ACCESS MODEL IN COOPERATIVE INFORMATION SYSTEMS

Preserving local autonomy with a global integration process

Eric Disson, Danielle Boulanger

MODEME Team, FRE CNRS 5055, Université Jean Moulin Lyon 3, 15, quai Claude Bernard 69007 Lyon, France

Keywords: Information Systems Security, Access Policies Heterogeneity, Access Model, Information Systems

Federation, Cooperation.

Abstract: This research focuses on access security in cooperating information systems. The offered modeling has to

treat the interoperation of open and evolutive information systems and, moreover, has to guarantee the

respect of various local security policies. The coexistence of heterogeneous information sources within an

information systems framework involves homogenization problems between local security policies. We

distinguish two types of heterogeneity: heterogeneity of the local access policies and semantic heterogeneity

between object or subject instances of the local access schemas. To solve this twofold difficulty, we propose

an original role model allowing a unified representation of local access schemas. This model preserves the

flow control properties in the three main access policies (discretionary, role-based model and multilevel

models). The described access schemas are enriched to establish intra-system access authorizations.

1 INTRODUCTION

This research focuses on access security in

cooperating information systems. The offered

modelling has to treat the interoperation of open and

evolutive information systems and, moreover, has to

guarantee the respect of various local security

policies.

Two main assumptions are taken in federated

dat

abases: autonomy and heterogeneity (Shet et al.

90). The first refers to the ability of the local

database system to retain a most large degree of

control over the aspects of the systems.

Heterogeneity means that databases built on

different schema designs and different data access

models must be interconnected. The highest

heterogeneity level is the semantic heterogeneity

between local entities of the federation. An other

heterogeneity problem is the difference between

local organizational security methods (different

schemas of user types and objects). Federated

security systems must support both open and / or

closed security axioms and logical access modes.

2 RELATED WORKS

Several approaches are used to define federated

security models:

• using views and granting authorizations on the

views

to allow or prevent a global user to access

information within a federation. In the Goyal’s

(Goyal 91) approach, access rules are used to

authorize or deny the access to a global view.

• extending an existing access control model

(suc

h as DAC or MAC) to deal with the

problems of autonomy and heterogeneity.

The CHASSIS (Configurable, Heterogeneous,

d Safe, Secure Information Systems) project

(Jonscher et al. 94) is a tight coupled system with

discretionary access control and a right granting

system. In tightly coupled systems, a federation

authority exists and the federated database system

has its proper access model. In case of conflicts,

prohibitions override permissions. Access rights can

be granted to individual users and to roles. Multiple

role activation is controlled by an activation conflict

relation. Several rules exist to infer implicit rights

according to the data model. In this approach the

global schema has more importance than local ones.

Some other propositions (Olivier 94) use a multi-

level access control but in a relatively compatible

and homogeneous database system. In (Oliva 02)

authors propose an other MAC model with the same

259

Disson E. and Boulanger D. (2004).

ACCESS MODEL IN COOPERATIVE INFORMATION SYSTEMS - Preserving local autonomy with a global integration process.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 259-266

DOI: 10.5220/0002610702590266

 SciTePress

objective. But we think this access model is too

constrained for the local systems to be use in an

cooperative process. Several propositions (Sandhu

96) and (Sandhu 98) use a role-based access control

model for DAC and MAC simulation in non

federated systems but their approaches of access

model heterogeneity are relevant for database

federation security. The AMAC model uses both

MAC and DAC models at the federated level

(Pernul 93). It supports an automated labeling object

system to compute large data queries in a federated

system. These approaches have two limitations: the

federated manager has a bad local security visibility

and the sub-transaction (part of the global query) to

a local system could be aborted later affecting the

performance of the federated system; the lack of

logical secured architecture do not permit how the

federated security can be enforced.

One of the issues in the Distributed Object

Kernel (DOK) (Tari et al. 97) is the development of

a federated access control and a secured logical

architecture. It allows the DOK system to enforce

federated security policies in the context of

autonomous, distributed and heterogeneous

databases. The authors consider DAC and MAC

access control. The federated level of the DOK

system supports a bottom-up approach for access

control: the Global Access Control (GAC) is derived

from all the local security policies and ensures that

no violation or overriding of local policies is

possible. The DOK system is an open system: the

federated access list for an aggregate is explicited as

a union of the different security information defined

in the local databases. If only one database allows

the reading of the aggregate, according to global

policies, the user has ‘read access’ to the required

information.

Some propositions focus on security object

similarity evaluation like (Castano et al. 97); the

authors propose similarity criteria and associated

metrics to compare security specifications of

different applications. They consider security

specifications according to a role-based model

providing powerful authorization mechanisms

suitable for similarity analysis. They use a set of

basic criteria called affinity criteria (like synonymy,

genericity…), some dictionaries of terms and roles,

and a global similarity coefficient to compute the

authorization affinity between two roles. They deal

with the highest level of data semantic heterogeneity

and not with the access model heterogeneity level.

Security in federated information systems is a

critical issue. When a high security level is defined it

often implies a tight coupling among local

databases. Similarly, a loose coupling leads to local

information sources autonomy and consequently to a

poor global security level.

3 OUR APPROACH

To solve this twofold difficulty, we propose a three

steps process to integrate a local system in the

federation (see figure 1). At first, the local

administrators define the exported schemas. An

original “extended role model” allows a unified

representation of local access schemas. This model

preserves the flow control properties in the three

main access policies (discretionary (Lampson 71),

role based model and multilevel models (Bell et al.

76) ). At the third phase of the integration process,

the described access schemas are enriched to

establish intra-system access authorizations.

AMDO Class

SDO Class

Federated level

Security

Domain

Security

Domain

Distribution

Local level

Descriptive

Classes

Data model

describe Class

Undescribed local level :

Exported data schema

Described local schema 1 :

Object described data schema

Described local schema 2 :

Object described data schema

RBAC described access schema

Figure 1: The overall security incorporation process.

We propose a global framework dedicated to

autonomous preexisting data sources cooperation

provided with an acceptable security level based on

a rich descriptive object oriented layer.

To constitute the descriptive layer we define

metadata insuring an homogeneous representation of

each local available information source (Boulanger

et al. 98), (Boulanger et al. 00). The layer supports

global queries treatment through Data Descriptive

Objects (DDO) and Semantic Links (SemL). DDO

and SemL are dedicated to the abstract description

of the local data entities structure and the semantic

links among them. For a given data model

(relational, object, rule-based…) a set of DDO

classes is defined to allow a description of the model

as precise as required at the federated level. Thus for

each local data entity a DDO is instantiated in the

descriptive layer. To improve the expressiveness of

the description, a set of SemL classes is also created

(SemL are data model independent) to express

semantic links among the data. It allows to

implement inner links at the local level as well as

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

260

inter-database links: semantic links like synonymy,

hypernymy and hyponymy describe syntactic and

conceptual equivalencies among the data entities.

The obtained semantic network constitutes a

knowledge base used for global imprecise queries

processing.

We use a Role-Based Access Model (Disson et

al. 01) to describe each local system at the global

cooperation level. This model is enriched by specific

metadata describing the data manipulation rights.

We do not use the data definition rights and rights

administration concepts in the global system with

the loosely cooperation hypothesis. Such access

rights are administrated only by the local data

owners or “security officers”. RBAC models are

efficient for simulating other access policies

(Nyamchama et al. 96), (Sandhu et al. 96) and

respect the loosely coupled cooperation hypothesis.

The local security items are modeled with two

concepts. The security object (passive data entity)

and security subject (active entity like user) are

described with Security Descriptive Object (SDO)

which are instantiated from SDO classes (Data,

User…). The Application SDO class describes the

general security strategy of the local system.

The local security authorization units like groups

(DAC policies), roles (RBAC policies) or MAC

“containers” (result of cartesian product between

MAC category and MAC classification hierarchy of

the local model) are described by Access Policy

Descriptive Object (APDO).

The main objective of the flow control policy at

the global level is to respect the local users’ profiles

: a local user can read or modify federated

information only if it is equivalent to local

information on which he has such authorizations.

In each local information system the security

manager must define the flow control policies

adapted to the exchanges between the system and

the federation. The import policy (input flow of the

local system) is defined to be strict. It is a common

feature that each local system must respect. The

export policy (output flow of the local system) is

either strict or liberal.

• Strict import policy: in our proposal, all the

local systems adopt the same import access

policy. At any time the following security axiom

has to be valid: “for a given local user, the access

to a global data must be equivalent to the access

to a local data belonging to the local user’s

profile”. A user profile is defined as a set of

access rights to local objects. In our proposal the

set of access rights is stored in the (one or more)

roles which reference the proper User at the

descriptive layer of the framework.

• Strict or liberal export policy: the export

policy in a local system defines the way local

data can be read from the federated level. In the

case of a liberal export policy, the access

requests from the federated level are

automatically performed on local Security

Objects. Access equivalencies defined among the

DDO referenced in the User and the actual local

data are used to verify the rights the user has on

the concerned data. Access rules on the Security

Objects related to the federated user predominate

access rules defined at the local level.

In the case of a strict export policy a first

mapping allows to detect which Role of the local

system corresponds to Roles related to the global

user. Then a second mapping is performed to

verify the correspondence of access rights related

to the Security Objects referenced in the Role.

At last, we define a global trusted session

respecting the import and export data policies

between the federation and its various members. A

solution to implement our object model of secured

cooperation is also proposed.

4 THE DESCRIPTIVE

CANONICAL MODEL

The figure 2 highlights our data and security

canonical model. Successively we specify local

access policy descriptive classes, local access

schema descriptive classes and link classes.

Our objectives are:

• to represent local access schemas respecting

different access policies (DAC, MAC, RBAC).

• to establish access equivalence between

described schemas.

• to control the federated information flow with:

• the respect of local user profiles.

• the respect of local exportation policies

(information flow from a local system to the

federation).

Permission

Link

pmode

Permission

Link

pmode

Object

oname

oniv

Object

oname

oniv

User

uid

uhab

User

uid

uhab

0..*

1..1

0..*

1..1

0..1

1..1

0..*

1..*

father son

Session

sniv

Session

sniv

Role

rname

rniv

Role

rname

rniv

Heritage

Link

lmode

Heritage

Link

lmode

1..1

0..*

1..1

Exclusion

Link

emode

Exclusion

Link

emode

0..*

2..*

Figure 2: The canonical model (reduced version).

ACCESS MODEL IN COOPERATIVE INFORMATION SYSTEMS

261

An Access Policy Descriptive Object is defined

by the tuple < FID; LD; LAP; LAMT; LMT; {role}

>. FID is the Federated Identifier of the local

system; LD is the Local Designation. LAP is the

Local Access Policy which can be chosen in the set

{ DAC; RBAC; MACS; MACL } with DAC for

Discretionary Access Control (Lampson 71), RBAC

for Role-Based Access Control, MACS and MACL

for respectively mandatory model with strict I-

property and mandatory model with liberal I-

property (Bell 76). LAMT is the Local Access Mode

Table and defines the correspondences between the

local access modes and the federated access modes.

The Local Mandatory Table (LMT) defines the

correspondences between the local secrecy hierarchy

level of a mandatory system and the federated

secrecy level hierarchy. LMT attribute is null-valued

in case of DAC or RBAC system description. {role}

is a set of Roles which describe discretionary user

group, role and mandatory category.

At the federated level we use five logical access

modes: read-only (r), execute (x), append (a),

upgrade (u) and delete (d) with r ^ x ^ a ^ u ^ d.

Each local access mode is described by a federated

access mode combination. For example, in Unix

system the “write” access mode is described by the

federated access mode combination a + u + d. All

the local access mode descriptions are defined in the

Local Access Mode Table.

The Local Access Mode Table contains the

federated access mode combinations which is

equivalent to each local access mode (mainly read-

only and write-only local access modes). Then the

Local Mandatory Table is created to translate the

local secrecy level hierarchy.The dominate level is

always the first. For example, a local system with

the hierarchy of sensibility Non-Classified <

Classified < Secret < Top Secret is described by the

LMT {(Non-Classified; 1); (Classified; 2);

(Secret; 3); (Top Secret; 4)}.

A Security Object represents a secured entity of

the local access schema. A SO is defined by the

tuple < FID; LD; ML; DDO >. FID is the Federated

Identifier of the local resource. LD is the Local

Designation. FSL is the Federated Sensibility Level.

This attribute is null in case of DAC or RBAC

model description. DDO is a referenced Data

Descriptive Object. Each local secured data is

described by one to n Security Objects and one Data

Descriptive Object (see section 5).

A User Object describes a physical user of the

local access schema. A User is defined by the tuple

< FID; LD; FSL >. FID is the Federated Identifier of

the local user. LD is the Local Designation and FSL,

the Federated Sensibility Level. This attribute is null

in DAC or RBAC model description.

A Permission defines the access mode

combination the Subjects Descriptive Object of a

given role is allowed to execute on one Security

Object.

An Access Rule is defined by the tuple < so; m >

with so, a SO reference and m, a federated access

mode combination.

Our access model is a closed security system: all

non-authorized accesses are forbidden.

A Role is used in two cases: to represent a local

discretionary user group, or to extract each

sensibility level of a local mandatory category.

A Role is described by the tuple < FID; LD;

FSL; {Permission}; {User}; {AHL} {CLO};

{AELO} >. FID is the Federated Identifier of the

described element. LD is the Local Designation of

the described element. FSL is the Federated

Sensibility Level. This attribute is null in case of

DAC or RBAC model description. {Permission} is

the set of Permissions which defines access modes

to Security Object allowed for the Subject

Descriptive Object. {AHL} is the set of Access

Heritage Links. {CLO} is the set of Constraint Link

Objects, and {AELO}, the set of Access Equivalent

Link Objects (see the section 6).

An Access Heritage Link defines an access mode

combination from a “father” role to a “son” role with

the tuple < “father”; “son”; Mode > where “father”

is the “father” role reference, “son” is the “son” role

reference and Mode is a federated access mode

combination that Subject Descriptive Objects of the

“father” role are allowed to execute on all the

Security Objects of the “son” role. A null Mode

means that all SDO of the “father” role may execute

Access Rules of the “son” role (complete access).

Two types of Constraints are used in our system:

An Exclusion Constraint Link Object (ECLO)

references two or more roles. A User can be

referenced in only one role in a set of roles which

references the same ECLO (static constraint).

An Activation Constraint Link Object (ACLO)

references two or more roles. For a given user

session, the user actives only one role, in a set of

roles which references the same ACLO (dynamic

constraint).

5 A EXAMPLE OF MAC POLICY

SCHEMATA DESCRIPTION

Mandatory security models govern the access to

information by classifying the subjects and objects

in the system (Bell et al. 76). Objects are passive

entities storing information. Subjects are active

entities accessing the objects. Generally, a subject is

considered to be an active process operating on

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

262

user’s behalf. Mandatory access classes are

associated with every object and subject in the

system. A secrecy level hierarchy (with the relation

“dominate”) is used to qualify each object and

subject (mandatory clearance).

Two axioms define access rules of a subject to

an object (referenced in the same category):

• Read axiom: A subject with a mandatory

clearance c can read all the objects with a

secrecy level dominated by c.

• Write or I-property: A subject with a

mandatory clearance c can write on all objects

with a secrecy level strictly equal to c (strict I-

property) on all objects with a secrecy level

dominating c (liberal I-property).

Mandatory models can belong to three categories

relatively to the security object granularity. In

single-level mandatory models, the components of

Security Objects (i.e. attributes in an object class or

in a relational table) have the same secrecy level

(Jajodia et al. 90), (Millen et al. 92). In our

proposition, each mandatory object is described by

one single SO (security description) referencing one

DDO (data description). An attribute must have the

same Mandatory Level as its class level. In multi-

level mandatory models, attributes in an object class

or in a relational table are mandatory objects. Their

levels of sensibility can dominate or be equal to the

level of sensibility of their classes / relational tables

(Keefe et al. 90), (Lunt 90). Each mandatory object

is also described by one single SO but in this case,

Mandatory Levels of Attribute and classes /

relational tables are not necessarily equal. In poly-

instantiated multi-level mandatory models, instance

attribute can be multi-valued. The attribute value

captures the secrecy level equal to subject’s

clearance level (Denning 87). Each attribute is

described by one DDO and n SO (SO have different

Mandatory Levels); n is the secrecy level number in

the local mandatory hierarchy of sensibility.

A local mandatory access system is proposed in

six steps:

• A Local Model Descriptive Object describes

the local access security policy. First the Local

Access Mode Table is created and contains the

federated access mode combinations which is

equivalent to each local access mode (mainly

read-only and write-only local access modes).

Then the Local Mandatory Table is created to

translate the local secrecy level hierarchy.

• For each local subject with a given clearance

level cl, is created a User with secrecy levels. Ex:

Mr. Smith has a clearance level “Secret” in a

mandatory system with the LMT {(Non-

Classified,1); (Classified;2);(Secret;3); (Top

Secret;4)}. Mr. Smith subject is described by one

User with the Mandatory Clearance 3.

• Security objects describing the local

mandatory objects:

Single level objects with a given secrecy level sl:

is created one SO with a Mandatory Level equals

to sl. The SO points to its related DDO.

Poly-instantiated objects in a lattice-based access

model: are created as much SO as there is

secrecy levels in the local sensibility hierarchy.

Each SO has a different Mandatory Level. All

the SO reference a single DDO.

• For each local mandatory category is created

as much roles as there is secrecy levels in the

local sensibility hierarchy. The User (subject of

the local mandatory category) having a

Mandatory Clearance n is referenced in the role

with a Mandatory Level n.

• Mandatory security axioms:

Read axiom and strict I-property:

For each role with a Mandatory Level n are

created two permissions (with mode = a+u+d ≈

write and with mode = r for read) per SO

referenced in the role.

In a described local mandatory category, Access

Heritage Links (with mode = r) bind each role of

a given level n (dominant) with the role of the

level n-1 (dominated) providing a descending

read access heritage.

Read axiom and liberal I-property:

For each role with a Mandatory Level n is

created two permissions (with mode = a+u+d ≈

write and with mode = r for read) per SO

referenced in the role.

In a described local mandatory category, Access

Heritage Links (with mode = r) bind each role of a

given level n (dominant) with the role of the level n-

1 (dominated) providing a descending read-only

access heritage.

In a described local mandatory category, Access

Heritage Links (with mode = a+u+d) bind each

ROLE of a given level n (dominated) with the

ROLE of the level n+1 (dominant) providing an

ascending write-only access heritage.

The Figure 3 illustrates such a local mandatory

model description. The local mandatory model is

composed of:

• A local single-level mandatory policy with a

liberal I-property (EX2 IS:APDO).

The following Local Access Mode Table: Read

(r) and Write (a+u+d).

The local hierarchy of sensibility is Non-

Classified (NC), Classified (C), Secret (S) and

Top Secret (TP) with the dominate relation “>”:

TS > S > C > NC. The Local Mandatory Table

is: 1. Non-Classified, 2. Classified, 3. Secret and

4. Top Secret.

• A mandatory category: Finance.

ACCESS MODEL IN COOPERATIVE INFORMATION SYSTEMS

263

• The following Objects of the category

Finance: Sales Result (NC), Salary (C), Account

105 (S), Financial Plan (TS)

The subject Smith with “Secret” clearance level

belonging to the category Finance.

:AHL

Mode= r

:AHL

Mode= a+u+d

:AHL

Mode= r

:AHL

Mode= r

:AHL

Mode= a+u+d



{[read;(r)];[write;(a;u;d)]}



{(1;NC);(2;C);(3;S);(4;TS)}

EX2 IS :APDO

FID= 001

LD= EX2 IS

LAP= MACLIB

LAMT=



LMT=



Fin4 :Role

Fin3 :Role

:AHL

Mode= a+u+d

Fin2 :Role

Fin1 :Role

:Permission

Mode= a+u+d

:Permission

Mode= a+u+d

Smith :User

FID= 018

LD= Smith

MC= 3

:Permission

Mode= a+u+d

:Permission

Mode= a+u+d

SalesResult :SO

FID= 006

LD= Sales result

FSL= 1

Salary :SO

FID= 005

LD= Salary

FSL= 2

Account105 :SO

FID= 008

LD= Account 105

FSL= 3

FinancialPlan :SO

FID= 002

LD= Financial plan

FSL= 4

:Permission

Mode= r

:Permission

Mode= r

:Permission

Mode= r

:Permission

Mode= r

FID= 004

LD= Finance category

FSL= 1

FID= 003

LD= Finance category

FSL= 2

FID= 002

LD= Finance category

FSL= 3

FID= 001

LD= Finance category

FSL= 4

Figure 3 : An example of mandatory model description

with liberal I-property.

The User 018 is created with Mandatory

Clearance 3. The User is referenced in the right role.

• The “read” axiom is implemented by a

descending access heritage (AHL with Mode =

r). The liberal I-property is implemented by an

ascending access heritage (AHL with mode = a

+u +d). This heritage does not exist in a

mandatory model with strict I-property.

• An Activation Constraint Link Object is

referenced by the fourth role and forbids the

simultaneous activation of the User "Smith".

This MAC schema description respects the MAC

information flow acyclicity (see the grayed

sensibility hierarchy of Mr. Smith’s session).

6 THE FEDERATED

ARCHITECTURE

The global descriptive layer is composed of data

description objects with access links and implements

a flow control policy.

6.1 Access Bridge definition

For each data source involved in the federated

information system a descriptive process is

performed in order to create a semantic description

of data at the federate level. All the knowledge

intensive processes dedicated to global queries

treatment and overall security setup use the data

Descriptive Objects (DDO) composing the

descriptive layer as the main resource for local data

access.

Semantic links describe not only structural

relationships among entities but also semantic links

useful at the global level. With such links it is

possible to enrich the data descriptive level allowing

a higher level for reasoning processes about local

information.

In our proposal the semantic descriptive layer is

used by semantic evaluation functions. The semantic

distance between two objects is given by the

following formulae borrowed from the

terminological description research field : SD =

S(Nbi x Wi), with Nbi = Number of semantic links

of type i linking the two objects in the global

descriptive semantic net, and Wi = Weight of the

link of type i. It is useful to give a weight to

semantic links since a SemL type may be more or

less important in a semantic evaluation. Semantic

distance is mainly used when global security access

equivalencies have to be defined in order to allow

secured local data access by global user queries.

IS 2 IS 2

IS 1IS 1

Access Schema DescriptionData Schema Description

DDO

SDO

Syn

Access Equivalence Link

creation

Ael

Search for Semantic Link

(synonymy)

Search for Semantic Link

(synonymy)

+ semantic distance calculus (d)

If d ≤α

with α = AEL_Threshold

IS 2IS 2 IS 2IS 2

IS 1IS 1IS 1IS 1

Access Schema DescriptionData Schema Description

DDO

SDO

Syn

Access Equivalence Link

creation

Access Equivalence Link

creation

Ael

Search for Semantic Link

(synonymy)

Search for Semantic Link

(synonymy)

+ semantic distance calculus (d)

Search for Semantic Link

(synonymy)

Search for Semantic Link

(synonymy)

Search for Semantic Link

(synonymy)

+ semantic distance calculus (d)

Search for Semantic Link

(synonymy)

+ semantic distance calculus (d)

If d ≤α

with α = AEL_Threshold

Figure 4: the AEL Creation Process.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

264

The rules to define access equivalencies between

SO and between ROLE belonging to different local

systems are (see figure 4):

1- when a synonymy link exists between two

DDO, an Access Equivalence Link (AEL) is

instantiated and references the related SO.

2- we use a Semantic Distance (SD) to evaluate

similarity between DDO belonging to a ROLE. The

SD threshold (T) is given by the federated security

officer. If SD>=T, an AEL is instantiated and

references the two ROLE.

Equivalence links between ODS complete this

procedure to control information flow (with the

respect of local profiles) at the federation level.

The figure 5 (at the end of the paper) offers an

example: at the federated level the global schema is

describing an hospital organization and a DAC

model describing a private clinic. The ODS are

shadowed.

6.2 The federated flow control policy

In each local information system the security

manager must define the flow control policies

adapted to the exchanges between the system and

the federation. The import policy (input flow of the

local system) is defined to be strict. Each local

system must respect it. The export policy (output

flow of the local system) is either strict or liberal

(see the figure 6).

Information

System 1

Description

Information

System 2

Description

Local

Information

System 1

Request

Local

Information

System 2

Liberal passive

Exportation

Policy

Passive Strict

Exportation

Policy

Information

System 3

Description

Local

Information

System 3

Active

Importation

Policy

Active

Exportation

Policy

Passive Liberal

Importation

Policy

Information

System 4

Description

Local

Information

System 4

Federated Information System

Figure 6: The federated security policy.

Strict import policy: in our proposal, all the local

systems adopt the same import access policy. At any

time the following security axiom has to be valid:

“for a given local user, the access to a global data

must be equivalent to the access to a local data

belonging to the user’s local profile. A user profile is

defined as a set of access rights to local objects. In

our proposal the set of access rights is stored in the

(one or more) Roles which reference the proper User

at the descriptive layer of the framework.

Strict or liberal export policy: the export policy

in a local system defines the way local data can be

“son” from the federated level. In the case of a

liberal export policy, the access requests from the

federated level are automatically performed on local

Security Objects. Access equivalencies defined

among the DDO referenced in the User and the

actual local data are used to verify the user’s rights

on the concerned data. Access rules on the Security

Objects related to the federated user predominate

access rules defined at the local level.

In the case of a strict export policy, a first

mapping allows to detect which Role of the local

system corresponds to Roles related to the global

user. Then a second mapping is performed to verify

the correspondence of access rights related to the

Security Objects referenced in the Role.

7 CONCLUSION

It is obvious that security problems in federated

loose coupled systems is a difficult issue when local

autonomy data sources is respected, due to the

dynamic evolution of local systems and the complex

mappings required to yield various security models

and policy interoperability. We have exhibited a

proposal providing a secured framework for

information systems cooperation. This proposal tries

to give an appropriate answer to such complex

problems by combining a dynamic description of

local information sources and a global security

policy derived from the local ones.

The originality is in the mix of (i) a federated

architecture based on a rich descriptive layer

composed of object oriented metadata and (ii) a role-

based object model homogeneizing the local data

access security schemas (discretionary and non-

discretionary models).

Many questions are still in research phase: in

particular further work is required to evaluate the

impact of nested transactions during the query

resolution process to the security framework. A

validation phase for our description model is also

necessary to be sure it can cover almost any local

security policy at the local level.

ACCESS MODEL IN COOPERATIVE INFORMATION SYSTEMS

265

REFERENCES

Lampson B.W., Protection, Princeton Symposium of

Information Science and Systems. 1971.

Lunt T.F., Multilevel Security for Object-Oriented

Database Systems, Database Security III: Status and

Prospects, North-Holland, 1990.

Bell D.E., LaPadula L.J., Secure Computer System:

Unified Exposition and Multics Interpretation,

Technical Report MTR-2997, MITRE Corp., Bedford,

Mass, 1976.

Millen J.K., Lunt T.F., Security for Object-Oriented

Database Systems, IEEE Symposium on Research in

Security and Privacy, 1992.

Boulanger D., Disson E., Dubois G., Object-Oriented

Metadata for Secured Cooperation of Legacy

Information Systems, International Workshop on

Model engineering IWME’00, Sophia-Antipolis and

Cannes, France, 12-16

June 2000.

Nyanchama M., Osborn S., Modelling mandatory access

control in role-based security systems, Database

Security VIII: Status and Prospects. Chapman-Hall,

1996.

Boulanger D., Dubois G., An Object Approach for

Information System Cooperation, Information Systems

vol. 23, n°6, 1998.

Olivia M., Saltor F., Maintaining the Confidentiality of

Interoperable Databases with a Multilevel Federated

Security System in M. S. Olivier and D. L. Spooner

(Eds). Database abd Application Security XV. Kluwer

Academic Publishers, 2002.

Castano S., Martella G. and Samarati P., Analysis,

comparison and design of role-based security

specifications, Data & Knowledge Engineering 21,

1997.

Olivier M.S., A Multilevel Secure Federated Database,

Database Security VII, North-Holland, 1994.

Denning D.E., Secure Distributed Data Views: the Sea

View formal security model, Technical Report A003

SRI International, 1987.

Pernul G., Canonical Security Modelling for Federated

Databases, Interoperable Database Systems, North-

Holland, 1993.

Disson E, Boulanger D., Dubois G., A Role-Based Model

for Access Control in Database Federations, 3

International Conference on Information and

Communications Security, ICICS’01, Xian, China, 13-

16 November 2001, LNCS 2229 Springer Verlag.

Sandhu R. S., Munawer Q., How to do Discretionary

Access Control Using Roles, ACM Role-Based Access

Control Workshop, 1998.

Sandhu R. S., Role Hierarchies and Constraints for

Lattice-based Access Controls, Fourth European

Symposium on Research in Computer Security, Rome,

Italy, 1996.

Goyal M.L., Singh G.V., Access Control In

Heterogeneous Database Management Systems,

Computers and Security, 10(7), North-Holland, 1991.

Sandhu R.S., Coyne E.J., Feinstein H.L., Youman C.E.,

Role-Based Access Control Model, IEEE Computer,

Vol 29, n°2, 1996.

Jajodia S., Kogan B., Integrating an object-oriented data

model with multi-level security, IEE Symposium on

Security and Privacy, 1990.

Shet A.P., Larson J.A., Federated Database Systems for

Managing Distributed Heterogeneous and Autonomous

Databases, ACM Computing Surveys vol.22 n°3,

1990.

Jonscher D., Dittrich K.R., An Approach for Building

Secure Database Federations, Int.’l Conf. On Very

Large Databases, Santiago, 1994.

Keefe T., Tsai W., Prototyping the SODA Security Model,

Database Security III: Status and Prospects, North-

Holland, 1990.

Tari Z., Fernandez G., Security Enforcement in the DOK

Federated Database System, Database Security X,

1997.

Role

External

Student

Role

Medical

Team

DAC Group

Patient

Management

DAC Group

Medical

Role

Staff

Medical

File

Doctor

Medical

File

doctor

Dosage

Insurance

policy

Insurance

policy

Drug

DiseaseDisease

Patient

File t

Patient

File

write

read

≈

write

read

write

All

read

syn

≈

Public

Hospital

User

Smith

User

Wesson

depend

Private

Clinic

Role

External

Student

Role

Medical

Team

DAC Group

Patient

Management

DAC Group

Medical

Role

Staff

Medical

File

Doctor

Medical

File

doctor

Dosage

Insurance

policy

Insurance

policy

Drug

DiseaseDisease

Patient

File t

Patient

File

write

read

≈

write

read

write

All

read

syn

≈

Public

Hospital

User

Smith

User

Wesson

depend

Private

Clinic

Figure 5: An example of Global Schema

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

266
