Should We Prove Security Policies Correct?

Sebastiano Battiato Giampaolo Bella Salvatore Riccobene

Dipartimento di Matematica e Informatica, Universit

a di Catania

Viale A.Doria, 6 — I-95125 Catania, ITALY

Abstract. Security policies are abstract descriptions of how a system should be-

have to be secure. They typically express what is obligatory, permitted, or forbid-

den in the system. When the system is implemented, its formal veriﬁcation con-

sists in checking whether it conforms to the norms that its policy stated. Hence,

security policies signiﬁcantly inﬂuence the ﬁnal assessment of real systems.

Experience shows that important policies suffering inconsistencies have reached

the ﬁnal stage of implementation in a real system. Here comes the need for formal

analysis at the abstract level of policies. It is advocated that known inductive

techniques and a general-purpose proof assistant can be used proﬁtably for the

proof of correctness of security policies.

1 Introduction

A security policy for a generic system can be informally explained as a set of norms

(rules) stating who can or cannot do what in the system. Security policies underlie

all areas of Computer Science where some form of security is required, ranging from

databases to operating systems, but also pervade the real world. For example, ”access

to record i ought to be forbidden at week-ends” might be part of the security policy

for a DBMS. Likewise, ”in case of ﬁre, one ought to leave the building” is (part of)

the security policy for modern constructions. The examples may raise the intuition that

security policies must enjoy some correctness property.

The motivations for our work are at least twofold. A policy does not describe how

a system behaves or how it is perceived to behave, but, rather, how it should behave

to be secure, whatever the adjective secure means for the system. That ideal behaviour

is exactly what one needs to (and must!) keep in mind when one is verifying a real

system. The system passes the veriﬁcation when it is shown to conform to its intended

functioning speciﬁed in its security policy. It follows that the security policy plays a

major role in the ﬁnal assessment of the real system. But recent experience tells that the

huge policy underlying a huge e-commerce protocol like SET may suffer signiﬁcant

incompleteness (omitted features) or ambiguity (unclear features) [1, 2]. We advocate

that a method for formally verifying abstract system properties at the policy level is

needed.

Research efforts in the analysis of security policies already exist, but they appear

to have succeeded mostly in terms of speciﬁcation rather than of veriﬁcation. A variety

of modal logics are used as speciﬁcation languages, equipped with three deontic opera-

tors, Obligatory, Permitted and Forbidden, which formalize the respective modalities:

Battiato S., Bella G. and Riccobene S. (2004).

Should We Prove Security Policies Correct?.

In Proceedings of the 1st International Workshop on Electronic Government and Commerce: Design, Modeling, Analysis and Security, pages 56-65

DOI: 10.5220/0001389600560065

 SciTePress

obligations, permissions and interdictions. Deontic logics are typically endowed with

systems of inference rules whereby given facts of the logics can be proved or refuted [3,

4]. To our current understanding, what appears to be missing is some mechanism for the

automatic generation of tests, hence a full veriﬁcation method. For example, let us con-

sider a security policy for ﬁle-system access. Checking that a candidate norm such as ”a

System Security Ofﬁcer is permitted to write on system ﬁles” induces no contradiction

is indeed interesting. But verifying that none of the norms for a System Security Ofﬁ-

cer induces contradiction or that no norm at all induces contradiction would be deeper

results, much closer to some notion of policy correctness. Equivalent terminology is

policy consistency.

Absence of contradictions and absence of dilemmas are the basic requirements of

policy correctness. There is a contradiction when something is at the same time permit-

ted and forbidden, or at the same time obligatory and forbidden — for example, ”Bob

is permitted to issue a nonce; Bob is forbidden to issue a nonce”. There is a dilemma

when both something and its opposite are obligatory, or both are forbidden — for exam-

ple , ”it is obligatory that Alice registers her public key; it is obligatory that Alice does

not register her public key”. The speciﬁc application domain may impose additional re-

quirements to policy correctness, such as secrecy, i.e. protecting resources from agents

with insufﬁcient rights, and fairness, i.e. distributing resources equally

Our idea is to use mathematical induction to model security policies. We borrow

concepts from the inductive method to verifying security protocols introduced by Paul-

son [5] and developed with Bella [6, 7]. Each policy norm can be expressed as an in-

ductive rule extending a given trace of norms. The security policy can then be modelled

inductively as the set of all possible traces of norms that the policy admits. Agents and

actions to which the norms apply can be speciﬁed for the sake of expressiveness, or left

as generic members of unbounded sets. Once the policy is a set built up by induction,

the corresponding inductive principle can be used to prove safety properties of the set.

The basic requirements of policy correctness indeed are safety properties. This position

paper sets up and demonstrates the foundations of our approach to verifying security

policies, while the next step is to complete mechanizing the approach with the proof

assistant Isabelle/HOL [8]. The language of Higher Order Logic will make the speciﬁ-

cation of policy properties easier, while Isabelle’s simpliﬁer will resolve the trivial cases

without human intervention. These features will make the analysis of vast policies pos-

sible. If we compare security protocols and security policies in terms of speciﬁcation

efforts, we expect many more, though simpler, rules in the case of policies. Hence, the

human efforts required by the veriﬁcation can be expected to be smaller.

The structure of this position paper is simple. The treatment of security policies

(§2) begins with the concepts of contradictions and dilemmas and terminates with a

published, example policy [9]. Our inductive modelling of policies and their properties

comes next (§3). A few remarks conclude (§4).

2 Security policies

A security policy explains how a system should behave to be considered secure. To take

an example from the real world, modern building evacuation systems are considered

117

secure when the people in the building do follow the security policy to evacuate in case

of ﬁre — people are part of the system. The law inspectors will simply sign a conformity

declaration for the building if it has got a reasonable security policy and its inhabitants

are informed of it. This conﬁrms once more that it is impossible to claim security for a

system that is missing a security policy.

At this stage, we can deﬁne a security policy more formally (Deﬁnition 1).

Deﬁnition 1 (Security Policy). A security policy is a set of norms regulating the modal-

ities — obligations, permissions, interdictions — for a set of agents on some actions.

It is worth remarking that a security policy may be a very large set of norms. Con-

sider the policy regulating the internal functioning of a ﬁnancial institution, for example.

Hundred, if not thousand norms must coexist together, and if it is easy and quick to state

a single, meaningful norm, it is hard to derive a full understanding of how the new norm

will impact the existing kernel [10].

2.1 Modalities

The following treatment develops on a generic action a, which is formalized as a

boolean. This makes it possible to logically relate actions using conventional boolean

connectives.

As mentioned above, the basic requirements towards correctness of a policy are

absence of contradictions and absence of dilemmas. Studying these requirements im-

poses a careful understanding of the semantics of the modalities. Obligatory is the basic

modality, in the sense that all other modalities are deﬁned from it as follows.

Deﬁnition 2 (Permission). An action is permitted if and only if not performing it is not

obligatory:

Permitted(a) , ¬Obligatory(¬a)

Deﬁnition 3 (Interdiction). An action is forbidden if and only if not performing it is

obligatory:

Forbidden(a) , Obligatory(¬a)

Security policies are sometimes enriched with another modality, Waived, expressing

that an action must not necessarily done. This also can be deﬁned in terms of the basic

modality as its logical negation.

Deﬁnition 4 (Waiver). An action is waived if and only if it is not obligatory to perform

it:

Waived(a) , ¬Obligatory(a)

2.2 Contradictions

If an action is permitted, then having it forbidden too is a contradiction according to

common understanding. (What if you read the following public notice: smoking is for-

bidden, and smoking is permitted!). An even more trivial contradiction would be to

118

have an action waived and at the same time obligatory. These may be formalized by

dedicated deﬁnitions, but it is more important to investigate what the general structure

of a contradiction is. It would make it conceivable to check an entire policy against that

structure, so as to verify whether contradictions exist at all.

2.3 Dilemmas

If it is forbidden to perform an action and at the same time not to perform it, this

clearly is a dilemma, because it would make it impossible not to violate the policy.

(What if you read the following public notice: smoking is forbidden, and not smoking is

forbidden!). However, it is not a dilemma that it is waived to perform an action and at the

same time not to perform it, because such a combination just establishes freedom upon

that action. Also dilemmas can be easily formalized by dedicated deﬁnitions, though

a general version of their structure would be more important towards verifying policy

correctness.

2.4 An example policy

As an example, we introduce in Figure 1 a simple, published policy for ﬁle system

access due to Cholvy and Cuppens [9], slightly amended by Bella [10]. Each modality

is abbreviated by its initial. The users of the ﬁle system can play four roles. Norms N1

to N4 state that a normal user (who plays role user) is permitted to read any public ﬁle,

but to write only on those he owns. He is also forbidden to downgrade any ﬁles, and

obliged to change his password if it is old. Norms N5 and N6 state that a secret user

(who plays role secret) is also permitted to read or write on secret (i.e. non-public)

ﬁles. Norm N7 states that a system security ofﬁcer (who plays role sso) is permitted

to downgrade any ﬁle. The last norm is for bad users (who play role bad), those who

have for example forgotten to change their password for too long. The norm forbids all

actions to bad users.

Each policy norm is simple, but the policy as a whole is complex because of the

obvious constraints on roles. Secret users are in fact also users; system security ofﬁcers

are also secret users; bad users may be either users or secret users. These constraints

should also be composed using a transitivity relation, yielding for example that system

security ofﬁcers also are users. With these constraints, it is not trivial to get a synergic

understanding of the entire policy. Just to anticipate a contradiction, notice that norms

N3 and N7 cause a contradiction on action downgrade(a, f) because a system security

ofﬁcer is also a normal user. A more systematical study on whether the policy suffers

other problems is presented later (§3).

3 An inductive approach to policy veriﬁcation

Our idea is to formalize a security policy as the set of all admissible traces of norms.

A trace of norms can be interpreted as a possible reduction of the policy to speciﬁc

actions. It is the same idea that turned out successful with security protocols [6, 5]. The

119

N1: N2:

if play(a,user) and public(f) if play(a,user) and public(f)

then and owner(f,a) then

P(read(a,f)) P(write(a,f))

N3: N4:

if play(a,user) if play(a,user) and password(a,p)

then and old(p) then

F(downgrade(a,f)) O(change password(a))

N5: N6:

if play(a,secret) and not(public(f)) if play(a,secret) and not(public(f))

then and owner(f,a) then

P(read(a,f)) P(write(a,f))

N7: N8:

if play(a,sso) if play(a,bad)

then then

P(downgrade(a,f)) F(read(a,f))

F(write(a,f))

F(downgrade(a,f))

F(change password(a))

Fig. 1. An example security policy for ﬁle-system access [9]

set is deﬁned by induction, and properties of interest can be proved about it using the

corresponding induction principle.

As in the previous section, a generic action is formalized here as the boolean vari-

able a. In consequence, asserting a indicates that the corresponding action is performed,

while asserting ¬a indicates that the same action is not performed.

3.1 Modelling a policy

If P is declared as a set of traces of norms, it can be deﬁned inductively as follows.

– The empty trace belongs to P.

– Extending a trace of P with a norm stated by the policy yields a trace of P.

The example policy in Figure 1 can be formalized accordingly, as in Figure 2. Fat

square braces denote rule preconditions, while # is the list cons operator.

Here, agents and ﬁles have been formalized as freetypes, and agent roles as a

datatype. The constraints on roles can be trivially introduced as axioms of implica-

tional form, such as play(a, secret) → play(a, user). The modalities can be deﬁned in

terms of the basic modality, according to deﬁnitions 2, 3 and, if needed, 4.

A remark is necessary about consequential policies, which apply some norms on the

basis that other norms apply. For example, we may have a policy rule stating that if a

secret user is permitted to read secret ﬁles, then so is a system security ofﬁcer. These can

be modelled inductively without extra efforts. Our example policy is not consequential.

120

Base: [ ] ∈ P

N1: [| nms1 ∈ P; play(a,user); public(f) |]

=⇒ P(read(a,f)) # nms1 ∈ P

N2: [| nms2 ∈ P; play(a,user); public(f); owner(f) |]

=⇒ P(write(a,f)) # nms2 ∈ P

N3: [| nms3 ∈ P; play(a,user) |]

=⇒ F(downgrade(a,f)) # nms3 ∈ P

N4: [| nms4 ∈ P; play(a,user); password(a,p); old(p) |]

=⇒ O(change

password(a)) # nms4 ∈ P

N5: [| nms5 ∈ P; play(a,secret); ¬public(f) |]

=⇒ P(read(a,f)) # nms5 ∈ P

N6: [| nms6 ∈ P; play(a,secret); ¬public(f); owner(f,a) |]

=⇒ P(write(a,f)) # nms6 ∈ P

N7: [| nms7 ∈ P; play(a,sso) |]

=⇒ P(downgrade(a,f)) # nms7 ∈ P

N8: [| nms8 ∈ P; play(a,bad) |]

=⇒ F(read(a,f)) # F(write(a,f) #

F(downgrade(a,f) # F(change password(a)) # nms8

∈ P

Fig. 2. Modelling the example policy inductively

3.2 Modelling and proving policy properties: sanity checks

A crucial issue in formal veriﬁcation is to build a realistic model. As a form of sanity

check, we can prove a trivial, subsidiary lemma.

Lemma 1 (Permission w.r.t Interdiction). If an action is permitted, then it is not for-

bidden:

Permitted(a) → ¬Forbidden(a)

Proof. By deﬁnitions 2 and 3.

When the proof is conducted on a theorem prover, the deﬁnitions are installed as

simpliﬁcation rules, hence a single appeal to the simpliﬁer solves the theorem. It may

be interesting to look at the converse lemma.

Lemma 2 (Interdiction w.r.t Permission). If an action is forbidden, then it is not per-

mitted:

Forbidden(a) → ¬Permitted(a)

Proof. Converse of Lemma 1. Alternatively, by deﬁnitions 2 and 3.

121

3.3 Modelling and proving policy properties: no contradictions

As we are working towards a mechanization on a proof assistant, it is preferable to de-

ﬁne the policy properties in their simplest form. All deﬁnitions can be used as simpliﬁ-

cation rules to prove more complex properties, perhaps not of immediate understanding,

by reducing them to the simple ones.

As for contradictions, we have come to the conclusion that their general structure

can be expressed as in the following deﬁnition.

Deﬁnition 5 (Contradiction). An action leads to contradiction if and only if it is at

the same time obligatory and not obligatory, or not to perform it is at the same time

obligatory and not obligatory:

contradiction(a) , (Obligatory(a) ∧ ¬Obligatory(a)) ∨

(Obligatory(¬a) ∧ ¬Obligatory(¬a))

Our deﬁnition should be read as the simplest form of contradiction, although its

intuitiveness may be subject to debate. Other, more elaborated, contradictions (such as

those mentioned above, §2.2) can be simpliﬁed into this, as expressed by the following

theorems.

Theorem 1. If an action is both permitted and forbidden, then it leads to contradiction:

Permitted(a) ∧ Forbidden(a) → contradiction (a)

Proof. By Lemma 1 and deﬁnitions 3 and 5. Alternatively, by Lemma 2 and deﬁnitions 2

and 5. Alternatively, by deﬁnitions 2, 3 and 5.

Theorem 2. If an action is both waived and obligatory, then it leads to contradiction:

Waived(a) ∧ Obligatory(a) → contradiction (a)

Proof. By deﬁnitions 4 and 5.

3.4 Modelling and proving policy properties: no dilemmas

We have also deﬁned the simplest structure for dilemmas as in the following deﬁnition.

Deﬁnition 6 (Dilemma). An action leads to dilemma if and only if it is at the same

time obligatory to perform it and not to perform it:

dilemma(a) , Obligatory(a) ∧ Obligatory(¬a)

Given the simplest form of a dilemma, more elaborated situations in fact are dilem-

mas if they can be reduced to that form. The following theorem is elementary to prove

but signiﬁcant. Theorems of the same form can be analogously proved also for the other

two modalities.

122

Theorem 3. If an action is forbidden and so is not to perform it, then it leads to

dilemma:

Forbidden(a) ∧ Forbidden(¬a) → dilemma (a)

Proof. By deﬁnitions 3 and 6.

The notions introduced so far are intuitive but may be tricky. For example, the reader

may notice that Deﬁnition 6 is missing some symmetry with respect to Deﬁnition 5. In

particular, one may be tempted to enrich it with a second disjunct and obtain

(Obligatory(a) ∧ Obligatory(¬a)) ∨ (¬Obligatory(a) ∧ ¬Obligatory(¬a))

However, the second disjunct is logically equivalent, by Deﬁnition 4, to

Waived(a) ∧ Waived(¬a)

which clearly must not count as a dilemma because if an action is waived and so is not

to perform it, then there just is augmented freedom.

3.5 Modelling and proving policy properties: correctness

Absence of contradictions and dilemmas is the basic requirement of policy correctness

(plus others, depending on the application domain).

If the policy is modelled as an inductively deﬁned set, we would like to establish

those properties on every trace of the set. To do so, we must lift our deﬁnitions of

contradiction and dilemma over traces. Below, set turns a list into the set of elements of

the list.

Deﬁnition 7 (Contradiction on Trace). An action leads to contradiction on a trace if

and only if there exists an action that leads to contradiction by means of norms of the

trace:

contradiction(a, nms) , (Obligatory(a) ∈ set nms ∧ ¬Obligatory(a)) ∈ set nms ∨

(Obligatory(¬a) ∈ set nms ∧ ¬Obligatory(¬a) ∈ set nms)

Deﬁnition 8 (Dilemma on Trace). An action leads to dilemma on a trace if and only

if there exists an action that leads to dilemma by means of norms of the trace:

dilemma(a, nms) , Obligatory(a) ∈ set nms ∧ Obligatory(¬a) ∈ set nms

Deﬁnition 9 (Policy Correctness). Correctness of a security policy holds if and only

if its inductive model P does not suffer any contradictions or dilemmas for any actions

on any of its traces:

correctness (P) , ∀ nms a.

nms ∈ P → ¬contradiction(a, nms ) ∧ ¬dilemma (a, nms )

If we attempt to prove this property with the help of a theorem prover, should the prop-

erty fail, the prover would exhibit the counterexample showing which action and which

norm contradict the property on which trace.

123

3.6 On the example policy

If we attempt to prove correctness of the example policy, the inductive proof will fail

at several stages. For example, in case of norm N7, proceeding backward the prover

simpliﬁes ¬Permitted(downgrade(a, f)) to Obligatory(¬downgrade(a, f )). We need

to contradict the latter fact to close the proof. A dedicated subproof would show that it

is impossible in case a also is a normal user, due to norm N3. This is more entangled

to describe than to verify even by pen-and-paper, let alone with the help of a proof

assistant. The constraints of the system on agent roles must be stated because the prover

will ask us to address the case when agent a of norm N7 matches agent a of norm N3.

The constraints tell that they can match, hence a contradiction on the corresponding

actions is possible.

The example policy hides a number of other contradictions (not of interest in this

paper) but no dilemma. For the sake of demonstration, we can imagine to extend the

policy with an intuitive rule that waives system security ofﬁcers from changing their

password when it is old. The policy model can easily account for the change by includ-

ing the extra rule given in Figure 3.

N9: [| nms9 ∈ P; play(a,sso); password(a,p); old(p) |]

=⇒ W(change password(a)) # nms9 ∈ P

Fig. 3. An extra policy rule leading to dilemma

A putative proof that the policy does not suffer dilemmas (towards a proof of policy

correctness) can be conducted by inductive arguments similar to those given above. It

would fail at least on the trace of norms where both norms N4 and N9 applied, due to

the constraints on agent roles.

4 Conclusions

Security policies are typically analyzed using dedicated modal logics. The existing liter-

ature supports the claim that veriﬁcation in this ﬁeld lacks mechanization. It is important

to verify using the calculus of the logic that a given candidate leads to contradiction or

dilemma. It would be more important to either verify that there is no such candidate or

to exhibit such a candidate.

This can be done using an inductive method to modelling and verifying policies. We

intend to mechanize the method with the help of a proof assistant such as Isabelle. The

prover will hold the burden of simplifying expressions, thus making it possible to cope

with large policies. Having done that, testing the method on real-world policies will be

possible.

We have provided inductive deﬁnitions for absence of contradictions and absence

of dilemmas, the basic components of protocol correctness. Other components can be

added but the foundational treatment is already available at present.

124

References

1. Bella, G., Massacci, F., Paulson, L.C.: Verifying the SET Registration Protocols. IEEE

Journal of Selected Areas in Communications 21 (2003) 77–87

2. Bella, G., Massacci, F., Paulson, L.C., Tramontano, P.: Formal Veriﬁcation of Cardholder

Registration in SET. In Cuppens, F., Deswarte, Y., Gollmann, D., Waidner, M., eds.: Proc. of

the 6th European Symposium on Research in Computer Security (ESORICS 2000). LNCS

1895, Springer-Verlag (2000) 159–174

3. Cholvy, L.: Checking Regulation Consistency by using SOL-resolution. In: International

Conference on Artiﬁcial Intelligence and Law. (1999) 73–79

4. Cuppens, F., Saurel, C.: Specifying a Security Policy: A Case Study. In: Proc. of the 9th

IEEE Computer Security Foundations Workshop, IEEE Press (1996)

5. Paulson, L.C.: The Inductive Approach to Verifying Cryptographic Protocols. Journal of

Computer Security 6 (1998) 85–128

6. Bella, G.: Inductive Veriﬁcation of Smart Card Protocols. Journal of Computer Security 11

(2003) 87–132

7. Bella, G., Paulson, L.C.: Mechanical Proofs about a Non-Repudiaton Protocol. In Boulton,

R.J., Jackson, P.B., eds.: Proc. of the 14th International Conference on Theorem Proving in

Higher Order Logics (TPHOLs’01). LNCS 2152, Springer-Verlag (2001) 91–104

8. Paulson, L.C.: Isabelle: A Generic Theorem Prover. LNCS 828. Springer-Verlag (1994)

9. Cholvy, L., Cuppens, F.: Analyzing Consistency of Security Policies. In: Proc. of the 16th

IEEE Symposium on Security and Privacy, IEEE Press (1997)

10. Bella, G.: Interactive Simulation of Security Policies. In Panda, B., ed.: 17th ACM Sympo-

sium on Applied Computing, ACM Press and Addison Wesley (2002) 242–252

125
