Designing Software Architecture to Support Continuous Delivery and
DevOps: A Systematic Literature Review
Robin Bolscher and Maya Daneva
University of Twente, Drienerlolaan 5, Enschede, The Netherlands
Keywords: Software Architecture, Continuous Delivery, Continuous Integration, DevOps, Deployability, Systematic
Literature Review, Micro-services.
Abstract: This paper presents a systematic literature review of software architecture approaches that support the
implementation of Continuous Delivery (CD) and DevOps. Its goal is to provide an understanding of the state-
of-the-art on the topic, which is informative for both researchers and practitioners. We found 17 characteristics
of a software architecture that are beneficial for CD and DevOps adoption and identified ten potential software
architecture obstacles in adopting CD and DevOps in the case of an existing software system. Moreover, our
review indicated that micro-services are a dominant architectural style in this context. Our literature review
has some implications: for researchers, it provides a map of the recent research efforts on software architecture
in the CD and DevOps domain. For practitioners, it describes a set of software architecture principles that
possibly can guide the process of creating or adapting software systems to fit in the CD and DevOps context.
1 INTRODUCTION
The practice of releasing software early and often has
been increasingly more adopted by software
organizations (Fox et al., 2014) in order to stay
competitive in the software market. Its popularity
fueled the development of practices collectively
labeled as Continuous Delivery (CD) Chen, 2015a).
Over the past few years, the notion of CD organically
evolved and was further built upon to create what is
now known as DevOps (Bass et al., 2015). While
embracing CD and DevOps in their organizations,
many software development practitioners
experienced that not all styles of software
architectures are suitable for applying the CD
principles and practices, particularly in case of large
monolithic (Garousi et al., 2019) and highly coupled
architectures (Sturtevant, 2017; Bucchiarone, 2018;
Knoche and Hasselbring, 2018). Since both the CD
and DevOps movements are growing more mature
each year, it is important to have a clear
understanding on the various approaches of software
architecture that may or may not be suitable in this
context. This need motivated us to do a systematic
literature review (SLR) in order to create a state-of-
the-art understanding on adapting existing and
designing new software architectures tailored for CD
and DevOps practices.
For clarity, before elaborating on the subject of
this SLR, we present the definitions of the concepts
that we will address: Software architecture of a
system is the set of structures needed to reason about
the system, which comprise software elements,
relations among them, and properties of both
(Humble and Farley, 2010). Continuous Delivery
(CD) is a software engineering discipline in which
teams keep producing valuable software
incrementally in short cycles and ensure that the
software can be reliably released at any time (Chen,
2015; Humble and Farley, 2010). DevOps is a set of
practices intended to reduce the time between
committing a change to a system and the change
being placed into normal production, while ensuring
high quality (Bass et al., 2015). As one could see from
the definitions, CD and DevOps are quite overlapping
in their goals. Later in this paper, we will see that
there is indeed a strong relation between the two and
that DevOps practices rely heavily on the CD
principles. Since the two concepts are so similar, the
effect they have on software architecture is expected
to be very similar as well. This is why these two
concepts are both included in our SLR.
This paper is structured as follows. Section 2
describes the industrial relevance of the subject and
Bolscher, R. and Daneva, M.
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review.
DOI: 10.5220/0007837000270039
In Proceedings of the 14th International Conference on Software Technologies (ICSOFT 2019), pages 27-39
ISBN: 978-989-758-379-7
Copyright
c
2019 by SCITEPRESS Science and Technology Publications, Lda. All r ights reserved
27
our motivation for this SLR. Section 3 discusses
related work with particular focus on the potential
benefits of DevOps practices. Section 4 presents the
goal of this research effort. Section 5 describes the
method (Kitchenham, 2007) used for our SLR.
Section 6 presents the results to the research questions
of our SLR and describes other relevant topics found
in the literature. Section 7 is on the limitations to this
research. Section 8 presents the discussion of the
results. Section 9 concludes with summarized
answers to the research questions. Section 10 is about
future work.
2 MOTIVATION
DevOps is currently progressing from the “peak” of
the Gartner Hype Cycle for Application Services
towards the more valuable “plateau of productivity”,
according to a 2015 market research report by Cap
Gemini on DevOps (Menzel, 2015). This source also
states DevOps is evolving from a niche to a
mainstream strategy employed by 25% of Global
2000 organizations. Furthermore, according to the
2017 State of DevOps Report by Puppet and the
DevOps Research and Assessment Group (Kersten,
2017), the percentage of respondents claiming to
work on DevOps grew from 16% in 2014 to 27% in
2017. This report (Kersten, 2017) also found that high
performing DevOps IT organizations deploy software
46 times more frequently, have a 440 times shorter
lead time for implementing changes, and 96 times
faster mean time to recover (from downtime) and a 5
times lower change failure rate (in comparison to the
low performing DevOps IT organizations). In
general, one of the key conclusions of the report
(Kersten, 2017) is that lean product management
(including concepts such as CD and DevOps) drives
higher organizational performance. This means that
for IT organizations there is a lot to be gained through
the adoption of CD and DevOps practices. Although
a lot of research has been performed and practical
experience gained over the last 5 years (Ghantous and
Gill, 2017), to the best of our knowledge, little has
been done so far to consolidate the output of this
research in a systematic way and help develop a deep
understanding of the CD and DevOps phenomena. In
particular, we could find no literature source that
consolidates the published knowledge regarding the
relationship between the concept of software
architecture and CD and DevOps. Understanding this
relationship is important for shaping our
understanding of the architecture principles and
approaches that work in the context of CD and
DevOps and those that do not. We felt motivated to
respond to this need by carrying out a SLR aiming to
provide an overview of the latest developments of
software architecture approaches in the context of CD
and DevOps.
3 RELATED WORK
DevOps is not a strictly defined method; its
implementation varies a lot as shown in a recent
qualitative study on DevOps in practice (Erich et al.,
2017). Therefore, the desired and expected benefits of
implementing DevOps vary just as much. Erich et al.
(2017) indicated the varying benefits organizations
set out to achieve by initiating DevOps: reduced lead
and release time, improved problem solving,
feedback gathering and overall product quality,
increased velocity, and increased focus on new
features. These authors reported however that not all
these benefits were actually achieved by the
organizations that implemented DevOps: in fact, the
main benefits achieved in these authors’ case study
organizations were: higher deployment frequency,
shorter lead time, improved automated testing,
feedback gathering and problem solving, fewer
escalations (caused by friction between development
and operations departments), more public facing
services and an increased velocity.
Furthermore, a 2017 SLR on DevOps (Ghantous
and Gill, 2017) presents a set of 17 benefits that can
potentially be achieved by implementing DevOps.
These are all benefits found in literature up to 2017,
however it does not necessarily mean that all these
benefits are always achievable in practice.
Next, a case study on DevOps implementation in
an IT company in New-Zealand (Senapathi et al.,
2018) lists the realized benefits and their relations. It
reports two main categories of benefits, namely,
increased development team engagement and
improved customer experience. Furthermore, Chen
(2015b) presents from a practitioner’s perspective the
potential benefits of architecting for CD. The author
describes five categories of observed benefits after
moving 22 software applications to CD: accelerated
time to market, improved ability to consistently build
the right product, improved productivity and
efficiency, improved product quality and improved
customer satisfaction.
As these literature sources (Erich et al., 2017;
Ghantous and Gill, 2017; Senapathi et al., 2018;
Chen, 2015) suggest, there are many potential
benefits reported so far, and many of those are in fact
indicated by multiple authors. In what follows, we
ICSOFT 2019 - 14th International Conference on Software Technologies
28
aggregated and categorized the benefits reported by
these sources in three categories: (1) benefits
pertaining to culture, (2) to product quality, and (3) to
development and operations processes. Some benefits
might be considered in more than one category (albeit
rephrased), however for the sake of simplicity this is
kept to a minimum.
Culture: The main cultural benefit to be achieved by
implementing DevOps is that teams are happier and
more engaged. The benefits in this category include:
B1. Higher level of autonomy;
B2. Learning new technologies;
B3. Feeling valued;
B4. Improved collaboration;
B5. Knowledge sharing;
B6. Natural communication;
B7. Less of a blaming culture;
B8. Fewer escalations (caused by Dev vs. Ops
friction).
Product Quality: Organizations implementing
DevOps report to be able to create higher quality
products faster and therefore create a better customer
experience. The benefits in this category include:
B9. Shorter lead time;
B10. Improved code quality;
B11. Automated testing (quality assurance);
B12. Real time, automated monitoring;
B13. Continuous innovation;
B14. Frequent deployment;
B15. Better scalability;
B16. Less down time.
Development and Operations Processes: DevOps
teams remove the friction between the previously
separated development and operations departments
and create understanding for each other’s problems.
Furthermore, processes are highly automated and
traceable which improves the overall velocity of the
software development and lowers the chance of bugs
ending up in released software. The benefits in this
category include:
B17. Continuous planning;
B18. Parallel deployment;
B19. Continuous integration;
B20. Improved cloud and database management
(infrastructure-as-code);
B21. Easy code rollback;
B22. Improved feedback gathering;
B23. Secure pipeline;
B24. Automated deployments;
B25. Scalable, repeatable, traceable and
automated processes.
4 RESEARCH GOAL
The goal of this SLR is to analyse the published
scientific output on the topics at hand in order to
create an overview of the issues and requirements for
software architecture design in the context of CD and
DevOps. These requirements could possibly be used
to create a set of software architecture principles that
can guide software developers and architects in the
process of creating or adapting a software system to
be used in a CD and DevOps context.
To this end, the central research question of this
SLR is the following: What software architecture
approaches support the implementation of
Continuous Delivery and DevOps, according to
published literature?
This question has been decomposed in three sub-
questions:
RQ1. What are the potential software
architectural problems when adopting CD and
DevOps practices on an existing software
system?
RQ2. What characteristics of a software
architecture are important for enabling CD and
DevOps?
RQ3. What software architecture styles are
suitable for being used in a CD and DevOps
context?
5 RESEARCH PROCESS
Our SLR is conducted following the guidelines of
Kitchenham (2007). These were complemented with
the guideline of Kuhrmann et al. (2017). These
guidelines define a process including three phases: (1)
planning, (2) conducting, and (3) reporting. The first
two phases have some (sub-) stages associated with
it; planning consists out of the identification of the
need for a review (see Section 2) and the development
of the review protocol (see Section 5.1). The third
phase, reporting, consists out of identification of
research, selection of primary studies, study quality
assessment, data extraction and monitoring, and data
synthesis (see Section 6).
5.1 Review Protocol
In order to find relevant articles, two digital
repositories of scientific publications were queried:
Scopus and Web of Science. We chose them, because
they are comprehensive and also because our
university had subscriptions to both. The search string
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review
29
( "software architecture" AND ( "continuous
delivery" OR "continuous deployment" OR
"devops" OR "dev-ops" OR "dev ops" ) ) was used.
The search was carried out on May 14, 2019. It was
applied to the Title, Abstract and Keyword sections
of the Scopus database, and to the Title, Abstract and
Topic sections of Web of Science. The queries
formatted and refined for each repository can be
found in the Appendix items “Scopus search query”
and “Web of Science Search Query”.
This search string is composed as presented above
since this research is focused on the intersection of
software architecture and CD/DevOps, hence the
query combines these concepts. Performing the
search resulted in 39 papers from Scopus over a time
span of 9 years (2010-2019). Executing the same
query on Web of Science resulted in 15 papers over a
time span of 5 years (2014-2018). Looking at the
number of papers published per year it appears that
2015 through 2017 were the most active years.
Therefore, we chose to only include papers published
after Jan 1, 2015. This ensured that our SLR contains
the most relevant and up-to-date literature.
We used the following inclusion and exclusion
criteria for selecting papers out of the search results
obtained in the previous step.
Inclusion Criteria:
I1. The paper discusses as its core topic either
DevOps or CD in a software architecture
domain;
I2. The paper takes a practical point of view on the
problem domain (e.g. a case study or
expert/practitioner experiences and opinions).
Exclusion Criteria:
E1. The paper is published before Jan 1, 2015;
E2. The paper presents no link to DevOps, CD or
similar practices;
E3. The paper is purely theoretical;
E4. The paper is a duplicate of a paper that was
already found either in Scopus or in Web of
Science and has already been included;
E5. The paper is not written in English.
After applying exclusion criterion E1, Scopus
provided 36 papers, and Web of Science ̶ 14. Since
there are many publications on both software
architecture and CD/DevOps, inclusion criterion I1
and exclusion criterion E2 were added to filter the
materials that are not in any way applicable or related
to both of these topics. It is the intersection of these
subjects that we are interested in. Inclusion criterion
I2 and exclusion criterion E3 were added to find
published work presenting real-world experiences.
Since this research is mainly conducted to help
practitioners with the potential problems arising from
applying CD/DevOps on their software architectures,
it is important to explore the real-world practice by
using case study-based research methods, expert
interviews or practitioners’ perceptions and personal
experiences. Exclusion criterion E5 was added for
obvious reasons. The initial selection of all 49 papers
was done by applying the inclusion and exclusion
criteria by reading the papers title, abstract and
metadata.
After the initial filtering, only 23 papers were still
in scope of this SLR. There were many duplicates
found between the results of Scopus and Web of
Science. The papers that passed the initial filtering
were read in detail and filtered by re-applying the
inclusion/exclusion criteria. After the second
selection round, there were 13 papers left, these
finally represent the body of literature to be used in
the final stage of Kitchenham’s SLR method (2007):
data extraction and monitoring, and data synthesis.
The papers are: Stutevant, 2017; Chen, 2015b; Erder
and Pureur, 2015; Woods, 2016; Shahin et al., 2016;
Elberzhager et al., 2017; Villamizar et al., 2015;
Schermann et al., 2018; Stahl and Bosch, 2018; Pahl
et al., 2018; Berger et al., 2017; Chen et al., 2015;
Bass, 2017.
6 RESULTS
Our selected papers and their mappings to our RQs
are presented in Table 1. Note that two of the papers
(Erder and Pureur, 2015; Woods, 2016) are not
included in this table because they could not be
properly mapped to any research question (i.e. they
talk about architecture and CD/DevOps, but do not
shed light on our RQs).
Table 1: Literature results mapped onto RQs.
Research question
Reference
RQ1. Issues
Shahin et al., 2016; Elberzhager
et al., 2017;Villamizar et al.,
2015; Schermann et al., 2018;
Stahl and Bosch, 2018
RQ2.
Characteristics
Stutevant, 2017; Chen, 2015b;
Shahin et al., 2016; Pahl et al.,
2018; Berger et al., 2017; Chen et
al., 2015
RQ3. Styles
Shahin et al., 2016; Elberzhager
et al., 2017; Villamizar et al.,
2015; Schermann et al., 2018;
Pahl et al., 2018; Berger et al.,
2017; Chen et al.2015; Bass, 2017
ICSOFT 2019 - 14th International Conference on Software Technologies
30
As indicated in Table 1, there are papers that
discuss potential software architectural issues of
implementing CD/DevOps on existing systems in a
meaningful way. Furthermore, 6 papers mention
important software architectural characteristics, and 8
papers discuss some form of software architecture
style, all in the context of CD/DevOps.
Before presenting the answers to our RQs, it is
worthwhile mentioning that a number of authors of
our set of 14 papers, emphasize the importance of the
intersection of DevOps and software architecture. We
observe in five out of the 14 papers make explicit
statements on this. Chen et al. (2015) describe the
importance of software architecture with regard to
DevOps as follows: one cannot realize DevOps in a
scalable way without building this into the
architecture”. These authors also state that
architectural tactics must be implemented system-
wide to support DevOps objectives (Chen et al.,
2015). Furthermore, Pahl et al. argue that in order to
address continuous service systems development and
operation a particular software architectural style is
needed (Pahl et al., 2018). Len Bass, author of the
seminal book DevOps: A Software Architect's
Perspective (Bass et al., 2015), states in his paper
(Bass, 2017) that “the architect is critical for success
in adopting DevOps practices”. Shahin et al. (2016)
report on the growing realization that implementing
CD/DevOps may necessitate software architectural
modifications, and even go as far as saying that
software architecture should take the lead when
implementing CD. These statements further
reinforced our believe that if we make a contribution
to the body of knowledge on the topic of software
architecture and CD/DevOps by means of this SLR,
our work would possibly be of service to a wider
audience than originally thought (at the moment when
we initiated this work).
In what follows, we summarize the literature as it
relates to our RQs.
6.1 Software Architecture Issues
This section pertains to RQ1. We observe that all five
papers (Shahin et al., 2016; Elberzhager et al., 2017;
Villamizar et al., 2015; Schermann et al., 2018; Stahl
and Bosch, 2018) discussing architecture issues agree
that it is not trivial to adopt CD/DevOps practices on
an existing system.
Our examination of these papers yielded 10
software architecture issues which we present in
Table 2. In fact, these are architectural obstacles in
the adoption of CD/DevOps. Elberzhager et al. (2017)
identify four key issues that are important to consider
before moving towards implementation of DevOps,
one of them is about the possible impact on the
current software architecture (Elberzhager et al.,
2017). What is more, Elberzhager et al. argue that “in
the case of an existing software product, a detailed
analysis is needed as to the degree to which it can
support the goals to be achieved with the DevOps
approach“.
Table 2: Identified issues.
ID
Issue
Reference
IS1
Scaling
Villamizar et al., 2015
IS2
Decomposition
Scherman et al., 2018
IS2
Methods and tools
Elberzhager et al., 2017;
Stahl and Bosch, 2018
IS4
Highly coupled
(monolithic)
systems
Shahin et al., 2016
IS5
Ever-changing
operational
environments and
tools
Shahin et al., 2016
IS6
Monolithic
database
Shahin et al., 2016
IS7
Application level
dependencies
Shahin et al., 2016
IS8
Testing
Shahin et al., 2016
IS9
Logging
Shahin et al., 2016
IS10
Monitoring
Shahin et al., 2016
When an application is not designed to scale
(IS1), it is very difficult to apply DevOps practices,
an important aspect of which is the presence of a
highly automated infrastructure. This issue has a
direct connection with highly coupled (monolithic)
systems (IS4), since these systems are often not
scalable by design. Scaling monolithic applications is
a problem because they are composed of many
internal services and if a service needs to be scaled
due to increasing load, then the whole monolith has
to be scaled up (Villamizar et al., 2015). Another
problematic aspect of the monolithic codebase is its
monolithic database (IS6). Many systems, which are
not designed for decomposability, rely on a central
database. This becomes a problem when the software
architecture changes into a more loosely coupled,
individually deployable, set of components. The
database can form a choke-point for operations as it
remains an undeployable (and unscalable) unit.
A first step to make an existing monolithic system
more scalable is increasing its decomposition, which
ultimately enables DevOps practitioners to scale
individual components of the system instead of the
whole. However, many systems are not
decomposable as is (IS2). Even if a system is
decomposed into multiple (separately deployable)
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review
31
components, new issues arise such as tracing errors
and finding root causes of production issues traveling
through multiple system components (Schermann et
al., 2018). Moreover, dependencies on application
level (IS7) inhibit decomposition and decrease the
deployability of a system (Shahin et al., 2016).
One of the cornerstones of CD/DevOps is tool
support. However, finding and incorporating proper
tool support is a challenge on its own (IS3). For
example, continuous integration (CI) systems can
become rather complex, such that they need their own
development and operations team taking care of
evolving and maintaining the CI workflow of the core
products. Ståhl and Bosch (2017) even developed an
architecture framework specifically for CI/CD
systems, which indicates the potential complexity of
the tools needed for CD/DevOps adoption. They also
report that “as a rule, continuous integration and
delivery systems are highly customized and purpose-
built software products”.
Shahin et al. (2016) point out that another
challenge at architectural level was the influence of
ever-changing environments and tools on
architecture design to enable CD practice“. These
authors reports that practitioners may have had issues
transferring and deploying systems in various
heterogeneous operations environments (IS5).
Next, testing is another prominent obstacle that
needs to be overcome when moving towards
CD/DevOps (IS8). This issue consists of three sub-
issues: (i) improving test quality, (ii) making code
more testable, and (iii) test automation (Shahin et al.,
2016). For example, automated testing is a core pillar
of DevOps. Without it DevOps engineers cannot
quickly determine the quality of the software that is
to be deployed. This is because failure to do it
consistently, would result in either (much) slower
deployments, or decreased software quality, both
which are undesired.
Finally, logging and monitoring are increasingly
important when the CD/DevOps adoption becomes
more mature. Highly automated pipelines, as a result
of CD/DevOps, enables practitioners to deploy
software to production faster than ever before, also
including bugs. Some will slip through the
(automated) testing process, therefore the authors of
(Schermann, 2018) state that monitoring is a
prerequisite for keeping practitioners aware of events
in the production environments. CD increases the
complexity of deployment process, which necessitates
designing and implementing sophisticated logging
and monitoring mechanisms” (Shahin et al., 2016).
6.2 Beneficial Software Architecture
Characteristics
This section reports the results related to RQ2. Table
3 summarizes our findings. We found 17 software
architecture characteristics that our selected literature
sources deemed beneficial. These are listed in the
second column of Table 3. In the third column, we
present the papers addressing each characteristic. The
number of references in the rightmost column clearly
indicates those software architecture characteristics
have been treated most frequently in relation to
CD/DevOps in scientific literature; these are:
deployability (CH2), testability (CH11), automation
(CH3), loosely coupled (CH6), modifiability (CH1).
It is not surprising that deployability (CH2) is the
most prevalent software architecture characteristic
that according to our selected literature would enable
CD/DevOps adoption. Chen et al. (2015) argue that
CD “requires architectural support for deploying
without requiring explicit coordination among
teams”. Chen (2015b) describes a list of
Architecturally Significant Requirements (ASRs)
which the author defines as “requirements that have
a measurable impact on a software system’s
architecture”, one of these ASRs is deployability.
Adding to that, Chen states that one of the aspects of
a deployable architecture is being able to deploy
software without downtime and moving the software
quickly between different environments (e.g. testing,
production). Furthermore, Shahin et al. (2016) have
identified five main architectural principles. The first
one is concerned with small and independent
deployment units such as services, components but
also the database. Furthermore, Bass (2017) discusses
that the ability to continuously deploy depends on the
system architecture and the possible team
dependencies arising from this architecture.
Modularity (CH15) is a way to make a software
system more deployable (Shahin et al., 2016; Pahl et
al., 2018), by reducing dependencies and isolating
changes in the software. Another related
characteristic is the use of stateless components
(CH5). Berger et al. (2017) discovered that in order
to improve the deployability and elastic scaling
process it helps to make services/components
stateless so that they can be stopped and restarted
without causing issues.
Sturtevant (2015) states: “Architecture will
become the biggest bottleneck to your DevOps
transformation. You need a balanced focus on agile
process and agile architecture” (CH1). Chen et al.
(2015) describe a DevOps tactics tree that consists of
tactics (a checklist of architectural concerns) that
ICSOFT 2019 - 14th International Conference on Software Technologies
32
would help enable the achievement of DevOps goals.
One of the top level tactics of this tree is architecture
modifiability (CH1). Chen (2015b) also discusses
modifiability as one of the ASRs.
Table 3: Software architecture characteristics supporting
CD/DevOps.
ID
Software
architecture
characteristics
Reference
CH1
Agility/Modifiabilit
y
Stutevant, 2017;
Chen, 2015b; Chen et
al.2015;
CH2
Deployability
Chen, 2015b; Chen et
al.2015; Shahin et al.,
2016; Bass, 2017
CH3
Automation
Berger et al., 2017;
Chen et al.2015; Bass,
2017
CH4
Traceability
Berger et al., 2017;
Bass, 2017
CH5
Stateless
components
Berger et al., 2017
CH6
Loosely coupled
Stutevant, 2017; Pahl
et al., 2018; Berger et
al., 2017
CH7
Production
versioning
Chen et al.2015;
CH8
Rollback
Chen et al.2015;
CH9
Availability
Chen et al.2015;
CH10
Performance
Chen et al.2015;
CH11
Testability
Chen, 2015b; Shahin
et al., 2016
CH12
Security
Chen, 2015b
CH13
Loggability
Chen, 2015b; Shahin
et al., 2016
CH14
Monitorability
Chen, 2015b
CH15
Modularity
Shahin et al., 2016;
Pahl et al., 2018;
CH16
Virtualization
Pahl et al., 2018;
CH17
Less reusability
Shahin et al., 2016
Another important software architecture
characteristic on Chen’s ASR list (2015b) is
testability (CH11). As the software moves through
the CD pipeline it is subjected to tests at different
stages to ensure the software is of known quality and
ready for release. The author states that good
testability needs to be implemented on the
architectural level to make certain that developing
tests is feasible and cost effective. Testability is also
one of the five main architectural principles presented
by Shahin et al. (2016). The authors distinguish
between improving test quality, making code more
testable and test automation, and in general argue that
testability should be approached from an architectural
point of view first. Finally, the DevOps tactics tree
considers testability as one of the top level tactics
(Chen et al., 2015).
Sturtevant et al. state that loosely coupled (CH6)
architectures increases the performance in a DevOps
environment by decreasing application and inter-
team dependencies generally found in highly coupled
architectures (Sturtevant, 2017). In the same vein,
Pahl et al. (2018) state that one of the cloud
architecture principles is loose coupling, this is
especially important in the context of cloud resource
virtualization and elastic scaling. Berger et al. (2017)
note that loose coupling (in the form of a publish-
subscribe pattern) is important to the software
architecture in the context of CD/DevOps.
Automation (CH2) is one of the key principles of
CD/DevOps and is paramount to a successful
implementation. Chen et al. state that “everything
must be automated” and they stress that the
architecture should support this (Chen et al., 2015).
Additionally Bass points out that DevOps practices
rely heavily on tool support and automation, and that
it is the task of the architect to guide and support the
developers in setting up the automation processes
with the appropriate tools (Bass, 2017). Finally,
Berger et al. state that the deployment procedure
should be automated to avoid manual interaction and
increase overall deployment speed 9berger et al.,
2017).
Once a system is decomposed into many services
it becomes more difficult to see where in the system
an error originated and how it travelled through
several services. Traceability (CH4) of errors is
therefore an important characteristic to consider in the
architecture (Bass, 2017). There is another side to
traceability, namely, tracing software sources
throughout the integration and deployment process.
Bergeret al., (2017) states that due to the many
releases it is important to be able to trace a piece of
software running in production back to a commit.
This, in turn, creates certainty regarding those pieces
of code that are actually running in production and
helps for potential debugging or auditing purposes.
Chen et al. (2015) report on several other
characteristics: production versioning (CH7),
rollback (CH8), availability (CH9) and performance
(CH10). Production versioning refers to the ability to
have multiple versions of the same service in
production simultaneously, which improves the
deployability of the system by allowing for
deployment strategies such as canary releases. The
rollback characteristic is a useful safe guard because
deploying software systems many times a day
assumes that something would go wrong and then a
roll back can restrict the impact. Next, performance
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review
33
refers in fact to ‘scaling performance’, i.e. being able
to provision and deploy new instances of services,
which prevents the system from slowing down once
the load gets higher. Chen et al. (2015) also mention
availability (CH9), however from the text it does not
become clear why this would be more applicable to
CD/DevOps practices, it seems that this characteristic
is more specific to the system being discussed in the
paper.
A less apparent characteristic is security (CH12).
Chen (2015b) stresses that during start-up an
application might be more vulnerable compared to
when it is fully started, since CD/DevOps increases
the deployment frequency applications will start and
stop more often. The author also describes other
characteristics, loggability (CH13), and
monitorability (CH14). These two characteristics
both have the same goal: to give DevOps engineers
more control and information over the complex
production environment. When having a lot of
services in production (which are replaced often by
deploying) it is important to have proper (centralized)
log aggregation in place (Shahin et al., 2016). This
ensures that information, requests and errors can be
followed when they travel through multiple services.
Pahl et al. (2018) add an important characteristic,
namely virtualization (CH16), which refers
specifically to infrastructure virtualization known as
is one of the cornerstones of DevOps ( the so-called
infrastructure-as-code). In their research,
virtualization (of infrastructure) enables elastic
scaling and quicker (repeatable), more fault tolerant
deployments, it also enables developers (with less
operations experience) to work with the
infrastructure.
The final characteristic, less reusability (CH17),
goes against what developers have been doing for
many years. With the popularity of DRY (meaning
don’t repeat yourself) i.e. a principle to reduce
repetition in software developers were told to reuse
as much code as possible (e.g. by creating complex
abstractions). However, Shahin et al. (2016) report
that “focusing too much on reusability can be a huge
bottleneck to continuously deploying software”. The
main argument against reusability in CD/DevOps
context, according to the authors, is that it hinders the
deployability of autonomous teams by creating more
dependencies between software components. It is also
argued to be a threat to testability and overall
development velocity.
6.3 Software Architecture Styles
This section is concerned with discussing literature
found related to RQ3. In our SLR, there are 8 papers
that discuss architectural styles in the context of
CD/DevOps. There is a dominant architectural style
present in these papers: micro-services. All 8 papers
either discuss micro-services or present them as the
“go-to” architectural style for CD/DevOps practices.
We observe that only 2 out of the 8 papers also
mention other architectural styles or patterns.
Micro-services are a set of small services that can
be developed, tested, deployed, scaled, operated and
upgraded independently, allowing organizations to
gain agility, reduce complexity and scale their
applications in the cloud in a more efficient way.
Besides that, micro-services are very popular, they
are being used and promoted by industry leaders such
as Amazon, Netflix and LinkedIn (Villamizar, 2015).
Shahin et al. describe micro-services as the first
architectural style to be preferred for CD practice, by
designing fine-grained applications as a set of small
services (Shahin et al., 2016).
Three papers (Stahl and Bosch, 2018; Pahl et al.,
2018; Berger et al., 2017) state explicitly some
specific benefits of employing the micro-services
architecture concept. Micro-services are said to be
helpful in increasing modularity and isolating
changes and as a consequence increasing deployment
frequency (Bass, 2017). An experience report by
Berger et al. (2017), where the authors implemented
CD practices in a team developing software for self-
driving cars, reports how a loosely coupled micro-
service architecture helped them move towards CD.
Chen et al. argue that micro-service architectures
feature many of the CD/DevOps enabling
characteristics (CH2, CH7, CH8) and are (in
combination with DevOps) the “key to success” of
large-scale platforms (Chen et al., 2015).
Three other papers (Shahin et al., 2016;
Elberzhager et al., 2017; Schermann et al., 2018)
explicitly state some downsides of the micro-services
architecture. E.g. tracing errors and finding root
causes of production issues traveling through
multiple system components (Schermann et al.,
2018), resulting in increasingly complex monitoring
(IS10) and logging (IS9) (Shahin et al., 2016). Plus,
at the inception stage of a project a micro-services
architecture might be less productive due to the
required effort for creating the separate services and
the necessary changes in the organizational structure,
eventually as the project matures the efficiency of the
micro-services architecture surpasses that of the
ICSOFT 2019 - 14th International Conference on Software Technologies
34
monolithic architecture though (Elberzhager et al.,
2017).
Other authors (Villamizar et al., 2015; Schermann
et al. 2018; Pahl et al. 2018) treat the suitability of the
concept of micro-services in a particular context. Pahl
et al. (2018) state that the idea of micro-services has
been discussed as a suitable candidate for flexible
service-based system composition in the cloud in the
context of deployment and management automation.
Furthermore, Schermann et al. (2018) look at
micro-services from a continuous experimentation
perspective which is based on CD. These authors state
that “continuous experimentation is especially
enabled by architectures that foster independently
deployable services, such as micro-services-based
architectures”.
Micro-services emerged as a lightweight subset of
the Service-Oriented Architecture (SOA), it avoids
the problems of monolithic applications by taking
advantage of some of the SOA benefits (Villamizar et
al., 2015). Pahl et al. (2018) note that loose coupling,
modularity, layering, and composability are guiding
principles of service-oriented architectures.
The last architectural style is vertical layering. It
is mentioned by Shahin et al. (2016) and refers to
removing team dependencies by splitting software
components into vertical layers (instead of horizontal
layers, e.g. presentation, business and persistence). It
can be argued if this is an architectural style on its
own, as it is also a characteristic of micro-services
and SOAs in general.
6.4 Software Architecture Methods
This section discusses four interesting concepts that
we found in the selected literature and that are not
directly related to our RQs, but still are relevant to the
problem domain addressed in our research.
The first one is the concept of Evolutionary
Architecture which is designed to support
incremental change to the architecture in CD context.
Shahin et al. (2016) report the increased popularity of
Evolutionary Architecture amongst the participants in
these authors’ research on CD, opposed to big upfront
architecture.
The second is the concept of Continuous
Architecture (CA), which refers to the method of
managing the architecture originating from the need
to encompass CD in the architecture process. A very
clear way to explain the concept of CA is cited from
the book on the subject by Erder and Pureur (2015):
“if our objective is to build a cathedral, an Agile
developer will start shoveling, but an enterprise
architect will look at a 5-year plan, the goal of
Continuous Architecture is to bridge this gap”. There
are six CA principles defined in the book by Erder
and Pureur:
1. Architect products not just solutions for
projects.
2. Focus on quality attributes not on functional
requirements.
3. Delay design decisions until they are absolutely
necessary.
4. Architect for change leverage “the power of the
small”.
5. Architect for build, test and deploy.
6. Model the organization of your teams after the
design of the system.
Finally, Woods (2016) puts forward two other
concepts instrumental to the architecture process: (i)
release models and (ii) configuration management
models. Release models describe the process of
moving an application from the developer’s machine
to the production environment, while configuration
management models help to get a grasp on the
complex configuration spread out among the various
micro-services.
7 LIMITATIONS
A limitation to this study is the time span for which
papers are included (2015-2019). There is always a
risk that a potentially relevant paper is excluded by
enforcing this criterion. However, we have
reasonable grounds to believe this risk is rather low.
First, DevOps was only coined as a concept in 2009
when Patrick Dubois organized the first DevOps
Days conference (https://legacy.devopsdays.org/
events/2009-ghent/ ). In the next 5 years (2009-2014),
research interest was minor: using the search queries
found in the Appendix, there were only 3 papers
published in the period 2010-2014. This is in stark
contrast to the period 2015-2018, when 62 papers
were published. From this we can conclude that by far
the largest part of relevant literature has been
included.
Another limitation to this study could be that only
two scientific databases were used (Web of Science
and Scopus). This might have reduced the variety of
searchable literature. However, bibliographic studies
(Harzing and Alakangas, 2016; Mongeon and Paul-
Hus, 2016) on the coverage of Scopus and Web of
Science suggest that it is one of the broadest and the
most comprehensive searchable digital libraries.
Therefore, we think that the chance of missing a study
is relatively low.
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review
35
As part of preparing this paper, we reviewed
practitioners’ articles from developers community
online magazines and industry-wide blogs that cover
DevOps and related technologies: www.devops.com
and www.devopsdigest.com. These two sites seemed
relevant to our research in order to understand
whether the practitioners’ sources align with our
findings. We searched these DevOps sites for papers
by using “software architecture” as a search word. We
then chose 20 papers from each site and looked in
there for information related to our RQs. In this
review, we however could not find a paper that
provided information that was contradicting our
findings. Nor information that adds to the lists
presented in Tables 2 and 3. Of course, although this
step was done in a structured way, it is not to mean
that we compare it with a fully planned and executed
systematic examination of grey literature (the
practitioners’ papers from community sites are in fact
grey literature in the sense of Garousi et al. (2019)).
We think that such examination that includes online
community platforms in DevOps and CD is a
worthwhile piece of work because only then we could
develop a more complete understanding of what
happens in practice.
8 DISCUSSION
Using Kitchenham’s literature quality assessment
guidelines (2007), the papers were ranked (see Table
4) on a scale from 1 to 5, where 1 means high quality
and 5 means low quality. The result of this ranking is
shown in Table 4, se the second column. It must be
noted that the applicability of the quality assessment
ranking schema (Kitchenham, 2007) could be
questioned in the context of this research, as
Kitchenham’s ranking is based upon the research
method used in the respective primary studies (i.e. the
publications included in the set). We observe that
very few of the papers collected evidence
systematically by using a research method that was
also explicitly described in much detail. Most of the
papers included in our SLR report on the
accumulation of experiences and anecdotic evidence
by practitioners (e.g. Chen, 2015b). In turn, as our
included papers did not have extensive presentation
of research methods being employed, all papers have
a relatively low quality ranking (see Table 4). This is
important to take into account when reviewing the
results of this SLR. We think there might be two
reasons for the low quality: first, it can be the
relatively young field of research (which is growing
since 2014/2015); second, it can be the fact that the
CD and DevOps are ideas created in industry, with
industry taking the lead in publishing, compared to
scholars.
Table 4 Literature quality assessment and countries of
origin of the 13 selected papers.
Quality
Assessme
nt Rank
Origin
5
USA
4
China
5
USA
5
UK
5
Australia
2
Germany
2
Colombia
5
Switzerland/
Austria
5
Sweden
5
USA
5
Sweden
5
USA
5
USA
Another important aspect of the papers included
in this SLR is the country or region of origin. As the
third column of Table 4 shows, there is quite a variety
in origin of the papers included in this SLR. This
results in a representative body of literature that
encompasses various organizational cultures,
working styles and values. This allows us to think that
our findings could possibly be generalizable
(Wieringa and Daneva, 2015) across organizations in
various countries.
A set of 10 potential software architectural issues
has been identified in this paper. This set is not
exhaustive and rather generic, however, it does create
an image of the problems that practitioners might
have to deal with when adopting CD/DevOps
practices (on existing software systems). Some are
rather obvious, such as decomposition and monolithic
architectures, others are less straightforward, such as
logging and monitoring in order to improve or retain
the traceability capabilities of a system.
Furthermore, 17 software architectural
characteristics that are considered beneficial for
adopting CD/DevOps practices are presented. There
is a clear Top-5 of most frequently discussed
characteristics. It is apparent that there is some
overlap to be found between the identified issues and
the beneficial characteristics. These beneficial
characteristics cannot directly be classified as
solutions to the software architectural issues, e.g.
testability (CH11) is not a solution to the problem
domain of testing (IS8). However, the characteristics
ICSOFT 2019 - 14th International Conference on Software Technologies
36
indicate what features of a software architecture
should be focused on in order to prevent or overcome
the potential issues. The overlap between the issues
and characteristics identified in the literature only
strengthens their individual relevance to the problem
domain.
We identified micro-services as the most
dominant software architecture style that appears in
literature with respect to CD/DevOps. All 8 papers
that discuss a form of software architecture styles
mention (or are solely centred around) micro-
services. This was expected, due to the popularity of
the style among practitioners and the fact that micro-
services are designed to be independently developed
and deployed. Many, if not all, of the beneficial
software architectural characteristics are in some way
addressed by the micro-services architecture style.
Therefore, it seems that micro-services can be
considered the answer to the main research question
of this paper. We however think that this does not
mean that the micro-services style itself does not
bring any new problems, e.g. traceability, monitoring
and logging are becoming increasingly complex
when applying the micro-services architecture style.
More research is needed in order to better understand
the possible “side effects” of deploying micro-
services in real world projects.
Furthermore while the selected literature in this
work answered our RQs, these literature sources also
touched upon a rather interesting topic: Evolutionary
and Continuous Architecture. Both are considered as
approaches of managing the architecture, which are
designed to support incremental change to the
architecture. This is in contrast to more conventional
up-front architecture development methods, such as
the well-known waterfall model Royce (1987) or the
BDUF (Big Design Up Front) approach (these are not
primarily software architecture development methods
but do put emphasis on finalizing the architecture
design before actually writing the software).
Evolutionary and Continuous Architecture seem to
bridge the gap between agile development methods
(short term) and enterprise architecture (long term).
This SLR could not go into depth regarding the topics
of Evolutionary and Continuous Architecture, but it
might be interesting for future research efforts to
establish a link between software architecture in a
CD/DevOps context and a form of
Evolutionary/Continuous Architecture.
9 CONCLUSION
This section summarizes the answer to our RQs.
RQ1: What are potential software architectural
problems when adopting CD and DevOps practices
on an existing software system?
Since Jan 1, 2015, five papers were published that
discuss software architectural problems when
adopting CD/DevOps practices on an existing
software system. From these five papers, 10 distinct
problems were identified and reported in Table 2. The
main architectural problem is traceable to the
presence of highly-coupled monolithic systems that
are hard to decompose for CD practices.
RQ2: What characteristics of a software
architecture are important for enabling Continuous
Delivery and DevOps?
From the six papers found in recent literature that
discuss aspects or characteristics of software
architectures that are important for enabling
CD/DevOps, 17 (mostly distinct) characteristics were
identified (see Table 3). Out of those, the Top-5 most
frequently discussed characteristics are:
Deployability (CH2), Testability (CH11),
Automation (CH2), Loosely coupled (CH6), and
Modifiability (CH1).
RQ3: What software architecture styles are
suitable for being used in a Continuous Delivery and
DevOps context?
Eight out of the 13 papers in our SLR discussed
some form of software architecture style that would
be suitable for use in a CD/DevOps context. Notable
is the fact that all the papers that discussed some form
of architecture style discussed micro-services. This
demonstrates the dominance of this particular style in
the research (and practitioners) domain. There were
other styles mentioned, service-oriented architecture
(of which micro-services is an implementation), and
vertical layering (though it can be argued that this is
not an architectural style on its own).
10 FUTURE WORK
This SLR has identified 10 distinct architectural
problems when adopting CD and DevOps practices
on an existing software system, the largest of these
issues is that of highly coupled monolithic systems.
Therefore, more research is necessary into efficient
and fault-tolerant methods to migrate existing
monolithic code bases towards micro-service
architectures in order to improve the adoptability of
CD/DevOps. The 17 characteristics that are important
for enabling CD/DevOps, identified in this research,
could be a contributing factor to that future research.
From another perspective, Continuous
Architecture (CA), could fill a void between short
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review
37
term software architecture and long term enterprise
architecture. It would be interesting to investigate the
role CA could play in enabling and improving
CD/DevOps practices.
Finally, the problems and characteristics
summarized in Table 2 and Table 3, respectively,
could possibly be translated into a work of reference,
a set of guidelines or a framework to help
practitioners deal with software architecture related
issues in the context of CD/DevOps. Developing such
guidelines could be instrumental for consolidating
practitioners’ knowledge of the field.
REFERENCES
Fox, A., D.A. Patterson, and S. Joseph (2014) Engineering
software as a service: an agile approach using cloud
computing. 2014: Strawberry Canyon LLC.
Chen, L. (2015a) Continuous delivery: Huge benefits, but
challenges too. IEEE Software, 32(2): p. 50-54.
Bass, L., I. Weber, L. Zhu (2015) DevOps: A Software
Architect's Perspective. Addison-Wesley.
Sturtevant, D. (2017) Modular Architectures Make You Agile
in the Long Run. IEEE Software, 35(1): p. 104-108.
Bucchiarone, A., et al. (2018) From Monolithic to
Microservices: An Experience Report from the Banking
Domain. IEEE Software, 35(3): p. 50-55.
Knoche, H., W. Hasselbring (2018) Using Microservices
for Legacy Software Modernization. IEEE Software,
35(3): p. 44-49.
Bass, L., P. Clements, R. Kazman (2003) Software
architecture in practice.Addison-Wesley.
Humble, J. and D. Farley (2010) Continuous Delivery:
Reliable Software Releases through Build, Test, and
Deployment Automation. Pearson Education.
Kitchenham, B. (2007) Guidelines for performing
Systematic Literature Reviews in Software
Engineering, Keele University, UK.
Menzel, G. (2015) DevOps - The Future of Application
Lifecycle Automation. [accessed July 11, 2018] https://
www.capgemini.com/wp-content/uploads/2017/07/
devops_pov_2015-12-18_final.pdf.
Kersten, N. (2017) The 2017 State of DevOps Report.
Puppet + DORA, Portland, US.
Erich, F., C. Amrit, M. Daneva (2017) A qualitative study
of DevOps usage in practice. Journal of Software:
Evolution and Process, 29(6): p. e1885.
Ghantous, G.B., A. Gill (2017) DevOps: Concepts,
Practices, Tools, Benefits and Challenges. In PACIS
2017 Proceedings. 96.
Senapathi, M., J. Buchan, H. Osman (2018). DevOps
Capabilities, Practices, and Challenges: Insights from
a Case Study. in Proceedings of the 22nd International
Conference on Evaluation and Assessment in Software
Engineering 2018. ACM.
Chen, L.P. (2015b) Towards Architecting for Continuous
Delivery. 12th Working IEEE/IFIP Conference on
Software Architecture, ed. L. Bass, P. Lago, and P.
Kruchten. 131-134.
Erder, M., P. Pureur (2015) Continuous Architecture:
Sustainable Architecture in an Agile and Cloud-Centric
World. Continuous Architecture: Sustainable
Architecture in an Agile and Cloud-Centric World.
2015. 1-303.
Woods, E. (2016) Operational: The Forgotten
Architectural View. IEEE Software, 33(3): p. 20-23.
Shahin, M., M.A. Babar, and L. Zhu (2016) The
Intersection of Continuous Deployment and
Architecting Process: Practitioners' Perspectives.
Elberzhager, F., et al. (2017) From Agile Development to
DevOps: Going Towards Faster Releases at High
Quality - Experiences from an Industrial Context, in
Software Quality: Complexity and Challenges of
Software Engineering in Emerging Technologies, D.
Winkler, S. Biffl, and J. Bergsmann, Eds. 33-44.
Villamizar, M., et al. (2015)Evaluating the monolithic and
the microservice architecture pattern to deploy web
applications in the cloud. 10th Computing Colombian
Conference (10CCC).
Schermann, G., et al. (2018) We're doing it live: A multi-
method empirical study on continuous experimentation.
Information and Software Technology, 99 (7), 41-57.
Ståhl, D., J. Bosch, (2017) Cinders: The continuous
integration and delivery architecture framework.
Information & Software Technology, 2017. 83(3) 76-93.
Pahl, C., P. Jamshidi, O. Zimmermann (2018) Architectural
Principles for Cloud Software. ACM Transactions on
Internet Technology, 2018. 18(2).
Berger, C., et al. (2017) Containerized Development and
Microservices for Self-Driving Vehicles: Experiences
& Best Practices. 2017 IEEE Int. Conf. on Software
Architecture Workshops. 7-12.
Chen, H.M., et al. (2015), Architectural Support for
DevOps in a Neo-Metropolis BDaaS Platform, in 2015
IEEE 34th Symposium on Reliable Distributed Systems
Workshop. 2015. p. 25-30.
Bass, L., The Software Architect and DevOps (2017) IEEE
Software, 35(1), 8-10.
Harzing, A.-W., S. Alakangas (2016), Google Scholar,
Scopus and the Web of Science: a longitudinal and
cross-disciplinary comparison. Scientometrics, 106(2),
787-804.
Mongeon, P., A. Paul-Hus (2016) The journal coverage of
Web of Science and Scopus: a comparative analysis.
Scientometrics, 106(1), 213-228.
Royce, W.W. (1987) Managing the development of large
software systems: concepts and techniques. in
Proceedings of the 9th international conference on
Erich, F., Amrit, C., Daneva, M.
(2014) A Mapping Study on Cooperation between
Information System Development and Operations.
PROFES’14, 277-280
Fritzsch, J., Bogner, J., Zimmermann, A., Wagner, S.
(2018) From Monolith to Microservices: A
Classification of Refactoring Approaches. DEVOPS
2018, 128-141
ICSOFT 2019 - 14th International Conference on Software Technologies
38
Kuhrmann, M., Méndez Fernández, D., Daneva, M. (2017)
On the pragmatic design of literature studies in software
engineering: an experience-based guideline. Empirical
Software Engineering 22(6), 2852-2891
Wieringa, R.J., Daneva, M. (2015) Six strategies for
generalizing software engineering theories. Sci.
Comput. Program. 101: 136-152
Garousi, V., Felderer, M., Mäntylä, M.V. (2019) Guidelines
for including grey literature and conducting multivocal
literature reviews in software engineering. Information
& Software Technology 106: 101-121
APPENDIX
Scopus search query
TITLE-ABS-KEY ( "software architecture" AND
"continuous delivery" OR "continuous
deployment" OR "devops" OR "dev-ops" OR
"dev ops" ) AND ( LIMIT-TO ( PUBYEAR ,
2018 ) OR LIMIT-TO ( PUBYEAR , 2017 ) OR
LIMIT-TO ( PUBYEAR , 2016 ) OR LIMIT-TO
( PUBYEAR , 2015 ) )
Web of Science search query
TOPIC: ("software architecture" AND
("continuous delivery" OR "continuous
deployment" OR "devops" OR "dev-ops" OR "dev
ops")) Refined by: PUBLICATION YEARS: (
2018 OR 2017 OR 2016 OR 2015 ) Timespan: Last
5 years. Indexes: SCI-EXPANDED, SSCI,
A&HCI, CPCI-S, CPCI-SSH, ESCI
Designing Software Architecture to Support Continuous Delivery and DevOps: A Systematic Literature Review
39
