APPLYING ONTOLOGIES IN THE KNOWLEDGE DISCOVERY

IN GEOGRAPHIC DATABASES

Guillermo Nudelman Hess, Cirano Iochpe

Universidade Federal do Rio Grande do Sul, Caixa Postal 15064, Porto Alegre, RS, Brasil

Instituto de Informática

Keywords: Geographic Database, Ontologies, Semantic integration, Conceptual modeling

Abstract: This article proposes a software architecture to integrate geographic databases conceptual models. The goal

is the preprocessing phase on the knowledge discovery in database, using geographic databases conceptual

schemas as input data, in order to obtain analysis patterns candidates. The semantic unification is very

important in this process, since the data mining tools are not capable to recognize synonyms neither to

distinguish between homonymous. In this way a methodology to refer the knowledge basis was developed.

1 INTRODUCTION

Because of the increasing use of the Geographic

Information Systems (GIS) in the last past years, the

conceptual modeling of the Geographic Database

(GDB) has become a very important task. However,

each one of the GIS software has its own data

model, which has it focus in the logical phase of the

database project (Silva, 2003).

Plenty of conceptual models to the GDB project

have been proposed, attending to make the GDB

modeling independent from the implementation

platform. Among them, some are the UML-

GeoFrame (Rocha, 2001) and MADS (Parent, 1999).

The core of most of them is equivalent, and a

complete comparative study is presented in (Bassalo,

2002).

The use of the conceptual modeling allows also

the project documentation and the reuse of the

model, or part of it, several times. This reuse is

specially interesting in GDB, since its modeling is

quite complex, and part of the geographic concepts

of the real world being modeled is repeated for

distinct applications. In this way the use of analysis

patterns (Gamma, 1995) is usefeull. Analysis

patterns are the essence of the conceptual modeling

for the solution of a recurrent problem in a specific

context.

To support the acknowledgment of analysis

patterns automatically, the Knowledge Discovery in

databases (KDD) (Fayyad, 1996) can be applied.

This process has several steps, as shown in Figure 1.

The data mining (DM) and post-processing of

conceptual schemas was performed in (Silva, 2003),

by the use of DM tools that produce associative

rules. However, a few conceptual schemas could be

mined, because the pre-processing phase was not

addressed. The present work is focused in this phase.

ure 1 - The KDD

rocess

(

ad, 1996

)

To mine a number of conceptual schemas in

possibly different data models it is necessary put

them all in the same format, because they have to be

stored to be reused after. Unfortunally, this does not

occurs with the GDB conceptual models, because

there is not a modeling pattern addopted as a

standard.

To reach a correct data preparation, this schemas

integration accomplishes two levels, the syntatic and

the semantic. The first one relates to the equivalence

of the constructors of each model. A research over

the unification of the refered models was initiated in

(Bassalo, 2002), where is presented the constructors

union set.

The semantic level of the integration comprises

the problem of unification between names used to

describe the real world phenomena being modeled

and the associations among them. In this sense it is

necessary to build a Knowledge Organization

System (KOS) (Hodge, 2000), such as a controlled

vocabulary, a taxonomy, a thesaurus (Qin, 2001), a

509

Nudelman Hess G. and Iochpe C. (2004).

APPLYING ONTOLOGIES IN THE KNOWLEDGE DISCOVERY IN GEOGRAPHIC DATABASES.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 509-512

DOI: 10.5220/0002634505090512

 SciTePress

semantic network or an ontology (Guarino, 1998) to

store the concepts concerning of the geographic

applications domain.

Section 2 of this article presents the context of

the GDB semantic integration problem. A software

architecture for the integration of GDB conceptual

schemas is presented in Section 3. Section 4 details

the proposed metodology to query ontology in the

designed software architecture. At last, conclusions

and future works are presented in Section 5.

2 WHY SEMANTIC UNIFICATION

OF GDB SCHEMAS

The semantic integration, even in databases or

conceptual models, is a very complex and costly

task, once it has to address variety kinds of

heterogeneity.

Bergamaschi et. al (Bergamaschi, 1998)

classifies the heterogeneity in terms of nomenclature

and structure. The first case englobes the naming

conflicts, such as synonyms and homonymous.

Structural heterogeneity concernes the differences

existing in the conceptual model, in terms of

attributes and associations of the modeled concepts.

Geographic databases try to model the real world

phenomena. Thus the set of elements to be

modeled are concrete and quite restricted. The

attributes and associations between the geographic

elements are always the same. The only thing that

varies is the approach, which depends on the

application and the designer’s knowledge, and also

the names used to represent the same things. In this

sense, the development of a set of definitions about

names, attributes and associations of the geographic

phenomena is usefull, in at least two aspects,

described in the next subsections.

2.1 Integration of Geographic

Applications

To make the integration of geographic application

possible, three requisites must be satisfied

(Bergamaschi, 1998):

1. The conceptual schemas of each source

must be available;

2. There must be semantic information in the

schema;

3. A canonical data model must exists. This

standard model must have enough expressivity

power to describe all the models to be

integrated;

Once the target of the integration proposed in

this paper is of conceptual schemas, the first

requisite is autmatically satisfied. The other

requisites are satified by the use of the work

developed in (Bassalo, 2002) and by the use of GML

(OpenGIS, 2001).

Through the use of a KOS to eliminate semantic

heterogeneity not only the data mining is possible,

but also at least other three capabilities can be

reached (Sheth, 2000):

4. Terminological transparency: Ambiguities

created by homonymous and synonyms are

eliminated;

5. Context sensitive processing: Depending on

the context (attributes and associations) in

which a concept is in, it is possible to infer its

meaning;

6. Semantic correlation: Integration between

conceptual schemas, combining both aspects

above.

2.2 New applications modeling aid

The database conceptual modeling process is a

complex task, but really important to guarantee the

correct working and the manutenability of the

database. In order to automate this process and aid

the designer, a number of CASE tools are

disposable. However, this is not true for the GDB

conceptual modeling. There are some academic

proposals, but specific for one data model, such as

RoseGIS (Hess, 2003) and MADS editor (Parent,

1999).

None of these CASE tools has information about

the real world and how is its behavior. The

consequence is that the designer is who has to give

all sort of information about the application’s

domain. Thus, the build of a KOS containing the

elements (phenomena, in case of GDB) and the

associations of the domain may contribute to the

database project (Sugumaran, 2002), and thus to the

GDB project. The designer can face his modeling

against the existing KOS, so he can detect possible

inconsistencies and incompleteness, such as missing

entities, attributes and associations.

3 THE ARCHITECTURE

To reach correct data preparation of conceptual

schemas based on different data models, it is

necessary to develop a mechanism to unify those

models. This integration aims to eliminate possibles

ambiguities of understanding and data redundancy.

As the ontology is the KOS chosen technique,

Figure 2 presents a generic architecture to translate

conceptual schemas, independent of the data model.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

510

A conceptual schema is primarily converted into

a syntactic canonical file format (SCFF), that is,

only in the syntactic level. According to the data

model in which the schema is based a specific set of

rules is applied.

This syntactic integration turns conceptual

schemas into a canonical data model, totally

independent of platform. The Geographic Markup

Language (GML) (OpenGIS, 2001) encoding is the

chosen format to be used as the canonical data

model.

Even knowing the GML is not capable to

represent all of the constructors from all the data

models it was adopted for having a significative set

of elements used in the GDB modeling and because

it is standard data format proposed by the OpenGIS.

Moreover, in the future GML can be extended to

handle the missing constructors.

The second step of the process consists in pass

the SCFF through an ontology, to guarantee the

semantic level of the data preprocessing. The result

is a semantic and syntactic canonical file format

(SSCFF). The last step of the data preprocessing

consists in trasform the SSCFF file to the FDE file

(Silva, 2003) which can be handled by the data

mining tools.

4 THE ONTOLOGY’S ROLE

Ontologies are used, in this work, to conceptualize.

The use of an ontology by itself does not provide a

complete solution to the semantic integration

problem. It is impossible to the ontology to

contemplate all the ways to express a real world

phenomenon. Depending on the geographical

location of the designer the names used to the same

concept may vary. Moreover, the spelling of the

same concept may vary too, specially in case of

abreviation.

To solve the situations cited above the ontology

process may use some similarity matching (Cohen,

1998) techniques. This matching has to occurs in the

level of names and in the level of the structure of a

term, considering hierarchies, associations and

attributes of the candidate concepts stored in the

ontology (Bergamaschi, 1998).

4.1 The algorithm to search and

update the ontolgy

Figure 3 illustrates the algorithm to search the

ontology.

SearchConcept

Ontology

SimilaritySearch

ConceptFound

ConceptNotFoun

AddConceptOntology

CandidatesNotFound

Calculate Candidates

Similarity

ShowWeighedC

andid at es

Co nc ep tS el ec tio n

UpdateExisting

Concept

NewTerm( synonym )

ure 2 - Conce

tual schema inte

rator architecture

Figure 3 - The ontology searching process

Step 1 – Search a concept in the ontology: Each

concept in the conceptual schema is searched in the

ontology. If the term is found with the same name

and exactly the same attributes and associations, the

query ends and starts for the next concepts. If the

name, attributes or associations are different from

the ones stored in the ontology, go to step 2.

Step 2 – Similarity search: Applying techniques

of similarity matching cadidates to synonyms of the

input concept are identified. The similarity

coefficient is calculated, based on criteria of name

and structure similarity. If candidates are found, go

to step 3. If there are no candidates, go to step 4.

Step 3 – Terms selection: Each one of the terms

identified as possible synonyms to the input concept

is presented to the domain expert, who identifies the

most appropriate. If it is an insertion of a new

synonym of a concept already stored, without the

need to update its structure (attributes and

associations), go to step 4. If it is necessary to

update the concept structure, go to step 5.

Step 4 – Insertion of a concept in the ontology:

The term is added to the ontology. If it comes from

step 3, it is associated to its equivalent in the

ontology. If it comes from step 2, it is added to the

ontology with all attributes and associations. The

algorithm searches for the next term.

Step 5 – Update of an existing concept: The

structure (attributes and associations) of an existing

concept is updated in the ontology.

APPLYING ONTOLOGIES IN THE KNOWLEDGE DISCOVERY IN GEOGRAPHIC DATABASES

511

5 CONCLUSIONS

The use of analysis patterns can contribute to the

improvement of GDB conceptual models because

they are tested and aproved solutions. This can

reduce the time needed to the conceptual project and

also reduce the possibility of making mistakes. The

obtainment of these patterns can be done by the

KDD process application. One of the important

phases of this process is the data preprocessing.

Specifically in GDB conceptual schemas the data

preprocessing consists in the integration of the

conceptual schemas designed based on different data

models and with naming variations to the same real

world concepts. Thus the integration must be

performed in two levels, syntacticaly and

semanticaly which was the focus of this paper. The

semantic integration among distinct conceptual

schemas must be aided by an ontology, which allows

searching by names and also searching by structure

as attributes and associations.

Another benefit of using ontologies, is the fact

the knowledge is stored and can be updated and

interchanged. Not only analysis patterns can be

deduced but also the ontologies existing concepts

can help the designer in modeling a new conceptual

schema. However to explore all the ontologies

potentialities and in an efficient way it is necessary

to combine it with another technique very used in

heterogeneous databases, known as similarity

matching.

The next steps of this research are the study of

the similarity matching techniques and more

important the definition of a set of criteria to be

considered in the similarity coefficient calculus and

also the weight of each one. The implementation of

the algorithm proposed in section 4 is also a future

work to test the efficiency of this solution to the

semantic unification.

REFERENCES

Bergamaschi, S. et al., 1998. An Intelligent Approach to

Information Integration. In Internation Conference on

Formal Ontology in Information Systems (FOIS’98).

Italy.

Bassalo, G.H.M.; Iochpe, C.; Bigolin, N., 2002.

Representando esquemas no Formato Atributo-Valor

para a Inferência de Padrões de Análise. In: IV

Brazilian Symposium on GeoInformatics - GeoInfo

2002. Caxambu, Brazil.

Cohen, W.W., 1998. Integration of Heterogeneous

Databases Without Common Domains Using Queries

Based on Text Similarity, In

Proceedings of the 1998

ACM SIGMOD international conference on

Management of data. USA.

Fayyad, U. M.; Piatetsky-Shapiro, G.; Smyth, P, 1996.

From Data Mining to Knowledge Discovery in

Databases. AI Magazine, v.17, n.3, p.37-54.

Gamma, H.E.; Johnson, R.; Vlissides J., 1995. Design

Patterns: Elements of Reusable Object-Oriented

Software. Addison-Wesley.

Guarino, N., 1998. Formal Ontology and Information

Systems. In Proc. of In Internation Conference on

Formal Ontology in Information Systems (FOIS’98).

Italy.

Hess, G.N.; Iochpe, C.; Silva, C.M.S., 2003. RoseGIS:

Uma ferramenta CASE para projeto de banco de dados

geográficos. In GISBrasil 2003. Brazil.

Hodge, G., 2000. Knowledge Organization Systems: An

Overview. In System of knowledge Organization for

Digital Libraries: Beyond Traditional authority files.

OpenGIS Consortium, 2001. Geography markup

Language (GML) 2.0. Open GIS Implementation

Specification. Available in http://www.opengis.net.

Parent, C. et al., 1999. Spatio-temporal conceptual models:

data structures + space + time. In Proc.7th ACM GIS,

Kansas City, USA.

Qin, J.; Paling, S., 2001. Converting a controlled

vocabulary into an ontology: the case of GEM,

Information Research 6, 2001.

Rocha, L. V.; Edelweiss, N.; Iochpe, C., 2001 GeoFrame-

T: A Temporal Conceptual Framework for Data

Modeling. In: ACM Symposium on Advances in GIS.

Atlanta, USA.

Sheth, A.P., 2000. Changing focus on interoperability in

information systems: From systems, syntax, structure

to semantics. In Interoperating Geographic

Information Systems”.

Silva, C.M.S.; Iochpe, C.; Engel, P.M., 2003. Using

Knowledge Discovery in Database to Identify

Analysis Patterns, 5

International Conference on

Enterprise Information System, Angers, France.

Sugumaran, V.; Storey, V., 2002. Ontologies for

Conceptual Modeling: their creation, use and

management. In Data & Knowledge Engineering.

Elsevier.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

512
