A Fuzzy Logic Programming Environment for Recycling Facility
Selection
Esra Çakir
a
and H. Ziya Ulukan
Faculty of Engineering and Technology, Department of Industrial Engineering, Galatasaray University, İstanbul, Turkey
Keywords: Fuzzy Logic Programming, Fuzzy Prolog, Bousi~Prolog, Recycling Facility Selection, Waste Collection
Center Selection.
Abstract: Recycling of wastes is a crucial subject for a sustainable environment. One of the main problem in this area
is the appropriate location of the collection centers and recycling facilities. These facilities can be paired
according to the criteria such as: distance, cost, type of waste. In this paper, fuzzy linguistics Prolog is used
to find importance weights of selection criteria and to match facilities for decision making process.
Bousi~Prolog is a fuzzy Prolog that enables working with both fuzzy linguistic and linguistic tools to guide
the Prolog systems towards computing with paradigm phrases that can be very helpful to the linguistic
resources.
1 INTRODUCTION
Logic programming has been commonly used for
information representation, expert system creation or
deductive database in the field of Artificial
Intelligence. It has, however, lost ground in the
Artificial Intelligence scene in latest years. Because
in real-life problems, expressions are not precise, they
are approximate, even blurred. Fuzzy Logic
Programming (FLP) is a research area which
investigates how to introduce fuzzy logic concepts
into logic programming aiming to deal with the
imprecision and/or vagueness existing in the real
world. The main objectives of this new language are
to support flexible query answering, to allow the
manipulation of fuzzy sets and to incorporate other
features with which it is possible to easily handle
imprecise information using declarative techniques.
As an extension of Prolog, the most commonly
used logic programming language, was proposed. In
order to preserve most of its syntactic characteristics,
it will find the greatest distinctions in several
particular structures and in their resolution and
unification algorithms. For these purpose, the
language was renamed as Bousi~Prolog (abbreviated
BPL), with Bousi being the Spanish abbreviation for”
Unificación BOrrosa por SImilitud."
a
https://orcid.org/0000-0003-4134-7679
The outline of the paper is as follows. Section II
includes literature review. Logic programming
language Prolog and Bousi~Prolog, which is
formalized as a transition system based on a
proximity-based unification relation, is presented in
Section III. Waste facilities were chosen as the
application area, matching and criteria weighting was
made between waste collection centers and recycling
facilities by using Bousi~Prolog in Section IV.
Finally, we give our conclusions and future research
lines in Section V.
2 LITERATUR REVIEW
Bousi~Prolog is an extension of the standard Prolog
language that implements a weak unification
algorithm based on proximity relations, that is,
reflexive and symmetric binary fuzzy relations
(Dubois et al., 1988, Fontana and Formato, 2002
Orchard, 1998). Bousi~Prolog has already been used
in interesting real applications such as text cataloging
(Cayrol et al., 1982), knowledge discovery (Fontana
et al., 1999) and linguistic feedback in computer
games (Formato et al., 2000), (Julian et al., 2009).
A similarity relation is an extension of the crisp
notion of equivalence relation and it can be useful in
any context where the concept of equality must be
Çakir, E. and Ulukan, H.
A Fuzzy Logic Programming Environment for Recycling Facility Selection.
DOI: 10.5220/0008397503670374
In Proceedings of the 11th International Joint Conference on Computational Intelligence (IJCCI 2019), pages 367-374
ISBN: 978-989-758-384-1
Copyright
c
2019 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
367
weakened. In (Sessa, 2002) a new modified version of
the Linear resolution strategy with Selection function
for Definite clauses (SLD resolution) is defined,
which is named similarity-based SLD resolution (or
Weak SLD resolution: WSLD). This operational
mechanism can be seen as a variant of the SLD
resolution procedure where the classical unification
algorithm has been replaced by the weak unification
algorithm formally described in (Sessa, 2002) (and
reformulate in terms of a transition system in (Julian
and Rubio, 2006)) (Julian and Rubio, 2010,
Mukaidono et al., 1989).
The weak unification algorithm implemented in
Bousi~Prolog is an extension of Martelli and
Montanari’s unification algorithm for syntactic
unification (Julian et al., 2009, Julian and Rubio,
2009, Lee, 1972). Such algorithm extends the classical
one by relaxing the strict true/false result of
unification and replacing it by a real number in the unit
interval [0,1], which indicates the approximation
degree of the unification. Informally, the weak
unification algorithm states that two expressions
f(u(1)…u(n)) and g(u(1)…u(n)) weakly unify, if the
root symbols f and g are approximate and each
argument u(i) and v(i) weakly unify, with i
{1,...,n}.
Hence, if there is a syntactic clash between two
different expressions, the weak unification algorithm
does not produce a failure but a success with a certain
approximation degree. Notice that, Bousi~Prolog
computes substitutions as well as approximation
degrees (Julian et al., 2009).
Although Bousi~Prolog weak unification algorithm
generalizes the operating system provided in
(Mukaidono et al., 1989) and improves the language’s
expressive authority, some disadvantages emerge
when considering real-life information and knowledge
bases. As pointed out lately in (Alsinet and Godo,
1998), the weak unification maintains strict features of
the classical unification, such as the arity of the
predicate and function symbols. The weak unification
mechanism should therefore be relaxed as the
resemblance between two phrases should be
determined by the data contained in each expression
and it should not rely on either the arity or subterms
order.
3 METHODOLOGY
Classical Prolog is not able to represent and handle
the vagueness and/or imprecision that exists in the
real world in an explicit. To be sure,
dealing with vagueness and /or imprecision is crucial
in most application fields of Artificial Intelligence,
such as expert systems, fuzzy control, robotics,
computer vision, machine learning or data recovery.
Thus, enhancing these languages with new equipment
is essential (Julian and Rubio, 2009).
3.1 Prolog
Prolog is a fifth generation computer language family
used in artificial intelligence applications. It was
invented by Alain Colmerauer and his working group
at the University of Marseille Aix in France in the
early 1970s. It comes from the French
"Programmation en Logique" word. In the early
1980s, the studies conducted in order to ensure logic
can as a computer language have also intensified. The
interest in the subject has increased to a great extent
with the Japanese announcing the fifth generation
computer project in 1981.
Prolog is a tool that helps human beings in the
development of the necessary methods for defining
and solving the problem with its structure suitable for
logical and symbolic thinking.
Assume a fragment of a deductive database that
stores information about people and their preferences.
Under the question about whether somebody likes
tea, that person may answer: ‘I do not like’,
‘a little’, ‘so much’, ‘very much’.
%% FACTS
likes(ally, tea, a_little).
likes(jane, tea, very_much).
likes(kim, tea, so_much).
likes(ashley, tea, does_not).
%% RULES
drink(X,Y):-likes(X, Y, very_much).
In a standard Prolog system, if we ask about
people who will drink tea ‘‘?-drink(X,tea)’’,
only one answer is obtained: Yes, X=jane.
However, ally and kim also are reasonable
candidates to drink tea. Hence, if we are looking for a
flexible query answering procedure, more accurate to
the real world behaviour, ally and k im should be
appear as answers.
3.2 The Bousi~Prolog Programming
Language
BousiProlog is an extension of the standard Prolog
language. Its operational semantics is an adaptation of
FCTA 2019 - 11th International Conference on Fuzzy Computation Theory and Applications
368
the Selection-function driven Linear resolution for
Definite clauses. (SLD resolution) principle where
classical unification has been replaced by a fuzzy
unification algorithm based on proximity relations
defined on a syntactic domain. Hence,the operational
mechanism is a generalization of the similarity-based
SLD resolution principle (Sessa, 2002).
The BPL syntax is mainly the Prolog syntax but
enriched with a built-in symbol used for
describing proximity relations by means of what we
call a “proximity equation”. Proximity equations are
expressions of the form: “<symbol> ~ <symbol> =
<degree>.” (Julian and Rubio, 2010).
The BPL language makes use of two directives to
define and declare the structure of a linguistic variable
(Sessa, 2002): domain and fuzzy_set. The
domain directive allows to declare and define the
universe of discourse or domain associated to a
linguistic variable. The concrete syntax of this
directive is:
:-domain(Dom_Name(n,m,Magnitude)).
where, Dom_Name is the name of the domain, n
and m (with n < m ) are the lower and upper bounds of
the real subinterval [n,m], and Magnitude is the
name of the unit wherein the domain elements are
measured. For example, the directive :-
domain(age(0,100,years)). Defines a
domain with name age, whose values are numbers
(between 0 and 100) measured in years. The
fuzzy_set directive allows to declare and define a
list of fuzzy subsets (which are associated to the
primary terms of a linguistic variable) on a predefined
domain. The concrete syntax of this directive is:
:-fuzzy_set(Dom_Name,[FSS_1(a1,b1,c1
[,d1]),
...,
FSS_n(an,bn,cn[,dn]])).
Fuzzy subsets are defined by indicating their
name, FSS_1, and membership function type. At
this time, it is possible to define two types of
membership functions: either a trapezoidal function,
if four arguments are used for defining the fuzzy
subset or a triangular function, if three arguments are
used.
Once a domain and the fuzzy sets associated to the
primary terms have been declared, composite terms
may be generated through the following grammar:
<Term> ::= <Atomic_term> |
<Composite_term>
<Composite_term> ::=
<TModif>#<Atomic_term>
<TModif> ::= very | somewhat |
more_or_less | extremely
Consider the given example in subsection
3.1.Prolog, as BousiProlog allows to work with
linguistic dictionaries, a list of similar concepts for
the source concept “adjectivescould be
obtained by using WordNet::Similarity. This
list can be represented in BousiProlog by means of
a set of proximity equations.
%% PROXIMITY EQUATIONS
does_not~a_little=0.6.
a_little~very_much=0.3.
does_not~so_much=0.2.
so_much~very_much=0.7.
a_little~so_much=0.5.
The BousiProlog system answers ‘‘X=ally
with 0.3’’, ‘‘X=jane with 1.0’’ and
‘‘X=kim with 0.7’’. To obtain the first answer,
the BousiProlog system operates as follows: since
we have specified that a little is close to very much,
with degree 0.3, these two terms may unify “weakly”
with approximation degree 0.3, leading to the
unification of likes(ally, tea, a little)
and likes(X, tea, very much), with X=ally
and approximation degree 0.3; therefore, the assertion
drink(ally,tea) is stated with approximation
degree 0.3.
3.2.1 Approximate Reasoning
Approximate reasoning is basically the inference of
an imprecise conclusion from imprecise premises. In
this section we want to make a reflexion on fuzzy
inference, such as it was formalized by Zadeh (Zadeh,
1965, Zadeh, 1975), and how BousiProlog can deal
with this kind of reasoning.
Each granule of knowledge is represented by a
fuzzy set or a fuzzy relation on the appropriate
universe. The premises of an argument are expressed
as fuzzy rules and a fuzzy inference is a
generalization of modus ponens that can be
formalized as: “if x is F then y is G” and “x is F’”
then “y is G’”. Roughly speaking, x and y are
variables that takes values on ordinary sets U and W,
F and F’ are fuzzy subsets on U whilst G and G’ are
fuzzy subsets on W. There has been proposed several
methods to compute G’, though there is not consensus
A Fuzzy Logic Programming Environment for Recycling Facility Selection
369
as to which is the best. The method proposed by
Zadeh consists of identifying from F and G a fuzzy
relation, R on U and W, which has a consequence over
G’ on W (Julian and Rubio, 2010).
BousiProlog constructs a fuzzy relation over
the fuzzy domains involved in a BPL program. This
fuzzy relation is built at compile time. Afterwards, at
run time, it is used by the weak SLD resolution
procedure to infer an answer to a query. (Sessa, 2002)
For instance, BousiProlog models the following
fuzzy inference in a very natural way: “if x is new
then x is fast” and “car-A is middle” then car-A is
somewhat fast”.
:-domain(age(0,100,years)).
:-fuzzy_set(age,[new(0,0,30,50),
middle(20,40,60,80),
old(50,80,100,100)]).
:-domain(speed(0,40,km/h)).
:-fuzzy_set(speed,[slow(0,0,15,20),
normal(15,20,25,40),
fast(25,30,40,40)]).
speed(X, fast) :- age(X, new).
age(car-A, middle).
Now, if we launch the goal “?- speed(car-
A, somewhat#fast)”, the BPL system answers
Yes with 0.375”.
3.2.2 Flexible Query Answering in
Reductive Database
Databases are elements of software that collect and
store data (which can be retrieved, added, updated or
removed by users). Because the data in the actual
globe is often permeated by vagueness and
inaccuracy, database systems should address this
issue. They should also allow flexible retrieval of
data. There are several approaches to fuzzy flexible
database. In this study we show how to implement a
fragment of a flexible database in the Prade-
Testemale (Prade and Testemale, 1984).
Below, we present a BPL program implementing a
fragment of a flexible deductive database in the style
of Prade and Testemale. That is, databases that
incorporate the notion of fuzziness by means of fuzzy
sets that may be used as attributes of a table. This
example shows a database fragment for a person who
is familiar with pharmacies in the city. This person
wants to find the pharmacy by preference (ie, close to
home).
%% DIRECTIVES declaring and defining
linguistic variables
%% (i.e., fuzzy sets)
%% Linguistic variable: distance
:-domain(distance,0,60,minutes).
:-fuzzy_set(distance,
[close(0,10,20,40),
medial(25,35,45,50),
far(40,45,50,60)]).
%% FACTS
%% Pharmacy table
%% pharmacy(Name, Street).
pharmacy(ph_1,st_1).
pharmacy(ph_2,st_2).
pharmacy(ph_3,st_3).
pharmacy(ph_4,st_4).
pharmacy(ph_5,st_5).
%% Distance table
%% distance(District, District,
Distance)
%% to home
distance(st_1, home,
somewhat#medial).
distance(st_2, home, more_or_less
#close).
distance(st_3, home, very#far).
distance(st_4, home, close).
distance(st_5, home, somewhat#far).
%% RULES
%% find(Pharmacy, Distance)
find(Pharmacy,Street, Distance):-
pharmacy(Pharmacy, Street),
distance(Street, home, Distance).
Now select find/2 (The number “2” means
there is two input for query “find”.) selects those
which may be considered close to home with a certain
degree. More precisely, if we launch the goal “?-
find(Pharmacy, st_1, close).”, we
obtain: Yes, Pharmacy = ph_1 with 0.3”.
This means that there is a pharmacy named “ph_1”
on the street named “st_1” and approximation
degree to home is 0.3. If we launch the goal “?-
find(Pharmacy, st_4, close).”, we
obtain: “Yes, Pharmacy = ph_4 with 1.0”.
This means that there is a pharmacy named “ph_4”
on the street named st_4” and approximation
degree to home is 1.0.
FCTA 2019 - 11th International Conference on Fuzzy Computation Theory and Applications
370
4 APPLICATION
Assume a flexible deductive database in style of
Prade and Testemale (Prade and Testemale, 1984)
storing information on fourteen recycling facilities
and three waste collection centers which have
properties such as cost, distance and energy
generation capacity. These properties are expressed in
fuzzy numbers. The Table 1 shows the fuzzy
expressions.
Table 1: Fuzzy Expressions of Criteria.
Cost
cheap
normal
expensive
(200,200,450
,600)
(300,450,650,
700)
(550,750,800,900)
Distance
close
medial
far
(0,0,30,80)
(20,45,70,90)
(50,85,110,120)
Energy
Generation
Capacity
fair
good
excellent
(0,0,1,3)
(2,5,7)
(6,8,9,10)
Cities where recycling facilities are located are
located in different places. The recycling costs of
these facilities are known. However, the energy
generation capacity of the facility is expressed by
using fuzzy numbers instead of crisp numbers for
reasons such as material and machine destruction.
Similarly, the distance of waste collection centers to
the zones is expressed in fuzzy numbers. These
relationships are shown in the Figure 1.
Our aim is to match waste collection center and
recycling facility according to cost, distance and
capacity. A BPL program code is prepared in
APPENDIX. Here is the query used to run the code.
%% GOAL EXAMPLE
% find (Facility, City, Collection,
Cost ,Distance , Capacity).
Now find/6” selects those facilities, which
may be considered “cheap”, “close” and
“excellent” to the “collection_no with a
certain degree. More precisely:
If we launch the goal ?- find(Facility,
City, Collection, Cost ,Distance
, Capacity).”, the answer is: Facility
= facility_1, City = city_A,
Collection = collection_1, Cost =
cost_400, Distance = medial,
Capacity = fair, With
approximation degree: 1.0”. This
means that the first match with the
approximation degree = 1.0 and this
is the properties of the match.
Figure 1: Facility locations and recycling costs.
If we write six criteria to our query, the query will
give us the degree of membership of this match.
For example, if we launch the goal ?-find
(facility_13, city_H,
collection_2, normal ,close ,
good).”, the answer is: “Yes. With
approximation degree: 0.92”.
Because we asked the code; Compare
facility_13 in city_H and
collection_2 according to
cheapness, closeness and good
energy capacity.
Also, we can find the best match of the degree of
membership according to the selected criteria.
For example, if we launch the goal ?-find
(Facility, City, collection_3,
expensive, medial, excellent.”, the
answer is: Facility = facility_7,
City = city_D, With approximation
degree: 0.82”. Because we asked the
code; find a Facility for match
with collection_3 according to
expensive cost, medial distance
A Fuzzy Logic Programming Environment for Recycling Facility Selection
371
and excellent energy capacity. So,
the answer is “Yes, i found facility_7
to match with approximation
degree: 0.82”.
These queries are based on criteria. In the last
question, if we make the distance “close
instead of “medial”, the approximation will be
different even if it matches the same facility. For
example; ?-find(Facility, City,
collection_3, expensive , close ,
excellent.”, the answer is: Facility =
facility_7, City = city_D, With
approximation degree: 0.517”.
Because we asked the code; find a
Facility for match with
collection_3 according to
expensive cost, close distance
and excellent energy capacity. So,
the answer is “Yes, i found facility_7
to match with approximation
degree: 0.517”.
If an irrelevant match is asked, the code answers
“No answers”. This means that the
approximation is zero. For example; ?-
find(Facility,City,collection_1,
expensive , far , fair.”, the answer
is: “No answers”. Because we asked the
code; find a Facility for match
with collection_1 according to
expensive cost, far distance and
fair energy capacity. There are no
suitable facilities for a match in these properties.
As a result, if we want to match waste collection
centers (collection_(1-2-3)) and
recycling facilities (facility_(1…14)) that
meet the criteria of "cheap", "close" and
"excellent", our query should be "?-find
(Facility, City, collection_ (1-
2-3), cheap, close, excellent).”.
The best match is ”collection_1 and
“facility_11” with the approximation
degree : 0.277. The outputs are shown in Table
2.
The advantage of using this program is to estimate the
weight of these criteria. Thanks to these queries,
weighting can change according to the changes in
criteria. An example is given below.
Example: Suppose we only have
“facility_2” and ”facility_13”, and all of
three collections. We want to match this waste center
with 2 recycling facilities in different regions. Let our
criteria be “cost”, “distance” and “energy
generation capacity” of the facility. In the
Table 3, the approximation degrees of the query "?
-find (facility (2-13), City,
collection_1-2-3), normal, medial,
good).” are given.
Table 2: Approximation degrees according to “cheap, close,
excellent” criteria.
Waste Collection Center
collection_1
collection_2
collection_3
Recycling
Facility
Facility_11
,city_F
Facility_11
,city_F
Facility_11
,city_F
Approxima
tion Degree
0,277
0,25
0,171
Table 3: Approximation degrees according to “normal,
medial, good” criteria.
Waste Collection Center
collection_1
collection_2
collection_3
facility
_2
1,0
0,3
0,436
facility_
13
0,405
0,4
0,405
In the Table 4, the approximation degrees of the
query "? -find (facility_ (2-13),
City, collection_ (1-2-3), normal,
far, good).”
Table 4: Approximation degrees according to “normal, far,
good” criteria.
Waste Collection Center
collection_1
collection_2
collection_3
facility_
2
0,357
1,0
0,245
facility_
13
0,891
0,17
0,891
As shown in the tables, we fixed three fuzzy criteria
and made facility and collection weighting. On the
other hand, we did the same weighting by changing
the distance criterion. As a result, we found that fuzzy
criterion change affects at weighting, but in terms of
other criteria, the change was made in the same way.
FCTA 2019 - 11th International Conference on Fuzzy Computation Theory and Applications
372
5 CONCLUSION AND FUTURE
WORK
In this study, waste collection is related to artificial
intelligence and a sample code is written with fuzzy
logical programming language BousiProlog that is
an extension of the standard Prolog language with a
fuzzy unification algorithm based on proximity
relations. This is to remark that, it is a useful tool for
dealing with approximate reasoning and modelling
vagueness, also selecting centers with flexible query
answering in deductive databases for decision-
making process.
As a matter of future work, we should
incorporate: graphical tools for helping the
programmer to define fuzzy sets; other fuzzy
matching options and new application areas such as
project management, decision making on
environmental-technical criteria.
ACKNOWLEDGEMENTS
This research has been financially supported by
Galatasaray University Research Fund (19.402.002).
REFERENCES
Alsinet T., Godo L., 1998. Fuzzy Unification Degree. In
Proc. of the 2nd Intl. Workshop on Logic Programming
and Soft Computing’98, Manchester (UK) , pp 18.
Cayrol M., Farency H., Prade H., 1982. Fuzzy pattern
matching. Kybernetes, 11:103-106.
Dubois D., Prade H., Testemale C., 1988. Weighted fuzzy
pattern matching. Fuzzy Sets and Systems, 28:313-331.
Fontana F.A., Formato F., 1999. Likelog: A logic
programming language for flexible data retrieval. In
Proc. of the ACM SAC, pp. 260267.
Fontana F.A., Formato F., 2002. A similarity-based
resolution rule. Int. J. Intell. Syst., 17(9):853872.
Formato F., Gerla G., Sessa M.I., 2000. Similarity-based
unification. Fundam. Inform. , 41(4):393414.
Julian P., Rubio C., 2006. A wam implementation for
flexible query answering. In A.P.del Pobil, editor, In:
Proc. of the 10th IASTED International Conference on
Artificial Intelligence and Soft Computing (ASC 2006),
August 28-30, 2006, Palma de Mallorca, pages 262
267. ACTA Press.
Julian P., Rubio C., 2009. A similarity-based WAM for
BousiProlog. In: LNCS, vol 5517, pp. 245252.
Springer, Heidelberg.
Julian P., Rubio C., 2009. UNICORN: A Programming
Environment for BousiProlog. In: Proc. of
PROLE’09.
Julian P., Rubio C., Gallardo J., 2009. BousiProlog: a
Prolog extension language for flexible query
answering. In: ENTCS, vol 248, pp. 131-147. Elsevier,
Amsterdam.
Julian P., Rubio C., 2009. A Declarative Semantics for
BousiProlog. In:Proc. of 11th Intl. Symposium on
PPDP’09. ACM SIGPLAN.
Julian P., Rubio C., 2010. Bousi~Prolog - A Fuzzy Logic
Programming Language for Modeling Vague
Knowledge and Approximate Reasoning. In: ICFC-
ICNC, vol 5517, Valencia, Spain, October 24-26.
Lee R.C.T., 1972. Fuzzy Logic and the Resolution
Principle. Journal of the ACM , 19(1):119129.
Mukaidono M., Shen Z.L., Ding L., 1989. Fundamentals
of fuzzy Prolog. Intl. J Approximate Reasons, 3, pp.
10801086.
Orchard R.A., 1998. Fuzzy Clips Version 6.04A. User’s
Guide Integrated Reasoning. Institute for Information
Technology. Canada.
Prade H., Testemale C., 1984. Generalizing database
relational algebra for the treatment of
incomplete/uncertain information and vague queries.
Information Science, 34:115143.
Sessa M.I., 2002. Approximate reasoning by similarity-
based sld resolution. Theoretical Computer Science,
275(1-2):389426.
Zadeh L. A., 1965. Fuzzy Sets. Information and Control,
8(3):338353.
Zadeh L. A., 1975. The Concept of a Linguistic Variable
and its Applications to Approximate Reasoning I, II and
III. J. of Information Sciences 8 and 9, Elsevier.
APPENDIX
%% DIRECTIVES
%% Linguistic variable: cost
:-domain(cost,0,900,dolar).
:-fuzzy_set(cost,[cheap(200,200,450,600),
normal(300,450,650,700),
expensive(550,750,800,900)]).
%% Linguistic variable: distance
:-domain(distance,0,120,minutes).
:-fuzzy_set(distance,[close(0,0,30,80),
medial(20,45,70,90), far(50,85,110,120)]).
%% Linguistic variable: energy generation
capacity
:-domain(capacity,0,10,capacity).
:-fuzzy_set(capacity,[fair(0,0,1,3),
good(2,5,7),excellent(6,8,9,10)]).
%% FACTS
%% Facility table
%% facility(Facility_name, City, Cost,
Capacity).
A Fuzzy Logic Programming Environment for Recycling Facility Selection
373
facility(facility_1, city_A, cost#400,
fair).
facility(facility_2, city_A, cost#650,
good).
facility(facility_3, city_B, cost#900,
extremely#excellent).
facility(facility_4, city_B, cost#700,
very#good).
facility(facility_5, city_B, cost#850,
somewhat#good).
facility(facility_6, city_C, cost#200,
very#fair).
facility(facility_7, city_D, cost#800,
excellent).
facility(facility_8, city_D, cost#750,
very#good).
facility(facility_9, city_E, cost#250,
somewhat#fair).
facility(facility_10, city_F, cost#700,
very#good).
facility(facility_11, city_F, cost#550,
somewhat#excellent).
facility(facility_12, city_G, cost#300,
fair).
facility(facility_13, city_H, cost#500,
more_or_less#good).
facility(facility_14, city_H, cost#800,
excellent).
%% Cities table
%% city(Name, Zone)
city(city_A,zone_1).
city(city_B,zone_1).
city(city_C,zone_2).
city(city_D,zone_3).
city(city_E,zone_4).
city(city_F,zone_4).
city(city_G,zone_4).
city(city_H,zone_5).
%% Distance table
%% distance(Zone, Collection, Distance)
%% to waste collection center no1
distance(zone_1,collection_1,medial).
distance(zone_2,collection_1,somewhat#clo
se).
distance(zone_3,collection_1,far).
distance(zone_4,collection_1,extremely#cl
ose).
distance(zone_5,collection_1,more_or_less
#far).
%% to waste collection center no2
distance(zone_1,collection_2,very#far).
distance(zone_2,collection_2,somewhat#clo
se).
distance(zone_3,collection_2,more_or_less
#medial).
distance(zone_4,collection_2,somewhat#far
).
distance(zone_5,collection_2,close).
%% to waste collection center no3
distance(zone_1,collection_3,more_or_less
#close).
distance(zone_2,collection_3,extremely#fa
r).
distance(zone_3,collection_3,somewhat#med
ial).
distance(zone_4,collection_3,far).
distance(zone_5,collection_3,more_or_less
#far).
%% RULES
%% close_to(Facility, Collection)
close_to(Facility, Collection, Distance
):- facility(Facility, City, _, _),
city(City, Facility_Dist),
distance(Facility_Dist, Collection,
Distance).
find (Facility, City, Collection, Cost
,Distance , Capacity):-facility(Facility,
City, Cost, Capacity),
close_to(Facility,Collection,Distance).
FCTA 2019 - 11th International Conference on Fuzzy Computation Theory and Applications
374
