BAYESIAN NETWORK STRUCTURAL LEARNING FROM

DATA: AN ALGORITHMS COMPARISON

Francesco Colace, Massimo De Santo, Mario Vento

Dipartimento di Ingegneria dell’Informazione ed Ingegneria Elettrica, Università degli Studi di Salerno, Via Ponte Don

Melillo 1, 84084, Fisciano (Salerno), Italia

Pasquale Foggia

Dipartimento di Informatica e Sistemistica, Università di Napoli “Federico II”, Via Claudio, 21, 80125 Napoli, Italia

Keywords: Bayesian Networks, Structural Learning algorithms, Machine Learning

Abstract:

The manual determination of Bayesian Network structure or, more in general, of the probabilistic

models, in particular in the case of remarkable dimensions domains, can be complex, time

consuming and imprecise. Therefore, in the last years the interest of the scientific community in

learning bayesian network structure from data is considerably increased. In fact, many techniques

or disciplines, as data mining, text categorization, ontology description, can take advantages from

this type of processes. In this paper we will describe some possible approaches to the structural

learning of bayesian networks and introduce in detail some algorithms deriving from these ones.

We will aim to compare results obtained using the main algorithms on databases normally used

in literature. With this aim, we have selected and implemented five algorithms more used in

literature. We will estimate the algorithms performances both considering the network

topological reconstruction both the correct orientation of the obtained arcs.

1 INTRODUCTION

A Bayesian Network is a graphical model for

probabilistic relationship among a set of variables.

In the last period this modelling has become a

popular representation for encoding uncertain

knowledge in expert systems (Heckermann, 1995).

It could be useful and interesting to learn the

structure of Bayesian Networks given the data. The

main aim of structural learning algorithms is to

make clear the relationship between the entities of

the domain and to specify the causality ties starting

from the observations of domain variables values.

In very general terms the different learning

methods of probabilistic network structures from

data can be classified into three main groups

(Singh, 1995): some of these methods are based on

linearity and normality assumptions others are

more general but require extensive tests of

independence relations (Fung, 1990)(Pearl,1991);

others are based on a Bayesian approach (Cooper,

1992). In this paper a comparison between the

obtained results of some structural learning

algorithms is performed. With this aim we have

selected five algorithms among the most important:

the Bayesian algorithm (Heckermann, 1995), K2

(Cooper, 1992), K3 (Bouckaert, 2002), PC

(Spirtes, 2001) and TPDA (Cheng, 1997). The

paper is organized as follows: in the section 2 we

will describe the various approaches and the

general structure of an algorithm for the structural

learning. In the section 3 we will describe the

selected networks and the reference data sets. and

the obtained results. We will finish with a brief set

of conclusion.

527

Colace F., De Santo M., Vento M. and Foggia P. (2004).

BAYESIAN NETWORK STRUCTURAL LEARNING FROM DATA: AN ALGORITHMS COMPARISON.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 527-530

DOI: 10.5220/0002625305270530

 SciTePress

2 ALGORITHMS OF

STRUCTURAL LEARNING

The main aim of structural learning algorithms is

to point out the relations between the entities of the

domain and to specify the causality ties starting

from the observations of domain variables values.

In general, the structural learning algorithms can

follow two main research lines: a not Bayesian

approach (dependence analysis) and a Bayesian

approach (search and score). In order to infer

automatically the existence of dependence

relations between the domain variables algorithms,

that follow the not Bayesian approach, execute

statistical independence tests on the network data

set samples. Algorithms based on Bayesian

approach codifies the uncertainty on the structure

of a dominion X = {X

,...,X

} introducing an

aleatory variable M. The states of this aleatory

variable represent the possible structures

associated to X. After this phase the algorithm

chooses the model m that maximizes the “a

posteriori” probability P(m|D), where D is the data

set. In the next paragraphs we will describe in

detail the main characteristics of five algorithms

that we aim to compare. These algorithms are the

most important in literature representing the main

approaches in the structural learning field.

2.1 The Bayesian algorithm

The bayesian algorithm resolves the problem of the

Structural Learning from data determining the

structure m that maximizes the probability p(M =

m|D), where M = {m

, ...,m

} is a set of models

that contains the true model of a domain X, D is

the set of the samples. According this approach if

we have two models m

and m

representing the

domain X, we will choose m

if p(m

|D) > p(m

|D).

So we choose as scoring function the logarithm of

p(D|m) that with simple passages becomes equal

to: Score(m) = log (p(m|D)) =

log(p(m))+log(p(D|m))-log(p(D)) =log(p(D|m)).

The introduced approximation is acceptable

because both log(p(D)) both the prior knowledge

on the model, log(p(m)), in the hypothesis of

complete “a priori” ignorance on the domain

structure, are constant values. The statistical

criterion of reference is the Maximum Likelihood

while if the contribution of log(p(m)) is not

negligible the algorithm can use the Maximum a

Posteriori (MAP) principle. In this paper we will

refer to the algorithm based on a “model selection"

approach and will make also the hypothesis that

the best model has the maximum of the distribution

p(m|D) localized around a model µ. In order to

select the µ we introduce a function whose value is

higher when the model m is closer to µ.

2.2 The K2 algorithm

This algorithm derives from a bayesian algorithm

in which the assumption of complete ignorance on

the probability distribution of the models is made

(Cooper, 1992). The K2 procedure differs from a

typical bayesian algorithm also for the

initialization phase: while in the bayesian approach

we could use a starting graph with the “a priori”

knowledge of an expert that can describe a starting

topological ordering (from fathers to sons nodes)

of the nodes. In fact this information reduces the

cardinality of the searching space of the models. In

this approach the scoring function is defined as:

∏

iiss

XgBPDBp

),()(),(

where D is a data

set of the

m complete cases and B

is the structure

of a bayesian network. The function g(X

,π

)

represents the variations obtained in the scoring

function after the introduction of a new

dependence relation so of a new father node for X

The core of this approach is a greedy search

algorithm where at its beginning no nodes have

fathers. A real disadvantage of this approach is the

impossibility of delete an arc after its introduction

in the network.

2.3 The K3 algorithm

This type of algorithm, introduced in the paper

(Bouckaert, 2002), is based on a bayesian

approach, but as in K2 algorithm gives a new

definition for the scoring function. In this case the

scoring function is based on the Minimum

Description Length (MDL) metric. The MDL

approach is so formalized: the learned network

must minimize the total description length defined

as: the description length of the samples and the

description length of a pre-existent network

structure supplied from an expert or generate in a

previous process of learning In this approach

samples and pre-existent network structure are

independent in order to elaborate them separately.

The scoring function in this approach is so defined:

where B represents a possible structure, D is the n

samples of data set, the value r

represents the

states number of node X

is the number of

possible configurations of father nodes for each

111

(, ) log(()) * (, ) log( )

( , ) log( )

(1)

ijk ijk

ijk

LBD PB N HBD k N

HBD

kqr

===

=+ −

=−

∑∑∑

=−

∑

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

528

node X

and N

ijk

are the occurrences in D of X

with

state k and fathers configuration j.

2.4 The PC algorithm

This algorithm is based on a constraint satisfaction

approach (Spirtes, 2001). The PC procedure

consists of an initialization phase where a fully

connected DAG, associated to a domain X, is set

up and an iterative phase that searches the implicit

relations of independence between the samples. In

every iteration we consider a set C(X,Y) of

adjacent nodes to X without Y with cardinality

greater or equal to the current n value. So for every

subset S, with cardinality n and extracted from C,

the algorithm carries out the order n statistical test

in order to determine if X and Y are d-separated

from S. In the affirmative case the arc X-Y is

removed and a new S set is examined with the

same procedure. After the investigation of all

possible S in C the n value is increased and the

algorithm is repeated until C has cardinality greater

or equal to n. In order to determinate the arcs

orientation the algorithm uses consideration based

on conditional independence.

2.5 TPDA Algorithm

The TPDA algorithm is a dependence-based

algorithm. It divides the process of learning in

three phases: Drafting, Thickening and Thinning.

The Drafting phase produces an initial relations set

through test on cross entropy value between the

variables of the domain. After this phase we obtain

a graph where it is present only a path between two

nodes. The second phase, "thickening", adds arcs

to the single connected graph if it is not possible to

d-separate two nodes. The resulting graph contains

all arcs of the true model and some extra-links.

These false arcs are produced by errors in the test.

The third phase, "thinning", consists in the

examination of all arcs and its exclusion if the two

nodes are conditionally independent. At the end of

this phase the algorithm orients arcs with an

approach similar to PC algorithm.

3 EXPERIMENTAL RESULTS

The main idea of this paper is to compare some of

most important structural learning algorithms. We

have implemented all algorithms previously

described and we have tested them using seven

bayesian networks and their relative datasets. A

briefly description of networks and datasets is

showed in the next paragraph.

3.1 Test Networks description

We have selected seven networks and their related

dataset in order to test the algorithms previously

described. In table 1 there is a briefly description

of all selected networks and related datasets.

Table 1: Analysed Networks and Datasets

Network Name

Nodes

Number

Arcs

Number

Data Set

Samples

Alarm (Pearl, 1991) 37 46 10.000

Angina (Cooper, 1992) 5 5 10.000

Asia (Glymour, 1987) 8 8 5.000

College (Singh, 1995) 5 6 10.000

Led (Fung, 1990) 8 8 5.000

Pregnancy (Buntime, 1996) 4 3 10.000

Sprinkler (Suzuki, 1999) 5 5 400

We used the previously described algorithms on

these networks. We have experimented the

algorithms using two different sorting for the

nodes of the networks: ordered (correct sorting of

node starting from fathers to sons) and inverse. We

have choosen two different sorting in order to test

in any case the performances of algorithms. We

have defined two indexes:

Topological Learning =

Correct Arcs

Correct Arcs+ Missing Arcs+ Added Arcs

∑

∑∑ ∑

Global Learning =

Correctly Oriented Arcs

Correctly Oriented Arcs+ Wrongly Oriented

Arcs+ Added Arcs+ Missing Arc

∑

∑∑∑∑

The first index measures the ability of the

algorithm in the learning of correct topology of the

net. The second index, instead, measures the ability

of the algorithm in the learning of correct networks

(topology and correct orientation of arcs). In

figures 1 and 2 we have depicted the average

indexes values obtained by every algorithm in the

learning processes of the various networks. In

figure 1 we have the results for ordered nodes with

and in figure 2 the results for inverse nodes.

Algorithms that are based on a scoring function

maximization approach have the best results in the

case of ordered starting structure. In particular the

K2 algorithm has the best performance: 88% as

topological index and 88% for the global index.

The constraint-based algorithms have the worst

results and show an important difference between

the two indexes (18% for PC and 24% for TPDA).

So we can say that these algorithms also when are

able to identify the topology of the network often

BAYESIAN NETWORK STRUCTURAL LEARNING FROM DATA: AN ALGORITHMS COMPARISON

529

mistakes on the orientation of the arcs. On the

other hand, if we use inverse nodes sorting the

bayesian algorithm, in particular K2 and K3,

deteriorate their performances: 29% for

Topological Learning index and 67% for Global

Learning index for the K2 algorithm and 27% for

Topological Learning index and 67% for Global

Learning index for the K2 algorithm. In particular,

they are not able to learn the correct topology: arcs

and their orientations. The performances of

constraints based algorithms remain fundamentally

the same.

4 CONCLUSION

In this paper we have described some algorithms

for the structural learning of Bayesian networks.

We have selected five algorithms able to represents

the most important and common approaches that

are present in literature. We have implemented,

according the authors specifications, these

algorithms and we have tested them on the most

common datasets. We have made experimentations

in two different ways: ordered and inverse starting

nodes sorting. We can say that in the case of

correct starting nodes sorting algorithms based on

a Bayesian approach and more in general on the

maximization of a predefined scoring function

obtain better results than algorithms based on

statistical independence tests. On the other hand

these algorithms have a more stable behaviour to

nodes sorting. An interesting future work could be

a complete characterization of examined

algorithms trying to make clear the relationship

between the starting sorting of the networks nodes

and learned networks.

REFERENCES

Singh, M., Valtorta, M., 1995. Construction of Bayesian

Network Structures from Data: a Brief Survey and

an Efficient Algorithm. In International Journal of

Approximate Reasoning

Fung R. M., Crawford S. L., 1990. Constructor: a

System For The Induction of Probabilistic Models.

In Proceedings of AAAI-90

Pearl J., Verma T., 1991. A Theory of Inferred

Causation, In Principles of Knowledge

Representation and Reasoning, Morgan Kaufmann

Cooper G. F., E. Herskovits, 1992. A Bayesian Method

For The Induction of Probabilistic Networks From

Data, In Machine Learning, 9

Buntime W., 1996. A Guide to the Literature on

Learning Probabilistic Network from Data, In IEEE

Transaction on KDE, vol. 8, no. 2

Suzuki J., 1999. Learning Bayesian Belief Networks

Based on the MDL Principle: an Efficient Algorithm

Using the Branch and Bound Technique, In IEICE

Trans. Inf. & Syst., Vol. E82

Bouckaert R., 2002. Probabilistic Network Construction

Using the Minimum Description Length Principle,

Lecture Notes in Computer Science, Vol. 747

Spirtes, P., Glymour, C., Scheines, R, 2001. Causation,

Prediction and Search, In MIT press

Cheng , J., Bell, D., Liu, W., 1997. Learning belief

networks from data: an information theory based

approach, In Proceedings of the Sixth ACM

International Conference on Information and

Knowledge Management

Heckermann, D., Geiger, D., and Chickering, D., 1995.

Learning Bayesian Networks. In The Combination of

Knowledge and Statistical Data. Machine Learning,

20(3)

APPENDIX

Figure 1: Topological and Global Average values

obtained using ordered data sets

Figure 2: Topological and Global Average values

obtained using inverse data sets

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

530
