USING SECURITY ATTACK SCENARIOS TO ANALYSE

SECURITY DURING INFORMATION SYSTEMS DESIGN

Haralambos Mouratidis

School of Computing and Technology, University of East London, England

Paolo Giorgini

Department of Information and Communication Technology, University of Trento, Italy

Gordon Manson

Department of Computer Science, University of Sheffield, England

Keywords:

Information Systems Analysis, Systems Engineering Methodologies, Security, Scenarios

Abstract:

It has been widely argued in the literature that security concerns should be integrated with software

engineering practices. However

, only recently work has been initiated towards this direction. Most of this

work, however, only considers how security can be analysed during the development lifecycles and not how

the security of an information system can be tested during the analysis and design stages. In this paper we

present results from the development of a technique, which is based on the use of scenarios, to test the

reaction of an information system against potential security attacks.

1 INTRODUCTION

In previous papers, we have presented a process that

allows developers to identify the security

requirements of an information system (Mouratidis,

2003), reason about a suitable architectural style

(Mouratidis, 2003a), and successfully transform

security requirements to design (Mouratidis, 2003b).

However, an important issue is to test how the

stem under devel

opment copes with possible

attacks. Testing is widely considered an important

activity that helps to identify errors in a system and

techniques such as control and data flow testing,

formal specifications, special testing languages, and

test tools have been used for many years in testing

systems, and they are considered valuable solutions

for many projects. However, most of these

approaches are difficult to apply, they require

special training and skills, and they employ their

own concepts and notations (Ryser, 1999).

These requirements usually conflict with many of

the c

haracteristics that a security orie

nted process

should demonstrate, such as to be clear and well

guided, to allow non-security specialists to consider

security issues in the development process and to

employ the same concepts and notations throughout

the development lifecycle of a software system.

This paper presents results from the development

of a

scenario-based

technique to test how an

information system under development copes

against potential security attacks. Section 2 provides

a brief overview of the Tropos methodology

necessary for readers non-familiar with the

methodology. Section 3 discusses our approach by

describing the Security Attack Scenarios, whereas

Section 4 illustrates our approach with the aid of an

example taken from the health care sector. In

Section 5 we present a discussion of related work

and Section 6 presents some concluding remarks and

future work.

2 THE TROPOS METHODOLOGY

Tropos is a development methodology tailored to

describe both the organisational environment of a

system and the system itself.

Mouratidis H., Giorgini P. and Manson G. (2004).

USING SECURITY ATTACK SCENARIOS TO ANALYSE SECURITY DURING INFORMATION SYSTEMS DESIGN.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 10-17

DOI: 10.5220/0002599000100017

 SciTePress

Tropos adopts the i* modelling framework (Yu,

1995), which uses the concepts of actors, goals,

tasks, resources and social dependencies for defining

the obligations of actors (dependees) to other actors

(dependers). Actors have strategic goals and

intentions within the system or the organisation and

represent (social) agents (organisational, human or

software), roles or positions (represent a set of roles.

A goal represents the strategic interests of an actor.

In Tropos we differentiate between hard goals

(simply called goals hereafter) and soft goals. Soft

goals represent non-functional requirements and

have no clear definition or criteria for deciding

whether they are satisfied or not (Yu, 1995). An

example of a soft goal is “the system should be

scalable”. A task represents a way of doing

something. Thus, for example a task can be executed

in order to satisfy a goal. A resource represents a

physical or an informational entity while a

dependency between two actors indicates that one

actor depends on another to accomplish a goal,

execute a task, or deliver a resource.

Therefore, in Tropos we consider the system as

an actor, which can be decomposed to sub-actors,

and we delegate to it goals to be satisfied (functional

requirements). In order to satisfy such goals we can

design the system in different ways and these can

have different affect on the non-functional

requirements, such as performance, reliability and

security.

In previous papers (Mouratidis, 2003 –

Mouratidis, 2003a – Mouratidis, 2003b), we have

presented how we extended the Tropos

methodology, by introducing the concepts of

security reference diagram and security constraints

and by redefining existing Tropos concepts such as

secure entities, secure dependencies, and secure

capabilities to enable it to consider security aspects

throughout the whole development process.

A security diagram (Mouratidis, 2002)

represents the connection between security features,

threats, protection objectives, and security

mechanisms that help towards the satisfaction of the

objectives. Security features represent security

related features that the system-to-be must have.

Protection objectives represent a set of principles

that contribute towards the achievement of the

security features. Threats on the other hand represent

circumstances that have the potential to cause loss or

problems that can put in danger the security features

of the system, while security mechanisms identify

possible protection mechanisms of achieving

protection objectives.

A security constraint (Mouratidis, 2002) is

defined as a constraint that is related to the security

of the system, whereas secure entities represent any

secure goals/tasks/resources of the system. Secure

goals are introduced to the system to help in the

achievement of a security constraint. A secure goal

(Mouratidis, 2002) does not particularly define how

the security constraint can be achieved, since (as in

the definition of goal) alternatives can be

considered. However, this is possible through a

secure task, since a task specifies a way of doing

something (Yu, 1995). Thus, a secure task

represents a particular way for satisfying a secure

goal. For example, for the secure goal Authorise

Access, we might have secure tasks such as Check

Password or Check Digital Signatures. A resource

that is related to a secure entity or a security

constraint is considered a secure resource

. For

example, an actor depends on another actor to

receive some information and this dependency

(resource dependency) is restricted by a constraint

Only Encrypted Info.

A secure dependency (Mouratidis, 2003)

introduces security constraint(s), proposed either by

the depender or the dependee in order to

successfully satisfy the dependency. For example a

Doctor (depender) depends on a Patient (dependee)

to obtain Health Information (dependum). However,

the Patient imposes a security constraint to the

Doctor to share health information only if consent is

obtained. Both the depender and the dependee must

agree in this constraint (or constraints) for the secure

dependency to be valid. That means, in the depender

side, the depender expects from the dependee to

satisfy the security constraints while in the dependee

side, a secure dependency means that the dependee

will make an effort to deliver the dependum by

satisfying the security constraint(s).

A secure capability (Mouratidis, 2003b)

represents the ability of an actor to achieve a secure

goal, carry out a secure task and/or deliver a secure

resource. For example, consider an actor that is

responsible for providing cryptographic services in

an information system. This actor should posses

(amongst other) secure capabilities to decrypt

incoming data and encrypt outgoing data.

3 ATTACK SCENARIOS

The popularity of scenarios have been increased

among software engineers and are proven to be

valuable for eliciting information about systems

requirements, communicating with stakeholders and

providing context for requirements (Ryser, 2000).

As a result, scenarios have been applied in many

different areas of computer science research, such as

software engineering (Potts, 1994), business-process

reengineering (Anton, 1994), and user interface

design (Carroll, 1991). In particular, many cases can

USING SECURITY ATTACK SCENARIOS TO ANALYSE SECURITY DURING INFORMATION SYSTEMS

DESIGN

be found in the literature (Ryser, 1999 – Ryser 2000

– Lalioti, 1995), where scenarios have been used for

the validation of requirements.

We have decided to choose a scenario-based

approach because scenarios can be easily integrated

within development methodologies and can be

adapted to the methodology’s notation and concepts.

This is due to the fact that scenarios can be

represented in various ways (Ryser, 2000). In this

research, a scenario, called Security Attack Scenario,

is represented as an enhanced Tropos diagram,

which aims to analyse how the system copes in

different kinds of security attacks.

Therefore a scenario should include enough

information about the system and its environment to

allow validation of the system’s security

requirements with respect to particular attacks. As

such, we define a Security Attack Scenario as an

attack situation describing the actors of a software

system and their secure capabilities as well as

possible attackers and their goals, and it identifies

how the secure capabilities of the system’s actors

prevent (if they prevent) the satisfaction of the

attackers’ goals.

The presented approach aims to identify the goals

and the intentions of possible attackers, identify

through these a set of possible attacks to the system

(test cases), and apply these attacks to the system to

see how it copes. By analysing the goals and the

intentions of the attackers the developer obtains

valuable information that helps to understand not

only the how the attacker might attack the system,

but also the why an attacker wants to attack the

system. This leads to a better understanding of how

possible attacks can be prevented. In addition, the

application of a set of identified attacks to the

system contributes towards the identification of

attacks that the system might not be able to cope

(failed test cases) and this leads to the re-definition

of the actors of the system and the addition of new

secure capabilities to enable them to protect against

those attacks.

A Security Attack Scenario involves a possible

attacker, possible attack(s), the resources that are

attacked, and the actors of the system related to the

attack together with their secure capabilities.

An attacker is depicted as an actor who aims to

break the security of the system. The attacker

intentions are modelled as goals and tasks and their

analysis follows the same reasoning techniques that

the Tropos methodology employs for goal and task

analysis. Attacks are depicted as dash-lined links

(called attack links) that contain an “attacks” tag,

starting from one of the attackers goals and ending

to the attacked resource.

For the purpose of a Security Attack Scenario, a

differentiation takes place between internal and

external actors of the system. Internal actors

represent the core actors of the system whereas

external actors represent actors that interact with the

system. Such a differentiation is essential since it

allows developers to identify different attacks to

resources of the system that are exchanged between

external and internal actors of the system.

The process is divided into three main stages:

creation of a scenario, validation of the scenario, and

testing and redefinition of the system according to

the scenario. Even though the presented process is

introduced as a sequence of stages, in reality is

highly iterative and stages can be interchanged

according to the perception of the developers. The

following three sub-sections describe each of those

stages.

3.1 Scenario Creation

There are two basic steps in the creation of a

scenario. The first step involves the identification of

the attackers’ intentions and the possible attacks to

the system and the second step involves

identification of possible countermeasures of the

system to the indicated attacks.

3.1.1 Identify the intentions of a possible

attacker

During the first step, the intentions of an attacker are

analysed in terms of goals and tasks. Some of these

goals can be identified by the threats modelled on

the security reference diagram. For example, a

possible threat to a system could be the application

of cryptographic attacks, i.e. attacks aiming to

modify the content of messages transmitted across

the network. Such a threat could introduce the goal

“perform cryptographic attacks” to a potential

attacker. However, other goals (apart from the ones

introduced by the threats identified in the security

reference diagram) could be derived from the

analysis of a possible attacker’s intentions. This is

due to the fact that an attack is an exploitation of a

system’s vulnerability, whereas a threat is a

circumstance that has the potential to cause loss or

harm (Schneier, 2000). Therefore, an attack can lead

to a threat only if the exploitation of the

vulnerability leads to a threat. This means that some

attacks can be successful but do not lead to threats as

other system features protect the system.

When the analysis of the attacker’s intentions has

been completed, possible attacks to the resources of

the system are indicated using attack links.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

3.1.2 Identify possible countermeasures

The next step in the creation of a security attack

scenario involves the identification of the actors of

the system that posses capabilities to prevent the

identified, from the previous step, attacks.

Secure capabilities can prevent attacks in the

information system in the sense that an actor with

such capabilities can react to the attacks.

Therefore, the actors (internal and external) of the

system related to the identified attack(s) are

modelled. The secure capabilities, of each actor, that

help to prevent the identified attacks are identified

and dashed-links (with the tag “help”) are provided

indicating the capability and the attack they help to

prevent. As an example, consider an internal actor

that depends on an external actor to obtain some

private information. An attacker aims to read the

transmitted data (eavesdropping). However, the

external and the internal actors could have been

assigned with secure capabilities to encrypt any data

transmitted between them. As a result,

eavesdropping becomes very difficult, since the data

is transmitted across the network only encrypted.

3.2 Scenario Validation

When the scenarios have been created, they must be

validated. Therefore, the next stage of the process

involves the validation of the scenario. Software

inspections are proved as effective means for

document-based validation (Kosters, 2001) and as

such are the choice of this research for the validation

of the security attack scenarios. The inspection of

the scenarios involves the identification of any

possible violations of the Tropos syntax and of any

possible inconsistency between the scenarios and the

models of the previous stages. Such an inspection

involves the use of validation checklists. Consider,

for instance, the following checklist.

1. Is a name defined for each scenario?

2. Are actors represented using the correct

notation?

3. Are attack links and help links correctly

denoted?

4. Do the attack scenarios capture all possible

attacks?

5. Do different scenarios exist for the same kind

of attacks?

6. Are there any missing parts on the identified

scenarios? (Any links missing or any actors

missing?)

7. Are there any secure capabilities identified in

the previous stages not present in the scenarios?

8. Are there any actors, identified in the

previous stages, related to the attacks not present

in the scenarios?

9. Are there any threats identified on the

security reference diagram not present on the

scenarios?

10. Are all the resources that can be attacked

present in the scenarios?

11. Are the non-prevented attacks correctly

marked?

It must be noticed that although inspections have

been proposed by this research for the validation of

the security attack scenarios, different techniques

could be applied depending on the developers and

the nature of the system. As an example, validation

techniques to requirements specification are (apart

from inspections) walkthroughs and prototyping

(Kosters, 2001).

When the scenarios have been validated, the next

step aims to identify test cases and test, using those

test cases, the security of the system against the

potential attacks. Each test case is derived from a

possible attack depicted in the security attack

scenarios. For each test case a precondition is

necessary (the state of the system before the attack),

an expected system reaction (how the system reacts

in the attack), and also a discussion that forms the

basis for the decision regarding the test case.

The test cases are applied and a decision is

formed to whether the system can prevent the

identified attacks or not. The decision whether an

attack can be prevented (and in what degree) or not

lies on the developer. However as an indication of

the decision it must be taken into consideration that

at least one secure capability must help an attack, in

order for the developer to decide the attack can be

prevented. Attacks that cannot be prevented are

notated as solid attack links (as opposed to dashed

attack links).

For each attack that it has been decided it cannot

be prevented, extra capabilities must be assigned to

the system to help towards the prevention of that

attack. In general, the assignment of extra secure

capabilities is not a unique process and depends on

the perception of the developer regarding the attack

dangers. However, a good approach could be to

analyse the capabilities of the attacker used to

perform the attack and assign the system with

capabilities that can revoke the attacker’s

capabilities.

4 AN EXAMPLE

To illustrate our approach we apply it to a case study

from the medical area. This case study is part of a

USING SECURITY ATTACK SCENARIOS TO ANALYSE SECURITY DURING INFORMATION SYSTEMS

DESIGN

real-life system, called the electronic Single

Assessment Process (eSAP), under development at

the University of Sheffield (Mouratidis, 2003c). The

electronic Single Assessment Process (eSAP) system

is a health and social care information system for the

effective care of older people. To make this example

simpler and more understandable, we consider a

substantial part of the eSAP system.

The application of the Security Attack Scenarios

to the eSAP aims to analyse the security of the

system by considering the intentions of possible

attackers and the secure capabilities that have been

assigned to the actors of the system and provide

recommendations to improve the system’s security.

As derived from the analysis of the eSAP system

(Mouratidis, 2003d), the three main security features

are privacy, integrity and availability. According to

Stallings (Stallings, 1999), the following categories

of attacks can be identified that can put in danger the

above security features.

Interception, in which an unauthorised party,

such as a person, a program or a computer, gains

access to an asset. This is an attack on privacy.

Modification, in which an unauthorised party not

only gains party to but also tampers with an asset.

This is an attack on integrity.

Interruption, in which an asset of the system is

destroyed or becomes unavailable or unusable. This

is an attack on availability.

Due to lack of space in this paper we present only

scenarios regarding interception and interruption

attacks.

Let us first consider an interception attack

scenario in which a possible attacker wishes to

attack the privacy of the system, in other words to

obtain information such as assessment information

or a care plan. As identified in the analysis of the

eSAP system, social engineering, password sniffing

and eavesdropping are the main threats to the

privacy of the system.

Therefore, the attacker’s main goal can be

decomposed to Read Data and Get Access to the

System sub-goals as shown in Figure 1. The first

sub-goal involves the attacker trying to read the data

that it is transmitted to and from the eSAP system,

whereas the second sub-goal involves the attacker

trying to break into the system and gain access to it.

To accomplish the first sub-goal the Attacker

should try to read the data transferred between the

Social Worker and the eSAP system’s actors such as

the Assessment Evaluator and the Authenticator.

To accomplish the second sub-goal, the Attacker

might use password sniffing or social engineering.

In the first case, the Attacker scans all the

resources that flow in the network looking for

passwords whereas in the case of social engineering,

the Attacker tries to deceive the Social Worker in

order to obtain valuable information, such as their

authorisation details that will allow them to gain

access to the system. Therefore, for the presented

attack scenario the reaction of the system should be

tested (amongst other) against three test cases, read

data, password sniffing and social engineering.

Test Case 1: read data

Precondition: The Social Worker actor tries to

obtain an assessment evaluation. The Attacker tries

to read the transmitted data.

System expected security reaction: The

system should prevent Attacker from reading any

(S)Change

Cryptographic

algorithm

(S)

Ask for Consent

(S) Secure

Capability

ure 1: Interce

tion attacks scenario

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

important information.

Discussion: The Attacker will try to read the

data from any resource transmitted between the

external actors and the eSAP system. However,

curerntly the system and its external actors have

capabilities to encrypt and decrypt data. As a result

all the important data is transmitted across the

network encrypted and therefore it is difficult for

the Attacker to read it. However, the Attacker

might try to obtain (or sometimes even guess) the

encryption key.

Test Case Result: The system is protected

against read data attacks. However, a

recommendation would be for the system to

change the cryptographic algorithm often.

Test Case 2: Password sniffing

Precondition: The Social Worker tries to

obtain access to the eSAP system by providing

their authorisation details. The Attacker tries to

intercept the authorisation details.

System expected security reaction: prevent

attacker from obtaining users’ passwords

Discussion: the main target of the Attacker

would be all the resource transmitions between the

Social Worker and the eSAP system. Currently the

system does not have any kind of protection in this

kind of attack. A good technique to defend against

password sniffing is to use one-time-passwords. A

one-time-password is a password tha is valid for

only one use. After this use, it is not longer valid,

and so even if the

Attacker obtains such a password it is useless.

However, the users must be able to gain access to

the system more than once. This can be

accomplished with, what is commonly known as,

a password list. Each time a user tries to access the

system they provide a different password from a

list of passwords.

Test Case Result: Currently the system fails to

protect against password sniffing attacks. For the

eSAP system to be able to react in a password

sniffing attack, the external actors of the system

(such as the Nurse, the Social Worker, the Older

Person) must be provided with capabilities to

provide passwords from a password list.

Test Case 3: Social engineering

Precondition: The Attacker tries to obtain

system information directly from the Social

Worker.

System expected security reaction: help

towards the prevention of social engineering

Discussion: The Attacker will try to deceive

any external actors (such as the Social Worker in

the presented scenario) into giving any

confidential, private or privileged information. It is

worth mentioning that the Attacker will not

directly ask for this information but they will try to

gain the trust of the actors and then exploit this

trust.

Test Case Result: Currently the system helps

towards the prevention of social engineering by

requesting consent for any information to be

shared. However, this alone does not guarantee the

successful prevention against social engineering. A

primary defence measurement against software

engineering is security awareness training. Good

resistance training will help to prevent actors from

being persuaded to give information away.

As mentioned above, interruption attacks

mainly aim the availability of the system. From an

Attacker’s point of view, such attacks can be

mainly categorised into two main categories,

physical attacks and electronic attacks (Figure 2).

Physical attacks include any attacks to the

infrastructure of the system, whereas electronic

attacks involve attacks such as denial of service

attacks.

Therefore, the Attacker’s main goal (attack

eSAP availability) can be decomposed to physical

and electronic attacks.

Physical attacks involve the cutting of a

communication line, or the destruction of a part of

the system.

On the other hand, one of the most popular

electronic attacks to the availability of a system is

denial of service attacks. Since physical attacks to

the eSAP system are outside the focus of this

research project, only a test case involving a denial

of service attack is considered.

Test Case: denial of service

Precondition: The Attacker tries to make the

eSAP system unavailable by performing a denial

of service attack.

System expected security reaction: the eSAP

should be able to detect the attack and recover.

Discussion: During a denial of service attack,

the Attacker tries to prevent the normal operation

of the communication facilities of the system.

Since a denial of service attack is an active attack,

the main goal of the eSAP system is to detect the

attack and recover from any disruption it may

cause as fast as possible. Towards this direction,

the actors of the system must have capabilities to

operate even if some other actors have become

unavailable. Mostly, denial of service attacks

USING SECURITY ATTACK SCENARIOS TO ANALYSE SECURITY DURING INFORMATION SYSTEMS

DESIGN

Figure 2: Interruption attacks scenario

require from Attackers to steal an administration

account of a hose computer in the network.

Therefore, an efficient way to prevent such attacks

is to secure the system. In addition, the Attacker

might make use of spoofed source address. To stop

this, the system must perform filtering mainly

when internal actors communicate with external

ones.

Test Case Results: The eSAP system provides

authorisation mechanisms and therefore helps

towards the effective security of the system and in

turn the prevention of denial of service attacks.

However, filtering is required to make the

protection against denial of service attacks even

better. Therefore, an actor should be introduced to

the system that will perform such filtering.

4.1 Discussion on the use of

scenarios in the eSAP system

In order to test the security of the system, two

different kinds of scenarios were identified

involving four different test cases. By applying

these test cases many useful results were obtained

about the security of the eSAP system. First of all,

it was identified that the system provides enough

protection against some of these attacks. Secondly,

for the attacks that the system did not provided

adequately protection, extra actors and extra secure

capabilities were identified and the following

modifications (amongst other) took place in the

eSAP system.

Capabilities were given to the external actors

as well to the Cryptography Manager to enable

them to change the cryptographic algorithm often.

The lack of such capabilities was identified during

the read data test case of the interception attack

scenario.

The external actors of the system were given

the capability to provide passwords from a

password list, and the Authenticator was given

capabilities to successfully process such

passwords. The lack of such capabilities was

identified by the application of the password-

sniffing test case of the interception attack

scenario.

An actor was introduced to the system to filter

the eSAP in order to help towards the protection of

denial of service attacks. The lack of such an actor

was identified by the application of the denial of

service test case of the interruption security attack

scenario.

5 RELATED WORK

Scenarios have been used in many areas of

software engineering, from requirements

modelling (Potts, 1994) to requirements validation

(Ryser, 2000).

Our idea of analysing the intentions of possible

attackers is similar to the one presented by Liu et

al (Liu, 2002). However, the way that our

scenarios are created, verified and applied is totally

different.

Yu’s work is basically used to identify security

requirements; the Security Attack Scenarios in our

work are used to test the security requirements of

the system identified in the previous development

stages. So a very similar idea is applied in a

different stage of the development lifecycle.

Yu argues that when the intentions of the

attackers are identified we can equip the system

with countermeasures, however it is never

mentioned how we can do this neither provides a

kind of process for providing such

countermeasures.

Moreover, in our approach we consider test

cases, in other words we provide ways to test each

scenario for specific test cases, reason about the

reaction of the system and take a final decision if

the system can react to the specific attack. In cases

that the system cannot react to the attack, possible

countermeasures are discussed and secure

capabilities are introduced to the actors of the

system to satisfy them.

Yu’s analysis takes place in a higher level than

the one proposed by us. Yu proposes the analysis

to take place during the early requirements. This

could be a bit superficial for security since

modelling security requirements as softgoals does

not adequately model security (Mouratidis, 2002).

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

In our case, we know the secure capabilities of the

actors of the system (and therefore we have a more

precise idea of what security measurements our

system has) and we can reason about the security

attacks according to those capabilities.

6 CONCLUSIONS AND FUTURE

WORK

In this paper we have presented results from the

development of a scenario-based approach to test

how a software system under development copes

against potential security attacks.

The introduction of security attack scenarios to

test the system’s response to potential attacks

provides developers the ability to realistically

check how the developed system will react to

possible security attacks. This, in turn, allows

developers to re-consider particular system

functions with respect to security until the system

under development satisfies all the security

requirements.

The presented work is part of our efforts aiming

to extend the Tropos methodology in a degree that

will allow developers to successfully consider

security issues during the whole development

lifecycle of an information system.

Therefore, future work includes the full

integration of the presented technique within the

security oriented process of the Tropos

methodology, and its application to more case

studies in order to further assess its validity.

REFERENCES

Anton, A.I., McCracken W.M., Potts C., 1994. Goal

Decomposition and Scenario Analysis in Business

Process Reengineering, Proceedings of the 6

Conference on Advanced Information Systems

(CAiSE-1994), The Netherlands.

Carroll, J.M., Rosson, M.B., 1991. Getting Around the

Task-Artifact Cycle: How to Make Claims and

Design by Scenario, IBM Research Report, Human

Computer Interaction, RC 17908 (75365).

Kosters, G., Pagel, B.U., Winter, M., 1997. Coupling

Use Cases and Class Models, Proceedings of the

BCS-FACS/EROS workshop on "Making Object

Oriented Methods More Rigorous", Imperial

College, London-England.

Lalioti, V., Theodoulidis, C., 1995. Visual Scenarios for

Validation of Requirements Specification,

Proceedings of the 7th International Conference on

Software Engineering and Knowledge Engineering

(SEKE'95), Rochville, Maryland-USA.

Liu, L., Yu, E., Mylopoulos, J., 2002. Analyzing

Security Requirements as Relationships Among

Strategic Actors, Proceedings of the 2

Symposium

on Requirements Engineering for Information

Security (SREIS’02), Raleigh-North Carolina.

Mouratidis, H., 2002. Extending Tropos Methodology to

Accommodate Security, Progress Report, Computer

Science Department, University of Sheffield.

Mouratidis, H., 2003d. Analysis and Design of a

Multiagent System to Deliver the Single Assessment

Process for Older People, RANK Report, Computer

Science Department, University of Sheffield.

Mouratidis, H., Giorgini, P., Manson, G., 2003a.

Integrating Security and Systems Engineering:

Towards the Modelling of Secure Information

Systems, Proceedings of the 15

Conference on

Advance Information Systems (CAiSE-2003),

Velden-Austria.

Mouratidis, H., Giorgini, P., Manson, G., 2003b.

Modelling Secure Multiagent Systems, Proceedings

of the 2

International Joint Conference on

Autonomous Agents and Multiagent Systems

(AAMAS-2003), Melbourne-Australia.

Mouratidis, H., Giorgini, P., Manson, G., Gani A., 2003.

Analysing Security Requirements of Information

Systems Using Tropos, Proceedings of the 5

International Conference on Enterprise Information

Systems (ICEIS-2003), Angers-France.

Mouratidis, H., Philp, I., Manson, G., 2003c. A Novel

Agent-Based System to Support the Single

Assessment Process of Older People, (to appear)

Journal of Health Informatics.

Potts, C., Takahashi, K., Anton A.I., 1994. Inquiry

Based Requirements Analysis, IEEE Software,

March 1994.

Ryser, J., Glinz, M., 1999. A Practical Approach to

Validating and Testing Software Systems Using

Scenarios, Proceedings of the Third International

Software Quality Week Europe (QWE'99), Brussel-,

Belgium.

Ryser, J., Glinz, M., 2000. SCENT - A Method

Employing Scenarios to Systematically Derive Test

Cases for System Test, Technical Report 2000.03,

Institut für Informatik, University of Zurich.

Schneier, B., 2000. Secrets and Lies: Digital Security in

a Networked World, John Willey and Sons.

Stallings, W., 1999. Cryptography and Network

Security: Principles and Practice, Prentice-Hall,

Second Edition.

Yu, E., 1995. Modelling Strategic Relationships for

Process Reengineering, PhD thesis, Department of

Computer Science, University of Toronto, Canada.

USING SECURITY ATTACK SCENARIOS TO ANALYSE SECURITY DURING INFORMATION SYSTEMS

DESIGN
