A XML-BASED BOOTSTRAPPING METHOD FOR PATTERN

ACQUISITION

Xingjie Zeng, Fang Li, Dongmo Zhang

Department of Computer Science, Shanghai Jiaotong University, Shanghai China, 200030

Athena I.Vakali

Department of Informatics Aristotle University of Thessaloniki Greece

eywords: XML based applications, Bootstrapping method, Pattern Acquisition, Information Extraction

Abstract: Extensible Markup Language (XML) has been widely used as a middleware because of its flexibility. Fixed

domain is one of the bottlenecks of Information Extraction (IE) technologies. In this paper we present a

XML-based domain-adaptable bootstrapping method of pattern acquisition, which focuses on minimizing

the cost of domain migration. The approach starts from a seed corpus with some seed patterns; extends the

corpus based on the seed corpus through the Internet and acquires the new patterns from extended corpus.

Positive and negative examples classified from training corpus are used to evaluate the patterns acquired.

The result shows our method is a practical way in pattern acquisitions.

1 INTRODUCTION

XML plays a very important role in many Internet

applications. There are three main advantages in

XML based applications. First, XML can represent

both structured and semi-structured information due

to its flexible format. Second, it is very easy to

convert other kinds of data into XML, because XML

is regarded as a common standard for exchanging

information. Third, all XML formats share a basic

common grammar; any XML parser can parse any

XML document. Many available tools for

manipulating (parsing, reading, writing, translating)

XML data (such as [A. Deutsch, etc. 1999] ) are

beneficial to different applications, thus XML-based

information extraction system can deal with different

data sources with different types of information

expressed in different languages.

Information Extraction (IE) is a text

understanding task, which involves finding facts in

natural language texts, and transforming them into a

logic or structured representation (e.g., a database

table) according to predefined templates and patterns,

such as Snowball [E. Agichtein etc. 2000], which

extracts the company headquarters’ location, the

other extracts information about Infectious Disease

Outbreaks from the web page content [R. Grishman,

etc. 2002]. Even if IE seems to be now a relatively

mature technology, it suffers from a number of yet

unsolved problems that limit its dissemination

through industrial applications, such as systems are

not really portable from one domain to another.

Domain migration means re-developing some

resources, which is boring and time-consuming task

(for example [Riloff 1995] mentions a 1500 hours

development). In order to decrease the time spent on

the elaboration of resources for the IE system, we

use a seed corpus of domain dependent that helps

defining associated resources.

In this paper, we present a domain-portable

bootstrapping method to acquire domain patterns

from web pages. “Domain-portable” means that the

method can be conveniently used in different

domains with relatively low cost of domain

adaptation. The cost includes a seed corpus with

some seed patterns, “key slots” for the specific

domain and domain-specific Named Entities (NE)

recognition system. The approach bootstraps two

sets of data-points in parallel---in the dual spaces of

patterns and corpus---which are statistically

correlated with each other and with the topic of

303

Zeng X., Li F., Zhang D. and I.Vakali A. (2004).

A XML-BASED BOOTSTRAPPING METHOD FOR PATTERN ACQUISITION.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 303-308

DOI: 10.5220/0002607803030308

 SciTePress

interest. Started from a tiny seed corpus, a huge

corpus can be eventually collected and patterns can

be extracted from it.

The rest of this paper is structured as follow: the

system overview will be given first; then, the

approach is described in section 3, 4 respectively;

finally some experiments and evaluations are

presented.

2 SYSTEM OVERVIEW

Figure 1 show the framework of our experimental

system, which can be mainly divided into three

modules: Corpus Gathering Module, Information

Extraction Module, and Information Management

Module.

z Corpus Gathering module:

it searches for related web pages through the

“google” search engine, extracted records

provided by the Information Management

Module are used as key words. Then it filters

web page contents based on a simple domain

keyword list, and new training corpus can be

formed. After being tagged with part-of-speech

(POS) and domain specific name entities (NE),

the new corpus is sent to the Information

Extraction Module.

z Information Extraction module:

positive and negative examples are first

identified by the classifier, then, the pattern

learner draw some new patterns based on

positive examples, the new patterns merge with

the old patterns and evaluated by the negative

examples. A special evaluation method has been

developed in the system. Only those patterns,

which are greater than the threshold, are

regarded as the new patterns and used for next

loop as old patterns.

z Information Management Module:

based on the patterns, extracted information are

stored as records in the module and managed

according to key slots based on domain.

3 XML-BASED PATTERNS AND

RECORDS

With XML there are already some parsers, if

flat-text database is used, the whole parser have to

write. When text format is changed the parser has to

change as well, but the XML parser will not change,

it's automatically forward-compatible. In addition,

there is no need to preserve referential integrity in

our application, and with no transactional support,

obviously there is no obligation to use the Relational

Database Management System (RDBMS).

Figure 1: System framework

Invalid

Pattern

Training

Corpus

Pattern Set

XML

Seed Pattern

Internet

Search Engine

Domain

Keyword Filter

POS Tagging

NE recognition

New Training

Corpus

Seed Corpus

Pattern

Learner

Valid Pattern

Pattern

Evaluation

Information Extraction Module

Result Set

Management

Information

Management Module

Corpus Gathering Module

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

304

Figure 2 illustrates an example of single-slot

surface pattern in our test domain: investment.

“Single-slot” means that the pattern can extract only

one slot filler at a time. “Surface pattern” means that

the pattern contains no semantic information, thus

there is no requirement of semantic analysis for

sentences in the corpus. In this way it is more

realistic to implement the domain-adaptable method.

4 BOOTSTRAPPING METHOD

FOR PATTERN ACQUISITION

We have developed a bootstrapping process for

pattern acquisition that features the following four

points:

1. A classifier is developed to identify positive

examples and negative examples from training

corpus, positive examples are made of those

sentences that contain the related events, such as

investment event in our system and the negative

examples are made of the sentences that don’t

contain the interested events.

2. Positive examples can be used to learn the

extraction patterns associated with domain event.

Negative examples are used to evaluate the new

patterns acquired.

3. New acquired patterns with their records can be

used to extract new corpus and extend the

training corpus gradually.

4. Starting with a seed patterns and corpus, new

acquired patterns merged with old patterns are

used in the next iteration.

4.1 Document classifier

The training corpus is extracted from the Internet

according to extracted records. Because of the

complexity of natural languages, some sentences

may not be regarded as a positive examples related

to specific domain. Following two examples are

searched from Internet by the same keyword set

(Intel), (investment) :

Sen 1 (Translation: Intel will

slow down its venture investment)

Sen 2

1.98 5 (Translation: It

will increase Intel

’s investment at Shanghai Capsulation

and Test factory from 198 millions dollars to 500 millions

dollars.)

These two sentences both contain the NE: “

(Intel)”, however, the first sentence has nothing to

do with the investment event, thus it is a negative

example, while the second sentence describes an

investment event and it is a positive example. In

order to reduce the noise of these negative examples,

we should classifier the new training corpus to

maintain the high precision of the new extracted

patterns.

The input of the classifier are sentences which

have been POS tagged and NE recognized, the

output is positive or negative examples based on a

statistical model.

At the beginning, the training corpus is divided

into positive examples P, negative examples N and

undefined examples U.

P contains those sentences which can be

</pattern>

</slot>

</domain>

// domain name

// the pattern can extract which slot

// pattern fits to which language

// slot filler with proper matching NE type "FIRM-NP"

// the upper and lower elements must be adjacent closely

// the word/phrase “invest” is in the thesaurus set

// NE with "MONEY" type but not slot filler

// a word/phrase “to” not in thesaurus set

// pattern end

// another pattern matching the same slot

//other slot/subslot

The pattern can be showed as:[investor FIRM-NP] +[MONEY] [FIRM-NP]

; “investor” means the NE [FIRM-NP] is slot filler for investor slot

; “+” means some undeclared elements can exist here

Figure 2: An example of pattern

AN XML-BASED BOOTSTRAPPING METHOD FOR PATTERN ACQUISITION

305

extracted by the current pattern set; N contains those

sentences which includes less than

keywords which

are supposed to be related with certain event.

is a

predefined threshold, can be different value for

different domain; U contains those sentences which

are unknown as positive or negative.

Then, create the statistical model M

statis

based on

the P and N using the following procedure:

Proc

Deleting the stop-word in each sentence S

Dividing S into following segments using

each [NE] as delimiter

pre(NE

) = {P

, P

,……}

follow(NE

) = {P

, P

,……}

……

preced(NE

) = {P

, P

,……}

follow(NE

) = {P

(i+1)1

, P

(i+1)2

,……}

; where [NE

] is the recognized i

; in sentence S, P

is the j

term

; between [NE

i-1

] and [NE

]

if([NE

]==[NE

])

{

pre(NE

)=pre(NE

) pre (NE

);

follow(NE

)=follow(NE

) follow(NE

);

pre(NE

)=follow(NE

)=null;

}

Score(ph) = a* (pos+neg)/sum

; “ph” is a term in pre(NE) or follow(NE)

; “sum” is the appearance count of “ph”

; in the training corpus C

; ”pos” is the count of “ph” in P

; “neg” is the count of “ph” in N

statis

= {M

NE1

NE2

}

NEi

= {{Score(hP

), Score(hP

) },

{Score(tP

), Score(tP

) }}:

; where:“hP

” is a term in pre(NE

)

; “Score(hP

)” is the score of hP

;

“tP

” is a term in following(NE

)

; “Score(tP

)” is the score of tP

endProc

Algorithm 1. Tern Position Weight

Statistical Model Mstatis Generation

Now, we can calculate the Score(S) for each

sentence S by simply sums each word’s score in S,

and then to sort the sentences based on Score(S). We

define here two parameters Min(pos) and Max(neg),

then reclassify the corpus and form new positive

examples P

new

and new negative examples N

new

based on this two paramenters:

Min(pos) = min Score(s) in the P

Max(neg) = max Score(s) in the N

new

={sentences whose score is higher than

or equal to Min(pos)}

new

={sentences whose score is lower than

or equal to Max(neg)}

If P

new

is same as P and N

new

is same as N, the

process of classifying is over, otherwise create new

statistical model M

statis

based on P

new

and N

new

, and

to reclassify the corpus again and again.

4.2 Pattern Generation

From those sentences in positive examples P, new

patterns are created. Then they are added to current

pattern set. Based on the Crystal algorithm [ S.

Soderland, etc. 95] new pattern set are generalized

and evaluated as the description in algorithm2.

In the Crystal algorithm, the criterion to evaluate

a pattern’s validation is the error rate of patterns’

extraction result. But we think that precision is much

more preferred to recall, for users are much willing

to see a few hundred of records with comparably

high precision than to see hundreds of records with

much redundancy. So in our system, we restrict the

evaluation criteria like this: if a pattern can extract

result from the negative examples N, then it is

deleted from the pattern set.

P=an initial pattern removed from the

pattern set

Loop

If (P can extract result from N)

exit loop

P'=the most similar pattern to P

If (P'==NULL), exit loop

U=the unification of P and P'

If(U can extract result from N)

exit loop

Delete all patterns covered by U

Set P=U

Add P to the pattern set

Return the pattern set

Algorithm 2. Pattern Generalizing and Evaluating

The new pattern set will extract more record

from the training corpus, and these new record can

be used to search for new instances from Internet.

Such as from the Sen 2 of chapter 4.1, can

generate new pattern as:

New Pattern: [FIRM-NP] [MONEY] [FIRM-NP]

[PERCENTAGE]

Translation: [investor FIRM-NP] has spent [MONEY] in

buying [FIRM-NP]’s [PERCENTAGE] stocks

After generated, it may match the instances as:

Sen 3. [FIRM-NP ] [MONEY 5

ln(1 /(2 * )) 0, 0

ln(2 * ) 0, 0

ln( / )

pos neg

neg pos neg

pos pos neg

pos neg other

⎧

⎪

=≠

⎪

⎨

≠=

⎪

⎩

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

306

] [FIRM-NP ][PERCENTAGE 51%]

(Translation: such as [FIRM-NP Newbridge

Capital] has spent [MONEY 500 millions dollars] in

buying [FIRM-NP Korea First Bank]’s 51% stock)

With some other pattern’s extraction result, the

new record {“investor: Newbridge Capital”,

“invested-party: Korea First Bank”, “invest-sum:

500 billions dollars”} will be used for the next

iteration.

4.3 Information Management

Let’s look at two sentences first:

Sen 4. /

1.98

Translation: It will increase Intel

’s investment at Shanghai

Capsulation and Test factory from 198 millions dollars to

500 millions dollars.

Sen 5. ( ) 9 20

3.02

Translation: Sep. 20

, Intel Co., Ltd.(China) announced in

Beijing that it will invest another 302 millions dollars

its factory at shanghai, this increases Intel

’s investment at

Shanghai Capsulation and Test factory

to 500 millions

dollars.

Obviously, these two sentences present the same

event, we can extract “investor”(Intel), “invested

party”(Shanghai Capsulation and Test factory) and

“total investment”(500 millions dollars) from both

of them, while from the first sentence we can

additionally extract “completed investment”(198

millions dollars) and from the second sentence we

can additionally extract “investment date”(Sep. 20

)

and “additional investment” (302 millions dollars).

In order to manage information conveniently we

should merge them into one record.

How can recognize two sentences address the

same event or two records are overlap partly? Here

we adopt an idea of “key slots”. In another word, we

think that in a specific domain there must be some

slots that are much more important than other slots.

If both “key slots” are same, their extracted records

are about the same event and should be merged into

one record. In different domain, there are different

“key slots” (such as “investor” and “invested party”

as the key slots in our investment domain).

According to experimental result, the merge

precision reaches 98.9%.

5 EXPERIMENT AND

EVALUATIONS

In the experimental system, we select the

“investment” as the test domain. We build up the

seed corpus consisting of 7 investment events with

55 single-slot surface patterns. ICTCLAS system

(provided by Institute of Computing Technology,

China Science Academy) is used in our pattern

acquisition to tokenize and POS tag.

5.1 Evaluation of the Positive and

Negative Examples

At last, the training corpus consists of 8706

sentences extracted from 3443 web pages. After

classifying the training corpus, we get the positive

examples containing 1035 sentences with the

precision of 87.74%, and the negative examples

including 2682 sentences (threshold

=2) with the

precision of 89.68%.

In positive examples, errors are mainly occurred

with those sentences, which say a future or cancelled

investment event. In negative examples, errors are

caused by the POS tagging and NE recognition in

the sentence. Especially many abbreviations of

company name cannot be recognized properly, thus

some sentences are misjudged as negative examples.

5.2 Evaluation of the Bootstrapping

Pattern Acquisition

The training corpus comes from the Internet, where

an event may be appeared several times in different

web sites with different sentences, as long as we can

extract one time from any one of these

heterochromatic sentences we think we succeed in

extracting this event.

After about 20 iterations the size of corpus and

the result of information are stable, as illustrated in

the figure 3. As we can see, new pattern set has high

precision.

0,2

0,4

0,6

0,8

iteration

precison and recall

200

400

600

800

1000

pattern count

Figure 3: Evaluating the Learned Patterns

AN XML-BASED BOOTSTRAPPING METHOD FOR PATTERN ACQUISITION

307

The recall is relatively low which is mainly

caused by the following reasons:

1. In the pattern acquisition, we use only the

positive examples, which is of only 11.89% in

the total training corpus. Although recall on the

training corpus can only reach 42.4%, the recall

on the positive examples will be much better.

2. Many events have few instances even one

instance; they are often of an individual or

infrequent structure. Obviously it is much

difficult to extract an event from few or even one

instance.

Following shows two patterns in investment

domain with its precision in pattern acquisition.

Pattern1 for invested-party with the precision of

88.9%:

Pattern1. +[stuff FIRM-NP]+

Translation: buy stocks of [invested-party FIRM-NP]

Pattern2 for investment amount with precision of

94.1%:

Pattern2. [invest-sum MONEY]

Translation: total investment reaches [invest-sum

MONEY]

6 CONCLUSION

In this paper, we describe a bootstrapping method to

acquire patterns in Information Extraction. Starting

with a tiny seed corpus and patterns, the

bootstrapping process collects new documents from

the Internet and extracts new domain patterns. This

approach overcomes the shortcoming in the scale of

training corpus of traditional method. In order to

improve the precision of acquisition, a classifier is

used to identify new positive and negative examples

for pattern acquisition and evaluation. A statistical

model is used in the classification in our prototype.

At last, we present a “key slots” idea in the

information management module in order to merge

multiple extracted records. Experiments show that

the precision of pattern acquisition of our method is

high.

However there are some points to be improved

in our future work:

1. In classifying the new corpus, the recall is less

than 50%. With the improvement on the recall,

many new patterns can be acquired from the

positive examples; also more negative examples

can be used to evaluate these new patterns.

2. Different forms of a NE can not been identified,

especially between the abbreviation of a

company’s name and its full name. For example,

“

”, “ ”, these tow phrases

are the same company name but in different

forms.

ACKNOWLEDGMENTS

This research work was supported by the grant No.

60083003 from National Natural Science

Foundation of China.

REFERENCES

S. Abiteboul, D. Quass, J. McHugh, J. Widom, and J.

Wiener, 1997. The Lorel query language for

semi-structured data. International Journal on Digital

Libraries, 1(1):68-88, April

S.Cluet, C.Delobel, J.Siemon and K. Smaga, 1998. Your

Mediators Need Data Conversion! in Processing of

ACM-SIGMOD International Conference on

Management of Data, 177-188.

S.Cluet, S. Jacqmin, and J.Siemon, 1999. The New

YTAL: Design and Specifications. Technical Report,

INRIA.

A. Deutsch, M. Fernandex, D. Florescu, A.Levy and D.

Suciu. A query language for XML. in International

World Wide Web Conference, 1999

M. Fernandez, J. Siemon, P. Wadler, 1999. XML Query

Languages: Experiences and Examples.

http://wwwdb.research.bell-labs.com/user/simeon/xqu

ery.html

E. Agichtein & L. Granvno, 2000. Snowball: Extracting

Relations from Large Plain-Text Collections. in

Proceedings of the 5th ACM International Conference

on Digital Libraries.

R. Grishman, S. Huttunen & R. Yangarber, 2002,

Real-Time Event Extraction for Infectious Disease

Outbreaks. in Proceedings of Human Language

Technology Conference (HLT)

S. Soderland, D. Fisher, J. Aseltine & Wendy Lhenert,

1995. CRYSTAL: Inducing a Conceptual Dictionary.

in proceedings of the 14th IJCAI’ 95.

Ellen Riloff & Janyee Wiebe, 2003. Learning Extraction

Patterns for Subjective Extractions. University of

Utah, The Association for Computational Linguistics

(ACL)

Roman Yangarber, 2003. Counter_Training in Discovery

of Semantic Patterns. New York University, the

Association for Computational Linguistics (ACL)

Ellen Riloff, 1995. Little Words Can Make a Big

Difference for Text Classification. University of Utah,

in proceedings of the 18th Annual International

Conference on Research and Development in

Information Retrieval (SIGIR’95)

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

308
