TRANSACTION DESIGN FOR DATABASES WITH HIGH

PERFORMANCE AND AVAILABILITY

Lars Frank

Department of Informatics, Copenhagen Business School, Howitzvej 60, DK-2000 Frederiksberg, Denmark.

Keywords: ACID properties, database availability

, short duration locks, multi-databases, client/server technology, ERP

systems and E-commerce.

Abstract: When many concurrent transactions like ERP and E-commerce orders want to update the same

stock records, long duration locking may reduce the availability of the locked data. Therefore,

transactions are often designed without analyzing the consequences of loosing the traditional

ACID (Atomicity, Consistency, Isolation and Durability) properties. In this paper, we will analyze

how low isolation levels, optimistic concurrency control, short duration locks, and

countermeasures against isolation anomalies can be used to design transactions for databases with

high performance and availability. Long duration locks are defined as locks that are held until a

transaction has been committed, i.e. the data of a record is locked from the first read to the last

update of any data used by the transaction. This will decrease the availability of locked data for

concurrent transactions, and, therefore, optimistic concurrency control and low isolation levels are

often used. However, in systems with relatively many updates like ERP-systems and E-commerce

systems, low isolation levels cannot solve the availability problem as all update locks must be

exclusive. In such situations, we will recommend the use of short duration locks. Short duration

locks are local locks that are released as soon as possible, i.e. data will for example not be locked

across a dialog with the user. Normally, databases where only short duration locks are used do not

have the traditional ACID properties as at least the isolation property is missing when locks are not

hold across a dialog with the user. The problems caused by the missing ACID properties may be

managed by using approximated ACID properties, i.e. from an application point of view the

system should function as if all the traditional ACID properties had been implemented.

1 INTRODUCTION

In this paper, we will analyze how concurrency

methods like optimistic concurrency control and low

isolation levels can be integrated with short duration

locks and countermeasures against the absence of

the traditional ACID properties in order to design

transactions for databases with high performance

and availability. Table 1 gives an overview of the

properties of the methods used to increase

concurrency. Updating database transactions

consists often of several subtransactions. For

example, when a user is going to update some data

in a remote database, the user normally starts a

query that reads the data, which is going to be

updated. Next, the user makes corrections to the data

in user’s PC or workstation. Finally, the corrections

are sent to the remote database location where the

data is updated. If short duration locks are used in

the transaction described above, all the

subtransactions will have local ACID properties, but

the global transaction consisting of all the

subtransactions will not have the traditional ACID

properties. In this paper, we will use extended

transaction models where only approximated ACID

properties are implemented.

222

Frank L. (2004).

TRANSACTION DESIGN FOR DATABASES WITH HIGH PERFORMANCE AND AVAILABILITY.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 222-226

DOI: 10.5220/0002598702220226

 SciTePress

Table 1: Evaluation overview of methods to increase concurrency.

Evaluation criteria Optimistic

concurrency control

Low isolation levels Short duration locks Counter-

measures

Deadlock

Eliminates deadlock,

but restarts will occur

in case of conflicts

Can eliminate read-

write conflicts

Can eliminate both

read-write and write-

write conflicts

Special

countermeasures

against deadlock

may be

implemented

Hotspots

Hotspots will cause

many restarts

Can eliminate read-

write conflicts in

hotspots

Can diminish locking

time in hotspots

Special counter-

measures may be

designed against

hotspot problems

The atomicity

property

No problems No problems Extended transaction models should be used

The consistency

property

No problems May cause

inconsistency, and

therefore

countermeasures

may be used

Will cause

inconsistency, and

therefore

countermeasures

should be used

Asymptotic

consistency should

be used

The Isolation

property

No problems May cause isolation

anomalies, and

therefore

countermeasures

may be used

Will cause isolation

anomalies, and

therefore

countermeasures

should be used

Countermeasures

should be used to

manage isolation

anomalies

The durability

property

No problems No problems No problems if

atomicity is

implemented

No problems if

atomicity is

implemented

Distribution options

Distributed

concurrency control

will decrease

performance and

availability

May be implemented

in a distributed

DBMS without

further problems

Retriable

subtransactions may be

necessary to implement

atomicity

Many different

distributed

countermeasures

are available

Development costs

A DBMS facility A DBMS facility Extra costs for

compensation

implementation

Extra costs for

countermeasure

implementation

That is, the global atomicity property is

implemented by using compensatable, pivot and

retriable subtransactions in that order. The global

consistency and isolation properties are managed by

using countermeasures as described by Frank and

Zahle (1998). The global durability property is

implemented by using compensation and/or the

durability property of the local DBMS. By using this

transaction model it is possible to increase the

availability of both central and distributed databases

because only short duration locks are used. The

major disadvantage of using short duration locks is

the problems of managing the consistency of data.

However, these problems can be reduced/solved by

using countermeasures against the isolation

anomalies that occur when the isolation property is

missing.

The paper is organized as follows:

Section 2 will describe an extended version of the

countermeasure transaction model, which includes

central databases, and we will describe the most

important countermeasures against the isolation

anomalies used in central databases. In section 3, we

will illustrate how to design database transactions

optimized for high availability by using short

duration locks. Concluding remarks are presented in

section 5.

Related Research: The transaction model described

in section 2 is an extended version of the

countermeasure transaction model described by

Frank and Zahle (1998), Frank (1999), and Frank

and Kofod (2002). This model owes many of its

properties to e.g. Garcia-Molina and Salem (1987);

Mehrotra et al. (1992); Weikum and Schek (1992)

and Zhang (1994).

2 THE TRANSACTION MODEL

A multidatabase is a union of local autonomous

databases. Global transactions (Grey and Reuter,

TRANSACTION DESIGN FOR DATABASES WITH HIGH PERFORMANCE AND AVAILABILITY

223

1993) access data located in more than one local

database. In recent years, many transaction models

have been designed to integrate local databases

without using a distributed DBMS. The

countermeasure transaction model (Frank and Zahle,

1998) has, among other things, selected and

integrated properties from these transaction models

to reduce the problems caused by the missing ACID

properties in a distributed database that is not

managed by a distributed DBMS. In the

countermeasure transaction model,

a global

transaction involves a root transaction (client

transaction) and several single site subtransactions

(server transactions). Subtransactions may be nested

transactions, i.e. a subtransaction may be a parent

transaction for other subtransactions.

All communication with the user is managed from

the root transaction, and all data is accessed through

subtransactions. A subtransaction is either an

execution of a stored procedure that automatically

returns control to the parent transaction or an

execution of a stored program that does not return

control to the parent transaction. All remote

subtransactions are accessed through one of the

following types of middleware:

Remote Procedure Call (RPC)

From a programmer's point of view, a RPC

functions as a remote procedure call or submission

of a SQL query. From a performance and an

atomicity point of view, RPCs have the following

important properties:

• If a parent transaction executes several RPCs, the

corresponding stored procedures are executed

one at a time.

• A stored procedure or SQL submission has only

local ACID properties.

• The stored procedure or SQL submission

automatically returns control to the parent

transaction.

Update Propagation (UP)

In this context, UP is used in the sense of

propagating any data (not just updates) in such a

way that the data is transferred and stored/executed

with atomicity and durability properties. UPs have

the following properties, which are important from a

performance and an atomicity point of view:

• If a parent transaction initiates several UPs, the

corresponding, stored programs may be executed

in parallel.

• A stored program initiated from a UP has

atomicity together with the parent transaction,

i.e. either both or none are executed.

• The stored program does not automatically return

control to the parent transaction.

The following subsections will give a broad outline

of how approximated ACID properties are

implemented in the countermeasure transaction

model.

2.1 The Atomicity Property

An updating transaction has the atomicity property

and is called atomic if either all or none of its

updates are executed. In the countermeasure

transaction model, the global transaction is

partitioned into the following types of

subtransactions executed in different locations:

The pivot subtransaction that manages the atomicity

of the global transaction. The global transaction is

committed when the pivot subtransaction is

committed locally. If the pivot subtransaction aborts,

all the updates of the other subtransactions must be

compensated.

The compensatable subtransactions that all may be

compensated. Compensatable subtransactions must

always be executed before the pivot subtransaction

is executed to make it possible to compensate them

if the pivot subtransaction cannot be committed. A

compensatable subtransaction may be compensated

by executing a compensating subtransaction.

The retriable subtransactions that are designed in

such a way that the execution is guaranteed to

commit locally (sooner or later) if the pivot

subtransaction has been committed. A UP tool is

used to resubmit the request for execution

automatically until the subtransaction has been

committed locally, i.e. the UP tool is used to force

execution of the retriable subtransaction.

The global atomicity property is implemented by

executing the compensatable, pivot and retriable

subtransactions of a global transaction in that order.

For example, if the global transaction fails before the

pivot has been committed, it is possible to remove

the updates of the global transaction by

compensation. If the global transaction fails after the

pivot has been committed, the remaining retriable

subtransactions will be (re)executed automatically

until all the updates of the global transaction have

been committed.

2.2 The Consistency Property

The consistency property is not useful in distributed

databases with approximated ACID properties

because such a database is almost always

inconsistent.

2.3 The Isolation Property

The isolation property is normally implemented by

using long duration locks, which are locks that are

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

224

held until the (global) transaction has been

committed (Frank and Zahle, 1998). To ensure high

availability in locked data, short duration locks

should be used in all subtransactions, just as locks

should be released before interaction with a user.

This is not a problem in the countermeasure

transaction model as the traditional isolation property

is lost anyway. When transactions are executed

without isolation, the so-called isolation anomalies

may occur. If there is no isolation and the atomicity

property is implemented, the following isolation

anomalies may occur (Berenson et al., 1995 and

Breibart, 1992).

The lost update anomaly

is by definition a situation

where a first transaction reads a record for update

without using locks. Subsequently, the record is

updated by another transaction. Later, the update is

overwritten by the first transaction.

The dirty read anomaly

is by definition a situation

where a first transaction updates a record without

committing the update. Subsequently, a second

transaction reads the record. Later, the first update is

aborted (or committed), i.e. the second transaction

may have read a non-existing version of the record.

The non-repeatable read anomaly or fuzzy read

is by

definition a situation where a first transaction reads a

record without using locks. Later, the record is

updated and committed by a second transaction

before the first transaction has been committed. In

other words, it is not possible to rely on the data that

have been read.

The phantom anomaly

which is not dealt with in this

paper.

The countermeasure transaction model (Frank and

Zahle, 1998) describes countermeasures that reduce

the problems of the anomalies. The pessimistic view

countermeasure used in section 3 reduces or

eliminates the dirty read anomaly and/or the non-

repeatable read anomaly by giving the users a

pessimistic view of the situation. In other words, the

user cannot misuse the information. The purpose is to

eliminate the risk involved in using data where long

duration locks should have been used. A pessimistic

view countermeasure may be implemented by using:

• Compensatable subtransactions (or the pivot

transaction) for updates that limit the users’

options.

• Retriable subtransactions (or the pivot

transaction) for updates that increase the users’

options.

For example, when updating stocks, compensatable

subtransactions should be used to reduce the stocks

and retriable subtransactions should be used to

increase the stocks.

2.4 The Durability Property

Updates of transactions are said to be durable if they

are stored in stable storage and secured by a log

recovery system. The global durability property will

automatically be implemented, as it is ensured by the

log-system of the local DBMS systems (Breibart et

al., 1992).

3 TRANSACTION DESIGN IN E-

COMMERCE SYSTEMS

In this section, we will illustrate how to use our

transaction model in business-to-business E-

commerce. We will assume that the seller has a

customer file with the names, addresses, account

balances and credit limits for all his customers.

Therefore, the banks of the customers are not

involved in the following description of the order

transaction. At first, the buyer reads the offers made

by the seller. If the buyer wants to make an order,

the root transaction in the location of the buyer calls

a compensatable subtransaction at the location of the

seller. This subtransaction creates an order record

with relationship to the customer record at the same

location. Now, the buyer can make order-lines. For

each new order-line made by the buyer, the root

transaction starts a compensatable subtransaction,

and this subtransaction creates an order-line at the

location of the seller and updates the stock of the

product ordered in the order-line by using the

pessimistic view countermeasure. Pease notice that

making order lines cannot cause deadlock when only

short duration locks are used. If an order-line cannot

be fulfilled, the field “quantity-delivered” in the

order-line is updated. When the order form has been

completed, the pivot subtransaction updates the

account balance of the customer. If the credit limit

of the customer is not violated, the pivot

subtransaction will also confirm the deal for the

customer. Alternatively, the buyer will be the asked

to reduce the amount of the balance in order to avoid

violating the credit limit.By executing a

subtransaction that reduces the quantity ordered in

an order-line, the amount in the order-line can be

reduced and the stock of the product increased.

Finally, the buyer can retry to execute the pivot

subtransaction. The reread countermeasure should

be used as the customer record has been read earlier.

TRANSACTION DESIGN FOR DATABASES WITH HIGH PERFORMANCE AND AVAILABILITY

225

4 CONCLUSIONS

In this paper, we have analyzed how low isolation

levels, optimistic concurrency control, short duration

locks, and countermeasures against isolation

anomalies can be used to design transactions for

databases with high performance and availability.

The methods are independent of each other and,

therefore, a mixture of the methods may give the

best performance and availability. Using low

isolation levels will increase the availability of

locked data. If an application cannot accept the

anomalies that are caused by using a low isolation

level, it may be possible to minimize the time that

data is locked by substituting long duration

exclusive locks with short duration exclusive locks

and countermeasures against the anomalies that may

occur when a major database transaction is split into

minor database transactions performing the same

operations. The extra costs of this solution include

the implementation of approximated ACID

properties where e.g. DBMS aborts are substituted

by compensations. Even if all applications can

accept the anomalies caused by using a low isolation

level, problems may occur as there is no isolation

level that allows exclusive locks not to exclude

conflicting updates. Therefore, in hotspots where

many concurrent transactions update the same

records we recommend to use short duration

exclusive locks and countermeasures against the

anomalies that may occur when long duration

exclusive locks are substituted by short duration

locks.

Short duration locks and countermeasures against

the isolation anomalies should be mandatory for

long-lived transactions (Grey and Reuter, 1993) as

long duration locks per definition cannot be

recommended for such transactions. We have

illustrated how to use countermeasures against

isolation anomalies in E-commerce examples.

REFERENCES

Berenson, H., Bernstein, P., Gray, J., Melton, J., O’Neil,

E. and O’Neil, P., 1995, “A Critique of ANSI SQL

Isolation Levels”, Proc ACM SIGMOD Conf., pp. 1-

10.

Breibart, Y., Garcia-Molina, H. and Silberschatz, A.,

1992, “Overview of Multidatabase Transaction

Management”, VLDB Journal, 2, pp 181-239.

Frank, L., 1999, “Evaluation of the Basic Remote Backup

and Replication Methods for High Availability

Databases”, Software - Practice & Experience, Vol.

29, issue 15, pp 1339-1353.

L. Frank and Uffe Kofod, 2002, ‘Atomicity

Implementation in E-Commerce Systems’, Proc of the

Second International Conference on Electronic

Commerce, ICEB 2002, Taipei.

Frank, L. and Zahle, T, 1998, “Semantic ACID Properties

in Multidatabases Using Remote Procedure Calls and

Update Propagations”, Software - Practice &

Experience, Vol.28, pp77-98.

Gallersdörfer, R. and Nicola, M., 1995, “Improving

Performance in Replicated Databases through

Relaxed Coherency”, Proc 21st VLDB Conf, 1995, pp

445-455.

Garcia-Molina, H. and Salem, K., 1987, “Sagas”, ACM

SIGMOD Conf, pp 249-259.

Garcia-Molina, H. and Polyzois, C., 1990, “Issues in

disaster recovery”, IEEE Compcon., IEEE, New

York, pp 573-577.

Gray, J. and Reuter, A., 1993, “Transaction Processing”,

Morgan Kaufman, 1993.

Kung, H and Robinson, J, 1981, ‘On Optimistic Methods

for Concurrency Control’, ACM TODS 6, No. 2.

Humborstad, R., Sabaratnam, M., Hvasshovd, S. and

Torbjornsen, O., 1997, “1-Safe algorithms for

symmetric site configurations”, Proc 23th VLDB

Conf, 1997, pp 316-325.

Mehrotra, S., Rastogi, R., Korth, H., and Silberschatz, A.,

1992, “A transaction model for multi-database

systems”, Proc International Conference on

Distributed Computing Systems, pp 56-63.

O’Neil, P., “The Escrow Transaction Mode”, ACM TODS

11, No. 4, 1986.

Polyzois, C. and Garcia-Molina, H., 1994, “Evaluation of

Remote Backup Algorithms for Transaction-

Processing Systems”, ACM TODS, 19(3), pp 423-449.

Weikum, G. and Schek, H., 1992, “Concepts and

Applications of Multilevel Transactions and Open

Nested Transactions”, A. Elmagarmid (ed.): Database

Transaction Models for Advanced Applications,

Morgan Kaufmann, pp 515-553.

Zhang, A., Nodine, M., Bhargava, B. and Bukhres, O.,

1994, “Ensuring Relaxed Atomicity for Flexible

Transactions in Multidatabase Systems”, Proc ACM

SIGMOD Conf, pp 67-78.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

226
