IMPLEMENTING MULTIPLE CHANNELS OVER SSL

Yong Song, Victor C.M. Leung, Konstantin Beznosov

Department of Electrical and Computer Engineering,University of British Columbia, Vancouver,Canada

Keywords: Communication security, Mobile security, Multiple channels, SSL

Abstract: Multiple-Channel SSL (MC-SSL) is our model and protocol for the security of client-server

communication. In contrast to SSL, MC-SSL can securely provide applications with multiple channels, and

each of them can have a specific cipher suite and a various number of application proxies; meanwhile, the

channel negotiation and operation in MC-SSL are still based on SSL, which needs a small change in order

to support multiple cipher suites. In this paper, we first introduce the multiple-channel model of MC-SSL,

and then focus on the design and implementation of multiple channels over SSL, especially multi-hop proxy

channels and secondary channels.

1 INTRODUCTION

To address several limitations of TLS/SSL (Dierks,

1999) (referred as SSL in this paper), we have

proposed multiple-channel SSL (MC-SSL) (Song,

2004). Based on vanilla SSL, MC-SSL has several

advantages over it. First, MC-SSL supports a various

number of application proxies (or gateways)

between a client and a server. Second, MC-SSL

supports multiple cipher suites in a single connection

so that client and server can negotiate multiple

cipher suites for different data or contents. Third,

new factors such as security policies, device

capabilities, and security attributes of data are taken

into account in the security model of MC-SSL. As a

result, the multiple-channel nature of MC-SSL

enables MC-SSL to flexibly meet diverse security

requirements from different terminals, servers,

applications, and users. In particular, MC-SSL can

help resource-constrained devices such as PDAs and

cellular phones because they may need application

proxies for proxy services such as content

transformation or virus scanning, and also they can

save battery power and CPU time by using multiple

cipher suites.

MC-SSL supports two types of channels

between a client and a server: end-to-end and proxy

channels. The proxy channel protocol is described

(Song, 2004). This paper reports on the next step in

this work, design and implementation of multiple

cipher suites as well as an extension of single-hop

proxy channels to multi-hop proxy channels. The

prototype implementation demonstrates that the

design of MC-SSL protocol is feasible.

The rest of this paper is organized as follows.

Section 2 analyses the functional limitations of SSL

that motivated this work. Section 3 describes MC-

SSL. Section 4 discusses related work. Section 5

focuses on the design and implementation of MC-

SSL protocol. Section 6 concludes the paper.

2 PROBLEM MOTIVATION

SSL is a de facto security protocol at transport layer,

but it has some functional limitations. First, while

SSL can provide a secure point-to-point connection,

it does not securely support application proxies. If a

proxy P is involved between a client C and a server

S, C would normally set up an SSL connection with

P, and then P would act as the delegate of C and set

up another SSL connection with S. The purpose of

proxies could be virus scanning, content

transformation, or compression. An example of such

an SSL chain proxy model is the WAP gateway

architecture, in which the connection between C and

P is over WTLS, a variant of TLS protocol. The SSL

chain proxy model is shown in the lower part of

Figure 1, in which there is a various number of

proxies from P

to P

. Since any proxy in the chain

can read and modify sensitive data at will, this

model assume unconditional trust in all proxies at

least from one side of the connection. This can be

satisfied only if all proxies are administrated by the

organization or individual that also administrates C

246

Song Y., C. M. Leung V. and Beznosov K. (2004).

IMPLEMENTING MULTIPLE CHANNELS OVER SSL.

In Proceedings of the First International Conference on E-Business and Telecommunication Networks, pages 246-253

DOI: 10.5220/0001406302460253

 SciTePress

(or S). In other cases, C (or S) has to take risks of

information leakage and tampering unless the

exchanged information is non-sensitive.

C S

SSL

Figure 1: SSL end-to-end model and chain proxy model

The second limitation of SSL is that it can

employ only one cipher suite in a connection.

Although SSL allows re-negotiating the cipher suite

of a connection, frequent re-negotiations are

inefficient because of the message interaction and

certificate verification in the handshake protocol.

Besides, SSL only provides a duplex channel in

which the ciphers suites in both directions must be

the same at any time. If requests and responses need

different protection, then a client and a server have

to change cipher suite in every round, which is

inefficient for most applications. Accordingly, lots

of data is overly protected. For instance, a handheld

user checks email all day. She wants encryption for

the id/password of her email account when sending

requests but she does not require extra

confidentiality for her emails. It is good enough for

the user to have reasonable level of confidentiality

protection for the id/password, but no encryption for

email contents. This way, the battery power is

preserved. To summarize, the requirement for

communication security does not entail the strongest

cipher; moreover, security is tightly related to other

requirements. The SSL’s support for one cipher suite

at a time combined with the relatively high cost of

changing suites just in time makes it difficult for

applications to optimize the strength of data

protection according to the changes in the sensitivity

of the data in the channel.

In addition, to allow S to take various factors

into account and optimize the combination of

different channels, C may want to send S its

terminal capabilities and security policy. For

example, C may define whether proxies are allowed

to process data with sensitivity below a certain level,

and what cipher suites are strong enough to protect

data with a certain level of sensitivity. Lack of

negotiation support for proxies and multiple cipher

suites is the third limitation of SSL. These functional

limitations form a mismatch gap between the

capabilities of SSL and the requirements of the

applications with performance, power, and other

constrains. When mobile applications become more

popular, the gap will become more apparent. The

intent of MC-SSL design is to narrow this gap.

3 HIGH LEVEL DESCRIPTION OF

MC-SSL

Three key features of MC-SSL help us to address the

above limitations of SSL. Going in reverse order,

MC-SSL supports channel negotiation according to

the parties’ security policies, device capabilities, and

security attributes of data. To address second

limitation (only one cipher suite at a time and for

both directions), MC-SSL supports multiple cipher

suites and simplex channels with a specified traffic

direction. To address the first limitation (the

dilemma between unconditionally trusted proxies

and no proxy at all), we introduce proxy channels to

support partially trusted proxies.

In SSL, a channel is associated with a cipher

suite, which consists of a key exchange algorithm, a

cipher, and a hash algorithm, e.g., {RSA,

3DES_EDE_CBC/168, SHA-1}. The hash algorithm

is used to compute Message Authentication Code

(MAC). In MC-SSL, a cipher suite consists of only

two elements: a cipher for data encryption and

decryption, and a hash algorithm for MAC. We can

define it as a structure as follows:

{cipher and key size, hash algorithm for MAC} (1)

A MC-SSL connection can have multiple cipher

suites. We can characterize a point-to-point

connection as follows: {point 1, point 2, key

exchange algorithm, {cipher suite 1, cipher suite 2,

…}}, where each cipher suite forms a channel. Note

that the key exchange algorithm no longer belongs

to a cipher suite, but become an attribute of a

connection. Every MC-SSL connection must first

negotiate a cipher suite strong enough to form the

primary channel, the backbone for setting up and

controlling other channels in the same connection. A

primary channel is the first channel in a connection,

and it is established using the unchanged SSL

protocol. Other channels in an MC-SSL connection

are referred as secondary. They are new channels

added to an SSL connection so as to support

multiple cipher suites per connection. The sample

connection shown in Figure 2 can be characterized

as {A, B, RSA, {CS1, CS2, CS3, CS4}}, where

RSA is the key exchange algorithm, and CS1

through CS4 are cipher suites for channels 1 to 4.

Among them, channel 1 is the primary channel. The

protocol to support multiple cipher suites is

IMPLEMENTING MULTIPLE CHANNELS OVER SSL

247

described and discussed in Section 5.2. Secondary

channels are further divided into end-to-end and

proxy ones.

A B

Figure 2: Multiple cipher suites inside a connection

Figure 3: Proxy channel model of MC-SSL

Figure 4: Multiple-channel model of MC-SSL

Figure 3 shows the proxy model of MC-SSL, in

which point-to-point SSL connections collectively

form a shape of arc. C-S is an end-to-end channel,

and C-P

- … -P

-S is a proxy channel. In this model,

C-P

- … -P

-S is no longer an independent chain

proxy channel, as in Figure 1. Instead, it relies on the

C-S channel to do channel negotiation and

application data transportation. Besides, C or S can

deliberately choose one of the two channels to

transport data according to the protection

requirements of data so that sensitive information,

such as passwords and credit card numbers, do not

have to be disclosed to a third-party proxy. An MC-

SSL session can have zero or more proxy channels.

Each of them and the corresponding end-to-end

channel follow the proxy model illustrated in Figure

3. The protocol to negotiate a single-hop proxy

channel has been described in (Song, 2004). Section

5.1.2 of this paper discusses the multi-hop proxy

channel protocol.

A combination of the proxy model and the

multiple cipher suites is illustrated in Figure 4. In

MC-SSL, a channel is defined as a communication

“pipe” with or without intermediate application

proxies. Two MC-SSL endpoints communicate with

each other through the pipe using a cipher suite. In

addition, a channel can be either duplex, or simplex

with a flow direction. An MC-SSL channel is

characterized by the following set of attributes:

channel ≡ {ID, E

, E

, CS, {P

, P

, …, P

}, D} (2)

ID is the identifier of a channel in an MC-SSL

session context. E

and E

are either DNS names or

IP addresses of the corresponding endpoints. Cipher

suite, CS, is defined by expression (1). A proxy (P

)

is identified by its DNS name or IP address. A

channel can have zero or more proxies. If a channel

has no proxies, then it is an end-to-end channel.

Direction, D, indicates whether a channel is a duplex

channel, or a simplex channel pointing to one of the

two endpoints. The sample MC-SSL session in

Figure 4 has five channels. Among them, channel 1

and 4 are primary channels, and others are secondary

channels. Channel 2, 3, and 4 are negotiated through

channel 1, and channel 5 is negotiated through

channel 4. In addition, only channel 1 is a duplex

channel for application data; others are simplex

channels from S to C. For the client application, C

uses channel 1 to send encrypted requests to S, and S

may choose one of the five channels to send back

responses.

4 RELATED WORK

To avoid information leakage in the case of SSL

proxy chain, one approach is to use encryption-

based tunnelling to make data unreadable to a proxy.

For instance, Kwon et al. (Kwon, 2001) require C to

encrypt data twice: first for S using K

, and then for

a proxy using K

. Consequently, the proxy cannot

perform functions such as content transformation

and/or scanning. Another approach is to

simultaneously have an end-to-end SSL connection

and an SSL chain between C and S, both shown in

Figure 1. To provide confidentiality, sensitive data is

sent through the end-to-end connection. This is a

typical approach, employed, for instance, by

(Kennedy, 2000), but it is insecure because proxies

impersonate C to interact with S. Most servers today

still authenticate their clients using id/password. If a

proxy keeps a client’s id/password, then it can

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

248

impersonate C in unconstrained fashion. There are a

number of solutions for C to avoid exposing

id/password, such as sharing the master key or the

symmetric session keys with proxies, or helping a

proxy sign the verification data. However, a proxy

can still impersonate C during a particular session

and conduct person-in-the-middle attacks. MC-SSL

is securer than this approach simply because every

proxy is authenticated with its genuine identity;

therefore, there is no impersonation in MC-SSL.

Portmann and Seneviratne proposed a simple

extension to SSL to get an extra cleartext channel in

an SSL connection (Portmann, 2001). However, the

security strength of this method is questionable

because the cleartext channel is granted without

negotiation and operated without control. Moreover,

this method is not capable of creating other types of

channels.

Finally, we would like to compare MC-SSL with

XML security solutions including XML Security

(W3C, 2002) and Web Services Security (WSS)

(IBM, 2002; OASIS, 2003). XML Security is a set

of core specifications that define XML syntaxes to

represent encryption, hash, and digital signature.

WSS is a framework that unites a number of existing

and emerging specifications for the purpose of

constructing comprehensive security solutions for

XML-based Web services. WSS uses XML Security

as a building block. Compared with XML Security

and Web Services Security, MC-SSL is a complete

and compact protocol under application layer and is

able to provide authentication, key exchange, and

secure data transportation for client-server

applications with or without proxies. On the other

hand, both XML Security and WSS are not self-

contained protocols, and they do not attempt to

specify a fixed security protocol for authentication

and key exchange so that they can have the

extensibility and flexibilities to integrate existing or

new security technologies at different layers. As

with SSL, MC-SSL can be combined with XML

Security, or adopted by WSS for securing Web

Services. For example, by combining XML Security

with MC-SSL, an application can use MC-SSL to do

authentication and key exchange for client, server,

and proxies, and use XML Security to perform

complex encryptions and/or digital signatures on

application data. Similarly to SSL, MC-SSL appears

to be a more efficient solution than WSS/XML

Security for those applications that require bulk

protection of data because it avoids key

negotiation/generation for each individual message.

5 DESIGN AND

IMPLEMENTATION

A channel of MC-SSL can be categorised according

to different criteria. It could be a proxy channel if

there is at least one proxy in the channel; otherwise,

it is an end-to-end channel. In comparison, the

concept of a primary channel and a secondary

channel is not as obvious as the previous criterion.

As mentioned earlier in Section 3, a primary channel

is the first channel in a connection, and it is the basis

for secure negotiation and control of secondary

channels in the same connection. Besides, a primary

channel is actually the channel negotiated by the

unchanged SSL protocol. The purpose of secondary

channels is to provide multiple cipher suites;

therefore, if an application does not need multiple

cipher suites but need proxy support of MC-SSL, the

implementation of MC-SSL can keep SSL libraries

intact (Song, 2004).

In this section, we first discuss the protocol for

primary channels in Section 5.1, and then discuss the

protocol for secondary channels in Section 5.2. This

is also the natural order in an MC-SSL session

because secondary channels are “dependents” of

primary channels. Due to the space limitation, we

omit the description of the simple parts of the

protocol, such as the removal of a channel or the

modification of channel parameters.

5.1 Primary Channels

Primary channels can be classified into two types of

channels: end-to-end and proxy. In an MC-SSL

session, there is only one primary end-to-end

channel, which is illustrated as channel 1 in Figure

4; on the other hand, there could be a various

number of primary proxy channels. Figure 4 only

shows one such channel, that is, channel 4.

5.1.1 Primary End-to-end Channel and Primary

Single-hop Proxy Channel

We have described the protocol to negotiate and

make use of the primary end-to-end channel and

primary single-hop proxy channels (Song, 2004).

The protocol was referred as MC-SSL proxy

protocol because the negotiation of the primary end-

to-end channel is simply achieved by the re-use of

vanilla SSL. In the next section, we extend a primary

single-hop proxy channel to a primary multi-hop

proxy channel.

IMPLEMENTING MULTIPLE CHANNELS OVER SSL

249

5.1.2 Primary Multi-hop Proxy Channel

A single-hop proxy channel is obviously simpler

than a multi-hop one. This is why we always try to

combine multiple proxies into one proxy by forming

a proxy “cluster” that has a “cluster head” to act as

the representative. However, we kept the multi-hop

proxy capability of MC-SSL in because multi-hop

proxy channel might be necessary due to

administrative or security reasons. Also, a multi-hop

proxy channel is more general than a single-hop one,

and thus makes the model of MC-SSL more

complete and versatile.

First, we consider the simplest way to extend the

protocol for a single-hop proxy channel (Song,

2004), that is, to iteratively reuse the message

interaction between a proxy and a server for the

interaction between any two neighbouring proxies

shown in Figure 3. There are still some small

changes to all the request messages. They are

extended to carry information of multiple proxies. In

the stage of C-S handshake, C and S need to

exchange the information about IP addresses (or

DNS names), listening TCP ports, and even

certificates (or their URLs) of all proxies. Likewise,

the request message in the C-P

handshake is also

extended to contain information of multiple proxies.

After the C-P

handshake is done, P

connects to P

as the P-S handshake in the single-hop proxy

channel protocol does. This process continues

iteratively until the last proxy (P

in Figure 3)

connects to S.

After the handshake process is finished, every

entity in Figure 3 has authenticated its two

neighbours if we topologically look at the structure

in Figure 3 as a circle. Therefore, C can

transitionally trust proxies from P

to P

, and S has

similar transitional trust to proxies from P

to P

n-1

well. In the case of a single-hop proxy channel, there

is no need for transitional trust because C and S

have authenticated P by themselves. However, we

believe that transitional trust to proxies is good

enough for many applications because proxy

channels in MC-SSL are supposed to transport

relatively non-sensitive data.

Further, we can enhance this transitional trust

model by appending new message interactions to the

above handshake process. The enhancement is based

on the following two considerations: First, other

proxies than P

may also require authenticating C by

themselves, and then authorizing their proxy

services accordingly. Our solution is to help C

distribute its certificate and the verification data if C

can use a certificate for authentication. Second, S or

C might want to directly authenticate all proxies, in

other words, to verify the certificate of every proxy.

In order to satisfy these two requirements of

authentication, we have designed a protocol that

consists of two stages illustrated in Figure 5(a) and

(b). The rationale is to first obtain a random string or

number, and then ask C and all proxies to “sign” the

random string using their own private keys. The

“signatures” (verification data) are circulated and

used for identity verification.

Figure 5(a) shows the first stage, which purpose

is to generate a random string that is a concatenation

of random strings produced by all the entities in the

circle. The resultant string can be denoted as

follows:

R = R

+ R

+ …+ R

denotes a 32-byte cryptographically random

string generated by entity X, and ‘+’ denotes the

concatenation of two strings. This process starts and

ends at C. The message sent by C to P1 contains R

and finally C receives the complete random string

from S. The purpose of collectively generating a

random string is to make sure that no entity can be

“deceived” by other entities to accept a random

string that is not truly random. This method is

actually an extension of SSL, in which only two

entities (C and S) are involved.

+...+R

R = R

+...+R

{R, S

}

{R, S

}{R, S

+...+S

}

+...+S

}

Figure 5: The enhanced authentication:

(a) first stage (b) second stage

Figure 5(b) shows the second stage. C first sends

P1 a message, which contains the random string

generated in the first stage, the certificate (or its

URL) of C, and the digital signature signed upon R

using C’s private key. The signature proves that C is

the owner of the certificate. Each proxy adds a new

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

250

signature using its private key corresponding to its

own certificate; meanwhile, each proxy can verify

C’s identity using C’s certificate. S

in figure 6

denotes the signature of entity X. When the message

arrives at S, it has collected the signatures of all

proxies, and therefore S can choose to verify them

using their certificates. S can also forward them to C

so that C can verify them as well.

For the first stage, we add a new field in all the

proxy request messages and the S-C proxy finish

message to carry forward the random string, a flag

field to indicate if S or C requests verification of

proxies’ certificates, and another flag field to

indicate if any proxy requests verification of C’s

certificate. If the flag fields indicate that no

verification is required, the second stage will not

start. For the second stage, we create a new message

called MSG_CP_VERIFICAION to carry all the

necessary information. This protocol ends with a

MSG_CP_VERI_FINISH message from C to S.

The protocol described above is about the

authentication of proxies and the client. We may

also need to consider the security issues of

transporting and processing application data through

proxies. For example, an application may want to

make sure that every chunk of data goes through

every proxy in the proxy channel. To achieve data

authenticity, we can ask every proxy to “sign” the

data chunk using its private key or MAC key.

However, that obviously introduces heavy

computational burden because C or S has to deal

with every chunk of data. The cost for this kind of

protection seems too high for the same reason we

mentioned before: a proxy channel is not supposed

to transport highly sensitive data unless all the

proxies in the channel are highly trustable, and in

that case, the transitional trust model without strict

authenticity should be sufficient.

5.2 Secondary Channels

Up to this point, the protocols we described cannot

provide multiple cipher suites (or multiple channels)

inside a point-to-point connection. The only channel

we have is the primary channel provided by the

unchanged SSL protocol. In this section, we discuss

the protocols to negotiate and make use of secondary

channels. Every secondary channel can have its own

cipher suite and direction different from the

corresponding primary channel. In addition,

similarly to a primary channel, a secondary channel

can also be categorized as a secondary proxy

channel or a secondary end-to-end channel.

5.2.1 Negotiation of Secondary Channels

The negotiation process of secondary channels is

shown in Figure 6. The negotiation of secondary

end-to-end channels (shown in the A part) is much

simpler than that of secondary proxy channels

(shown in B part). Two new message formats are

added: the secondary channel request message

(SEC_CHAN_REQ), and the secondary channel

response message (SEC_CHAN_RESP). They are

required to be transported through primary channels.

In MC-SSL, messages for channel negotiation (or

management) must be transported using primary

channels so that all channel negotiation is as secure

as primary channels, which are provided by SSL. In

addition, both the request and the response messages

for secondary channels are able to carry requests and

responses for multiple secondary channels. The

purpose of this design is to reduce repetitive

negotiation if an application wants to negotiate more

than one secondary channel at some time, especially

at the beginning of an application session.

SEC_CHAN_REQ

SEC_CHAN_RESP

SEC_CHAN_REQ

SEC_CHAN_RESP

. . .

SEC_CHAN_REQ

SEC_CHAN_RESP

Figure 6: Negotiating secondary channels

In Figure 6, SEC_CHAN_REQ is the request

message for multiple secondary channels. For each

secondary channel, it carries information as follows:

the id of the secondary channel, the id of the

collaborative end-to-end channel if the secondary

channel is a proxy channel, a list of cipher suites

preferred by the message sender, and the data flow

direction of the channel. The collaborative end-to-

end channel of a proxy channel is the end-to-end

channel through which data control messages

(APP_DATA_CONTROL_PROXY) are transported

when application data is transported through the

proxy channel. Please refer to another paper (Song,

2004) for more explanation of the application data

protocol. SEC_CHAN_RESP is the response

IMPLEMENTING MULTIPLE CHANNELS OVER SSL

251

message for channel requests in SEC_CHAN_REQ

message.

For MC-SSL to support multiple cipher suites,

we decide to make a small extension to SSL (This

will be explained in the next section). However, it is

possible that the SSL implementation at C and/or S

does not support the new extension for MC-SSL. In

that case, the negotiation of secondary channels will

either fail or not start at all.

5.2.2 Extension of SSL for Secondary Channels

SSL is the basis of the design and the

implementation of MC-SSL. In order to support

multiple channels, we propose to slightly extend

current SSL protocol, that is, to add a new field in

every SSL packet. The new field is channel id,

which indicates the channel that a packet comes

from so that the receiver can choose the right cipher

suite to decrypt and verify the data fragment

encapsulated in the packet. The purpose of channel

id is to realize (de)multiplexation inside an SSL

connection.

Considering that other new extensions may

emerge to require changing the packet format of the

SSL record protocol as MC-SSL does, we prefer

adding a general extension field so that future

extensions or options can be accommodated without

change. A similar extension mechanism has been

introduced into the client and server hello messages

of SSL handshake protocol. RFC 3546 has the

details for TLS extensions (Blake-Wilson, 2003). In

fact, many Internet protocols such as TCP and IP

have fields in their packet formats for options or

future extensions.

Because of the introduction of channel id field,

several changes regarding SSL protocol and its

implementations follow. First, the calculation of the

MAC must include the value of channel id field if a

SSL packet has a MAC field; therefore, the channel

id will not be tampered at will. Second, SSL

software must choose the right cipher suite for each

incoming packet according to the channel id. The

mapping relation between a channel id and a cipher

suite is managed by the protocol described in section

5.2.1. Third, some API (Application Programming

Interface) functions of SSL are different than before:

the write function has a channel id as an input

parameter, and the read function returns as an output

parameter the id of the channel from which the data

comes. It is up to applications to decide how to use

different channels.

Obviously, adding a channel id field is a simple

and straightforward approach for SSL to support

multiple cipher suites. The downside is that the SSL

protocol has to be revised and SSL software needs

upgrade to a new version. To completely avoid the

change of SSL protocol and implementation, we

have figured out a possible alternative for SSL

libraries such as OpenSSL (OpenSSL, 2004). The

basic idea is to “switch” among different channels

instead of simultaneously having multiple channels

in a SSL connection. The switching of channels is

realized by a handshake process implemented in the

upper layer codes of MC-SSL instead of the

underlying SSL. Basically, one endpoint sends a

MC-SSL message to notify the other endpoint what

channel it wants to switch to, and then receive the

confirmation message from the other endpoint. After

that, MC-SSL automatically changes the working

cipher suite in the SSL session. However, things are

not finished yet. First, it is much harder to switch the

working cipher suite for proxy channels, especially

multi-hop proxy channels. Second, if we change the

working channel to a cleartext channel (null cipher

suite without MAC), and then when we want to

switch it back to the primary channel, we must make

sure that the handshake messages are not tampered

by a man-in-the-middle attacker; otherwise, we

could be deceived to use a channel that is

cryptographically weaker. As a result, we must make

one more handshake through the new channel to

exchange the MAC data that is calculated upon the

previous handshake messages. This approach turns

out to require a handshake process that resembles

the abbreviated handshake of TLS 1.0 (Dierks,

1999). Such a four-way handshake is inefficient if an

application frequently uses different channels, for

example, to use different cipher suites for requests

and responses. In conclusion, we prefer to add a

channel id field in SSL packets than to add a

complex handshake process.

5.2.3 Typical Usage of Multiple Cipher Suites

A typical SSL session uses a cipher suite including a

128-bit cipher, and MD5 or SHA-1 hash algorithm

for MAC. With MC-SSL we can have an additional

channel with only MAC, but without encryption.

This channel could be useful for transporting data

that does not need confidentiality but require

authenticity. Such a channel combination is similar

to that of IPSec, in which authentication alone or

authentication plus encryption can be separately

provided by Authentication Header (AH) and

Encapsulating Security Payload (ESP) protocol.

A combination of block cipher and stream cipher

is another usage of multiple cipher suites. Streaming

media applications such as VoIP telephony often use

a stream cipher for confidentiality or privacy, but a

block cipher is probably necessary for user

authentication. For SSL, it has to renegotiate one

more time or open an additional connection.

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

252

Cleartext channels are also available to

applications in MC-SSL. Certainly we must be very

cautious with a cleartext channel. As a rule of

thumb, if a cleartext channel could possibly

compromise the security or privacy of a

communication session, it should not be negotiated

from the beginning of a session. On the other hand,

cleartext channels could be very useful. A typical

usage is to transport non-sensitive information after

a person has been authenticated. For example, a

person can choose to read emails through a cleartext

channel after his authentication. Another typical

usage is to deliver “already-secured” information so

as to eliminate excessive cryptographic protection.

Examples of “already-secured” information include

but not limited to digitally signed documents or

software, and data or documents protected by XML

Security or other techniques.

5.3 Prototype

We have developed a prototype to test the ideas and

the protocols of MC-SSL. The underlying SSL

library we choose is OpenSSL (OpenSSL, 2004).

The prototype programs are written in C language

and run on Linux. The prototype has helped us

improve the protocols, and also demonstrated to us

that MC-SSL is feasible and functional.

6 CONCLUSION

In this paper, we present Multiple-Channel SSL,

which is a protocol extended from SSL. MC-SSL is

able to satisfy diverse security requirements for

different applications, especially for emerging

mobile or wireless applications.

For the protocol design and implementation of

multiple channels over SSL, we extend primary

single-hop proxy channels to further support

multiple proxies in a proxy channel, and we discuss

the protocols for the negotiation and the operation of

secondary channels. We also give some thoughts

about the typical usage of multiple cipher suites.

Currently, MC-SSL is developed on SSL. One

can also apply the multiple channel model of MC-

SSL to a security protocol on top of a datagram

protocol, such as UDP, so that applications such as

VoIP can make use of proxy channels and multiple

cipher suites. For instance, if two wireless terminals

communicate with VoIP over RTP, but they do not

support the same voice coding or compression

scheme, they can use MC-SSL to set up a proxy to

translate the voice coding without greatly

compromising the security. Besides, they can use

different cipher suites for user authentication and

voice traffic as mentioned in Section 5.2.3.

Therefore, we consider it as an interesting research

direction to develop a counterpart protocol of MC-

SSL for UDP-based applications. For current MC-

SSL protocol, we need to further analyse and

enhance its security as well as usability.

ACKNOWLEDGEMENT

This work was supported by grants from Telus

Mobility and the Advanced Systems Institute of BC,

and by the Canadian Natural Sciences and

Engineering Research Council under grant

CRD247855-01.

REFERENCES

Blake-Wilson, S., Nystrom, M., Hopwood, D., Mikkelsen

J., and Wright, T., 2003. Transport Layer Security

(TLS) Extensions. RFC 3546.

Dierks, T. and Allen, C., 1999. The TLS Protocol Version

1.0. RFC 2246.

IBM Corp. and Microsoft Corp., 2002. Security in a Web

Services World: A Proposed Architecture and

Roadmap. http://www-106.ibm.com/developerworks

/webservices/library/ws-secmap/

Kwon, E.K., Cho, Y.G., and Chae, K.J., 2001. Integrated

Transport Layer Security: End-to-End Security Model

between WTLS and TLS. Proc. IEEE 15th Int. Conf.

on Information Networking

Kennedy, D. J., 2000. An Architecture for Secure, Client-

Driven Deployment of Application-Specific Proxies.

Master’s Thesis, University of Waterloo.

OASIS Open, 2003. Web Services Security: SOAP

Message Security. http://www.oasis-open.org/

OpenSSL, 2004. http://www.openssl.org/

Portmann M. and Seneviratne A., 2001. Selective Security

for TLS, Proc. IEEE 9th Int. Conf. on Networks, pp.

216-221

Song, Y., Leung, V., and Beznosov, K., 2004. Supporting

End-to-end Security Across Proxies with Multiple-

Channel SSL. Proc. IFIP 18

World Computer

Congress, submitted paper.

W3C, 2002. XML Signature Recommendations,

http://www.w3.org/Signature/

W3C, 2002. XML Encryption Recommendations,

http://www.w3.org/Encryption/

IMPLEMENTING MULTIPLE CHANNELS OVER SSL

253
