VersaTL: Versatile Transfer Learning for IMU-based Activity

Recognition using Convolutional Neural Networks

Mubarak G. Abdu-Aguye

and Walid Gomaa

1,2

Computer Science and Engineering Department, Egypt-Japan University of Science and Technology, Egypt

Faculty of Engineering, Alexandria University, Egypt

Keywords:

Activity Recognition, Transfer Learning, IMU, Convolutional Neural Networks, Deep Learning.

Abstract:

The advent of Deep Learning has, together with massive gains in predictive accuracy, made it possible to

reuse knowledge learnt from solving one problem in solving related problems. This is described as Transfer

Learning, and has seen wide adoption especially in computer vision problems, where Convolutional Neural

Networks have shown great ﬂexibility and performance. On the other hand, transfer learning for sequences or

timeseries data is typically made possible through the use of recurrent neural networks, which are difﬁcult to

train and prone to overﬁtting. In this work we present VersaTL, a novel approach to transfer learning for ﬁxed

and variable-length activity recognition timeseries data. We train a Convolutional Neural Network and use its

convolutional ﬁlters as a feature extractor, then subsequently train a feedforward neural network as a classiﬁer

over the extracted features for other datasets. Our experiments on ﬁve different activity recognition datasets

show the promise of this method, yielding results typically within 5% of trained-from-scratch networks while

obtaining between a 24-52x reduction in the training time.

1 INTRODUCTION

Deep neural networks entered the mainstream with

the seminal work of Hinton and Salakhutdinov (Hin-

ton and Salakhutdinov, 2006). Since then, the gen-

eral trend in machine learning research has been to-

wards the adoption and analysis of deep methods as

applied to different domains. This can be mainly

attributed to the massive performance improvements

gained through the use of deep neural networks (Jor-

dan and Mitchell, 2015), with such methods deﬁning

the state of the art in several diverse applications to-

day. Additionally, deep methods have, in some sense,

reﬁned and justiﬁed previous intuition and hypotheses

regarding neural learning. Perhaps the most speciﬁc

case of this is the notion of hierarchical representation

as put forward in (Hinton and Salakhutdinov, 2006),

(Bengio, 2012), where (deep) neural networks are be-

lieved to learn features of the data in an incremental,

compositional manner. Some work done in visual-

izing the learned features (Zeiler and Fergus, 2014)

and activation maps (Harley, 2015) in image-based

Convolutional Neural Networks provide deﬁnitive ev-

idence of this phenomenon.

A direct implication of this sort of hierarchical

learning is that it enables the sharing or re-use of more

general, lower-level knowledge gained from solving

one problem in the solution of another problem shar-

ing the same or similar lower-level bases/primitives.

For instance, the problem of recognizing two differ-

ent objects will have similar requirements at a lower

level, e.g., recognizing boundaries or edges of the ob-

jects, up until some point where the visual character-

istics are sufﬁciently different from the two objects

(e.g. boxes and birds have radically different appear-

ances when considered in their entirety, even though

they are both composed of lines and curves). There-

fore, it becomes theoretically possible to re-use this

lower level knowledge in solving similar problems,

therefore saving time, resources, and requiring much

less training data than training a deep network from

scratch. This is described as transfer learning (Pan

et al., 2010) and is very commonly used in computer

vision tasks (Oquab et al., 2014),(Karpathy et al.,

2014).

For other types of data whose structures are

not trivial to decompose intuitively, transfer learn-

ing has not gained much traction for varying rea-

sons. Difﬁculties in dealing with varying data

lengths, as opposed to standard approaches to same

in image-based problems may be one cause of this.

For sequence/time-series data, approaches to trans-

Abdu-Aguye, M. and Gomaa, W.

VersaTL: Versatile Transfer Learning for IMU-based Activity Recognition using Convolutional Neural Networks.

DOI: 10.5220/0007916705070516

In Proceedings of the 16th International Conference on Informatics in Control, Automation and Robotics (ICINCO 2019), pages 507-516

ISBN: 978-989-758-380-3

507

fer learning have naturally adopted recurrent archi-

tectures like Long Short Term Memory (LSTM) net-

works (Hochreiter and Schmidhuber, 1997) due to

their sequence-modelling abilities and their ability

to generate a ﬁxed-size representation of their input

data regardless of its length. However, such net-

works require signiﬁcant effort to be properly initial-

ized and trained (Salehinejad et al., 2018) and are of-

ten prone to overﬁtting (Zaremba et al., 2014). On

the other hand, Convolutional Neural Networks have

much more desirable properties, i.e., they are much

more ﬂexible and robust, and can match recurrent

models even on sequential data (Yin et al., 2017), (Bai

et al., 2018). Therefore transfer learning approaches

relying on convolutional neural networks can be con-

sidered as viable alternatives to recurrent neural net-

works.

In this work we propose VersaTL, a transfer learn-

ing scheme for activity recognition data based on

convolutional neural networks. This is aimed at re-

laxing the requirement for large amounts of training

data usually required for training deep models from

scratch. Additionally, this serves to signiﬁcantly re-

duce the time required for the training process for

both small and large datasets with minimal loss in

predictive performance.We consider a ﬁxed number

of dimensions (i.e., number of axes/channels) for our

data. In order to deal with varying input lengths, we

incorporate a 1-D variant of Spatial Pyramid Pool-

ing (He et al., 2014) so as to obtain a ﬁxed length fea-

ture vector from the convolutional feature maps in our

network. We evaluate our proposed technique on ﬁve

different activity recognition datasets, as we consider

that there are common patterns in the data collected

during different activities regardless of the source of

the data or the activity itself. We achieve promising

results comparable to trained-from-scratch networks

using this scheme with expectedly much lower train-

ing time. Additionally, we show that our method com-

petes favorably against similar, extant methods.

The rest of this paper is structured as follows. In

Section 2 we discuss other literature that are relevant

to the works carried out in this paper. We provide

a brief description of key concepts relevant to this

work in Section 3. Section 4 describes the methodol-

ogy proposed by VersaTL in terms of its implementa-

tion and considerations. In Section 5 we describe the

datasets considered as well as the manner in which

our proposed technique was tested. Section 6 gives

the results of the experiments described in Section

5, as well as their consequent evaluation. In Sec-

tion 7 we discuss additional experiments and their re-

sults, which further clarify our arguments and provide

comparative information between our work and other

work already in literature. We conclude the paper in

Section 8 with a summary of our work and the out-

comes we obtained, together with points for future

consideration.

2 RELATED WORK

Here we discuss other works in literature which ap-

ply transfer learning to activity recognition. We group

them into two main categories based on the adopted

paradigm - instance-based methods, which aim to

adapt samples from one domain for reuse in another

domain, and feature-based methods, which aim to

transfer feature-extraction knowledge from the source

domain to the target domain.

2.1 Instance-based Transfer Learning

The work done in (Hu et al., 2011) is aimed towards

the adaptation of activity instances collected in the

performance of some task in the training of a clas-

siﬁer for another set of instances. They propose an

algorithm to do this, which functions by utilizing pre-

existing web data describing the two activity sets.

Based on the web data, a similarity framework is built

within which the instances for some activity in the

source domain may be mapped to some other activ-

ity in the target domain with some conﬁdence value.

They achieve results comparable to traditional meth-

ods highlighting the effectiveness of their technique.

The authors in (Khan and Roy, 2017) proposed an

instance-based transfer learning framework, where la-

belled samples from one set of activities (i.e source

activity set/domain) are re-used/boosted as samples

for matching/common activities in another activity

set, based on a transferability metric. K-Means clus-

tering is then used to derive ”anomalous” clusters of

the unseen/uncommon activities in the target activ-

ity set. A classiﬁer is then trained on samples from

the common and uncommon activities, the output

of which governs how new instances are classiﬁed.

Speciﬁcally, new samples are either matched using a

classiﬁer trained on the boosted samples or matched

using the anomalous clusters previously deﬁned, de-

pending on if the discriminatory classiﬁer classiﬁes

the sample as belonging to a common or uncommon

activity. The authors consider three datasets and re-

port up to 85% recall in inter-dataset testing, where

the target dataset contains previously unseen activi-

ties.

In contrast, the work carried out in this paper

is geared towards feature-based transfer learning,

ICINCO 2019 - 16th International Conference on Informatics in Control, Automation and Robotics

508

which we believe is more ﬂexible and does not de-

pend on domain interrelationships or the availability

of suitable samples from the source domain.

2.2 Feature-based Transfer Learning

In (Khan and Roy, 2018), the authors propose the

transfer of feature-extraction knowledge from one

dataset to another (i.e source to target). They trained

a Deep Sparse Autoencoder (DSAE) on pre-extracted

feature vectors and use a part of the encoder portion

of the trained network as a feature extractor. Three

Support Vector Machine classiﬁers are then trained,

one on features extracted from source-domain sam-

ples using the DSAE, another on features extracted

from the target domain using the DSAE and the last

trained on low-level features also extracted from the

target domain. Decision fusion techniques are then

used to combine the outputs of the SVMs to yield a ﬁ-

nal decision. The authors also compare their method

to two state-of-the-art transfer-learning based classi-

ﬁers and report better performance than both of them.

In (Chikhaoui et al., 2018), a transfer learn-

ing scheme utilizing a convolutional neural network

(CNN) is proposed. The authors pretrain a CNN-

based classiﬁer, and transfer the learned weights to

a new, similarly-structured network for the target do-

main. Further training on the target domain data is

then carried out with a view to ﬁne-tuning the new

network, without changing/updating the transferred

weights. The authors investigate the performance of

their method on three datasets and investigate its ef-

ﬁcacy across different users, device placements and

sensor modalities. They report F1-scores of up to 0.94

in some of the evaluated scenarios.

As compared to (Khan and Roy, 2018), VersaTL

does not make any assumptions about activity inter-

relationships between the source and target domains

as it aims for generality. Also, it obviates the need

for any feature pre-extraction due to the use of the

convolutional frontend, permitting the use of the raw

timeseries directly. Furthermore, it does not impose

any requirements or strictures on the classiﬁcation

methodology.

Additionally, VersaTL differs from (Chikhaoui

et al., 2018) which requires the use of samples with

ﬁxed lengths. We allow for both ﬁxed and varying-

length samples, which are a reality in the domain of

activity recognition. We also design our network to

be more compact. As a result, our network is simpler

as it has much fewer weights and therefore requires

much less training data. This permits the use of small

datasets as we demonstrate in the following sections.

3 BACKGROUND

3.1 Spatial Pyramid Pooling

Spatial Pyramid Pooling (SPP) was ﬁrst introduced

by He et al. in (He et al., 2014). It can be consid-

ered as a pooling method for yielding ﬁxed-length

outputs from feature maps in convolutional neural

networks, which traditionally rely on ﬁxed-size (im-

age) inputs. These ﬁxed-size inputs are usually ob-

tained by cropping or resizing the inputs, which affect

network accuracy on varying-size input (images) due

to accidentally-induced geometric deformations. By

eliminating this requirement, spatial pyramid pooling

makes it possible to train convolutional networks on

varying-size inputs, which was also found to boost

the predictive performance of such networks since

the features learned become scale and deformation-

invariant and can therefore be considered to be robust.

Traditional pooling methods such as max and av-

erage pooling use ﬁxed-length pooling windows. As

a result the size of their outputs depend on the size

of their input feature maps. SPP computes the size of

its pooling windows adaptively based on the size of

the input feature maps. Speciﬁcally, for a given pool-

ing size s, SPP computes a pooling window size and

the necessary amount of padding so as to divide the

input feature map(s) into s regions. Subsequently, it

performs a pooling operation (max or average) over

each (spatial) region, generating one feature per re-

gion. In this manner it generates the speciﬁed number

(as given by s) of output features per feature map.

In order to gain the invariance described previ-

ously, SPP is typically performed for different pool-

ing sizes. In practice this involves the division of the

input feature maps into the number of regions speci-

ﬁed by each pooling size, and yields one feature per

region. Therefore, the total number of features gener-

ated is the sum of the features generated per pooling

size considered. In (He et al., 2014), a pooling size of

1 was always considered in addition to other pooling

sizes. SPP with a pooling parameter/size of 1 can be

considered to be a global pooling operation i.e., it per-

forms pooling over the entire input feature map, yield-

ing a single feature. In this way it can be seen that

global pooling operations are particular cases of SPP

where the pooling parameters/sizes are set to 1. Thus

the use of SPP (and including 1 in the pooling sizes

to be considered) encompasses global pooling and ex-

tends it to arbitrary scales as well. This allows for the

maintenance of multiscale information obtained from

the input implicitly, preserving local and global char-

acteristics of the input regardless of its size.

Without a loss of generality, SPP can also be ap-

VersaTL: Versatile Transfer Learning for IMU-based Activity Recognition using Convolutional Neural Networks

509

plied to 1-D inputs such as timeseries data. In this

scenario the adaptive pooling window itself becomes

1-dimensional and its length is computed in terms of

the length of the sequence. The input series is then

padded (if necessary) and subdivided into chunks as

described previously, and then the pooling operation

(max or average) is performed over each chunk, yield-

ing one feature per chunk.

In the current work SPP parameters/sizes are de-

scribed using a hyphenated notation, e.g., a − b − c.

This notation implies that the input sample is divided

into a regions, and then region-wise pooling is per-

formed yielding a features. This is repeated for size

b, yielding b features and size c yielding c features.

Therefore for SPP parameters a −b−c, the total num-

ber of features computed per input feature map is

a + b + c, e.g., 4 − 2 − 1 yields 4 + 2 + 1 = 7 features

per feature map.

4 PROPOSED METHODOLOGY

The architecture of VersaTL is shown in Figure 1.

We begin with a convolutional neural network, con-

sisting of a feature extraction portion based on two

convolutional layers followed by a classiﬁcation por-

tion based on a three-layer feedforward neural net-

work. We use a dilated convolution in the second ﬁl-

ter, which allows for a wider receptive ﬁeld for con-

volutional ﬁlters while utilizing fewer weights than

a regular convolutional window. The output of the

convolutional ﬁlters depends on the length of the in-

put data. This is not directly suitable for the classi-

ﬁcation portion, which requires a ﬁxed-length feature

vector as input. To work around this limitation, we in-

clude a spatial pyramid pooling layer (He et al., 2014)

which converts the varying-length ﬁlter outputs into a

ﬁxed length vector. The use of spatial pyramid pool-

ing is inﬂuenced by its ability to summarize the gener-

ated feature maps over large and small (time) scales,

thereby preserving local and global characteristics of

the extracted features in a compact manner. As such,

we adopt this type of pooling rather than a global av-

erage or max-pooling so as to maintain some of the

temporal information/variations of the activity signals

while keeping the network size small. We use the

hyperbolic tangent (”tanh”) activation function in the

convolutional ﬁlters as we found it to yield superior

performance relative to the other activation functions.

Additionally, we include batch normalization layers

in between the feedforward layers in the classiﬁcation

portion. This was found to signiﬁcantly improve the

network performance and convergence time.

Given a parent dataset, we train the model in an

end-to-end manner, i.e., we train both the feature ex-

traction and classiﬁcation portions as a single unit us-

ing cross entropy loss and the Adam optimizer. Af-

ter this training, we consider the feature extraction

portion to be suitably discriminative for feature ex-

traction purposes. For any other dataset, the feature

extraction portion is used as a black box to gener-

ate ﬁxed-length feature vectors describing the input.

The generated vectors can then be used with any other

classiﬁer, although in this work we focus on using a

feedforward network tailored to the number of classes

in the (new) dataset for classiﬁcation. The feedfor-

ward network is then trained with some portion of

the generated vectors (collected in mini-batches) used

as training examples, and the remaining data is used

to evaluate the performance of the proposed method.

This approach has been adopted in this work as it is

virtually identical to the transfer learning scheme used

in computer vision tasks, which has shown itself to

yield excellent results.

Details of our experimental evaluations are pro-

vided in the following section.

5 EXPERIMENTAL

METHODOLOGY

5.1 Datasets Considered

In order to obtain performance estimates for our pro-

posed method, we consider ﬁve publicly-available ac-

tivity recognition datasets. The datasets chosen have

different sample counts and lengths and generally

consist of different activity sets. In addition, they

generally come from different devices with differ-

ent characteristics (e.g. placement, make and model

of the device, etc.). Although the datasets are com-

prised of different modalities (e.g accelerometer, gy-

roscope, magnetometer, orientation, etc.) we consider

the accelerometer and gyroscope readings only. This

is because these readings are available across all the

datasets and therefore allow for straightforward trans-

fer learning from one dataset to another.

5.1.1 Gomaa-1 Dataset

The Gomaa-1 dataset (Gomaa et al., 2017) consists of

603 varying-length samples collected from three sub-

jects, using an Apple SmartWatch series 1 at a sam-

pling rate of 50Hz. It contains 14 activities of daily

living.

ICINCO 2019 - 16th International Conference on Informatics in Control, Automation and Robotics

510

Figure 1: Proposed System Architecture.

5.1.2 Human Activity and Postural Transitions

(HAPT)

The human activity and postural transitions (HAPT)

dataset (Reyes-Ortiz et al., 2016) consists of 1, 214

varying-length samples collected from thirty subjects,

using Android smartphones at a sampling rate of

50Hz. It contains 6 activities and 6 postural transi-

tions.

5.1.3 Daily and Sports Activities

The Daily and Sports activities (Altun et al., 2010)

dataset consists of 9, 120 ﬁxed-length samples col-

lected from 8 subjects. The samples were recorded

using Xsens IMU units at a sample rate of 25Hz. It

contains 19 activities.

5.1.4 HAD-AW

The HAD-AW dataset (Mohammed et al., 2018) con-

sists of 4, 344 varying-length samples collected from

16 subjects. The data was obtained from an Apple

SmartWatch series I at a sampling rate of 50Hz, sim-

ilar to the Gomaa-1 dataset. It contains 32 widely-

varying activities.

5.1.5 Realistic Sensor Displacement

The Realistic Sensor Displacement (REALDISP)

dataset (Ba

nos et al., 2012), (Banos et al., 2014) con-

sists of samples collected from 17 subjects. Xsens

IMU units were used to capture the data at a sampling

rate of 50Hz. It consists of samples of 33 different

activities recorded while the data capture device was

displaced in one of three ways, which was done to

capture real-world placement scenarios.

Originally consisting of 4000+ varying-length

samples, 1, 397 of these were found to be usable after

Table 1: Details of Datasets Considered.

Name Samples Activities

Gomaa-1 603 14

HAPT 1214 12

Daily Sports 9120 19

HAD-AW 4344 32

REALDISP 1397 33

preprocessing and the subsequent elimination of inde-

terminate/unlabelled samples. Therefore, we consider

only these samples for our evaluations.

The details of these datasets are summarized in

Table 1.

5.2 Experimental Evaluations

To determine the efﬁcacy of our technique, we train

on each of the described datasets, and then perform

transfer learning (as described in section 4) on each

of the other four datasets. Therefore we report the re-

sults from both self-testing (i.e., train and test on same

dataset) scenarios, which serve as performance base-

lines, and transfer learning (i.e., train CNN on some

dataset, ﬁne-tune classiﬁer on some other dataset)

scenarios. We vary the parameters of the spatial pyra-

mid pooling layer (which changes the ﬁxed-length

feature vector size) to investigate their effect on the

performance of our method. In the transfer learn-

ing scenarios, since we use a feedforward network as

classiﬁer, we also tested different common mini-batch

sizes to ﬁnd a suitable value. A mini-batch size of

128 was found to be best and was used for the evalua-

tions of all the pooling parameters considered. We use

learning-rate scheduling and ﬁx the number of train-

ing epochs in both self-testing and transfer learning

scenarios at 35 epochs.

The training and testing cycles are repeated ﬁf-

teen (15) times, with different samples of data be-

VersaTL: Versatile Transfer Learning for IMU-based Activity Recognition using Convolutional Neural Networks

511

Table 2: Classiﬁcation Accuracy using 2-1 Pooling.

Training Dataset Testing Dataset

Gomaa-1 HAPT D Sports HAD-AW REALDISP

Gomaa-1 94.76 ± 1.67 94.95 ± 1.30 91.69 ± 0.88 81.59 ± 1.22 70.66 ± 1.68

HAPT 93.86 ± 2.09 95.76 ± 0.93 91.04 ± 0.54 82.04 ± 1.45 67.82 ± 2.17

D Sports 95.18 ± 1.82 94.60 ± 1.05 94.99 ± 0.47 82.32 ± 0.92 67.65 ± 2.35

HAD-AW 93.33 ± 2.22 95.43 ± 1.45 92.29 ± 0.53 87.29 ± 1.25 68.66 ± 2.55

REALDISP 93.55 ± 1.04 95.59 ± 0.96 92.75 ± 0.52 82.27 ± 1.01 74.78 ± 2.24

Table 3: Classiﬁcation Accuracy using 4-2-1 Pooling.

Training Dataset Testing Dataset

Gomaa-1 HAPT D Sports HAD-AW REALDISP

Gomaa-1 96.99 ± 1.28 94.53 ± 1.55 92.19 ± 0.64 82.66 ± 1.01 71.94 ± 2.64

HAPT 95.09 ± 1.90 96.00 ± 1.18 91.06 ± 0.76 83.10 ± 1.12 68.85 ± 1.77

D Sports 95.98 ± 1.48 95.24 ± 1.09 95.31 ± 0.36 83.20 ± 1.15 71.14 ± 3.70

HAD-AW 95.93 ± 1.55 95.61 ± 1.18 92.38 ± 0.50 88.36 ± 1.18 71.63 ± 2.15

REALDISP 95.58 ± 1.18 94.82 ± 1.55 92.59 ± 0.41 83.60 ± 1.02 76.60 ± 1.88

Table 4: Classiﬁcation Accuracy using 8-4-2-1 Pooling.

Training Dataset Testing Dataset

Gomaa-1 HAPT D Sports HAD-AW REALDISP

Gomaa-1 95.58 ± 1.76 94.86 ± 1.13 92.04 ± 0.85 82.97 ± 1.16 72.85 ± 1.75

HAPT 94.83 ± 1.75 96.05 ± 1.30 90.40 ± 0.79 83.14 ± 1.22 69.52 ± 2.68

D Sports 95.09 ± 1.79 95.15 ± 1.11 95.09 ± 0.33 83.22 ± 1.39 73.92 ± 2.25

HAD-AW 96.86 ± 1.20 95.10 ± 1.21 91.89 ± 0.77 88.65 ± 1.24 73.27 ± 2.52

REALDISP 95.62 ± 0.63 95.41 ± 1.18 92.35 ± 0.67 84.36 ± 1.05 77.40 ± 2.28

Table 5: Training Times (in Seconds) for Self Testing and Transfer Learning Scenarios (4-2-1 Pooling).

Training Dataset Testing Dataset

Gomaa-1 HAPT D Sports HAD-AW REALDISP

Gomaa-1 426.10 ± 5.95 16.44 ± 0.50 62.30 ± 1.37 49.70 ± 1.18 27.07 ± 0.95

HAPT 9.91 ± 0.29 513.33 ±4.50 62.02 ±0.94 49.44 ±0.90 27.02 ±0.65

D Sports 9.98 ±0.40 16.30 ± 0.40 1503.26 ± 13.38 50.20 ± 1.35 27.08 ± 0.75

HAD-AW 9.92 ± 0.35 16.32 ± 0.54 63.12 ± 1.63 1952.15 ± 16.19 27.16 ± 0.63

REALDISP 9.98 ± 0.31 16.33 ± 0.45 62.57 ± 1.42 49.84 ± 1.26 1413.45 ± 16.13

ing used for training and testing each time. 75% of

the data is used for training in both self-testing and

transfer learning scenarios, with the remaining 25%

being used for testing. We also carry out some tim-

ing evaluations in order to investigate the computa-

tional speed of our proposed method relative to train-

ing from scratch. Speciﬁcally we measure the train-

ing time in the self-testing scenarios and the sum of

the feature extraction and training times in the trans-

fer learning scenarios, with the latter measurements

reﬂecting the typical use case. The timings were

also obtained over ﬁfteen trials. The machine used

to obtain these timings utilized an 8-core Intel Xeon

Platinum 8168 CPU with 16GB of RAM. During the

training cycles, CPU-only training was used to give a

fair estimate of performance and eliminate any extra-

neous advantages due to the use of graphics process-

ing units (GPUs). We thereafter report the mean and

standard deviation of the obtained times measured in

seconds.

The results obtained and their subsequent discus-

sion are provided in the following section.

6 RESULTS AND DISCUSSION

The results obtained from our experimental evalua-

tions are shown in Tables 2-4. The diagonal elements

(highlighted in gray) indicate the self-testing scenar-

ios (training and testing over the same dataset) and

can therefore be considered to be the baseline perfor-

mance estimates for each dataset. The off-diagonal,

column-wise elements show the transfer learning re-

ICINCO 2019 - 16th International Conference on Informatics in Control, Automation and Robotics

512

sults, i.e. the results obtained from testing on the

column-speciﬁed dataset after training on the row-

speciﬁed dataset. The classiﬁcation accuracies ob-

tained are shown together with their standard devia-

tions in the tables (i.e accuracy ± std.deviation). As

stated previously, these values were obtained from av-

eraging the results over ﬁfteen experiments/trials.

In general, it can be seen that the results obtained

from transfer learning are averagely within 5% of the

results obtained from self-testing scenarios. The stan-

dard deviation of the results are also generally low,

remaining below 3% in all the scenarios considered.

This indicates the stability/robustness of the proposed

approach, and implies that transfer learning across the

datasets is effective and comparable to training from

scratch. It can subsequently be inferred that the fea-

ture extraction portion of the network is capable of ex-

tracting highly discriminative features from the parent

dataset, and that these features are common to activ-

ity data in general, regardless of the particular type of

activity or the device used in collecting the data. This

is also observed to hold true regardless of the size of

the parent dataset - the Gomaa-1, HAPT and REALD-

ISP datasets are comparatively small compared to the

Daily Sports and HAD-AW datasets. However, the

performance of our proposed method is maintained

even when these small datasets are used as the parent

datasets.

Additionally, it can be observed that the HAD-AW

and REALDISP datasets consistently have the high-

est transfer learning results. This can be attributed to

the fact that they consist of a large and diverse range

of activities, causing the convolutional ﬁlters to be

relatively more discriminative than when trained on

other datasets. The HAPT dataset, having the smallest

number of activities, accordingly shows the poorest

transfer learning results in all scenarios. This makes

a case for the use of class-diverse datasets as source

datasets for transfer learning. We examine this notion

further in section 7.

It can also be observed that the spatial pyramid

pooling size has an almost negligible impact on the

performance of the method. In particular, it has a very

slight effect on the self-testing results. However, the

performance obtained in the transfer learning scenar-

ios shows noticeable degradation when the smallest

pooling size (2-1, yielding 2+1 features per feature

map) is used. This can be expected since the dimen-

sionality of the feature vector is the smallest com-

pared to the other sizes. The virtually identical per-

formance of the 8-4-2-1 (yielding 8+4+2+1=15 fea-

tures per feature map) and 4-2-1 (yielding 4+2+1=7

features per feature map) pooling levels suggests that

activity recognition signals display medium to long-

term trends. That is, the additional local summariza-

tion offered by the 8-4-2-1 pooling level compared

to the 4-2-1 pooling level does not offer information

that is (very) beneﬁcial to the discrimination of activ-

ities. This makes a case for the use of the 4-2-1 pool-

ing level as a suitable pooling setting in the proposed

scheme.

The average time required for self-testing and

transfer learning scenarios (when using 4-2-1 Pool-

ing) is shown in Table 5. We do not evaluate the

timings for all the tested pooling parameters because

we consider the resulting differences to be negligible.

As can be observed, the self-training scenarios take

relatively long times, due to the multitude of oper-

ations inherent in training the convolutional layers.

The Daily Sports dataset also shows a lower train-

ing time in the self-training scenarios than the HAD-

AW and REALDISP datasets (which are smaller).

This can be attributed to the fact even though the

Daily Sports dataset has more samples, the samples

in the HAD-AW and REALDISP datasets are likely

much longer (i.e have more timesteps) than the sam-

ples in the Daily Sports dataset. As a result, the

striding of the convolutional ﬁlters for such samples

takes signiﬁcantly longer than for the samples in the

Daily Sports dataset. The transfer learning scenarios

take signiﬁcantly smaller amounts of time, yielding

a 24.17x speedup compared to the self-testing sce-

nario in the worst case (i.e on the Daily Sports dataset)

and a 52.31x speedup in the best case (i.e on the

REALDISP dataset). It can also be observed that the

timings for the transfer-learning scenarios are fairly

steady, regardless of the dataset which was used to

(pre)train the model. This implies that the transfer

learning times are purely dependent on the size of the

ﬁne-tuning/testing dataset. With the use of GPUs, the

transfer learning times may possibly be reduced even

further due to the speed beneﬁts obtainable from the

use of such devices.

7 ADDITIONAL

CONSIDERATIONS

In this section we brieﬂy describe relevant addi-

tional experiments carried out and the results obtained

thereof.

VersaTL: Versatile Transfer Learning for IMU-based Activity Recognition using Convolutional Neural Networks

513

Table 6: Classiﬁcation Accuracy - Feature Extraction Portion + 1 Fully-Connected Layer and 4-2-1 Pooling.

Training Dataset Testing Dataset

Gomaa-1 HAPT D Sports HAD-AW REALDISP

Gomaa-1 96.37 ± 1.08 93.00 ± 1.34 90.09 ± 0.77 81.31 ± 0.93 67.75 ± 2.04

HAPT 92.75 ± 1.73 96.31 ± 1.03 88.60 ± 0.80 78.45 ± 1.01 59.21 ± 3.38

D Sports 91.87 ± 1.54 92.85 ± 1.24 95.04 ± 0.54 78.87 ± 1.43 62.03 ± 1.91

HAD-AW 95.05 ± 1.25 94.60 ± 0.86 91.72 ± 0.55 88.34 ± 0.49 69.65 ± 1.58

REALDISP 93.90 ± 2.23 93.50 ± 1.41 90.91 ± 0.55 81.63 ± 1.17 76.01 ± 2.86

Table 7: Classiﬁcation Accuracy - Feature Extraction Portion + 2 Fully-Connected Layers and 4-2-1 Pooling.

Training Dataset Testing Dataset

Gomaa-1 HAPT D Sports HAD-AW REALDISP

Gomaa-1 96.15 ± 1.24 88.72 ± 2.15 78.61 ± 1.14 60.50 ± 1.46 48.01 ± 2.49

HAPT 64.94 ± 4.57 96.18 ± 1.11 72.58 ± 1.35 47.12 ± 2.45 36.99 ± 3.98

D Sports 57.26 ± 4.47 75.85 ± 2.53 95.08 ± 0.47 53.09 ± 2.28 38.99 ± 3.08

HAD-AW 85.96 ± 1.81 87.74 ± 2.08 85.00 ± 1.10 88.31 ± 0.75 54.80 ± 3.37

REALDISP 72.62 ± 4.78 82.17 ± 3.54 80.69 ± 1.40 60.61 ± 1.61 75.00 ± 2.27

Table 8: Comparative Results between (Chikhaoui et al., 2018) and our proposed technique.

Experiment Baseline F-Metric Obtained F-Metric

MobiAct → RealWorld (Chest) 0.496 0.903

MobiAct → RealWorld (Head) 0.796 0.832

MobiAct → RealWorld (Forearm) 0.796 0.809

RealWorld (Chest) → MobiAct 0.568 0.747

RealWorld (Head) → MobiAct 0.658 0.751

RealWorld (Forearm) → MobiAct 0.658 0.740

7.1 Effect of Layers and Dataset

Diversity on Transfer Learning

Performance

In order to justify the use of only the convolutional ﬁl-

ters as the feature extraction portion, we carry out two

additional experiments. In the ﬁrst of these, we in-

clude one of the fully-connected layers in the feature

extraction portion, then train only the two remaining

fully-connected layers. In the second, we include two

of the fully-connected layers in the feature extraction

portion, then train only the last fully-connected layer

i.e the classiﬁer layer. In both experiments, we ﬁx

the pooling sizes at 4-2-1. We aimed to determine the

effect of including the fully-connected layers in the

feature extraction portion i.e considering higher-level

features instead of lower-level ones. Additionally, we

also aimed to provide some insight into the behavior

of the discriminative powers of the convolutional ﬁl-

ters when trained on different datasets.

The results obtained from the ﬁrst and second ex-

periments are shown in Tables 6 and 7 respectively.

As expected, a degradation in performance is ob-

served in both schemes, with the higher degradation

being shown in the second experiment i.e training

only the last layer. This can be explained by the fact

that the features existing at successively-deeper layers

are higher-level (i.e more dataset-speciﬁc) and there-

fore transfer poorly to other datasets. This makes a

case for the use of only the convolutional ﬁlters for

transfer learning as they learn lower-level (i.e more

generic) features.

It is also pertinent to note that in both experiments,

the transfer learning performance when trained on the

HAD-AW and REALDISP datasets remains the best

relative to the other datasets. This is more apparent

in Table 6, where both datasets clearly show superior

performance to the others in the scenarios considered.

As described earlier, these datasets contain a large and

heterogenous number of activities, which causes the

features (i.e both low and high-level) learnt at suc-

cessive layers to be signiﬁcantly more discriminatory

than features learnt from other, less-diverse datasets.

Although the Daily Sports dataset contains 19 ac-

tivities and 9000+ samples, it is generally outper-

formed by the much-smaller (14 activities, 603 sam-

ples) Gomaa-1 dataset. This occurs because the

Gomaa-1 dataset, in spite of its smaller size and ac-

ICINCO 2019 - 16th International Conference on Informatics in Control, Automation and Robotics

514

tivity count, contains a wider variety of activities,

while the Daily Sports dataset has much less vari-

ety in its constituent activities. As a result, it can

also be observed from the tables that the Gomaa-1

dataset comes after the HAD-AW and REALDISP

datasets in transfer learning performance. The HAPT

dataset contains the fewest activities with a low va-

riety/heterogeneity. As such, it shows the highest

degradation in the resulting transfer learning perfor-

mance of all the considered datasets, as can be ob-

served from Tables 6 and 7. This is in consonance

with the behavior observed and discussed in Section

6 previously.

We believe that the results obtained from these ex-

periments further highlight the beneﬁt of training such

transfer learning models on activity-diverse datasets.

7.2 Comparison to Similar Transfer

Learning Schemes

In order to clearly illustrate the beneﬁt of VersaTL,

we also compare it to (Chikhaoui et al., 2018), which

is the most similar method to it. Due to constraints

on space and challenges with one of the considered

datasets, we consider six evaluations from their work

which are concerned with transfer-learning perfor-

mance between devices placed at three different lo-

cations on the body. We segment the two datasets

concerned (MobiAct (Chatzaki et al., 2016) and Re-

alWorld HAR (Sztyler and Stuckenschmidt, 2016)) as

described in (Chikhaoui et al., 2018) and derive the

average F-metric obtained from the scenarios they in-

vestigated. The results of these experiments are re-

ported on a normalized scale and shown in Table 8.

The baseline results (i.e from (Chikhaoui et al.,

2018)) are shown in the ”Baseline F-Metric” col-

umn. It can be seen that the results obtained from

our method (displayed in the ”Obtained F-Metric”

column) shows an improvement of up to 40% in the

F-metric. This illustrates the superiority of VersaTL

relative to the scheme proposed in (Chikhaoui et al.,

2018).

8 CONCLUSION

In this work we propose VersaTL, a transfer learning

scheme for activity recognition data using convolu-

tional neural networks (CNNs). We design a small

CNN and include a spatial pyramid pooling layer to

allow for inputs of any type (i.e ﬁxed or varying-

length). We then train the network (initially for clas-

siﬁcation) using standard methods. Subsequently, we

use the convolutional ﬁlters and the pooling layer as a

feature extractor. The feature extractor is then reused

for other datasets (different than the one used to train

the network initially) and dataset-speciﬁc feedfor-

ward neural networks are then trained to classify the

generated feature vectors.

The results obtained from our evaluations indicate

that VersaTL yields comparable performance (within

5%) to CNN-based classiﬁers trained from scratch,

while requiring a fraction of the training time. This

highlights the utility of our transfer learning tech-

nique in this domain. We believe that this could pave

the way for the widespread use of pretrained models

in activity recognition, similar to the way pretrained

models are used in computer vision, e.g., AlexNet,

VGGNet, etc.

In the future we intend to investigate the general-

izability of VersaTL to other types of timeseries data

which share the same number of axes/channels. The

restriction on the number of axes/channels is required

due to the convolutional ﬁlter-based frontend of our

method. Going further we may also investigate spe-

ciﬁc training of the feature extraction portion of the

network with a view to optimizing the learnt features

for discriminability.

REFERENCES

Altun, K., Barshan, B., and Tunc¸el, O. (2010). Comparative

study on classifying human activities with miniature

inertial and magnetic sensors. Pattern Recognition,

43(10):3605–3620.

Bai, S., Kolter, J. Z., and Koltun, V. (2018). An em-

pirical evaluation of generic convolutional and recur-

rent networks for sequence modeling. arXiv preprint

arXiv:1803.01271.

nos, O., Damas, M., Pomares, H., Rojas, I., T

oth, M. A.,

and Amft, O. (2012). A benchmark dataset to eval-

uate sensor displacement in activity recognition. In

Proceedings of the 2012 ACM Conference on Ubiqui-

tous Computing, pages 1026–1035. ACM.

Banos, O., Toth, M. A., Damas, M., Pomares, H., and Ro-

jas, I. (2014). Dealing with the effects of sensor dis-

placement in wearable activity recognition. Sensors,

14(6):9995–10023.

Bengio, Y. (2012). Deep learning of representations for

unsupervised and transfer learning. In Proceedings

of ICML Workshop on Unsupervised and Transfer

Learning, pages 17–36.

Chatzaki, C., Pediaditis, M., Vavoulas, G., and Tsiknakis,

M. (2016). Human daily activity and fall recognition

using a smartphone’s acceleration sensor. In Inter-

national Conference on Information and Communica-

tion Technologies for Ageing Well and e-Health, pages

100–118. Springer.

Chikhaoui, B., Gouineau, F., and Sotir, M. (2018). A

cnn based transfer learning model for automatic ac-

tivity recognition from accelerometer sensors. In

VersaTL: Versatile Transfer Learning for IMU-based Activity Recognition using Convolutional Neural Networks

515

International Conference on Machine Learning and

Data Mining in Pattern Recognition, pages 302–315.

Springer.

Gomaa, W., Elbasiony, R., and Ashry, S. (2017). Adl clas-

siﬁcation based on autocorrelation function of iner-

tial signals. In Machine Learning and Applications

(ICMLA), 2017 16th IEEE International Conference

on, pages 833–837. IEEE.

Harley, A. W. (2015). An interactive node-link visualiza-

tion of convolutional neural networks. In Interna-

tional Symposium on Visual Computing, pages 867–

877. Springer.

He, K., Zhang, X., Ren, S., and Sun, J. (2014). Spatial pyra-

mid pooling in deep convolutional networks for visual

recognition. In European conference on computer vi-

sion, pages 346–361. Springer.

Hinton, G. E. and Salakhutdinov, R. R. (2006). Reducing

the dimensionality of data with neural networks. sci-

ence, 313(5786):504–507.

Hochreiter, S. and Schmidhuber, J. (1997). Long short-term

memory. Neural computation, 9(8):1735–1780.

Hu, D. H., Zheng, V. W., and Yang, Q. (2011). Cross-

domain activity recognition via transfer learning. Per-

vasive and Mobile Computing, 7(3):344–358.

Jordan, M. I. and Mitchell, T. M. (2015). Machine learn-

ing: Trends, perspectives, and prospects. Science,

349(6245):255–260.

Karpathy, A., Toderici, G., Shetty, S., Leung, T., Suk-

thankar, R., and Fei-Fei, L. (2014). Large-scale video

classiﬁcation with convolutional neural networks. In

Proceedings of the IEEE conference on Computer Vi-

sion and Pattern Recognition, pages 1725–1732.

Khan, M. A. A. H. and Roy, N. (2017). Transact: Trans-

fer learning enabled activity recognition. In 2017

IEEE International Conference on Pervasive Comput-

ing and Communications Workshops (PerCom Work-

shops), pages 545–550.

Khan, M. A. A. H. and Roy, N. (2018). Untran: Recogniz-

ing unseen activities with unlabeled data using trans-

fer learning. In 2018 IEEE/ACM Third International

Conference on Internet-of-Things Design and Imple-

mentation (IoTDI), pages 37–47.

Mohammed, S. A., Elbasiony, R., and Gomaa, W. (2018).

An lstm-based descriptor for human activities recog-

nition using IMU sensors. In Proceedings of the 15th

International Conference on Informatics in Control,

Automation and Robotics, ICINCO 2018 - Volume 1,

Porto, Portugal, July 29-31, 2018., pages 504–511.

Oquab, M., Bottou, L., Laptev, I., and Sivic, J. (2014).

Learning and transferring mid-level image represen-

tations using convolutional neural networks. In Pro-

ceedings of the IEEE conference on computer vision

and pattern recognition, pages 1717–1724.

Pan, S. J., Yang, Q., et al. (2010). A survey on transfer

learning. IEEE Transactions on knowledge and data

engineering, 22(10):1345–1359.

Reyes-Ortiz, J.-L., Oneto, L., Sam

a, A., Parra, X., and

Anguita, D. (2016). Transition-aware human activ-

ity recognition using smartphones. Neurocomputing,

171:754–767.

Salehinejad, H., Baarbe, J., Sankar, S., Barfett, J., Colak, E.,

and Valaee, S. (2018). Recent advances in recurrent

neural networks. CoRR, abs/1801.01078.

Sztyler, T. and Stuckenschmidt, H. (2016). On-body

localization of wearable devices: An investiga-

tion of position-aware activity recognition. In

2016 IEEE International Conference on Per-

vasive Computing and Communications (Per-

Com), pages 1–9. IEEE Computer Society.

http://ieeexplore.ieee.org/xpl/articleDetails.jsp?

arnumber=7456521.

Yin, W., Kann, K., Yu, M., and Sch

utze, H. (2017). Com-

parative study of cnn and rnn for natural language pro-

cessing. arXiv preprint arXiv:1702.01923.

Zaremba, W., Sutskever, I., and Vinyals, O. (2014). Re-

current neural network regularization. arXiv preprint

arXiv:1409.2329.

Zeiler, M. D. and Fergus, R. (2014). Visualizing and under-

standing convolutional networks. In European confer-

ence on computer vision, pages 818–833. Springer.

ICINCO 2019 - 16th International Conference on Informatics in Control, Automation and Robotics

516
