • • ◦ ◦

Analysis Capabilities ◦ ◦ • ◦

Graph Generation ◦ ◦ • ◦

License • • • ◦

Hardware Requirements • − • •

−Low/Basic ◦ Medium/Average • High/Advanced

• Graph Generation: visualization capabilities are

strictly related to the analysis of the aforemen-

tioned features, and the same consideration can be

deducted. More generically, this is another limi-

tation of current TIPs (Sauerwein et al., 2017).

• License: all TIPs considered in this analysis (in-

cluding the limited version of SoltraEdge) are re-

leased with open source licenses.

• Hardware Requirements: MISP, CRITs and

SoltraEdge have very similar requirements in

terms of RAM and hard disk size needed. CIF, in-

stead, has higher requirements, especially in terms

of processing capabilities.

Due to its ability to be integrated with SIEMs and

IDSs; its high ﬂexibility features for integrating inter-

nal and custom solutions; the support of speciﬁc data

exchange standard, such as STIX, as well as good

built-in information sharing capabilities; the avail-

ability of a very detailed on-line documentation

;

and a huge and responsive on-line community, in case

of development issues; the selected threat intelligence

platform is the MISP.

4 ENRICHED THREAT

INTELLIGENCE PLATFORM

ARCHITECTURE

The Enriched Threat Intelligence Platform (ETIP) is

composed of two main modules: (i) the Composed

IoC Module, and (ii) the Context Aware Intelligence

Sharing Module as shown in Figure 1.

OSINT

Feeds

Context Aware Intelligence Sharing Module

Infrastructure

and OSINT

Data

External Entities (i.e.,

SIEMs, CSIRTs, SOCs, …)

MISP

Instance

Heuristic

Module

Enriched Threat Intelligence Platform (ETIP)

TIPs

IoCs Aggregating

Process

Composed IoC Module

single IoCs

Composed IoCs

Enriched IoCs

Figure 1: Enriched Threat Intelligence Platform architec-

ture.

While the ﬁrst module collects several security

events (i.e., IoCs) provided from different OSINT

feeds, and then interrelates them, generating thus

IoCs with more information – composed IoCs –, the

second module receives these composed IoCs and

correlates them with information provided by security

tools deployed in the organization network infrastruc-

ture. Applying a heuristic analysis to these data, the

resulting IoC can be further enriched, providing more

insights about how much the incoming information

could be considered as real intelligence by the enter-

prise.

https://www.circl.lu/doc/misp/book.pdf

SECRYPT 2019 - 16th International Conference on Security and Cryptography

4.1 Composed IoC Module

We propose a component to generate composed IoCs,

i.e., for collecting different IoCs from different TIPs,

correlating them, and then, generating new composed

IoCs. The architecture of the component is repre-

sented in Figure 2. The main parts are the following:

OSINT

Feed

OSINT

Feed

TIP

…

TIP

…

Collector

IoC Normalizer

IoCs

Composed

IoCs

Deduplicator

IoC Aggregator

Figure 2: Composed IoC Module Architecture.

• OSINT Feeds. Open source intelligence informa-

tion regarding to security events, such as cyber-

attacks, exploitation of software vulnerabilities,

malware domains, IP blacklists.

• TIPs. Different TIPs are used in parallel to collect

several OSINT data provided from diverse feeds,

which take advantage of the enrichment capabil-

ities they offer, such as improving OSINT threat

intelligence with external data not included in OS-

INT feeds (e.g., asn source, whois).

• Collector. The output of the different TIPs, as a

form of IoCs, is channelled to a collector module.

The TIP’s IoCs are seen as OSINT feeds but in an

IoC format (e.g., STIX, MISP format).

• IoC Normalizer. Since IoCs might be collected

in different formats (depending on the format

adopted by TIPs), it is necessary to normalize

them in a single and common format (e.g., MISP

format). After this process, they are stored in a

database to be processed by the component.

• Deduplicator. IoCs received from different TIPs

can be equals, since TIPs can be conﬁgured with

the same OSINT feeds. The deduplicator mod-

ule analyzes the received IoCs with those already

exist in the database with the aim to identify du-

plicated IoCs and remove them before being pro-

cessed by the IoC aggregator module.

• IoC Aggregator. Aggregates different but re-

lated IoCs, and generates new ones. The pro-

cess consists on identifying IoCs that contain rel-

evant interrelated information, aggregating them

in a same set, and then, merging that information

into a single IoC, creating a new IoC that we call

composed IoC. These new IoCs are stored in the

database for later be used by the context aware

threat intelligence component (see Section 4.2).

4.1.1 Implementation

The proposed component was implemented using the

MISP platform, for which the deduplicator and aggre-

gator modules were developed in Python 3, and inte-

grated in MISP. This latter acts as the collector and

IoC normalizer to receive and normalize the data that

can be provided from different TIPs, and then uses the

developed modules to process the received data.

The component offers to the end user the possi-

bility of conﬁguration based on two criteria: (1) the

trust level of the IoC assigned by the MISP commu-

nity, where, for example, an IoC with level 2 means

that IoC has the trustiest level of conﬁdence and its

information is relevant; (2) the interrelation type be-

tween IoCs which will be considered by the IoC ag-

gregator module. This interrelation can be based on

IoC as a whole or their attributes, which the former

only allows interrelations between IoCs that belong

to the same threat category, whereas the latter permits

a most deep analysis and connection between IoCs,

allowing to generate new data provided by IoCs of

different categories (e.g., IoCs belonging to the MISP

network category and from type of vulnerability).

IoC 0 (76)

IoC 1.A (32)

IoC 1.B (74)

IoC 1.C (46)

IoC 1.D (51)

IoC 2.B (71)

IoC 3.A (102)

IoC 2.A (16)

OSINT Feed 1 OSINT Feed 2 OSINT Feed 3

Figure 3: Schematic for the creation of a composed IoC.

The component considers dividing the OSINT

feeds in two categories: (1) low level feeds, which

consist mainly of IP addresses and URLs; and (2) high

level feeds, which contain a more advanced analysis

with information about network artifacts, campaigns,

etc.; that feed TIPs (e.g., CRIT, MISP). It performs

queries to the database to identify new entries and

other entries that have matches, and then merge them

Enriching Threat Intelligence Platforms Capabilities

forming a new IoC and inject it into the database,

which is labelled with a tag that allows identifying

it as a rich IoC and avoids the creation of loops.

Figure 3 exempliﬁes a composed IoC. In the ﬁg-

ure, starting from an IoC that contained 76 elements,

we were able to identify 7 other IoCs, originating

from 3 distinct OSINT feeds, that were correlated.

The merging of these IoCs allowed the creation of a

new IoC containing 468 elements.

4.2 Context Aware Intelligence Sharing

Module

The context aware intelligence sharing module is able

to correlate static and real-time information (e.g., In-

dicators of Compromise), related to the monitored

infrastructure, with data coming from external OS-

INT sources through OSINT data fusion and analy-

sis tools, to check the relevance and accuracy of the

data. Furthermore, the module is also able to share

both the original and the enriched information with

external entities, in an automated way.

The proposed module architecture, depicted in

Figure 4, is composed of two main elements: (i) a

MISP Instance, in charge of gathering data from both

OSINT-based sources and the monitored infrastruc-

tures, as well as sending the enriched IoCs to inter-

nal components, systems and tools (e.g., SIEMs) or

sharing them with trusted organizations; and (ii) the

Heuristic Component, in charge of performing the

heuristic analysis, with the ﬁnal aim of computing a

Threat Score, enriching the data coming from OSINT-

based sources, and sending it back to the MISP In-

stance.

Input Data

OSINT Data

Collector

MISP

Database

Infrastructure Data

Collector

Heuristic

Database

Heuristic

Engine

Threat

Score

Agent

MISP

Instance

Heuristic

Component

External Entities (i.e.,

SIEMs, CSIRTs, SOCs, …)

Figure 4: Context Aware Intelligence Sharing Module.

4.2.1 MISP Instance

From Figure 4, the OSINT and Infrastructure data col-

lectors are responsible of capturing useful data from

OSINT, IoCs and the infrastructure in order to eval-

uate a set of pre-deﬁned heuristics and to compute a

threat score. Collected OSINT data are stored in the

MISP Database, whereas collected infrastructure data

are stored in the Heuristic Component Database.

The integration between security tools, as well as

internal SOC and CSIRTs, and the context aware in-

telligence sharing module is possible thanks to the

adoption of MISP. The objective is to use, as much as

possible, the built-in sharing capabilities of the plat-

form when this interaction takes place, such as a ze-

roMQ publish-subscribe model

. MISP comes with

so-called “MISP-modules”, used both for ad-hoc im-

port and export of threat information. If required, new

modules could be created from scratch and integrated

with the MISP Instance, without modifying the core

functionalities of the platform.

The heuristic component receives all data com-

ing from the monitored infrastructures, through MISP.

Data could be dynamic (e.g., IoC detected in the in-

frastructures) or static and generic information about

a speciﬁc infrastructure (e.g., used sensors, operat-

ing systems, speciﬁc lists of IP addresses). These

data are stored in the MISP database, represented

through the JSON format (e.g., STIX, MISP events),

or through simple documents related to generic in-

formation. Since its usage is of great interest to

the heuristic component, data could be also stored

in a different way, using for instance a private non-

relational database such as MongoDB

, which sim-

pliﬁes the information retrieval by the heuristic engine

and allows for a full control of the analysis performed

by the tool.

The adoption of MISP makes it possible to auto-

matically share data with external entities thanks to

its built-in information sharing capabilities. For those

cases in which the external entity is using a MISP

instance, the sharing process is performed by sim-

ply synchronizing both instances. Otherwise, MISP

comes with a list of REST APIs, which are accessed

from any internal and external services with differ-

ent levels of access rights, to directly interact with its

database, to push/pull cyber-security related events.

4.2.2 Heuristic Component

The heuristic component receives information com-

ing from multiple sources (e.g., OSINT data, infras-

tructure, IoCs, etc.) to be used in the Threat Score

(T S) analysis performed by the heuristics engine.

This latter considers a set of conditions that are eval-

uated for every single feature. A score is assigned to

http://zeromq.org/

https://www.mongodb.com/

SECRYPT 2019 - 16th International Conference on Security and Cryptography

every feature (i.e., individual score). The sum of all

individual scores results into the Threat Score associ-

ated to the data being analyzed.

The database from the heuristic component stores

the information of the infrastructure and the OSINT

data collector. The Threat Score Agent is responsi-

ble for the generation of the resulting enriched In-

dicator of Compromise (eIoC), including the Threat

Score for the security information received from OS-

INT data sources. The eIoCs shared by this compo-

nent includes the same information received from OS-

INT, as well as the associated Threat Score and the

features considered in the evaluation.

5 THREAT SCORE (TS)

EVALUATION

The threat score evaluation is part of the heuris-

tic component that uses a threat score function (de-

tailed in Section 5.1) to compute the relevance of

the received data. The process performs an analysis

methodology composed of the following steps:

1. Source Identiﬁcation: during this phase we

search and identify all possible sources of infor-

mation. Examples of these sources are: security

logs, databases, report data, OSINT data sources,

IoCs, etc.

2. Heuristics Identiﬁcation: different features

(e.g., heuristics) are identiﬁed from the input

data. Such features provide relevant informa-

tion about the infrastructure (e.g., vulnerabilities,

events, faults, errors, etc.) useful in the threat

analysis and classiﬁcation process. Examples of

heuristics are: CVE, IP source, IP destination,

port source, port destination, timestamp, etc.

3. Threshold Deﬁnition: for each heuristic, mini-

mum and maximum possible values are deﬁned

based on characteristics associated to the instance.

We checked, for instance, if the input data con-

tains or not a CVE for the detected threat. A

threshold (e.g., 0-5) is assigned to cover all pos-

sible results.

4. Score Computation: for each possible instance

of the identiﬁed heuristic, a score value is as-

signed based on expert knowledge. All individ-

ual scores are then aggregated and a ﬁnal score is

computed. The resulting value will indicate the

priority and relevance of the security information

coming from OSINT data sources and the moni-

tored infrastructure.

5. Training Period: a set of preliminary tests need

to be performed during a training process to eval-

uate the performance of the engine. The tests in-

clude real data to analyze the score obtained indi-

vidually (for each heuristic) and globally (for the

whole event) which help to analyze false positive

and negative rates.

6. Engine Calibration: in order to minimize devia-

tions (e.g., reduce number of false positive, false

negative) the engine must be calibrated by analyz-

ing the obtained results, adding other heuristics

and/or modifying the assigned values to current

attributes.

7. Final Tests: Once the engine is calibrated, we can

repeat previous tests or add new ones in order to

evaluate the performance of the tool.

5.1 Threat Score Function

The heuristics-based threat score is composed of a set

of individual scores as a complement of other pre-

diction tools to indicate the priority and relevance

of incoming security information received from OS-

INT and infrastructure data sources. There exists a

large number of different aggregation operators (e.g.,

Arithmetic Mean, Geometric Mean, Harmonic Mean,

Weighted Mean, Ordered Weighted Averaging) (Ra-

vana and Moffat, 2009; Torra and Narukawa, 2007)

that can be used for the computation of the threat

score. They differ on the assumptions about the data

(data types) and the type of information that we can

incorporate in the model.

From the aforementioned aggregation operators,

the Weighted Mean (WM) is the selected function to

compute the threat score, due to the following ad-

vantages: (i) simple and straightforward function; (ii)

avoids indeterminate results and/or null values; (iii)

can be used if one or more individual scores are zero;

and (iv) individual scores are assumed to have differ-

ent weights depending on the source and the relevance

of the information.

The proposed Threat Score (T S) is deﬁned as the

sum of all individual heuristic values (X

) times its

corresponding weight factor (P

). This latter considers

multiple criteria (e.g., relevance, accuracy, timeliness,

variety). The sum is then affected to the completeness

parameter (C

), as shown in Equation 1.

T S = C

∑

i=1

× P

(1)

The resulting T S ranges from zero to ﬁve (0 ≤

T S ≤ 5), the higher the TS value, the more reliable

the IoC. Thus, a T S with a value between zero and one

Enriching Threat Intelligence Platforms Capabilities

(0 ≤ T S ≤ 1) indicates a Very Low level of priority;

a T S with a value between one and two (1 ≤ T S ≤ 2)

indicates a Low level of priority; a TS with a value be-

tween two and three (2 ≤ T S ≤ 3) indicates a Medium

level of priority; a T S with a value between three

and four (3 ≤ T S ≤ 4) indicates a High level of pri-

ority; and a T S with a value between four and ﬁve

(4 ≤ T S ≤ 5) indicates a Very High level of priority.

5.2 Heuristic Value

The ﬁrst part of the (T S) function refers to the value

assigned to a given heuristic (X

) based on the type

of information processed during the evaluation. Con-

sidering, for instance, that one of the features to be

evaluated is the presence of a Common Vulnerabil-

ity Exposure (CVE)

identiﬁed in the input data, the

engine will check if the word ‘CVE’ appears in the in-

put data in order to retrieve the complete CVE number

(i.e., CVE-AAAA-NNNN).

If a CVE is found, the engine checks for its

associated Common Vulnerability Scoring System

(CVSS)

. More speciﬁcally, the engine will search

for its associated base score, which considers access

vector, access complexity, authentication, and impact

related information based on availability, conﬁden-

tiality and integrity. Depending on the CVSS score,

the vulnerability is labeled as none, low, medium,

high or critical, as shown in Table 2.

Table 2: Common Vulnerability Score System (CVSS) v3

Ratings.

Severity None Low Med High Critical

Lower Bound 0.0 0.1 4.0 7.0 9.0

Upper Bound 0.0 3.9 6.9 8.9 10.0

Source:

https://www.ﬁrst.org/cvss/speciﬁcation-document

Each evaluated feature is assigned an individual

score based on the deﬁned threshold (e.g., from 0 to

5) that will indicate the level of impact of the fea-

ture with respect to the event. We deﬁne the variable

“Score CVE” that will compute the individual score

value assigned to the presence of a CVE in the input

data based on the conditions described in Table 3.

Other features (e.g., source/Destination IP, cre-

ation and validity timestamps, etc.) may use posi-

tive and/or negative values in the assignment process.

Such individual values are then tuned in the training

and calibration processes so that the ﬁnal threat score

reduces the number of false positives and negatives.

https://www.mitre.org

https://www.ﬁrst.org/cvss/speciﬁcation-document

Table 3: Examples of Individual Threat Score.

Criteria Condition Score

No CVE If CVE == ” 0

CVE exists with

CVSS ‘none’ or

0.0

If CVE 6= ” &

CVSS = ‘none’ |

CVSS = 0.0

CVE exists with

CVSS ‘low’ or

less than 4.0

If CVE 6= ” &

CVSS = ‘low’ |

CVSS ≤ 4.0

CVE exists with

CVSS ‘medium’

or less than 7.0

If CVE 6= ” &

CVSS = ‘med’ |

CVSS ≤ 7.0

CVE exists with

CVSS ‘high’ or

less than 9.0

If CVE 6= ” &

CVSS = ‘high’ |

CVSS ≤ 9.0

CVE exists with

CVSS ‘critical’

or less than 10.0

If CVE 6= ” &

CVSS = ‘critical’

| CVSS ≤ 10.0

5.3 Weighting Criteria

The second part of the (T S) function corresponds

to the weighting criteria (P

). According to Henry

Dalziel (Dalziel, 2014), Threat Intelligence refers to

speciﬁc information that must meet three speciﬁc cri-

teria: (i) it must be relevant, for the entity who re-

ceives it, (ii) actionable and (iii) valuable, from a

business perspective. In (ENISA, 2015) the concept

of “actionable information” is deﬁned by the Euro-

pean Union Agency for Network and Information Se-

curity (ENISA), from an organization point of view

as the information that can be used immediately for

speciﬁc and strategical decision making. Considering

(ThreatConnect, 2018) and (ENISA, 2015), in order

to be “actionable”, information must meet the follow-

ing criteria:

Relevance: it must have some impacts on speciﬁc

receiver’s assets, such as networks, software and

hardware. That is, indicators of compromise will usu-

ally be considered relevant when a threat could affect

the monitored infrastructure. In order to determine

the relevance, it is crucial to determine types of threats

targeting your assets/systems, considering real-time

information (e.g., IoC), from many internal sources,

because they are able to provide dynamic and con-

tinuous information about current internal monitoring

operation, together with a global view of the infras-

tructure status.

In our analysis, this criterion evaluates if the in-

formation associated to a given attribute is useful to

identify a threat. Relevance is computed as shown in

Table 4.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

Table 4: Relevance Criteria.

Relevance Score

Attribute with no data 0

Optional Attribute 1

Attribute does not identify threat but

helps in the analysis

Attribute is useful to identify threat 7

Mandatory attribute to identify threat 10

Timeliness: threat intelligence is more reliable

when it allows detecting attacker’s activity, especially

during the same intrusion, to monitor how it evolves

during time. Moreover, information about events

older than a few hours are, most of the times, irrel-

evant and non-actionable due to the dynamic nature

of some threat’s characteristics, considering that some

of them are discovered and analyzed months after the

initial compromise.

In our analysis, this criterion evaluates if a de-

tected event is related to an already detected one,

by the infrastructure or by the OSINT-based compo-

nents, and if for instance, such events refer to the same

threat, but with a different level of intrusion, provid-

ing new or updated information. Timeliness is com-

puted as shown in Table 5.

Table 5: Timeliness Criteria.

Timeliness Score

Attribute with no data 0

Attribute has never been seen 1

Attribute has been seen with the same

value

Attribute has been seen with a different

value

Accuracy: the receiver side should be able to pro-

cess the received data as soon as possible. It depends

mainly on three factors, which are the conﬁdent of

the source from which data is retrieved, the trust level

placed in those sources (which, in turn, could depend

on factors such as false positives/false negatives rates)

and the local dynamic context of the receiver. The lat-

ter is crucial in order to avoid inaccurate results and

efforts when dealing with incident response.

In our analysis, information coming from OSINT-

based components will be compared to the informa-

tion coming from the infrastructure, if there is a match

of one or more attributes, a score will be computed.

Accuracy is computed as shown in Table 6.

Table 6: Accuracy Criteria.

Accuracy Score

Attribute with no data 0

Attribute has some data with no match 1

There is a match of one source and the

infrastructure

There is a match of two sources and the

infrastructure

Variety: detection and prevention should not rely

on a single technique or tool. It is crucial to use

a combination of systems, tools (e.g., IDS, IPS and

Firewalls) and sources (e.g., OSINT), especially when

they are able to detect the threat at different levels of

intrusions (kill chain phases).

In our analysis, this criterion evaluates the sources

from where the information is originated or detected

e.g., infrastructure, OSINT-based components. Vari-

ety is computed as shown in Table 7.

Table 7: Variety Criteria.

Variety Score

Attribute with no data 0

Data come from one source 1

Data come from two sources 5

Data come from all sources 10

Ingestibility: received information must be easy to

ingest into internal data management systems for fur-

ther processing and analysis phases. This is achiev-

able using speciﬁc standards for representing this

data, allowing the receiver to process data as fast as

possible, helping also security analysts, as well as

through the usage of speciﬁc transfer protocols for

sharing the related intelligence.

Ingestibility is not considered in our analysis since

we are assuming that all received data is expressed in

a structured way and uses a speciﬁc standard format

to be processed in the system. The data collection

will be handled directly by the MISP instance. This

criterion would have been meaningful in case of re-

ception of unstructured information, but this scenario

is not considered by the context aware OSINT plat-

form. The analysis will focus on other criteria with

the possibility of adding new ones in the future.

Completeness: Threat intelligence should provide

valuable and complete information to the ﬁnal re-

ceiver, evaluated from the local cyber context point

of view of the latter. Sometimes, sources are incom-

plete when considered alone, but their provided data

Enriching Threat Intelligence Platforms Capabilities

become actionable once combined or processed with

other internal data available to the destination or re-

ceived from other external sources.

In our analysis, this criterion is used as an over-

all assessment of the heuristic and not for individ-

ual score evaluation of the attributes. Each heuristic

is composed of one or more attributes (e.g., CVE is

composed of six attributes: (i) no cve, (ii) cvss none,

(iii) cvss low, (iv) cvss medium, (v) cvss high, (vi)

cvss critical. Completeness is measured as the num-

ber of attributes with a non-empty value over the total

number of attributes, as shown in Equation 2.

Non Empty Attributes

Total Attributes

(2)

6 PRELIMINARY RESULTS

In this section we will illustrate the advantages of our

approach, and the beneﬁts our platform will bring in

terms of prioritizing threat information received from

external sources (e.g., OSINT). We will use the Con-

text Aware Intelligence Sharing Module to evaluate

relevance, accuracy, and other features on the infor-

mation received from the Composed IoC Module. For

the threat score evaluation we will consider both: the

data coming from the infrastructure through security

systems and tools (e.g., SIEMs, IDS), as well as, IoCs

obtained by open source and public feeds. The re-

sulting threat score will be inserted in the information

associated to the analized IoC. The higher the threat

score value, the higher the priority of the associated

information when handled by incident response teams

and security analysts.

The Composed IoC module will provide both: sin-

gle and composed IoCs to the Context Aware Intel-

ligence Sharing module. We expect that the com-

posed IoCs will have an associated threat score higher

than the threat score of each single IoCs they con-

tain. The entire process considered in this use case

is characterized by four sequential phases: Collect-

ing and Aggregating phases, performed by the Com-

posed IoC module, followed by the Sharing phase,

which involves both modules, and the TS Evaluation

phase, completely handled by the Context Aware In-

telligence Sharing module.

Collecting Phase: to collect OSINT data we con-

ﬁgured a MISP instance with 34 OSINT feeds from

higher value information (e.g., CVE vulnerabilities)

and low value information (e.g., IP blacklists). These

feeds are provided by diverse public free entities and

reach MISP in different formats, such as csv and txt

ﬁles. OSINT data are normalized in a single format,

namely the MISP format, and then stored as IoCs

in the MISP database. Afterwards, the deduplicator

module we developed is executed to load the IoCs and

search for duplicates in order to delete them. This task

allows improving MISP in two forms: identify dupli-

cated IoCs and reduce the quantity of data stored, and

therefore, increasing the MISP performance.

Aggregating Phase: After removing the duplicated

IoCs, the aggregator component analyses the result-

ing IoCs to look for connections among them. For the

connections found, the aggregator puts the involved

IoCs in the same group of IoCs, since they are related

to the same malicious threat. At the end, we have

several and different groups of IoCs forming clusters,

each one for a particular threat category. At the point

of view of a threat category, a cluster can contain

IoCs correlated between them and related with a same

(sub-)threat (or attack) and possibly with other valu-

able malicious information that can be provided in a

same IoC. This means that a cluster can contain sub-

clusters of IoCs regarding to different attacks. Such

sub-clusters can well characterize, this point of view,

attacks that have been executed, for which individual

IoCs could not allow their identiﬁcation. Finally, each

sub-cluster is represented as one IoC, i.e., all its IoCs

are merged in a single one, generating a composed

IoC, and then, they are stored in the MISP database.

Sharing Phase: the ﬁnal outcome of the composed

IoC module is sent to the context aware intelligence

sharing module for proceeding with the ﬁnal compu-

tation of the threat score. This integration is achieved

easily thanks to the adoption of MISP.

More precisely, two different MISP instances are

used, one by each module. For simplicity, and for

facilitating reader comprehension, we will refer to

them as MISP

and MISP

, respectively. These in-

stances have been synchronized between each other

to allow a real-time and completely automated infor-

mation sharing, following the guidelines provided in

the MISP book

for setting up a MISP synchroniza-

tion server on MISP

. This server has been associ-

ated to a speciﬁc user with synchronization privileges,

which is replicated in both instances. Injecting, and

publishing IoCs in MIS P

on behalf of this user, trig-

gers a push operation of one or more IoCs directly on

MISP

, completing the one-way information sharing

needed for this use case scenario.

When the synchronization server is set up, the

sync user authentication key must be speciﬁed. This

https://www.circl.lu/doc/misp/book.pdf

SECRYPT 2019 - 16th International Conference on Security and Cryptography

information is provided by MISP

, when the user is

created.

TS Evaluation Phase: to perform the computation

of the threat score, MISP

needs to be extended with

new functionalities. For this speciﬁc use case, we

developed a new MISP export module, integrating it

with the core software of the platform, following the

guidelines

provided by the MISP community and

developers. In this way, the module is available di-

rectly from the MISP UI, where it can be triggered

manually by the user for a speciﬁc IoC, to retrieve

and send the IoC directly to the Heuristic Module of

the platform (Figure 4), where the threat score func-

tion has been implemented, and added to the original

IoC as a new MISP attribute.

Aiming at correlating IoCs with infrastructure

data, as well as with other useful information about

cyber events from open source and public feeds, a

MongoDB

database is used, and the information

is stored as JSON documents. The ﬁnal IoC (i.e.,

enriched IoC) could be shared with speciﬁc security

tools or internal SOCs and CSIRTs, with the addi-

tional threat score used for determining the priority of

the contained data, in case of some defence activities

would be needed.

In order to provide practical examples of the func-

tionality of our platform, eleven samples of composed

IoCs have been considered, and the entire process pre-

viously described has been executed in each of them.

As a result, the threat score (T S) is computed for ev-

ery single IoC (sIoC) integrating the composed ones,

making it possible to compare with the threat score

computed for the composed IoCs (cIoC).

For the heuristic analysis, a subset of nine MISP

attributes

has been selected, composed of the ones

which are more relevant according to the monitored

infrastructure (i.e., vulnerability, ﬁlename, ip-src, ip-

dst, hostname, domain, url, link, and md5). This does

not mean that other attributes are discarded, they sim-

ply have a higher importance when speciﬁc criteria

are evaluated, especially for relevance and complete-

ness.

Results are summarized in Table 8. Each row is

associated to a sample of composed IoCs (e.g., S

..., S

), specifying the number of single IoCs (sIoC)

composing them, their individual Threat Score (T S),

and the global TS associated to the composed IoC

(cIoC).

More information about our platform can be found

in https://caisplatform.wixsite.com/english.

https://github.com/MISP/misp-modules

https://www.mongodb.com/

https://www.circl.lu/doc/misp/categories-and-types/

Table 8: Threat Score Results.

Samples N. of

sIoCs

individual TS Global

5 1.86, 2,55, 1.80,

0.71, 1.94

3.18

3 1.43, 2.32, 1,58 2.53

3 2.48, 1.54, 1.09 2.87

6 1.18, 1.40, 1.54,

0.64, 1.41, 2.03

3.07

2 2.84, 1.66 3.22

17 1.39, 2.22, 2.21,

1.99, 1.87, 0.70,

1.66, 1.10, 0.56,

0.96, 0.94, 0.56,

1.58, 2.66, 2.27,

1.36, 1.08

3.98

7 2.09, 3.27, 1.89,

0.89, 2.88, 1.93,

1.66

2.84

4 3.06, 2.68, 2.11,

1.55

3.11

11 1.66, 1.21, 2.35,

1.92, 1.33, 1.29,

1.6, 0.90, 0.88,

1.02, 0.56

4.13

2 2.43, 2.31 2.54

2 0.99, 0.55 1.29

As depicted in Table 8, in most of the cases, the

T S of the composed IoCs is higher than the T S for

each of the related single ones. This improvement is

strictly dependent on two main factors:

1. The number of attributes present in the IoC. The

higher this number, the higher the probability of

increasing the overall quality when the aggrega-

tion is performed; and

2. The quality of the single IoCs. The higher the

quality of the information found in the attributes

present in the sIoCs, the lower the probability to

increase the overall quality when aggregating sev-

eral IoCs.

For the ﬁrst factor, we have seen samples S

and S

with a high number of single IoCs (17 and 11 IoCs re-

spectively), for which the T S of their cIoC has greatly

improved compared to the one of each sIoC. For the

second factor, we have seen samples S

, S

, and

, in which the aggregation process is not able to

add a relevant level of quality to the ﬁnal IoC. In these

cases, the quality of the information identiﬁed in the

sIoC samples results in high T S values. Although in

most of the cases, the T S value of the cIoC is higher

than the one associated to each sIoC, the improvement

Enriching Threat Intelligence Platforms Capabilities

is low, having in some cases a lower T S value in the

cIoC compared to one of the sIoC (i.e., S

It is important to note that among all the criteria

used in the T S computation, the completeness (i.e.,

) is the criterion that affects the most the ﬁnal re-

sult. Whereas, all other criteria are adding individual

values to the T S, the completeness criterion is mul-

tiplying to the overall addition, affecting to a higher

level the T S results of single or composed IoCs.

7 CONCLUSION

This paper presents ET IP, an enriching threat intel-

ligence platform, as an extended import, quality as-

sessment processes and information sharing capabil-

ities in current TIPs. The proposed platform gath-

ers and processes structured information from exter-

nal sources (e.g., OSINT sources) and from the moni-

tored infrastructure. The platform is composed of two

main modules: (i) a Composed IoC Module, in charge

of collecting, normalizing, processing and aggregat-

ing IoCs from OSINT feeds; and (ii) a Context Aware

Intelligence Sharing Module, able to correlate, assess

and share static and real time information with data

obtained from multiple OSINT sources.

The ETIP platform computes a Threat Score (T S)

associated to each IoC before sharing it with both in-

ternal monitoring systems and tools (e.g., SIEMs) and

trusted external parties. Enriched IoCs will contain a

threat score that will enable SOC analysts to priori-

tize the analysis of incidents. The Threat Score eval-

uates heuristics with two types of weights: (i) indi-

vidual weights assigned to every attribute (e.g., rele-

vance, accuracy, variety, etc.); and (ii) global weight

(i.e., completeness criterion) assigned to the heuristic.

The higher the T S value, the more reliable the IoC.

Thus, as the T S value approaches to zero, the IoC can

be considered as poor, incomplete and/or not reliable

with a very low priority level.

Future work will concentrate in developing new

attributes to enrich the threat score analysis, improv-

ing the quality of the reﬁned threat intelligence to be

shared, providing not only the ﬁnal threat score, but

also detailed information about each single criterion

used in the evaluation of the score itself, which in

turn helps to improve threat detection and incident re-

sponse.

ACKNOWLEDGMENT

The research in this paper has received funding from

the EC through funding of DiSIEM project, ref.

project H2020-700692, NeCS project, ref. project

H2020-675320 and LASIGE Research Unit, ref.

UID/CEC/00408/2019.

REFERENCES

Accenture (2017). Cost of cyber crime study. Online.

CEA (2018). The cost of malicious cyber activity to the u.s.

economy. Online Report.

Dalziel, H. (2014). How to deﬁne and build an effective cy-

ber threat intelligence capability. In Syngress, eBook.

ENISA (2015). Actionable information for security incident

response. In Online Technical Paper.

ENISA (2017). Exploring the opportunities and limitations

of current threat intelligence platforms.

Liao, X., Yuan, K., Wang, X., Li, Z., Xing, L., and Beyah.,

R. (2016). Acing the ioc game: Toward automatic

discovery and analysis of open-source cyber threat in-

telligence. In ACM SIGSAC Conference on Computer

and Communications Security, pages 755–766.

Mavroeidis, V. and Bromander, S. (2017). Cyber threat in-

telligence model: An evaluation of taxonomies, shar-

ing standards, and ontologies within cyber threat in-

telligence. In Intelligence and Security Informatics

Conference, pages 91–98. IEEE.

Owen, T. (2015). Threat intelligence & siem. In Masters

Research Project, Lewis University.

Ravana, S. D. and Moffat, A. (2009). Score aggregation

techniques in retrieval experimentation. In Twentieth

Australasian Database Conference.

Sabottke, C., Suciu, O., and Dumitras, T. (2015). Vulnera-

bility disclosure in the age of social media: exploiting

twitter for predicting real-world exploits. In In 24th

USENIX Security Symposium, pages 1041–1056.

Sauerwein, C., Sillaber, C., Mussmann, A., and Breu, R.

(2017). Threat intelligence sharing platforms: An ex-

ploratory study of software vendors and research per-

spectives. In Conference on Wirtschaftsinformatik.

Sillaber, C., Sauerwein, C., Mussmann, A., and Breu, R.

(2016). Data quality challenges and future research

directions in threat intelligence sharing practice. In

ACM on Workshop on Information Sharing and Col-

laborative Security, pages 65–70. ACM.

Skopik, F., Settanni, G., and Fiedler, R. (2016). A prob-

lem shared is a problem halved: A survey on the di-

mensions of collective cyber defense through security

information sharing. computers & security, 60:154–

176.

ThreatConnect (Accessed February 2018). Threat intel-

ligence platforms. everything you’ve ever wanted to

know but didn’t know to ask. In Ebook.

Torra, V. and Narukawa, Y. (2007). Modeling decisions:

Information fusion and aggregation operators. In

Springer-Verlag Berlin Heidelberg.

Tounsi, W. and Rais, H. (2018). A survey on technical threat

intelligence in the age of sophisticated cyber attacks.

In Computers & Security, volume 72, pages 212–233.

Ventures, C. (2017). 2017 cybercrime report. Online.

SECRYPT 2019 - 16th International Conference on Security and Cryptography
