The Saga Pattern in a Reactive Microservices Environment

Martin

Stefanko

, Ond

rej Chaloupka

and Bruno Rossi

2 a

Red Hat, Brno, Czech Republic

Masaryk University, Faculty of Informatics, Brno, Czech Republic

Keywords:

Saga Pattern, Compensating Transactions, Reactive, Microservices, Distributed Systems.

Abstract:

Transaction processing is a critical aspect of modern software systems. Such criticality increased over the years

with the emergence of microservices, calling for appropriate management of transactions across separated

application domains, ensuring the whole system can recover and operate in a possible degraded state. The

Saga pattern emerged as a way to deﬁne compensating actions in the context of long-lived transactions. In this

work, we discuss the relation between traditional transaction processing models and the Saga pattern targeting

speciﬁcally the distributed environment of reactive microservices applications. In this context, we provide a

comparison of the current state of transaction support in four Java-based enterprise application frameworks

for microservices support: Axon, Eventuate Event Sourcing (ES), Eventuate Tram, and MicroProﬁle Long

Running Actions (LRA).

1 INTRODUCTION

Transaction processing is widely recognized as a crit-

ical aspect of modern applications (Little et al., 2004).

Particularly in a distributed environment, understand-

ing and reaching transaction consistency based on

the currently available technology stack represents a

complex task. The microservices architectural pat-

tern separates the application domain into a set of iso-

lated services that collaborate together to model dif-

ferent business concepts (Sharma, 2017). Due to their

distributed character, microservice systems are sub-

ject to issues associated with failure processing. To

ensure that the system is able to function even in a

degraded state, these applications are commonly de-

signed with certain quality properties which are de-

ﬁned as ”reactive systems properties” in the Reactive

Manifesto: responsiveness, resilience, elasticity and

asynchronous message passing (Bon

er et al., 2018).

These characteristics extend to the application of

transaction processing in a reactive environment. As

transactions usually include multiple services while

still providing ACID (Atomicity, Consistency, Iso-

lation, Durability) guarantees (Haerder and Reuter,

1983), all participants must reach a shared uniform

consensus on the transaction result. This consensus is

achieved through the utilization of consensus protocol

represented conventionally by the Two-phase Commit

https://orcid.org/0000-0002-8659-1520

protocol (2PC). However, due to their locking nature,

these protocols may present difﬁculties to achieve the

reactive systems properties (Stonebraker and Cattell,

2011). The Saga pattern (Garcia-Molina and Salem,

1987) represents an alternative approach to transac-

tion processing applicable particularly to long living

transactions – transactions that can span through sev-

eral days. In a long running transaction, consensus

protocols like 2PC may hold locks on resources for

long periods – not acceptable in a reactive environ-

ment as it makes individual services less responsive.

The goal of this work is to detail the relation be-

tween traditional transaction processing models and

the saga pattern in the distributed environment of re-

active microservices. To understand the current sup-

port, we compare four Java-based application frame-

works for microservices support (Axon, Eventuate

Event Sourcing, Eventuate Tram, and MicroProﬁle

Long Running Actions), in terms of implementation

complexity, support for the saga pattern, and perfor-

mance by using a common scenario.

2 THE SAGA PATTERN

A saga, as described in the original publication

(Garcia-Molina and Salem, 1987), is a sequence of

operations that can be interleaved with other opera-

tions. Each operation, which is a part of the saga, rep-

Štefanko, M., Chaloupka, O. and Rossi, B.

The Saga Pattern in a Reactive Microservices Environment.

DOI: 10.5220/0007918704830490

In Proceedings of the 14th International Conference on Software Technologies (ICSOFT 2019), pages 483-490

ISBN: 978-989-758-379-7

483

resents a unit of work that can be undone by the com-

pensation action. The saga guarantees that either all

operations complete successfully or the correspond-

ing compensation actions are run for all executed op-

erations to cancel the partial processing.

Operations. An operation represents a particular

work segment that is a part of the saga. Each saga can

be split into a sequence of operations in which each

one individually can be implemented as a transaction

with full ACID guarantees. When the operation com-

pletes, all results of the performed work are expected

to be persisted in the durable storage. This means that

the external observer may see the system in intermedi-

ate states of the saga execution, as well as that it may

also introduce the system into an inconsistent state be-

tween the individual operation invocations.

The ability to commit a partial operation breaks

the isolation (serializability) property as it makes the

segment changes available before the saga ends. In-

termediate saga states may also introduce consistency

contraventions. However, the saga utilizes the even-

tual consistency model which guarantees that the state

will become eventually consistent after the saga com-

pletes (both successfully or by compensations calls).

Compensations. Each operation in a saga needs to

have an associated compensation action. The purpose

of the compensating action is to semantically undo

the work performed by the original operation. This

is not necessarily the contradictory action that puts

the system into the same state as it was before the

operation began or generally the saga started.

BASE Transaction. In contrast to the traditional

transaction approach, the Saga pattern relaxes the

ACID requirements to achieve availability and scal-

ability with built-in failure management. As the saga

commits each operation separately, updates of the not

fully committed saga are immediately visible to other

parallel operations (Gray, 1981) which directly breaks

the isolation property.

Sagas utilize an alternative BASE model (Helland,

2007; Helland and Campbell, 2009) which values the

availability over the consistency provided by ACID –

the so-called CAP theorem (Gilbert and Lynch, 2012).

The speciﬁed system properties are:

• Basically Available – The system guarantees

availability with regards to the CAP theorem.

• Soft State – The state may change as time pro-

gresses even without any immediate modiﬁcation

request due to the eventual consistency.

• Eventual Consistency – The state of the system

is allowed to be in inconsistent states, but if the

system does not receive any new update requests,

then it guarantees that the state will eventually get

into the consistent state (Vogels, 2009).

In practice, many modern applications are not al-

ways entirely restricted to all of the ACID transaction

guarantees, so the saga pattern with the BASE model

is emerging as a real alternative to traditional transac-

tional approach.

Distributed Sagas. The notion of sagas can be natu-

rally extended into distributed environments (Garcia-

Molina and Salem, 1987). The saga pattern as an

architectural pattern focuses on integrity, reliability,

quality and it pertains to the communication patterns

between services (Sharma, 2017; Nadareishvili et al.,

2016). This allows the saga deﬁnition in distributed

systems to be redeﬁned as a sequence of requests

that are being placed on particular participants invo-

cations. These requests may provide ACID guaran-

tees, but this is not restricted and it must be ensured

by individual participants. Similarly, each participant

is also required to expose the idempotent compen-

sating request handler which can semantically undo

the request that is handled by this participant in the

saga. Analogously to the centralized system, the dis-

tributed saga management requires a transaction log

and a Saga Execution Component (SEC) which in

an optimal environment needs to be distributed and

durable.

As all components are now distributed, the saga

management system needs to deal with a number of

additional problems that are not present in the local-

ized environment with the main problem being net-

work and participant failures that may happen be-

tween remote invocations. However, generally ap-

proaches from the non-distributed environment still

apply.

3 SAGA IMPLEMENTATIONS

COMPARISON

In this section we compare four implementations of

the saga pattern that can be utilized in the enterprise

Java applications – Axon

, Eventuate Event Sourcing

(ES)

, Eventuate Tram

and MicroProﬁle Long Run-

ning Actions (LRA)

with its current implementation

based on the Narayana project

. Table 1 summarizes

the main differences of the frameworks. As of the

time of this writing, these four frameworks are the

only Java projects which support saga implementa-

tions to some extent.

https://axoniq.io

https://eventuate.io

https://eventuate.io/abouteventuatetram.html

https://github.com/eclipse/microproﬁle-lra

https://github.com/jbosstm/narayana/tree/master/rts/lra

ICSOFT 2019 - 14th International Conference on Software Technologies

484

Table 1: Saga implementations comparison.

Problem Axon Eventuate ES Eventuate

Tram

LRA

CQRS restriction Yes Yes Optional No

Asynchronous by

default

Yes Yes No No

Saga tracking and

deﬁnition

No No Yes No

Single point of failure No Yes Yes Yes

Communication restrictions Yes Yes Yes No

Distributed by default No Yes Yes Yes

As a part of the investigation of the each discussed

framework, we created a sample application simu-

lating the saga processing in the production environ-

ment. The main goal of this quickstart projects is to

compare the base attributes of the investigated saga

solution provided by these frameworks. This includes

the comparison of the development model, microser-

vices feasibility, maintainability, scalability, perfor-

mance and the applicability of the reactive principles

within the saga execution. All samples are microser-

vices applications that represent a backend processing

for orders with a simple REST user interface.

Common Scenario. A user is able to create an or-

der by a REST call to the dedicated endpoint of the

order-service microservice. This endpoint expects

a product information in the JavaScript object no-

tation (JSON) format containing the product id, the

commentary, and the price. For simplicity reasons, an

order always consists only of a single product.

Generally, each microservice is a standalone Java

application that must run in a separated Java environ-

ment. By default, all examples are accessible on the

local address. Every microservice is also able to run

in the Docker platform and all quickstarts can be eas-

ily set up using the Docker Compose project. Details

can be found in repositories of individual projects.

Every order request (saga invocation) is asyn-

chronous - the REST call to the order endpoint imme-

diately returns a response. All of the following inter-

actions are documented by messages that are logged

by the individual microservices. The overall saga pro-

cess can be examined in the order-service or in the

case of LRA in the api-gateway modules.

The persisted saga data (orders, shipments, and

invoices) can be queried by the respective REST

endpoints in individual services. For the CQRS

based examples, this information is available at the

query-service microservice, otherwise each mi-

croservice is expected to be responsible for maintain-

Figure 1: The saga model.

ing its individual persistence solution which corre-

sponds to the microservices pattern deﬁnition.

Order Saga. The saga pattern applied in this appli-

cation performs the order requests (Fig. 1). The or-

der saga consists of three parts – the production of

shipping and invoice information and if both invoca-

tions are successful, the actual order creation. If any

part of the processing fails, the whole progress is ex-

pected to be undone. For instance, if the shipment is

successfully created but the invoice assembly is not

able to be conﬁrmed, the persisted shipment infor-

mation, as well as the order, must be canceled (also

optionally notifying the user that the order cannot be

created). To initiate failures scenarios in examples

both shipment-service and invoice-service ex-

pect product information containing a speciﬁc prod-

uct identiﬁcation: failShipment or failInvoice

respectively.

The Saga Pattern in a Reactive Microservices Environment

485

3.1 Axon Service

Axon is a lightweight Java framework that helps de-

velopers build scalable and extensible applications by

addressing these concerns directly in the core archi-

tecture. It builds upon the Command Query Respon-

sibility Segregation (CQRS) pattern (Fowler, 2018).

The individual services contain separated aggregates

each processing its respective commands and produc-

ing events. Any inter-service interaction is restricted

to the use of the command and event buses.

Platform. Axon service is a Java Spring Boot mi-

croservices application. Individual projects repre-

sent standalone runnable applications (fat java archive

(jar)) which is the preferred distribution method for

the Spring Boot applications.

As a CQRS based quickstart, Axon service uses

two different and separated communication channels

to exchange information between services: the com-

mand bus and the event bus. By default, Axon frame-

work constraints both channels to a single JVM and

therefore one microservice. However, developers are

also able to specify several speciﬁc ways of the con-

ﬁguration to distribute messages between different

services which is used in this Axon quickstart.

3.1.1 Problems

Maintenance of the Saga Structure. The main sub-

stantial problem of the saga processing in Axon is the

missing structure of the internal lifecycle of the saga.

The only operations provided by the platform are the

start and the stop of the saga. The actual invocation

of participants, collecting of responses and handling

of the compensations is up to the developer as the

only way of communication with the saga is through

events.

In this application, the OrderManagementSaga

contains two internal classes – OrderProcessing

and OrderCompensationProcessing which are re-

sponsible for tracking of the saga execution and com-

pensation respectively. This kind of the saga deﬁni-

tion can be harder to maintain and more error prone

as sagas as expected to be generally more complex

processes.

AMQP Usage with Sagas. When the distributed

event bus is processing events from an AMQP queue

which the saga class is listening to, the framework

does not deliver events correctly to the attached han-

dlers. This issue has been reported to the Axon frame-

work and it will be ﬁxed in the next release. The

workaround that was used in the quickstart was to ar-

tiﬁcially wait 1000 milliseconds before delivering the

event from the queue to the framework.

CQRS Restrictions. As CQRS is a pattern that man-

ages the domain formation of the application, Axon

can place hard requirements for the projects that do

not follow the CQRS domain separation. Sagas in

Axon are only a specialized type of the event listener.

The only way Axon produces events is through an in-

teraction with the aggregate instance - events are pro-

duced purely as a response to the received command.

Therefore, the use of Axon sagas in the non-CQRS

environment may be too restrictive to the user imple-

mentation.

3.2 Eventuate Service

Eventuate is a platform for developing asynchronous

microservices with the main focus placed on the dis-

tributed data management. The platform consists of

two products – Eventuate Event Sourcing (ES) and

Eventuate Tram. Similarly to Axon, Eventuate ser-

vice is also based on the event sourcing and the CQRS

pattern. The business execution is managed in the ag-

gregates which correspond to the respective microser-

vices projects. The communication is as a result re-

stricted to the command processing and the event ap-

plication. However, conversely to Axon, the com-

mand and event buses are not distributed. The re-

mote messaging is restricted to the REST protocol.

This quickstart represents the pure CQRS approach to

the saga processing. This means that the whole saga

implementation is created by the developer using the

platform only for the event and command distribution.

For this reason, the Eventuate service is more com-

plex than any other quickstart but for the example pur-

poses, it distinctively demonstrates how sophisticated

is the saga administration provided by all remaining

platforms.

Platform. Eventuate service is a microservices ap-

plication consisting of a set of Spring Boot business

services, one backing module and a number of sup-

port services provided by the Eventuate platform.

This quickstart is established as an Eventuate Lo-

cal version of the platform. This means that it uses

underlying SQL database for the event persistence

and the Kafka streaming platform for the event dis-

tribution. Eventuate Local provides ﬁve services used

by the quickstart that are managed by the platform,

namely, Apache Zookeeper, Apache Kafka, MySQL

database, the change data capture component (CDC)

and the Eventuate console service. The example em-

ploys these services as Docker images included in the

provided docker-compose conﬁguration.

ICSOFT 2019 - 14th International Conference on Software Technologies

486

3.2.1 Problems

Complexity. As this project represents a plain CQRS

based example, it demonstrates the background pro-

cess required for the saga execution. Therefore, the

complexity of this quickstart may appear more criti-

cal than in other projects as the background saga ex-

ecution often contains many optimizations. The main

complexity problem is that the project contains a high

number of command and event classes. This is re-

quired as aggregate classes are only able to consume

commands and produce events. For this reason, the

communication between components often demands

additional steps.

Command Bus Distribution Restrictions. This

quickstart uses the REST architectural style for the

remote distribution of commands between services.

Even if all of the microservices are connected to the

same MySQL database, they cannot directly propa-

gate commands between each other. This is due to

the way Eventuate dispatches commands through the

aggregate repository. The aggregate repository rep-

resents the database table that is restricted to one ag-

gregate and it is provided by the platform through the

dependency injection. For this reason, it must declare

the target aggregate class and the command type. The

sharing of the aggregate class type may be very re-

strictive, especially for microservices applications.

Aggregate Instantiation. The Eventuate framework

creates the instances of aggregate classes by a call

to the default constructor. This effectively prohibits

the use of aggregate instance managed by the under-

lying server container. For this reason, each aggre-

gate in this project is separated into two classes – the

actual aggregate responsible for the command pro-

cessing and the event subscriber instance managing

incoming events. This restriction is seconded by the

rule stating that each produced event from the aggre-

gate’s command processing method must also be ap-

plied by the different method of the same aggregate.

This limitation exists because of the event sourcing

feature providing the ability to replay already exe-

cuted commands to reconstruct the aggregate’s state

in the case of failure. The aggregate then may contain

unnecessary empty methods as the saga also requires

the propagation of the information to different com-

ponents (e.g., the REST controller).

Event Entity Speciﬁcation. As well as the com-

mand type, Eventuate also requires the deﬁnition of

the event type each aggregate is able to apply. The

problem rises when the events need to be shared be-

tween several modules. This is a common require-

ment as the CQRS pattern requires the query domain

to be separated. The event interfaces are therefore

included in the shared library module same as the

service-model used in this project. The hard coded

information of the full name of the aggregate class

used in the @EventEntity annotation then may be-

come hard to maintain.

Platform Structure. The platform structure places

the obligation on each developed microservice to con-

duct with the connecting requirements. This means

that every service must provide linking information

for the Eventuate platform services described in the

previous section, namely, MySQL database, Apache

Kafka, Apache Zookeeper and CDC component. This

information is replicated in all individual services and

therefore predisposed to errors.

3.3 Eventuate Tram Service

The Eventuate Tram service quickstart is based on

the recently introduced Eventuate Tram framework.

The Eventuate Tram framework extends the platform

with asynchronous messages that can be sent as a part

of a database transaction. It utilizes the traditional

Java Database Connectivity (JDBC) and Java Persis-

tence API (JPA) to provide the transactional messag-

ing. This enables the microservice to atomically up-

date its state and to publish this information as a mes-

sage or as an event to other services.

Platform. Similarly to the Eventuate ES distribu-

tion, the Eventuate Tram establishes four services that

form the Tram platform: Apache Zookeeper, Apache

Kafka, MySQL database and CDC component. The

ﬁfth service, Console server, is not included as the

platform does not present this functionality by the

time of this writing. All services are deployed by the

docker-compose conﬁguration distributed with the

framework.

The most important element in this application is

the saga deﬁnition that is located in the OrderSaga

class of the order-service. This deﬁnition uses the

declarative approach with the ﬂuent API to denote

the saga in steps of execution. Every step declares a

handler method representing a participant request that

will be invoked when this step is reached by a refer-

ence to the private method in this class as well as the

reference to its compensation handler.

3.3.1 Problems

Destination Identiﬁcation. The destination channels

in Tram are characterized by a simple string which

may cause problems in the case of name conﬂicts.

The choice of the handler to be invoked when mes-

sage is received depends on two values – the name

of the channel and the command dispatcher id. When

The Saga Pattern in a Reactive Microservices Environment

487

both strings match the same destination even in dif-

ferent services, the platform delivers the commands

between handlers in the random fashion which may

become a complex issue in larger projects.

Command Handlers. Handler methods that are ref-

erenced in the deﬁnition are restricted to the commu-

nication model provided by the platform. This allows

a single command to be sent to the required desti-

nation. Unfortunately, the platform does not allow

the saga to perform any other operation without the

participant invocation which may lead to unnecessary

empty commands and channels declarations.

Similarly, the saga may need to send multiple dif-

ferent commands to the same participant. This may

cause problems with deﬁnitions of compensation and

reply handlers as the developer needs to mind the log-

ical grouping of participant invocations.

3.4 LRA Service

MicroProﬁle Long Running Actions (LRA) is a spec-

iﬁcation developed in collaboration with the Eclipse

MicroProﬁle initiative (

Stefanko, 2017). There are

several companies currently participating and con-

tributing to it (e.g., Red Hat or Payara). It proposes

a new API for the coordination of long running ac-

tivities with the assurance of the globally consistent

outcome and without any locking mechanisms. The

LRA speciﬁcation is based on the Context and Depen-

dency Injection (CDI) and Java API for RESTful Web

services (JAX-RS) Java EE speciﬁcations. The com-

munication is handled over HyperText Transfer Pro-

tocol (HTTP) and the Representational State Transfer

(REST) architectural style.

Platform. This quickstart is composed as a set of

WildFly Swarm microservices. Every service is de-

signed to be deployed to the OpenShift container ap-

plication platform provided by Red Hat, Inc.

Narayana’s implementation (http://narayana.io) of

the Long Running Actions speciﬁcation is not com-

posed as a platform, but rather as a standalone co-

ordination service. This project employs the stan-

dalone Narayana LRA coordinator which is con-

structed as a WildFly Swarm microservice called

lra-coordinator. All other traditional microser-

vices requirements are handled by the OpenShift

platform. This covers service discovery and loca-

tion transparency, monitoring, logging, resiliency and

health checks (failure discovery) which is why this

conﬁguration is not included in example services.

3.4.1 Problems

REST Restriction. The Narayana Long running ac-

tions are a very efﬁcient development model for the

microservices applications. Although it mainly aims

for the compatibility with the MicroProﬁle speciﬁca-

tion (REST and CDI), it does not restrict microser-

vices to essentially any other particular implementa-

tion restrictions. Even if the MicroProﬁle is restricted

to REST invocations, Narayana LRA speciﬁcation

does not require the usage this architectural style for

the communication with the coordinator. However,

the only implementation that is currently available is

based on REST, but it certainly can be extended to

other communication protocols in the future.

LRA Execution. The current implementation is that

the LRA framework provides only coordination and

management capabilities, it does not handle the saga

structuring and execution. Extraction of these capa-

bilities directly to the LRA processing would be cer-

tainly applicable in many common speciﬁcally reac-

tive applications use cases which can ease the devel-

opment and orchestration of the saga execution.

Single Point of Failure. By the time of this writing,

the LRA coordinator represents a single point of fail-

ure for the LRA processing in Narayana because it

contains the object store that is used for storing the

LRA information. User services also need to be ad-

justed for the situations when the coordinator is not

available.

3.5 Performance Test

To compare examples for their applicability in real

systems from the performance perspective, a simple

performance test has been created to investigate how

they behave under large load. Tables 2 and 3 present

a summary of the performance test executions. The

processing delay deﬁnes the time between the last

sent request and the last processed order and the to-

tal time denotes time from the ﬁrst request to the last

completed order. The format for both times is mm:ss.

Results presented in Table 3 represent the best result

of three performed test executions in scenario 2. The

test has been run in the cloud computing platform

Digital Ocean (www.digitalocean.com). The virtual

machine speciﬁcation:

Fedora 27 x64, Kernel: 4.13.9-300.fc27.x86_64

6 vCPUs (Intel(R) Xeon(R), E5-2650 v4 2.20GHz)

RAM: 16 GB, SSD: 320 GB, OpenJDK 1.8.0_144,

Maven 3.5.0, Gradle 2.13

The performance test is using the PerfCake (http://

perfcake.org) testing framework to generate requested

number of order requests. As all investigated frame-

works perform the saga execution asynchronously,

the test ﬁrst requests the number of orders and then

performs the get orders call to the respective service

ICSOFT 2019 - 14th International Conference on Software Technologies

488

Table 2: Performance test, time in mm:ss – scenario 1 (1 000 requests, 10 threads).

Project Processing delay Total time Completed requests

Axon service 00:46 00:51 1 000

Eventuate service 00:49 00:58 2 000

Eventuate Tram service 00:27 00:34 1 000

LRA service 00:04 01:10 1 000

Table 3: Performance test, time in mm:ss – scenario 2 (10 000 requests, 100 threads).

Project Processing delay Total time Completed requests

Axon service 06:53 07:44 5 657

Eventuate service 14:05 14:46 19 791

Eventuate Tram service 03:20 03:56 10 000

LRA service 00:22 08:58 10 000

in periodic intervals. The test ends when all orders are

processed or the deﬁned timeout is reached (Fig. 2).

Every example has been tested in two modes –

1000 order requests with 10 threads (scenario 1) and

10 000 order requests with 100 threads (scenario 2).

The reason was that some of the frameworks are not

able to handle the second test because of various prob-

lems discussed in the following sections. Scenario 2

has been run three times for each individual example,

and the presented results are taken from the best exe-

cution. Each test execution has been run in the same

setup on a new virtual machine.

Figure 2: Saga performance test execution.

Axon Service. The major performance problem

of this example was the artiﬁcial one second delay

placed on the shipment and invoice response retrieval

in the order-service. This problem has been re-

ported to the Axon framework and this quickstart has

been provided with a ﬁxed conﬁguration that removed

the need for the timeout. This setting will be included

by default in the Axon next release.

Another problem were synchronous REST calls

for inter-service command dispatching over dis-

tributed command bus. This issue has been reported

and was still investigated by the time of this writing.

The performance test in the scenario 1 has been

executed successfully in 51 seconds. The scenario 2

met the limits of the platform when the database lock

for the ﬁrst command could not be taken after about

5000 requests. This scenario was run three times with

the best result of 5657 completed orders in 7 minutes

and 44 seconds.

Eventuate Service. This performance test discov-

ered a new issue in the Eventuate Local platform –

when order requests are created in fast succession, the

database update may fail which results in redelivery

of the same events and therefore several orders for

one request. This problem has been reported to the

Eventuate project.

In the scenario 1, the 1000 requests have been cre-

ated in 58 seconds, but because of the mentioned issue

the ﬁnal count reached 2 000 orders. Scenario 2 was

executed three times where each run produced differ-

ent amount of completed orders. The presented test

execution ﬁnished after 14 minutes and 46 seconds

with 19 791 completed orders.

Eventuate Tram Service. The Eventuate Tram

project performed well in the scenario 1 which has

been ﬁnished in 34 seconds with all completed or-

ders. However, scenario 2 in some cases produced

an exception in the Kafka service that timed out on

the session.timeout.ms – a timeout that is used to

detect consumer failures. The default value for this

property is hardcoded in the Eventuate code base and

cannot be customized. This issue has been reported to

The Saga Pattern in a Reactive Microservices Environment

489

the platform as the feature request. The representing

successful run has been completed in 3 min. 56 sec.

LRA Service. This quickstart was for the perfor-

mance test adjusted to be run directly in the Docker

platform to simulate a similar environment for all ex-

amples. The test presented that the LRA coordinator

orchestration does not inﬂuence the processing per-

formance. The scenario 1 has been ﬁnished with ex-

ceptional overhead only 4 seconds and total time 1

minute and 10 seconds while the scenario 2 ﬁnished in

8 minutes and 58 seconds with just 22 seconds spent

on the additional saga processing. Both scenarios suc-

cessfully completed all order requests.

Summary. In general, both Eventuate Tram and LRA

performed in this test better than Axon or Eventu-

ate ES because the main focus of these frameworks

is placed on saga development. However, Axon and

Eventuate ES still present a simpliﬁed integration of

the saga pattern in CQRS based applications.

4 CONCLUSIONS

This paper covered transactions concepts that can be

utilized for the transaction commit problem in modern

software architectures. It covered conventional trans-

actional approaches utilizing two-phase commit pro-

tocol and application to the distributed environment of

microservices. The saga pattern (Garcia-Molina and

Salem, 1987) has been introduced as an alternative

approach to traditional transaction processing.

Development support of the saga pattern for pro-

duction environments was explored through the in-

vestigation of saga processing in four Java frame-

works – Axon, Eventuate ES, Eventuate Tram and

Narayana LRA. All of the frameworks were examined

in terms of the implementation of an order process-

ing microservices application utilizing the saga exe-

cution. Both Axon and Eventuate ES provide sim-

pliﬁed deﬁnitions of the saga pattern, however, at the

expense of the manual saga execution tracking and

the mandatory CQRS pattern application. Conversely,

Eventuate Tram and LRA are frameworks speciﬁcally

designed for saga executions. Both frameworks pro-

vide easy integrations and transparent executions of

sagas in enterprise Java applications. These quickstart

applications were also compared from a performance

perspective through a created test that examined saga

processing under large applied load. These perfor-

mance experiments resulted into several suggestions

of possible improvement points in the saga process-

ing of individual frameworks. In conclusion, the saga

pattern (Garcia-Molina and Salem, 1987) provides a

sophisticated alternative to conventional transaction

processing by means of its non-blocking nature – use-

ful in modern microservices applications.

ACKNOWLEDGEMENTS

The research was supported from ERDF/ESF ”Cy-

berSecurity, CyberCrime and Critical Informa-

tion Infrastructures Center of Excellence” (No.

CZ.02.1.01/0.0/0.0/16 019/0000822).

REFERENCES

Bon

er, J., Farley, D., Kuhn, R., and Thompson, M. (2018).

Reactive manifesto. https://www.reactivemanifesto.

org.

Fowler, M. (2018). Cqrs. https://martinfowler.com/bliki/

CQRS.html.

Garcia-Molina, H. and Salem, K. (1987). Sagas. ACM SIG-

MOD Record, 16(3):249–259.

Gilbert, S. and Lynch, N. (2012). Perspectives on the CAP

theorem. Computer, 45(2):30–36.

Gray, J. (1981). The transaction concept: Virtues and lim-

itations. In Proceedings of the Seventh Int. Confer-

ence on Very Large Data Bases - Volume 7, VLDB

’81, pages 144–154. VLDB Endowment.

Haerder, T. and Reuter, A. (1983). Principles of transaction-

oriented database recovery. ACM Computing Surveys,

15(4):287–317.

Helland, P. (2007). Life beyond distributed transactions: an

apostate’s opinion. In CIDR, pages 132–141.

Helland, P. and Campbell, D. (2009). Building on quick-

sand. CoRR, abs/0909.1788.

Little, M., Maron, J., and Pavlik, G. (2004). Java transac-

tion processing. Prentice Hall.

Nadareishvili, I., Mitra, R., McLarty, M., and Amundsen,

M. (2016). Microservice architecture: aligning prin-

ciples, practices, and culture. ” O’Reilly Media, Inc.”.

Sharma, U. R. (2017). Practical Microservices. Packt Pub-

lishing Ltd., 1 edition.

Stonebraker, M. and Cattell, R. (2011). 10 rules for scalable

performance in ’simple operation’ datastores. Com-

mun. ACM, 54(6):72–80.

Stefanko, M. (2017). Saga implementations com-

parison. http://jbossts.blogspot.cz/2017/12/saga-

implementations-comparison.html.

Vogels, W. (2009). Eventually consistent. Communications

of the ACM, 52(1):40.

ICSOFT 2019 - 14th International Conference on Software Technologies

490
