The End of the Nightly Batch: How In-memory Computing and the

Cloud Are Transforming Business Processes

Antoine Chambille

and Gaëlle Guimezanes

Department of Research and Development, ActiveViam SAS, 46 rue de l’Arbre Sec, Paris, France

Keywords: Cloud, In-memory Computing.

Abstract: This paper illustrates our conviction that data processing relying on nightly batches is a thing of the past. It

shows how a complex analytics platform for huge amounts of data can be created from scratch in a matter of

minutes on the cloud, thus negating the need for dedicated on-premise machines that would do the job slower

at a higher cost. We also present the CloudDBAppliance project, where we aim at building a Cloud database

platform that will be available as a service, and will integrate the operational database with the tools for further

data analysis, eliminating the hassle of exporting the data for processing.

1 INTRODUCTION

This is perhaps the closest thing to a tradition in the

still-young field of IT. For decades, organizations

have used nightly batches to integrate and compute

all the changes registered during the day and deliver

to business users their data in the morning.

It was the best and often only way to move data

from operation systems onto analytical platforms for

decision-making without affecting live users. It was

also a practical way to complete complex calculations

on fixed-size hardware.

However, this is not true anymore. With both in-

memory computing and the Cloud having achieved

full technological maturity, calculations that were

previously too costly and had to be broken down into

manageable data chunks can now be conducted in

true real-time by in-memory solutions, while the

Cloud model provides the flexibility to deal with

business peaks, ensures a smooth user experience

throughout and erases the need to write off costly

hardware investments.

In this paper, we will benchmark ActivePivot

(ActiveViam, 2019), a reference in-memory analytics

database from ActiveViam, on the Cloud with some

of the most resource-intensive, real-world business

use cases today and see how this technology

combination can enable organizations to drive their

https://orcid.org/0000-0002-1344-4802

https://orcid.org/ 0000-0002-6933-9171

business in real-time, working with data that is either

continuously updated or loaded and aggregated on-

the-fly, and what benefits it brings to the business.

Ultimately, we will see that nightly batches have

become both unnecessary from a technical standpoint

and not competitive cost-wise.

2 TESTING A FINANCE

USE-CASE ON A CLUSTER ON

THE CLOUD

We simulated a use-case from the finance industry

based on ActiveViam’s experience working with the

largest banks in the world. Finance is one of the most

demanding verticals for analytical capabilities. We

loaded millions of transactions, prices and

sensitivities recorded for hundreds of historical dates,

amounting to 50 TB of data in memory across a

1,600-core cluster on Google Cloud. We wanted to

see if a combination of Google Cloud hardware and

services and ActivePivot in-memory technology

could achieve high-enough performances to perform

live analytics on such a volume of data during the

course of a regular work day, without relegating any

task to batch processing. We tested the scenario from

start to finish, including setup, loading, queries and

calculations.

654

Chambille, A. and Guimezanes, G.

The End of the Nightly Batch: How In-memory Computing and the Cloud Are Transforming Business Processes.

DOI: 10.5220/0007905606540659

In Proceedings of the 9th International Conference on Cloud Computing and Services Science (CLOSER 2019), pages 654-659

ISBN: 978-989-758-365-0

2.1 Setup and Loading

The exceptional storage and networking

infrastructure used by public cloud providers make it

possible to decouple storage from compute. They are

fast enough to load large datasets in minutes and

operate in-memory analytical platforms on demand.

At least that is the theory, because not every

software platform can be operated on-demand. In-

memory databases from Oracle, Microsoft and SAP

for instance are now available in the Cloud, but still

follow a monolithic architecture where storage is

attached to and managed by the database, and that

database is always on. To take full advantage of the

cloud model and effectively eliminate the need for

batch processing, another approach is needed that

decouples storage from compute and allows

customers to use memory resources on demand. In

practice it means storing data in object storage and

loading it on the fly at massive speeds in VMs, started

on demand and disposed of when the analysis is done.

We leverage the Google Cloud Platform to do just

that. We store the historical dataset in Google Cloud

Storage, we start servers on the fly when a user needs

them and shut them down when they are done. To

mount the data in memory and deliver analytics in the

hands of business users, we use the ActiveViam

platform.

In the following section we explain in practice

how we did it for a 50TB dataset (500 historical days,

100GiB per day). In short, we managed to start a

1600-cores, 64TB RAM cluster from scratch, load the

50TB in-memory and be ready to serve real-time

queries, all in less than 20 minutes...

2.1.1 Using Scripts to Set up a Whole

Infrastructure: In-memory Computing

without the Hassle

It can be difficult to take full advantage of in-memory

computing. Managing tens of server nodes

dynamically, optimizing data loading from cloud

storage, efficient memory allocation of billions of

records in terabytes of RAM or parallel computing on

hundreds of core and NUMA architectures are

difficult tasks. Fortunately, in a public cloud model

the cloud and the software providers take care of all

issues related to configuration and optimization, and

client organization only need to start the servers to

access almost immediately a fully-functioning

analytics platform.

In the case of Google Cloud and ActiveViam, you

can start and stop 100 servers if you want with a short

script calling cloud APIs or by describing resource

templates in tools such as the Google Deployment

Manager. All servers start with a given image, in our

case a Linux operating system configured with

memory intensive settings.

Example of an allocation loop from the script used

in the benchmark:

for ((i=0; i < 100; i++)) do

NODE_NAME="$INST_NAME-$NODE_TYPE-$i"

changeLine "TC_NODE_NUM" "$i"

"$STARTUP_SCRIPT_FILE"

echo "=== Creating new $NODE_TYPE

node [$NODE_NAME]..."

# Create node

gcloud compute instances create

$NODE_NAME \

--custom-cpu 32 --custom-memory

624 \

--custom-extensions \

--min-cpu-platform skylake \

--zone $ZONE \

--metadata-from-file startup-

script=$STARTUP_SCRIPT_FILE \

--tags http-server,https-server \

--image-project ubuntu-os-cloud \

--image-family ubuntu-1604-lts

$MACHINE_SPECS \

--async –quiet

done

Note that in this scenario, we take advantage of

“custom” instances in the Google Cloud Platform. It

allows us to tune the “memory-to-core” ratio, and

allocate servers optimized for in-memory computing.

In this case we allocate 100 servers with 32 vCPUs

(16 cores, Intel Xeon Skylake) and 624 GiB of RAM

(at the time of the experiment the maximum with

custom instances).

To take advantage of such a cluster (1600 cores,

64TB RAM!) you need the latest technological

advances: In-memory column stores,

multidimensional cubes, advanced memory

management that breaks the limits of garbage

collection on the Java platform, work stealing thread

pools to maximize the usage of the cores, MVCC to

support real-time incremental updates… You need all

that and more to deliver high definition analytics on

the fly. But you don’t need to learn how to do those

things. It’s integrated in the ActiveViam platform.

2.1.2 Data Loading

The next challenge is data loading. The dataset must

The End of the Nightly Batch: How In-memory Computing and the Cloud Are Transforming Business Processes

655

be transferred from cloud storage to the cluster within

minutes to satisfy the on-demand constraint, which

means we must move 50TB in minutes. This is where

you can really leverage the world class infrastructure

of a large public cloud provider.

We have 500 days of historical data, so we load 5

days per node (500GiB). The objective is that each

one of the 100 nodes downloads its data at maximum

speed, and that they all do it at the same time.

At the time of this test the maximum bandwidth

of the network interface in a GCP instance was 16

Gbit/s. So, an instance had the theoretical capacity to

transfer data at 2GiB per second. In this case the data

is actually downloaded from Google Cloud Storage

and the throughput of a data transfer is far less than

that, being HTTP based. ActiveViam developed a

special connector that opens tens of HTTP

connections to blob storage and performs the transfer

in parallel, transparently reconstructing blocks. With

this trick, a node running the ActiveViam connector

can saturate the 16 Gbit/s cap and actually download

500GiB in about 5 minutes.

Figure 1: Opening several connections to the storage for

each VM.

Of course, when 100 instances download their

500GiB concurrently and at full speed, Cloud storage

becomes the next bottleneck. This is where cloud

infrastructures are really put to the test, and during

our benchmark we observed impressive scalability

from Google Cloud Storage. The 50TB dataset was

entirely transferred from storage to the 100 nodes

cluster in less than 10mn, as shown on Figure 1.

That’s a monumental 90GiB/s effective throughput

between storage and compute, reached with possibly

the simplest and least expensive storage solution in

the cloud platform.

So, it takes a few minutes to start the GCP

instances, 10 minutes to transfer the data, and another

few minutes for the ActiveViam platform to get its in-

memory data structures ready. All together the entire

cluster is ready in about 20 minutes.

Figure 2: Downloading 50TB with 100 instances. Amount

of data downloaded per instance in GiB (Y axis) when time

passes (time in minutes on X axis).

It is fast enough to be started up at the beginning

of the work day, or at any time at the request of

business, without having to schedule a batch.

2.2 Benchmarking Queries for

Interactive Analysis

Finally, we looked at the performance of interactive

queries on this on-demand cluster. We performed two

different queries and check if they follow Gustafson’s

Law (Gustafson, 1988): queries on twice the dataset

should take the same time if you also double the CPU

power and RAM. Query 1 performs aggregations on

all the records of the dataset, Query 2 performs

aggregations on a filtered selection of records (about

10%).

We scaled up the cluster step by step, each time

doubling its size, from 1 VM to 100 VMs. Below you

can see that the scale-up is good: the query times are

close to constant. In the end, we only observe a 10%

difference between a query running on a single VM

and a query running on a 100-VMs cluster. Query

times, as shown on Figure 3, remain well under half-

a-second, which is fast enough to provide end users

with a comfortable, responsive experience for

analysis.

Figure 3: Scaling of ActiveViam queries. Time taken for a

query in ms (Y axis) per number of nodes (X axis).

ADITCA 2019 - Special Session on Appliances for Data-Intensive and Time Critical Applications

656

For this test, we deliberately simulated a use case

that is as challenging as the most demanding real-

world business, or even more. The lesson here is that

if it can free itself from batch processing, there isn’t

really any business case in the real world that cannot.

3 ONE INSTANCE ONLY: AN

ALTERNATIVE TO BATCH

PROCESSING FOR SMALLER

APPLICATIONS

The previous use-case that we just presented is

extreme, but most of the business applications that

currently use batch processing are in fact of a much

smaller scale. Some of the use-cases that we

encounter at ActiveViam are listed in Table 1. As we

can see, those use cases don’t need to be run on a huge

cluster and can be run on a single machine, even if

that machine needs to be one with large memory.

Table 1: Use-case and memory usage.

Use cases

Typical

memory usage

Dynamic pricing for online retailers, real-time

portfolio monitoring for one trading des

128 GB

Global Finished Vehicle Logistics management,

multichannel and geolocalized retail pricing

512 GB

Supply chain control tower for a global retailer,

market risk Value at Risk and Expected Shortfall

(FRTB regulation)

1 TB

Trade level xVA analytics for investment banks 4 TB

3.1 An Affordable Alternative on

Public Clouds

Dedicated in-memory computing servers on premise

have experienced a slow progression over the last 10

years. Such machines remain expensive and their

specific configuration means they cannot be

repurposed as easily as more conventional hardware.

They represent a significant investment that, like all

hardware purchases, will depreciate over time and

eventually will have to be sold or written off.

On the other hand, in-memory computing is now

completely mainstream and standardized on all the

main public cloud platforms. Public clouds have

turned a terabyte of memory into a commodity and

the major cloud providers offer a similar range of

compute instances optimized for in-memory

computing, going from a few GB to several terabytes

all available on a “pay-as-you-use” basis. Such

memory sizes as those presented in Table 1 are

readily available on public clouds nowadays.

This is true for conventional hardware

configurations as well, but using the Cloud for in-

memory applications is especially attractive from a

budget standpoint considering the fairly high

purchasing price of the specialized hardware needed

for this usage.

Price has become standardized, and there is no

premium on large memory servers like there used to

be. Basically, a TB of memory is now a commodity

that can be purchased for around $7 per hour from any

major public cloud provider as shown in Table 2.

Please note that these prices were snapshotted at a

given time, for example sake only, since prices on

public clouds evolve continuously.

Table 2: High-memory instances from major public Clouds.

GCP Azure AWS

128

n1-highmem-16

9.1$ /TB/h

E16 v3

8.5$ /TB/h

r5.4xlarge

7.8$ /TB/h

512

n1-highmem-64

9.11$ /TB/h

E64 v3

9.3$ /TB/h

r4.16xlarge

8.7$ /TB/h

n1-ultramem-40

6.5$ /TB/h

M64s

7$ /TB/h

x1.16xlarge

7$ /TB/h

n1-ultramem-160

6.8$ /TB/h

M128ms

7$ /TB/h

x1e.32xlarge

7$ /TB/h

One dilemma when starting an in-memory

computing project is how to choose the right server

for your project, and there is a temptation to over-

provision, especially if you anticipate growth. With

the cloud, you use exactly what you need now. If the

business grows, you can switch to a larger resource

almost seamlessly - as long as the software is

designed to cope.

We have shown that it is possible to load data

from the Cloud storage and launch ActivePivot

instances very quickly to answer to a business query

that, in previous architectures, would have to wait for

the next nightly batch. However, this design assumes

that the business applications producing the data

consumed by ActivePivot have actually pushed their

data in real-time to the Cloud storage. In the next

section we will discuss the CloudDBAppliance

project, in which we aim to build a platform that will

be able to contain both the operational database and

the analytical one, both in-memory, allowing for the

shortest delays between a change in the operational

data and its availability for analytical queries.

3.2 CloudDBAppliance: Operational

Database and Analytics, All in One

The CloudDBAppliance project is funded by

European Union’s Horizon 2020 research and

innovation programme. It aims at producing a Cloud

The End of the Nightly Batch: How In-memory Computing and the Cloud Are Transforming Business Processes

657

Database Appliance for providing a Database as a

Service able to match the predictable performance,

robustness and trustworthiness of on-premise

architectures. This project will deliver a cloud

database appliance featuring both the next-generation

hardware for in-memory computing and the

necessary software for processing high update

workloads on an operational database, performing

fast analytics and applying data mining / machine

learning techniques on a data stream or on a data lake,

the robustness being protected by redundancy and

failover mechanisms.

We have tested the ActivePivot analytical

database on the hardware built during this ongoing

project. The platform we tested is a Bull Sequana

S800 with 8 processors Intel(R) Xeon(R) Platinum

8158 CPU @ 3.00GHz, (which represents 96 cores),

each constituting a NUMA node with 512 GB of

RAM (4 TB in total). For our experiment, we have

used the well-known TPC-H benchmark’s dbgen tool

(TPC, 2019) to generate data at two different scales:

we used a factor of 100, then 500, to generate

respectively 107 GB then 542 GB of data. Those data

quantities are roughly representative of the two

smaller use case sizes cited in Table 1, for which the

platform would have enough memory to co-host the

operational database and the analytical database. The

data (as generated in CSV format) was stored on SSD

disk on the machine. We evaluated the total startup

time, from launching the command line that starts the

analytical database until the analytical database is

able to answer queries on the full dataset. This

includes the file reading, parsing to transform the

CSV into the actual data types, adding the data to the

datastore, and publishing to the analytical cube.

On the 107 GB dataload, the total startup time was

6 minutes and 31s, which represents an average

throughput of 2,209,997 records published per second

on that initial load. On the factor 542 GB dataload,

the total startup time was 29 minutes and 9 seconds,

with an average throughput of 2,006,060 records

published per second. The total startup time might

seem a bit long considering everything is local to the

machine with no need to download the data through

network. However, the loading performance is

hindered by the TPC-H setting in which all data

resides in a single CSV file: even if the parsing and

publishing of records can happen in parallel, the

actual file reading still has to be done sequentially.

We are currently implementing a connector

between the LeanXcale database, the operational

database that was selected for the CloudDBAppliance

project (CloudDBAppliance, 2018), and the

ActivePivot analytical database. We expect

throughputs to be much higher, since the data will be

pushed directly from the in-memory database, so:

 The data will be read from RAM, not SSD disk;

 the data will already be in a binary format, no need

for parsing the CSV into actual data types;

 the data will already be broken into individual

records, removing the constraint of having to read

one single CSV file sequentially.

We can envision several scenarii for the best usage of

the platform’s capacities. In one scenario, the

operational database is always on, but the rest of the

machine resources are shared between different kinds

of applications: the ActivePivot analytical database

can be started on-demand to compute complex

analytical queries, and be shut down after usage to

leave resources to other applications such as machine

learning Spark jobs performed on the datalake. In that

scenario, the main difference from using a

datawarehouse built from nightly batches is that the

data will be fresher, since the application can be

loaded on-demand from the latest version available in

the operational database. In another scenario, the

ActivePivot is always on, receiving data updates

continuously from the operational database. This way

analytical queries can be performed at any time

without any loading phase and reflect real-time

changes in the operational data. In both scenarii, the

whole machine is always up because the operational

database has to be always available. The main

advantage of being in the Cloud rather than using an

on-premise machine resides in the ability to easily

switch from one configuration to another when the

needs evolve, instead of having to buy a new server.

The LeanXcale operational database indeed comes

with data migration capacities that allow to switch the

hosting machine without interruption of service, and

restarting an ActivePivot on the new machine has

been shown to be a less than half an hour affair.

4 CONCLUSION

While it’s not feasible to try out every use case, we

believe we demonstrated through our tests that one of

the most demanding business cases can be addressed

fully without the need for a recurring nightly batch. If

financial risk analytics can be performed without

scheduled batches through a combination of cloud

infrastructure and in-memory computing, we are

convinced that there aren’t many real-world business

scenarios that cannot be addressed in the same way.

Furthermore, while it serves its purpose for

decades, nightly batch processing now appears not

ADITCA 2019 - Special Session on Appliances for Data-Intensive and Time Critical Applications

658

only a second-rate option at best, but simply wasteful

compared to the alternative. It is wasteful in time, in

capital and in power. Fortunately, the transition to a

better model is now easier than ever for organizations.

We are currently participating in a research

project that aims at building a cloud platform on

which an operational database is integrated with

analytical capabilities, allowing for real-time data

processing without hassle.

ACKNOWLEDGEMENTS

The CloudDBAppliance

project has received funding

from the European Union’s

Horizon 2020 research and

innovation programme under

grant agreement No. 732051.

REFERENCES

ActiveViam, 2019. ActivePivot product page.

https://activeviam.com/en/products/activepivot-in-

memory-analytical-database.

The CloudBDAppliance Consortium, 2018. Deliverable

D2.3: Final version of the In-Memory Many-Core

Operational Database.

Gustafson, J., 1988. Reevaluating Amdahl’s Law. In

Communications of the ACM. Volume 31 Issue 5.

TPC, 2019. TPC-H Homepage. http://www.tpc.org/tpch/.

The End of the Nightly Batch: How In-memory Computing and the Cloud Are Transforming Business Processes

659
