MANAGING WEB-BASED INFORMATION

Marco Scotto, Tullio Vernazza

DIST – Università di Genova,Via Opera Pia, 13, I-16145 Genova, Italy

Alberto Sillitti, Giancarlo Succi

Libera Università di Bolzano, Piazza Domenicani, 3, I-39100 Bolzano, Italy

Keywords: Web Mining, Information Retrieval

Abstract: The heterogeneity and the lack of structure of World Wide Web make automated discover

y, organization,

and management of Web-based information a non-trivial task. Traditional search and indexing tools provide

some comfort to users, but they generally provide neither structured information nor categorize, filter, or

interpret documents in an automated way. In recent years, these factors have prompted the need for

developing data mining techniques applied to the web, giving rise to the term “Web Mining”. This paper

introduces the problem of web data extraction and gives a brief analysis of the various techniques to address

it. Then, News Miner, a tool for Web Content Mining applied to the news retrieval is presented.

1 INTRODUCTION

The World Wide Web has become a huge source of

information, but its content cannot be manipulated in

a general way due to two main issues:

 Fi

nding relevant information is a difficult

task beca

use the web is unstructured. Search

engines, such as Altavista, Google, Lycos

and many others, provide some comfort to

users, but their query facilities are often

limited and the results come as HTML

pages

 Mo

st of the information, present on the web,

s stored as HTML pages. HTML is a semi-

structured format designed to describe the

layout of web pages not their content, and

machines hardly process HTML.

These factors have prompted the need for

devel

opi

ng data mining techniques applied to the

web, giving rise to the term “Web Mining”. This

paper introduces the problem of the extraction of

information from the web and analyzes the various

techniques to approach it. Then, it presents News

Miner, a tool for news extraction, integration and

presentation, based on Web Content Mining. News

Miner is a server side application that periodically

scans a set of news sites, integrates news building a

repository, and makes them available to an

application server that use such information to build

user-specific web pages. In particular, it organizes

HTML documents, which are semi-structured, into

structured XML documents, using XSLT

(eXtensible Stylesheet Language Transformation)

and XPath (XML Path Language). This paper is

organized as follows: section 2 introduces Web

Mining; section 3 analyzes the different types of

Web Mining; section 4 describes the design and the

implementation of News Miner; finally, section 5

draws the conclusions.

2 WEB MINING

Web Mining can be broadly defined as “the

discovery and analysis of useful information from

the World Wide Web” (Madria et al., 1999). In Web

Mining, data can be collected at different levels:

server side, client side, proxy servers, or obtained

from an organization’s database. For instance, data

can be stored in browser caches or in cookies at

client level, and in access log files at server or proxy

level. Web Mining can be decomposed into four

575

Scotto M., Vernazza T., Sillitti A. and Succi G. (2004).

MANAGING WEB-BASED INFORMATION.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 575-578

DOI: 10.5220/0002633005750578

 SciTePress

subtasks, according to Etzioni (Etzioni, 1996). Each

task is discussed in the next paragraphs.

2.1 Information Retrieval

Information Retrieval deals with automatic

discovery of all relevant documents satisfying a

specific query. Most of the work on information

retrieval focuses on automatic indexing of web

documents. However, web pages indexing is not a

trivial task if compared to database indexing where

there are well-defined techniques. The huge number

of web pages, their heterogeneity, and frequent

changes in number and content make this task very

difficult. At present there are several search engines

for querying and retrieve web documents, each one

has a unique interface and a database, which covers

a different fraction of the Web. Their indexes have

been created and constantly updated by web robots,

which scan millions of web pages and store an index

of the words in the documents.

2.2 Information Extraction

Once the documents have been retrieved, the

challenge is the automated extraction of knowledge

from the source without any human effort. At

present most of the work in information extraction is

carried out by wrappers built around web sources. A

wrapper is a special program, which accepts queries

about information present in the pages of the source,

extracts the requested information and returns the

result. But it is impractical to build wrappers for web

sources by hand for several reasons: the number of

web pages is very large, a lot of new pages are

frequently added and the format of web pages often

changes. Ashish and

Knoblock (Ashish and

Knoblock, 1997) propose an approach to semi-

automatically generation of wrappers for Web

sources.

2.3 Generalization

Once automated the discovery and extraction

processes from web pages, the next step is the

generalization from the experience. This phase

involves pattern recognition and machine learning

techniques. The bigger obstacle in learning about

web is the large amount of unlabelled data. Many

data mining techniques require inputs labelled as

positive or negative examples with respect to some

concept. Fortunately, clustering techniques do not

require labelled inputs and have been applied

successfully to large collections of documents. Other

techniques, used in this phase, are association rules.

They allow the discovery of all associations and

correlations among data items where the presence of

one set of items in a transaction implies, with a

certain degree of confidence, the presence of other

items.

2.3 Analysis

Analysis is a data-driven problem where humans

play an important role for validation and

interpretation of the results. Once patterns have been

discovered, analysts need suitable tools to

understand, visualize, and interpret these patterns.

One technique is represented by OLAP (On Line

Analytical Process), which uses data cube structure

for simplifying visualization of multidimensional

data. Some others (Mobasher et al., 1997) proposed

an SQL-like language for querying the discovered

knowledge.

3 WEB MINING CATEGORIES

Web Mining includes three areas, based on which

part of the Web mine:

 Web Content Mining (WCM),

 Web Structure Mining (WSM),

 Web Usage Mining (WUM).

The distinctions among the above categories are

not clear-cut; the three Web Mining tasks could be

used in isolation or combined in an application. An

overview of each category follows.

3.1 Web Content Mining

The aim of the WCM is the automation of the

process of information discovery and extraction

from Web documents and services. Mainly, there are

two approaches to solve this problem (Cooley et al.,

1997):

1. Agent Based approach: “it involves

artificial intelligence systems that can act

autonomously or semi-autonomously on

behalf of a particular user, to discover and

organize Web-Based information”.

2. Database approach: “it organizes

heterogeneous and unstructured or semi-

structured data into more structured data,

such as relational database, and using

standard database querying mechanism and

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

576

data mining techniques to access and

analyze this information”.

3.2 Web Structure Mining

Web Structure Mining (Kleinberg, 1998) tries to

extract information from the link structures of the

web. The web can be modelled as a graph where

Web pages are the vertices and hyperlinks are the

edges. WSM categorizes Web pages and extract

information, such as the similarity and relationship

among different Web sites. For example, links

pointing to a document offer an index of the

popularity of the document (authority site), while

links coming out of a document offer an index of the

richness or the variety of topics covered in a

document (hub site).

3.3 Web Usage Mining

While the two others techniques use the real or

primary data on the web, Web Usage Mining

(Srivastava et al., 2000) mines secondary data

generated by users interactions with the web. Web

usage data includes data regarding web server

access, logs, proxy server logs, browser logs, and

any other data generated by the interaction of the

users and the web. WUM is the “process of applying

data mining techniques to the discovery of usage

patterns from Web data”. The knowledge extracted

can be used to achieve different goals such as

service personalization, site structure, and web

server performance improvement.

4 NEWS MINER

News Miner is a server side application that

periodically scans a set of news sites defined by the

system administrator, integrates news building a

repository, and makes them available to an

application server. News Miner is based on the

Service Oriented Architecture (Sillitti et al., 2002);

in particular, it exploits news services available on

Internet to provide an integrated news service. The

system is completely written in Java, using open

source libraries (Apache Xalan, Apache Xerces,

etc.), and standard W3C communication protocols

(HTML, XML, etc.). The architecture includes three

main components (Fig. 2): a News Retriever, a News

Repository, and a Data Provider.

Figure 1: News Miner architecture

4.1 News Retriever

The News Retriever reads the configuration file and

queries the web sites of selected news providers. It

extracts news information, classifies news and stores

them into a News Repository. This phase includes

two main subtasks: News Extraction and News

Integration.

The News Extractor downloads news web pages,

extracts data and produces an XML document. The

downloaded documents are often not well-formed

HTML documents. Errors are corrected using an

HTML lint that produce XHTML (eXtensible

HTML) documents which are always well formed.

An XHTML document is an XML document that

can be processed using standard processing tools

such as XSLT processors. Then, the News Extractor

applies an XSLT transformation to the document to

extract relevant data (Fig. 3) that the News

Integrator collects as XML documents. The process

is performed for each news provider that supplies

the selected category, according to the configuration

file. System administrator provides the

transformation style sheets for each news provider at

configuration time. The News Integrator performs

categories merging of different news providers.

Technologies involved in this step are DOM

(Document Object Model) and XPath. At the end of

the two processes, the system produces a news

repository: a set of XML documents analyzable

through standard data mining techniques.

Figure 2: News Extractor overview

MANAGING WEB-BASED INFORMATION

577

4.2 News Repository

The News Repository stores all the retrieved news

and provides them to the Data Provider. News is

stored as a set of XML documents. XML format is

chosen because it is the standard interchange format

for representing structured information.

4.3 Data Provider

The Data Provider (Fig. 4) sends data to different

kind of clients (e.g., web browsers, handhelds, smart

phones, etc.) adapting the content to the specific

features of the client. The Data Provider is an

Application Server that retrieves data from the News

Repository and creates a presentation layout for

sending to clients. The Data Provider adapts the

format of the content to the specific client to produce

the best results as possible. As instance, pages in the

HTML format are provided to web browsers; the

same set of pages is provided to WAP (Wireless

Application Protocol) enabled cell phones using the

WML (Wireless Markup Language) format.

Figure 3: Data Provider

3 CONCLUSIONS

The rapid growth of the amount of information on

Internet makes locating a specific subset a tedious

and time-consuming task. Due to this, in the next

years, automatic extraction and integration of web-

based information will become more and more

important. This paper proposed News Miner, an

automatic tool for news extraction and integration

based on XML language. It extracts relevant data

from HTML pages using XSLT language. A

weakness of this approach is that the extraction

mechanism depends on a human input describing the

HTML structure. This becomes an issue when the

structure of web sources changes rapidly requiring

frequent updates to the style sheets. In the future, we

intend to develop a GUI for helping users to

generate and maintain correct XSLT style sheets. In

particular, it will allow the user simply to highlight

the information that is to be extracted directly on the

screen without having to write a single line of XSLT

code. Extracting news from web services, based on

protocols, such as SOAP (Simple Object Access

Protocol) or XML-RPC (XML Remote Procedure

Call), will provide relevant enhancements to the

architecture.

REFERENCES

Ashish N., Knoblock C., 1997. Wrapper Generation for

Semi-structured Internet Sources. Workshop on

Management of Semistructured Data, Ventana

Canyon Resort, Tucson, Arizona.

Cooley R., Mobasher B., Srivastava J., 1997. Web

Mining: Information and Pattern Discovery on the

World Wide Web, In ICTAI '97, 9th International

Conference on Tools with Artificial Intelligence.

DOM (Document Object Model) specifications – web site:

http://www.w3.org/DOM

Etzioni O., 1996. The World Wide Web: quagmire or gold

mine?, In Communications of the ACM 39(11).

Kleinberg J. M., 1998. Authorative Sources in a

Hyperlinked Enviroment, In Proc. of the ACM-SIAM

Symposium on Discrete Algorithms.

Mobasher B., Jain N., Han E.-H., Srivastava J., 1997.

Web Mining: Patterns from WWW Transactions. Dept.

Comput. Sci., Univ. Minnesota, Tech. Rep. TR96-050.

Sillitti A.,

Vernazza T., Succi G., 2002. Service Oriented

Programming: A New Paradigm of Software Reuse. In

Seventh International Conference on Software Reuse

ICSR-7.

Srivastava J., Cooley R., Deshpande M., Tan P., 2000.

Web Usage Mining: Discovery and Applications of

Usage Patterns from Web Data, In SIGKDD

Explorations, Vol. 1, Issue 2, 2000.

WML (Wireless Markup Language) specifications – web

site: http://www.wapforum.org/what

XHTML (eXtensible HyperText Markup Language)

specifications – web site: http://www.w3.org/MarkUp/

XPath (XML Path Language) specifications – web site:

http://www.w3.org/TR/xpath

XSLT (eXtensible Stylesheet Language Transformation)

specifications – web site:

http://www.w3.org/Style/XSL/

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

578
