Semantic-based Obligation for Context-Based Access Control

Mouiad AL-Wahah, Ahmed Saaudi and Csilla Farkas

College of Engineering and Computing, University of South Carolina, 301 Main St, Columbia, SC, U.S.A.

Keywords: Description Logic, Access Control, OWL, Authorization, Obligation, Policy Rules.

Abstract:

In this paper, we present a dynamic and extensible semantic-based obligation framework. Our framework is

meant to be used in conjunction with context-based authorization. Our approach is suitable to incorporate dy-

namically changing obligation requirements. We express obligation requirements and contextual information

as ontologies. We employ Description logic and Logic Programming technologies for modeling contexts, priv-

ileges and obligations. We show how semantic-based techniques can be used to support adaptive and dynamic

obligation for Context-Based Access Control (CBAC) policies. We also show that our framework is expressive

enough to incorporate obligation’s needs in dynamic environments. Furthermore, we have developed a proof

of concept implementation to demonstrate our work.

1 INTRODUCTION

Context-Based Access Control (CBAC) is suitable

for dynamic environments (AL-Wahah and Farkas,

2018b). In such environments, the authorization

policy should adapt to its ever-changing environ-

ment.Integrating obligations into CBAC control pol-

icy allows a system to react quickly to new circum-

stances and change obligation requirements easily

when needed (Elrakaiby et al., 2012). However, only

a few of the current authorization models (Fornara,

2011; P

erez et al., 2009; Robinson and Purao, 2009;

Rubab et al., 2014) provide an obligation for context-

based access control policies. Moreover, they provide

only limited support for the following requirements:

• Adaptability: Context-Based Access Control

(CBAC) should be adaptable to the ever-changing

conditions of dynamic environments.

• Extensibility: Executing obligations by users or

systems highly depends on application and policy

requirements. The design must be extensible to

support new types of obligations.

• Modularity: Obligation framework shows support

ﬂexible activation and deactivation of obligations.

Our framework provides a dynamic and adaptive

semantic-based obligation support for CBAC policies.

Dynamic adaptability is provided through policy ad-

justment operations that keep the policy rules updated

with the latest context changes. Obligation are mod-

iﬁed: 1) When the context of the requester, resource,

or environment changes in a way, that change should

be reﬂected in the access control policy; 2) When an

obligation evolves over time. Our approach can be

adopted by existing CBAC systems to provide obli-

gation services. Our semantic-based obligation sup-

ports capabilities such as checking the access control

and obligation policies for conﬂict and consistency,

explaining inferences and helping to instantiate and

validate the variables in dynamic environments.

The rest of this paper is organized as follows: In

section 2, we present the context-based access control

system modeling. Section 3 presents our semantic-

based context obligation. Section 4 shows how to

check obligation states, and Section 5 contains our

implementation results. Related works are surveyed

in Section 6, and we conclude with suggestions for

future work in Section 7.

2 CBAC SYSTEM MODELING

“Context” has been deﬁned by Dey et al. (Dey et al.,

2001) as “any information that is useful for character-

izing the state or the activity of an entity or the world

in which this entity operates.” In CBAC, the system

administrator (or resource owner) speciﬁes a set of

contexts and deﬁnes for each context a set of appli-

cable permissions. When an entity (a user) operates

under a certain context, (s)he acquires the set of per-

missions (if any) that are associated with the active

context. When the active context changes, the previ-

Al-Wahah, M., Saaudi, A. and Farkas, C.

Semantic-based Obligation for Context-Based Access Control.

DOI: 10.5220/0008120105350540

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 535-540

ISBN: 978-989-758-378-0

535

ous permissions are revoked, and new permissions are

assigned (Corradi et al., 2004). Hence, context plays

the role of a bridge between the requester and access

permissions.

We present a motivating scenario that will be used

as a running example throughout the rest of this paper.

Motivating Example “University Travel Autho-

rization (TA) forms are used to specify permitted

travel expenses. Upon approval of a TA form, the

traveler and the travel ofﬁce must oblige to some re-

quirements. For example, a traveler must be on cam-

pus when applying for TA, and the traveler is obli-

gated to turn in itemized receipts within ﬁfteen days

of the conference. When a traveler submits itemized

receipts, the system is obliged to reimburse the trav-

eler.”

We develop a framework to support context-based

obligation, see Figure 1.

Figure 1: Architectural view of the obligation framework.

In this ﬁgure, the CBAC engine is used to en-

force the context-based authorization and the obliga-

tion policies. CBAC engine supports two modules:

obligation enforcer and obligation monitor. Obliga-

tion monitor continuously monitors the system state

over time. Obligation enforcer is used to create, ac-

tivate, enforce, and deactivate obligations. The con-

text manager receives requests from the policy en-

gine, asking for a speciﬁc context. In its response

to these requests, the context manager gathers, anno-

tates, processes, and reasons over the gathered data to

produce the context. Then it sends the resulted con-

text to the CBAC policy engine. System ontologies

are used for semantic-based system description. This

enables the representation of both ﬁne-grained and

coarse-grained obligation requirements. The require-

ments are used to derive dynamic obligation policies,

which are used later to enforce and dispense the priv-

ileges and commitments of the obligation.

The obligation ontology, OBL, is shown in Fig-

ure 2. Once an Obligation is created, it can be in one

of two temporal states: Persistent or Transient. In

case of persistent obligation, all the data associated

with the obligation should be saved by the system.

For transient obligation, the data associated with the

obligation is only available temporarily. The created

obligation also can be in one of the following opera-

tional states, Ful f illed, Pending, Violated (these are

speciﬁed by CBAC ontology as we will see later).

Obligation can also be a system obligation or a

user obligation. The data property isUserObl allows

to represent this property. Value of True means it

is a user obligation, while False value is for system

obligation. An obligation is imposed on a Sub ject

(a system or a user) to oblige her/him/it to per-

form some Action before getting further access to a

Resource (data or services). Deadlines of the obliga-

tions are speciﬁed using hasT Frame object property,

which in turn uses two properties hasStartTime and

hasEndTime.

Figure 2: Obligation ontology.

2.1 Context-Based Access Control

Model

In this section, we present a brief overview of

a CBAC approach suggested by (AL-Wahah and

Farkas, 2018a) in which we deﬁne Context-Based Ac-

cess Control model. In this model, access requests are

evaluated based on the contexts associated with the

subject and the requested resources. Each request is

matched with context’s metadata that speciﬁes and ac-

tivates the policy rule to be enforced. The authors use

rule-based Logic Programming (LP) to encode con-

text and policy rules.

Deﬁnition 1. (Access Control Policy (ACP)

Rules). An access control policy rule is a 6-tuple

hs, sc, rs, rc, p, aci, where s ∈ Sub ject, rs ∈ Resource,

sc, rc ∈ Context, where sc is the subject’s con-

text and rc is the resource context (optional),

p ∈ Permission={“Deny”, “Permit”}, and ac ∈

Action={read, write, delegate, revoke}.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

536

Table 1: Access Authorization rules example.

No. Rule

Rule: A student who is with context

AtCampusStudent can access on-

line TA application.

Each rule is instantiated when an access request is

received.

Deﬁnition 2. (Access Request (AR)). An Access re-

quest is given as a triple hs, rs, aci, where s ∈ Sub ject,

rs ∈ Resource, ac ∈ Action.

When an access request is received, the policy en-

gine requests the contexts of the subject s and the re-

source rs. Assume the context of s is sc. If using the

context sc, the policy engine can derive a permission,

i.e., p is “Permit”, and there is no conﬂict, CBAC

grants the access permission for the request. Other-

wise, the request is denied.

We represent our model using the OWL-DL on-

tologies (Hitzler et al., 2010). The context model

is built around the concept of contextual attribute.

Contextual attributes model the physical/logical en-

vironment such as location and temperature. Speciﬁc

context subclasses can be represented under Generic

Concept Context. Each subcontext class consists of

attribute values and constants.

The active context holds the current context of

an entity at a speciﬁc instant of time. Active con-

text reﬂects a snapshot of an entity’s context. We

should note that the context ontology can be extended

or shrunk by adding or removing subcontexts or by

adding or removing contextual attributes to the sub-

contexts. From our running example, we build the

access control authorization rule as shown in Table 1.

This rule states that if a subject requests an access

of the type TAaccess, and the subject s has a context

AtCampusStudent then the request is permitted.

3 SEMANTIC-BASED

OBLIGATION FOR CBAC

In traditional CBAC authorization, the context plays

the role of a bridge between a subject requesting an

access and the requested resource. If a subject has

the context, then (s)he can access the resource. In

obligation-supported CBAC authorization, the bridge

is represented by a context plus the required obliga-

tion. We differentiate between two types of the con-

text: reference context and obligation context.

(Reference Context c). A context that is not associ-

ated with an obligation and is instantiated by context

manager.

(Obligation Context oc). A context that is dynam-

ically generated by CBAC engine and is associated

with an obligation.

By creating a new context of obligation, we avoid

modiﬁcation of the authorization framework and the

CBAC policy. Obligation context oc, is generated

based on reference context. That obligation is always

related to a speciﬁc action (or a set of actions). Also,

the obligation must be fulﬁlled for its obligation con-

text to be satisﬁed. An obligation context is dynam-

ically generated by CBAC engine, while a reference

context c is instantiated by context manager. Creation

of speciﬁc obligation is achieved in conjunction with

an authorization decision enforcement. After its cre-

ation, an obligation must be activated. Activation of

an obligation is triggered by certain events (such as

time elapsing and action applied on a resource).

4 CHECKING OBLIGATION

STATES

One of the crucial tasks in managing obligations is

how to deﬁne and track its states. We propose three

major operational states. These are as follows:

• Fulﬁlled: An obligation is Fulﬁlled when its con-

ditions are satisﬁed by the subject.

• Pending: Obligation can be in Pending state in

two situations: 1) The action requested by a sub-

ject is issued before the start time of the obliga-

tion. 2) The action requested by a subject may not

relate to the obligation, but the due date/time of

the obligation is still valid (does not elapse yet).

• Violated: The action requested by a subject is re-

lated to the obligation, but the due date/time of the

obligation is invalid (already elapsed)

The CBAC ontology uses three properties to con-

trol the obligation process. These properties are

committedTo, hasObligation and oblig ID. The

property committedTo is used by CBAC engine

to check if there is an obligation associated with

the current decision. If there is one, it calls the

oblig en f orcer module to enforce it via executing

obligation policy speciﬁed for that matter. Property

hasObligation is used to create an obligation and

link it to the current decision so that the subject will

further be granted more privileges if (s)he/it satis-

ﬁes it. Each obligation has a unique identiﬁer called

oblig

ID. To monitor obligations, the CBAC engine

checks the operational states of the obligation. The

values of these states are modiﬁed by obligation en-

forcer and being monitored by obligation monitor.

Semantic-based Obligation for Context-Based Access Control

537

The obligations are speciﬁed using DL axioms.

For example, the obligation that requires a subject to

ﬁnalize TA itemized receipts is represented using the

DL axiom shown in Figure 3.

Figure 3: Generic obligation axiom.

Using this generic obligation, we will specify an-

other obligation to represent a reference obligation.

For example the reference obligation for our example

above is given by the DL axiom shown in Figure 4.

Figure 4: Reference DL obligation axiom.

Assume we have the following obligation business

rule:

Table 2: Obligation rule for the running example.

No. Rule

Rule: A student who is with context

FinalizingTAStudent can ﬁnalize

the on-line TA application.

We should note that the authorization decision in

presence of obligation may be different than the au-

thorization decision alone. We represent obligation

policies in a predicate form as follows:

is obliged(CBAC, p): To check if the decision is as-

sociated with an obligation to be enforced. The

ﬁrst parameter is CBAC ontology and the second

parameter is the decision previously returned by

evaluate(s, sc, r,CBAC, RS) function. This function is

called after Permit decision is made.

is committed(CBAC, p): This predicate, if returns

True, means that the request is associated with an

obligation and that obligation must be enforced be-

fore granting access. Same as is obliged(CBAC, p)

function, except that this function is called before the

Permit decision is made.

deactivate(OBL,CBAC, oblig ID): Deactivate the

obligation by deallocating its instances from OBL and

CBAC ontologies.

oblig ID ← get oblig ID(s,CBAC): Gets the obliga-

tion identiﬁer.

en f orce oblig(oblig ID,CBAC,OBL,s,sc,ac,r,OblP):

Enforces the obligation for the request in hand. This

predicate reads as follows: subject s working under

context sc should take the action ac on the resource

r only when (s)he fulﬁlls the obligation which is

recognized by an identiﬁer oblig ID and parameters

OblP.

Algorithm 1: Obligation-Supported Access Authorization.

Input: CBAC, CBAC ontology, OBL is a obligation

ontology, RQ is an Access Request, RS is access con-

trol rule-set.

Output: Access decision, either “Deny” or “Permit”.

1: RT ←parse(RQ) . RT = hs, r, aci

2: if RT = access then

3: sc←getContext(s);

4: p←evaluate(s, sc, r,CBAC, RS);

5: if p = “Permit” AND

noCon f lict(p, s, sc, r,CBAC, RS) then

6: if is obliged(CBAC, p) = True then

7: oblig ID ← get oblig ID(s,CBAC)

8: en f ocre oblig(oblig ID, OBL,

Oblig(s, sc, ac, rs, [ts, te], ps, tss))

9: Permit Access;

10: exit();

11: end if

12: else

13: Deny Access;

14: exit();

15: end if

16: else

17: return(“Not access request”);

18: end if

The function evaluate(s,sc,rs,CBAC,RS), takes

the access control ontology CBAC as input and

achieves the DL-based reasoning to get the inferred

model in f model. The access control policy rules, rep-

resented as Jena forward inference rules, will be ap-

plied on in f model to derive an access decision. The

function getrulesnumber(RS) returns the number of

rules in the access control policy rule-set RS. The

Boolean function noCon f lict(p,s,sc,rs,CBAC,RS),

works just like evaluate(s,sc,rs,CBAC,RS) function

but it returns a Boolean value if two conﬂicting rules

(“Permit” and “Deny”) are ﬁred at the same time.

5 IMPLEMENTATION

Our obligation implementation is carried out on Win-

dows 8.1 machine with 1.9 GHz CPU, 4 GB RAM

SECRYPT 2019 - 16th International Conference on Security and Cryptography

538

and 500 GB HDD. We used the on-line Freedatagen-

erator to generate unduplicated data instances in the

form of excel sheets. Then we use Cellﬁe plug-in for

Prot

e to assert these instances to the model ontolo-

gies. The rules used for this purpose are based on Java

Script Object Notation (JSON) (Friesen, 2019). We

use SWRL (Semantic Web Rule Language) to specify

and trigger operational state transitions. For situations

that need to delete an instance from the knowledge

base, we use Java-based API.

The obligation’s state checking and transition are

implemented using SWRL rules. When executed,

these rules transit the obligation operational status

from state to state if the conditions of the transition

are met. Because obligation express future conditions

that may not exist in the present time (the time of a

request), we randomly generate events (actions-based

or temporal) that trigger obligation policies. These

events are generated using our Java application and

fed into the model ontologies. After DL-reasoning

is complete, the execution of SWRL rules follows.

These two steps derive all the deductions needed to

make the authorization decision. Figure 5 shows the

results of our obligation approach simulation. It dis-

plays the time needed for different number of obli-

gations’ enforcement. In Figure 6, we display the

number of DL axioms required to encode the different

number of obligations.

Figure 5: Obligation Enforcement Time for Different Obli-

gation Numbers.

Figure 6: Number of Obligations versus Number of Axioms

Processing Time.

6 RELATED WORK

Obligation in access control has been extensively

studied by researchers. For example, Hilty et al.

(Hilty et al., 2005) propose a formal framework

for enforcing obligation policies through using Dis-

tributed Temporal Logic (DTL) to classify data pro-

tection requirements. Bettini et al. (Bettini et al.,

2002) propose an approach for specifying and eval-

uating provisions and obligations in Access Control

(AC). Their method is based on the expression of Dat-

alog Rules and reasoning for evaluating authorization

and obligation decisions. They use the term “provi-

sion” to refer to the conditions that must be met before

data is released after a request is received. We should

note that provisions are encoded within our semantic-

based authorization model. Authors in (S¸ensoy et al.,

2010) provide Polar, a framework for the semantic

deﬁnition and enforcement of permission, prohibi-

tion and obligation statements. Their deﬁnition of

an obligation involves activation conditions and con-

tents. Polar uses SPARQL-DL (P

erez et al., 2009)

queries for checking the fulﬁllment of consumer obli-

gations using reasoning, where activation conditions

are translated into standard SPARQL queries (Marﬁa

et al., 2015). Chen et al. (Chen et al., 2012) deﬁne

a model that engages obligations in the environment

of risk-aware access control. Ardagna et al. (Ardagna

et al., 2010) present an identity management system,

called PRIME. PRIME supports autonomous creden-

tials and policy languages that support anonymous

credentials. While the policy language supports obli-

gations, it is limited regarding the dynamic instan-

tiation of these obligations. Pontual et al. (Pontual

et al., 2011) present an approach to support user obli-

gation enforcement. The authors propose the property

of accountability to model unfulﬁlled obligations. A

novel aspect of their work is to consider authoriza-

tion needs for fulﬁlling obligations as well as the de-

pendency among multiple obligations. However, it is

unclear how the proposed approach accommodate dy-

namically changing environments.

7 CONCLUSIONS AND FUTURE

WORKS

We present a semantic-based formal speciﬁcation for

obligation policies and show how to use obligation

policies in conjunction with authorization decision

making. A novelty of our work is that we support

dynamically generated obligation. This is a crucial

requirement in an environment where the context of

access requests changes over time.

Semantic-based Obligation for Context-Based Access Control

539

Obligation is regarded as one of the requirements

associated with a speciﬁc action. If subjects can del-

egate their privileges and there is an obligation com-

bined with these privileges, then we need to investi-

gate delegation of obligation as well. Another direc-

tion for future work is to engage trust management

with authorization and obligation.

REFERENCES

AL-Wahah, M. and Farkas, C. (2018a). Context-aware iot

authorization: A dynamic and adaptive approach. In

13th International Conference for Internet Technology

and Secured Transactions. (ICITST-2018), pages 64–

72. Infonomics Society.

AL-Wahah, M. and Farkas, C. (2018b). Context delegation

for context-based access control. In 2nd International

Workshop on A.I. in Security, pages 70–79. ECML.

Ardagna, C. A., Camenisch, J., Kohlweiss, M., Leenes, R.,

Neven, G., Priem, B., Samarati, P., Sommer, D., and

Verdicchio, M. (2010). Exploiting cryptography for

privacy-enhanced access control: A result of the prime

project. Journal of Computer Security, 18(1):123–

160.

Bettini, C., Jajodia, S., Wang, X., and Wijesekera, D.

(2002). Provisions and obligations in policy man-

agement and security applications. In Proceedings of

the 28th international conference on Very Large Data

Bases, pages 502–513. VLDB Endowment.

Chen, L., Crampton, J., Kollingbaum, M., and Norman, T.

(2012). Obligations in risk-aware access control. In

Privacy, Security and Trust (PST), 2012 Tenth Annual

International Conference on, pages 145–152. IEEE.

Corradi, A., Montanari, R., and Tibaldi, D. (2004). Context-

based access control management in ubiquitous envi-

ronments. In Proceedings of the 3rd IEEE Interna-

tional Symposium on Network Computing and Appli-

cations, pages 253–260. IEEE.

Dey, A., Abowd, D., and Salber, D. (2001). A concep-

tual framework and a toolkit for supporting the rapid

prototyping of context-aware applications. Hum.-

Comput. Interact., 16(2):97–166.

Elrakaiby, Y., Cuppens, F., and Cuppens-Boulahia, N.

(2012). Formal enforcement and management of obli-

gation policies. Data & Knowledge Engineering,

71(1):127–147.

Fornara, N. (2011). Specifying and monitoring obliga-

tions in open multiagent systems using semantic web

technology. In Semantic agent systems, pages 25–45.

Springer.

Friesen, J. (2019). Java XML and JSON, Document Pro-

cessing for Java SE. APress.

Hilty, M., Basin, D., and Pretschner, A. (2005). On obliga-

tions. In European Symposium on Research in Com-

puter Security, pages 98–117. Springer.

Hitzler, P., Kr

otzsch, M., and Rudolph, S. (2010). Foun-

dations of Semantic Web Technologies. Chapman and

Hall/CRC Press.

Marﬁa, F., Fornara, N., and Nguyen, T. (2015). Modeling

and enforcing semantic obligations for access control.

In Multi-Agent Systems and Agreement Technologies,

pages 303–317. Springer.

erez, J., Arenas, M., and Gutierrez, C. (2009). Seman-

tics and complexity of sparql. ACM Transactions on

Database Systems (TODS), 34(3):1–16.

Pontual, M., Chowdhury, O., Winsborough, W. H., Yu, T.,

and Irwin, K. (2011). On the management of user

obligations. In Proceedings of the 16th ACM sym-

posium on Access control models and technologies,

pages 175–184. ACM.

Robinson, W. and Purao, S. (2009). Specifying and moni-

toring interactions and commitments in open business

processes. IEEE software, 26(2):72–79.

Rubab, I., Ali, S., Briand, L., and Traon, Y. L. (2014).

Model-based testing of obligations. In 2014 14th In-

ternational Conference on Quality Software, pages 1–

10. IEEE.

S¸ensoy, M., Norman, T., Vasconcelos, W., and Sycara, K.

(2010). Owl-polar: Semantic policies for agent rea-

soning. In International Semantic Web Conference,

pages 679–695. Springer.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

540
