LEARNING BY DOING AND LEARNING WHEN DOING

Dovetailing E-Learning and Decision Support with a Data Mining Tutor

Klaus P. Jantke, Steffen Lange

German Research Center for Artificial Intelligence, Saarbrücken, Germany

Gunter Grieser, Peter Grigoriev

Technical University of Darmstadt, Dept. Informatics, Darmstadt, Germany

Bernhard Thalheim

Christian-Albrechts-University of Kiel, Dept. Informatics, Kiel, Germany

Bernd Tschiedel

Technical University of Cottbus, Dept. Informatics, Cottbus, Germany

Keywords: E-Learning, Knowledge Discovery, Data Mining, Decision Support, Learning on Demand

Abstract: In this paper, e-learning meets decision support in enterprises’ business practice. This presentation is based

on an on-line e-learning system named DaMiT for the domain of knowledge discovery and data mining (see

http://damit.dfki.de). The DaMiT system has primarily been developed for technology enhanced learning in

German academia. It is now on the cusp of entering training on demand in enterprises. Simple stand-alone

e-learning seems quite unrealistic and does not meet the needs of industry. It is very unlikely that employees

take a detour to study theory of whatever sort. More likely, they are willing to engage in studies whenever

the need derives directly from their practical work. In those cases, they might even be willing to dive into

theory. How to dovetail e-learning and enterprise business applications, such that both sides benefit from it?

1 INTRODUCTION

There is no doubt at all that technology enhanced

learning is going to change education on all levels

ranging from schools over universities to profession-

nal training and lifelong learning. The process is

boosted by the Internet in pervading the world.

The recently observable progress in the area

named e-learning is enormous and ranges from a

flood of content (For illustration, the German Fed-

eral Ministry for Education and Research, BMBF,

has put about 200 Mio. Euro into 100 joint projects

to develop content for academic e-learning. Another

200 Mio. Euro went into schools and professional

education, all this within only 3 years.) to technolo-

gical innovations. We are all on the cusp of

inventing truly adaptive e-learning systems, based

on deep learner modelling, expressive XML-based

content representation and flexible, attractive and

appealing generation and presentation technologies.

There are still a number of open problems also in

technology, but the R&D community is very active.

In industry, however, one observes an obvious

reluctance. Employees tend to restrain from getting

involved in extra activities. Moreover, the

management frequently has understandable reser-

vations about introducing another software system

and further diversifying the IT infrastructure.

This situation bears abundant evidence for the

need of truly integrating e-learning into business

processes and IT infrastructures of enterprises.

Last but not least, the questions under discussion

are relevant to universities and other academic insti-

tutions when pondering about marketing potentials.

238

P. Jantke K., Lange S., Grieser G., Grigoriev P., Thalheim B. and Tschiedel B. (2004).

LEARNING BY DOING AND LEARNING WHEN DOING - Dovetailing E-Learning and Decision Support with a Data Mining Tutor.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 238-241

DOI: 10.5220/0002623602380241

 SciTePress

2 ALMOST AN EXCUSE

Due to the necessity to reduce the submission from 8

down to 4 pages, the authors refrain from any deeper

discussion of what data mining and decision support

are about. However, DaMiT is an e-learning system

facing the subject of data mining. Studies in this area

do require intensive learning by doing, and when

decision support in enterprises is ongoing, the

DaMiT system is offering a framework of integrated

learning on demand called learning when doing.

3 ACTIVE LEARNING IN DaMiT

This chapter contains a detailed discussion of

learning by doing in the DaMiT system. Chapter 4

is showing how to exploit the doing-oriented

features of the system for learning when doing,

e.g., in industrial settings, in governmental working

environments or in research institutes. To bridge this

gap is the aim of the present paper.

3.1 Observational Learning

Data mining may be considered both a science and

an art. When practicing the art of data mining, a

quite substantial amount of the underlying knowl-

edge is implicit. But how to transmit implicit

knowledge by means of e-learning? This is a parti-

cularly tough question if the teachers are not always

aware of the knowledge they are propagating when

being engaged in teaching. Sometimes, one says you

just need to get some feeling about it.

The problem of implicit knowledge is even more

important when the domain is a rather young one

and results are not matured, established publications

do not yet exist and teachers are not experienced, as

it usually applies to data mining.

The DaMiT system is equipped with several

“playgrounds” where learners can experience those

phenomena which are rather difficult to deal with

explicitly. Learners experience different phenomena

like, e.g., how very small changes in the input data

result in enormous changes of the classifier induced

or, alternatively, when substantial changes to the

data do not change the hypothesized classifier at all.

It is surely one of the highlights in education

when learners are able to pose interesting problems

to their teachers. Figure 1 displays an applet where a

learner can generate decision problems to be solved

by the DaMiT system in generating decision trees

over regular patterns. The learners provide the input

data, i.e. positive and negative examples, and the

system generates a certain decision tree with regular

patterns serving as tests in the nodes of the tree. The

learners can inspect the generated tree and, then, can

modify the posed learning problem according to

their ideas of how to make the learning task more

easy or more difficult to the system.

Figure 1: An Applet for Posing Tasks to the System

Observational learning of this type can not easily

be substituted by other learning forms. Data mining

always contains a phase of exploration.

3.2 Experiencing True Data Mining

There is not much hope for learning to swim or to

ride a bicycle when sitting on a sofa, only. Quite

analogously, there is not much hope for learning

data mining by reading text books or texts of some

web-based e-learning system like DaMiT, only. You

need to do it, and you need to do it properly.

The DaMiT system contains case studies as well

as what we call competitive exercises. Those

exercises are of the quality of practical data mining

problems. There is a continuous competition among

all learners in finding better and better solutions to

these problems.

Figure 2: A Competitive Exercise in DaMiT

LEARNING BY DOING AND LEARNING WHEN DOING: DOVETAILING E-LEARNING AND DECISION

SUPPORT WITH A DATA MINING TUTOR

239

4 LEARNING ON DEMAND

When in practice problems do arise which may be

explained or interpreted over large and usually

distributed data, the essence is rarely sufficiently

understood in the very beginning. Symptoms are

recognized, but a useful diagnosis may take some

time and may be laborious.

For illustration, an enterprise’s management may

recognize a growing number of customers cancelling

their business relations with that enterprise. A first

self-evident management decision might be to ask

somebody to look into the individual data and find

out the reasons. If this fails, what to do next?

Even if no pressing problems urge the manage-

ment to inspect larger data bases, certain desires for

cost reduction may lead to the wish of understanding

relations not properly understood so far. For in-

stance, if a mailing action in direct marketing shall

be more focussed than it used to be before, one

should find out which customers are very likely to

respond and which are not. Again, a self-evident

management decision might be to ask somebody to

look into the data and tell which customers are to be

addressed. If this fails, what to do next?

To have an appropriate e-learning system at the

management’s fingertips may help a lot. You can get

consulting about the general problem you are facing,

you can get knowledge about approaches and tech-

nologies, you can get tools for attacking your pro-

blem, and, finally, you can get support in evaluating

your own solution to the problem you have.

In a system like DaMiT, as seen above, you can

find problems similar to the one you are facing. And

you can get all this for free, because a large amount

of the e-learning content is open to the public.

Figure 3: A Case in Direct Marketing Optimization

More generally speaking, with a system like

DaMiT one can get consulting about the characteri-

stics of a problem, about basic variants and crucial

details to be considered, and about ways of how to

go forward towards a solution. This means already

learning when doing.

Assume that a problem like that of finding those

customers which are likely to respond to a mailing

activity is understood as a classification problem.

Let us further assume that the general principles of

decision tree induction are understood and believed

to be helpful. (If not, consult the system and learn

more about this area.) Then it is a management deci-

sion to go for generating a decision tree classifier

over the own data base.

In that case, data understanding and data prepa-

ration are inevitable steps. There is no hope at all to

take your data as they are and start learning any use-

ful classifier. In practice, this problem is generally

awkwardly underestimated. In enterprises, one may

study the lessons and try the tools for data under-

standing. Doing so means learning when doing.

If the tool has been chosen – we take QuDA, a

tool developed at TU Darmstadt, in the sequel, for

illustration – and the data are prepared, one can get

involved in the laborious process of interactively

generating a classifier.

Normally, one comes up with a first classifier,

inspects it and returns to the generation process.

Figure 4: QuDA in doing Decision Tree Induction

This figure is displaying the generation and in-

spection of a decision tree by means of QuDA over

the data of a realistic direct marketing case study.

There is a node of the decision tree highlighted and

all customers classified by this node are listed in the

window below.

A user should check whether he agrees with an

approximate classification like this. If not, he has to

return to the tree generation process.

Data mining tools offer different ways to take a

subtree of the classifier generated so far and con-

tinue model generation at the point picked up.

Following the exemplified procedure in an enter-

prise when dealing with the own problem on the

own data is not only the right way to solve a pro-

blem, it is also an instance of learning when doing.

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

240

Recall that data mining is both an art and a

science, and whatever we generate by means of data

mining technologies and tools, we only do arrive at

hypotheses. There can not be any guarantee at all

that models (like, e.g., decision trees) generated over

given data behave as successful as expected over

other data in the future.

There is a need to verify generated models. How

to do that appropriately, which alternatives do exist,

and what the results mean and how they are backed

up by statistics, can be studied in DaMiT – another

case of learning when doing.

Figure 5: Verifying a Generated Decision Tree

The present Figure 5 shows a verification result

for the decision tree of Figure 4 generated by means

of the C4.5 implementation of QuDA.

Once a model has been established, as shown in

Figure 6, it can be exported from the generation tool

and saved for use in the future.

Figure 6: A Solution to the Application Problem

XML standards like PMML allow for an integra-

tion into an enterprise’s IT infrastructure.

There is no closing sentence about learning when

doing, because in areas like knowledge discovery

and data mining, learning never ends. Systems like

DaMiT are further developed to support this type of

lifelong learning.

5 SUMMARY & CONCLUSIONS

On the one hand, the Internet in pervading the world

has changed our daily life, and it is currently

changing human learning at all stages ranging from

schools through higher education to training in

enterprises, research labs and governmental institu-

tions and to lifelong learning. Technology enhanced

learning is providing quite new opportunities.

On the other hand, there is the obviously eternal

gap between academia and practice which appears as

a certain reluctance to e-learning in practice.

Despite these obvious difficulties, we are at the

cusp of closing the gap. As exemplified in the data

mining domain, even academic e-learning has the

urgent need of doing, i.e. learning by doing. In

practice, for sure, there is the need of knowledgeable

doing which leads to learning when doing. Enter-

prise application integration will allow for a proper

dovetailing of learning and doing. Data mining may

be an area worth for doing it now.

The present paper is based on work of colleagues

and friends from 11 academic institutions and draws

benefit from many other partners using the DaMiT

system in their educational practice.

Note that as a courtesy to interested readers,

there is an extended version of this paper available

(see http://www.dfki.de/~jantke).

REFERENCES

Arikawa, S., Miyano, S., Shinohara, A., Kuhara, S.,

Mukouchi, Y., and Shinohara, T., 1993. A machine

discovery from amino acid sequences by decision trees

over regular patterns.

New Generation Computing, 11,

361-375.

Grieser, G., Lange, S. and Memmel, M., 2003. DaMiT:

Ein adaptives Tutorsystem für Data Mining. In Von e-

Learning bis e-Payment 2003, K.P. Jantke, W.S.

Wittig and J. Herrmann (eds.), infix, 192-203.

Grigoriev, P.A. and Yevtushenko, S.A., 2003. Elements of

an agile discovery environment. In 6th Int. Conference

on Discovery Science, DS 2003. G. Grieser, Y. Tanaka

and A. Yamamoto (eds.), Springer Verlag, LNAI

2843, 309-316.

Jantke, K.P., Memmel, M., Rostanin, O., Thalheim, B. and

Tschiedel, B., 2003. Decision Support by Learning-

On-Demand. In CAiSE Workshop 2003, Klagenfurt.

Linthicum, D., 2000. Enterprise Application Integration.

Addison-Wesley.

Thalheim, B. and Düsterhöft, A., 2001. SiteLang: Concep-

tual Modeling of Internet sites. In 20th Int. Conference

on Conceptual Modeling, ER'2001. SpringerVerlag,

LNCS 2224, 179-192.

LEARNING BY DOING AND LEARNING WHEN DOING: DOVETAILING E-LEARNING AND DECISION

SUPPORT WITH A DATA MINING TUTOR

241
