BALANCING STAKEHOLDER’S PREFERENCES ON

MEASURING COTS COMPONENT FUNCTIONAL SUITABILITY

Alejandra Cechich

Departamento de Ciencias de la Computación, Universidad del Comahue, Neuquén, Argentina

Mario Piattini

Escuela Superior de Informática, Universidad de Castilla-La Mancha, Ciudad Real, España

Keywords: Component-Based System Assessment, COTS components, Software Quality.

Abstract: COTS (Commercial Off-The-Shelf) components can be in

corporated into other systems to help software

developers to produce a new system, so that both artefacts – components and the system – form a single

functional entity. In that way, developing software becomes a matter of balancing required and offered

functionality between the parties. But required functionality is highly dependent on component’s users, i.e.

stakeholders of a COTS component selection process. Inputs to this process include discussions with

composers, reuse architects, business process coordinators, and so forth. In this paper, we present an

approach for balancing stakeholder’s preferences, which can be used in the process of measuring functional

suitability of COTS candidates. We describe and illustrate the use of our proposal to weight requirements

of components and determine suitable COTS candidates for given software.

1 INTRODUCTION

The last decade marked the first real attempt to turn

software development into engineering through the

concepts of component-based software engineering

(CBSE) and commercial Off-The-Shelf (COTS)

components. It is clear that CBSE affects software

quality in several ways, ranging from introducing

new methods for selecting COTS components to

defining a wide scope of testing principles and

measurements (Cechich et al, 2003).

The idea is to create high-quality parts and put

together. However, joining high quality parts

not necessarily produces a high-quality system.

At the same time, defining quality features able to

be m

easure

d might mitigate the impact of selecting

and integrating COTS components. Although

measures are not straightforward to take, it might be

possible to focus on different aspects of a

component, which indirectly – or perhaps directly in

some cases – provide metrics on the resulting

composition. In that way, metrics might be used to

improve the process of selecting and integrating

components by reducing risks on decision-making

tasks (Sedigh-Ali et al., 2001).

Components are plugged into a software

archi

ecture that connects participating components

and enforces interaction rules. The architectural

options are high-level descriptions of components

and their expected interactions. For instance, the

model in Alexander and Blackburn (1999), supposes

that there is an architectural definition of a system,

whose behaviour has been depicted by scenarios or

using an architecture description language (ADL).

The model explores the evaluation of components

using a specification-based testing strategy, and

proposes a semantics distance measure that might be

used as the basis for selecting a component from a

set of candidates.

Our proposal (Cechich and Piattini, 2004), has

ted this model as a basement for quality

measurement. We express the semantics distance in

terms of functional suitability measures, which

provide a better identification of the different COTS

functionalities. To do so, a system can be extended

or instantiated through the use of some component

type. Due several instantiations might occur, an

115

Cechich A. and Piattini M. (2004).

BALANCING STAKEHOLDER’S PREFERENCES ON MEASURING COTS COMPONENT FUNCTIONAL SUITABILITY.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 115-122

DOI: 10.5220/0002607201150122

 SciTePress

assumption is made about what characteristics the

actual components must possess from the

architecture’s perspective. Thus, the specification of

the architecture A (SA) defines a specification S

for

the abstract component type C (i.e. SA ⇒ S

). Any

component K

, that is a concrete instance of C, must

conform to the interface and behaviour specified by

We should remark the importance of determining

behavioural incompatibilities through the use of

scenario specifications, even thought the scenario S

is not explicitly included into our measure

definitions. This is due to the fact that we consider

the definition of metrics as a process included into a

broader measurement process, which defines some

activities for setting the measurement context – such

as defining scenario specifications or identifying

stakeholders (Cechich and Piattini, 2003).

Determining the needed quality is difficult when

different stakeholders have different needs. One

might be tempted to state that the stakeholder

requiring the highest component quality should

determine the overall level of quality to the CBS.

But what if that component use is rather minor and

unimportant to the CBS, whereas the major

component use does not require anywhere near such

a level of quality? Thus it is necessary to balance

conflicting requirements for CBS quality.

Weighting requirements for COTS component

selection can be problematic. Sometimes these

weights are inconsistent and lead to confusion about

which are the most essential customer requirements

(Maiden and Ncube, 1998). Using more

sophisticated methods, such as the AHP method

(Saaty, 1990), has received some interest in the

application of well-known COTS component

selection procedures. However, simpler decision-

making techniques can also be appropriate to resolve

disagreements promoting a cost-effective use. In any

case, clearly defining a way of balancing preferences

on requirements is essential to the selection process.

On the other hand, the requirements elicitation

techniques have widely used a family of goal-

oriented requirements analysis (GORA) methods –

I* (I* homepage; Mylopoulos et al., 1999), KAOS

(KAOS homepage; Dardenne et al., 1993), and GRL

(GRL homepage) – as an approach to refine and

decomposing the needs of customers into more

concrete goals that should be achieved.

In this paper, we describe a proposal to balance

stakeholder’s preferences during a COTS component

selection process. Our proposal extends a version of

a Goal-Oriented Requirements Analysis Method

called AGORA (Kaiya et al., 2002) by considering

additional features of COTS components. The

proposal might be combined with other techniques

for weighting preferences such as the Goals-Skills-

Preferences Framework (Hui et al., 2003) and the

AHP method. Then, the balanced requirements are

included into the computation of a compact suite of

measures on functional suitability of the COTS

component candidates.

In Section 2 of the paper we briefly introduce our

measurement approach for COTS component’s

functional suitability. Section 3 then presents the

notion of AGORA graphs as it might be used in

COTS component selection to balance stakeholder’s

preferences. Finally, section 4 introduces our

weighting procedure to functional suitability based

on measures derived from the graph. We conclude

with an overview of research directions and future

extensions.

2 MEASUREMENT OF COTS

FUNCTIONAL SUITABILITY

In the previous section, we have emphasized the fact

that the output from the system should satisfy the

user’s requirements by using the functionality

supplied by at least one COTS component. They are

plugged into a software architecture that connects

participating components and enforces interaction

rules.

Given a specification S

for an abstract

component type C, a candidate component K to be a

concrete instance of C must conform to the interface

and behaviour specified by S

Although the process of selecting a component K

consists of evaluating interface and semantic

mappings, in our work only semantic mappings are

addressed. Mappings in S

, which represent the

different required functionalities, are established

between input and output domains. We focus on

incompatibilities derived from functional differences

between the specification in terms of mappings of a

component K

) and the specification in terms of

mappings of S

Let’s illustrate the measurement procedure by

using an E-payment system as an example. We

suppose the existence of some scenarios describing

the two main stages of the system – authorisation

and capture. Authorisation is the process of

checking the customer’s credit card. If the request is

accepted, the customer’s card limit is reduced

temporarily by the amount of the transaction.

Capture is when the card is actually debited.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

116

The scenarios will provide an abstract

specification of the mappings of S

that might be

composed of:

- Input domain: (AID) Auth_IData{#Card,

Cardholder_Name, Exp-Date}; (CID)

Capture_Idata{Bank_Acc, Amount}.

- Output domain: (AOD) Auth_Odata{ok-

Auth}; (COD) Capture_Odata{ok_capture,

DB_update}.

- Mapping: {AID → AOD};{CID → COD}

Suppose we pre-select two components to be

evaluated, namely K

and K

respectively. A typical

situation for inconsistency in the functional

mappings between S

, S

and S

is illustrated in

Figure 1, where dashed lines indicate (required)

mappings with respect to S

, and the solid lines are

(offered) mappings with respect to S

(grey) and S

(black). Note that the input domain of the

component K

does not include all the values that the

specification S

requires, i.e. the capture

functionality is not provided. Besides, the input

domain of the component K

includes more values

than the required by S

, although the mapping

satisfies the required functionality. We should also

note that there is another functionality provided by

, i.e. {Taxes → Statistics}, which might inject

harmful effects to the final composition.

Figure 1: Functional mappings of S

and S

Our measures of functional suitability have been

classified into two different groups: component-level

measures and solution-level measures. The first

group of measures aims at detecting

incompatibilities on a particular component K,

which is a candidate to be analysed. However, it

could be the case that we need to incorporate more

than one component to satisfy the functionality

required by the abstract specification S

. In this case,

the second group of measures evaluates the

functional suitability of all components that

constitute the candidate solution.

To clarify the use of the specification S

during

the measurement procedure, we briefly introduce

some metrics. At the component-level, we have

defined the following measures (Cechich and

Piattini, 2004):

• “Compatible Functionality” (CF

) as the

amount of functional mappings provided by S

and required by S

in the scenario S.

• “Missed Functionality” (MF

) as the amount of

functional mappings required by S

in the

scenario S and not provided by S

• “Added Functionality” (AF

) as the amount of

functional mappings not required by S

in the

scenario S and provided by S

• “Component Contribution”(CC

) as the

percentage in which a component contributes to

get the functionality required by S

in the

scenario S.

Now, let’s calculate the functional suitability

measures on K

for the E-payment example.

Considering the functional mappings provided by K

({AID → AOD; CID → COD; Taxes →

Statistics}), the component-level measure results are

as follows:

) = 2; MF

) = 0, AF

) = 1;

) = 1.

•AID

•CID

dom S

•Taxes

dom S

•AOD

•COD

ran S

•Statistics

ran S

(i)S

(i)

These values indicate that the component K

is a

candidate to be accepted for more evaluation; i.e. the

component is completely functionally suitable. But

there is one added function that could inject harmful

side effects into the final composition. Besides, there

are another types of analysis the component should

be exposed before being eligible as a solution – such

as analysis of non-functional properties (Chung et

al., 2000), analysis of vendor viability (Ballurio et

al., 2002), and so forth.

Adaptation required by the components should

also be quantified. For example, measurement might

be defined at three levels: (1) size measures will be

basically in terms of the amount of adaptability

needed by a component-based solution; (2)

complexity of adaptation will be measured in terms

of interactions with target components that are

identified to determine all potential mismatches; and

finally, (3) architectural adaptability might define

calculations for measures of changes that affect

system’s stability (Cechich and Piattini, 2003) in

terms of architectural adaptability.

BALANCING STAKEHOLDER’S PREFERENCES ON MEASURING COTS COMPONENT FUNCTIONAL

SUITABILITY

117

3 STAKEHOLDER’S

PREFERENCES ON COTS

FUNCTIONALITY

Stakeholders might try to find the best component

(or set of components) decomposing and weighting

the goals of the abstract specification S

, as it was

presented in the previous section. For example, a

reuse architect may be interested in identifying and

acquiring components promoting the value of reuse

and ensuring consistency of design across projects; a

certifier may be interested in setting component

specification standards and ensuring compliance and

consistency of components across different teams; or

a business process coordinator may be interested in

demonstrating the value of components with respect

to business processes (Allen and Frost, 2001).

Hence, functional requirements are affected by

different views that should be conciliated.

Generally speaking, goals can be decomposed to

calculate a preference value for each stakeholder.

The extended version of a Goal-Oriented

Requirements Analysis Method called AGORA,

(Kaiya et al., 2002), is a top-down approach for

refining and decomposing the needs of customers

into more concrete goals that should be achieved for

satisfying the customer’s needs.

An AGORA goal graph, is an attributed version

of AND-OR goal graphs, whose parts can be

described as follows:

• Attribute values are attached to nodes and

edges, in addition to structural characteristics of

the graph. There are two types of attributes:

o A preference matrix is attached to a

node, i.e. a goal, and stands for the

degree of preference or satisfiability of

the goal for each stakeholder; and

o A contribution value is attached to an

edge to express the degree of the

contribution of the goal to the

achievement of its connected parent

goal.

• Rationale can be attached to an attribute as well

as a node and an edge. It represents

decomposition decisions associated to goal

refinement and attribute value definition.

The procedure to construct an AGORA goal

graph involves:

• Establishing initial goals as customers’ needs.

• Decomposing and refining goals into sub-goals.

• Choosing and adopting the goals from the

alternatives of decomposed goals.

• Detecting and resolving conflicts on goals.

The stakeholders attach the value subjectively.

However, they can use some systematic techniques,

such as the AHP method (Saaty, 1990), to assign

more objective values.

The contribution values and preference matrices

help to choose suitable sub-goals. Basically, when a

sub-goal is connected to an edge having a high

contribution, it can be a candidate to be chosen as a

successor of his parent goal

Since a preference matrix includes the

preference degree for each stakeholder, we can

identify the conflicts among them by analysing the

variance on the diagonal elements of the matrix.

In the following subsection, we introduce an

extension of the AGORA graph to include some

necessary elements when evaluating COTS

components. Our approach explicitly considers some

characteristics of COTS components to balance

stakeholder’s preferences on functional goals.

3.1 AGORA Graphs in COTS

Selection

Initial goals are typically considered as the customer

needs and assigned to nodes of the graph. But when

incorporating COTS components, goals should be

balanced against COTS services. For example, using

the main concepts of goal-oriented requirements

engineering, the goal acquisition and specification

process (Alves, 2003; Alves and Finkelnstein, 2002)

includes the necessity of identify goals that help to

distinguish between products (called core goals)

from those that are provided by most available

products (called peripheral goals). Then, our

proposal extends the AGORA graph to include a

first categorisation of goals into core and peripheral.

A second categorisation is due to the traditional

separation of requirements into functional and non-

functional properties. This classification remains

relevant due to the different treatments given to the

properties when defining quality attributes and

measurements. In this work, only functional

suitability is considered. Then, we limit the scope of

this paper to analysing functional properties.

Initial goals, as considered in AGORA graphs, are

the needs of the customers that will be refined and

decomposed into sub-goals one after another. It is

possible to have more than one sub-goal of a parent

goal, and it is also possible to use two types of

decomposition corresponding to the logical

combination of the sub-goals – one is AND-

decomposition and the other is OR-decomposition.

Therefore, with the functional goals of the

component specified by mappings in S

, the next

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

118

step is to refine the goals considering the

perspectives of different stakeholders – reuse

architect, certifier, business process coordinator, etc.

Then, the computation of stakeholder’s preference

values for the refined goals will allow us to add

preferences to mappings of S

, distinguishing

between core and peripheral functional goals.

In our context of component-based systems, an

AGORA graph describes the abstract specification

of a required component (S

) according to the

scenario S. Figure 2 shows a snapshot of a possible

AGORA graph for our E-payment case.

There are two types of conflicts on goals; one is

the conflict between goals and the other one is the

conflict on a goal between stakeholders. The first

type of conflicts appears in Figure 2 between the

goals “Prevent unauthorised debits” and “No

authorisation”, whose edge has a negative

contribution value. The second type appears in the

figure on the goal “Input AID data”. The diagonal

elements of the preference matrix show that the

reuse architect gave the preference value 8 by

himself, while the business process coordinator’s

preference is –5 given by himself (Figure 3 shows

the preference matrix where the stakeholders are

identified).

When we find a large variance on the diagonal

elements of the preference matrix, there is a

possibility of conflict among the stakeholders for the

goal. In this case, the relevant stakeholders would be

forced to negotiate for the conflict resolution of the

goal. Negotiation can be supported by methods such

as the WinWin (Boehm et al., 1995).

In Figure 2, final goals are identified to achieve

the initial goals, i.e. the sub-goals “Input AID data”,

“Issue AOD data”, “Register formally with the

bank”, and “Input the user identification by Web

page by user”.

It seems that information to apply a traditional

negotiation process is enough. But, we have already

remarked the importance of distinguishing between

core and peripheral goals when selecting COTS

components. This characterisation would lead to

dealing with a third type of conflicts on goals:

conflicts between the abstract specification of a

component and its possible instantiations. These

conflicts should be resolved when the COTS

component selection actually take place. Then, it is

important to add some extra information on the

graph, so the negotiation will be possible.

Then, the AGORA graph in Figure 2 has been

extended adding the labels <core>/<peripheral> to

facilitate the future negotiation. For example,

suppose that we evaluate the components K

and K

introduced in section 2. We easily note that

component K

should be withdrawn from analysis

because it does not offer one core functionality. We

should search for other components or combination

of components, such as K

, to instantiate the three

core goals of the graph. On the other hand, there is a

peripheral goal (“Input the user identification by

Web page by user”) on the graph, which would be

desirable to have. However, its categorisation as

peripheral makes this functionality a candidate to be

discharged (or to be added by an adapter), when

there are no COTS candidates offering it.

For international

credit cards

For customers

having CCards

E-payment

authorisation

Anyone who

have CCard

Easy to

authorise

Prevent

unauthorised

debits

+10

Everyone

Authorise

immediately

Authorisation

Authorise by

password

Input the user

identification via

Web page by user

By password

automatically

and

immediately

Input AID

data

Issue AOD

data

formally with

the bank

-10

+10

-7

8 7 0

8 10 –3

5 10 -5

-2 10 0

0 10 –5

0 10 -8

-3 7 0

0 10 –3

0 10 -5

Easy classification

into the reuse library

Capture is highly

dependent on DB

platforms

<Core>

Figure 2: A snapshot of the AGORA graph for the E-

payment case

8 7 0

8 10 –3

5 10 -5

RA CE BC

RA: Reuse Architect

CE: Certifier

BC: Business Process

Coordinator

Figure 3: An example of a preference matrix

BALANCING STAKEHOLDER’S PREFERENCES ON MEASURING COTS COMPONENT FUNCTIONAL

SUITABILITY

119

4 MEASURING DESIRABILITY

AND MODIFIABILITY OF

GOALS

Besides the classification of goals as core and

peripheral, the attributes desirability (level of

importance for a goal to be met), and modifiability

(level in which a goal can be modified) are proposed

as attributes for goal description when selecting

COTS components (Alves and Filkenstein, 2002).

By using an AGORA graph, we can estimate the

quality of several properties of the adopted goals.

Particularly, correctness is assumed as a quality

factor that represents how many goals in a

specification meet stakeholder’s needs. Correctness

in AGORA is strongly related to contribution values

on the path of the adopted goal as well as on its

stakeholder’s preference value. Particularly, the

average stakeholder’s preference value of the

adopted final goals (Cup) is defined by Kaiya et al.

(2002) as:

Cup = AVE (∪

∈

FinalGoal, s

∈

Stakeholder, m

∈

Preference

s,customer

| has(f,m)})

where m

s,customer

means a stakeholder’s

preference value evaluated by the stakeholder s in

the preference matrix m. The results of the

calculation for all the core goals of Figure 2 are as

follows:

Cup(RA) = ((8 + 8 + 5) + (-2 + 0 + 0) + (-3 + 0 +

0)) / (3 + 3 + 3) / 10 = 0.18

Cup(CE) = ((7 + 10 + 10) + (10 +10 + 10) + (7 +

10 + 10)) / (3 + 3 + 3) / 10 = 0.93

Cup(BC) = ((0 – 3 – 5 ) + (0 – 5 – 8 ) + (0 – 3 –

5)) / (3 + 3 + 3) / 10 = – 0.32

Cup = (0.18 + 0.93 – 0.32) / 3 = 0.26

In COTS component selection, this measure

might indicate the degree of agreement on

stakeholder’s preferences, i.e. on the desirability of

the core goals of the abstract specification S

Lower results of Cup, such as 26% in our case, show

a need of further discussion on the required

functionality of the component C; i.e. causes of

disagreement should be detected. For example,

stakeholders have different goals, even their

perceptions of reality vary significantly. Then,

scenarios may drive the agreement process and

establish partial consistency among existing systems

– all systems involved in using the COTS

component.

On the other hand, modifiability is about the

degree in which committed goals can be changed

when selecting COTS components. Let’s briefly

clarify the point: suppose there is a strong agreement

on a set of goals (Cup = 80%), however the search

of COTS candidates offering the functionalities

shows that there are no candidates available. In this

case, evaluators should have agreed on the degree in

which the goals (even categorised as core) can be

modified. Then, the modifiability of the goals will

help to decide on acquiring COTS components with

less functionality than required, adding the

functionality by means of an adapter (such as a

wrapper), or building the missed functionality from

scratch.

In (Kaiya et al, 2002), the quality metrics for

modifiability include how an AND-OR graph is

closed to a tree structure. When there are many

incoming edges to a goal, the goal contributes to an

achievement of many goals. In consequence, these

many goals should be under consideration in case of

changing the goal. The quality metric is defined as

follows:

Tre =

#{g ∈ RefinedGoals | #{e|incoming(g,e)=1}}

#RefinedGoals

RefinedGoals = Goals – Initial Goals

Calculations for Figure 2 show that there are 3

initial goals and 13 refined goals, from which only 9

have one incoming edge. Then, the result of the

calculation of Tre (modifiability) for Figure 2 is 9 /

13 = 0.69. In other words, the figure shows four

goals whose incoming edges are more than one (13 –

4 = 9), out of 13 refined goals.

We should note that other quality metrics such as

unambiguity, completeness, and consistency might

be calculated on AGORA graphs. However,

desirability and modifiability are the main properties

when we apply the analysis on abstract

specifications of COTS components aiming at being

included into a selection procedure.

4.1 Weighting the functional

requirements of Sc

Functional mappings of S

, as introduced in section

2, are associated to one or more refined goals of the

graph. By doing so, an agreement among

stakeholders might be achieved by calculating the

desirability of each group of refined goals

representing a particular mapping. For the example

in Figure 2, calculations should be split into three

groups: one containing the core goals referring to the

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

120

authorisation functionality (two core refined goals),

another containing the capture functionality (one

core refined goal), and another containing the

peripheral goal. Then, desirability of the three

groups should be calculated and decisions should be

made based on the following cases, where

“agreement-threshold” is a suggested value between

0.6 and 0.7 and “core/peripheral” is the type of

refined goal:

• Case 1: desirability(refined goal/s) < agreement-

threshold ∧ core ⇒ Try other scenarios to get

agreement

• Case 2: desirability(refined goal/s) < agreement-

threshold ∧ peripheral ⇒ decision to discharge

• Case 3: desirability(refined goal/s) ≥ agreement-

threshold ∧ peripheral ⇒ decision to retain

• Case 4: desirability(refined goal/s) ≥ agreement-

threshold ∧ core ⇒ keep for the selection

process

Modifiability is calculated to be used during the

selection procedure, whether decisions on buying or

developing should be made.

Let’s consider again the E-payment example. The

functional suitability measures introduced in section

2 were calculated for two COTS candidates – K

and

. Before starting the selection procedure, an

abstract specification of the component (S

) was

defined as a reference to be used when comparing

candidates, and the component K

was indicated as

the most functionality suitable. However, the

agreement on the functionality required by the

abstract specification S

is not enough (Cup indicator

is around 26%). It would indicate that we should

have tried other scenarios to get agreement (case 1).

Hence, the desirability measure might have been

used to avoid further investment in searching

candidates while required functionality is still not

clear, i.e. we should not proceed comparing the

functionality offered by candidates until desirability

of all core requirements has reached the agreement-

threshold.

Of course, actually classifying the requirements

as “core” or “peripheral” is another different

concern. We assume that the classification is valid

and it remains stable during the selection process.

However, 69% of modifiability would indicate that

there is a good chance of negotiating (and changing)

the requirements when balancing between offered

services of candidates. But it also could indicate that

the classification as “core” should be reviewed.

Having higher values on modifiability (around 90%)

on a core requirement would indicate that we could

potentially resign most of our expectations on this

requirement letting offered services prevail. For

example, we could keep some of the alternative

goals resigning others whether COTS candidates are

hard to find or adapt.

Summing up, desirability might reduce search

and selection efforts by detecting functionality on

which there is no enough agreement; and

modifiability might help to predict a space of

negotiation and change when constraints from actual

candidates are applied.

CONCLUSIONS

Assessing component-based systems, especially

systems with COTS components, differs in several

ways from the usual situation. Now, stakeholders

must be willing to resign some of their requirements

trying to adjust their expectations to what actual

candidates offer in a marketplace. In this context,

balancing requirements among offerings is an

outstanding concern when selecting COTS

components. In this paper, we have introduced a

proposal for calculating a preference value for each

functional requirement, and we have weighted the

desirability and modifiability of core and peripheral

goals. These calculations are some of the inputs

required by a broader measurement procedure,

which would lead to a more objective evaluation of

COTS candidates.

However, an aspect that needs further discussion

is the possibility of establishing a set of main

stakeholders or roles on a selection process.

Furthermore, when an organisation implements the

approach, it needs to identify which specific roles

and priorities it should address and what does or

does not work for that organisation. Preference

matrices should be limited to these specific roles, so

calculations are kept between practical and

meaningful boundaries.

Another aspect that needs more attention is the

diverse possibilities of documenting the

specification S

. We have chosen scenarios because

of their wide use on evaluating architectures,

however other representations might be more

suitable depending on specific constraints of the

system.

Finally, the classification of requirements as core

or peripheral needs to be derived from a previous

analysis on factors that traditionally influence

software requirements elicitation processes.

BALANCING STAKEHOLDER’S PREFERENCES ON MEASURING COTS COMPONENT FUNCTIONAL

SUITABILITY

121

ACKNOWLEDGMENTS

This work was partially supported by the CyTED (Ciencia

y Tecnología para el Desarrollo) project VII-J-RITOS2, by

the UNComa project 04/E048, and by the MAS project

supported by the Dirección General de Investigación of

the Ministerio de Ciencia y Tecnología (TIC 2003-02737-

C02-02).

REFERENCES

Alexander R. and Blackburn M., 1999. Component

Assessment Using Specification-Based Analysis and

Testing. Technical Report SPC-98095-CMC,

Software Productivity Consortium.

Allen P. and Frost S., 2001. Planning Team Roles for

CBD. In Component-Based Software Engineering -

Putting the Pieces Together, Addison-Wesley. Edited

by G. Heineman and W. Council.

Alves C., 2003. COTS-Based Requirements Engineering.

In Component-Based Software Quality: Methods and

Techniques, Springer-Verlag LNCS 2693.

Alves C. and Filkenstein A., 2002. Challenges in COTS-

Decision Making: A Goal-Driven Requirements

Engineering Perspective. In Proceedings of the

Fourteenth International Conference on Software

Engineering and Knowledge Engineering, SEKE’02.

Ballurio K., Scalzo B., and Rose L, 2002. Risk Reduction

in COTS Software Selection with BASIS. In

Proceedings of the First International Conference on

COTS-Based Software Systems, ICCBSS 2002,

Springer-Verlag LNCS 2255 , pp. 31-43.

Boehm B., Bose P., Horowitz E., and Lee M., 1995.

Software Requirements Negotiation Aids: A Theory-

W Based Spiral Approach. In Proceedings of the 17

International Conference on Software Engineering,

pp. 243-253.

Cechich A., Piattini M., and Vallecillo A., (eds.) 2003.

Component-Based Software Quality: Methods and

Techniques, Springer-Verlag LNCS 2693.

Cechich A. and Piattini M., 2003. Defining Stability for

Component Integration Assessment. In Proceedings of

the 5th International Conference on Enterprise

Information Systems, ICEIS 2003, pp. 251-256.

Cechich A. and Piattini M., 2004. On the Measurement of

COTS Functional Suitability. In Proceedings of the

International Conference on COTS-based Software

Systems, ICCBSS 2004, Springer-Verlag LNCS.

Chung L., Nixon B., Yu E., and Mylopoulos J., 2000.

Non-Functional Requirements in Software

Engineering. Kluwer Academic Publisher.

Dardenne A., van Lamsweerde A., and Fickas S, 1993.

Goal-directed Requirements Acquisition. Science of

Computer Programming, Vol. 20, pp. 3-50.

GRL homepage, http://www.cs.toronto.edu/k-m/GRL/

Hui B., Lisakos S., and Mylopoulos J., 2003.

Requirements Analysis for Customizable Software: A

Goals-Skills-Preferences Framework, In Proceedings

of the 11

IEEE International Requirements

Engineering Conference, pp. 117-126.

I* homepage, http://www.cs.toronto.edu/km/istar

Kaiya H., Horai H., and Saeki M., 2002. AGORA:

Attributed Goal-Oriented Requirements Analysis

Method. In Proceedings of the IEEE International

Conference on Requirements Engineering, pp. 13-22.

KAOS homepage, http://www.info.ucl.ac.be/research/

projects/AVL/ReqEng.html

Maiden N. and Ncube C., 1998. Acquiring COTS

Software Selection Requirements. In IEEE Software,

Vol. 15(2), pp. 46-56.

Mylopoulos J., Chung L., and Yu E., 1999. From Object-

Oriented to Goal-Requirements Analysis,

Communications of the ACM, 42(1), pp. 31-37.

Saaty T.L., 1990. The Analytic Hierarchy Process.

McGraw-Hill.

Sedigh-Ali S., Ghafoor A., and Paul R., 2001. Software

Engineering Metrics for COTS-Based Systems. IEEE

Computer Magazine, pp. 44–50.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

122
