Exact and Approximate Rule Extraction from Neural Networks with

Boolean Features

Fawaz A. Mereani

1,2 a

and Jacob M. Howe

1 b

City, University of London, London, U.K.

Umm AL-Qura University, Makkah, Saudi Arabia

Keywords:

Neural Networks, XSS, Rule Extraction, Explainable AI.

Abstract:

Rule extraction from classiﬁers treated as black boxes is an important topic in explainable artiﬁcial intelligence

(XAI). It is concerned with ﬁnding rules that describe classiﬁers and that are understandable to humans, having

the form of (I f ...T hen...Else). Neural network classiﬁers are one type of classiﬁer where it is difﬁcult to know

how the inputs map to the decision. This paper presents a technique to extract rules from a neural network

where the feature space is Boolean, without looking at the inner structure of the network. For such a network

with a small feature space, a Boolean function describing it can be directly calculated, whilst for a network with

a larger feature space, a sampling method is described to produce rule-based approximations to the behaviour

of the network with varying granularity, leading to XAI. The technique is experimentally assessed on a dataset

of cross-site scripting (XSS) attacks, and proves to give very high accuracy and precision, comparable to that

given by the neural network being approximated.

1 INTRODUCTION

Artiﬁcial intelligence and machine learning, and in

particular neural networks, can produce models that

give high predictive accuracy, leading to excellent

performance in complex tasks such as detecting ob-

jects in the images (He et al., 2016), or understanding

natural language (Cho et al., 2014). The model re-

sulting from a trained neural network is essentially

a black box: the way in which the neural network

reaches a decision from the input data is not ac-

companied by an explanation that can be interpreted

by a user. There is growing interest in being able

to explain the decision making resulting from ma-

chine learning models. That might be by opening up

black box models (Baehrens et al., 2010; Bach et al.,

2015), by developing methods that help to understand

what the model has learned (Mahendran and Vedaldi,

2015; Nguyen et al., 2016), or (as will be done in

the current work) by extracting rules from the net-

works. The term Explainable Artiﬁcial Intelligence

(XAI) captures the problem of making artiﬁcial intel-

ligence systems understandable to humans (Gunning,

2016). XAI aims to ”produce more explainable mod-

https://orcid.org/0000-0003-2832-304X

https://orcid.org/0000-0001-8013-6941

els, while maintaining a high level of learning per-

formance (prediction accuracy); and enable human

users to understand, appropriately, trust, and effec-

tively manage the emerging generation of artiﬁcially

intelligent partners” (Gunning, 2016).

In previous work, a variety of machine learning

techniques were used to detect JavaScript based cross-

site scripting (XSS) attacks (Mereani and Howe,

2018a; Mereani and Howe, 2018b). The performance

of the resulting classiﬁers was evaluated and they

achieved high predictive accuracy results in the detec-

tion of XSS attacks using a large real-world data set

of malicious and benign scripts. A curious aspect of

this work is that most of the features used for training

the model are Boolean valued.

The current paper investigates rule extraction from

neural networks trained to detect XSS attacks using a

feature set building on (Mereani and Howe, 2018b).

The work starts from the observation that if the fea-

tures that a neural network is working with are all

Boolean, then the trained neural network precisely de-

ﬁnes a Boolean function. That is, for any combination

of (Boolean) inputs, the result of the classiﬁcation by

the trained neural network is either malicious or be-

nign, a Boolean value. If the number of features is

small, then each possible input combination can be

evaluated, resulting in the enumeration of the truth ta-

424

Mereani, F. and Howe, J.

Exact and Approximate Rule Extraction from Neural Networks with Boolean Features.

DOI: 10.5220/0008362904240433

In Proceedings of the 11th International Joint Conference on Computational Intelligence (IJCCI 2019), pages 424-433

ISBN: 978-989-758-384-1

ble for the Boolean function that the neural network

represents. As the number of features increases, the

size of the truth table quickly becomes infeasible to

produce and reduce (in (Mereani and Howe, 2018b),

62 features were used). Hence for neural networks

deﬁned over larger features spaces approximations of

the encoded neural network are considered and a sam-

pling based approach is taken. This approach to rule

extraction treats the neural network as a black box,

and the extracted Boolean function results in a deci-

sion making method that is more explainable to hu-

mans (Gunning, 2016). The approach extends to any

other problem with a Boolean feature set. The contri-

butions of this paper as follows:

• Re-engineering of the features required to use

machine learning techniques to detect JavaScript

based XSS attacks, by reducing and ranking the

features in (Mereani and Howe, 2018b)

• The observation that this feature set is entirely

Boolean, hence a trained classiﬁed deﬁnes a

Boolean function

• A technique to approximate this Boolean function

when the feature set is large is provided

• An empirical evaluation of rule extraction from,

and approximation of, neural networks for XSS

detection is given.

The rest of this paper is organised as follows: Sec-

tion 2 gives background and related work on methods

for extracting rules and the detection of XSS attacks

in scripts. Section 3 describes the dataset used, in-

cluding how features are selected and ranked, how

neural networks are trained and evaluated using this

data set, and the method used for constructing and

approximating Boolean functions. Section 4 presents

results related to the application of the rule extraction,

and Section 5 discusses the results. Further discussion

and concluding remarks are given in Section 6.

2 BACKGROUND AND RELATED

WORK

2.1 Rule Extraction

Many applications need to build an accurate and

easy to understand classiﬁer by using traditional tech-

niques. These requirements (accuracy, ease) always

work in a paradoxical manner, as (Breiman et al.,

2001) has stated, “Unfortunately, in prediction, ac-

curacy and simplicity (interpretability) are in con-

ﬂict.” Therefore, the extraction of rules is a middle

method between the two requirements by implement-

ing a simple set of rules based on (I f ...T hen...Else)

to simulate the work of the predictions of the model.

Extraction of rules aims to ﬁnd rules that can be un-

derstood in terms of how the classiﬁcation models

work. Furthermore, rule extraction techniques pro-

pose to explain the predictive rules that are made in-

side the black box without modiﬁcation (Craven and

Shavlik, 1996; Martens et al., 2009; Baesens et al.,

2011). Extracted rules are important in the ﬁeld of

data mining, where they have been described as an

important process to identify useful patterns that can

be understood (Fayyad et al., 1996).

Algorithms for extracting rules from neural net-

works are divided into three main types. The ﬁrst type

is called the black box or pedagogical, the second is

decompositional, and the third is eclectic. Pedagog-

ical is not interested in the internal structure of the

network, but is interested in extracting the relation-

ship between inputs and outputs without the need to

scrutinise the behaviour of the internal network (Taha

and Ghosh, 1996; Tsukimoto, 2000). An example

of using a pedagogical method is found in (Saito and

Nakano, 1988), where the rules were extracted from a

multilayer medical diagnostic system by monitoring

the effect of network outputs when changing inputs.

Furthermore, the VIA method (Thrun, 1993) is an-

other example which uses a generate and test proce-

dure to extract the rules from neural networks trained

by backpropagation. This method is characterised by

performing the output of the network through the sys-

tematic variation of the pattern of input. Decompo-

sitional is the extraction of the rule directly from the

layers in the network with the customisation of the

linguistic meaning of the layers. The rules are ex-

tracted by analysing activation, outputs of hidden lay-

ers, and the weights that are related to them (Etchells

and Lisboa, 2006). In (Setiono and Liu, 1995) a three

step algorithm to understand neural networks is pro-

posed. The ﬁrst step is to decrease the weight by

creating a backpropagation network to reﬂect the im-

portant connections on its larger weights. Second, to

trim the network by deleting irrelevant connections

while maintaining predictive accuracy. In the third

step, the rule is extracted by estimating the values of

the hidden unit activation. In (Setiono and Liu, 1997)

the decompositional technique NeuroLinear is capa-

ble of extracting rules from the oblique classiﬁcation

of the neural networks with one hidden layer. Eclec-

tic method is the combination of the previous two

methods. An example of this method is (Keedwell

et al., 2000) in which they suggest a method to dis-

cover trends in large datasets using a neural network

as a black box to discover knowledge, but at the same

Exact and Approximate Rule Extraction from Neural Networks with Boolean Features

425

time examines the weights by pruning and clustering

the activation values of the hidden units. Control pa-

rameters have been used to analyse the data for con-

trolling the probability of occurrence and the accuracy

of the rules.

Extracting rules using a decompositional ap-

proach is complex and large, where the time and

computation are the most important constraints of

the method. The pedagogical approach is potentially

faster because it does not analyse the weights or in-

ternal structure of the neural network, but the most

important disadvantage is that it is less likely to ﬁnd

all the correct rules that describe the behaviour of the

neural network. The eclectic approach is slower but

more precise because it combines the two approaches

(Augasta and Kathirvalavakumar, 2012).

One of the most common methods to extract rules

from non-rule based classiﬁers is to produce decision

trees, corresponding to rules of the form of i f ...then.

The tree is the model, the leaves are classes, and the

branches represent the sequence of features that lead

to that class (Ardiansyah et al., 2016). The deci-

sion tree family of classiﬁers can capture rules that

can be represented using several forms that can be

understood by humans as explained in (Bondarenko

et al., 2017). If-Then / If-Then-Else rules contain an

“i f ” condition, potentially over a number of logical

operands such as conjunction, disjunction, and nega-

tion, followed by a “then” that indicates a class. An

example of an “i f ...then...else” rule is: i f (a

< x

) and (a

< x

< a

) then ClassA else ClassB.

M-of-N rules make a decision for only one class for

which M rules must be covered from a full set of

N rules, and these rules can be more compact than

“i f ...then” rule sets. Oblique rules / multi-surface

method tree have rules which separate a space by us-

ing planes, and this allows a data point to be cat-

egorised as belonging to a speciﬁc class. Equation

rules are similar to oblique rules, but using non-linear

equations to separate spaces. Fuzzy rules are sim-

ilar to “i f ...then” rules, but dealing with fuzzy sets

and an underlying many-value fuzzy logic. Here, the

black box, pedagogical approach with Boolean func-

tions acting the role of the decision tree rules is taken.

2.2 Minimising Boolean Expression

It is often useful to ﬁnd a compact representation

for a Boolean function. A minimal representation of

a Boolean expression is simpler to understand and

write, as well as less prone to error in interpreta-

tion. Importantly, a minimal representation can be

more effective and efﬁcient when implemented in ex-

periments (Rudell, 1986). Therefore, minimising a

Boolean expression to ﬁnd a representation equiva-

lent to the original expression but of a minimum size,

is considered here.

Minimisation can be done in several ways depend-

ing on the number of variables. There are several

common methods used to minimise expressions. Kar-

naugh Maps (Karnaugh, 1953) are a graphical way

to minimising a Boolean expression. Taking a truth

table of the expression as a matrix, then eliminat-

ing all the complementary pairs, results in a min-

imised Boolean expression. This method is effective

for small number of variables, but becomes more dif-

ﬁcult for larger numbers of variables. Manipulating

expressions using the rules and theories of Boolean

algebra might also be used, but again these methods

do not scale well. The Tabular (or Quine-McCluskey)

Method is a more efﬁcient method of calculating Kar-

naugh Maps and can be practical when minimising

expressions that contain larger numbers of variables

(Manojlovic, 2013). Reduced Ordered Binary Deci-

sion Diagrams (ROBDDs) (Bryant, 1992) place an

order on the variables of a Boolean function, and

then represent this function as a graph structure, giv-

ing a canonical, non-redundant representation of the

Boolean function, given the variable ordering. The

Tabular Method will be used in this approach.

2.3 Cross-Site Scripting

Cross-Site Scripting (XSS) is a type of attack target-

ing web applications, ranked by OWASP as one of

the top 10 attacks (OWASP, 2017). XSS is standardly

prevented from being executed through good coding

practice, using sanitization and escaping to prevent

untrusted content being interpreted as code (Wein-

berger et al., 2011). Parser-level isolation provides an

alternative, conﬁning user input data during the life-

time of the application (Nadji et al., 2009). Black-

lists are viewed as easy to circumvent and these ap-

proaches are preferred (Weinberger et al., 2011).

Machine learning techniques have been applied

to prevent XSS attacks. An early approach (Likar-

ish et al., 2009) evaluates ADTree, SVM, Naive

Bayes, and RIPPER classiﬁers by tracking the sym-

bols that appear in malicious and benign scripts, and

achieved precision of up to 92%. Another approach,

(Wang et al., 2013), extracts features used in ma-

licious scripts much more than benign, such as the

DOM-modifying functions and the eval function; this

method achieved accuracy rate of up to 94.38%. Fur-

thermore, in (Mereani and Howe, 2018a) a number

classiﬁers were evaluated: SVM with linear and poly-

nomial kernels, k-NN and Random Forest. Using a

k-NN classiﬁer achieved high accuracy results up to

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

426

99.75%, with precision rate up to 99.88%. Here the

extracted features depend on the occurrence or not

of a syntactic element within a script. A neural net-

work classiﬁer was evaluated in (Mereani and Howe,

2018b) to prevent XSS attacks by using ensemble and

cascading techniques and the results gave a very high

accuracy of up to 99.80% in the base level which their

feature groups used directly, and 99.89% at the meta

level where the features are the outputs of base level.

As well as in scripting, there is emerging interest

in using neural networks to detect malware in exe-

cutables, for instance, in (Rhode et al., 2017) a recur-

rent neural network is used to detect malicious exe-

cutables at execution time with 93% accuracy.

3 METHODOLOGY

This section describes the dataset used in the exper-

iments, the approach to selecting features to build

analyses with, and the training of neural networks.

The aim of this work is to ﬁnd Boolean functions as

rules extracted from the neural networks, which can

be used as classiﬁers. The approach to extracting a

Boolean function from a neural network is given, both

for exact rule extraction, and for a series of approxi-

mations to a network.

3.1 Datasets

The current work uses the dataset from (Mereani and

Howe, 2018b), with the training set augmented with

addition ﬁles from CSIC 2010 (Gim

enez et al., 2010)

(with 152 malicious instances and 3971 benign in-

stances). The purpose of increasing the dataset is to

cover more types of scripts to extract more precise

rules. The classiﬁers are to determine whether or not

text entered into a web application represents a cross-

site script. Hence the dataset consists of 43,218 ﬁles,

of which 28,068 labelled as benign and 15,150 la-

belled as malicious. Note that 9,068 of the benign

scripts are plain text from (Wang et al., 2011). These

are then divided into a training set of 19,122 instances

(5,150 malicious and 13,972 benign) and a testing set

of 24,096 instances (10,000 malicious and 14,096 be-

nign), with no overlap between the training and test-

ing datasets.

3.2 Selected Features

The starting point of this work is to abstract the in-

put into the same 62 features as used in (Mereani and

Howe, 2018b). These are divided into two groups,

alphanumeric and non-alphanumeric features. Rather

than working with these features immediately without

further reﬂection as in (Mereani and Howe, 2018b),

here the features have been ranked by using Algo-

rithm 1 (MathWorks, 2019). The method selects the

most powerful features in a sequential feature selec-

tion. This method works by minimising over all fea-

ture subsets, which uses the deviance and chi-square

to ﬁnd the most powerful features. The deviance is

twice the difference between the log likelihood of

that model and the saturated model, and the inverse

of the chi-square with degrees of freedom is used to

set the termination tolerance parameter. The applica-

tion of the ranking algorithm on the feature set shows

that only 34 features need be used, and the ranking

of these selected features in order of effectiveness is

given in Table 1. The key observation of these fea-

tures is that they are all Boolean valued, allowing the

exploitation of this additional 0/1 valued structure.

Algorithm 1: Ranking Features Algorithm.

Input: Original features set;

Start with empty features subset;

Feature = Sequential Feature Selection;

while (Deviance > Chi-Square) do

Feature Subset = Add feature to selected

feature subset;

Feature = Sequential Feature Selection;

end

Table 1: Selected Features.

No. Features No. Features

1 Alert 18 %

2 < 19 (&lt)

3 { 20 @

4 ? 21 Onload

5 ! 22 StringfromCharCode

6 JS File 23 :

7 HTTP 24 \

8 - 25 ]

9 ’ 26 (

10 ; 27 ‘

11 & 28 Img

12 , 29

13 Src 30 ==

14 Space 31 /

15 &# 32 Onerror

16 Eval 33 //

17 . 34 iframe

3.3 Classiﬁer Optimisation

Feed forward neural network classiﬁers were built us-

ing the features from Table 1. The classiﬁers were

Exact and Approximate Rule Extraction from Neural Networks with Boolean Features

427

built using a single hidden layer, and the number of

neurons (units) within the network is set to be 10

hidden units. The train function updates the weight

and bias values and was optimised by setting it to be

”trainbr,” which is used to minimise a combination

of squared errors and weights. Two neural networks

were built: one using all 34 features, which is viewed

as the best network, the one from which rules are to

be extracted, and the other using the top 16 features,

which will be used for comparison, evaluation and

discussion.

3.4 Neural Networks and Boolean

Functions

Observe that a neural network each of whose input

features is Boolean, and whose output is a Boolean

value, is precisely equivalent to a Boolean function.

Enumerating each possible input, and calculating the

corresponding output results in the truth table for this

Boolean function. Hence, the neural network can be

replaced by this Boolean function, resulting in a rule

based system, each of whose decisions is explainable

and auditable. In the current study, the feature set is

Boolean, therefore this approach applies. However,

whilst for a low number of features this rule extrac-

tion technique might be applied directly, the number

of potential inputs grows exponentially, and the prob-

lem quickly becomes infeasible.

3.5 Sampling

The key neural network in this work is the one trained

over a feature space with 34 features. This provides

an exemplar case for where the Boolean function de-

ﬁned is too large to generate from the network. De-

spite this, there is motivation to ﬁnd a Boolean func-

tion that can be used in place of the neural network.

The approach taken is to sample the neural network

and use this sample to build a Boolean function; this

Boolean function then provides an approximation of

the original function. The idea is to ﬁx a number of

features for which producing Boolean function via a

truth table is feasible and to determine what value the

function should take by interrogating the neural net-

work with the full feature set. For example, suppose

it is determined that considering 4 features will result

in a truth table that can be feasibly constructed. Then

the four highest ranking features (in Table 1) will pro-

vide the entries for the truth table. For a row of the

truth table, the values of these features is ﬁxed, and

then extended with values for the remaining 30 fea-

tures to give an input to the neural network, which is

then queried and the result noted. This is done re-

peatedly and from the resulting sample the most fre-

quently occurring result is the entry in the truth table.

Whilst the training dataset is relatively large, with

19,112 scripts, this is still very small compared to the

possible inputs to the neural network. This means

that whilst the neural network learns from its training

set, the generalisation is not necessarily great enough

that every input to the neural network is equally mean-

ingful. That is, a random sampling extending the ﬁxed

values might not give a good results, since it might

not match the shape of likely inputs. Indeed, this was

observed in development, with inputs holding the de-

fault value dominating. In order to counteract this,

the extensions were generated from the training set,

with a random selection of instances from the train-

ing set being selected (with the full 34 features), and

these being used for sampling the neural network with

the ﬁxed features replacing the corresponding feature

values.

Algorithm 2 speciﬁes the sampling method. Here,

the input to the algorithm is L (an integer) the number

of ﬁxed features, NN a trained neural network (in this

case with 34 features) and Sample a random selection

from the training set of inputs to the neural network

(in this work consisting of 1024 inputs). A truth ta-

ble, TT, for the ﬁxed features, with undeﬁned output

values, is constructed by buildInitTruthTable. Each

row of this truth table is considered in turn. The val-

ues of the row of TT are substituted into each element

of Sample leading to an input which is passed to the

neural network NN for classiﬁcation. If the result is

classiﬁcation as malicious the a counter for malicious

instances, malicious count is incremented, otherwise,

benign count is incremented. Once each element of

Sample has been considered, a comparison between

the two counts is made, and the output column of the

truth table TT is populated with 0 if most instances are

malicious, and 1 otherwise.

This work investigates successive approximations,

with a varying number of ﬁxed features: 1, 2, 4, 8, 10,

12 and 16 features. In order to sample the 34 feature

neural network, 1024 cases from training dataset were

used as the basis for the samples. As described above,

the entry for each row of truth table is simply the most

common verdict returned by the neural network being

approximated.

3.6 Extracting Rules

After labelling all rows in the truth table, each row can

be considered to be a rule that describes one class. To

give a more succinct set of rules, the Boolean func-

tion can be minimised (Schwender, 2007) resulting in

simpliﬁed expressions. The minimised Boolean func-

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

428

Algorithm 2: Sampling Method Algorithm.

Input: L ∈ N, NN, Sample;

TT = buildInitTruthTable(L);

for row in TT do

malicious count = 0;

benign count = 0;

for s in Sample do

input = substitute(row, s);

result = NN(input) ;

if result == malicious then

malicious count ++;

else

benign count ++;

end

if malicious count > benign count then

TT[row] = 0 ; \\Malicious

else

TT[row] = 1 ; \\Benign

end

tions are then evaluated as classiﬁers. For minimising

Boolean functions “Logic Friday” (Rickmann, 2012)

has been used which uses the Tabular Method as a

minimisation algorithm.

4 RESULTS

In the experiments, MatLab 2018b was used to build

the neural networks, and to ﬁnd the truth tables based

on these neural networks. This was done using vari-

ous numbers of ﬁxed features: 1, 2, 4, 8, 10, 12, and

16. The extracted truth tables deﬁned a set of rules

acting as a classiﬁer approximating the original neu-

ral network, and these rule sets were then reduced to

a more compact representation using “Logic Friday”

(Rickmann, 2012).

4.1 Neural Networks

Table 2 gives the performance of the neural network

classiﬁer, which was trained using the full 34 features,

and tested using the testing dataset. Evaluation uses

the confusion matrix, along with Accuracy, Precision,

Sensitivity, and Speciﬁcity measures. This network is

the one from which rules are extracted, giving a series

of approximations.

For later comparison purposes, Table 3 repeats

this evaluation, but this time showing the performance

of a neural network classiﬁer created using just the

16 highest ranked features. For this network, the

Boolean function that the network deﬁnes can be pre-

cisely extracted and Table 4 shows the number of the

rules that result from constructing the truth table for

the 16 features, along with the number of rules that

classify scripts as benign after minimisation is applied

(hence any script whose features do not match a rule

for benign is malicious).

Table 2: Neural Network Classiﬁer Performance Using 34

Features.

Accuracy 99.88 Confusion Matrix

Precision 99.98 M B

Sensitivity 99.75 M 9998 8

Speciﬁcity 99.98 B 25 14071

Table 3: Neural Network Classiﬁer Performance Using 16

Features.

Accuracy 99.78 Confusion Matrix

Precision 99.94 M B

Sensitivity 99.53 M 9994 6

Speciﬁcity 99.95 B 47 14049

Table 4: Classiﬁer Labelling Using 16 Feature.

Features Malicious Benign Minimised

Classifer 41,549 23,987 2,560

4.2 Rule Extraction

The rules were extracted from the neural network

trained on 34 features by applying the sampling

method for each row in the truth table, hence the num-

ber of extracted rules is equal to (2

Features

), where

each row describes one rule. This process was re-

peated for 1, 2, 4, 8, 10, 12, and 16 features. Each of

these gives an approximation to the neural network,

and the purpose of this repetition is to observe the

number of rules that are extracted and the accuracy

of the results on the testing dataset.

Tables 5,..., 11 give the results of testing the rules

extracted from the 34 feature neural network, ap-

proximating with 1, 2, 4, 8, 10, 12 and 16 features.

Again, the evaluation is given in terms of the confu-

sion matrix, and the Accuracy, Precision, Sensitivity

and Speciﬁcity measures.

Table 5: Results of Using 1 Feature.

Accuracy 91.96 Confusion Matrix

Precision 80.70 M B

Sensitivity 99.92 M 8070 1930

Speciﬁcity 87.95 B 6 14090

Table 12 summarises the number of rules for each

class by using the various numbers of selected fea-

Exact and Approximate Rule Extraction from Neural Networks with Boolean Features

429

Table 6: Results of Using 2 Features.

Accuracy 91.96 Confusion Matrix

Precision 80.70 M B

Sensitivity 99.92 M 8070 1930

Speciﬁcity 87.95 B 6 14090

Table 7: Results of Using 4 Features.

Accuracy 98.95 Confusion Matrix

Precision 97.54 M B

Sensitivity 99.92 M 9754 246

Speciﬁcity 98.28 B 7 14089

Table 8: Results of Using 8 Features.

Accuracy 98.13 Confusion Matrix

Precision 95.62 M B

Sensitivity 99.87 M 9562 438

Speciﬁcity 96.98 B 12 14084

Table 9: Results of Using 10 Features.

Accuracy 99.15 Confusion Matrix

Precision 98.00 M B

Sensitivity 99.96 M 9800 200

Speciﬁcity 98.60 B 3 14093

Table 10: Results of Using 12 Features.

Accuracy 99.82 Confusion Matrix

Precision 99.62 M B

Sensitivity 99.96 M 9962 38

Speciﬁcity 99.73 B 3 14093

Table 11: Results of Using 16 Features.

Accuracy 99.90 Confusion Matrix

Precision 99.94 M B

Sensitivity 99.82 M 9994 6

Speciﬁcity 99.95 B 18 14078

tures. The ﬁnal column gives the number rules that

classify the input as benign after minimisation (hence,

any input not matching one of these rules is classiﬁed

as malicious).

4.3 Timing

The number of extracted rules grows exponentially

with the number of features used for approximation.

Therefore, it is important to take into account the time

taken by the proposed method. Table 13 gives the

time taken for each approximation, including the ex-

traction of the rules, and their minimisation.

Table 12: Number of Rules for Selected Features.

Features Malicious Benign Minimised

1 Feature 1 1 1

2 Features 2 2 1

4 Features 7 9 3

8 Features 100 156 29

10 Features 384 640 62

12 Features 1,560 2,536 229

16 Features 39,792 25,744 2,488

Table 13: Timing of Rule Extraction from the Classiﬁer.

Features Interval

1 Feature 18 sec

2 Features 37 sec

4 Features 120 sec

8 Features 390 sec

10 Features 7,846 sec

12 Features 30,598 sec

16 Features 482,618 sec

5 DISCUSSION

The key result in this paper is that presented in Ta-

ble 11. This table gives the evaluation of a Boolean

function over 16 variables/features as a rule-based

classiﬁer, where the Boolean function has been ex-

tracted from the neural network over 34 features eval-

uated in Table 2. The performance of this rule-based

classiﬁer matches (in fact, slightly betters) that of the

neural network that it is modelling, with 99.90% ac-

curacy and 99.94% precision, demonstrating that rule

extraction has been successfully accomplished. For

comparison, a neural network was training using the

same 16 features, with the results presented in Ta-

ble 3, and again the extracted rule-based Boolean

function classiﬁer in Table 11 performs slightly bet-

ter than this neural network.

A series of approximations have been built and

evaluated in Tables 5,.., 11, using an increasing num-

ber of features. The number of rules both before and

after minimisation is given in Table 12. As might

be expected, as the number of features increases, the

number of rules (after minimisation) increases too,

and the performance of the resulting classiﬁers im-

proves. The improvements are not necessarily mono-

tonic, but the pattern is clear. The improvements

come at some cost – as can be seen in Table 13, with

the current approach to implementation, the time to

build the Boolean functions increases exponentially,

with the best approximation using 16 features tak-

ing more than ﬁve days of computation. If compar-

ing against the Boolean function extracted from the

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

430

16 feature neural network, the number of minimised

rules is comparable, but it should be noted that it is

much faster to extract the rules from the small net-

work, since sampling is not required (and also note

that the resulting rules are a precise description of the

neural network).

One motivation for this investigation is to extract

rule-based systems, where some level of explainable

AI is produced. That is, for any classiﬁcation, the rea-

soning can be described, allowing decision making to

be auditable. The approximations given in this work

give such auditable decisions. The successive approx-

imations show that relatively good performance can

be achieved with the use of only a small number of

features. That the sampling approach gives approx-

imations with some degree of noise is illustrated by

the anomalous 8 feature case, where the introduc-

tion of feature 7, URL addresses, leads to some ad-

ditional misclassiﬁcations, compared to the courser 4

feature classiﬁer. It should also be noted that the very

course 1 feature classiﬁer still gives useful result, with

80.70% precision. The reason for this result is that the

highest ranking feature is the use of ”Alert” within

the script and that a high proportion of attacks in the

database use this, whilst it is rarely used in benign

scripts. This ﬁrst feature is very powerful. This obser-

vation (whilst not surprising to the authors) is a good

illustration of XAI in action, where the rule-based

system has made the explanation explicit. However,

it should be noted that the best approximation still re-

quires thousands of rules even after minimisation, and

whilst this makes decision making auditable, it is less

clear that each individual decision can be interpreted

by a human user, in the context of the larger number

of rules.

As noted in the methodology, the current approach

requires a double use of the training set, ﬁrstly to train

the neural network, and secondly to guide the sam-

pling approach used in the approximation of the neu-

ral network by a Boolean function. However, given

the size of the Boolean function described by the

trained neural network, some kind of guidance seems

inevitable in a black box approach to approximation.

The black box approach has worked, resulting in suc-

cessfully extracting rules in form of (i f ...then...else)

in order to distinguish malicious and benign scripts

without delving deeper into the inner structure of the

neural network classiﬁer.

6 CONCLUSION

This paper demonstrates the ability to perform rule

extraction from a neural network classiﬁer, where the

feature space is Boolean, the result being a Boolean

function initially described by a truth table, then min-

imised to a more compact representation. Differ-

ent levels of approximation were investigated. The

rules extracted provide good results in classiﬁcation

of scripts as malicious or benign, with testing demon-

strating up to 99.94% accuracy and precision rate up

to 99.90% using a 16 feature approximation of the 34

feature neural network. These results are as good as

those for the initial neural network, though the current

implementation takes a long time to compute the ap-

proximation (a single expensive rule extraction is not

in itself problematic, however it limits the scalability

of the approach, and means that it cannot be used for

rapid updates of the rules). The number of rules ex-

tracted grows with the number of features used in the

approximation. As discussed in Section 5, this means

that these rules are auditable – it is easy to look up

the reasoning for any given classiﬁcation – whilst it

remains to be investigated whether a human user of

the rule set views thousand of rules (each easily inter-

preted by itself) as being humanly intelligible.

It is possible to use the proposed black box

method of extracting rules from the classiﬁers for

other kinds of classiﬁcation, and for other problems

where the features are Boolean. Future work is to in-

vestigate this, as well as how this approach might be

generalised to features which are not Boolean valued,

by piecewise approximation, or otherwise. Further re-

ductions of the rules (perhaps using BDDs), in par-

ticularly further approximation to give more compact

rules sets will also be explored.

In conclusion, a process following XAI principles

of giving an interpretation of a black box classiﬁer in

a form of rules that are understandable to humans has

be shown to lead to a successful rule based outcome.

REFERENCES

Ardiansyah, S., Majid, M. A., and Zain, J. M. (2016).

Knowledge of extraction from trained neural network

by using decision tree. In 2016 2nd International Con-

ference on Science in Information Technology (IC-

SITech), pages 220–225. IEEE.

Augasta, M. G. and Kathirvalavakumar, T. (2012). Rule ex-

traction from neural networks—a comparative study.

In International Conference on Pattern Recognition,

Informatics and Medical Engineering (PRIME-2012),

pages 404–408. IEEE.

Bach, S., Binder, A., Montavon, G., Klauschen, F., M

uller,

K.-R., and Samek, W. (2015). On Pixel-Wise Ex-

planations for Non-Linear Classiﬁer Decisions by

Layer-Wise Relevance Propagation. PLoS ONE,

10(7):e0130140.

Exact and Approximate Rule Extraction from Neural Networks with Boolean Features

431

Baehrens, D., Schroeter, T., Harmeling, S., Kawanabe, M.,

Hansen, K., and M

uller, K.-R. (2010). How to Ex-

plain Individual Classiﬁcation Decisions. Journal of

Machine Learning Research, 11:1803–1831.

Baesens, B., Martens, D., Setiono, R., and Zurada, J. M.

(2011). Guest Editorial White Box Nonlinear Predic-

tion Models. IEEE Transactions on Neural Networks,

22(12):2406–2408.

Bondarenko, A., Aleksejeva, L., Jumutc, V., and Borisov, A.

(2017). Classiﬁcation Tree Extraction from Trained

Artiﬁcial Neural Networks. Procedia Computer Sci-

ence, 104:556–563.

Breiman, L. et al. (2001). Statistical modeling: The two cul-

tures (with comments and a rejoinder by the author).

Statistical Science, 16(3):199–231.

Bryant, R. E. (1992). Symbolic Boolean Manipulation with

Ordered Binary Decision Diagrams. ACM Computing

Surveys, 24:293–318.

Cho, K., Van Merri

enboer, B., Gulcehre, C., Bahdanau,

D., Bougares, F., Schwenk, H., and Bengio, Y.

(2014). Learning Phrase Representations using RNN

Encoder-Decoder for Statistical Machine Translation.

In Empirical Methods in Natural Language Process-

ing, page 1724–1734. Association for Computational

Linguistics.

Craven, M. W. and Shavlik, J. W. (1996). Extracting tree-

structured tepresentations of trained networks. In

Advances in Neural Information Processing Systems,

pages 24–30. MIT Press.

Etchells, T. A. and Lisboa, P. J. (2006). Orthogonal search-

based rule extraction (OSRE) for trained neural net-

works: a practical and efﬁcient approach. IEEE trans-

actions on Neural Networks, 17(2):374–384.

Fayyad, U., Piatetsky-Shapiro, G., and Smyth, P.

(1996). From data mining to knowledge discovery in

databases. AI magazine, 17(3):37–37.

Gim

enez, C. T., Villegas, A. P., and Mara

on, G.

A. (2010).

HTTP data set CSIC 2010. Information Security In-

stitute of CSIC (Spanish Research National Council).

Gunning, D. (2016). Explainable Artiﬁcial Intelligence

(XAI). Technical Report DARPA/I20, Defense Ad-

vanced Research Projects Agency.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Computer Vi-

sion and Pattern Recognition, pages 770–778. IEEE.

Karnaugh, M. (1953). The map method for synthesis

of combinational logic circuits. Transactions of the

American Institute of Electrical Engineers, Part I:

Communication and Electronics, 72:593–599.

Keedwell, E., Narayanan, A., and Savic, D. (2000). Creat-

ing rules from trained neural networks using genetic

algorithms. Internation Journal of Computers, System

and Signal, 1(1):30–42.

Likarish, P., Jung, E., and Jo, I. (2009). Obfuscated ma-

licious Javascript detection using classiﬁcation tech-

niques. In Malicious and Unwanted Software (MAL-

WARE), pages 47–54. IEEE.

Mahendran, A. and Vedaldi, A. (2015). Understand-

ing Deep Image Representations by Inverting Them.

In Computer Vision and Pattern Recognition, pages

5188–5196. IEEE.

Manojlovic, V. (2013). Minimization of Switching Func-

tions using Quine-McCluskey Method. International

Journal of Computer Applications, 82(4):12–16.

Martens, D., Baesens, B., and Van Gestel, T. (2009). De-

compositional rule extraction from support vector ma-

chines by active learning. IEEE Transactions on

Knowledge and Data Engineering, 21(2):178–191.

MathWorks (2019). Feature selection. https://uk.

mathworks.com/help/stats/feature-selection.html.

Accessed: 11/3/2019.

Mereani, F. A. and Howe, J. M. (2018a). Detecting Cross-

Site Scripting Attacks Using Machine Learning. In

International Conference on Advanced Technologies

and Applications Intelligent Systems and Computing,

pages 200–210. Springer.

Mereani, F. A. and Howe, J. M. (2018b). Preventing Cross-

Site Scripting Attacks by Combining Classiﬁers. In

Proceedings of the 10th International Joint Confer-

ence on Computational Intelligence - Volume 1, pages

135–143. SciTePress.

Nadji, Y., Saxena, P., and Song, D. (2009). Document Struc-

ture Integrity: A Robust Basis for Cross-site Scripting

Defense. In Network and Distributed System Security

Symposium. Internet Society.

Nguyen, A., Yosinski, J., and Clune, J. (2016). Multi-

faceted Feature Visualization: Uncovering the Dif-

ferent Types of Features Learned by Each Neu-

ron in Deep Neural Networks. arXiv preprint

arXiv:1602.03616.

OWASP (2017). OWASP Top 10 - 2017 rc1.

https://www.owasp.org. Accessed: 7/6/2017.

Rhode, M., Burnap, P., and Jones, K. (2017). Early

Stage Malware Prediction Using Recurrent Neural

Networks. Computers and Security, 77:578–594.

Rickmann, S. (2012). Logic Friday (version 1.1.4)[com-

puter software]. https://web.archive.org/web/

20131022021257/http://www.sontrak.com/. Ac-

cessed: 24/11/2018.

Rudell, R. L. (1986). Multiple-valued logic minimiza-

tion for PLA synthesis. Technical Report UCB/ERL

M86/65, University of California, Berkeley.

Saito, K. and Nakano, R. (1988). Medical diagnostic ex-

pert system based on PDP model. In Proceedings of

IEEE International Conference on Neural Networks,

volume 1, pages 255–262.

Schwender, H. (2007). Minimization of Boolean Expres-

sions using Matrix Algebra. Technical report, Tech-

nical Report//Sonderforschungsbereich 475, Kom-

plexit

atsreduktion in Multivariaten Datenstrukturen,

Universit

at Dortmund.

Setiono, R. and Liu, H. (1995). Understanding Neural Net-

works via Rule Extraction. In IJCAI, volume 1, pages

480–485.

Setiono, R. and Liu, H. (1997). NeuroLinear: From neural

networks to oblique decision rules. Neurocomputing,

17(1):1–24.

Taha, I. and Ghosh, J. (1996). Three techniques for extract-

ing rules from feedforward networks. In Intelligent

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

432

Engineering Systems Through Artiﬁcial Neural Net-

works, pages 23–28. ASME Press.

Thrun, S. B. (1993). Extracting Provably Correct Rules

from Artiﬁcial Neural Networks. Technical report,

University of Bonn.

Tsukimoto, H. (2000). Extracting rules from trained neu-

ral networks. IEEE Transactions on Neural Networks,

11(2):377–389.

Wang, H., Lu, Y., and Zhai, C. (2011). Latent aspect rat-

ing analysis without aspect keyword supervision. In

Proceedings of the 17th ACM SIGKDD International

Conference on Knowledge Discovery and Data Min-

ing, KDD ’11, pages 618–626, New York, NY, USA.

ACM.

Wang, W.-H., Lv, Y.-J., Chen, H.-B., and Fang, Z.-L.

(2013). A Static Malicious JavaScript Detection Us-

ing SVM. In Proceedings of the International Confer-

ence on Computer Science and Electronics Engineer-

ing, volume 40, pages 21–30.

Weinberger, J., Saxena, P., Akhawe, D., Finifter, M., Shin,

R., and Song, D. (2011). A Systematic Analysis of

XSS Sanitization in Web Application Frameworks. In

European Symposium on Research in Computer Secu-

rity, volume 6879 of Lecture Notes in Computer Sci-

ence, pages 150–171. Springer.

Exact and Approximate Rule Extraction from Neural Networks with Boolean Features

433
