RETRO-DYNAMICS AND E-BUSINESS MODEL APPLICATION

FOR DISTRIBUTED DATA MINING USING MOBILE AGENTS

Ezendu Ifeanyi Ariwa

Department of Accounting, Banking & Financial Systems

London Metropolitan University, United Kingdom

Mohamed B. Senousy

Associate Professor

Department of Computer and Information Systems

Sadat Academy for Management Sciences, Egypt

Mohamed M. Medhat

Department of Computer and Information Systems

Sadat Academy for Management Sciences, Egypt

Keywords: Knowledge Discovery – OIKI DDM – Decision Support System [DSS]

Abstract: Distributed data mining (DDM)

is the semi-automatic pattern extraction of distributed data sources. The

next generation of the data mining studies will be distributed data mining for many reasons. First of all,

most of the current used data mining techniques require all data to be resident in memory, i.e., the mining

process must be done at the data source site. This is not feasible for the exponential growth of the data

stored in organization(s) databases. Another important reason is that data is inherently distributed for fault

tolerance purposes. DDM requires two main decisions about the DDM implementations: A distributed

computation paradigm (message passing, RPC, mobile agents), and the used integration techniques

(Knowledge probing, CDM) in order to aggregate and integrate the results of the various distributed data

miners. Recently, the new distributed computation paradigm, which has been evolved as mobile agent is

widely used. Mobile agent is a thread of control that can trigger the transfer of arbitrary code to a remote

computer. Mobile agents paradigm has several advantages: Conserving bandwidth and reducing latencies.

Also, complex, efficient and robust behaviours can be realized with surprisingly little code. Mobile agents

can be used to support weak clients, allow robust remote interaction, and provide scalability. In this paper,

we propose a new model that can benefit from the mobile agent paradigm to build an efficient DDM model.

Since the size of the data to be migrated in the DDM process is huge, our model will overcome the

communication bottleneck by using mobile agents paradigm. Our model divides the DDM process into

several stages that can be done in parallel on different data sources: Preparation stage, data mining stage and

knowledge integration stage. We also include a special section on how current e-business models can use

our model to reinforce the decision support in the organization. A cost analysis in terms of time consumed

by each minor process (communication or processing) is given to illustrate the overheads of this model and

the other models.

1 INTRODUCTION

Since distributed data mining is an emerging field of

study, the modeling of distributed data mining

systems is one of the key research areas in the data

mining studies. We propose a new DDM model

called OIKI (Optimized Incremental Knowledge

Integration) system.

In this paper, we will discuss a theoretical

back

ground of the distributed data mining

motivation and definitions in Section (2). In Section

(3), related work to our research is discussed. DDM

models are studied in Section (4). Section (5)

500

Ifeanyi Ariwa E., B. Senousy M. and M. Medhat M. (2004).

RETRO-DYNAMICS AND E-BUSINESS MODEL APPLICATION FOR DISTRIBUTED DATA MINING USING MOBILE AGENTS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 500-507

DOI: 10.5220/0002596405000507

 SciTePress

discusses the notation and different cost functions

for DDM models. Our model will be presented and

studied in details in Section (6). The most popular e-

business model and how it can benefit from our

proposed model are discussed in Section (7). An

analytical study for the proposed cost functions for

each model is discussed in Section (8) Finally,

conclusions and future work are presented in Section

(9).

2 BACKGROUND

The explosive growth in data stored in databases and

data warehouses has generated an urgent need for

new techniques that can intelligently transform this

huge amount of data into useful knowledge.

Consequently, data mining has become an important

research area (Chen et al.: 1996).

Data mining differs from other data analysis

techniques in that the system takes the initiative to

generate patterns by itself (Information Discovery

Inc.: 1997). Therefore, it is an exploratory analysis

system (Turkey: 1973).

Data mining is concerned with the algorithmic

means by which patterns, changes, anomalies, rules

and statistically significant structures and events in

data are extracted from large data sets (Fayyad et al:

1998 and Grossman: 1999).

Data mining studies can be classified into two

generations. Studies in the first generation have

focused on which kinds of patterns to mine. Studies

in the second generation have focused on how

mining can interact with other components in the

framework like DBMS (Johnson: 2000).

Two requirements dictate the need for distributed

data mining: data may be inherently distributed for a

variety of practical reasons including security and

fault tolerant distribution of data and services or

mobile platform. Also, the cost of transporting data

to a single site is usually high and sometimes

unacceptable (Prodromidis: 1999; Kargupta et al.:

2000). The second requirement is that many of the

mining algorithms require all data to be resident in

memory. This might be unfeasible for large data

sets, because these learning algorithms do not have

the capability to process this huge amount of data.

Data partitioning is one of the popular solutions for

this problem (Provost: 1997). Consequently, data in

this case is artificially distributed (Malhi: 1998).

DDM offers techniques to discover knowledge in

distributed data through distributed data analysis

using minimal communication of data (Kargupta et

al.: 2000). Typical DDM algorithms involve local

data analysis from which a global knowledge can be

extracted using knowledge integration techniques

(Kargupta et al.: 2000).

3 RELATED WORK

In Davies et al. (1996), one of the recent works in

DDM studies is concerned with an agent-based

approach to data mining.

Several DDM systems have been proposed. In

Kargupta et al. (1997), PADMA system has been

presented. In Botia et al. (1998), the basic design

and implementation guidelines in a generic data

mining system have been studied. In Martin et

al.(1999), an agent infrastructure for data mining

systems has been proposed. In Stolfo (1997), Java

Agents for Meta-learning (JAM) over distributed

databases has been proposed. In Kargupta et al.

(1999), Collective Data Mining (CDM) theory and

implementation have been studied. In Chattratichat

et al. (1999), architecture for distributed enterprise

data mining has been presented.

In Guo (1999), a knowledge integration technique

using knowledge probing has been studied.

The cost models for Client/Server, mobile agents

and hybrid DDM models have been proposed in

Krishnaswany et al. (2000). This study has presented

a different data mining scenarios involving various

architectural models.

4 DDM MODELS

There are two architectural models used in the

development of DDM systems: Client/Server (CS)

model and mobile agent model. In the following

subsections, we will discuss each model.

4.1 Client/Server Based DDM Model

The Client/Server model uses the remote procedure

call (RPC) mechanism in the communication

between the clients and the server. The RPC allows

a program on the client to invoke a procedure on the

server using stubs on each side. The client-side stub

acts as a proxy for the real procedure. It accepts calls

for the procedure and arranges for them to be

RETRO-DYNAMICS AND E-BUSINESS MODEL APPLICATION FOR DISTRIBUTED DATA MINING USING

MOBILE AGENTS

501

forwarded to the server. The server-side stub

receives the call for a procedure and returns the

results to the client-side stub. Finally, the client-side

stub returns the result to the original RPC call

(Crowley: 1997; Gray: 1995).

The CS-based DDM uses one or more DM servers.

The client requests are sent to DM server that

determines the required data sources and collects

data from different locations and brings all the

required data for the specified mining process to the

DM sever. The DM server in turn houses the data

mining algorithms. The mining process is

accomplished on the DM server and the results are

returned to the requested client.

…

Client

Data

Source 1

Data

Source 2

Data

Source n

4.2 Mobile Agent Based DDM Model

A fundamental problem exists with Client/Server

architectures is that if the server does not provide the

exact service that the client requires, then the client

must take a series of RPCs to obtain the end service.

This might result in an overall latency increase and

in intermediate information between the client and

the server during the service processing.

Consequently, CS architecture may waste the

network bandwidth. Dale (1997) Gray et al.(2000).

A mobile agent does not waste the bandwidth,

because the agent migrates to the server. The agent

performs the necessary sequence of operations

locally, and returns just the final result to the client.

Gray et al. (2000). The major drawback in the CS-

based DDM model is that huge amount of data sets

migrate form the data sources locations to the DM

sever to accomplish the required DM process. This

results into a considerable waste in the network

bandwidth and consequently a big increase in

latency.

A typical mobile agent-based DDM process begins

with a client request for a DM process. The client

determines the required data severs for the DM

process and multicasts a set of mobile agents data

miners MADMs. The MADMs migrate to the data

servers and perform the data mining operations

locally and return the final results (knowledge) to

the client. Finally, the client uses a knowledge

integration (KI) program to integrate the DM results

from the different MADMs. Figure (2) illustrates the

described mobile agent-based DDM process.

Server

Request

Data Data Data

Results

(Knowledge)

Figure 1: Illustrates typical Client/Server based DDM process

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

502

…

Data

Server 1

Data

Server 2

Data

Server n

Figure 2: Typical mobile-agent-based DDM Process

5 OIKI DDM MODEL

Optimized Incremental Knowledge Integration

(OIKI) DDM model is a mobile agent based DDM

model that overcome the drawbacks of the

traditional mobile agent based DDM model. Instead

of transferring the results from each data server to

the client, the client controls migration of the results

among data servers to be integrated locally and

finally, the final results are transferred to the client.

The typical OIKI DDM process: the client multicasts

MADMs and MAKIs (Mobile Agents-Knowledge

Integrators) to the required data servers. The data

mining process is performed locally on each data

server. The size of results of the first two

accomplished DM processes are compared. The

smaller one is migrated to the larger one. The

knowledge integrator agent integrates the results of

these two data servers. This process is repeated until

all integrated results are resident in a specific data

server and finally, the final results are sent back to

the client. Consequently, the OIKI DDM process

passes through three main stages: 1) Preparation

Stage: The client multicasts MADMs and MAKIs to

data servers. 2) Data Mining Stage: Data mining

process is performed locally on each data server. 3)

Knowledge Integration Stage: An incremental

knowledge integration technique is performed on the

data servers where the smaller results are migrated

to the larger one to optimize the cost of results

migration among data servers. Figure (3) illustrates

the typical OIKI DDM process.

DM Request

MADM

Result 2 Result n

Result 1

Client

KI Program

RETRO-DYNAMICS AND E-BUSINESS MODEL APPLICATION FOR DISTRIBUTED DATA MINING USING

MOBILE AGENTS

503

…

6 THE APPLICATION OF OIKI

DDM MODEL IN E-BUSINESS

The OIKI DDM model has its great benefits to

current e-business models for many reasons; we

explore here some facts to demonstrate our idea:

- Current e-business models depend on the

existence of one or more databases in order

to store the business data such as storefront

model (Amazon.com), portal model

(Yahoo.com), and recruiting on the web

model (Monster.com). Due to the growth

amounts of data stored in these databases,

many databases are partitioned and

distributed among several sites. Other

organizations build a number of data marts

to be used in the decision making process.

- Data mining could be used in Customer

Relationship Management (CRM) as

follows:

a) Association rules extraction for

customer attraction.

b) Sequential patterns extraction for

customer retention.

c) Deriving classifiers and data clusters

for cross-selling.

From the above discussion, the OIKI DDM model

could be used to mine the business data efficiently.

The MADMs and MAKIs are sent to the database

partitions or data marts of a specific e-business

organization and perform the data mining and

knowledge integration processes locally. So, this

model makes the data mining process scalable to any

number of data sites. In addition, this model can be

used to mine the data of several e-business

organizations in the same field. These organizations

have a contract to benefit from the hidden

knowledge of their stored data. This can raise the

efficiency of these organizations, because the

extracted knowledge will be more accurate. The

following are some examples of a typical use of

OIKI DDM model in e-business:

Example 1

75% of customers purchase product 1 also purchase

product 2 of an e-business organization.

This rule can be obtained using OIKI DDM model

as follows:

- A client sends a set of mobile agents

association rule mining (MADMs) and

mobile agents association rule integrator

(MAKIs) to the database partitions

containing the needed data about the

purchased products.

- MADMs perform the association rule

mining process locally.

Data

Server 1

Data

Server 2

Data

Server n

Client

R1 Rn

MADM

MAKI

MADM MADM

MAKI MAKI

Final

Result

ure 3: T

ical OIKI DDM Process

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

504

- MAKIs migrate with the results from a

database partition containing smaller results

to a database partition containing larger

ones in order to optimize the

communication cost.

- The previous step is repeated until all the

results are integrated.

We should note that OIKI DDM model has a great

advantage over the traditional mobile agent based

models. The incremental integration of the mining

results makes the strength of a rule increased or

decreased incrementally. Thus, some rules may be

disappeared before the knowledge integration

process is finished.

Example 2

Clients purchasing product x, tend to be engineers.

This derived classifier could be obtained using OIKI

DDM model:

- A client sends a set of mobile agents

classification mining (MADMs) and mobile

agents classifier integrator (MAKIs) to the

database partitions containing the needed

data about the purchased products and their

customers.

- MADMs derives a set of classifier

functions using each database partition as a

training set.

- MAKIs migrate with classifiers from a

database partition containing smaller

classifiers to a database partition containing

larger ones in order to optimize the

communication cost. Meta-classification

techniques might be used.

- The previous step is repeated until all the

results are integrated.

The advantage of OIKI DDM model over the

other DDM models is the use of a database

partition as a training set which makes the time

needed for training decreased. Then, the meta-

classification process is done incrementally

which makes this process easier and time

efficient.

From the above example, the extracted

knowledge would be used in marketing, so,

a) The organization places the product 2

to advertisements in the web page of

product 1.

b) The organization sends newsletters and

special offers about product x to

engineers.

We can conclude that OIKI DDM model is used in

various data mining techniques when data is

distributed among several sites and it is more

efficient over the other models because of the use of

mobile agent technology and the incremental

knowledge integration.

7 BENEFITS TO E-BUSINESS

There are a number of e-business models currently

used in the implementation of e-business

applications. Examples of such models are storefront

model, auction model, portal model, dynamic

pricing models, B2B models, online trading and

lending models and e-learning models. The most

commonly used model is storefront model using

shopping-cart technology, where there is a merchant

database stores all information about customers and

goods. Deittel et al. (2001). And the e-business

intelligence is accomplished through the use of data

miners. Senousy et al. (2001).

The OIKI DDM model can be used in the storefront

e-business model where the data servers are the

merchant’s databases. Thus, the merchant can

analyze the data stored in the distributed databases

used in the e-business. Figure (5) shows how the

storefront e-business model can benefit from the

OIKI DDM model in the data analysis. The e-

business analyzer software sends MADMs and

MAKIs to the required databases according to the

DM request. The MADMs perform the data mining

tasks on each database. The MAKIs perform the

knowledge integration tasks such that the smaller

results migrate to the larger ones. The e-business

analyzer software controls the results migration

among merchant’s databases in order to optimize the

incremental knowledge integration process.

RETRO-DYNAMICS AND E-BUSINESS MODEL APPLICATION FOR DISTRIBUTED DATA MINING USING

MOBILE AGENTS

505

R1 Rn

…

Merchant

Database 1

Merchant

Database 2

Merchant

Database n

8 CONCLUSIONS AND FUTURE

WORK

The OIKI DDM model overcomes the drawbacks of

traditional mobile agent based DDM model by

making the knowledge integration process an

incremental process. This makes the DDM system

scalable to any number of data servers. The way of

performing the incremental knowledge integration

process in the OIKI DDM model makes this process

optimized. The storefront e-business model can

benefit from our model by applying the DDM

process on the merchant’s databases.

Our future work is concerned with an analytical

based comparison among DDM models, and

performance evaluation of these models. Advanced

simulation techniques would be used. The

implementation issues of the proposed model are

research areas that have a lot of work to be done.

The study of the efficient knowledge integration

techniques is an essential research area to the OIKI

DDM model implementation.

REFERENCES

Botia, A., Garijo, R., and Skarmeta F., 1998, “A Generic

Data Mining System: Basic Design and

Implementation Guidelines”, Workshop on Distributed

Data Mining at the 4

International Conference on

Data Mining and Knowledge Discovery (KDD-98).

Chen, M., Han, J., and Yu, P., 1996, “Data Mining: An

Overview from Database Perspective”, IEEE

Transactions on Knowledge and Data Engineering,

8(6): 866-883, 1996.

Crowley, C., 1997, Operating Systems: A Design-Oriented

Approach, IRWIN, Boston.

Dale, J., 1997, “PhD thesis: A Mobile Agent Architecture

to Support Distributed Resource Information

Management”, Department of Electronics and

Computer Science, Faculty of Engineering, University

of Southampton.

Davies, W., and Edwards, P., 1996, “Distributed Learning:

An Agent-Based Approach to Data Mining”,

Technical Report of Department of Computer Science,

King’s College, University of Aberdeen.

Deitel, H., Deitel, P., and Neito, T., 2001, e-Business and

e-Commerce: How to Program, Prentice Hall.

Fayyad, U., Bradley, P., and Mangasarian O., 1998, “

Mathematical Programming for Data Mining:

Formulations and Challenges”, Journal of Computing,

special issue on Data Mining.

e-business data analyzer

MADM

MAKI

MADM MADM

MAKI MAKI

Final

Result

ure 5: A

OIKI DDM to storefront e-

usiness model

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

506

Gray, R., Kotz, D., Cybenko, G., Rus, D., 2000, “Mobile

agents: Motivations and state-of-the-art systems”,

ftp://ftp.cs.dartmouth.edu/TR/TR2000-365.ps.Z.

Gray, R., 1995, “Ph.D. Thesis Proposal: Transportable

Agents”, Department of Computer Science, Dartmouth

College.

Guo, Y., and Sutiwaraphun, 1999, “Integrating

Knowledge in Distributed Data Mining”, Department

of Computing, Imperial College.

Grossman, R., Kasif, S., Moore, R., Rocke, and Ullman,

J., 1999, “Data Mining Research: Opportunities and

Challenges”, A Report of three Workshops on Mining

Large, Massive, and Distributed Data.

Information Discovery Inc., 1997, “A Characterization of

Data Mining Technologies and Processes”, Journal of

Data Warehousing.

Johnson, T., Lakshmanan, L., and Ng, R., 2000, “The 3W

Model and Algebra for Unified Data Mining”,

Proceedings of the 26

VLDB Conference.

Kargupta, H., Hamzaoglu, I. and Stafford, B., 1997,

“Scalable, Distributed Data Mining Using An Agent

Based Architecture”, in Proc. of the 3rd Int. Conf. on

Knowledge Discovery and Data Mining, Newport

Beach, California, (eds), D.Heckerman, H.Mannila,

D.Pregibon, and R.Uthurusamy,

Kargupta,H., Park,B., Hershberger,D., and Johnson, E.,

1999, “Collective Data Mining: A New Perspective

Toward Distributed Data Mining”, to appear in

Advances in Distributed Data Mining, (eds)

H.Kargupta and P.Chan, AAAI Press.

Krishnaswamy, S., Zaslavsky,A., and Loke,S,W., 2000,

“An Architecture to Support Distributed Data Mining

Services in E-Commerce Environments”, 2nd

International Workshop on Advanced Issues in E-

Commerce and Web-Based Information Systems, San

Jose, Californinia, July 8-9.

Malhi, B., 1998, “Master thesis report: Providing Support

for Resource Management Tools in a Wide Area High

Performance Distributed Data Mining System”,

Laboratory for Advanced Computing, University of

Illinois at Chicago,

http://lac.uic.edu/~balinder/thesis.htm.

Martin,G., Unruh,A., and Urban,S., 1999, “An Agent

Infrastructure for Knowledge Discovery and Event

Detection”, Technical Report MCC-INSL-003-99,

Microelectronics and Computer Technology

Corporation (MCC).

Prodromidis, A., 1999, “Ph.D. Thesis: Management of

Intelligent Learning Agents in Distributed Data

Mining Systems”, School of Arts and Science,

Columbia University.

Provost, F., 1997, “Scaling Up Inductive Algorithms: An

Overview”, Proceedings of the Third International

Conference on Knowledge Discovery and Data

Mining, California, August, 1997, pp 239-242.

Senousy, M., and Medhat, M., 2001, “A Proposed

Architecture for E-telligence Integration Model”,

Proceedings of the 8

Scientific Conference on

Information Systems and Computer Technology,

Cairo.

Stolfo,S,J., Prodromidis,A,L., Tselepis, L., Lee,W.,

Fan,D., and Chan,P,K., 1997, “JAM: Java Agents for

Meta-Learning over Distributed Databases”, in Proc.

of the 3rd Int. Conf. On Data Mining and Knowledge

Discovery (KDD-97), Newport Beach, California,

(eds) D.Heckerman, H.Mannila, D.Pregibon, and

R.Uthurusamy, AAAI Press, pp. 74-81.

Turkey, J., 1973, Exploratory Data Analysis, New York:

McMillan.

RETRO-DYNAMICS AND E-BUSINESS MODEL APPLICATION FOR DISTRIBUTED DATA MINING USING

MOBILE AGENTS

507
