OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION

SYSTEM: WEB SECURITY VERSUS SYSTEM PERFORMANCE

Ben Soh, Aaron Joy

Applied Computing Research Institute

Department of Computer Science & Computer Engineering

La Trobe University

Bundoora, VIC, Australia 3083

Keywords: Authentication, Web Security

Abstract: A web authentication system uses a number of functions to provide integrity of messages sent between the

client and the web server. These include hash functions, public key encryption, and nonce length. In this

paper, we present an optimal analysis of investigating the effects of some different parameters on the web

security and performance of the authentication system. Our main aim is to devise a technique to achieve the

best of both worlds: optimal web security and system performance. To the best of our knowledge, such

approach is the first attempt to combine the two dependability attributes in a quantitative study.

1 INTRODUCTION

Figure 1 shows the web server framework that we

have developed at La Trobe University (A Joy et al.,

2002). A secure channel established between a client

and the web server is used to combat interception

and modification attacks. However, to protect the

client and web server against fabrication attacks (C.

Kaufman et al., 1995), we need to incorporate into

the secure web server framework two forms of

authentication: (i) user-level authentication and (ii)

machine-level authentication. User-level

authentication is provided by one-time passwords

(OTP) (A. Jones, 1981)(N.Haller et al., 1998), while

machine-level authentication is provided by a hybrid

authentication system, which is the subject of this

paper.

Figure 1: Full web server framework

The hybrid authentication system uses a number of

functions to provide integrity of messages sent

between the client and the web server. These include

hash functions, public key encryption, and nonces

(see Section 2). In this paper, we present a

quantitative analysis of investigating the effects of

various parameters on the security and performance

of the hybrid authentication system. Our main aim is

to devise a technique to achieve the best of both

worlds: optimal web security and optimal system

performance. To the best of our knowledge, this type

of quantitative analysis in terms of the two

dependability attributes is still lacking in the

research community.

2 THE HYBRID

AUTHENTICATION SYSTEM:

BRIEF DESCRIPTION

Authentication

Encrypted Channel

Connection-Oriented

Logging and

Intrustion Detection

User

Machine

The following is a semantic representation of the

hybrid authentication system based on X.509 (C.

I’Anson et al., 1990), where A is a client and B is an

web server. Firstly, A generates a non-repeating

number, r

, which is used to detect replay attacks

and to prevent forgery. A then sends the following

message to B:

A Æ B: B {r

, Ap, sgnData} ,

where

281

Soh B. and Joy A. (2004).

OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION SYSTEM: WEB SECURITY VERSUS SYSTEM PERFORMANCE.

In Proceedings of the First International Conference on E-Business and Telecommunication Networks, pages 281-286

DOI: 10.5220/0001383502810286

 SciTePress

B {} = the encryption of {} using B’s public key

= non-repeating number

Ap = A’s public key

SgnData = Digital signature.

The sgnData is for data origin authentication and is

provided by a digital signature that involves the hash

value of the data and is then encrypted using the

user’s private key. This provides verification that A

and B are in possession of their appropriate private

key. Once B receives the message it carries out the

following actions:

• Obtains Ap

• Verifies the signature, and thus the integrity

of the information.

• Checks that B itself is the intended recipient.

• Checks if r

has not been replayed.

Once the above verification process is

completed, B generates r

a non-repeating number

similar to r

. B then sends the following message to

A :

BÆA: A{r

, Bp, r

sgnData}.

B can also provide data origin authentication by

using sgnData which is included in the message.

Once receiving the message, A will:

• Verify the signature, and thus the integrity

of the information.

• Check that B itself is the intended recipient.

• Check if rB has not been replayed.

• Check that rA is the same rA it has sent.

If all the above criteria are satisfied, A sends B

the final message

AÆB: B{r

,Bp}

On receiving this message, B checks that the same r

was sent back and the message is meant for B. The

final message is crucial for preventing a man-in-the-

middle attack on the web server, by enabling the

client and the web server to authenticate each other

without the use of a timeserver.

3 PERFORMANCE AND

SECURITY EVALUATION

PARAMETERS OF THE HYBRID

AUTHENTICATION SYSTEM

The dependability, in terms of system performance

and security of our hybrid authentication system,

depends on four main parameters: the type of hash

function, the nonce length, the length of the random

seed, and the number of random seeds used. These

four parameters are discussed in the following

subsections.

3.1 Hash Functions

A hash function is a “computationally efficient

function mapping binary strings of arbitrary length

to binary strings of some fixed length, called hash

values” (A. Menezes et al.,1996). For a hash

function to be of cryptographically secure, (i) the

hash function h must be chosen so that it is

computationally infeasible to find two distinct inputs

which will hash to a common value, and (ii) given a

specific hash-value say y it is computationally

infeasible to find an input x such that h(x)=y.

The hash function is used in the hybrid

authentication system to provide data integrity for

the messages sent by the web server and the client.

The information in the message is hashed and the

resultant hash value is encrypted with the public key

of the recipient. Our hybrid authentication system

can accept any of the three types of hash functions:

MD5 (R.Rivest,1992), RIPEMD-160 (B. Preneel et.,

1997), and SHA-1 (SECURE HASH STANDARD,

1995). Each of these hash functions has its own

specifications but the same underlying principles.

They can all provide the hash value for the creation

of a digital signature in the hybrid authentication

system.

3.2 Nonce Length

A nonce is a set length of random bytes that the

client and server send to each other. It contains a

value used no more than once as an identifier to

prevent (undetectable) replay attacks (A. Menezes et

al.,1996). The nonce is a major part of the hybrid

authentication system, by enabling the system to

carry out its authentication function without the use

of timeservers. To achieve this, the clients include a

nonce in an outgoing message sent to the web

server. Thus, any recipient of these messages

requires the knowledge of this nonce. This enables

the client and the web server to achieve a fixed point

as their reference time during the message

exchanges. This is analogous to a shared clock. The

maximum time permitted for a message exchange is

constrained by the timeout period, which somewhat

enforces the use of local, independent clocks (A.

Menezes et al.,1996). The three nonce sizes used in

our hybrid authentication system are 100, 50, and 20

(bytes), thus giving sample spaces of 6.668 x 10

240

2.582 x 10

120

, and 1.461 x 10

, respectively.

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

282

3.3 Random-Seed Length

The random-seed length is the size of the random

data that will be placed into the array in the function

RAND_pseudo_bytes() of the hybrid authentication

system. This random data is then used by another

function RAND_seed() to carry out the public-key

data encryption. The three sample spaces used are

1000, 500, and 100 (bytes).

3.4 The Number of Random Seeds

Used

The number of times the public–key encryption is

seeded is given by the number of random seeds

generated by the following code segment :

for(int j=0; j < NUMBER_OF_TIMES_SEEDED;

j++)

{

RAND_pseudo_bytes(rand_seed,

KEYGEN_NUMBER_RAND_SEED);

RAND_seed(rand_seed, sizeof rand_seed);

}

It is noteworthy that the code uses the for() loop so

that the function RAND_pseudo_bytes() and

RAND_seed() can be run more than once.

4 PERFORMANCE EVALUATION:

EXPERIMENTAL SETUP AND

RESULTS

The performance evaluation of the hybrid

authentication system is based on the speed at which

the client and server authenticate each other with the

variation of the four parameters discussed in the

previous section. The simulations were run on a

Pentium (200MMX with 64mb of EDO ram) using

Redhat Linux 7.0. The UNIX time command was

used to obtain the time required for the hybrid

authentication system to complete the full

authentication task. The evaluation was based on the

end-to-end authentication in that messages were

passed from the server functions to the client

functions without going through the

communicational channel. This was done so that the

results would not be affected by the channel delays

between the client and the server.

Tables 1-4 are snapshots of the results obtained and

respectively show the effects on the system

performance of the hybrid authentication system

caused by:

hash functions

the nonce length

the random-seed length

the number of random seeds used.

Table 1: Performance wrt hash functions

Nonce

length

(bytes)

Seed

length

(bytes)

Average Performance Time

(s) wrt hash functions

seed

used

SHA-1 RIPEN

D-160

MD5

100 1000 .3973 .3823 .3863

50 500 .2999 .3010 .2980

20 100 .2677 .2720 .2683

100 100 .2707 .2637 .2647

50 500 .2870 .2843 .2837

20 1000 .3123 .3220 .3127

100 500 .2737 .2750 .2727

50 1000 .2883 .2847 .2850

20 100 .2627 .2690 .2653

Table 2: Performance wrt the nonce length

Average Performance

Time (s) wrt nonce

length

No o

Hash

Function seeds

used

Seed

length

(bytes)

100 50 20

SHA-1 1000 .3973 .3317 .3323

RIPEND-160 500 .3127 .3010 .2987

MD5 100 .2690 .2713 .2683

SHA-1 100 .2707 .2667 .2657

RIPEND-160 500 .2857 .2843 .2860

MD5 1000 .3083 .3083 .3127

SHA-1 500 .2737 .2790 .2730

RIPEND-160 1000 .2850 .2847 .2983

MD5 100 .2627 .2677 .2653

Table 3: Performance wrt the seed length

Average Performance

Time (s) wrt seed length

seeds

used

Nonce

length

(bytes)

Hash function

1000 500 100

100 SHA-1 .3973 .2970 .2687

50 RIPEND-160 .3473 .3010 .2677

20 MD5 .3330 .2970 .2683

100 SHA-1 .3110 .2840 .2707

50 RIPEND-160 .3127 .2843 .2700

20 MD5 .3127 .2853 .2727

100 SHA-1 .2877 .2737 .2707

50 RIPEND-160 .2847 .2777 .2627

20 MD5 .2843 .2777 .2653

OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION SYSTEM: WEB SECURITY VERSUS SYSTEM

PERFORMANCE

283

Table 4: Performance wrt the number of seeds

Average Performance

Time (s) wrt the

number of seeds

Hash

functions

Nonce

length

(bytes)

Seed

length

(bytes)

3 2 1

SHA-1

100 1000 .3973 .3110 .2877

RIPEND-160

50 500 .3010 .2843 .2777

MD5

20 100 .2683 .2727 .2653

SHA-1

100 100 .2687 .2707 .2707

RIPEND-160

50 1000 .3473 .3127 .2847

MD5

20 500 .2970 .2a853 .2777

SHA-1

100 500 .2970 .2840 .2737

MD5

50 1000 .3323 .3083 .2850

RIPEND-160

20 100 .2720 .2713 .2690

Based on the results of the performance evaluation,

we define for our hybrid authentication system a

measure called Performance Index (PI) as the

inverse of the average performance time. For

example, for the hybrid authentication system using

SHA-1 as the hash function, the nonce length of 100

bytes, the seed length of 1000 bytes and 3 random

seeds, the PI is 1/0.3573 = 2.7988.

5 WEB SECURITY EVALUATION

As a matter of fact, quantitative measures for web

security evaluation are yet to be agreed upon in the

research community. Consequently we need some

mechanisms to calibrate our hybrid authentication

system from the security point of view. To this end,

we utilize the industrial data and standards, expert

knowledge and research outcomes in the field,

within the sample space of the four parameters

described in Section 3. In the sample space of the

parameter concerned, a parameter value deemed to

offer the maximum security will be given a weight

of 1; the weight is otherwise less than 1 (which we

will discuss below). For our hybrid authentication

system, we define a measure called Security Index

(SI) as the average weight of the 4 parameters:

SI = (hash_function_weight +

nonce_length_weight + seed_length_weight +

number_of_seeds_weight) / 4

where hash_function_weight etc are self-

explanatory. This calibration would not lead to an

absolute measure for security evaluation but would

be useful as a tool for comparative and sensitivity

studies by varying the values of those parameters of

the hybrid authentication system.

For our hybrid authentication system, the sample

space of the hash function parameter is {MD5,

RIPEND-160, SHA-1}. Since the collision method

found by Paul Oorschot and Michael Wiener (R. M.

Needham, 1993), MD5 and RIPEMD-160 have been

found to contain weaknesses. In particular, the

CryptoBytes newsletter (B. Preneel et., 1997) best

described MD5’s situation: “The presented attack

does not yet threaten practical applications using

MD5, but it comes rather close”. Also, Paul Van

Oorschot and Mike Wiener (C. Kaufman et al.,

1995) showed that a brute-force job on MD5 can be

done in less than a month…” To date, SHA-1 has

been found to be the most secure hash function

among the three. Based on the expert knowledge,

we consider within the sample space that SHA-1 has

a hash_funciton_weight of 1. Using the 30/70 rule

for a comparative study, we assign 0.43 to the

hash_function_weight of RIPEND-160 and 0.18 to

MD5, which is deemed the weakest among the three.

The nonce is an important factor for authentication

in that the larger the nonce the less chance will the

nonce be predicted and compromised by an attacker.

Our nonce_length space is {100, 50, 20}. On this

basis, 100 bytes of nonce is given a weight of 1.

Using the rule of proportionality for a comparative

study, 50 bytes of nonce is given a weight of 0.5,

and 20 bytes of nonce a weight of 0.2.

For the random-seed length, the sample space used

is {1000, 500, 100}. From a security point of view,

the larger the random data seeded the more random

is the public-key encryption. This implies that it will

be harder for an attacker to find a pattern (National

Institute Of Standards and Technology, 2001).

Hence, 1000 bytes of seed length has a weight of 1,

500 bytes a weight of 0.5, and 100 bytes a weight of

0.1 (by proportioning).

The sample space for the number of random seeds

used is {3, 2, 1}. The number of seeds determines

the number of times the public-key encryption is

seeded. If data are seeded more frequently, they will

tend to be more random, which would be harder for

an attacker to compromise. Thus, a weight of 1 is

given if the number of seeds used is 3. By

proportioning, a weight of 0.67 and 0.33 is given if

the number of seeds used is 2 and 1, respectively.

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

284

6 OPTIMAL WEB SECURITY-

AND-PERFORMANCE INDEX

FOR THE HYBRID

AUTHENTICATION SYSTEM

From the above discussions, it is obvious that

performance and security are two opposing

dependability attributes. For example, if the random

seed length is excessive (which is good for security

reasons), system performance will be reduced

tremendously, as mentioned in (D. Eastlake et al.,).

This points to the need for a compromise between

performance and security for our hybrid

authentication system. To this end, using

Performance Index (PI) and Security Index (SI)

defined in Sections 4 and 5 respectively, we propose

a composite index called Authentication System

Index (ASI), which is defined as follows:

ASI = PI x SI.

Using the ASI, we are able to find an optimal set of

the parameters used in our hybrid authentication

system, in terms of both security and system

performance. Table 5 gives a snapshot of the results

involving ASI. By analysing all the data (not

included here because of space constraints), we are

able to list down the following observations for our

hybrid authentication system:

1. The random-seed size of 1000 bytes is too large,

which reduces the ASI value. A seed size of 500

(or 100) bytes may give optimal ASI.

2. The nonce size of 20 bytes is too small. A size of

100 (or 50) bytes may produce optimal ASI.

3. For optimal ASI, the number of random seeds

used can be just one.

7 CONCLUSION

In this paper, we have presented a quantitative

analysis on the web security and system

performance evaluation of an actual hybrid

authentication system. We have proposed a

composite index called Authentication System Index

(ASI), which can be used to evaluate at the same

time both the security and performance of our hybrid

authentication system.

From the results obtained, we have found that: (i) a

nonce size of either 50 or 100 bytes is fine for

optimal security and system performance; this

concurs with the findings presented in (D. Eastlake

et al.,); (ii) it is claimed in (D. Eastlake et al.,) that

1000 bytes for the size of the seeds used seem too

large, and our study in this paper proves this point;

our results show 100 (or 500) bytes is a good seed

size to be used for our authentication system, and

(iii) the number of seeds used (i.e. frequency of

seeding the public-key encryption) can be just once,

which would give sufficient randomness.

REFERENCES

A Joy and B Soh, “A proposed secure TCP connection-

oriented model for e-commerce systems,” Proceedings

of International Conference on Internet and

Multimedia Systems and Applications, Hawaii, Aug

12-14, pp 68-73, 2002.

C. Kaufman, R. Perlman, and M. Speciner. Network

Security Private Communications in a Public World,

Prentice Hall 1995.

A. Jones, “Password authentication with insecure

communication,” ACM Communications, vol. 24,

number 11, 1981, pp 12-21.

N.Haller, C. Metz, P. Nesser, and M. Straw . “A One-

Time Password System,” RFC2289, February 1998,

http://www.ietf.org.

C. I’Anson and C. Mitchell. “Security defects in CCITT

recommendation X.509 – The directory authentication

framework,” Computer Communications Review, pp

45-53, April 1990.

A. Menezes, P. van Oorschot and S. Vanstone, Handbook

of Applied Cryptography, CRC Press, 1996.

R.Rivest, “The MD5 Message-Digest Algorithm”, Internet

RFC 1321, April 1992.

B. Preneel, and A. Bosselaers, “The Cryptographic Hash

Function RIPEMD-160”, CryptoBytes, vol 3, no 2,

Autumn 1997.

National Institute of Standards and Technology, SECURE

HASH STANDARD, FIPS PUB 180-1, 1995. February

13 2001

http://www.itl.nist.gov/fipspubs/fip180-1.htm.

R. M. Needham , “Denial Of Service,” Proceedings of the

1st ACM conference on Computer and

Communications Security

, pp 151-153, November 3-5,

1993, Fairfax, VA USA.

National Institute Of Standards and Technology, FIPS 112

– Password Usage. 1995. September 2001,

http://www.itl.nist.gov/fipspubs/fip112.htm.

D. Eastlake, S Crocker, and J Schiller, “Randomness

Recommendations for Security”, rfc1750,

http://www.i

OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION SYSTEM: WEB SECURITY VERSUS SYSTEM

PERFORMANCE

285

APPENDIX

Table 5: Performance versus Security

No of seeds

used

Nonce

length

(bytes)

Seed

length

(bytes)

Hash

functn

PI SI ASI

3 100 1000 SHA-1 2.51701.00002.5170

3 50 500 SHA-1 3.33440.75002.5008

3 20 100 SHA-1 3.73550.57502.1479

2 100 100 SHA-1 3.69410.69252.5582

2 50 500 SHA-1 3.48430.66752.3258

2 20 1000 SHA-1 3.20200.71752.2974

1 100 500 SHA-1 3.65360.70752.5849

1 50 1000 SHA-1 3.46860.70752.4469

1 20 100 SHA-1 3.80660.40751.5512

3 100 1000 RIPEND-

160

2.61570.85752.2430

3 50 500 RIPEND-

160

3.32230.60752.0183

3 20 100 RIPEND-

160

3.67650.43251.5901

2 100 100 RIPEND-

160

3.79220.55002.0857

2 50 500 RIPEND-

160

3.51740.52501.8467

2 20 1000 RIPEND-

160

3.10560.57501.7857

1 100 500 RIPEND-

160

3.63630.56502.0545

1 50 1000 RIPEND-

160

3.51250.56501.9846

1 20 100 RIPEND-

160

3.71750.26500.9851

3 100 1000 MD5 2.58870.79502.0580

3 50 500 MD5 3.35570.54501.8289

3 20 100 MD5 3.72720.37001.3791

2 100 100 MD5 3.77790.48751.8417

2 50 500 MD5 3.52490.46251.6302

2 20 1000 MD5 3.19800.51251.6390

1 100 500 MD5 3.66700.50251.8427

1 50 1000 MD5 3.50880.50251.7631

1 20 100 MD5 3.76930.20250.7632

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

286
