Automatic Reuse of Prototypes in Software Engineering: A Survey of

Available Tools

A. S

anchez-Villar

ın

1 a

, A. Santos-Monta

1 b

and J. G. Enr

ıquez

2 c

IWT2 Research Group, University of Seville, Spain

Computer Languages and Systems Department, University of Seville, E.T.S. Ingenir

ıa Inoform

atica,

avda. Reina Mercedes s/n, 41012, Seville, Spain

Keywords:

Prototypes, Prototypes Tools, Prototypes Reuse.

Abstract:

The use of prototypes as an excellent mechanism for communication between software users has been fully

accepted in the literature. Both the academic and business worlds agree on its use as a software technique,

used primarily to capture requirements and as a means of communication with the user. However, often,

prototypes are developed very quickly or without the collaboration of the users. This is one of the main

reasons why the real power of the prototypes is not used in software development. The initial hypothesis of

this research is that this problem occurs because prototypes are regarded as disposable milestones. This paper

analyzes whether there are adequate tools on the market to help development teams to reuse prototypes as

an exceedingly mechanism for starting and expediting new software development projects. With the present

study we show different tools for prototypes that, even though they are a preliminary evaluation, show the

disadvantages to be solved in the future development and research of solutions.

1 INTRODUCTION

The use of prototypes to improve the communication

with clients are ﬁnal users is a technique not only con-

sidered in software engineering. In fact, it is a tech-

nique considered in mainly any product development.

Thus, for instance, the design thinking methodology

(Brown et al., 2008; Dym et al., 2005) proposes the

deﬁnition of prototypes as the base for each product

deﬁnition and it has to be developed after empathiz-

ing, deﬁning and thinking with ﬁnal users.

In software engineering context, interface proto-

types are recognized as a very powerful tool for the

communication with client and ﬁnal users (Alavi,

1984). However, in practice, it has been noticed that

software and interfaces prototypes are developed in

a very fast way, with very few resources, and even,

without the enrollment of users. Results of this pro-

cess normally are discarded in the rest of the life cycle

and it provokes that some software teams and com-

panies consider them as a “required play” that only

use resources with a minimum of beneﬁces (Escalona

https://orcid.org/0000-0002-7740-5327

https://orcid.org/0000-0002-0749-6411

https://orcid.org/0000-0002-2631-5890

et al., 2004).

Under our experience with companies (Escalona

and Koch, 2004), this idea is not so wild. When we

consider to develop prototypes in the development life

cycle (mainly in the early phases), we have to decide

several critical aspects like use high or low conﬁdence

prototypes or the use of vertical or horizontal proto-

types among others. These decisions require time and

resources and if the prototypes are considered as a dis-

posable milestone, this cost seems not to be justiﬁed.

Another option to this situation is to try to develop

prototypes that could be “reused” in the next activities

of the software development life cycle, for instance,

in interface design. However, translating prototypes

to software interfaces requires a manual process, con-

sequently, it produces an increase of cost again.

To ﬁnd a solution to this situation, there are sev-

eral tools in the market that promise to help to the de-

velopment teams to develop prototypes that could be

“automatically” translated into future software inter-

face. Thus, the investment of prototypes development

is justiﬁed and the team could beneﬁt from prototypes

advantages.

In this paper, we present a global view about tools

that promise to help us in the process to generate anal-

ysis and design products or even coding prototypes

144

Sánchez-Villarín, A., Santos-Montaño, A. and Enríquez, J.

Automatic Reuse of Prototypes in Software Engineering: A Survey of Available Tools.

DOI: 10.5220/0008352901440150

In Proceedings of the 15th International Conference on Web Information Systems and Technologies (WEBIST 2019), pages 144-150

ISBN: 978-989-758-386-5

automatically or, at least, semi-automatically.

The rest of this paper is structured as follows.

Firstly, we starting with a very short introduction of

the context where this research is being developed,

which is very closed to the enterprise world. In Sec-

tion 3, the methodology followed for this study is de-

scribed. Section 4 instances the methodology pro-

posed in previous section and presents the results ob-

tained. Section 5 presents learned lessons and ﬁnally,

paper ﬁnishes with a set of conclusions and future

works.

2 CONTEXT

Coding prototypes with the same precision with

which they were designed is a real problem in daily

programming (McMillan et al., 2012). Unfortunately,

current methods found in both literature and industry

do not allow prototypes to be transformed into modiﬁ-

able code, following requirements and characteristics

that must be met. In a Scrum (Schwaber and Bee-

dle, 2002) or Design Sprint methodology (Banﬁeld

et al., 2015) context, the importance of having vali-

dated prototypes saves a lot of time and avoids future

problems if the programming is in an advanced state.

The problem that is cited is common within the

iMedea project (innovative Medical Engineering As-

sistance) (Escalona, 2019) by G7Innovation (G7 In-

novation, 2019) in Seville, in which the prototypes

are validated in collaboration with the Inebir clinic,

but there are details or formulas that escape once they

are translated to the code. G7 Innovation is a SME

(Small and Medium Enterprise) focused in the devel-

opment of software oriented to sanitary environments.

In fact, they produce high TIC results in the ﬁeld of

Smart Laboratories, Human Reproduction or speciﬁc

results for chronic treatment using different devices

and sensors (V. Cid, 2019; L. Morales, 2019). In this

context, the communication between the sanitary en-

vironment and the IT engineers is a critical factor to

assure the quality of the results. For this reason, they

used they have developed, a version of a methodology

named NDT (Navigational Development Techniques)

(Escalona and Arag

on, 2008) that, in its current ver-

sion mix Scrum with Design Thinking principles.

It is not the aim of the paper the presentation of

the methodology but, basically, it covers three main

steps: the ﬁrst one is to “discover the problem”. In

this phase, users and engineers work together to de-

ﬁne the problem and a ﬁrst set of prototypes for the

solution. These prototypes are improved in different

iterations and, at the end of this ﬁrst step they get a

very high-ﬁdelity prototype. After that, in the second

step, the IT Team execute the life cycle to analyze,

design and built the software to support these proto-

types. In the third steps, the result is implanted and

deployed in the environment. It is only a short pre-

sentation but, obviously, each step has a set of phases,

task and techniques to be applied that can be obtained

from (NDT-Navitgational Development Techniques,

2019). However, this global view, let us to introduce

our motivation to present the problem that we want

to try to start to solve with this paper. The team in

iMedea requires that, after design a very high-ﬁdelity

prototype, they must create the analysis, the screen or

any aspect from zero, and the original prototypes are

only used for communication. They claim if it will

possible to try to reuse them to automatically gen-

erate products in the next phases automatically. In

fact, NDT use the Model Driven Paradigm (MDE)

(Dom

ınguez-Mayo et al., 2012) in other aspects, for

instance, to produce test from requirements. So, the

question that motives this work is: could be possible

to use prototypes deﬁned and validated with the user

to generate products in the rest of the life cycle?

In this sense, it is necessary to use tools that opti-

mize the process from obtaining the validation of the

prototypes to the already programmed views, evalu-

ating that it is possible to obtain a code that can be

modiﬁed later and that is faithful to the styles of the

prototypes. To this end, it will be inevitable that the

prototypes are made with delicacy, effort and enthusi-

asm, as this would save time in programming.

3 METHODOLOGY

Systematic Literature Reviews (SLRs) (Kitchenham

and Brereton, 2013) and Systematic Mapping Studies

(SMSs) (Petersen et al., 2008) are some of the most

commonly used methods for performing state-of-the-

art studies in software engineering. The choice of

each of them depends on the objectives to be achieved

with the research.

SLRs are more expensive to perform than SMSs

(Velthuis, 2014). The main objective of an SLR is

to identify best practices based on empirical studies,

the one of SMSs, is to provide a classiﬁcation and a

thematic analysis of a concrete topic.

The most widely accepted SLR method around

software engineering, is the one proposed by Kitchen-

ham (Kitchenham and Brereton, 2013). This proposal

concludes that a review of the literature should consist

of the following phases:

• Planning: before an SLR, it is necessary to con-

ﬁrm the need for the research. The most impor-

tant activity is writing the research questions that

Automatic Reuse of Prototypes in Software Engineering: A Survey of Available Tools

145

deﬁne the review protocol.

• Conducting: is about executing the protocol that

is deﬁned.

• Reporting: describe how the ﬁnal report is pre-

pared.

The method that deﬁnes the process of a SMS pro-

posed by Petersen et al. (Petersen et al., 2008), shows

a lot of similarities with the one presented by Kitchen-

ham, establishing set of ﬁve steps, where each of them

produces an output. These steps are:

• Deﬁnition of the Research Questions: this activ-

ity is related to the formulation of the Research

Questions (RQs) that will guide the work.

• Conduct Search: this activity is related to execute

the search, based on the RQs. The search it is

normally executed in different digital libraries and

based on some keywords extracted from the RQs.

• Screening of Papers: this activity is related to ap-

ply the inclusion and exclusion criteria with the

aim of selecting the most relevant and close pa-

pers to the topic of the research.

• Keywording using Abstracts: this activity is re-

lated to the building of the classiﬁcation scheme,

where all the primary papers selected in the previ-

ous phase will be categorized.

• Data extraction and mapping process: this ﬁnal

activity, is related to the data extraction and the

mapping process based on the results obtained in

the keywording activity. This activity will let the

researchers to classify which is the state of the art

of the topic and to identify gaps and possibilities

for future research.

SLRs and SMSs are considered valid formal meth-

ods for carrying out studies and surveys related to

technological tools or solutions, so they were our ﬁrst

consideration to execute our study. However, there

are some limitations, such as: deﬁning search engines

or keywords, among others, that do not allow to ex-

ecute any of the methodologies strictly. Considering

that the scope of this work is much more focused on

the industrial than on the scientiﬁc literature, it has

been taken as a reference.

4 COMPARATIVE STUDY

At the time of beginning the study of the tools, it was

thought to use the search and selection mechanism

proposed by Barbara Kitchenham, which is known as

SLR. However, thanks to what was contributed in the

paper (Escalona et al., 2014), “it was seen that SLRs

proposals are highly directed towards answering re-

search questions on some scientiﬁc knowledge. Nev-

ertheless, SLR is not enough for a study led to com-

pare technologies or tools solutions”.

Therefore, the study of the tools and the ques-

tions of the questionnaire presented below have been

obtained in an empirical way analyzing the needs of

work groups in projects, as is the example of iMedea

project by G7Innovation, which had a clear need to

improve for the modelling of the prototypes, as it is

introduced in Section 2. Through a follow-up of the

project and by means of questions to the members of

the team it was possible to obtain the following ques-

tionnaire.

On the other hand, tools were obtained empiri-

cally analyzing which are the most used in the current

market of the software industry and the most popular

among the users.

4.1 Characterization Map

According to previous section, our idea is to try to cre-

ate high detailed and high-ﬁdelity prototypes, which

could be automatically translate into analysis, design

products or even ﬁnal screens. For this aim, and fo-

cusing our work in iMedea scenario, a research about

systems that allow to convert interface prototypes de-

signed into a typed prototype such as XML or HTML

has been done. It has been proved many different

tools, applications such as Axure or JustinMind, or

online converters like the web “zamzar.com”. After

proving and analyzing all the investigated tools, we

realized that no one tool did exactly the same that we

were researching, due to the tool did not convert to the

format we wanted or because the tool returned conver-

sions very little satisfactory, then it would not be able

to be used.

Following this idea, it has been elaborated a se-

ries of questions that allow to validate if a tool offers

good functionalities to do the conversion of the proto-

types. They are formed by a set of trichotomy ques-

tions whose afﬁrmative answer indicates that the tool

owns a good characteristic, the negative that indicates

that it has not that characteristic or an intermediate

answer that indicate that it has only that characteristic

partly. These questions were developed in the collab-

oration of iMedea team and they are the next, sorted

by relevance:

• Q01 - Does it allow to convert or export proto-

types into multiple formats, such as XML and

HTML?

• Q02 - Is the conversion done correctly, exporting

it with the correct tags?

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

146

• Q03 - Is possible to interact with the system via

API?

• Q04 - Also to convert into different formats, does

the tool allow to create its own prototypes in

HTML or another typed language?

• Q05 - Are there versions of the tool for the main

operative system such as Windows, Mac OS and

Linux?

• Q06 - Is the complete system free?

• Q07 - In the case that the tool is paid, are there

licenses for students and universities?

• Q08 - Does the tool receive periodically updates

and is followed by a community?

• Q09 - Does the tool have a good customer ser-

vice?

• Q10 - Is the system intuitive and user friendly?

In order to answer these questions, we deﬁned

several searching criteria in order to look in the most

relevant research search engines: Scopus, Scholar,

etc. but, as we introduce, this engines are not the most

suitable for tools searching and we had to move to

google following criteria deﬁned in (Escalona et al.,

2014). Thus, we obtained a set of ten suitable tools

that seem cover part of our requirements. Next sec-

tions present an analysis of all of them.

4.2 Selected Tools

Below is shown a summary of the study made to the

tools used that will be presented, analyzing the pros

and cons of each one. After applying several search-

ing criteria, we selected tools presented in Table 1.

Each tool is identiﬁed by a code and for each of them,

a references and short description is presented and

also a set of advantages and disadvantages in a very

short way.

4.3 Evaluation

A high ﬁdelity prototype deﬁned by iMedea team that

was validated with the user, was taken as reference to

be redesigned for each tool

Two juniors engineers have modelled this exam-

ple in each numerated tool getting the results that

are presented in Table 2 supervised by two senior re-

searchers. Thus, this table presents an instance of the

characterization map presented in Section 4.1.

We cannot present the concrete prototype that we used

because it is property of G7 Innovation but if any reader is

interested in knowing more about the prototype and iMedea,

please contact with authors to share information.

In table, we ﬁnd each question in columns and

each tool in rows. Each cell presents the results of

the evaluation of each question for each tool. In each

cell, three values are possible:

• Y: It means “Yes” and represents that this tool

completely answers this question.

• N: It means “No” and represents that this tool

does not support this question at all.

• P: It means “Partially” and represents that this

tool only supports this question partially.

5 LEARNED LESSONS

From Table 2 we found that none tool is completely

suitable for our aim. We analyze in detail.

Q01 - Does it allow to convert or export prototypes

into multiple formats, such as XML and HTML?

Only three tools support this requirement. It is some-

thing very relevant because we require to get a for-

mat that we can analyze and generate analysis source

products from them.

Q02 - Is the conversion done correctly, exporting it

with the correct tags?

To answer this question, we test the tool with a real

prototype for iMedea. We detected that conversion or

generation (in the tools that allow some of that) have

fails or produce different mistakes.

Q03 - Is possible to interact with the system via Ap-

plication Programming Interface (API)?

Only two tools offer this possibility to us. The global

idea that we have it is to analyze the “core” of our

prototypes and to generate analysis and/or design el-

ements from it, for instance, using mechanisms like

Model Driven Engineering, but, if we are closed to its

“core”, the tool must be completely discarded.

Q04 - Also to convert into different formats, does the

tool allow to create its own mock-ups in HTML or

another typed language?

Different formats are not so relevant for iMedea

project because the environment is a ﬁxed one, but,

if we think a bigger company with different environ-

ments, it can be a very restrictive aspect. In this sense,

none tool allows to convert in different formats.

Q05 - Are there versions of the tool for the main op-

erative system such as Windows, Mac OS and Linux?

This question is, like question Q04, more relevant for

big companies. As can be deduced from Table 2, tools

are focused on a concrete format.

Automatic Reuse of Prototypes in Software Engineering: A Survey of Available Tools

147

Table 1: Overview of selected tools.

ID Tool Description Advantages Disadvantages

A01 Balsamiq

(Balsamiq,

2019)

Application that facilitates

and speed up the creation of

sketches, both for web and

mobile.

Simplicity. Finished unprofessional.

Payment version.

A02 Microsoft

Expres-

sion Blend

(Microsoft

Expression

Blend, 2019)

Professional tool of design,

with the ﬁnal purpose to pro-

vide experiences of users at-

tractive.

Finished profes-

sional.

Payment version.

A03 Adobe XD

(Adobe XD,

2019)

Tool based in vectors to de-

sign and create prototypes of

the user experience for ap-

plications.

Finished pro-

fessional.

Free version.

Complex use.

A04 moqups (Mo-

qups, 2019)

Web application simpliﬁed

and intuitive that helps to

create and collaborate in

wireframes, models, dia-

grams and prototypes.

User friendly. Payment version.

A05 invision (Invi-

sion, 2019)

Platform of design of digital

products that is used to cre-

ate the best experiences of

clients of the world.

Finished profes-

sional. User friendly.

Free.

It has not API.

A06 Zeplin

(Zeplin,

2019)

Application to use in team,

to the design with guides of

precise style or code frag-

ments automatically.

Intuitive use. Payment version.

A07 Zamzar (Za-

mzar, 2019)

Web application that allows

to convert Mockups made

in PowerPoints into HTML,

XML and other languages.

Easy and intuitive.

It has API.

Payment version.

Poor conversion.

A08 Wireframe

Sketcher

(Wireframe

Sketcher,

2019)

Tool to create wireframes,

models and prototypes for

applications, is multiplat-

form.

Compatibility with

Eclipse IDE.

Finished unprofes-

sional.

Use few intuitive.

A09 Justinmind

(Justinmind,

2019)

Tool to create prototype

adapted to mobiles.

Intuitive use. Payment version.

A10 Axure (Ax-

ure, 2019)

Tool to create prototypes

and convert them into other

languages

Finished pro-

fessional.

Adapted to mobile.

Easy and intuitive.

It has API.

Payment version.

Q06 - Is the complete system free?

We can deduce that there is no tool is completely free

access. It should be not a big problem but, if we ana-

lyze the requirements that non-free access tools offer

in the rest aspect, it is difﬁcult to justify the invest-

ment in a SME company for acquired a tool. This is

a relevant question, since the costs of the tools should

not be ignored, even if they differ greatly from per-

sonal expenses.

Q07 - In the case that the tool is paid, are there li-

censes for students and universities?

In our environment, this question is quite relevant,

perhaps, it is not so relevant for enterprise environ-

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

148

Table 2: Characterization map.

Q01 Q02 Q03 Q04 Q05 Q06 Q07 Q08 Q09 Q10 Totals

A01 P N N N P P N Y P N Y: 1 N: 5 P: 4

A02 N N N N N P N N P Y Y: 1 N: 7 P: 2

A03 Y N P N N P N N P Y Y: 2 N: 5 P: 3

A04 Y N P N P P N N P Y Y: 2 N: 4 P: 4

A05 P Y N N P P N N P Y Y: 2 N: 4 P: 4

A06 P N P N P P N N P Y Y: 1 N: 4 P: 5

A07 Y P Y N Y P P P N Y Y: 4 N: 2 P: 4

A08 P P N N N P N N P N Y: 0 N: 6 P: 4

A09 P N P N P P N N P Y Y: 1 N: 4 P: 5

A10 P N Y P Y P N P P Y Y: 3 N: 2 P: 5

ment, but universities and students are a very relevant

community to test, to improve or even to analyze tools

like this one. We can see that very few consider this

aspect.

Q08 - Does the tool receive periodically updates and

is followed by a community?

To have a relevant community or support is essential

in any tool acquisition. From results in Table 2, we

deduce that few of tools have a good or a partially

good community to support its implantation.

Q09 - Does the tool have a good customer service?

To answer this question, we have navigated by cus-

tomer client services of the different tools. We have

analyzed opinions and, in general, it seems not to be

too much critics to the support. However, we consider

that this question should be analyzed under a contract

in case of acquiring a tool and it depends of the con-

crete environment where it will be used.

Q10 - Is the system intuitive and user friendly?

To answer this question, we value the environment by

ourselves experiences. As we introduced, it is a pre-

liminary study and it was executed in a very concrete

environment with few resources (only two junior soft-

ware engineers as testers). However, in general, we

consider that tools are friendly and easy to use. It is

relevant in environments like iMedea one, because in

companies, mainly in SME, the cost of the learning

curve in new tools is a critical aspect to be consid-

ered.

Finally, with learned lessons, we consider that,

with this very preliminary work, the current situation

shows that there is an important gap in software en-

gineering in this aspect. It opens a tool for our future

research with the assurance that it is also relevant for

companies.

6 CONCLUSIONS AND FUTURE

WORKS

This paper has presented a preliminary comparative

study about tools for software prototyping. Starting

from a real problem detected in our experience with

companies, the scenario presented in Section 2, we

try to follow Escalona et al. (Escalona et al., 2014) to

compare and try to the current situation.

In the context of a very concrete problem, a

SME called G7 Innovation, which develops a con-

crete product based on prototypes called iMedea, we

have deﬁned a characterization schema based on ten

relevant questions. With a team composed by two ju-

nior software engineers, these questions have been an-

swered for each tool.

We are aware that this study has important gaps

that we want to try to solve in our future works. First,

searching was not exhaustive. After this study, we

are considering trying to make a research SLR to try

to look, not tools, just approaches or research related

with our aims to try to ﬁnd inspiration about how to

try to solve the problem. In fact, we read previous ex-

perience, like NDT-Prototypes (Garc

ıa-Garc

ıa et al.,

2012) that proposes to use Model-Driven Engineer-

ing, it could be a future way to consider.

Other important gap is about the deﬁnition of the

schema. The deﬁnition of the questions was made in

the concrete context of iMedea and we must improve

them deﬁned research questions that cover a higher

spectrum.

Searching criteria is also a very important gap. As

we introduce, classical research search engines were

not a good alternative because we were looking for

tools. Obviously, if we want to execute a SLR, we

have not only to deﬁne a good set of research ques-

tion, just also a good set of search criteria.

Despite of these gaps, we can conclude that this

preliminary evaluation, opens an important opportu-

Automatic Reuse of Prototypes in Software Engineering: A Survey of Available Tools

149

nity to research. Obviously, the situation of G7 In-

novation and iMedea is very frequently, so the enter-

prise requires this kind of solutions. With this study,

we have put the ﬁrst seed to start to research and to

develop solutions in this direction.

ACKNOWLEDGEMENTS

This research has been supported by the Polo-

las project (TIN2016-76956-C3-2-R) of the Spanish

Ministry of Economy and Competitiveness. We want

to thank Professor Mar

ıa J. Escalona for her support

in this study and G7 Innovation for its support in the

comparative evaluation and in the use of iMedea ex-

amples.

REFERENCES

Adobe XD (Last Accessed: July, 2019). https://www.adobe.

com/es/products/xd.html.

Alavi, M. (1984). An assessment of the prototyping ap-

proach to information systems development. Commu-

nications of the ACM, 27(6):556–563.

Axure (Last Accessed: July, 2019). https://www.axure.

com/.

Balsamiq (Last Accessed: July, 2019). https://balsamiq.

com/.

Banﬁeld, R., Lombardo, C. T., and Wax, T. (2015). De-

sign sprint: A practical guidebook for building great

digital products. ” O’Reilly Media, Inc.”.

Brown, T. et al. (2008). Design thinking. Harvard business

review, 86(6):84.

Dom

ınguez-Mayo, F., Escalona, M. J., Mej

ıas, M., Ross,

M., and Staples, G. (2012). Quality evaluation for

model-driven web engineering methodologies. Infor-

mation and Software Technology, 54(11):1265–1282.

Dym, C. L., Agogino, A. M., Eris, O., Frey, D. D., and

Leifer, L. J. (2005). Engineering design thinking,

teaching, and learning. Journal of engineering edu-

cation, 94(1):103–120.

Escalona, M. (2019). imedea: Una soluci

on orientada en el

paciente. In Proceedings of Infors@alud, page 239.

Escalona, M., Mej

ıas, M., and Torres, J. (2004). Devel-

oping systems with ndt & ndt-tool. In 13th Inter-

national conference on information systems develop-

ment: methods and tools, theory and practice, Vilna,

Lithuania, pages 149–59.

Escalona, M. J. and Arag

on, G. (2008). Ndt. a model-driven

approach for web requirements. IEEE Transactions on

software engineering, 34(3):377–390.

Escalona, M. J., Garc

ıa Garc

ıa, J. A., Dominguez-Mayo,

F. J., and Ramos, I. (2014). Technical tool surveys

and comparative studies: a systematical approach.

Escalona, M. J. and Koch, N. (2004). Requirements engi-

neering for web applications-a comparative study. J.

Web Eng., 2(3):193–212.

G7 Innovation (Last Accessed: July, 2019). http://

g7innovation.com/.

Garc

ıa-Garc

ıa, J. A., Ortega, M. A., Garc

ıa-Borgo

non, L.,

and Escalona, M. J. (2012). Ndt-suite: a model-

based suite for the application of ndt. In Interna-

tional Conference on Web Engineering, pages 469–

472. Springer.

Invision (Last Accessed: July, 2019). https://www.

invisionapp.com/.

Justinmind (Last Accessed: July, 2019). https://www.

justinmind.com/.

Kitchenham, B. and Brereton, P. (2013). A systematic re-

view of systematic review process research in soft-

ware engineering. Information and software technol-

ogy, 55(12):2049–2075.

L. Morales, R. Rodriguez-Le

on, A. S. A. S.-V.-N. S.-G. J.

G.-G. F. D. J. N. (2019). Metodolog

ıa de trabajo ori-

entada al usuario. un ejemplo real en g7 innovation:

el proyecto imedea. In Proceedings of Infors@alud,

pages 155–156.

McMillan, C., Hariri, N., Poshyvanyk, D., Cleland-Huang,

J., and Mobasher, B. (2012). Recommending source

code for use in rapid software prototypes. In Proceed-

ings of the 34th International Conference on Software

Engineering, pages 848–858. IEEE Press.

Microsoft Expression Blend (Last Accessed: July,

2019). https://www.microsoft.com/es-es/download/

details.aspx?id=10156.

Moqups (Last Accessed: July, 2019). https://moqups.com/.

NDT-Navitgational Development Techniques (Last Ac-

cessed: July, 2019). http://iwt2.org/.

Petersen, K., Feldt, R., Mujtaba, S., and Mattsson, M.

(2008). Systematic mapping studies in software en-

gineering. In Ease, volume 8, pages 68–77.

Schwaber, K. and Beedle, M. (2002). Agile software devel-

opment with Scrum, volume 1. Prentice Hall Upper

Saddle River.

V. Cid, D. Soto, C. R. M. C. N. S.-G. A. J. F. D.-J. N.

(2019). Concepto plm (patient lifecycle management)

en el entorno sanitario. una nueva concepci

on llevada

a la pr

actica. In Proceedings of Infors@alud, pages

155–156.

Velthuis, M. G. P. (2014). M

etodos de investigaci

on en in-

genier

ıa del software. Grupo Editorial RA-MA.

Wireframe Sketcher (Last Accessed: July, 2019). https://

wireframesketcher.com/.

Zamzar (Last Accessed: July, 2019). https://www.zamzar.

com/es/convert/ppt-to-html5/.

Zeplin (Last Accessed: July, 2019). https://zeplin.io/.

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

150
