A Comparative Study of Misapplied Crypto in Android and iOS

Applications

Johannes Feichtner

1,2

Institute of Applied Information Processing and Communications (IAIK), Graz University of Technology, Austria

Secure Information Technology Center – Austria (A-SIT), Austria

Keywords:

Static Analysis, Slicing, Android, iOS, Cryptography, Application Security.

Abstract:

Many applications for Android and iOS process sensitive data and, therefore, rely on cryptographic APIs

natively provided by the operating system. For this to be effective, essential rules need to be obeyed, as

otherwise the attainable level of security would be weakened or entirely defeated. In this paper, we inspect the

differences between Android and iOS concerning the proper usage of platform-speciﬁc APIs for cryptography.

For both platforms, we present concrete strategies to detect critical mistakes and introduce a new framework for

Android that excels in pinpointing the origin of problematic security attributes. Applied on real-world apps

with cryptography, we ﬁnd that out of 775 investigated apps that vendors distribute for both Android and iOS,

604 apps for iOS (78%) and 538 apps for Android (69%) suffer from at least one security misconception.

1 INTRODUCTION

In recent years, Android and iOS have emerged as the

two leading operating systems in the smartphone in-

dustry. Many applications for these platforms perform

security-critical tasks and require that sensitive data is

processed reliably. Sadly, there is little information on

how responsibly apps treat personal information, such

as passwords and encryption keys. A wrong applica-

tion of cryptography or security-critical functionality,

however, may expose secrets to unrelated parties and,

thereby, undermine the intended security level.

The research of security aspects on mobile plat-

forms has received a lot of attention. A majority of

publications in this ﬁeld focus on the Android ecosys-

tem where the openness of the platform promotes pro-

gram inspection. This process of reverse engineering

is predominantly driven by the motivation to check

the existence and correct implementation of security

mechanisms. Manually verifying how critical func-

tionality has been realized can be challenging due to

the rising complexity and size of today’s programs.

Automated solutions, on the other side, are often tai-

lored to the inspection of particular parameters but

fail to perform a conclusive identiﬁcation and analysis

of relevant program parts. This issue is aggravated

by the heterogeneity of Android and iOS, which does

not only cause distinct attack vectors but also prevents

inspection tools from being re-used for both platforms.

A common method to protect sensitive information

in Android and iOS apps is the use of system-provided

APIs that expose cryptographic functionality. While

these high-level interfaces reduce the burden of the

developer to understand how cryptographic primitives

work internally, it is still vital to use APIs with pa-

rameters that do not give a false sense of security.

Therefore, several platform-independent rules have to

be observed. Among them are for example, (1) the

need to prevent the electronic code book (ECB) mode

for block ciphers,(2) the need to avoid constant keys or

credentials that are in the worst-case hard-coded into

the app, or (3) the need to derive initialization vectors

(IV) from a pseudo-random number generator.

While analyzing thousands of Android apps in

2013, researchers have deﬁned six common types

of mistakes in using cryptographic APIs and con-

ﬁrmed that issues were present in 88% of all inspected

apps (Egele et al., 2013). Since then, approaches have

been elaborated to better detect (Shao et al., 2014;

Muslukhov et al., 2018) and mitigate (Ma et al., 2016)

crypto API misuse in Android. Similar efforts have

also been made regarding iOS apps (Feichtner et al.,

2018; Li et al., 2014) where security problems have

been uncovered in 82% of apps checked. As related

work underlines that correct usage of system-provided

APIs for crypto purposes is rather the exception than

the norm, it stresses the need for further research that

discloses reasons for the high frequency of misuse.

Feichtner, J.

A Comparative Study of Misapplied Crypto in Android and iOS Applications.

DOI: 10.5220/0007915300960108

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 96-108

ISBN: 978-989-758-378-0

Problem.

It is still unclear whether apps that are

available for both Android and iOS suffer from similar

implementation weaknesses. Available research of

misapplied crypto in mobile apps usually does not

cross the line between platforms. Thus, it is hard to

argue whether API misuse is the result of a developer’s

lack of knowledge or ignorance, or more likely due to

problematic design decisions in the system-provided

API and its too complex documentation.

Moreover, most related work for Android focuses

on highlighting the widespread of misapplied crypto

rather than pinpointing the exact origin of problematic

statements in code. While there is undoubtedly a need

for tools to warn about these kinds of problems, so far

they are unable to give clear advice to developers and

analysts about the origin of rule-violating code.

The ability to directly compare execution traces of

API invocations is important, since it is crucial to see

why methods are invoked with cryptographically weak

values. In addition, also with regards to the platform,

execution traces can provide valuable insight into why

some rules are signiﬁcantly more violated than others.

Approach.

To assess and compare the occurrence of

misapplied crypto in Android and iOS apps, we pursue

a three-stage process:

Streamline application analysis for both platforms

by establishing a workﬂow and output format that

ensures inspection results on Android and iOS are

comparable. To achieve that, we designed and im-

plemented a framework that bridges the previously

deﬁned gap in analyzing Android apps.

Based on a general set of crypto API rules not to

violate, we identify detection strategies that hold

on both platforms. Due to the different design

of Android and iOS, individual constraints apply

regarding parameters crypto API methods can take.

Using analysis frameworks that incorporate the

predeﬁned rules, we conduct an automated study

of misapplied crypto on a manually compiled set

of apps that include cryptography and that are ofﬁ-

cially distributed for both Android and iOS.

Results.

We manually collected a set of 775 mobile

apps that apparently originate from the same vendor

and are distributed in the ofﬁcial stores of Android

and iOS. All of them had at least 1,000 installations or

ratings on each platform, and their use of cryptography

seemed obvious, i.e., password managers or secure

messengers. We found that 78% or 604 apps for iOS

and 69% or 538 apps for Android violated at least one

basic security rule. The analysis also showed strong

indications that the prevalence of some issues is almost

solely based on design decisions of the API.

Contribution. Our contributions are as follows:

We introduce a new framework to automatically

dissect Android apps, identify common misuse

of crypto APIs and exactly pinpoint the origin of

wrongly chosen security-relevant attributes

. As

security rules might change over time or by APIs

being updated, we propose a modular design that

allows for easy adaptability to future needs. The

analysis output shows a precise data ﬂow of param-

eters that are used in calls to crypto APIs. Apart

from analysts, the resulting report in XML format

can also easily be understood by developers, who

can use it to ﬁx found issues quickly.

We derive concrete detection strategies for general

security rules and assess how they can be violated

on each platform. Used in combination with anal-

ysis frameworks for Android and iOS, problems

can reliably be identiﬁed based on given data ﬂows

and, referring to the objective of this paper, the

results on both platforms are comparable.

We present the ﬁrst comparative evaluation of mis-

applied crypto in Android and iOS apps. Applied

on a carefully compiled set of 775 apps for iOS

and their counterparts for Android, we assess the

spread of common mistakes in apps for both plat-

forms. We ask if developers know how to use the

system-provided APIs correctly and check if apps

that are considered to be secure on one platform,

typically fulﬁll the same expectations on the other.

Outline.

The remainder of this paper is organized

as follows. In Section 2, we discuss related work. In

Section 3, we explain the structure of Android and

iOS apps, cryptography APIs, and the principle of

Program Slicing. In Section 4, we present our modular

solution for Android to automatically identify security-

relevant attributes in apps by means of static slicing.

Section 5 shows precise detection strategies that have

been modeled as ruleset within our framework. In

combination with an existing framework for analyzing

iOS apps, in Section 6, we study violations of security

rules in real-world apps. Section 7 concludes our work.

2 RELATED WORK

The analysis of cryptography-related problems on

mobile platforms has attracted a lot of attention in the

past years. In this section, we discuss several related

research that is closely related to our work.

The source code of the framework is available at

https://github.com/IAIK/CryptoSlice

A Comparative Study of Misapplied Crypto in Android and iOS Applications

Misapplied Crypto APIs.

Evaluation of reports in

Common Vulnerabilities and Exposures (CVE) re-

vealed that 83% of all ﬁndings related to cryptography

in mobile applications were due to the wrong usage of

crypto APIs (Lazar et al., 2014). Focusing on the us-

ability of different crypto libraries, other studies (Acar

et al., 2017; Nadi et al., 2016) conclude that, aside

from too complex interfaces and insecure defaults, typ-

ical reasons for misuse are often to be found in poor

documentation, missing code samples, and further fea-

tures required by the library to work securely.

Although reducing the decision-space for the

choice of insecure parameters and a simpliﬁcation of

APIs helps in preventing mistakes, a variety of po-

tential weaknesses remain (Chatzikonstantinou et al.,

2015). However, keeping security rules that match

these issues up-to-date can be challenging as APIs

evolve over time. A recent work, thus, concentrated

on automatically aligning security rules to changes in

API design (Paletov et al., 2018).

Detecting API Misuse.

Among the ﬁrst tools to

automatically check Android applications for misap-

plied crypto APIs was CryptoLint (Egele et al., 2013).

Based upon the reverse-engineering framework Andro-

guard, it dervies a control-ﬂow graph over all functions.

Subsequently, static program slicing is employed to

inspect the parameters passed to cryptographic opera-

tions. Tested with almost 11,000 Android applications,

the authors found that 88% of them commit at least

one security mistake. As the reasoning of their rules

is valid for both Android and iOS, we re-implement

them using our own detection strategies. Inspired by

CryptoLint, the CMA analyzer pursued a similar ob-

jective (Shao et al., 2014). Besides rules for crypto

APIs, the authors also proposed to consider further

security-relevant rules. Newer case studies of crypto

API misuse on Android conﬁrm that even more than

5 years after the ﬁrst study, the general issue is still

widespread (Muslukhov et al., 2018; Ma et al., 2016).

In comparison with Android, only few related con-

tributions target the iOS platform. Supported by the

fact that Dalvik bytecode in Android applications can

be decompiled to Java code, existing tools for static

analysis are easily applicable. On iOS, solutions for

binary analysis have to be aligned to the speciﬁcs of

Objective-C and Swift, such as control-ﬂow decisions

at runtime and computing points-to sets. In a recent

study, the impact of crypto misuse was assessed for a

set of iOS apps (Feichtner et al., 2018). The authors

tested 417 apps and found that 82% of them violated at

least one security rule. Other works for iOS concern-

ing APIs survey the usage of private APIs or pursue a

source-to-sink analysis using static and dynamic meth-

ods (Deng et al., 2015; Li et al., 2014).

Static and Dynamic App Analysis.

Publications

concerning mobile app analysis usually involve ei-

ther dynamic or static analysis. Dynamic approaches

work by monitoring the live execution of an app. On

Android, tools like TaintDroid or TaintART can ana-

lyze and detect privacy leakage in the current execution

path (Enck et al., 2010; Sun et al., 2016). Nevertheless,

they inherently miss code paths that are not visited at

runtime. With the need to manually run each app, a dy-

namic approach is less suited for the objective of this

work and will, thus, not be considered more in-depth.

Methods for static analysis, as an alternative, typi-

cally apply taint tracking on a reverse-engineered rep-

resentation of Dalvik bytecode (Android) or ARMv8

64-bit code (iOS). On Android, with a source-like

representation, the main challenge is to follow all exe-

cution paths as sound and precisely as possible. Fully-

ﬂedged frameworks, such as FlowDroid (Arzt et al.,

2014) and IccTA (Li et al., 2015) tackle this challenge.

Unfortunately, their general design prevents them from

being speciﬁcally applied using security rules. Self-

contained implementations and speciﬁc output formats

make them challenging to extend and, regarding our

purpose, do not contribute to making analysis results

between Android and iOS comparable.

3 BACKGROUND

In this section, we highlight substantial differences

of applications for Android and iOS with regards to

reverse-engeering. Followed by that, we present the

idea of program slicing and ﬁnally focus on the use of

system-provided crypto APIs on both platforms.

3.1 Reverse-engineering Apps

The heterogeneity of Android and iOS also extends

to the ﬁle formats used for apps of the corresponding

platform. In the following, we point out individual

characteristics and describe how apps have to be trans-

formed to be able to perform program inspection.

3.1.1 Android

Android apps are mostly developed in Java or Kotlin.

During compilation, stack-based JVM bytecode is

translated to register-based Dalvik bytecode that is

later interpreted by the Dalvik Virtual Machine (DVM).

By reusing and eliminating repetitive function signa-

tures, code blocks, and string values, the Dalvik com-

piler manages to effectively reduce the uncompressed

bytecode size. As a result, all parts are merged into a

single executable ﬁle named classes.dex.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

A classes.dex executable consists of multiple sec-

tions. Starting with a header, specifying the ﬁle type

using a magic number, and the format version number,

the subsequent sections reference all strings, type iden-

tiﬁers, class and method signatures, ﬁelds, and method

identiﬁers using unique IDs. The actual program code

is stored in a separate data section.

The process of reverse-engineering Android apps

usually consists in converting the Dalvik ﬁle to Java’s

.class format. Using predeﬁned rules and constraint

solving mechanisms, tools, such as dex2jar

or enjar-

ify

, translate register-based Dalvik bytecode to stack-

based JVM code. As this process is non-deterministic,

it often leads to spurious or wrong code translations.

Alternatively, instead of decompiling Dalvik byte-

code to Java, it can be represented as Smali code.

Smali is a mnemonic language to represent Dalvik

bytecode in a parseable format. As it keeps the se-

mantics of code very close to the original, it is often a

preferable choice over more intricate decompilation.

3.1.2 iOS

iOS executables are packaged in the Mach-O ﬁle for-

mat and enclose at least one 64-bit executable for

an ARMv8 CPU. The ﬁle is split into three sections:

Header, Load Commands, and Data. The ﬁrst part

identiﬁes the ﬁle as Mach-O ﬁle and includes informa-

tion about the target CPU architecture. Next, the ﬁle

layout and designated memory location of segments

are deﬁned. The third section ﬁnally consists of dif-

ferent regions with program code and sections that are

loaded into memory during runtime.

In contrast to Android where apps are provided in a

reversible bytecode format, iOS applications are com-

piled to machine code that is tailored to a particular

CPU architecture. Manually inspecting the disassem-

bled code of an iOS binary can be challenging due to

the complexity and size of today’s apps. Automated

solutions, as an alternative, have to be aligned to the

characteristics of ARMv8 code for iOS. As apps for

iOS are developed in runtime-oriented languages, such

as Objective-C and Swift, most control-ﬂow decisions

are made during runtime. Instead of calling methods

directly or through virtual method tables, it uses a

dynamic dispatch function in the runtime library.

Recent research (Feichtner et al., 2018) proposed

the following workﬂow to reverse-engineer iOS apps:

Decompile the ARMv8 disassembly of an app into

LLVM IR code

and then compute points-to sets for

all pointers using a context-insensitive approach.

https://github.com/pxb1988/dex2jar

https://github.com/Storyyeller/enjarify

https://llvm.org/docs/LangRef.html

3.2 Program Slicing

Static slicing can be used to determine all code state-

ments of a program that may affect a value at a speci-

ﬁed point of execution (slicing criterion). The result-

ing program slices cover all possible execution paths

and allow conclusions to be drawn about the function-

ality of the program. In our Android framework, we

adopt the algorithm of (Weiser, 1981) to create slices

of Smali code and to ﬁnd paths from the origin of a

parameter to its use, e.g., in cryptographic functions.

Weiser presented a method that models the data

ﬂow within a function using equations. Relevant vari-

ables and statements are determined iteratively. The

algorithm consists of two steps (Tip, 1995):

Follow Data Dependencies: This step is executed

iteratively, if control dependencies are found.

Follow Control Dependencies: Includes relevant

variables of control ﬂow statements. The ﬁrst step

is repeated for affected variables.

3.3 Cryptography APIs

Mobile apps rely on cryptography to protect sensitive

data. In the following, key aspects of the cryptographic

APIs included in Android and iOS are highlighted.

3.3.1 Android

By including the Java Cryptographic Architecture

(JCA), Android supports a well-established set of se-

curity APIs. The JCA is provider-based which means

that the interfaces may be implemented by multiple

cryptographic engines in the background. The actual

providers and available algorithms vary based on the

used version of Android.

Symmetric and asymmetric encryption schemes

are made available to developers through the

Cipher

class

. To use a speciﬁc scheme, developers pro-

vide a transformation string as an argument to the

Cipher.getInstance()

method. The parameter en-

closes the algorithm name, cipher mode, and padding

scheme to use within the returned Cipher object.

3.3.2 iOS

On iOS, the platform libraries CommonCrypto and

Security expose APIs to perform security-related op-

erations. The ﬁrst library provides symmetric ci-

phers, hash functions, and a key derivation function

https://developer.android.com/reference/javax/crypto/

Cipher

A Comparative Study of Misapplied Crypto in Android and iOS Applications

(PBKDF2). The second library features functional-

ity for asymmetric ciphers, certiﬁcate handling, and

keychain access.

4 PINPOINTING API MISUSE IN

ANDROID APPS

Designed for the inspection of single aspects in An-

droid apps, our framework features static analysis

on deﬁnable slicing patterns in order to identify and

highlight the improper usage of security-relevant func-

tionality. The modular architecture of the Java-based

framework offers the ability to automatically extract,

disassemble and investigate programs. By applying

static backtracking techniques, the control and data

ﬂow of relevant code segments is opened up and serves

as input for further evaluation. For this purpose, our

framework incorporates rules (see Section 5) to make

reliable assumptions about the degree of security, com-

mon cryptography-related constructions are able to

provide. Besides analyzing these constructions, it is

determined whether they deviate from being employed

correctly. The framework also supports the manual

analysis of apps by delivering well-arranged graphs,

representing the static slice of user-deﬁnable patterns.

In comparison with similar solutions, such as

CMA (Shao et al., 2014) or CryptoLint (Egele et al.,

2013), we can give clear advice about the origin of

rule-violating code, rather than being only able to con-

ﬁrm its existence. In experiments, we also noticed that

related work tend to ﬂag all apps that violate any rules

as insecure. While this is true in the strict sense, it

disregards the practical impact of rule violations: apps

might use crypto APIs also for other purposes than

encryption. Without looking at the actual execution

paths, it might go unnoticed if encryption is only em-

ployed for obfuscation. A similar case occurs if, e.g.,

libraries used in apps initialize variables holding en-

cryption keys, salt values, or IVs with insecure default

values but overwrite them before actual usage. As a

consequence, our framework does not draw a binary

conclusion on the (in)security of apps but provides

reports with potentially problematic execution paths,

as identiﬁed by the conditions in our security rules.

The overall workﬂow of our framework, as illus-

trated in Figure 1, can be summarized as follows:

1. Preprocessing:

We translate the Dalvik bytecode

from an Android app archive in .apk format to

Smali code and parse it to an object representation.

2. Static Slicing:

Based on the given security rules

deﬁning abstract slicing patterns, we derive con-

crete slicing criteria. We perform static backtrack-

Preprocessing

App Object

Static Slicing

paths.xml

.apk Input

graph.xml

Slice tree

report.xml

Security Rules

Analysis Task

Figure 1: Analysis workﬂow.

ing, follow all possible execution paths, and orga-

nize these data ﬂows in a graph representation.

3. Security Rule Evaluation:

Using a breadth-ﬁrst

search, we browse individual execution paths and

check whether they comply with our security rules.

In the following, we provide a more detailed in-

sight and explain the individual analysis steps.

4.1 Preprocessing

Although Android code is usually based on Java or

Kotlin code, we do not try to decompile Dalvik byte-

code back to Java. As pointed out by the creators of the

Dare decompiler (Octeau et al., 2012), decompilation

is only likely to succeed for 95% of the app classes. In-

stead, we disassemble Dalvik bytecode to Smali code,

a register-based intermediate language. Therefore, the

ﬁle classes.dex contained in each Android app archive

is processed using the tool baksmali

. As a result, we

obtain a list of ﬁles with code similar to Java, which

we parse into an object representation that resembles

all essential attributes and basic blocks.

4.2 Static Slicing

The ability to trace information in backward direc-

tion is a core component of our framework in order to

isolate those parts of an app that are relevant regard-

ing a speciﬁc slicing criterion. In the following, we

present the implemented techniques for static slicing

and highlight practical challenges.

4.2.1 Slicing Patterns

Slicing naturally depends on a slicing criterion ref-

erencing a speciﬁc line of program code. Consider-

ing our objective to track arbitrary data ﬂows, a more

generic representation is needed. Therefore, we pro-

pose so-called slicing patterns that conceptually de-

scribe an object to track in XML format.

https://github.com/JesusFreke/smali

SECRYPT 2019 - 16th International Conference on Security and Cryptography

100

Patterns include no references to particular pro-

gram lines but comprise all necessary info to dynam-

ically build slicing criteria. Using slicing patterns in

our security rules, they become applicable for a large

set of targets and lead to a multitude of slicing criteria.

In the default behavior, slicing criteria are deter-

mined by searching for all

invoke

statements match-

ing the given pattern. Therefore, all code lines of

an application are scanned, looking for the provided

method signature. For each match, the appendant pro-

gram statement is considered as a starting point for

slicing. Subsequently, the name of the register to track

is located by associating the index of each occurring

As a result, a set of suitable slicing criteria is delivered.

4.2.2 Backtracking

Backward slicing traverses all preceding code state-

ments that have inﬂuenced a speciﬁc register at the

initial slicing criterion. Starting at a particular state-

ment, we follow all usages of a register back to the

point where it is deﬁned. This approach is commonly

referred to as Use-Deﬁnition (or short use-def). The

resulting slice models the data ﬂows of all variables

that affect the starting point.

For each criterion, ﬁrst the register is identi-

ﬁed which matches the deﬁned parameter of interest.

While backtracking the register, all involved program

statements are recorded as slice nodes and added to a

slice tree. Tracking ends when constants are assigned

to the currently tracked register and slicing is no longer

feasible. Likewise, the slicing process terminates when

the tracked register is overwritten or track is lost, e.g.,

when referenced methods cannot be resolved.

Technically, our implementation works using a

FIFO queue. The to-do list collects all registers, ﬁelds,

return values, and arrays that are subject to tracking.

Moreover, it holds a reference to all objects that have

already been followed and excludes them from being

re-processed. When requested by the slicer, the queue

returns the next object to track, which includes the

The implemented slicing algorithm is not contin-

gent on previously generated program dependency

graphs and, hence, supports fast and computationally

inexpensive program analysis. Nevertheless, to lever-

age the potential of today’s multi-core processors, the

framework supports the analysis of multiple Android

apps in parallel. Thereby, it is possible to inspect large

amounts of apps in minimal time.

4.2.3 Slice Trees and Constants

The slicing process dynamically builds a tree with all

encountered slice nodes for a speciﬁc slicing criterion.

The top node is always the criterion, deduced from

the pattern since it represents the root of all possible

execution paths that can be modeled. Subjacent nodes

stand for all code lines which are contained in the

slice. In case there are multiple execution paths (e.g.

if-else statement), a slice node might have links from

multiple predecessor nodes. When code statements are

iterated multiple times (e.g. for or while loop) cycles

are induced between vertices. Each (intermediate)

node involves a list of all predecessor nodes, including

the originating register name and the register name,

related to the current program statement.

A slice tree can comprise one or multiple leaf nodes

whereas each describes either a constant or indicates

an abruptly ended slicing process. Assuming that a

constant value, such as an integer, an array, or a string,

is copied into the tracked register, slicing may stop

since the register value is redeﬁned. For backward

slicing this signiﬁes that the tracking process has led

to one or more values that affect the slicing criterion.

Leaf nodes are also inserted in case slicing loses track.

This happens, for instance, when registers are set as

parameters in calls to unresolvable methods.

Since all disclosed path endpoints are invariant,

we regard them as constants. Aside from containing

information about values that are assigned to regis-

ters, constants also explain why paths end at certain

points. This is achieved by retaining metadata from

slicing. For example, each constant is assigned a cate-

gory which clearly deﬁnes the type of the underlying

value. Similarly, in case tracking stops abruptly, con-

stants are put in place to describe the cause.

4.3 Security Rule Evaluation

Each of the implemented security rules ﬁrst tries to

ﬁnd predeﬁned method signatures and then, based on

the found matches, veriﬁes whether they correspond

to the predeﬁned security model. In case a rule is vio-

lated, an alert is issued, accompanied by details about

the problematic statement. Thereby, the framework

manages to evaluate the exact location of rule-violating

code lines and writes information about the involved

class, method and code to the console as well as to

an XML report. As a consequence, the result is easily

readable and can, moreover, be interpreted automati-

cally by parsing the XML report. Evidently, to also

consider the context in which security-related ﬁndings

appear and to prevent false positives, studying linked

execution paths can provide valuable insights.

A Comparative Study of Misapplied Crypto in Android and iOS Applications

101

The security rules are executed in consecutive order

and independent from each other. The only shared

feature is a reporting system, used to summarize the

output of all evaluated checks. Each rule incorporates

the entire workﬂow described in the previous sections.

Due to the extensible approach, adding further security

rules is supported by requiring only little effort.

5 CRYPTOGRAPHIC API MISUSE

In this section, we present detection strategies for a

set of security rules we use to detect common security-

critical implementation ﬂaws in Android and iOS apps.

Similar to related research (Muslukhov et al., 2018;

Feichtner et al., 2018), we investigate whether apps

that use system-provided crypto APIs achieve a crypto-

graphic notion of IND-CPA security. Indistinguishabil-

ity under a chosen plaintext attack or IND-CPA states

that attackers are unable to extract even a single bit of

plaintext from a ciphertext within a certain amount of

time. Encryption can be considered secure if it is IND-

CPA secure (Egele et al., 2013). In practice, however,

faulty implementations or wrongly-chosen parameters,

e.g., a constant or hard-coded encryption key, thwart

IND-CPA security. Therefore, six general rules were

proposed to keep encryption secure. In the following,

for each we derive concrete detection strategies that

can immediately be applied for Android and iOS apps.

Rule 1: Do Not Use ECB Mode for Encryption.

In ECB mode, data blocks are enciphered indepen-

dently from each other and cause identical message

blocks to be transformed into identical ciphertext

blocks. Consequently, data patterns are not hidden

and conﬁdentiality may be compromised.

On Android, developers can request an instance of

a particular cipher by passing a suitable transformation

value as a parameter to

Cipher->getInstance()

Typically, this value is composed of the algorithm, an

operation mode, and the padding scheme to use. E.g.,

to request an instance providing AES in ECB mode

with PKCS#5 padding, “AES/ECB/PKCS5Padding”

has to be speciﬁed. While it is indispensable to de-

clare an algorithm, explicitly setting mode and padding

may be omitted. In that case, the underlying provider

will implicitly assume ECB mode. Besides AES, this

affects all symmetric block ciphers.

Determine all invocations of the method

Cipher->getInstance()

and for each occur-

rence, backtrack the ﬁrst parameter, register

holding the transformation value.

Find all possible execution paths, where the end-

point resembles a transformation or speciﬁes a

symmetric block cipher, such as AES or DES.

For each selected path, verify whether it in-

cludes parts of a transformation value, e.g.

/OFB/NoPadding. If found, complete the algo-

rithm name in the path endpoint with the deter-

mined mode and padding descriptor.

Raise an alert if the transformation value either

explicitly declares ECB mode, or speciﬁes only

the algorithm name.

On iOS, by default CBC is preferred over ECB mode.

ECB mode is only used when the developer explicitly

speciﬁes to use this mode of operation.

For each invocation of

CCCryptorCreate()

CCCrypt()

CCCryptorCreateWithMode()

, or

backtrack the third parameter,

options

, specify-

ing whether to use ECB or CBC mode.

Raise an alert if the any of the possible execution

paths ends with a constant value of 2 which would

indicate ECB mode (kCCOptionECBMode).

Rule 2: No Non-random IVs for CBC Encryption.

Constant or predictable initialization vectors (IVs) lead

to a deterministic and stateless encryption scheme,

susceptible to chosen-plaintext attacks. If CBC mode

is selected for encryption, developers should provide a

non-random IV. If no IV is given at all, the cipher uses

an all-zeros IV, which is at least as bad as a constant.

By analyzing byte arrays set as IVs, we learn if IVs

are composed of static values or deduced from con-

stants, e.g. strings. IVs can also be predictable when

weak pseudo-random number generators (PRNG) are

employed. Besides probing for speciﬁc indicators, we

are naturally unable to make assumptions about the

predictability of values. Similarly, non-static IVs can-

not implicitly be assumed unpredictable.

On Android, to specify an IV for encryption, typi-

cally an

AlgorithmParameterSpec

is passed as argu-

ment to

Cipher->init()

. If it encapsulates an object

of the type

IvParameterSpec

, an IV is manually de-

ﬁned rather than being generated randomly.

For all invocations of

Cipher->init()

with an

AlgorithmParameterSpec

object as 2nd argu-

ment, backtrack the value of this parameter.

Using the found list of constants, verify whether

an object of the type

IvParameterSpec

is created

by calling its constructor. Abort, if none is found.

From each available slicing path, extract the sub-

path that begins at the

argument, passed to the

constructor of the IvParameterSpec object.

Raise an alert if the

parameter is derived from

a statically deﬁned byte array, a string (e.g. using

SECRYPT 2019 - 16th International Conference on Security and Cryptography

102

String->getBytes())

, or by calling the insecure

Random API.

On iOS, we assert that an IV is evidently generated

using a cryptographically secure PRNG.

For each invocation of

CCCryptorCreate()

CCCrypto()

, or

CCCryptorCreateWithMode()

we backtrack the 6th parameter, specifying the IV.

Alert if a possible execution path does not call

CCRandomGenerateBytes()

in CommonCrypto

or SecRandomCopyBytes in the Security library.

Rule 3: Do Not Use Constant Encryption Keys.

Keeping encryption keys secret is a vital requirement

to prevent unrelated parties from accessing conﬁden-

tial data. Statically deﬁned keys clearly violate this

basic rule and render encryption useless.

On Android,

SecretKeySpec

can be used to spec-

ify a key. If derived from a constant, it must not be

used for symmetric encryption. However, with public-

key crypto, the encryption key is not a secret and can

also be wrapped as a

SecretKeySpec

object. Thus,

we distinguish between keys for symmetric and asym-

metric encryption and also check the 2nd parameter of

SecretKeySpec

, which speciﬁes the algorithm to use.

For all invocations of

SecretKeySpec->init()

backtrack the ﬁrst parameter, holding the key.

Verify for all contained constants if the

key

param-

eter is derived from a statically deﬁned byte array,

or a string (e.g. using String->getBytes()).

If at least one possible key has been found, also

backtrack the 2nd parameter of the corresponding

SecretKeySpec object and extract all data ﬂows.

For each execution path, verify whether one of

the following asymmetric encryption schemes is

speciﬁed: DHIES, ECIES, ElGamal, RSA. If the

algorithm is not a known public-key algorithm, we

conclude that the statically deﬁned key is used for

symmetric encryption and raise an alert.

On iOS, we assure that any byte array speciﬁed as key

does not exclusively consist of constant values.

For each invocation of

CCCryptorCreate()

CCCrypto()

, or

CCCryptorCreateWithMode()

we backtrack the 4th parameter, holding the key.

For any path, we ensure that key elements originate

from a non-constant or hard-coded source.

Rule 4: Do Not Use Constant Salts for PBE.

randomly chosen salt ensures that a password-based

key is unique and slows down brute-force and dictio-

nary attacks. Salts passed to key derivation functions

(KDF), thus, must not exclusively depend on constant

values.

On Android, parameters to use with KDFs can be

declared using the

PBEKeySpec

API. Subsequently, a

SecretKeyFactory

instance transforms the password

to an encryption key by invoking

generateSecret()

Find all invocations of

PBEKeySpec->init()

PBEParameterSpec->init()

and backtrack the

parameter with the salt value.

Raise an alert if any execution path providing

the

salt

parameter, is derived from a stati-

cally deﬁned byte array, a string (e.g. using

String->getBytes())

, or by calling the insecure

Random API.

On iOS,

CCKeyDerivationPBKDF()

must not be pro-

vided with an entirely constant salt value.

For all calls to

CCKeyDerivationPBKDF()

, back-

track the 4th parameter, specifying the

salt

value.

For any execution path, we ensure that byte arrays

with the salt originate from a non-constant origin.

Rule 5: Do Not Use < 1,000 Iterations for PBE.

low iteration count signiﬁcantly reduces the costs and

computational complexity of table-based attacks on

password-derived keys. We, thus, expect apps to use

≥ 1,000 rounds in KDFs, as proposed by RFC 8018

On Android, the iteration count for PBE is declared

using the PBEKeySpec or PBEParameterSpec API.

Find all invocations of

PBEKeySpec->init()

PBEParameterSpec->init()

and backtrack the

parameter with the iteration count value.

Raise an alert if any execution path terminates at a

constant integer whose value less than 1,000.

On iOS, the

rounds

parameter of the method

CCKeyDerivationPBKDF()

speciﬁes the amount of

iterations to use for key derivation.

For all calls to

CCKeyDerivationPBKDF()

, back-

track the 7th parameter with the

iteration

count.

For any execution path, we raise an alert if it does

not end at a constant integer value ≥ 1,000.

Rule 6: Do Not Use Static Seeds for Random-num-

ber Generation.

If a PRNG is seeded with a stat-

ically deﬁned value, it will produce a deterministic

output which is not suited for security-critical applica-

tions.

With Android 4.2 (API level 16), the default PRNG

provider has been changed from Apache Harmony

to the native

AndroidOpenSSL

. Before that, it was

possible to override the internally designated seed with

a custom value which, in case it was constant, caused

the generation of deterministic output values.

https://tools.ietf.org/html/rfc8018#section-4.2

A Comparative Study of Misapplied Crypto in Android and iOS Applications

103

For all invocations of

SecureRandom->init()

backtrack the ﬁrst parameter, holding the byte

array with the seed. Likewise, for all calls to

SecureRandom->setSeed()

compute slices for

the

seed

argument, which may consist of a byte

array or eight bytes stored in a

long

integer value.

For all found execution paths, check if any supplies

the seed parameter with constant input values.

An alert is raised if the parameter is derived from

a statically deﬁned byte array, a string (e.g. using

String->getBytes()), or a 64-bits integer.

On iOS, the platform APIs do not support seeding the

underlying PRNG. This misuse, thus, cannot occur.

6 EVALUATION

In the following study, we present the ﬁrst comparative

evaluation of misapplied crypto APIs in Android and

iOS apps. Related research regarding crypto misuse

never crossed the line between platforms. As it has

already been demonstrated that security-critical imple-

mentation weaknesses are prevalent in both Android

or iOS, we focus our analysis speciﬁcally on apps that

are available for both platforms.

The goal of this evaluation is twofold. First, we

ask if developers know how to use system-provided

APIs correctly and give an impression of how often

security misconceptions occur in popular apps. To

prevent false positives or out-of-context ﬁndings, we

manually study reported execution traces. Second, we

ask how likely it is that apps which vendors distribute

for both platforms, also violate the same security rules.

Therefore, we compare the ﬁndings of mistakes in

apps for Android with those in their iOS counterparts.

6.1 Method and Dataset

For the automated study of Android apps, we employ

our framework, as presented in Section 4. For each

inspected app, it outputs a report in XML format,

lists found rule violations and associated execution

paths. For iOS, we rely on an existing open-source

framework

, which pursues a very similar approach

and emits HTML reports with execution traces for in-

spected security properties. We, however, align the

security rules to the detection strategies presented in

Section 5 to establish for both platforms comparable

conditions to detect crypto API misuse.

https://github.com/IAIK/ios-analysis

Table 1: Dataset of apps for evaluation.

Count [%]

Downloaded from iOS App Store 1,322

Matching Android apps in Google Play 976

iOS: No CommonCrypto calls 172 18%

Android / iOS: With crypto API calls 804 82%

iOS: App not decompilable 21 3%

Android: App archive corrupted 4 0.5%

Android / iOS: Out of memory 4 0.5%

Analyzable apps with crypto API usage 775 96%

6.1.1 Dataset

We manually compiled a set of apps where the use

of cryptography seemed inevitable to provide speciﬁc

functionality. Empirically, we found that this require-

ment affects at least apps for password management,

secure messaging, document encryption, sensitive data

exchange, and secure cloud storage.

While Google Play uniquely identiﬁes apps by

their package name, e.g., com.example, the iOS App

Store features no comparable identiﬁers. We were,

thus, looking for other descriptors suited to match apps

that were provided for both platforms. We found that

for the vast majority of multi-platform offered apps,

the title and/or description text used in the stores are

usually widely consistent over both platforms.

Consequently, we identiﬁed and downloaded 1,322

free apps from the iOS App Store, where we assumed

the use of cryptography. Using the title and description

text of each app, we were searching Google Play for

an Android pendant and were successful for 976 apps.

All of them had at least 1,000 installations or ratings

as indicated by Google Play and the iOS App Store.

With a version for Android and iOS each, in total, we

have acquired 2 × 976 = 1, 952 apps for analysis.

After fetching iOS apps via iTunes, we used

Clutch

on a jail-broken iPhone to decrypt them. By

inspecting their library bindings, it became evident that

only 82% or 804 iOS apps included calls to Common-

Crypto. As the remaining set of 172 apps without calls

to system-offered crypto APIs also provided function-

ality where the use of cryptography seemed reasonable,

security might be missing or provided by third-party

libraries, which our rules are not designed to cover.

6.1.2 False Positives and False Negatives

As the two frameworks do not only warn about the ex-

istence of problematic statements but can also pinpoint

their origin, we leverage the data ﬂow seen in exe-

cution paths to assess the soundness of issues found.

https://github.com/KJCracks/Clutch

SECRYPT 2019 - 16th International Conference on Security and Cryptography

104

By manually validating all obtained analysis reports,

we prevent ﬁndings of false positives and ensure that

all rule violations indeed occur in code that has real

practical impact on the security of apps.

False positives or out-of-context results can occur,

e.g., if encryption is only used for obfuscation and

not for actually enciphering secret messages. Like-

wise, apps might include code where crypto routines

are only initialized with insecure default attributes but

never used. By manually examining the execution

traces before acknowledging a rule violation, we mini-

mize false positives that could have occurred, e.g., if a

backtracked value was a parameter to a function that

had never been invoked.

As our security rules evaluate method signatures

of system-provided APIs, we can be conﬁdent that

these calls are always found, even if apps obfuscate

their program code. On Android and iOS, we, thereby,

effectively avoid false negatives.

6.2 Results

In total, we studied 976 apps where vendors provided

a version for Android and iOS via the ofﬁcial app

stores. As summarized in Table 1, we did not ﬁnd

references to CommonCrypto in 18% or 172 apps

for iOS. Irrespective of whether they actually con-

tain cryptography-related code, we excluded these

apps from further analysis, since we knew a priori

that our security rules would not detect any violations

in them. Interestingly, for all remaining 804 iOS apps

that use the CommonCrypto API, also all correspond-

ing Android pendants included calls to methods in

java.security.*

java.crypto.*

. This strongly

indicates that crypto is actually needed for the correct

functionality of these apps, rather than being just in-

cluded incidentally, e.g., via used third-party libraries.

The inspection of 24 iOS and 5 Android apps failed

due to errors in processing the app archives. Of them,

21 apps for iOS could not be decompiled from ARMv8

to LLVM IR code due to missing mappings of instruc-

tion codes. Also, our Android framework was unable

to process four apps, where the archive was damaged,

despite repeated tries to re-download a functional ver-

sion from Google Play. For another four apps, out

of memory errors occurred during pointer analysis on

iOS or register tracking on Android.

For 775 apps supplied to the iOS framework and

our solution for Android, the analysis workﬂow ter-

minated successfully. For each inspected application,

we obtained a generated report that included the re-

sult of the performed security checks and for all rule

violations, listings with problematic execution paths.

6.2.1 Violations of Security Rules

We found that 78% or 604 apps for iOS and 69% or 538

apps for Android commit at least one security-critical

mistake. Among them, we identiﬁed 52% or 404 apps,

where the Android and iOS versions of the same app

commit at least one mistake on both platforms.

Table 2 lists our observations of violated security

rules. We discuss the ﬁndings in more detail below.

Rule 1: Do Not Use ECB Mode for Encryption.

On Android, we observed that 77% or 587 apps use

instances of symmetric ciphers where the underlying

mode of operation is ECB. Manually studying found

execution path clariﬁes that block ciphers are mostly

declared without explicitly specifying the mode and

padding to use. This causes the underlying provider to

apply ECB mode implicitly. Although the use of AES

is predominant, at times we also noticed

Cipher

ob-

jects, specifying the nowadays weak DES algorithm.

CBC being the default mode on iOS, 25% or 192

apps explicitly declared to use ECB. In 22% or 172

apps, this mode was speciﬁed in the iOS version and

also deployed in Android pendant of the same app.

Rule 2: No Non-random IVs for CBC Encryption.

35% or 271 apps on Android speciﬁed a static IV orig-

inating from hard-coded byte arrays or constant values.

Manually verifying the results, we found that the ma-

jority derived a cryptographically secure IV using the

API

SecureRandom

. Some Android apps relied on the

Random API instead, which leads to predictable IVs.

On iOS, this was the most prominent problem: 64%

or 494 apps used a constant IV. Mostly, no IV was

declared at all, thus, implicitly causing an all zeros IV.

Rule 3: Do Not Use Constant Encryption Keys.

Hard-coded encryption keys were identiﬁed as an issue

in 41% or 320 Android apps and 59% or 455 iOS apps.

Regarding the prevalence in apps for both platforms,

31% or 243 apps used constant data as key material.

Table 3 highlights the provenience of key material.

The according execution traces show that most apps

which employ constant keys do so by deriving them

from string values or by declaring byte arrays with

constants. In practice, apps typically create distinct

instances of

Cipher

(Android) and

CCCryptor

(iOS)

objects for encryption and decryption. However, as

they usually refer to the same constant key material,

the total number of hard-coded secrets exceeds the

number of apps with this issue.

Besides being entirely variable or static, from

studying the execution paths, we learned that encryp-

tion keys can also be mixed, consisting of a statically

deﬁned key concatenated with a non-constant value.

A Comparative Study of Misapplied Crypto in Android and iOS Applications

105

Table 2: Violations of security rules in 775 apps for Android and iOS.

Rule (R)

Overall rule violations in apps Rule violations in same

Android iOS apps on both platforms

R1: Do not use ECB mode for encryption 598 (77%) 192 (25%) 172 (22%)

R2: No non-random IVs for CBC encryption 271 (35%) 494 (64%) 200 (26%)

R3: Do not use constant encryption keys 320 (41%) 455 (59%) 243 (31%)

R4: Do not use constant salts for PBE 112 (14%) 84 (11%) 49 (6%)

R5: Do not use < 1,000 iterations for PBE 119 (15%) 145 (19%) 104 (13%)

R6: Do not use static seeds for PRNGs 25 (3%) - -

Applications with ≥ 1 rule violations 538 (69%) 604 (78%) 404 (52%)

No rule violation 237 (31%) 171 (22%) 371 (48%)

Interpreting these keys as constants would be inaccu-

rate as we are unable to make assumptions about the

entropy provided by the non-constant part.

Rule 4: Do Not Use Constant Salts for PBE.

identiﬁed that 14% or 112 Android apps and 11% or

84 inspected iOS apps passed constant salt values as

input to key derivation functions. This effectively un-

dermines the protection of password-based encryption

against table-based attacks. On both platforms, most

apps violating this rule declared a static byte array ini-

tialized with zero values. In 6% or 49 apps, this issue

occurred in both versions of the same app.

Rule 5: Do Not Use < 1,000 Iterations for PBE.

On Android, we found that 15% or 119 apps employ

less than the minimally advised amount of 1000 itera-

tions for Password-Based Encryption (PBE). Likewise,

19% or 145 apps for iOS and 13% or 104 apps on

both platforms declared a too small value. Regarding

the distribution of the iterations, most rule-violating

apps speciﬁed a count of either 20, 50, 64, or 100. In

execution traces of iOS apps without this issue, we

could observe a signiﬁcant prevalence of apps using

CCCalibratePBKDF()

API to dynamically derive an

iteration count, rather than hard-coding a value.

Rule 6: Do Not Use Static Seeds for Random-num-

ber Generation.

As the platform APIs on iOS do

not offer a seedable PRNG, this rule can only be vi-

olated by Android apps. Changes in the underlying

PRNG implementation have globally ﬁxed this vulner-

ability for systems running Android 4.2 (API level 16)

or newer. Due to this and only 3% or 25 Android apps

declaring a constant seed for use with

SecureRandom

the practical impact of this rule violation is limited.

6.3 Discussion

The study of 775 apps that were distributed for An-

droid and iOS revealed that in 52% or 404 apps

security-critical mistakes were present in both versions.

Table 3: Origin of constant secrets used as key material.

# Violations on Android iOS

Constant string used as encryption key 238 305

Constant byte array as key 96 164

Hash value of constant string 9 36

iOS: Secret retrieved from NSUserDefaults - 28

Applications violating rule 3 320 455

The individual rule violations per platform have clearly

shown a trend that some misuses happen more often

on a speciﬁc platform. At the same time, it became

obvious that the likelihood for some other mistakes is

independent of a particular API design.

The most signiﬁcant difference in rule violations

across platforms was observed in the ﬁrst rule targeting

the use of ECB mode for encryption. The high number

of 77% or 598 Android apps with this issue can be

attributed to the fact that, unless a mode is speciﬁed,

an implicit fallback to ECB occurs. In contrast, on

iOS only 25% or 192 apps explicitly speciﬁed ECB

instead of the default mode CBC. This circumstance

strongly indicates that the prevalence of this problem

on Android is caused by an insecure default setting.

Another notable difference between the two plat-

forms has shown regarding the use of non-random IVs

for CBC encryption. On Android, if no IV is speciﬁed,

Cipher

will automatically generate a strong IV that

can be retrieved via

Cipher->getIV()

. As opposed

to that, not declaring an IV on iOS will cause that a

NULL (all zeros) IV is used for encryption. This again

highlights the importance of secure default settings.

The most frequently violated issue in apps for both

platforms affects constant encryption keys. Compared

with other security violations, the

key

parameter al-

ways has to be provided manually. Sadly, both devel-

opers of Android and iOS apps, seem to be not aware

of the radical consequences of hard-coding secrets.

Summarizing, we have seen that the origins of mis-

takes fall into two categories: ﬁrstly, those which are

based on insecure default values in the correspond-

SECRYPT 2019 - 16th International Conference on Security and Cryptography

106

ing API, e.g., implicit ECB mode on Android, or a

NULL IV on iOS, and secondly, security problems

that occur due to developers not carefully handling

security-critical parameters, like encryption keys.

As a remedy, we propose a two-fold strategy:

1. API Changes:

Unsafe default values in APIs,

such as ECB mode on Android, should be re-

placed by secure alternatives. In occasions, where

omitting arguments impairs security, e.g., a NULL

value as IV on iOS, a cryptographically secure ran-

dom value should be generated instead. Although

such profound changes might break compatibility

with existing code, they would require develop-

ers to improve their implementations and, thereby,

minimize the prevalence of problematic code.

2. Raising Awareness:

Modern IDEs for application

development, such as Android Studio or Apple

Xcode, feature sophisticated code inspection. Fol-

lowing our recipes presented to evaluate security-

critical attributes (see Section 5), code analysis in

IDEs should be extended to warn about harmful

practices, such as hard-coded encryption keys.

7 CONCLUSION

In this paper, we studied misapplied crypto APIs in

Android and iOS apps. By introducing an easily adapt-

able framework to track data ﬂows throughout Android

apps, we succeed in reliably pinpointing the origin of

wrongly chosen security-relevant attributes. Therefore,

we elaborated and implemented detection strategies to

assess the cryptographic soundness of parameters that

are used with encryption and key derivation APIs.

We presented the ﬁrst comparative evaluation of

crypto API misuse across platforms. Evaluated using a

carefully selected set of 775 apps that were distributed

for Android and iOS, we found security mistakes in

69% or 538 Android apps and 78% or 604 iOS apps.

Unsafe default values in platform-provided APIs and

missing developer awareness strongly contribute to

this widespread of problems. Our results also highlight

the need to compare concrete execution traces of API

invocations to better understand the context of methods

that are invoked with cryptographically weak values.

Finally, our study underlines that misapplied crypto is

still a severe issue in Android and iOS apps.

REFERENCES

Acar, Y., Backes, M., Fahl, S., Garﬁnkel, S. L., Kim, D.,

Mazurek, M. L., and Stransky, C. (2017). Comparing

the Usability of Cryptographic APIs. In IEEE Sympo-

sium on Security and Privacy – S&P, pages 154–171.

IEEE Computer Society.

Arzt, S., Rasthofer, S., Fritz, C., Bodden, E., Bartel, A.,

Klein, J., Traon, Y. L., Octeau, D., and McDaniel,

P. D. (2014). FlowDroid: Precise Context, Flow, Field,

Object-Sensitive and Lifecycle-aware Taint Analysis

for Android Apps. In Programming Language Design

and Implementation – PLDI, pages 259–269. ACM.

Chatzikonstantinou, A., Ntantogian, C., Karopoulos, G., and

Xenakis, C. (2015). Evaluation of Cryptography Usage

in Android Applications. In Bio-inspired Information

and Communications Technologies – BICT, pages 83–

90. ICST/ACM.

Deng, Z., Saltaformaggio, B., Zhang, X., and Xu, D. (2015).

iRiS: Vetting Private API Abuse in iOS Applications.

In Conference on Computer and Communications Se-

curity – CCS, pages 44–56. ACM.

Egele, M., Brumley, D., Fratantonio, Y., and Kruegel, C.

(2013). An Empirical Study of Cryptographic Misuse

in Android Applications. In Conference on Computer

and Communications Security – CCS, pages 73–84.

ACM.

Enck, W., Gilbert, P., Chun, B., Cox, L. P., Jung, J., Mc-

Daniel, P. D., and Sheth, A. (2010). TaintDroid: An

Information-Flow Tracking System for Realtime Pri-

vacy Monitoring on Smartphones. In Symposium on

Operating Systems Design and Implementation – OSDI,

pages 393–407. USENIX Association.

Feichtner, J., Missmann, D., and Spreitzer, R. (2018). Au-

tomated Binary Analysis on iOS: A Case Study on

Cryptographic Misuse in iOS Applications. In Secu-

rity and Privacy in Wireless and Mobile Networks –

WISEC, pages 236–247. ACM.

Lazar, D., Chen, H., Wang, X., and Zeldovich, N. (2014).

Why does cryptographic software fail?: a case study

and open problems. In Asia-Paciﬁc Workshop on Sys-

tems, APSys’14, Beijing, China, June 25-26, 2014,

pages 7:1–7:7. ACM.

Li, L., Bartel, A., Bissyand

e, T. F., Klein, J., Traon, Y. L.,

Arzt, S., Rasthofer, S., Bodden, E., Octeau, D., and

McDaniel, P. D. (2015). IccTA: Detecting Inter-

Component Privacy Leaks in Android Apps. In Inter-

national Conference on Software Engineering – ICSE,

pages 280–291. IEEE Computer Society.

Li, Y., Zhang, Y., Li, J., and Gu, D. (2014). iCryptoTracer:

Dynamic Analysis on Misuse of Cryptography Func-

tions in iOS Applications. In Network and System

Security – NSS, volume 8792 of LNCS, pages 349–362.

Springer.

Ma, S., Lo, D., Li, T., and Deng, R. H. (2016). CDRep: Au-

tomatic Repair of Cryptographic Misuses in Android

Applications. In Asia Conference on Computer and

Communications Security – AsiaCCS, pages 711–722.

ACM.

Muslukhov, I., Boshmaf, Y., and Beznosov, K. (2018).

Source Attribution of Cryptographic API Misuse in

Android Applications. In Asia Conference on Com-

puter and Communications Security – AsiaCCS, pages

133–146. ACM.

Nadi, S., Kr

uger, S., Mezini, M., and Bodden, E. (2016).

Jumping through hoops: why do Java developers strug-

A Comparative Study of Misapplied Crypto in Android and iOS Applications

107

gle with cryptography APIs? In International Confer-

ence on Software Engineering – ICSE, pages 935–946.

ACM.

Octeau, D., Jha, S., and McDaniel, P. D. (2012). Retargeting

Android applications to Java bytecode. In Foundations

of Software Engineering – FSE, page 6. ACM.

Paletov, R., Tsankov, P., Raychev, V., and Vechev, M. T.

(2018). Inferring crypto API rules from code changes.

In Programming Language Design and Implementa-

tion – PLDI, pages 450–464. ACM.

Shao, S., Dong, G., Guo, T., Yang, T., and Shi, C. (2014).

Modelling Analysis and Auto-detection of Crypto-

graphic Misuse in Android Applications. In Confer-

ence on Dependable, Autonomic and Secure Comput-

ing – DASC, pages 75–80. IEEE Computer Society.

Sun, M., Wei, T., and Lui, J. C. S. (2016). TaintART: A Prac-

tical Multi-level Information-Flow Tracking System

for Android RunTime. In Conference on Computer

and Communications Security – CCS, pages 331–342.

ACM.

Tip, F. (1995). A Survey of Program Slicing Techniques. J.

Prog. Lang., 3.

Weiser, M. (1981). Program Slicing. In International Confer-

ence on Software Engineering – ICSE, pages 439–449.

IEEE Computer Society.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

108
