UNSUPERVISED ARTIFICIAL NEURAL NETWORKS FOR

CLUSTERING OF DOCUMENT COLLECTIONS

Abdel-Badeeh M. Salem, Mostafa M. Syiam, and Ayad F. Ayad

Computer Science Department, Faculty of Computer & Information Sciences

Ain Shams University, Cairo, Egypt.

Keywords: Neural networks, Self-Organizing Map, Document Clustering.

Abstract: The Self-Organizing Map (SOM) has shown to be a stable neural network model for high- dimensional data

analy

sis. However, its applicability is limited by the fact that some knowledge about the data is required to

define the size of the network. In this paper the Growing Hierarchical SOM (GHSOM) is proposed. This

dynamically growing architecture evolves into a hierarchical structure of self–organizing maps according to

the characteristics of input data. Furthermore, each map is expanded until it represents the corresponding

subset of the data at specific level. We demonstrate the benefits of this novel model using a real world

example from the document-clustering domain. Comparison between both models (SOM & GHSOM) was

held to explain the difference and investigate the benefits of using GHSOM.

1 INTRODUCTION

The Self-Organizing Map (SOM) (Kohonen, 1982)

is an artificial neural network model that is well

suited for mapping high-dimensional data into a 2-

dimensional representation space. The training

process is based on weight vector adaptation with

respect to the input vectors. The SOM has shown to

be a highly effective tool for data visualization in a

broad spectrum of application domains (Kohonen,

1998) . Especially the utilization of the SOM for

information retrieval purposes in large free-form

document collections has gained wide interest in the

last few years (Lagus et Al., 1998) (Merkl, 1997)

(Rauber and Merkl, 2000). The general idea is to

display the contents of a document library by

representing similar documents in similar regions of

the map. One of the disadvantages of the SOM in

such an application area is its fixed size in terms of

the number of units and their particular arrangement,

which has to be defined prior to the start of the

training process. Without knowledge of the type and

the organization of the documents it is difficult to

get satisfying results without multiple training runs

using different parameter settings, which obviously

is extremely time consuming given the high-

dimensional data representation. Recently a number

of neural network models inspired by the training

process of the SOM and having adaptive

architectures were proposed (Fritzke, 1998). The

model being closest to the SOM is the so-called

Growing Grid (Fritzke, 1997), where a SOM-like

neural network grows dynamically during training.

The basic idea is to add rows or columns to the SOM

in those areas where the input vectors are not yet

represented sufficiently. More precisely, units are

added to those regions of the map where large

deviations between the input vectors and the weight

vector of the unit representing these input data are

observed. However, this method will produce very

large maps, which are difficult to survey and

therefore are not that suitable for large document

collections. Another possibility is to use a

hierarchical structure of independent SOMs

(Miikkulainen, 1995), where for every unit of a map

a SOM is added to the next layer. This means that on

the first layer of the Hierarchical Feature Map

(HFM) we obtain a rather rough representation of

the input space but with descending the hierarchy

the granularity increases. We believe that such an

approach is especially well suited for the

representation of the contents of a document

collection. The reason is that document collections

are inherently structured hierarchically with respect

to different subject matters. This is essentially the

way how conventional libraries are organized for

centuries. However, like with the original SOM, the

HFM uses a fixed architecture with a specified depth

383

M. Salem A., M. Syiam M. and F. Ayad A. (2004).

UNSUPERVISED ARTIFICIAL NEURAL NETWORKS FOR CLUSTERING OF DOCUMENT COLLECTIONS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 383-392

DOI: 10.5220/0002595203830392

 SciTePress

of the hierarchy and predefined size of the various

SOMs on each layer. Again, we need profound

knowledge of the data in order to define a suitable

architecture. In order to combine the benefits of the

neural network models described above we

introduce a Growing Hierarchical SOM (GHSOM).

This model consists of a hierarchical architecture

where each layer is composed of independent SOMs

that adjust their size according to the requirements

of the input data. The remainder of the paper is

organized as follows. In section 2 we describe the

architecture and the training process of the GHSOM

The used data set and preprocessing steps are

demonstrated in section 3. The results of

experiments in document clustering with both SOM

and GHSOM are provided in section 4. Finally, we

present some conclusions in section 5.

2 GROWING HIERARCHICAL

SOM (GHSOM)

The key idea of the Growing Hierarchical Self-

Organizing Map (GHSOM) is to use a hierarchical

neural network structure composed of a number of

individual layers each of which consists of

independent self-organizing maps. In particular, the

neural network architecture starts with a single unit

SOM at layer 0. One SOM is used at layer 1of the

hierarchy. For every unit in this layer 1 map, a SOM

might be added to the next layer of the hierarchy.

This principal is repeated with the third and any

further layers of the GHSOM.

Since one of the shortcomings of the SOM usage is

its fixed network architecture in terms of the number

units and their arrangement, we rather rely on an

incrementally version of the SOM. This relieves us

from the burden of predefining the network’s size

which is now determined during the unsupervised

training process according to the peculiarities of the

input data space. Pragmatically speaking, the

GHSOM is intended to uncover the hierarchical

relationship between input data in a straightforward

fashion. More precisely, the similarities of the input

data are shown in increasingly finer levels of detail

along the hierarchy defined by the neural network

architecture. SOMs at higher layers give a coarse-

grained picture of the input data space whereas

SOMs of deeper layers provide fine-grained input

discrimination. The growth process of the neural

network is guided by the so-called quantization

error, which is a measure of the quality of the input

data representation.

The starting point for the growth process is the

overall deviation of the input data as measured with

the single unit SOM at layer 0. This unit is assigned

a weight vector m

, m

= [µ

, µ

, …, µ

]

computed as the average of all input data. The

deviation of the input data, i.e. the mean

quantization error of this single unit, is computed as

given in expression (1) with d representing the

number of input data x. The mean quantization error

of a unit will be referred to as mqe in lower case

letters.

||||

mqe −=

(1)

After the computation of mqe

, training of the

GHSOM starts with its first layer SOM. This first

layer map initially consists of a rather small number

of units, e.g. a grid of 2 x 2 units. Each of theses

units i is assigned an n-dimensional weight vector

, m

i =

[µ

, µ

,…, µ

]

, m

i Є R

, which is initialized

with random values. It’s important to note that

weight vectors have the same dimensionality as the

input patterns.

The learning process of SOMs may be described as a

competition among the units to represent the input

patterns. The unit with the weight vector being

closest to the presented input pattern in terms of

input space wins the competition. The weight vector

of the winner as well as units in the vicinity of the

winner are adapted in such a way as to resemble

more closely the input pattern (Salem et Al., 2003).

The degree of the adaptation is guided by means of a

learning rate parameter α, decreasing in time. The

number of units that are subject to adaptation also

decreases in time such that at the beginning of the

learning process a large number of units around the

winner are adapted, whereas towards the end only

the winner is adapted. These units are chosen by

means of a neighborhood function h

, which is

based on the units’ distances to the winner as

measured in the 2-dimensional grid formed by the

neural network. In combining these principles of

SOM training, the learning rule may be written as

given in expression (2), where x represents the

current input pattern, and c refers to the winner at

iteration t

(t+1) = m

(t) + α(t) h

(t) [x(t)- m

(t)]

In order to adapt the size of this first layer SOM, the

mean quantization error of the map is computed ever

after a fixed number λ of training iterations as given

in expression (3). In this formula, u refers to the

number of units i contained in the SOM m. In

analogy to expression (1), mqe

is computed as the

average distance between weight vector m

and the

input patterns mapped onto unit i. The mean

quantization error of a map will be referred to as

MQE in upper case letters.

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

384

The basic idea is that each layer of the GHSOM is

responsible for explaining some portion of the

deviation of the input data as present in its preceding

layer. This is done by adding units to the SOMs on

each layer until a suitable size of the map is reached.

More precisely, the SOMs on each layer are allowed

to grow until the deviation present in the unit of its

preceding layer is reduced to at least a fixed

percentage τ

. Obviously, the smaller the parameter

is chosen the larger will be the size of the

emerging SOM. Thus, as long as MQE

>= τ

mqe

holds true for the first layer map m, either a new row

or a new column of units is added to this SOM. This

insertion is performed neighboring the unit e with

the highest mean quantization error, mqe

, after λ

training iterations. We will refer to this unit as the

error unit. The distinction whether a new row or a

new column is inserted is guided by the location of

the most dissimilar neighboring unit to the error unit.

Similarity is measured in the input space. Hence, we

insert a new row or a new column depending on the

position of the neighbor with the most dissimilar

weight vector. The initialization of the weight

vectors of the new units is simply performed as the

average of the weight vectors of the existing

neighbors. After the insertion the learning rate

parameter α and the neighborhood function h

are

reset to their initial values and training continues

according to the standard training process of SOMs.

Note that we currently use the same value of the

parameter τ

for each map in each layer of the

GHSOM.

Consider Fig.1 for a graphical representation of the

insertion of units. In this figure the architecture of

the SOM prior to the insertion is shown on the left

hand side where we find a map of 2x3 units with the

error unit labeled by e and its dissimilar neighbor

signified by d. Since the most dissimilar neighbor

belongs to another row within the grid, a new row is

inserted between units e and d. The resulting

architecture is shown on the right hand side of the

figure as a map of now 3 x 3 units.

As soon as the growth process of the first layer map

is finished, i.e. MQE

< τ

mqe

, the units of this

map are examined for expansion on the second

layer. In particular, those units that have a large

mean quantization error will add a new SOM to the

second layer of the GHSOM. The selection of these

units is based on the mean quantization error of layer

0. A parameter τ

is used to describe the desired

level of granularity in input data discrimination in

the final maps. More precisely, each unit i fulfilling

the criterion given in expression (4) will be subject

to hierarchical expansion.

∑

mqe

MQE

(3)

mqe

> τ

mqe

The training process and unit insertion procedure

now continues with these newly established SOMs.

The major difference to the training process of the

second layer map is that now only that fraction of

input data is selected for training which is

represented by the corresponding first layer map

unit. The strategy for row or column insertion as

well as the termination criterion is essentially the

same as used for the first layer map. The same

procedure is applied to any subsequent layers of the

GHSOM.

(4)

The training process of the GHSOM is terminated

when no more units require further expansion. Note

that this training process does not necessarily lead to

a balanced hierarchy, i.e. a hierarchy with equal

depth in each branch. The depth of the hierarchy will

rather reflect the un-uniformity, which should be

expected in real world data collections.

Consider Fig.2 for a graphical representation of a

trained GHSOM. In particular, the neural network

depicted in this figure consists of a single unit SOM

at layer 0, a SOM of 2 x 3 units in layer 1, six SOMs

in layer 2, i.e. one for each unit in layer 1map. Note

that each of these maps might have a different

number and different arrangement of units as shown

in the figure. Finally, there’s one SOM in layer 3,

which was expanded from one of the layer 2 units.

Figure 1: Insertion of units

Figure 2: Architecture of a GHSOM

UNSUPERVISED ARTIFICIAL NEURAL NETWORKS FOR CLUSTERING OF DOCUMENT COLLECTIONS

385

To summarize, the growth process of the GHSOM is

guided by two parameters τ

and τ

. The parameter

specifies the desired quality of input data

representation at the end of the training process.

Each unit i with mqe

> τ

mqe

will be expanded,

i.e. a map is added to the next layer of the hierarchy,

in order to explain the input data in more detail.

Contrary to that, the parameter τ

specifies the

desired level of detail that is to be shown in a

particular SOM. In other words, new units are added

to a SOM until the MQE of the map is a certain

fraction, τ

, of the mqe of its preceding unit. Hence,

the smaller τ

the larger will be the emerging maps.

Conversely, the larger τ

the deeper will be the

hierarchy.

3 DATA SET

For the experiments presented thereafter we use a

collection of abstracts from the first International

Conference on Intelligent Computing and

Information Systems, ICICIS 2002.

(

http://asunet.shams.edu.eg/confs/icicis2002.html) as

a sample document archive. ICICIS contains papers

covering the areas of; fuzzy sets, rough sets, genetic

algorithms, neural nets, data mining and knowledge

discovery, expert systems, information storage and

retrieval, web-based learning, medical informatics

and others.

The documents can be thought of as forming topical

clusters in the high-dimensional feature space

spanned by the words that the documents are made

up of. The goal is to map and identify those clusters

on the 2-dimensional map display. Thus we use full-

text indexing to represent the various documents. In

total, ICICIS consists of 68 papers containing 5417

content terms, i.e. terms used for document

representation.

3.1 Document Preprocessing

For the training of SOMs, the documents must be

encoded in form of numerical vectors. To be suited

for the learning process of the map, to similar

documents similar vectors have to be assigned. After

training of the map, documents with similar contents

should be close to each other, and possibly assigned

to the same neuron. The presented approach is based

on statistical evaluations of word occurrences. We

do not use any information on the meaning of the

words since in domains like scientific research we

are confronted with a wide and (often rapidly)

changing vocabulary, which is hard to catch in fixed

structures like manually defined thesaurus or

keyword lists. However, it is important to be able to

calculate significant statistics. Therefore, the number

of considered words must be kept reasonably small,

and the occurrences of words sufficiently high. This

can be done by either removing words or by

grouping words with equal or similar meaning. A

possible way to do so is to filter so-called stop words

and to build the stems of the words. An overview of

document pre-processing and encoding is given in

Figure 3.

Figure 3: Document preprocessing and encoding

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

386

The idea of stop word filtering is to remove words

that bear no content information, like articles,

conjunctions, prepositions, etc. Furthermore, words

that occur extremely often can be said to be of little

information content to distinguish between

documents. Also, words that occur very seldom are

likely to be of no particular statistical relevance.

Stemming tries to build the basic forms of words,

i.e. strip the plural ‘s’ from nouns, the ‘ing’ from

verbs, or other affixes. A stem is a natural group of

words with equal (or very similar) meaning. We

currently used the stemming algorithm of (Porter,

1980), which uses a set of production rules to

iteratively transform (English) words into their

stems.

3.2 Generating Characteristic

Document Vectors

Figure 3 shows the principle of the proposed

document encoding. At first, the original documents

are preprocessed, i.e. they are split into words, then

stop words are filtered and the word stems are

generated. The occurrences of the word stems

(frequencies) associated with the document are

counted. A component in a n-dimensional vector is

built, that characterizes the document. These vectors

can be seen as the fingerprints of each document.

For every document in the collection such a

fingerprint is generated. Using GHSOM, these

document vectors are then clustered and arranged

into a 2-dimensional maps, the so-called document

maps. Furthermore, each unit is labeled by specific

keywords that describe the content of the assigned

documents. The labeling method we used is based

on methods proposed in (Lagus et Al., 1999). It

focuses on the distribution of words used in the

documents assigned to the considered unit compared

to the whole document database.

4 EXPERIMENTAL RESULTS

AND DISCUSSION

For our data set we trained both conventional self-

organizing map and growing hierarchical SOM

(GHSOM); to explain the difference and investigate

the benefits of using GHSOM.

4.1 Trained Conventional SOM

Figure 4 shows a conventional self-organizing map

trained with the ICICIS abstracts data set. It consists

of 5 x 6 units represented as table cells with a

number of abstracts being mapped onto each

individual unit (we refer to the abstract with symbol

T). Each unit is labeled by specific keywords that

describe the content of the assigned abstracts. The

abstracts mapped onto the same or neighboring units

are considered to be similar to each other in terms of

the topic they deal with. We find, that the SOM has

succeeded in creating a topology preserving

representation of the topical clusters of abstracts. For

example, in the lower left corner we find a group of

units representing abstracts on the grid computing.

To name just a few, we find abstracts T22, T23 on

unit (5/1)

covering resource scheduling in grid

computing or T51, T53, T68 on unit (5/2) dealing

with intrusion detection architecture for

computational grids. A cluster of documents

covering knowledge discovery and data mining is

located in the upper left corner of the map around

units (1/1) and (1/2), next to a cluster on genetic

algorithms on units (1/3) and (2/3). Below this area,

on units (3/1), (3/2) and neighboring ones we find

abstracts on neural networks. Similarly, all other

units on the map can be identified to represent a

topical cluster of news abstracts.

4.2 Trained GHSOM

Based on the artificial unit representing the means of

all data points at layer 0, the GHSOM training

algorithm started with a 2 x 2 SOM at layer 1. The

training process for this map continued with

additional units being added until the quantization

error fell below a certain percentage of the overall

quantization error of the unit at layer 0. As

mentioned earlier, the growth process of the

GHSOM is guided by two parameters τ

and τ

. We

can say that, the smaller the parameter value τ

, the

more shallow the hierarchy, and that, the lower the

setting of parameter τ

, the larger the number of

layers in the resulting GHSOM network will be.

We use the notion (x/y) to refer to the unit located

in row x and column y of the map, starting with (1/1)

in the upper

UNSUPERVISED ARTIFICIAL NEURAL NETWORKS FOR CLUSTERING OF DOCUMENT COLLECTIONS

387

4.2.1 Deep Hierarchy

Training the GHSOM with parameter τ

= 0.07 and

= 0.0035 results in a rather deep hierarchical

structure of up to 4 layers. The layer 1 map is

depicted in fig. 5(a) grows to a size of 4 x 3 units, all

of which are expanded at subsequent layers. For

convenience we list the topics of the various units,

rather than the individual abstracts in the figure. For

example, we find unit (2/1) to represent all abstracts

related to knowledge discovery and data mining,

whereas neural network topics are covered on unit

(2/2), or abstracts related to genetic algorithms on

unit (4/1) in the lower left corner. Based on this first

separation of the most dominant topical clusters in

the abstract collection, further maps were

automatically trained to represent the various topics

in more detail. This results in 12 individual maps on

layer 2, each representing the data of the respective

higher-layer unit in more detail. Some of the units

on these layer 2 maps were further expanded as

distinct SOMs in layer 3.

We find the branch on data mining on unit (2/1) of

this map. This unit has been expanded to form a 2 x

2 map in the second layer as shown in fig. 5(b). Unit

(1/1) of this map is dominated by abstracts related to

enhancing algorithms for data mining, whereas, for

example, abstracts focusing on mining medical data

set are located in the lower left corner on unit (2/1).

Other dominant cluster on this map is rough set.

One unit of this second layer map is further

expanded in a third layer. Unit (1/2) in the upper

right corner representing abstracts related to data

mining using statistical techniques. These abstracts

are represented in more detail in the third layer.

4.2.2 Shallow Hierarchy

To show the effect of different parameter

settings we trained a second GHSOM with τ

set to half of the previous value (τ

= 0.035),

while τ

, i.e. the absolute granularity of data

representation, remained unchanged. This leads

to a more shallow hierarchical structure of only

up to 2 layers, with the layer 1 map growing to

a size of 5 x 4 units depicted in fig. 6. Again,

we find the most dominant branches to be, for

example, genetic algorithms located on unit

(1/3), data mining and knowledge discovery on

unit (2/3), and neural networks on the lower

right corner of this map. However, due to the

large size of the resulting first layer map, a fine-

grained representation of the data is already

provided at this layer. This results in some

larger clusters to be represented by two

neighboring units already at the first layer,

rather than being split up in a lower layer of the

hierarchy. For example, we find the cluster on

neural networks to be represented by two

neighboring units. One of these, on position (5/3),

covers abstracts related to using neural networks in

the industry. The neighboring unit to the right,

i.e. located on position (5/4) covers other

usages of neural networks.

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

388

Algorithm

rough

database

knowledge

Mine

T61

T63

Mine

data

system

Intelligent

Discovery

T56

T57

algorithm

genetic

Iris

T15

T32

T35

T37

T39

T60

algorithm

layout

Graph

T19

Approach

paper

Graph

problem

propose

cluster

Mine

algorithm

data

spatial

T55

T58

T59

set

system

attribute

T38

T44

algorithm

time

OAT

Optimum

binary

T65

use

algorithm

genetic

compare

expert

T20

T34

Engine

education

University

course

precious

paper

set

object

include

formula

T13

T17

system

algorithm

Engine

Test

practice

classify

learn

network

neural

rule

T45

T47

detect

system

neural

network

Artificial

T24

T36

T42

net

algorithm

Diffserv

traffic

contour

T11

T12

time

develop

example

paper

deploy

T26

method

control

design

aircraft

require

T10

T30

system

load

distribute

ATM

T18

T21

T25

T49

neural

Model

network

approach

problem

T43

T46

network

Optimum

problem

algorithm

propos

T33

T40

T41

algorithm

interest

wavelet

feature

Arab

T14

T16

T64

query

retrieval

Boolean

translate

Model

T62

T67

logic

uncertainty

Model

inform

mobile

T27

T28

T29

T31

user

design

system

inform

T48

T54

resource

grid

compute

T22

T23

grid

intrusion

process

T51

T53

T68

technology

Egypt

E-

Commerce

inform

Model

T66

field

role

user

technology

system

contain

capacity

section

CBR

T50

system

structure

find

custom

T52

Figure 4: 5 x 6 SOM of the ICICIS conference

UNSUPERVISED ARTIFICIAL NEURAL NETWORKS FOR CLUSTERING OF DOCUMENT COLLECTIONS

389

use

result

introduce

Quality

algorithm

down

inform

set

Model

E-business

accid

down

paper

approach

method

design

structure

down

paper

data

system

knowledge

Mine

down

system

learn

network

neural

Artificial

down

paper

use

high

apply

resource

down

network

algorithm

recognize


down

set

paper

education

system

web

down

use

ability

database

base

data

down

approach

genetic

propos

problem

algorithm

down

paper

solve

problem

Graph

Optimum

down

select

Draw

represent

algorithm

view

down

4.3 Comparison of Both Models

(Conventional SOM and

GHSOM)

While we find the SOM to provide a good

topologically ordered representation of the various

topics found in the abstracts collection, no

information about topical hierarchies can be

identified from the resulting flat map. Apart from

this we find the size of the map to be quite large

with respect to the number of topics identified. This

is mainly due to the fact that the size of the map has

to be determined in advance, before any information

about the number of topical clusters is available.

GHSOM has two benefits over conventional self-

Mine

data

database

algorithm

Discovery

T56

T57

data

algorithm

classify

system

statistic

down

Mine

medical

data

knowledge

Information

T59

T61

set

knowledge

algorithm

database

rough

T63

(b) Layer 2 map: 2x2 units;

Knowledge discovery

(a) Layer 1 map: 4x3 units; Main topics

Figure 5: Top and second level maps

organizing maps, which make this model

particularly attractive in an information retrieval

setting. First, GHSOM has substantially shorter

training time than self-organizing map. The reason

for that is, there is the obvious input vector

dimension reduction on the transition from one layer

to the next. Shorter input vectors lead directly to

reduced training time because of faster winner

selection and weight vector adaptation. Second,

GHSOM may be used to produce disjoint clusters of

the input data. Moreover, these disjoint clusters are

gradually refined when moving down along the

hierarchy. Contrary to that, the self-organizing map

in its basic form cannot be used to produce disjoint

clusters. The separation of data items is a rather

tricky task that requires some insight into the

structure of the input data. What one gets, however,

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

390

time

algorithm

Optimum

tree

binary

down

implement

algorithm

perform

Queue

Model

T12

algorithm

approach

problem

genetic

down

approach

query

document

inform

retrieve

down

process

service

efficient

implement

paper

down

paper

traffic

data

GPS

system

down

Mine

data

algorithm

set

knowledge

down

paper

compute

extract

result

match

down

use

Model

technique

process

work

down

control

design

estimate

system

aircraft

down

system

resource

network

compute

apply

down

result

paper

compare

algorithm

down

Model

evolve

software

process

down

variable

determine

classify

rule

system

down

network

propos

grid

describe

study

down

algorithm

interest

Arab

segment

Character

down

system

balance

load

heterogeneous

distribute

down

neural

set

Artificial

system

level

T24

paper

network

neural

operation

level

down

learn

network

neural

regress

recognition

down

Figure 6: Layer 1 map: 5x4 units shallow hierarchy

from a self-organizing map is an overall representation of

input data similarities. In this sense we may use the

following picture to contrast the two models of neural

networks. Self-organizing maps can be used to produce

maps of the input data whereas GHSOM produces an atlas

of the input data. Taking up this metaphor, the difference

between both models is quite obvious. Self-organizing

maps, in our point of view, provide the user with a single

picture of the underlying data archive. As long as the map

is not too large, this picture may be sufficient. As the maps

grow larger, however, they have the tendency of providing

too little orientation for the user. In such a case we would

advise to change to GHSOM as the model for representing

the contents of the data archive. In this case, the data is

UNSUPERVISED ARTIFICIAL NEURAL NETWORKS FOR CLUSTERING OF DOCUMENT COLLECTIONS

391

organized hierarchically, which facilitates browsing into

relevant portions of the data archive.

5 CONCLUSIONS AND FUTURE

WORK

We presented the GHSOM, a novel neural network

model based on the self- organizing map. The main

feature of this model is its capability of dynamically

adapting its architecture to the requirements of the

input space. Instead of having to specify the precise

number and arrangement of units in advance, the

network determines the number of units required for

representing the data at a certain accuracy level at

training time. This growth process is guided solely

by the desired granularity of data representation. As

opposed to other growing network architectures, the

GHSOM does not grow into a single large map, but

rather dynamically evolves into a hierarchical

structure of growing maps in order to represent the

data at each level in the hierarchy at certain

granularity. This enables the creation of smaller

maps, resulting in better cluster separation due to the

existence of separated maps. It further allows easier

navigation and interpretation by providing a better

overview of huge data sets.

We demonstrated that both the self-organizing map

and the hierarchical feature map are highly useful

for assisting the user to find his or her orientation

within the document space. The shortcoming of the

self-organizing map, however, is that each document

is shown in one large map and thus, the borderline

between clusters of related and clusters of unrelated

documents are sometimes hard to find. This is

especially the case if the user does not have

sufficient insight into the contents of the document

collection. The GHSOM overcomes this limitation

in that the clusters of documents are clearly visible

because of the architecture of the neural network.

The document space is separated into independent

maps along different layers in a hierarchy. The

similarity between documents is shown in a fine-

grained level in maps of the lower layers of the

hierarchy while the overall organizational principles

of the document archive are shown at higher layer

maps. Since such a hierarchical arrangement of

documents is the common way of organizing

conventional libraries, only small intellectual

overhead is required from the user to find his or her

way through the document space.

An important feature of GHSOM is that, the training

time is largely reduced by training only the

necessary number of units for a certain degree of

detail representation. The benefits of the proposed

approach have been demonstrated by a real world

application from the text classification domain.

Our future work on GHSOM includes fine-tuning

the basic algorithm and applying it to collections in

any language, provided that words as primary tokens

can be identified. This may require special

preprocessing steps for languages as Chinese, where

word boundaries are not eminent from the texts. In

addition, develop a method for setting the threshold

values (τ

and τ

) automatically according to

application requirements.

REFERENCES

T. Kohonen, “Self-organized formation of topologically

correct feature maps,” Biol. Cybern. vol. 43, 1982,

pp. 59–69.

T.Kohonen, “Self-organizing maps” Berlin, Germany:

Springer verlage, 1998.

K. Lagus, T. Honkela, S. Kaski, and T. Kohonen, “Self-

organizing maps of document collection: A new

approach to interactive exploration” In Proc. Int.

Conf. on Knowledge Discovery and Data Mining

(KDD-96), Portland, OR, vol.36, 1998, pp. 314-322

D. Merkl, “Exploration of text collections with

hierarchical feature maps”. In Proc. Int. ACM

SIGIR Conf. on Information Retrieval (SIGIR'97),

Philadelphia, PA, vol.62, 1997,pp. 412-419

A. Rauber and D. Merkl, “Finding structure in text

archives” In Proc. Europe an Symp. on Artificial

Neural Networks (ESANN98), Bruges, Belgium,

vol.18, 2000,pp.410-419

B. Fritzke, “Growing self-organizing networks -------

Why?” In Proc. Europ Symp on Artificial Neural

Networks (ESANN'96), Bruges, Belgium,

vol.16,1998,pp.222-230.

B. Fritzke, “Growing grid: a self-organizing network

with constant neighborhood range and adaptation

strength” Neural Processing Letters, 1997.

R. Miikkulainen, “Script recognition with hierarchical

feature maps” Connection Science, 2, 1995.

M. Salem, M. Syiam, and A. F. Ayad, “Improving self-

organizing feature map (SOFM) training algorithm

using k-means initialization” In Proc. Int. Conf. on

Intelligent Eng. Systems INES, IEEE,

vol.40,2003,pp.41-46.

M. Porter, “An algorithm for suffix stripping” Program

14(3), pp. 130-137, 1980.

K. Lagus, and S. Kaski, “Keyword selection method for

characterizing text document maps” In Proc of

ICANN99, Ninth International Conference on

Artificial Neural Networks,IEEE,vol 68, 1999,pp.615-

623

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

392
