TOWARDS CONCEPTUAL MEDIATION

A semantic architecture for dynamic integration of heterogeneous databases

Navas D., Ismael, Aldana M., José F.

Dpto. Lenguajes y Ciencias de la Computación, E.T.S. de Ingenería Informática, Universidad de Málaga, Spain

Keywords: Integrating Heterogeneous Data Sources, Dynamic Mediation, Semantics, Ontology, Web Services

Abstract: Mediators are usually developed as monolithic system

s which envelope the data source’s semantics as well

as its location. Furthermore, its architecture based on wrappers involves a high coupling degree among the

mediator’s components. This coupling does not allow sharing services with other organizations or the

dynamic integration of new data sources. Therefore, wrappers must be re-designed and manually added for

each mediation system. We propose an architecture for conceptual mediation in which the sources’ query

capabilities are published as web services. These services can be registered in one or more resource

directories (Semantic Directories), which are the core of this architecture because they provide the needed

flexibility and scalability for dynamic integration. Finally, we show an application in a bioinformatics

context to validate our approach.

This work has been supported by the Spanish MCyT Grant (TIC2002-04186-C04-04)

1 INTRODUCTION

In the last years, the Web has become a great

information repository that is manually accessed in

the majority of cases. The amount of information

and the complexity of a reasonable treatment to take

advantage of all this information have led to a lot of

research concerning database integration. The main

goal of these systems is to allow users to make

complex queries over heterogeneous databases, as if

it was a single one, using an integration schema.

Mediators offer user interfaces for querying the

system, based on the integration schema. These

mediators transform user queries into a set of sub-

queries that other software components (the

wrappers), which encapsulate data sources’

capabilities, will solve. Usually, sub-query results

are unstructured documents that are translated to

structured documents.

These mediation systems have evolved through

sev

eral improvements over traditional mediation

architecture (of systems such as Manifold (Levy,

1996) and TSIMMIS (Papakonstantinou, 1995)).

There have been a lot of improvements over the

traditional mediation context. Thus, the Carnot

project (Collet, 1991) introduces the use of

ontologies for modeling integration schemas. This

system makes use of a Cyc global ontology to

describe the information system. Taking advantage

of the information stored in a global dictionary, a

graph is generated for each SQL query. A semantic

component uses this graph and extends it with

relevant resource information, and then an optimal

query plan is generated for the extended graph. In

OBSERVER (Mena, 1996) the information loss in

database integration is studied. This system allows

users to establish an information loss maximum

value. The user can thus choose between search with

or without information loss. In (Sahuguet, 2000) and

(Ashish, 1997) automatic wrapper generation is

studied. These works are based on mediator feature

abstraction. Starting from this approach, we can

apply code reuse in wrapper design and

implementation processes, decreasing development

cost and time. The majority of proposed tools focus

their efforts on document transformation that gives

169

Navas D. I. and Aldana M. J. (2004).

TOWARDS CONCEPTUAL MEDIATION - A semantic architecture for dynamic integration of heterogeneous databases.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 169-176

DOI: 10.5220/0002606501690176

 SciTePress

Wrapper

Data Service

Semantic Directory

Planner

Domain Ontology

Mappings between

Schemas and

Domain Ontology

Available Resources

Query Plan

Query ij

Result

Wrapper

Data Service

Query ik

Results

Query Capabilities

Data Schema

Data Sources

Semantic Information

Semantic

Informatic

Semantic

Information

API

Query Capabilities

Data Schema

Data Sources

Application

User Interface

Query

Processor

Query Result

Browsing

Figure 1: A Conceptual Mediation Architecture

them structure. However a few solutions, such as

(Ashish, 1997), support full automatic wrapper

generation. In any case, they do not include

semantic information about the structured document

generated or information about query capabilities.

MIX (Baru, 1999) presents the use of XML for data

representation and for modeling query interfaces. In

this way, interoperability among mediators is

assured. Finally, (Arjona, 2002) proposes the use of

wrappers that return semantically annotated

information. This paper introduces the semantic

wrapper concept: “a semantic wrapper is a wrapper

that can manage web knowledge”. A Semantic

Wrapper can be seen as the natural extension of

current structural wrappers with the aim of adding

semantics to the extracted information. However,

this kind of wrapper is not used for exporting its

semantics as an available service, so it is difficult for

other mediators to reuse its knowledge. Mediators

must thus analyze query result semantics to extract

this knowledge.

Nonetheless, there are still several unsolved

problems in heterogeneous data integration,

including the following : (1) there is no reuse of

components among mediators; (2) mediators and

wrappers are strongly coupled; (3) query capabilities

and semantics are not published as part of the (web)

services; (4) software agents can not find wrappers,

as they are “hidden” behind of mediators.

Our proposal is an architecture for conceptual

mediation (see Section 2). This architecture includes

directories in which an ontology and semantic

information of resources are published. We propose

to improve the wrapper implementation process by

publishing them as web services, making their

semantics accessible. This evolution from traditional

wrappers to data services is motivated by several

factors:

– Data services can be reused by other mediators or

any other data accessing application.

– The semantics of data services is published on the

web so that the services are readily available to

other applications.

– Wrappers’ query capabilities can be enveloped

into one or more services.

This paper is organised as follows. Section 2

presents a novel architecture for conceptual

mediation, which makes use of web services to

allow dynamic integration. In section 3, we briefly

describe a biological use case to validate our

proposal. Finally, discussion and future works

sections conclude this paper.

2 AN ARCHITECTURE FOR

CONCEPTUAL MEDIATION

Our architecture seeks to make wrappers

independent entities and to eliminate their ties with

the mediator, thus increasing their reusability in

different applications. We emulate P2P hybrid

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

170

Data Services

Data

Web Site

getResources()

getCapabilities()

getSchema()

Form

Wrapper

Query (Q)

String

Data’s

Schemas

Data

Sources

Query

Capabilities

API

Figure 2: A Data Service Architecture

systems, which implement a directory with location

information of available resources. In these systems

the applications access directly to the resources by

means of connections point to point that the

directory has provided. Therefore, the flow of

information is greatly reduced w.r.t. the one

generated in the traditional client-server

architectures.

Our proposal for conceptual mediation arises

from two main considerations on the basic

architecture of mediation: (1) on the one hand the

isolation of wrappers, which are encapsulated as

web services (Data Services for us); and (2) on the

other, the added directory (Semantic Directory) with

information about these Data Services (See Figure

1). Although the basic configuration has been

developed with only one directory, nothing prevents

us from having distributed configurations and/or

from talking about more complex architectures with

several (maybe replicated) semantic directories (for

reasons of failure tolerance, availability or

scalability). This architecture allows wrappers to

contribute data, schemas of information and query

capabilities in a decentralized and easily extensible

manner.

A data service needs to be registered in one or

more semantic directories in order to be used by a

mediator or any other software agent. In other

words, data services, like P2P hybrid systems, must

know the location of semantic directories that are in

the same application domain. Finally, public

interfaces of data services and semantic directories

will allow applications that share the communication

protocol with it to take advantage of knowledge

about available directory resources. Next we present

the components of the proposed architecture as well

as their functionality.

2.1 Semantic Data Services

Semantic directories offer essential services for

obtaining the stored information and semantics

through several web methods, such as getting and/or

navigating over the domain ontology, the resources’

address, and the mappings. Besides, each directory

can offer a set of additional services. Figure 1 shows

a service for query processing which returns query

plans (Planner). This plan can be used and processed

by a specific type of application: the mediators.

These applications need to have a minimal query

processor, which must understand the plans, send

sub-queries to data resources and compose the

partial results. Note that the planners return sub-

queries in a language that data services can evaluate.

However, semantic directories could be increased

with other services in order to support other types of

applications/agents.

On the other hand, data services provide the

minimal elements for solving queries. We will

define this type of service and then describe how it

can solve access to a resource that has been included

in a query plan.

Definition 1: A wrapper is a function

W: (Q , R)

→

D. Given a query Q and a resource

R, a wrapper returns a structured document D

with the result of evaluating query Q in resource

Definition 2: A data service DS is a web service

that offers several web methods for obtaining

semantic and other information for querying a

wrapper (it is not the wrapper itself).

TOWARDS CONCEPTUAL MEDIATION: A semantic architecture for dynamic integration of heterogeneous databases

171

Planner

Domain

Ontology

Resources

API

Resources’

Schemas

getOntology()

getResources()

Schema(R)

getMappings()

getMappings(R)

QP=Query(Q)

Connect(R,S)

Disconnect(R)

Mappings Generator

Mappings

Figure 3: Internal Architecture of a Semantic Directory

The goal of this type of component is to allow

applications to access wrapper functionalities. In this

way, we have designed an extensible and adaptive

architecture in which we can define a data service as

“a service which offers wrapper query capabilities

using web protocols”.

The publication of these online web services

using UDDI (Universal Description Discovery

Integration) could allow other applications to

dynamically discover wrappers by means of an easy

interface. However, our data services have been

devised for publication in a specialized type of

directory: the semantic directory.

Figure 2 shows the internal architecture of a data

service (for a web resource) which accesses several

available data resources through web forms. This

type of service uses two step processing: (1) a first

step for accessing data sources using a wrapper,

which solves a query and returns an XML

document; and (2) the second one for exporting the

wrapper’s query capabilities and its semantics as a

web service. The web service’s semantics includes

information about query capabilities, data schemas

and data provenance. The latter is necessary, for

example in the context of bioinformatics where it is

important to know which is the information resource

that is being used (due to different data quality and

reliability). The data services need to describe their

source capabilities for translating user queries into

sub-queries that are understood by the concrete

source interface.

In a first approach we used the type of query

capabilities described in (Yemeni, 1999), and we

had defined the annotations for each attribute or

element. These query capabilities were expressive

enough to represent the capabilities of web

resources. However, we wanted to provide a solution

for heterogeneous data sources, because the

biological resources could be relational databases,

web resources or plain text. In our present approach

we use p-Datalog (Vassalos, 1997) to describe query

capabilities. It is a Datalog variant, which copes with

the need of a more powerful description language.

The p-Datalog source description language allows

defining capabilities for conjunctive queries. A

result of the cited paper is that p-Datalog can not

describe capabilities of certain powerful sources.

This type of service not only encapsulates a

wrapper’s query service, but also provides access to

the schema of the information they store. For this

purpose the getSchema(), getCapabilities() and

getSourcesInformation() methods are published as

an API, and they return respectively the data’s

schema, the query capabilities, and information

related to data sources used by the data service.

2.2 Semantic (Resource) Directories

Semantic directories are the core of this architecture,

because they provide essential services for

application domain users. Next we will define

several necessary terms for the semantic directory

definition and describe this type of resource

directory.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

172

Class

Gene

domain

Class

Organism

DataTypePropery

end

DataTypePropery

start

DataTypePropery

name

DataTypePropery

length

DataTypePropery

name

DataTypePropery

name

domain

Class

Protein

Class

GeneSequence

Class

ProteinSequence

DataTypePropery

end

DataTypePropery

start

domain

ObjectProperty

has_Proteins

ObjectProperty

has_GSequence

range

ObjectProperty

has_Genes

range

ObjectProperty

has_PSequence

range

domain

range

domain

Figure 4: Domain Ontology

Definition 3: A query plan QP is a tuple <Qs ,

Rs , Cp> where Qs is a vector of queries; Rs is a

vector that contains the resource address where

these queries must be evaluated and CP is a

composition plan that includes a method to

compose the result of evaluating each query Q in

the correct resource R.

Definition 4: A planner P is a function

P: Q Æ QP. Q is a query and QP is a query plan.

A semantic directory stores an ontology

(described with OWL), which must be generic for

the application domain (a Domain Ontology). This

ontology describes the core knowledge that is shared

by a set of applications or a user community. For our

purpose, the Domain Ontology can be seen as an

abstraction of the knowledge of the resource’s

schemas. Thus each schema could be considered as a

refinement of the domain ontology. The main

functionality of the directory is to provide access to

semantic information stored in it. However, it can

offer several value added services, for example for

returning an execution plan. This type of service

increases its functionality whenever similarity

between both models (the Domain Ontology and the

resources’ one) also increases. Information about

data services will be added to a semantic directory

when services register in it. So the data service

owner must use the connect method (offered by the

directory, see Figure 3) in order to publish his/her

service. This method saves information about the

service and calculates mappings between the

directory’s domain ontology and the service’s

schema. Semantic directories periodically ask

registered data services for updated information.

This allows maintaining schemas, query capabilities

and availability updated at all times and consistent

with data services. If there are changes, then the

directory recalculates mappings. Besides, the owner

of a service can disconnect it, making it unavailable

to be included in query plans.

Definition 5 : A Semantic Directory SD is a

server that stores a domain ontology DO,

mappings between data resource schemas (M)

and DO, and information about available

resources. Besides, it can offer a set of services,

such as a planner P. That is, we can define a

semantic directory as “a server that offers

information about available web resources (Data

Services), a domain ontology, mappings between

resource schemas and this ontology, and

provides services (for example, a query planner)

to application domain users”.

The storage of mappings between service

schemas and the domain ontology is very important,

due to their use in query planning. In the basic case,

applications send queries (Q

) in terms of the

ontology to the semantic directory, which returns a

query plan (QP) for this query. Each plan includes

links to services, a set of sub-queries for each

service (Q

... Q

) and a composition strategy. The

plans are based on mappings stored in the semantic

directory. Note that this architecture does not

implement a query processor, so the integration

applications can evaluate the QPs, releasing the

semantic directory of this task. Note that a mediator

is just one of the possible applications which has a

query processor to perform the query plan.

Besides, information stored in directories could

be used by other applications or agents that search

for information about: ontologies, data services

whose schema accomplish a condition, etc. In a

special context agents can implement their own

query plan generation algorithms. For this reason,

the directory’s API provides several methods to

retrieve information stored in it, which are:

getOntology(), getResources(), getSchema(R),

getMappings() and getMappings(R).

The getOntology() method returns an OWL

document, which includes the description of the do-

main ontology stored in the directory. A list of

TOWARDS CONCEPTUAL MEDIATION: A semantic architecture for dynamic integration of heterogeneous databases

173

code_qual(code_qual,code_feast)

type_qual(type_qual,code_feast)

qualifier(code_qual,code_feast)

q(code_feast, code_qual, type_qual, qualifier)

Qualifiers

code_feast

code_qual

type_qual

qualifier

Schema

ans(Cf,Cq,Tq,Q)

q(Cf,Cq,Tq,Q), ind

(Cf), ind

(Cf)

ind

(Cf)

code_qual($C,Cf)

ind

(Cf)

ind

(Cf)

type_qual($C,Cf)

ind

(Cf)

ind

(Cf)

qualifier($C,Cf)

ind

(Cf)

Indexes

Query Capabilities

Figure 5: Micado’s Query Capabilities. We have a qualifiers table in the Micado database. If we want to provide access to

query this using a data service, we need to define the table with the q predicate. In order to allow users to query with any

combination of the last three fields, we need to define three indexes. Finally, we describe the query capabilities needed.

available resources can be obtained with the getRe-

sources() method. For each resource R, we can ask

for its schema making use of the getSchema(R)

method. Finally, mappings between a schema or

overall schemas and the domain ontology are re-

turned respectively by the getMappings(R) and

getMappings() methods.

3 CONCEPTUAL MEDIATORS

The accumulated biological knowledge needed to

produce a more complete view of any biological

process (e.g. sequences, structures, gene-expression

data, pathways) is disseminated around the world in

the form of biological sequences and structure

databases, frequently as flat files, as well as image

and scheme-based libraries, web-based information,

particular and specific query systems, etc. Although

it is a common place statement that the volume of

data in biology is growing at exponential rates,

nonetheless, the key characteristic of biological data

is not so much its volume, but its diversity,

heterogeneity and dispersion (Rechemann, 2000).

BioBroker (Aldana, 2004) is an XML mediator

which supports biologist working in the field of

proteomics and genomics. This integrates

heterogeneous data sources: the nucleotide (EMBL)

and protein (SWISS-PROT) sequence information

(Bairoch, 2000), the worldwide repository of three-

dimensional structures of biological macromolecules

(PDB) (Berman, 2000) and the MICADO relational

database devoted to microbial genomes (Biaudet,

1997). These databases have been selected on the

basis of the difference in content, format, access

mechanism, and geographical location. We are

currently developing a mediator for integrating

biological resources, which will interact with a

semantic directory and several data services. This

will be the natural evolution of the previous XML

mediator (BioBroker). So next we present a sample

use of the proposed architecture for integrating gene

expression databases.

The semantic directory for BioBroker resources

includes an ontology which covers the concepts of

genomic and proteomic (see Figure 4). This figure

shows only some properties due to space limitations.

This simple ontology, which treats knowledge about

organisms, genes and proteins, is related with the

data sources through mappings between the data

schemas and the domain ontology.

We are developing the data services for each of

the BioBroker’s wrappers. In each one we must

define its semantics (query capabilities, data

provenance, etc.). Figure 5 shows the query

capabilities for the MICADO data service.

Let us suppose that we need to find the code_feat

of the genes of the Bacillus Subtilis that contains the

LKKQFVEAFG protein sequence (note that the field

qualifier has mapped to the field name of the gene

class). This query will be sent to the semantic

directory and it will return a query plan, which

includes a set of sub-queries, the data service in

which to evaluate each of them and a data

composition algorithm. In our example, this query

will produce the next sub-queries (which must be

evaluated in the SwissProt, EMBL and Micado

databases):

(Swiss-Prot and EMBL)

ans(Gn)

g(Gn,Sq),

sequence(‘*LKKQFVEAFG*’,Gn)

(Micado)

ans(Cf)

q(Cf,Cq,Tq,Q), qualifier(Gn,Cf)

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

174

Note that the second sub-query needs the Gene

Name (Gn) from the first one. Thus, the evaluation

must be sequential. Once results of first sub-query

are received, the system eliminates possible

inconsistencies and duplicates, and makes use of

these results into the second sub-query. Finally the

system translates results to ontology instances and

returns them to user application.

4 DISCUSSION

In this paper we describe an architecture for

conceptual mediation based-on a P2P and Web

Services architecture that presents advantages with

respect to traditional mediator system approaches.

The semantics introduced in the Semantic

Directories allows users to make more expressive

queries, viz. semantic queries that other mediators

cannot solve. They greatly increase the query

capabilities of this type of mediator. Besides, the

mappings between schemas and the domain

ontology of a semantic directory provide support for

solving these queries over the available resources.

The use of an architecture like P2P introduces a

high level of uncoupling between wrappers and

mediators or any other application, which could

involve wrappers. The directories supply an easy

way to integrate data sources and open new

directions in dynamic integration. Besides, our

proposal entails additional profits, such as the reuse

of wrapper components, access to data services for

other applications, use flexibility, etc. It provides

elements to obtain major interoperability among

integration systems that cooperate in the same

application domain or that belong to other domain

with which they have certain relationships.

In several domains in which there are no

“technological” users, such as biologists, dynamic

integration is a very important issue. In this context,

it is necessary to give users a simple environment for

integrating data information without the

modification of the mediator’s code or of the

integration schema. Using a domain ontology, users

can design queries starting from specific knowledge

that belongs to their field of research. However, the

proposed architecture requires that somebody

implement wrappers and publish them in the

semantic directories.

From our point of view, CBSD technology

(Szyperski, 1998) can help automatic generation of

wrappers, allowing us to configure data source

accesses as well as to choose appropriated

algorithms for each task. By applying this

technology users can generate wrappers just by

knowing the resources in which the information can

be found. Note that these resources are well known

by users, so they make use of them in their daily

work.

The case for use in biology is evidence of the

suitability of this kind of architecture for the

bioinformatics domain. In particular, the usefulness

of a mediator system is demonstrated by a diverse

set of applications aimed at combining expression

data with genomic, sequence-based and structural

information, so as to provide a general, transparent

and powerful solution that goes beyond traditional

gene expression data clustering.

Our architecture opens new ways to address

interesting issues, such as query decomposition

algorithms, result integration, data service location,

searches in data directories, etc.

5 FUTURE WORK

As future works, we propose several lines of

mediator development. Increasing the automation

level in wrapper creation and adding to this process

data service generation previously described, which

will reduce even more their cost of development.

Another interesting line stems from studying the

possibility of giving more semantics to these data

services, taking into account service quality,

relations with other domain ontologies, etc. Using

this additional information, we could generate

alternative query execution plans, allowing

applications to choose the one which is more

suitable or generating them based on certain features

(using local resources for the application location).

Besides, the scalability of this architecture will

provide the possibility of integrating not only data

services but also semantic directories, making

possible a full semantic integration of resources and

the interoperability between applications. Thus, we

will provide elements to achieve interoperability

between semantic integration systems that cooperate

in the same application domain or have certain

relations (Semantic Fields). Furthermore, we will

introduce a solution to integrate semantic fields and

obtain better query capabilities.

We plan to study automatic mapping between

schemas and ontologies taking into account a

previous experience (Madhavan, 2002). It can be

applied to establish correspondences between

retrieved document schemas and directory

ontologies in those new systems developed using our

architecture. Finally, we are interested in

establishing a semantic model to define the data

service’s query capabilities, which improves query

planning by adding inferences about query

TOWARDS CONCEPTUAL MEDIATION: A semantic architecture for dynamic integration of heterogeneous databases

175

capabilities to the reasoning between schemas and

the domain ontology.

REFERENCES

Aldana, J.F., Roldán, M., Navas, I., Pérez, A.J. and

Trelles, O., 2004. Integrating Biological Data Sources

and Data Analysis Tools through Mediators. ACM

Symposium on Applied Computing. Nicosia, Cyprus.

Arjona, J.L., Corchuelo, R.. Ruiz-Cortés, A. and Toro, M.,

2002. Extraction of Semantically-Meaningful

Information from the Web. Second International

Conference on Adaptive Hypermedia and Adaptive

Web Based Systems. Springer–Verlag. Málaga, Spain.

pp. 24–35.

Ashish, N. and Knoblock, C., 1997. Semi-automatic

Wrapper Generation for Internet Information Sources.

In conference on Cooperative Information Systems.

Bairoch, A. and Apweiler R., 2000. The SWISS-PROT

protein sequence database and its supplement

TrEMBL in 2000. In Nucleic Acids Res 28.

Baru, C., Gupta, A., Ludäscher, B., Marciano, R.,

Papakonstantinou, Y., Velikhov, P. and Chu, V., 1999.

XML-based Information Mediation with MIX. In

Demostrations, ACM/SIGMOD, pages 597-599.

Berman, H. M., Westbrook, J., Feng, Z., Gilliland, G.,

Bhat, T.N., Weissig, H., Shindyalov, I.N. and Bourne,

P.E., 2000. The Protein Data Bank. Nucleic Acids

Research, Vol. 28, No. 1 235-242.

Biaudet V, Samson F and Bessieres P., 1997. Micado a

network-oriented database for microbial genomes. In

Bioinformatics, Vol 13, 431-438. Oxford University

Press.

Collet, C., Huhns, M. and Shem, W., 1991. Resource

Integration Using a Large Knowledge Base in Carnot.

IEEE Computer, pages 55–62.

Levy, A., Rajaraman, A. and Ordille, J., 1996. Querying

Heterogeneous Information Sources Using Source

Descriptions. In Proc. VLDB, pages 251-262, Mumbai

(Bombay), India.

Papakonstantinou, Y., Garcia-Molina, H. and Widom, J.,

1995. Object Exchange Across Heterogeneous

Information Sources. In Proc. ICDE, pages 251-260,

Taipei, Taiwan, March.

Madhavan, J., Bernstein, P., Domingos, P. and Halevy A.,

2002. Representing and Reasoning about Mappings

Between Domain Models. In proceedings of the AAAI

Eighteenth National Conference on Artificial

Intelligence.

Mena, E., Kashyap, V., Sheth, A. and Illarramendi, A.,

1996. OBSERVER: An Approach for Query

Processing in Global Information Systems based on

Interoperation across Pre-existing Ontologies. In

conference on Cooperative Information Systems.

Sahuguet, A. and Azavant, F., 2000. Building Intelligent

Web Applications Using Lightweight Wrappers. In

Data Knowledge Engineering.

Szyperski, C., 1998. Component Software. Beyond

Object-Oriented Programming. Addison-Wesley.

Vassalos, V. and Papakonstantinou, Y., 1997. Describing

and Using Query Capabilities of Heterogeneous

Sources. In VLDB’97, 23rd International Conference

on Very Large Data Bases.

Web Services. XML-RPC,SOAP, sobre PHP, Perl, y otros

conceptos. http://web-services.bankhacker.com/

Yerneni, R., Li, C., Garcia-Molina, H. and Ullman, J.D.,

1999. Computing capabilities of mediators. In

SIGMOD, pages 443-454.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

176
