USER INTERFACE DESIGN FOR VOICE CONTROL SYSTEMS

Wolfgang Tschirk

Siemens AG Austria, Speech Recognition Resort

Erdberger Lände 26, A-1031 Wien, Austria

Keywords:

Voice control systems, speech recognition, user interfaces, man-machine interfaces.

Abstract:

A voice control system converts spoken commands into control actions, a process which is always imperfect

due to errors of the speech recognizer. Most speech recognition research is focused on decreasing the recogniz-

ers’ error rates; comparatively little effort was spent to ﬁnd interface designs that optimize the overall system,

given a ﬁxed speech recognizer performance. In order to evaluate such designs prior to their implementation

and test, three components are required: 1) an appropriate set of performance ﬁgures of the speech recognizer,

2) suitable performance criteria for the user interface, and 3) a mathematical framework for estimating the

interface performance from that of the speech recognizer. In this paper, we will identify four basic interface

designs and propose an analytical approach for predicting their respective performance.

1 INTRODUCTION

James Glass et al. point out that "developing conver-

sational interfaces is a classic chicken and egg prob-

lem. In order to develop system capabilities, one

needs to have a large corpus of data [...]. In order to

collect data that reﬂect actual usage, one needs to have

a system that users can speak to." (Glass et al., 2000).

Compared to the vast literature on traditional speech

recognition aspects like signal analysis, feature ex-

traction, pattern comparison techniques, and search

strategies, for which excellent reports are available in

(Rabiner and Juang, 1993), (IEEE, 1994), and (IEEE,

2002), little work was devoted to the development of

analytical methods for user interface design. How-

ever, analytical approaches can considerably shorten

trial and error loops in system development and raise

robustness and user-friendlyness of voice control sys-

tems in a way hardly achievable by classical speech

recognizer improvements.

A mathematical approach for dialogue control is

proposed in (Niimi and Nishimoto, 1999), where

the authors derive relations between speech recog-

nizer performance and dialogue efﬁciency, and com-

pare four strategies of conﬁrming user inputs. They

focus on keyword confusion and leave the prob-

lem most severe in real world voice control systems,

namely to balance the acceptance of non-keywords

with its counterpart, the keyword rejection, as fu-

ture work. The computer-aided design and develop-

ment approach for spoken dialogue systems given in

(Lin and Lee, 2001) estimates performance ﬁgures by

quantitative simulations, comparing different strate-

gies of query and conﬁrmation on a ﬁnite state ma-

chine model of the user interface.

In our paper, we consider all possible user inter-

face errors for four basic interface designs. We show

analytically how the error rates observed on the user

interface depend on those of the speech recognizer,

and how the former can be minimized while the latter

remain unchanged. As an auxiliary result, we express

the error rates for different vocabulary sizes in terms

of the rates for a single vocabulary of arbitrary (how-

ever reasonable) size, an achievement which greatly

reduces test effort. Throughout this paper, we con-

centrate on isolated word recognition, which is the

dominant technology for a wide range of voice control

systems. We take into account that, typically, users

of such systems are not pleased with a period of un-

certainty after having entered a command; therefore,

we do not allow delayed decisions, although they are

found to improve the performance of spoken dialogue

systems (Souvignier et al., 2000).

Another crucial aspect of voice control system de-

sign lies beyond the scope of our paper: the question

of selecting appropriate commands for a given set of

Tschirk W. (2004).

USER INTERFACE DESIGN FOR VOICE CONTROL SYSTEMS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 21-26

DOI: 10.5220/0002602100210026

 SciTePress

control functions − words that are easily recognized

automatically and, at the same time, correspond to the

intuitive choice of most users.

2 SPEECH RECOGNIZER

ERRORS

2.1 Error Types

In a speech recognizer’s front end, the incoming audio

signal is converted into parameters, commonly called

features, that carry information relevant for the recog-

nition act. The result is a pattern of features, which

may be a vector composed of energy values over time

and frequency or of other appropriate measures (Ra-

biner and Juang, 1993). Since here we do not deal

with the feature extraction, we consider the pattern

rather than the audio signal as the input to the speech

recognizer.

Then, within the context of isolated word recogni-

tion, a speech recognizer is an algorithm that assigns

one of N + 1 classes W

, 0 ≤ i ≤ N , to a pattern p.

We denote W

the garbage class, i.e. the class which

shall be assigned to all patterns derived from back-

ground noise. The set of classes {W

, 0 ≤ i ≤ N }

is the recognizer’s vocabulary; N, the number of non-

garbage classes, is the vocabulary size.

For classifying an incoming pattern p, the recog-

nizer calculates a score s

for each class W

. The

higher s

, the better p matches W

, such that ﬁnally

the class with the highest score is assigned to p. (For

recognizers that deliver a low score as an indicator for

a good match, we reverse the sign of the score). The

scores shall only depend on p; we envisage a func-

tional split where the recognizer is context-free and

any context-dependency is located in an extra compo-

nent of the user interface.

When a pattern is classiﬁed as garbage, we say that

it is rejected; otherwise we say that it is accepted.

Each recognition error falls into one of the following

three categories: confusion (a non-garbage pattern is

assigned the wrong non-garbage class), false rejec-

tion (a non-garbage pattern is classiﬁed as garbage),

and false acceptance (a garbage pattern is assigned a

non-garbage class).

A recognizer’s performance can be described in

terms of rates c of confusions, r of false rejections,

and a of false acceptances. Such rates are usually es-

timated by feeding a set of patterns which were not

used for training (the test set) into the recognizer and

counting the incorrect outcomes appropriately. If the

test set represents the patterns expected during oper-

ation, the rates measured can be viewed as a good

guess for the underlying probabilities.

2.2 Error Rates and Vocabulary Size

In Section 6, we give an algorithm for predicting the

error rates observable on the user interface. It in-

volves the estimation of the speech recognizer’s error

rates on different vocabulary sizes. Ideally, they are

obtained from testing; however, this might require an

enormous test effort and the availability of sufﬁcient

data. As an alternative, we now derive a formalism

for predicting the error rates c

, r

, and a

on a

vocabulary of size M from the rates estimated on a

vocabulary of size N. It is particularly helpful in the

design of voice control systems featuring large num-

bers of commands when data are available for only

a small number of words, and relies on assumptions

reasonable in the absence of other evidence:

If the recognizer receives a non-garbage pattern p

of class W

, we assume that 1) the probability that

p is rejected rather than accepted as W

does not de-

pend on the presence of classes other than W

and

, and 2) the probability that p is classiﬁed as W

rather than W

is equal for all i 6∈ {k, 0} and inde-

pendent of the presence of classes other than W

and

. If the recognizer receives a garbage pattern, we

assume that 3) the probability that p is classiﬁed as

rather than garbage is equal for all i 6= 0 and in-

dependent of the presence of classes other than W

and W

With these assumptions and the trivial ﬁgure

= 0, we obtain (see Appendix) for M, N > 0:

(M − 1)c

(N − 1) + (M − N )c

, (1)

(N − 1)r

(N − 1) + (M − N )c

, (2)

N + (M − N)a

. (3)

3 USER INTERFACE ERRORS

Also on the user interface, we observe confusions,

false rejections, and false acceptances. How the rates

of these errors derive from the speech recognizer’s er-

ror rates, depends on the particular user interface de-

sign. For a number of design alternatives, we will give

these relationships in the following sections.

In general, no design will be optimum with respect

to all three types of errors. Therefore, each voice con-

trol system calls for its own optimization criterion.

Some authors propose to use weighed sums of the er-

ror rates (Villarrubia and Acero, 1993) and to set the

weights according to the requirements of the particu-

lar application. Others measure dialogue efﬁciency in

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

terms of the average number of exchanges taken (Ni-

imi and Nishimoto, 1999) or the percentage of satis-

ﬁed users (Lin and Lee, 2001).

In our performance estimations, we will stick to the

rates of confusions, false rejections, and false accep-

tances, and, from the ﬁrst two of them, which relate

to incorrect system reactions on correct user inputs,

we will estimate a lower bound for the rate of failed

command sequences (a command sequence is a con-

catenation of keyword utterances required to make the

voice control system perform a certain action; e.g. a

command sequence consisting of light and switch on

may cause the voice control switch on the light).

4 SUBVOCABULARY TYPES

4.1 Embedded Subvocabulary

In a voice control system designed to control a light,

a heater, and a telephone, the word warmer makes

sense in the context of the heater control but not when

the light menu or the telephone menu are selected; the

commands switch on and switch off may be allowed

for both the light and the heater. In such a way, at each

time instant only a subset of the speech recognizer’s

vocabulary is active, and these subvocabularies may

have words in common.

If the system considers all classes, whether they be-

long to the active subvocabulary or not, we call the

subvocabulary embedded. First, we analyze this strat-

egy in its simplest form: an observable confusion oc-

curs, if the recognizer commits a confusion and the

result belongs to the active subvocabulary; an observ-

able false rejection occurs, if 1) the recognizer com-

mits a false rejection, or 2) the recognizer commits a

confusion and the result does not belong to the ac-

tive subvocabulary; an observable false acceptance

occurs, if the recognizer commits a false acceptance

and the result belongs to the active subvocabulary.

In the absence of user errors, which we assume

throughout this analysis, a correct non-garbage result

always belongs to the active subvocabulary. A wrong

non-garbage result is assumed to fall into each of the

remaining classes with equal probability. From this,

we ﬁnd the rates C

of confusions, R

of false re-

jections, and A

of false acceptances observable on

the user interface for an embedded subvocabulary of

size S > 0 out of a total vocabulary of size N ≥ S as

follows:

S − 1

N − 1

, (4)

= r

N − S

N − 1

, (5)

. (6)

For large N with small S, a more sophisticated

approach is favourable: if a non-garbage result falls

out of the active subvocabulary, then the class which

scored next is taken as a new hypothesis, and this pro-

cess is repeated until either a hypothesis is garbage

or falls into the active subvocabulary, or a predeﬁned

number H of hypotheses were examined. This strat-

egy is implemented in the voice control devices de-

scribed in (Tschirk, 2001). For 2 ≤ H ≤ N − S, the

observable error rates are given by:

S,H

= C

i=2

S − 1

N − i

N−i+1

i−1

j=1

N − S − j + 1

N − j

N−j+1

(7)

S,H

= R

i=2

N − S − i + 1

N − i

N−i+1

i=2

N−i+1

i−1

j=1

N − S − j + 1

N − j

N−j+1

(8)

S,H

= A

i=2

N − i + 1

N−i+1

i−1

j=1

N − S − j + 1

N − j + 1

N−j+1

(9)

In Section 7, we mainly refer to the usage of em-

bedded subvocabularies as given by Equations (4) to

(6). The power of examining more than one hypothe-

sis is shown in Section 7.4.

4.2 Separated Subvocabulary

If the system evaluates each incoming pattern with re-

spect to only those classes represented in the active

subvocabulary, disregarding the other ones, we call

the subvocabulary separated. The observable error

rates on a separated subvocabulary of size S are de-

rived from Equations (4) to (6) by setting N = S.

5 MENU ARRANGEMENTS

5.1 Hierarchical Menus

On an voice interface featuring menus, the user has to

select the appropriate menu prior to submitting a con-

trol command. In our example of Section 7.2, each

controllable device has its own menu. We can place

a device selection menu on the top level of the user

interface, such that switching on the light requires ei-

ther a sequence of 3 commands: select to go to the

USER INTERFACE DESIGN FOR VOICE CONTROL SYSTEMS

selection menu, light to select the light, and switch on

to switch it on, or, if the light menu was the last one

selected, a sequence of length 1: switch on. We call

this menu arrangement hierarchical.

5.2 Connected Menus

In order to support direct switching between menus,

we include each device identiﬁer into each of the

device menus, thus eliminating the selection menu.

Switching on the light requires either a command se-

quence of length 2: light and switch on, or of length 1:

switch on, depending on the recently selected menu.

We call this arrangement connected. Compared to the

hierarchical one, the connected arrangement requires

fewer steps on larger subvocabularies.

5.3 Command Sequence Behaviour

The error rates deﬁned so far apply to single-pattern

reception. Now we deﬁne a command sequence fail-

ure rate. A command sequence is considered success-

ful, if each command is recognized correctly, other-

wise it is considered failed. For the purpose of sim-

plicity, we assume that command sequences are not

interrupted by garbage reception. Consequently, the

command sequence failure rate below gives a lower

bound for the actual ﬁgure, and the false acceptance

rate has no impact on the command sequence perfor-

mance and is kept as an extra ﬁgure. Assuming in-

dependent recognition errors, the failure rate F

of a

command sequence of length L is given by

= 1 −

i=1

1 − (C

+ R

)

, (10)

where N

and S

are the recognizer’s vocabulary and

subvocabulary size, respectively, in the user interface

state corresponding to the reception of the i-th com-

mand. Equation (10) holds for all menu arrangements

and all subvocabulary types.

6 BASIC INTERFACE DESIGNS

Combining the alternatives given in Sections 4 and 5,

we identify four basic user interface designs:

design HE: hierarchical menu arrangement, em-

bedded subvocabularies,

design HS: hierarchical menu arrangement, sepa-

rated subvocabularies,

design CE: connected menu arrangement, embed-

ded subvocabularies,

design CS: connected menu arrangement, separated

subvocabularies.

In Section 7, we will evaluate, for three example

systems, these four designs, in order to point out the

advantages and drawbacks of each approach under the

conditions stated.

The evaluation of a design consists of four steps:

step 1: estimate the vocabulary and subvocabulary

sizes corresponding to each menu,

step 2: estimate the necessary speech recognizer

error rates via testing or by using Equations (1) to (3)

with appropriate test ﬁgures as inputs,

step 3: calculate the observable error rates for each

menu, using Equations (4) to (6) or (7) to (9),

step 4: for each command sequence type, calculate

the failure rate according to Equation (10).

7 EXAMPLE SYSTEMS

7.1 Example Speech Recognizer

Suppose a speech recognizer with the error rates:

= 0.005, r

= 0.03, and a

= 0.20 for a vocab-

ulary of size 10, on which the voice control systems

of Sections 7.2 to 7.4 shall be based. We do not con-

sider modiﬁcations of the recognizer itself. Instead,

we ask for the optimum user interface design for the

respective task, given the recognizer as it is.

7.2 Light, Heater, and Telephone

Control

Our ﬁrst example system shall control a light with

the commands switch on, switch off, brighter, and

darker, a heater with switch on, switch off, warmer,

and cooler, and a hands-free telephone with connect,

disconnect, louder, and softer. The device selectors

are light, heater, and telephone. For the hierarchi-

cal arrangement, select shall be used to enter the de-

vice selection menu. Note that each device has the

same number of control commands, which facilitates

our analysis; in real world systems, different devices

will, in general, have control command sets of differ-

ent sizes. We analyze the system following Section 6,

using Equations (1) to (3) together with the recognizer

ﬁgures of Section 7.1 in step 2. The results are shown

in Table 1; there, the select-and-control failure rate

corresponds to command sequences required to select

a device and invoke a control action on it, whereas the

control failure rate corresponds to commands invok-

ing a control action on an already selected device.

In this example, the lowest select-and-control fail-

ure rate is achieved by employing the connected menu

arrangement together with separated subvocabularies;

however, it is paid with the highest false acceptance

rate.

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

Table 1: Performance ﬁgures for different user interface de-

signs of a voice control system featuring device menus. In

the hierarchical designs, the false acceptance rate is taken

from the device menus, since voice control systems assume

that state most of the time (in the connected designs, the

false acceptance rate is equal for all menus).

HE HS CE CS

select-and-

control

failure rate 0.1073 0.0928 0.0719 0.0657

control

failure rate 0.0371 0.0323 0.0366 0.0334

false accep-

tance rate 0.0926 0.1111 0.1321 0.1489

7.3 Single–Device Control

The second example relates to a single 50-commands

control menu without subvocabularies. All designs

are identical, each command sequence is of length 1.

The performance is given in Table 2.

Table 2: Performance ﬁgures for a large single device con-

trol menu.

all designs

command sequence failure rate 0.0560

false acceptance rate 0.5556

Here, the exorbitant false acceptance rate is likely

to cause permanent unintentional activation of the

system. This undesired behaviour is a consequence of

the large number of commands allowed at each time

instant without any context.

7.4 Keyword Activation

As a third example, we modify the interface of Sec-

tion 7.3. We reduce the number of false acceptances

by introducing a sleep mode, in which the system ac-

cepts nothing but a certain wake up keyword. After

having been activated with wake up, it accepts each

one of its 50 commands and an extra sleep keyword,

which brings it back into the sleep mode.

The results of the analysis are shown in Table 3.

The wake-up-and-control failure rate corresponds to

command sequences required to get the voice control

system out of its sleep mode and invoke a control ac-

tion, whereas the control-or-sleep failure rate corre-

sponds to commanding an already active system or

bringing it back into the sleep mode. Since there are

only two menus, hierarchical and connected arrange-

ment are identical. In the active mode (ﬁrst and sec-

ond row), the interface behaves very similar to the one

of Section 7.3. In the sleep mode, false acceptances

are almost suppressed (last row), and we ﬁnd that the

technique of embedded subvocabularies yields a false

acceptance behaviour far better than that of separated

subvocabularies, at moderate cost with respect to the

wake-up-and-control failure rate (third row).

Table 3: Performance ﬁgures for different user interface de-

signs of a voice control system with keyword activation.

HE, CE HS, CS

control-or-sleep

failure rate 0.0570 0.0565

active mode

false acceptance rate 0.5543 0.5604

wake-up-and-control

failure rate 0.1108 0.0849

sleep mode

false acceptance rate 0.0109 0.0244

If, in case of an out-of-subvocabulary rejection in

the sleep mode, we examine a second hypothesis ac-

cording to Equations (7) to (9), we can lower the sleep

mode false acceptance rate almost without raising the

wake-up-and-control failure rate compared to the sep-

arated subvocabulary design:

Table 4: Performance ﬁgures for a voice control system

with keyword activation, examining a second hypothesis in

case of an out-of-subvocabulary rejection in the sleep mode.

HE, CE (H = 2)

wake-up-and-control

failure rate 0.0861

sleep mode

false acceptance rate 0.0170

8 CONCLUSION

We presented an analytical approach for estimating

the performance of voice control user interfaces, ap-

plicable to systems based on isolated word recogni-

tion and featuring menus. It allows for deriving de-

sign guidelines and focuses on user interface opti-

mization, given the speech recognizer’s performance.

In order to make such estimation feasible even if suf-

ﬁcient test data are not available, we derived a formal-

ism for predicting a speech recognizer’s error rates on

different vocabulary sizes from the rates obtained on

a single vocabulary of arbitrary (however reasonable)

size.

We illustrated the approach by comparing four ba-

sic user interface designs. Mechanisms for improving

voice interfaces which were left out of the study, such

as the weighing of errors according to their relative

USER INTERFACE DESIGN FOR VOICE CONTROL SYSTEMS

importance or the minimization of overall error rates

by taking into account the a priori probability of com-

mands, can easily be integrated into the formalism.

The framework given here can also be used to se-

lect the best recognizer for a particular task, which

may be characterized by non-negotiable parameters

such as the number of menus and the menu sizes.

The methods presented were developed in the

course of the design of voice remote control sys-

tems for physically disabled people (Tschirk, 2001).

They were found useful for early detection of design

strengths and weaknesses. Clearly, they cannot elim-

inate the need for exhaustive real world testing.

APPENDIX

We view the recognition of a non-garbage pattern of

class W

as an experiment (Papoulis, 1984); its out-

comes are the class indices j ∈ {0, . . . , N}. To each

outcome j, we assign a probability p(j), which is ei-

ther p

(N): the probability of correct recognition, or

(N): the probability of confusion into a speciﬁc

class, or p

(N): the probability of rejection.

p(k) = p

(N),

p(i, i 6∈ {k, 0}) = p

(N),

p(0) = p

(N),

with

(N) + (N − 1)p

(N) + p

(N) = 1. (11)

Confusion rate and false rejection rate are given by

= (N − 1)p

(N), (12)

= p

(N). (13)

From assumption (1) of Section 2.2 follows that

(N)/(p

(N)+p

(N)) does not depend on N; from

assumption (2) follows that p

(N)/(p

(N) +p

(N))

does not depend on N. Thus, both expressions are

constant, and there exist constant u = p

(N)/p

(N)

and v = p

(N)/p

(N), such that we can rewrite

Equations (11) to (13) to

(N − 1)v

u + (N − 1)v + 1

Since this holds for all N > 1, we obtain Equa-

tions (1) and (2).

Now we view the recognition of a garbage pattern

as an experiment and assign to each outcome either

(N): the probability of rejection, or q

(N): the

probability of acceptance with respect to a speciﬁc

class.

p(0) = q

(N),

p(i, i 6= 0) = q

(N),

with

(N) + Nq

(N) = 1. (14)

The false acceptance rate is given by

= Nq

(N). (15)

From assumption (3) of Section 2.2 follows that

(N)/(q

(N) + q

(N)) does not depend on N .

Thus, there exists a constant w = q

(N)/q

(N), such

that we can rewrite Equations (14) and (15) to

w + N

Since this holds for all N > 0, we obtain Equa-

tion (3).

REFERENCES

Glass, J., Polifroni, J., Seneff, S., and Zue, V. (2000). Data

collection and performance evaluation of spoken dia-

logue systems: The MIT experience. Massachusetts

Institute of Technology.

IEEE (1994). Special section on robust speech recognition.

In IEEE Transactions on Speech and Audio Process-

ing vol. 2, no. 4, pp. 549-643, October 1994.

IEEE (2002). Special issue on automatic speech recognition

for mobile and portable devices. In IEEE Transactions

on Speech and Audio Processing vol. 10, no. 8, pp.

529-658, November 2002.

Lin, B.-S. and Lee, L.-S. (2001). Computer-aided anal-

ysis and design for spoken dialogue systems based

on quantitative simulations. In IEEE Transactions on

Speech and Audio Processing vol. 9, no. 5, pp. 534-

548, July 2001.

Niimi, Y. and Nishimoto, T. (1999). Mathematical analy-

sis of dialogue control strategies. In Proceedings of

EUROSPEECH 99 vol. 3, pp. 1403-1406.

Papoulis, A. (1984). Probability, Random Variables, and

Stochastic Processes. McGraw-Hill, New York.

Rabiner, L. and Juang, B.-H. (1993). Fundamentals of

Speech Recognition. Prentice-Hall, Englewood Cliffs,

NJ.

Souvignier, B., Kellner, A., Rueber, B., Schramm, H., and

Seide, F. (2000). The thoughtful elephant: Strategies

for spoken dialog systems. In IEEE Transactions on

Speech and Audio Processing vol. 8, no. 1, pp. 51-62,

January 2000.

Tschirk, W. (2001). Neural net speech recognizers. Voice

remote control devices for disabled people. In

e & i Artiﬁcial Intelligence 7/8/2001, pp. 367-370.

Springer.

Villarrubia, L. and Acero, A. (1993). Rejection techniques

for digit recognition in telecommunication applica-

tions. In Proc. IEEE Int. Conf. Acoustics, Speech, and

Signal Processing 1993, pp. 455-458.

ICEIS 2004 - HUMAN-COMPUTER INTERACTION
