A HARDWARE-ORIENTED ANALYSIS OF ARITHMETIC

CODING – COMPARATIVE STUDY OF JPEG2000 AND

H.264/AVC COMPRESSION STANDARDS

Grzegorz Pastuszak

Warsaw University of Technology, Institute of Radioelectronics, Nowowiejska 15/19, Warsaw, Poland

Keywords: CABAC, binary arithmetic coding, H.264, MPEG-4 AVC, JPEG 2000

Abstract: This paper provides an in-depth analysis and com

parison of the arithmetic coding stages in the latest

compression standards: JPEG 2000 and H.264/AVC for image and video systems, respectively. An impact

of algorithm differences on hardware architecture is considered. Evaluation results show throughput

requirements that real-time multimedia applications have to satisfy.

1 INTRODUCTION

Coding efficiency is the one of the most important

features of all compression systems. Towards this

goal, they follow a general schema of three main

consecutive stages: modelling, quantization and

coding. The latter stage exploits some well-known

techniques, along with variable length codes and

arithmetic coding, which map input symbols into

binary sequences. The produced code streams

achieve shorter lengths with respect to their source

representation by making them dependent on

occurrence probabilities, as Shannon’s theorem

claims. Arithmetic coders are able to attain better

compression efficiency due to their property to

effectively map input data onto binary sequences

with fractional accuracy of lengths for entropy

approximation. Adaptation to local statistics

provides a path to further reduction of code stream

lengths. However, these properties imply much

higher computational complexity. JPEG 2000

(ISO/IEC 15444-1, 2000) and H.264/AVC (ISO/IEC

14496-10, 2003) are standards, where the Context

Adaptive Binary Arithmetic Coding (CABAC) is the

part of the compression scheme. Although CABAC

bases on the same general principles in both

standards, there are some substantial differences

between them.

The comparison of the standards provided in

(Marp

e et. all, 2003-Oct.) focuses mainly on the

compression efficiency providing complexity issues

rather in broad outline. CABAC algorithms, as they

stand, are extensively described in related works for

both JPEG2000 (Taubman et. all, 2002) and

H.264/AVC (Marpe et. all, 2003-July), (Marpe et.

all, 2003-Sept.). In case of JPEG 2000, the

bottleneck of the system arises from the entropy

coding stage along with the arithmetic coder. Some

optimisation methods were reported in literature and

they lend themselves to the newest video

compression schema. On the other hand, existing

differences necessitate unique approaches. In this

paper, we emphasize design details in terms of both

hardware complexity and speed. Moreover,

throughput evaluations are provided to find speed

requirements for real-time applications.

The remainder of the paper is organized as

llows: Section 2 illustrates consecutive stages of

the CABAC that are deeply analysed in subsections

2.1 – 2.4. Subsection 2.5 addresses bypass mode

variants. System-level conditions for arithmetic

coding are given in Section 3.1. The following ones

provide test conditions, evaluated requirements for

processing speed and discussion combining them

with hardware design methods; finally, Section 4

concludes the work.

2 MAIN STAGES OF THE CABAC

In terms of basic operations while executing the

CABAC algorithm, we may distinguish four main

stages. Fig. 1 shows their causal arrangement what

suggest how to implement the algorithm in hardware

309

Pastuszak G. (2004).

A HARDWARE-ORIENTED ANALYSIS OF ARITHMETIC CODING – COMPARATIVE STUDY OF JPEG2000 AND H.264/AVC COMPRESSION

STANDARDS.

In Proceedings of the First International Conference on E-Business and Telecommunication Networks, pages 309-316

DOI: 10.5220/0001386603090316

 SciTePress

Codestrea

formation

base

increase

Interval

length

shorting

Probability

state

updating

Code

stream

lps

mps/ lps

lps

mps/lps

Codestream

formation

base

increasing

Interval

len

shorting

Probability

state

updating

Code

stream

lps

mps/ lps

lps

mps/lps

Figure 1: Division of the arithmetic coding algorithm in terms of casual relationships allows pipelined architectures.

Here, Plps

denotes probability estimate of LPS, SN – renormalization shift number, C – the base before renormalization,

mps/lps – selects between MPS and LPS. The dashed line identifies optional feed back (JPEG2000).

to obtain a high throughput. First stage performs

updating the probability state array according to pre-

defined transaction rules. Each element of this state

array corresponds to one of the possible input

contexts, CX, and consists of two fields: the index

and the most probable symbol (MPS) value. The

index value identifies probability estimate of the

least probable symbol (LPS). An estimate for a

given context is forwarded to the second stage to

subdivide the current probability interval (A) into

two ones, as illustrated in Fig. 2 and Fig. 3.

Depending on LPS/MPS coding, one of them is

selected as a new one, and renormalized to desired

range by shifting left, if needed. The third stage

manages the interval base register (C - lower

endpoint). This register is increased when the upper

subinterval is selected as a new one. Successive

renormalization shifts for the A register trigger the

analogous behaviour of the C one, which releases

code bits from its MSB positions. The bits are

collected in the last stage into bytes and output to

external functional blocks to form a final

compressed stream.

2.1 Probability state updating

In JPEG 2000 and H.264/AVC, there are

respectively 19 and 399 possible contexts defined

for the CABAC. Each context has an associated

finite state machine conveying the index, as a 6-bit

vector, which assumes 47, in JPEG 2000, and 64, in

H.264/AVC, allowable values. The small number of

contexts, in the image compression standard, enables

hardware architectures to implement the probability

state array in registers, whereas the video schema

imposes using an on-chip memory to save area of an

integrated circuit. In spite of this drawback,

H.264/AVC exhibits more flexible properties for

pipeline-oriented approaches, since probability state

updating process experience no impact from the

probability interval renormalization. Such

dependencies exist in the case of JPEG 2000, while

coding MPS. If it does not cause renormalization

shifts then the probability state, pointed by the

current context, remains unchanged; otherwise a

MPS

C (the pointer of

code string)

C(0)

A(0)

MPS MPSLPS

A-Qe<Qe

C+A

MPS

C (the pointer of

code string)

C(0)

A(0)

MPS

MPS LPS

C+A

Figure 2: The interval subdivision in the JPEG2000

arithmetic coder.

Figure 3: The interval subdivision in the

H.264/AVC arithmetic coder.

ICETE 2004 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

310

CODE MPS

QA = (A>>6) & 3

A = A – Qe(I(CX),QA)

I(CX) = NMPS(I(CX))

RENORM

DONE

CODE LPS

A = Qe(I(CX),QA)

C = C + Qe(I(CX),QA)

I(CX) = NMPS(I(CX))

YES

I(CX))=0?

MPS = 1 - MPS(CX)

ENCODE(CX,S)

S xor MPS(CX) = 1?

YES NO

CODE MPS

A = A – Qe(I(CX))

A and 0x8000 = 0?

A < Qe(I(CX))?

C = C + Qe(I(CX))

C = C + Qe(I(CX)) A = Qe(I(CX))

I(CX) = NMPS(I(CX))

RENORM

DONE

YES

CODE LPS

YES

A < Qe(I(CX))?

C = C + Qe(I(CX))A = Qe(I(CX))

I(CX) = NMPS(I(CX))

YES

SWITCH(I(CX))=1?

MPS = 1 - MPS(CX)

ENCODE(CX,S)

S xor MPS(CX) = 1?

YES

Figure 5: Arithmetic coding procedure in

H.264/AVC: QA indicates two bits classifying the

interval length (A) to one of four subranges to better

match probability estimates. LPS is always assigned

to upper subinterval, whereas MPS to the lower one.

Figure 4: Arithmetic coding procedure in JPEG2000

embeds the conditional exchange of subintervals,

conditional probability update for MPS.

new value is stored in accordance with the index

transaction table. In the image compression schema,

indices, in the probability state array, are initialised

always to the same values defined in the standard

specification. H.264/AVC involves quite

complicated initialisation rules dependent on the

quantization parameter (Qp), the frame type and a

particular context number. Moreover, for INTER

frames, we can select between three sets of

initialisation schemas. The best choice may be done

on the base of the resultant compression rate and

depends on the video content. As for circuit, the

initialisation rules introduce a considerable amount

of both silicon and time resources. The first

implication arises from the need to keep a large

number of pre-defined constants in either the ROM

table or combinatorial logic. The second one is

caused by the necessity to check the rate for three

initialisation cases, while coding INTER frames.

Incorporating three CABAC engines, operating in

parallel, can solve the time problem at the expense

of hardware resources.

2.2 Interval length calculation

JPEG 2000 incorporates the 16-bits interval register,

whereas H.264/AVC uses the 9-bits one. As for

hardware, the increased precision improves slightly

coding efficiency at the expense of resources and a

longer carry chain. In considered standards, the

interval length undergoes multiplication-free

modifications, which realize its subdivision into two

disjoint ranges. Since multiplication products are

replaced by their tabled approximations, we would

deal with some losses in coding efficiency (up to

3%). To mitigate this drawback, both compression

schemes utilize different approaches. In JPEG 2000,

the CABAC executes the conditional exchange,

which ensures that the larger and smaller

subintervals are always assigned to MPS and LPS,

respectively. A fast hardware implementation

translates this feature to a comparator (A<2Qe?)

driving, together with MPS/LPS signal, the selection

of an appropriate subinterval. The associated latency

of this operation matches that in subtraction carry

chain (A-Qe), thereby, the additional circuit should

not deteriorate working frequency. H.264/AVC

employs another solution to improve coding

efficiency. Prior to subdivision (by subtraction), the

interval is classified to one of four ranges based on

its two bits located just after the MSB bit (which

should equa1 1). Each range corresponds to a

separate set of probability estimates to better

approximate a multiplication product (A*Qe).

Hence, given a set, the index points an appropriate

estimate ready for either the subtraction or

conditional interval reloading. A circuit,

implementing the H.264/AVC arithmetic coder, has

HARDWARE-ORIENTED ANALYSIS OF THE ARITHMETIC CODING – Comparative study of JPEG2000 and

H.264/AVC compression standards

311

Qe(I(CX))

POSITION

Next A

MPS/LPS

e<A

Qe(I(CX))

POSITION

Next A

MPS/LPS

Figure 7: The A-interval subdivision circuit in the

H.264/AVC arithmetic coder.

Figure 6: The A-interval subdivision circuit in the

JPEG2000 arithmetic coder.

JPEG2000: Qe(I(CX))

JVT: A-Qe(I(CX))

Next C

Shift

number

Increase

base

to provide all necessary probability estimate tables

what amounts to a relevant combinatorial logic. The

generated estimates should be available before

beginning subinterval calculation to minimize

propagation delays. Therefore, the pipelined

architecture should determine these estimates in a

preceding stage. However, selection between four

ones, depended on the interval bits, must be held at

the second stage what affects negatively timing.

Determining estimates in advance fails in case of

JPEG 2000 because of conditional state updating, as

described above. On the other hand, there is no need

for the selection. Moreover, less significant bits of

estimates vary weakly over all indexes, what drives

the logic synthesizer to simplify circuits, thus,

shorting critical paths. After all, the interval value is

renormalized by means of the shifting circuit. Fig. 6

and 7 depict interval length calculation circuits able

to process one symbol per clock cycle for considered

standards.

2.3 Interval base calculation

The base register in H.264/AVC needs 10 bits to be

implemented. The location of subintervals is

inverted with respect to JPEG 2000, i.e. in video

compression scheme the upper and the lower

correspond to LPS and MPS coding, respectively.

Most notably, while subtracting the probability

estimate from the interval length (LPS coding), the

base has to be increased by the subtraction product.

This dependency may affect negatively clock rate.

Locating the base circuit in a separate pipeline stage

gives somewhat shorter critical paths. As a

consequence of similar bit counts in carry chains (9

and 10), the delays of pipelined circuits match one

another. This observation holds for renormalization

units due to an identical shift number submitted to

both. The JPEG 2000 arithmetic coder keeps the

lower bound of the interval in the 28 bits register. It

experiences the analogous operations as the

H.264/AVC counterpart. From hardware

perspective, the main difference arises from their

sizes what reflects on the latency in carry chains. In

order to shorten critical paths in JPEG 2000, it is

viable to divide the base register into two parts and

place them in consecutive pipeline stages. Such

rearrangement refers also to relevant combinatorial

logic. Another distinguishing feature of the image

compression coder lays in the meaning of the oldest

part of the lower bound register, which supports

carry propagation and code data releasing. The

H.264/AVC version applies a different solution to

these problems, so that, it removes the need to

extend the base register towards MSB bits. The

typical circuit managing the base is shown in Fig. 8.

Figure 8: The C-

ase updating circuit able to

process one symbol per clock cycle.

ICETE 2004 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

312

2.4 Code stream generation

In the H.264/AVC arithmetic coder, output bits are

released from the second MSB position of the base

order to solve the problem of carry propagation,

ones, encountered in series, are counted without

outputting. Occurrence of the carry, indicated by the

MSB bit of the base register, activates releasing

binary one followed by a number of zeros.

Otherwise, the inverted version of such sequence

appears as an outcome after encountering a zero bit.

This procedure requires the use of a counter

signalling a total of outstanding bits. Its precision

should match a maximal possible code stream length

to prevent overflow when dealing with an extremely

long series. The produced bits are assembled into

bytes and released. It may happen that more then

one byte has to be output due to a large number of

outstanding bits. Provided the CABAC accepts one

symbol per clock cycle, the design must adjust this

rate to irregular code byte generation conditions by

inserting wait-states. The JPEG 2000 arithmetic

coder is free to that problem since at most two code

bytes can appear as an outcome after processing one

symbol. The algorithm imposes the need to keep the

last generated byte in the buffer ready to complete

carry. If there is the 0xFF byte, the control logic

inserts one stuffing bit into the MSB position of the

following byte. This bit assumes the zero value to

trap a carry. A dedicated down-counter points to bits

in the base register that have not been released so

far. In terms of higher performances, both

compression standards find a separate pipeline stage

to make the code stream generation adequate.

2.5 Bypass mode

The CABAC in H.264/AVC provides the bypass

mode, which, against the regular one, assumes

uniform probability distribution of submitted

symbols. Hence, it skips the probability state

updating routine. Since related symbols contribute to

the same code stream as in regular mode, it is natural

to use the same resources with their timing

constraints. The interval register remains unchanged

in bypass mode. This property, in conjunction with

skipping the probability adaptation, gives an

opportunity to process bypassed symbols and regular

ones in parallel. The probability estimates are

obtained by single shifting right (division by 2) the

interval value. Therefore, we must append one bit to

represent estimate accurately. In case of JPEG 2000,

the bypass mode forwards symbols directly to the

output stream without arithmetic encoding. As for

hardware, this approach allows increasing the

throughput to a rate determined by the bit-plane

coder performances, which submits input data to the

CABAC module. However, the total improvement is

not so significant since the standard enables the

bypass mode for some coding passes over lowest bit

planes.

3 EVALUATION

3.1 System-level constraints

Since the CABAC in H.264/AVC produces the

single code stream for an entire slice, all necessary

context-symbol data have to be applied to the one

functional block. Thus, its speed determines the

overall performances of the coder when input data

are received continuously. Lower bit-rates decrease

demands for throughput. Using rate-distortion

optimisation for each macro-block improves quality

at the same compression ratio. To obtain rates, we

need to carry out arithmetic coding (when used) for

all possible coding modes. As a consequence, it

burdens the CABAC with a large number of

computations and may lead to timing constraints for

the encoder. JPEG 2000 supports entropy-coding

parallelism by independent analysing rectangular

blocks of coefficients in the wavelet domain. Each

such code block generates a separate output stream,

which can be truncated in some points to increase

the compression ratio at the expense of quality

losses of the reconstructed image. Moreover, a

special mode drives the arithmetic coder to terminate

the stream on these points. For the sake of the rate

control policy, it is desired to produce more

outcomes to discard their less significant parts with

reference to the optimisation criteria. Thus, we need

faster CABAC engines to support this property.

3.2 Evaluation conditions

Evaluations have been conducted for some video

sequences taking into account the number of binary

symbols submitted to the arithmetic coder in both

standards. We examined test cases relating to CIF

and QCIF resolutions. As reference software for

image compression schema, we have employed

JJ2000 version 5.1 adapted to support video material

as Motion JPEG 2000 (ISO/IEC 15444-3, 2002). To

get characteristics following options have been used:

no tiling, five levels of wavelet decompositions, 9/7

wavelet filter, code block size of 64 x 64 samples,

regular coding mode, single quality layer. Explicit

quantization by step size has enabled to vary both

HARDWARE-ORIENTED ANALYSIS OF THE ARITHMETIC CODING – Comparative study of JPEG2000 and

H.264/AVC compression standards

313

Football - CIF

25 30 35 40 45 50

PSNR [dB]

trouhput [Msym/sec]

JPEG2000

JVT-IBBP

JVT(I)

Tempete - CIF

25 30 35 40 45 50

PSNR [dB]

trouhput [Msym/sec]

JPEG2000

JVT-IBBP

JVT(I)

Paris - QCIF

20 25 30 35 40 45 50

PSNR [dB]

trouhput [Msym/sec]

JPEG 20 00

JVT-IBBP

JVT(I)

For e m a n - QCIF

0.5

1.5

2.5

3.5

25 30 35 40 45 50

PSNR [d B]

trouhput [Msym/sec]

JPEG2000

JVT-IBBP

JVT(I)

Figure 9. Averaged throughput requirements for H.264/AVC (JVT) and Motion JPEG2000

Tempete - CIF

0.1

100

1000

25 30 35 40 45 50

PSNR [ d B]

trouhput [Msym/sec]

IBBP RD

INTRA RD

IBBP

INTRA

For e m a n - QCIF

0.01

0.1

100

1000

25 30 35 40 45 50

PSNR [ dB]

trouhput [Msym/sec]

IBBP RD

INTRA RD

IBBP

INTRA

Figure 10. Averaged throughput requirements for H.264/AVC (JVT) using RD optimization or not.

quality and rate. Additionally, the special case, when

no quantization is present, has been checked to

demonstrate the most critical conditions, when total

losses in quality of the reconstructed images results

only from the rate-control policy. For encoding

video material, the Joint Model (JM) of the Joint

Video Team (JVT), software version 7.4 has been

used. We have explored constraints when taking

advantage of the RD-optimisation (rate-distortion) or

not. All tests have skipped the rate controller to

determine quality losses by explicit quantization

parameter, Qp. The list of other settings has been as

follows: only one slice per picture, 2 reference

frames, full search of motion vectors, in IBBP mode:

I-frames every 15

, 2 B-frames between I and/or P.

All evaluations assumed frame rate of 30 Hz.

3.3 Evaluation results

Fig. 9 shows throughput (number of coded symbols)

versus quality expressed as average PSNR

(distortion) of the luminance component over all

frames in a given sequence. The average PSNR of

the chrominance components (U, V) has been

adjusted with reference to that of the luminance one

to obtain approximately the same differences for

both compression schemas. This objective has been

achieved by first producing curves for JPEG 2000,

and then, iteratively varying the quantization

parameter offset for chrominance components in

H.264/AVC reference model. As expected, the

throughput requirements increase significantly if we

ICETE 2004 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

314

Tempete - CIF

100

1000

0.1 1 10 10

rate [bps]

trouhput [Msym/sec]

Intr a RD

Intr a

MJPEG2000

Figure 11. Averaged throughput requirements for

H.264/AVC (JVT) and Motion JPEG2000 versus bit-rate.

JPEG2000

20 25 30 35 40 45 5

PSNR [d B]

trouhput [Msym/sec]

Football CIF

Football limit

Par is QCIF

Paris limit

Figure 12. Averaged throughput requirements for Motion

JPEG2000 with indicated maximal limits when no

quantization.

want to decrease distortions. Without RD

optimisation, the video compression schema takes

less time to accomplish the arithmetic coding routine

than JPEG 2000. The INTRA mode of H.264/AVC

demands a little smaller throughput then JPEG 2000

for the quality range of interest to most video

applications. However, at higher qualities, both

standards need similar processing speed of the

CABAC block with the tendency to favour the JPEG

2000. Of course, the use of INTER mode makes

H.264/AVC the best solution in terms of both

compression ratio and throughput of the entropy

coder. On the other hand, the compressed stream

must embed the INTRA frames, so, their temporal

impact on the latency of the arithmetic coder should

be taken into account. Using RD optimisation in

H.264/AVC increases demands for the CABAC

module by about two orders of magnitude (see Fig.

10). This computation growth is necessary only to

select the best mode for macroblock in the sense of

Lagrange’s minimization. The opportunity for

parallelism arises, since a macroblock can be

processed for different modes at the same time. As

depicted in Fig. 11, the computation demands for the

CABAC engine are almost proportional to a given

rate in both standards. So, on the base of imposed

bandwidth or storage limitations, we can estimate

desired throughput of the arithmetic coder.

Tempete - CIF, JVT(IBBP) RD on

100

150

200

250

300

25 30 35 40 45 5

PSNR [ d B]

trouhput [Msym/sec]

all symbols coded

bypass symbols skipped

Figure 13. Averaged throughput requirements for

H.264/AVC diminish when symbols obeying uniform

distribution are skipped.

3.4 Discussion

With the above observations, we re-examine the

pipelined structure of the arithmetic coders for real

time performances. Since the context generator in

JPEG 2000 occupies a relatively large silicon area of

the integrated circuits (due to coefficient memory), it

is payable to optimize the throughput of the CABAC

unit rather then to duplicate entropy coding paths

including both modules. Such single path,

embedding pipeline architecture able to process one

symbol per clock cycle, yields speed to target from

CIF sequences (4:2:0 – 4:4:4, 30 frames per second)

provided regular and lossless mode (Hsiao et. all,

2002), (Lian et. all, 2003), (Li et. all, 2002), (Fang

et. all, 2002). Approaches based on sequential

arrangement attain worse results in spite of higher

clock rates (Andra K et. all, 2003). The lossy

compression allows higher throughputs, as shown in

Fig. 12. Of course, the exact performances depend

primarily on the technology of an integrated circuits

and efforts spent to minimize critical paths. To speed

up the entropy coding, we can use parallel

processing paths and/or modify the architecture to

process two or more symbols per clock cycle.

In H.264/AVC encoder without RD optimisations,

the single CABAC engine, complying with pipeline

arrangement (like in JPEG 2000) able to process one

symbol per clock cycle, can easy support PAL and

NTSC standards in the compression range of most

interest. Moreover, it makes possible to target

HDTV at lower bit-rates (low quality). However, we

must remember that the throughput of the whole

video coder depends on the motion estimation unit

rather then the entropy coding stage. Taking

HARDWARE-ORIENTED ANALYSIS OF THE ARITHMETIC CODING – Comparative study of JPEG2000 and

H.264/AVC compression standards

315

advantage of the RD optimisation finds the

arithmetic coder to become another bottleneck of the

system. As mentioned above, employing several

engines in parallel mitigates timing constraints at the

cost of silicon resources. This can be realized in two

ways. The first assumes dividing a frame into a

number of slices and assigning one CABAC unit to

each of them. Prior to checking all coding scenarios,

we have to save the states of internal registers, and

then, encode a macroblock in series for various

modes staring from the same state. The second way

determines rates simultaneously in separate coding

units. One can combine these approaches as well.

Since some symbols obey uniform distribution, they

induce extension of the output stream by one bit. So,

when we want to estimate rates, it is enough to count

them without submitting to the arithmetic coder. Fig.

13 depicts the difference in throughput of the

CABAC, while benefiting from this opportunity.

4 CONCLUSIONS

The analysed arithmetic coding algorithms proves to

comply with the general schema of the pipeline

architecture design. Corresponding stages exhibit

some variants of the CABAC concepts requiring

different approaches to minimize critical paths. The

H.264/AVC version can achieve higher working

frequencies than the JPEG 2000 one due to smaller

sizes of the key registers. Owing to the latter

supports entropy coding parallelism, it can achieve

high performance, but a hardware designer should

primarily sophisticate the single entropy channel to

save a total of silicon area. Special attention must be

paid to optimise the CABAC unit in H.264/AVC,

when RD optimisation is on, including parallel

encoding engines, counting bypassed symbols, and

minimizing critical paths. Without RD

enhancements, the throughput of the single CABAC

gives opportunity even to target HDTV.

ACKNOWLEDGEMENT

The work presented was developed within activities

of VISNET, the European Network of Excellence,

(http://www.visnet-noe.org), founded under the

European Commission IST 6FP programme.

REFERENCES

ISO/IEC 15444-1, 2000, JPEG 2000 Part I Final

Committee Draft Version 1.0.

ISO/IEC 15444-3, 2002, Motion – JPEG 2000 Part 3.

ISO/IEC 14496-10, 2003, ITU-T Recommendation H.264

and ISO/IEC 14496-10 MPEG-4 Part 10, Advanced

Video Coding (AVC),.

Taubman D. S. and Marcellin M. W., 2002, JPEG2000:

Image Compression Fundamentals, Standard and

Practice. Norwell, MA: Kluwer.

Andra K., Chakrabarti C., and Acharya T., 2003, “A high

performance JPEG2000 architecture,” IEEE Trans.

Circuits and Systems for Video Technology, vol. 13,

no. 3, pp. 209–218.

Hsiao Y-T, Lin H-D, Lee K-B and Jen C-W, 2002, “High

Speed Memory Saving Architecture for the Embedded

Block Coding in JPEG 2000”.

Lian C.-J., Chen K.-F., Chen H.-H., and Chen L.-G., 2003,

“Analysis and architecture design of block-coding

engine for EBCOT in JPEG 2000,” IEEE Trans.

Circuits and Systems for Video Technology, vol. 13,

no. 3, pp. 219–230.

Li Y., Aly R.E., Wilso B. and Bayoumi M.A., 2002,

“Analysis and Enhancement for EBCOT in high speed

JPEG 2000 Architectures,” The 45th Midwest

Symposium on Circuits and Systems, 2002.

MWSCAS-2002.

Fang H-C, Wang T-C, Lian C-J, Chang T-H and Chen L-

G, 2002, “High Speed Memory Efficient EBCOT

Architecture for JPEG2000”.

Marpe D., Schwarz H, and Wiegand T., 2003-July,

”Context-Based Adaptive Binary Arithmetic Coding

in the H.264/AVC Video Compression Standard”,

IEEE Transactions on Circuits and Systems for Video

Technology.

Marpe D. and Wiegand T., 2003-Sept., ”A highly Efficient

Multiplication-Free Binary Arithmetic Coder and Its

Application in Video Coding”, Proc. IEEE

International Conference on Image Processing (ICIP

2003), Barcelona, Spain.

Marpe D., George V., Cycon H.L., Barthel K.U., 2003-

Oct, “Performance evaluation of Motion-JPEG2000 in

comparison with H.264/AVC operated in pure intra

coding mode”, Proc. SPIE on Wavelet Applications in

Industrial Processing, Rhode Island, USA.

ICETE 2004 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

316
