TURNING INFORMATION INTO ACTIONS

From Data to Business Processes through Web Services

Youcef Baghdadi

Department of Computer Science, Sultan Qaboos University, Po Box 36 Al Khod 123, Muscat, Oman

Keywords: Business Model - IS - Factual Dependency - Web Services - Business Process - B2B Integration.

Abstract: Sharing Web services across the enterprise

and to support B2B integration becomes more intensive and

critical for businesses. This paper proposes a process to generate Web services from the attributes

describing the business objects and the coordination artefacts as described in the highest abstraction level of

a business model i.e. the universe of discourse where the elements are unique. The process is based on a

new concept we introduce and call factual dependency. Factual dependency is a mechanism used to

aggregate attributes that are concerned by the same DB CRUD operations with respect to the time and the

space. Factual dependencies are then validated with regard to the possible business events to keep only the

relevant ones. Each distinct and valid factual dependency is specified in terms of input/output parameters to

generate a lowest level of granularity Web services. These Web services are then registered to be discovered

and (re)used at request by business processes in their reengineering or composition.

1 INTRODUCTION

The information system (IS) is a representation of

the business. This representation is used to control

the business. It mainly consists of data, applications

and middleware.

Nowadays, there exit various models to construct

ata, and tools to build and integrate applications.

However, we are still facing issues such as: (1) What

is a business process or exactly what level of

granularity we consider when we define a business

process? (2) Which business processes are

implemented by the applications? (3) Why do we

need to integrate applications and which types of

middleware are used? (4) How do we proceed to

integrate? (5) What are the business objects

represented by data? (6) How business objects are

related to business processes and vice-versa?

These issues are resulting from a misunderstanding

of t

he model (if any) used to abstract the business,

namely the abstraction levels and the

relationships/interfaces between them (Bubenko,

1994). Firstly higher and lower abstract levels are

described with different languages. Secondly, the

lower levels are more complex than the higher ones

as they contain more description details. For

instance, a customer may be a physical person or an

organization at the higher abstraction level (universe

of discourse), and various heterogeneous

representations in a lower level (IS) such as different

DB tables, flat files, or XML.

Accordingly, we propose a process to derive

busi

ness processes by composition of Web services

from only the knowledge a business has on its

perpetual elements at the highest level. These

elements are: (i) the business objects such as

products, parts, accounts, or partners/suppliers; and

(ii) the states of the coordination artefacts used by

the business processes. Indeed, these elements, with

simple semantics, are sound. That is, the knowledge

in terms of attributes we have on these elements are

sufficient to determine the business events they

undergo or trigger. Each business event involves

many operations. The chain of operations forms a

business process. We are interested only on database

CRUD operations to allow a lowest level of

granularity we can master without any ambiguity.

Each distinct and specified operation in terms of

input/output parameters generates a lowest level of

granularity Web services. The Web services are

registered to be further discovered and (re)used at

request by business processes. Accordingly, we can

dynamically compose business processes at request

by using the registered Web services.

This process is based on the concept of factual

depe

ndency we define as: ‘an attribute Y is factually

dependent on an attribute X if they are concerned by

the same CRUD operation’. A factual dependency

570

Baghdadi Y. (2004).

TURNING INFORMATION INTO ACTIONS - From Data to Business Processes through Web Services.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 570-574

DOI: 10.5220/0002631005700574

 SciTePress

between attributes, describing the elements of the

universe of discourse, allows us an aggregation of

the attributes concerned by the same business event.

2 BUSINESS MODEL

A business is an open system that seeks some goals

or responds to events. It consists of: (1) Business

Events, Input, and Output, (2) Production System,

(3) Logistic System, (4) Partners, (5) Business

Management/Control System, and (6) IS. These

components may be classified as components of the

universe of discourse, components of the enterprise

IS or components of the business management

system.

Business events, input/output, production system,

logistic system and partners are parts of the universe

of discourse. The universe of discourse contains four

types of elements: (1) Perpetual tangible as well as

intangible elements. We call them business objects

(BO). (2) The business events (BE) which are the

elements characterized by the space, the time and the

effect they have on the business objects or the

coordination artefacts. (3) The business processes

(BP) that transform business event/input into output

are the decompositions of the value chain. (4) The

Coordination artefacts (CA) used to coordinate and

interface the BP.

BO, BE, BP and CA are differently represented in

the enterprise IS.

The enterprise IS is a technology-based

representation of the elements of the universe of

discourse. This representation consists of data,

applications and middleware. Hence, it should

contain only one representation of each element as

defined in the universe of discourse. However, the

actual enterprise IS contains different

representations of the same element. This is due to

our different intuitions and perceptions of the reality,

different languages we use, and the variety of

technologies. For instance, a customer may be

perceived as an account or a partner. A track of this

perception is kept in different DB tables, files or

XML. Similarly, a BP is differently implemented

(e.g. application, components, objects or manual).

This representation breaking requires integration for

multiple reasons namely: (i) the need of

reconstructing the entire representation and (ii) some

BP involve more than one partner.

It is clear that the elements of the universe of

discourses are unique. That is, we have only the

original there is no clone. If we damage or lose an

element, we cannot reconstitute it. Whereas, the

elements of the enterprise IS have various

representations. That is, we may have various

technology-based copies of the same element. If we

damage or lose the copy, we can reconstitute it.

Integrating elements in the enterprise IS is more

complex; and mostly influenced by IT rather than

business perspectives. This is especially more

evident in the case of e-business, where new BP are

innovated, reengineered, or completely built from

scratch to respond to specific BE.

We propose a method to dynamically compose or

reengineer BP by using the registered . It is based on

the concept of factual dependency, which we detail

in the next two sections.

3 FACTUAL DEPENEDENCY

Our approach to turn data into BP through Web

services is based on the concept of factual

dependency between attributes of the BO or CA as

they are described in the universe of discourse.

3.1 Definition of Factual Dependency

A factual dependency is a dynamic-oriented

constraint between two attributes X and Y

describing the same element or distinct elements of

the universe of discourse. The constraint stipulates

that two values x of X and y of Y are

inserted/update/deleted/retrieved when a BE occurs.

An attribute Y is factually dependent on an

attribute X if the attributes X and Y are concerned

with the same CRUD operation. A factual

dependency is denoted X Î Y.

The concept of factually dependency allows an

aggregation of the attributes describing the elements

of the universe of discourse with respect to the BE

they undergo. That is, the attributes having the

values inserted, deleted, updated or retrieved by the

same BE are grouped together.

In a nutshell, each combination of attributes may

lead to an operation, which is particularly true for

retrieve operation where each possible project

operation (in the sense of the relational algebra).

Therefore, criteria to select relevant combinations

are required. These are the relevant BE.

3.2 Rules for Factual Dependencies

The concept of factual dependency is different from

the well-known concept of functional dependency

used in the relational schema design (Codd, 1990).

Therefore, the inference rules of the functional

dependency are not applicable for the factual

dependency, except the reflexive rule. However,

TURNING INFORMATION INTO ACTIONS: FROM DATA TO BUSINESS PROCESSES THROUGH WEB

SERVICES

571

factual dependencies respect certain rules, which

are:

• Rule 1: Reflexivity

X Î X

• Rule 2: Non-Augmentation

X Î Y does not automatically imply XZ Î YZ

• Rule 3: Non-Transitivity

X Î Y and Y Î Z does not imply X Î Z

• Rule 4: Commutative

X Î Y then Y Î X.

If the attributes X and Y are concerned by a CRUD

operation o1 then Y and X are concerned by the

same operation o1.

• Rule 5: Business events generation

X Î Y may lead to more than one BE.

Assume that the BO customer is described by the

attributes: name, address, balance, and mode of

payment. The distinct aggregations are as shown in

Table 1.

FD1: {Name, Address, Balance, Mode} is used for

new customer.

FD2: {Name, Balance} is used in two kinds of

operations: update and retrieve. For the update

operations, it is used when the BE ‘customer order’

occurs. It is also used when the BE ‘customer pays’.

For the retrieve operation, it is used to inquiry the

balance in order to trigger a BE. The rule 5 that

stipulates that a factual dependency may generate

more than one BE is applied.

FD3: {Name, Address} is used to update the

customer address when the BE ‘customer changes

address’ occurs.

FD4: {Name, Mode} is used to update the mode

of payment in different BE occurrence.

That is, we may have the same aggregation

concerned by many CRUD operations. Each

operation correspond to a distinct BE.

Theoretically, each combination of attributes is a

factual dependency that leads to an operation.

However, not all the factual dependencies are

relevant. We will consider only those corresponding

to the actual pertinent BE. A CRUD operation is not

applied if there are no BE occurring in the universe

of discourse. We update (create, modify or delete)

the states of the elements when BE occur. Similarly,

we attempt to retrieve information about BO or CA

in order to trigger BE or to assist us in performing

operations. However, there is a myriad of BE that

occur. We consider only those BE which occurrence

has an effect on the BO or CA. Hence, the relevant

BE are deductible from the factual dependencies.

BO and CA are defined by attributes and BE

they undergo or trigger in a similar way than the

objects of the object-oriented paradigm are

described by attributes and operations. To validate

the set of generated factual dependencies that will

lead to Web services, we confront each factual

dependency to an actual BE.

3.3 Web Services Generation

A Web service provides a standard way for any user,

through an application, to access BO and CA.

Indeed, once we keep track of a representation of

BO and CA in a legacy DB, a flat file or XML DB,

the Web services can access it via a simple CRUD

operation (e.g. stored procedure in the case of the

relational database). A Web services in turn is

accessed by any application (e.g. Java application

running on a Web server) that presents information

to end-user.

The specification of the Web services can be

generated from a set of valid factual dependencies.

Indeed, rule 5 stipulates that each factual

dependency may generate 1:N Web services (Fig1).

To keep a lowest level of granularity, each factual

dependency leads to 1:N operations depending on

the number of BE related to this factual dependency.

Each operation will require input/output parameters.

4 TURNING DATA INTO BP

The process of turning data into BP consists of:

Part 1: Turning data into Web services

This part consists of the following steps:

Step 1: Selection of BO and CA

Step 2: Description of BO and CA

This consists of defining, in terms of attributes, what

knowledge we need to use about BO and CA.

Step 3: Exhaustive list of factual dependencies

related to the set of attributes describing BO and

CA:

(i) Generate the factual dependencies by combining

the attributes.

(ii) Deduce the relevant factual dependencies by

confronting them to the business events as they may

occur in the universe of discourse (table 2).

(iii) Specify each factual dependency as a CRUD

operation with a focus on the input/output

parameters.

(iv) Implement, in the IS, the operations related.

This implementation may be a program, a stored

procedure, a component, an object, Java Bean, etc.

Step 4: Generation of Web services corresponding to

these operations.

This step is easy since the operations are specified in

term of input/output parameters. We can use a

CASE tool or any other tool at this stage to

automatically generate the Web services (e.g.

www7b.boulder.ibm.com/dmdd/library/tutorials/030

8freeze/0308freeze-2-1.html).

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

572

Step 5: Registration of the generated Web services.

The resulting Web services are registered in a

registry and discovery artefact so that it can be easily

discovered.

Part 2: Composition of the Web services onto BP

This part consists of the following steps:

Step 1: Identification of the BE

From the universe of discourse, identify the relevant

BE such as ‘customer order’.

Step 2: Description of the flow of the actions

corresponding to the BE (e.g. business rules).

Each BE triggers a set of actions with a particular

flow. These actions begin with the capture of the

event to the production of an output. We can use

tools to model the flow (e.g. BPEL4WS).

Step 3: Identification of the actions involving CRUD

operations.

The automated actions correspond generally to a set

of CRUD operations.

Step 4: Matchmaking between the operations and the

registered Web services.

Step 5: Replace in the flow (BPEL4WS) the CRUD

operations by their Web services.

Part 2 of the process is triggered by any new BE, a

B2B perspective, or when re-engineering the

existing BP.

5 RELATED WORK

The problem of integration is addressed in a number

of different ways through schema integration of

heterogeneous databases (Batini et al. 1986),

interoperability (e.g., COBRA, DCOM, RMI,

JDBC), e-Services (L. Wong, 2001), to the Web

services (Box, 2003; Chen et al., 2003; Kreger,

2001) and their composition (Jablonski, 2003 ;

Leyman, 2002) in order to integrate the applications

involved in the business processes. Each of them is

concerned with a specific aspect of the problem.

In the last three years, the object-oriented paradigm

has been extended with the introduction of Service-

Oriented-Architecture (SOA) model, which helps to

separate business intent from IT implementation.

This allows a sharing of business services across the

enterprise and to support B2B initiatives. The e-

services model is composed of a set of business

services, a set of business components, a set of IT

elements, and a set of business rules.

The approach described in this paper is in touch with

the e-services model, however, it is mainly based on

the factual dependency at the highest abstraction of a

business to determine Web services that enter in the

composition of any business process. The Web

services definition and specification are not intuitive

to the analyst for less ambiguity.

6 CONCLUSION

This work considers that traditional approaches for

integration are more IT-oriented, that is they are

proposed from an IT perspective not from a business

perspective. They focus on the complex elements of

the IS, which makes the integration task harder. Our

approach allows generation of de facto standards

Web services that facilitate the integration, from the

highest abstraction level (universe of discourse)

where the elements namely the business objects and

the coordination artefacts are easy to capture with

less analyst intuition. The Web services are

generated from valid factual dependencies regardless

of the business processes which will use or reuse

them in their composition.

This is a significant issue nowadays where

organizations are looking to sharing Web services

across the enterprise, to support B2B integration,

and to reengineer or compose business processes,

which is more and more intensive and critical for a

business survival.

We will develop after a global architecture and a

supporting tool that allows organization to really

turn information into action.

REFERENCES

Batini C., Lenzirini M. and. Navathe S.B. (1986). A

Comprehensive Analysis of Methodologies for

Database Schemas Integration. ACM Computing

Surveys, 18(4), 322-364.

Box,B., The Web Services Revolution,

http://www.eds.com/thought/thought_leadership_web

_revolution.pdf, 2003

Bubenko J., Enterprise Modeling, Ingenierie des Systems

d’Information, 2(6) 1994

Chen M., Chen A. K. N and Shao B. B. M, Implications

and Impacts of Web services to Electronic Commerce

Research and Practices, Journal of e-Commerce, Vol

4. No 4. (2003), pp 128-139

Codd E. , Relational Model for Data Management Version

2. Addison~Wesly, 1990

http://www7b.boulder.ibm.com/dmdd/library/tutorials/030

8freeze/0308freeze-2-1.html

Jablonski S. and Petrov I., Web Services, Workflow and

Metadata Management as the Means in the Eletrocnic

Collaboration Era, ICEIS 2003, Angers/France.

Kreger H., Web services: Conceptual Architecture

(WSCA 1.0), IBM Software Group, May 2001

Leyman F., and Roller D., A Quick Overview of

BPEL4WS, IBM Developer Work, August 2002

Wong L., e-Services: A Key Component for Success, eAI

Journal, March 2001, pp 18-25

TURNING INFORMATION INTO ACTIONS: FROM DATA TO BUSINESS PROCESSES THROUGH WEB

SERVICES

573

Table 1: Factual Dependencies as Aggregation of Customer Attributes

Factual

Dependency

Attribute

CRUD Operation

Name Address Balance Mode Comment

FD 1 Create

X X

X X Their values are

inserted together

FD 2 Update

Inquiry

X X Balance is updated

in distinct occasion

and also queried in

distinct occasions

FD 3 Update X X Changing the

address

FD 4 Update X X Changing the mode

of payment

Table 2: Factual Dependencies and Corresponding Business Events

Factual

Dependency

Attribute

CRUD Operation

Name Address Balance Mode Business Event

FD 1 Create

X X

X X New Customer

FD 2 Update

Inquiry

X X Order/Payment

Balance Inquiry

FD 3 Update X X New address

FD 4 Update X X Change Mode

Factual Dependency

M:N

Business Event

Figure 1: Relationship between Factual Dependencies and Business Events

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

574
