DESIGN AND REPRESENTATION OF THE TIME DIMENSION

IN ENTERPRISE DATA WAREHOUSES

A Business Related Practical Approach

Ahmed Hezzah, A Min Tjoa

Institute of Software Technology, Vienna University of Technology, Favoritenstr. 9-11/188, 1040 Vienna, Austria

Keywords: Data Warehouse, Time Dimension, Temporal Databases

Abstract: A data warehouse provides a consistent view of business data over time. In order to do that data is

represented in logical dimensions, with time being one of the most important dimensions. Representing

time, however, is not always straightforward due to the complex nature of time issues and the strong

dependence of the time dimension on the type of business. This paper addresses the specific issues

encountered during the design of the time dimension for multidimensional data warehouses. It introduces

design and modeling techniques for representing time in the data warehouse by the use of one or multiple

time dimensions or database timestamps. It also discusses generic problems linked to the design and

implementation of the time dimension which have to be considered for (global) business processes, such as

representing holidays and fiscal periods, increasing the granularity of business facts, considering the

observation of daylight saving time and handling different time zones. These problems seem to have wide

application, and yet, more in-depth investigations need to be conducted in this field for real-world time-

based analysis in enterprise-wide data warehouses.

1 INTRODUCTION

As business activities tend to change over time, the

business data must be able to represent that change

(Devlin, 1997). Therefore, data modeling and

application design approaches have not to focus only

on a static view of the section of the real world to be

modeled.

This might be adequate in operational

appl

ications, which manage only real-time data and

take a view mainly of the current state of the

business. A data warehouse, however, must

explicitly consider the temporal aspects of the data it

contains, because it must, by definition, provide a

historical view of the business.

But the majority of today’s modeling tools and

atabases still focus on the representations of

“snapshots” of the current business information. One

of the first approaches which incorporates the notion

of time for modeling enterprise data is described in

(Eder, 1987), where timestamps and states of entities

and relationships are introduced. This approach

leads to the specification of business rules with

situation/activation diagrams as described in (Lang,

1997). A detailed description of most current

research performed for this purpose can be found in

(Wijsen, 1999) and (Wijsen, 2003). This paper will

focus on some practical aspects of this research.

While operational systems are among other

ings designed to meet well-specified (short)

response time requirements, the focus of data

warehouses is the strategic analysis of data

integrated from heterogeneous systems (Inmon,

1996). This business requirement has consequences

for the data model design and for the architecture of

the data warehouse. The absence of support for this

temporal issue led data warehouse designers to take

several approaches to reflect history in the database

design (Snodgrass, 2000).

One important approach that is widely used is

ding timestamps to the data. A timestamp is a

specially defined field, in date-and-time format that

tracks when a data record has been created, deleted,

or changed in any way. Changes can be tracked on

field-, record/row, or file/table level, depending on

the required level of detail and the available storage.

However, in this paper we focus on tracking changes

on record/row level since this is the more common

approach in the data warehouse.

But as we move toward the multidimensional

app

roach data is represented in logical dimensions in

416

Hezzah A. and Min Tjoa A. (2004).

DESIGN AND REPRESENTATION OF THE TIME DIMENSION IN ENTERPRISE DATA WAREHOUSES - A Business Related Practical Approach.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 416-424

DOI: 10.5220/0002642604160424

 SciTePress

order to provide a consistent view of the data over

time, a view that can be used by decision support

systems. One of the major dimensions in every

multidimensional data warehouse is the time

dimension. The time dimension contains descriptive

temporal information, and its attributes are used as

the source of most of the temporal constraints in data

warehouse queries (Kimball, 1996). However, the

design of the time dimension is not always

straightforward as it strongly depends on the type of

business and the requirements of the enterprise.

The aim of this paper is to introduce a

specification of the time dimension in enterprise data

warehouse systems, which is consistently applicable

for handling the analysis of global enterprise data.

The problems arising in multinational corporate

groups when combining data with a temporal

dimension are enormously cost-intensive. Even the

minor problem of DST for one of the world-wide

leading energy companies could cause data

warehouse costs of millions of dollars, as it has been

investigated by one of the authors.

This paper deals with the subject matter related

to representing time in the data warehouse. It

discusses the design of the time dimension and

introduces design techniques for its implementation.

It presents a practical approach, which also models

relevant real world business issues such as holidays,

seasons, daylight saving time and fiscal periods by

extending the time dimension with new attributes

and flags. It uses the time dimension together with

timestamps to resolve major granularity issues.

Finally, it addresses issues related to having

different time zones and demonstrates how the use

of local and universal time can resolve these issues.

2 RELATED WORKS

The functions needed to implement a data

warehouse architecture including different types of

data are described in (Devlin, 1997) and (Inmon,

1996). It addresses the use of timestamps to store

periodic and historical business data, but doesn’t

consider the multidimensional approach widely used

today. This is more discussed in (Kimball, 1996)

with case studies of data warehouses for different

types of businesses, almost all using a daily-based

time dimension, unfortunately with no focus on the

issues related to its implementation.

Adding history to the temporal database

application is investigated in (Snodgrass, 2000) with

focus on issues related to valid and transaction time,

intervals and periods and state tables for valid and

transaction time. It also presents some

implementation considerations for the temporal

database logical and physical design and

demonstrates application development issues using

SQL.

A conceptual multidimensional data model,

which facilitates even sophisticated constructs based

on multidimensional data units or dimension

members, is introduced in (Nguyen, 2000). This

model is able to represent and capture natural

hierarchical relationships among dimension

members within a dimension as well as the

relationships between dimension members and

measure values and is modeled using UML.

Dimension updates are formally discussed in

(Vaisman, 2001).

(Bruckner, 2001) presents an approach for

modeling conceptual time consistency problems and

introduces a model that deals with timely delays.

However, this model doesn’t address issues related

to the time dimension as much as data consistency

and updating issues. Changes of dimension data are

discussed in (Eder, 2002), which presents an

approach to represent temporal behavior of master

data within existing, non-temporal data warehouses.

In (Ravat, 2000) a data warehouse class concept

is introduced, which is based on the concepts of

temporal filter and archive filter. It defines mapping

functions to specify derived, calculated, and specific

properties, and organize the inheritance hierarchy of

the warehouse classes, allowing extracting only

relevant data. In (Yang, 2000) Yang and Widom

study incremental maintenance of temporal views

using a temporal query language equivalent to

TSQL2. Although (Ravat, 2000) does not organize

data multidimensionally, it provides a more flexible

temporal model than (Yang, 2000) because the

purging values are not deleted, but they are archived.

The use of multiple time dimensions is

mentioned in (Kimball, 1999), which introduces the

concept of a data webhouse. It uses a clickstream

data mart to store all web activities for later analysis

of user behavior. This is also discussed briefly in

(Pedersen, 2001) with focus on the influence of the

web on data warehousing, but also the design of

clickstream fact tables and dimension tables.

Other temporal issues like fiscal periods and

granularity are briefly discussed in (Kimball, 2002)

and (Kimball, 1997) with more focus on using the

time dimension to resolve this issues, but design

issues are not investigated in detail.

The aim of this paper is to give a framework for

modeling the time dimension in data warehouses for

enterprise wide (global) information systems with

focus on its applicability for practical issues, such as

daylight saving time (DST) or problems related to

time zones, holidays, and fiscal periods. This paper

DESIGN AND REPRESENTATION OF THE TIME DIMENSION IN ENTERPRISE DATA WAREHOUSES - A

BUSINESS RELATED PRACTICAL APPROACH

417

presents design techniques for representing time in

multidimensional data warehouses and temporal

databases. It provides an approach to model practical

problems of different time representations, which

will be demonstrated considering relevant real-world

examples, such as the DST-problem, the modeling

of holidays, fiscal periods, etc., by using one or

multiple time dimensions and timestamps.

3 TEMPORAL ISSUES

3.1 The Time Dimension

The TIMESTAMP type available in SQL provides a

representation of time in a very fine precision. It

stores the year, month, day, together with the hour,

minute, second, and a number of fractional digits of

the second. It can be used in a database table to

record the occurrence of certain events (e.g. deposit

to and withdrawal from a bank account), as well as

the start and end of a certain state (e.g. a certain

employee belongs to a certain department).

As we move toward a multidimensional

approach the simple timestamp is replaced with a

time dimension. The time dimension is then filled

with a lot of helpful calendar attributes and is

connected to the fact table by a foreign key (Figure

1). But do we really need a dimension for time?

Wouldn’t it be better to use an SQL timestamp in the

fact table instead of the foreign key and avoid this

expensive join? To answer this question let’s take a

look at these simple queries:

• Show all the transactions that occurred

within a given period of time.

• Determine whether a certain transaction

occurred within a given period of time.

• Show transactions using complex calendar

navigation capabilities including seasons,

fiscal periods, day numbers, week numbers,

weekdays and holidays.

While the first two queries are pretty simple to

define using a single timestamp that stores the

occurrence time of each transaction, this is not the

case for the third query. Since SQL timestamp know

nothing about an organization’s calendar, fiscal

periods or holidays, these attributes are modeled

using a time dimension (Figure 2). This way the

application designer doesn’t have to embed these

calendar constrains in the application design, which

would require a set of complex queries to determine

these attributes. Besides that this would be very

slow, the end-user application can’t easily produce

the needed SQL.

A time dimension can easily be built using a simple

spreadsheet. A 20-year time dimension on daily

basis contains about 7300 rows, which is not much.

It can also be filled with a single SQL INSERT

statement, as we will see later. However, problems

will start to arise when the fact table requires

granularity smaller than a day, let it be an hour, a

minute, or a second. It’s not possible to create a

single time dimension with all the minutes or

seconds over a long period of time. There are more

than 500,000 minutes and 31 million seconds in a

year. So, for these cases the only way seems to be to

use SQL timestamps despite the limitations we

mentioned and to give up the ability to navigate

through seasons and fiscal periods to the nearest

second. We will come to this later when we talk

about granularity to see how to overcome this issue.

Time Dimension

time_key

.........

Fact Table

time_key

product_key

customer_key

geography_key

........

Product Dimension

Customer Dimension

ography Dimension

Figure 1: A multidimensional model

Time Dimension

time_key

sql_date

day_of_week

day_number_in_month

day_number_overall

week_number_in_year

week_number_overall

month

month_number_overall

quarter

year

fiscal_period

holiday_flag

weekday_flag

ure 2: The time dimension

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

418

3.2 Holidays, Seasons and Fiscal

Periods

The time dimension as defined above gives us the

ability to track business facts very well on a daily

basis. But as the business requirements become

more complex the time dimension must be extended

by new attributes to meet those requirements. For

example, the business might require looking at sales

on holidays versus non-holidays. With an OLTP

model holidays are usually stored in an own table,

which is filled with all the holidays and can be

joined with the sales table by date key. Thus a query

is then used to join this table with the sales table:

select sum(sales.quantity_sold)

from sales, holidays

where trunc(sales.date_time_of_sale) =

trunc(holidays.holiday_date);

As this looks pretty simple, since the holidays

table eliminates sales on days that are not holidays,

the case looks slightly different when we want to

eliminate sales on days that are holidays. The query

will look like that:

select sum(sales.quantity_sold)

from sales

where trunc(sales.date_time_of_sale)

not in (select holiday_date from

holidays);

Of course this query will take longer time to

execute. The sales table may contain millions of

rows, and the holidays table will contain about 50 to

100 rows. Here, the sub-query will be performed for

each row examined by the main query. So the time

to execute this query might be much longer than the

holidays query. Besides, it will become more

complex when we want to look at sales, not just on

holidays, but also on different seasons, fiscal periods

or weekdays. For each of these attributes a separate

table is necessary, which then must be joined with

the sales table.

Here comes the big advantage of the time

dimension. All these attributes can be integrated into

the time dimension in a way that effectively reduces

query execution time and provides more

functionality than using conventional RDBMS

tables. The tables for holidays, seasons, fiscal

periods and weekdays are replaced with attributes

and flags in the time dimension, which will look like

this:

create table time_dimension (

time_key integer primary key,

-- this is midnight (TRUNC) of the

-- date in question

sql_date date not null,

day_of_week varchar(9) not null,

-- 'Sunday', 'Monday'...

day_number_in_month integer not null,

-- 1 to 31

day_number_overall integer not null,

-- first day is 1

week_number_in_year integer not null,

-- 1 to 52

week_number_overall integer not null,

-- weeks start on Sunday

month integer not null, -- 1 to 12

month_number_overall integer not

null, -- first month is 1

quarter integer not null, -- 1 to 4

year integer not null,

fiscal_period varchar(10),

holiday_flag char(1) default 'f'

check (holiday_flag in ('t', 'f')),

weekday_flag char(1) default 'f'

check (weekday_flag in ('t', 'f')),

season varchar(50),

);

Of course these attributes must be defined and

filled according to the organization’s fiscal calendar.

Now if we want to report sales by season, the query

will be straightforward:

select td.season, sum(f.dollar_sales)

from sales_fact f, time_dimension td

where f.time_key = td.time_key

group by td.season;

Using the group by command we can report by

other attributes like holidays and fiscal periods in an

identical way, which makes the queries much faster

than using separate tables. Using other dimensions

like products, customers, manufacturers, etc. makes

us able to report by different criteria.

As mentioned above, the time dimension can be

populated using a spreadsheet or even easier with a

simple SQL INSERT statement. This is done using

SQL date formatting functions and a help table

integers, which supplies a series of numbers to be

added to a selected starting date. For this example let

January 1

1998 be the first date:

-- Uses the integers table to drive the

-- insertion, which just contains

-- a set of integers, from 0 to n.

DESIGN AND REPRESENTATION OF THE TIME DIMENSION IN ENTERPRISE DATA WAREHOUSES - A

BUSINESS RELATED PRACTICAL APPROACH

419

-- d below is the SQL date of the day -

-- we're inserting.

insert into time_dimension

(time_key, sql_date, day_of_week,

day_number_in_month,

day_number_overall,

week_number_in_year,

week_number_overall,

month, month_number_overall, quarter,

year, weekday_flag)

select n, d, rtrim(to_char(d, 'Day')),

to_char(d, 'DD'), n +

1,to_char(d,'WW'),trunc((n + 4) / 7),

-- Jan 1, 1998 was a Thursday, so +4 to

-- get the week numbers to line up with

-- the week

to_char(d, 'MM'),trunc(months_between

(d, '1998-01-01') + 1),to_char(d, 'Q'),

to_char(d, 'YYYY'),

decode(to_char(d,'D'), '1', 'f', '7',

'f', 't')

from (select n, to_date('1998-01- 01',

'YYYY-MM-DD') + n as d

from integers);

The remaining fields (

season, fiscal_period,

holiday_flag) cannot be filled using SQL date

functions and have to be populated afterwards.

Fiscal period and season depend on the

organization’s choice of fiscal year. To update the

holiday_flag field, which is ‘f’ by default, we need

two help tables: one for the fixed holidays and one

for the floating holidays.

create table fixed_holidays (

month integer not null

check (month >= 1 and month <= 12),

day integer not null

check (day >= 1 and day <= 31),

name varchar(100) not null,

primary key (month, day)

);

-- Specifies holidays that fall on the

-- n-th DAY_OF_WEEK in MONTH.

-- Negative means count backwards from

-- the end.

create table floating_holidays (

month integer not null

check (month >= 1 and month <= 12),

day_of_week varchar(9) not null,

nth integer not null,

name varchar(100) not null,

primary key (month, day_of_week, nth)

);

Some example holidays:

insert into fixed_holidays (name,

month, day)

values ('New Year''s Day', 1, 1);

insert into floating_holidays (month,

day_of_week, nth, name)

values (11, 'Thursday', 4,

'Thanksgiving');

After that, it is easy to update the

holiday_flag

in the time dimension using these two help tables

and any procedural language like PL/SQL to set the

holiday_flag to ‘t’ for the days just inserted into

the two tables.

In order to consider holidays in different

countries or in different time zones we could use

multiple holiday flags (

holiday_flag_1…

holiday_flag_n

), one for each country we need to

consider. For instance, October 3

is a national

holiday in Germany, so we set the

holiday_flag for

Germany to ‘

t’, while for all other countries we

leave it ‘

f’. This way, we can run queries like “how

did this German holiday affect sales in neighboring

countries like Austria and Switzerland?”.

3.3 Granularity

Granularity is the level of detail of the facts stored in

a data warehouse. As mentioned above, if we are

only modeling calendar days the time dimension

provides a very good approach to track business on a

daily basis. But what if we need to add some more

precision to the fact table in order to store more

temporal details? Can we just increase the

granularity of the time dimension to the nearest

hour, minute or even second or do we have to give

up the ability to navigate by time and to specify

seasons, fiscal periods and holidays?

To answer this question let’s first take a look at a

time dimension that stores all the days in a defined

period of time. This dimension will contain a row

for each day, which means that a 10-year dimension

will contain 3650 rows. Now if we want to track

changes to the nearest hour, minute, or second, this

could be done in one of the following ways:

Increase the granularity of the time dimension

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

420

Time Dimension

time_key

sql_timestamp

hour_number_in_day

hour_number_overall

day_of_week

day_number_in_month

day_number_overall

week_number_in_year

week_number_overall

month

month_number_overall

quarter

year

fiscal_period

holiday_flag

weekday_flag

season

Figure 3: A time dimension on hourly basis

With this approach the time dimension is

changed to store all the hours, minutes, or seconds of

the specified time period. For a 10-year time

dimension this will mean that it will contain approx.

87600 rows (3650 x 24) to store each hour, 500,000

rows for each minute, and over 31 million rows for

each second.

While this might be an acceptable size for storing

hours this is definitely not the case for minutes and

seconds. Moreover, in order to keep the size of the

time dimension small and predictable, the duration

must be kept constant by deleting old entries when

new ones are inserted. This makes the business data

stored only semi-periodic.

This approach is useful if the granularity is

limited to the nearest hour for a not too long period

of time (Figure 3), which also makes it possible to

navigate by hour, for e.g. to see what day times were

the best for sales. However, if we need to store the

time to the nearest minute or second, we prefer using

one of both other approaches.

Add timestamps to the fact table

Adding SQL TIMESTAMPS directly to the fact

table provides a very high precision as the

granularity of these timestamps can go up to some

fractions of the second. Occurring events can thus be

captured on the second of occurrence, and the start

and end of a status are also stored second exact.

This is good if a very high precision is needed

over the navigation features of the multidimensional

model. If we choose this approach we have to live

with the limitations of SQL TIMESTAMPS and give

up the ability to specify seasons, holidays, or fiscal

periods to the nearest second.

Use twin timestamps

This approach combines the advantages of both

previous approaches by using two timestamps on

each transaction record in the fact table. The first

would be an SQL TIMESTAMP as described in the

previous paragraph, and the second would be a day

id, a foreign key connecting to a calendar day

dimension (Figure 4).

The time of day could also be stored in a separate

numeric field instead of using a timestamp, or even a

separate dimension can be used for the time of day,

as we will see when we talk about time zones. But

anyway it should not be combined into one key with

the calendar day as this would make the time

dimension simply too large.

This way we can search for very precise time

periods, but also navigate to see all transactions that

occurred on a holiday.

3.4 Daylight Saving Time

Daylight Saving Time (DST) is the practice of

turning the clock ahead as warmer weather

approaches and back as it becomes colder again.

DST varies from country to country.

Here we are more concerned about the

representation of time on those days when the time

DESIGN AND REPRESENTATION OF THE TIME DIMENSION IN ENTERPRISE DATA WAREHOUSES - A

BUSINESS RELATED PRACTICAL APPROACH

421

time day_key product_key customer_key quantity price

25-MAR-2003 15:37:13

25-MAR-2003 16:15:45

03-APR-2003 11:47:02

1910

1919

12265

34324

25254

7657654

2423555

3545466

200

240

150

Figure 4: A fact table using twin timestamps

is shifted. This happens on two days every year. In

the European Union, DST starts the last Sunday in

March at 1 am UTC and ends the last Sunday in

October at the same time.

These two days must be treated differently in the

time dimension because they are different than other

days. While all other days of the year have 24 hours

and can thus be modeled as shown above the day

when the time is set to DST has only 23 hours since

the time is set from 0 am directly to 2 am UTC. On

the other hand, the day when the time is set back has

25 hours because the hour from 1 am to 2 am is

repeated twice.

Let’s take as an example March 30

2003 and

October 26

2003. On March 30

there is actually

no point in time when it is 1 am. The clock jumps

from 00:59:59 directly to 02:00:00. Therefore there

is no need to include the 1 am hour in an hourly-

based time dimension.

On October 26

, however, there are two points in

time when it is 1 am. The clock goes from 01:59:59

back to 01:00:00 again instead of 02:00:00. After

another hour the time is actually 02:00:00.

For our time dimension shown in Figure 3 this

means that on all last Sundays in March we only

need to insert 23 hours by leaving the 1 am hour, as

it does not really exist. The

hour_number_in_day

thus goes from 1 to 23. And on all last Sundays in

October we insert 25 hours by repeating the 1 am

hour. The

hour_number_in_day thus goes from 1 to

25 (Figure 5). Of course the DST days have to be

determined in advance before the time dimension is

filled with values.

The optional attribute

second_in_day can be

useful for the application to correctly determine the

timestamp and other time periods on those two

special days and it must be interpreted differently on

those two days than on normal days. Depending on

the application and the needed queries this attribute

can be used or not.

Finally, to make it easier for SQL to determine

the days when time is set to DST and back we use

another flag

DST_flag which is zero on normal days,

-1 on all last Sundays in March, and +1 on all last

Sundays in October.

Please note that the described model is using

UTC. If you design your time dimension for another

time zone, you have to consider the days and times

when the time is switched to DST and back.

3.5 Time Zones

Different time zones not only mean having different

times, but also DST is observed differently in

different regions, which makes the design of the

time dimension even more complicated.

As we mentioned at the end of the previous

section, the days and times when time is set to DST

must be considered in the design of the time

dimension. However, business data are not always

entered within the same time zone. This is one of the

reasons for using a Geography dimension. In a Sales

data warehouse this would help to store where a

product was sold. But which time should be used:

local or universal time?

Now that the web has become an extremely

important source of data warehouse data, a source

that produces data with the speed of a click, it brings

up several issues that are not yet resolved. Data

enters the warehouse from thousands of users in

different time zones, but must all be stored into the

same database.

Generally, it’s easier to store the local time than

to compute it based on time zones, which is very

useful for queries such as “at what time of day were

the most orders placed”. But as this can be done in

any time zone, and as online stores begin to be a

very important point of sale the use of universal time

might make more sense to compare order times

worldwide.

Therefore it is better to store both: local time and

universal time. This can be done by adding another

copy of the time dimension for universal time. And

as mentioned previously, to add more flexibility and

granularity the time-of-day can be separated from

the day by using two dimensions: a date dimension

and a time-of-day dimension for both local and

universal time (Figure 6). This gives us altogether

four dimensions for representing time. We split the

date from the time-of-day because these two

components of time have different descriptors. Date

relates to calendar and weekdays and seasons, and

time-of-day relates to the specific spot we are in

within a day.

The time-of-date dimension might also be used if

we have some specific intervals during the day that

we want to assign names to, afternoon, evening, etc.

This way we can navigate through sales facts by

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

422

time_key sql_timestamp seconds_in_day hour_no_in_day hour_no_overall

50975

50976

50975

50999

26-OCT-2003 00:00:00

26-OCT-2003 01:00:00

26-OCT-2003 02:00:00

26-OCT-2003 23:00:00

3600

7200

10800

90000

50975

50976

50975

50999

Figure 5: October, 26th 2003 modeled in the time dimension

absolute time as well as relative to the customer’s

time. Having separate dimensions for local and

universal time we don’t need to implement the time

calculation based on time zones into the application

logic. This makes our queries more efficient as well.

4 CONCLUSIONS

This paper addressed the most common issues

related to representing time in the multidimensional

data warehouse. It introduced design techniques

using one or multiple time dimensions or time-

stamps. The representation of holidays, seasons and

fiscal periods has been demonstrated by extending

the time dimension with new attributes and flags.

Different approaches have been introduced to

increase the granularity of business facts up to the

nearest second by using a combination of the time

dimension and timestamps. The paper also addressed

the issue of observing daylight saving time DST and

how it affects the design of the time dimension, and

provided an approach to handle this issue by

introducing 23-hour and 25-hour days. This

approach has been then modified to handle different

time zones by using multiple time dimensions and

storing the universal time in addition to the user or

customer’s local time and separating the time-of-day

in another dimension.

REFERENCES

Bruckner, R., Tjoa A.M., 2001. Managing Time

Consistency for Active Data Warehouse

Environments,

In Proc. of the Third International Conf

on Data Warehousing and Knowledge Discovery

(DaWaK 2001)

Devlin, B., 1997. The Data Warehouse, from Architecture

to Implementation, Addison Wesley Longman, Inc.

Eder, J., Kappel, G., Tjoa, A.M., Wagner, R., 1987, BIER

- The Behavior Integrated Entity Relationship

Approach, in: S. Spaccapietra (ed.), Proceedings of the 5th

Intenational Conference on Entity-Relationship

Approach, North-Holland, Amsterdam

Eder, J., Koncilia, C., 2002. Representing Temporal Data

in Non-Temporal OLAP Systems, University of

Klagenfurt

Inmon, W., 1996. Building The Data Warehouse, John

Wiley & Sons, Inc.

Kimball, R., 1996. The Data Warehouse Toolkit, John

Wiley & Sons, Inc.

Kimball, R., 1997. It’s Time for Time, DBMS Online

Kimball, R., 1999. The Clickstream Data Mart in the Data

Webhouse, Intelligent Enterprise

Local Date Dimension

local_date_key

sql_date

day_of_week

month

year

Fact Table

local_date_key

local_time_key

universal_date_key

universal_time_key

product_key

customer_key

geography_key

Local Time Dimension

local_time_key

sql_time

hour_of_day

time_segment_name

Figure 6: Splitting the time dimension into a date dimension and a time-of-day dimension

Univ. Time Dimension

universal_time_key

sql_time

hour_of_day

time_segment_name

Univ. Date Dimension

universal_date_key

sql_date

day_of_week

month

year

DESIGN AND REPRESENTATION OF THE TIME DIMENSION IN ENTERPRISE DATA WAREHOUSES - A

BUSINESS RELATED PRACTICAL APPROACH

423

Kimball, R., 2002. Tricky Time Spans, Intelligent

Enterprise

Lang, P., Obermair, W., Schrefl, M., 1997, Modeling

Business Rules with Situation/Activation Diagrams,

In: A. Gray, P. Larson (eds.): Proceedings of 13th

International Conference on Data Engineering (ICDE

'97), Birmingham, U.K., IEEE Computer Society Press

Nguyen, T., Tjoa, A.M., Wagner, R., 2000. An Object

Oriented Multidimensional Data Model for OLAP,

Proc. of 1st Int. Conf. on Web-Age Information

Management (WAIM 2000)

Pedersen, P., 2001. e-Decisions Transcript, Norwegian

School of Economics and Business Administration

Ravat, F., Teste, O., 2000. A Temporal Object-Oriented

Data Warehouse Model, DEXA'00

Snodgrass, R., 2000. Developing Time-Oriented Database

Applications in SQL, Morgan Kaufmann Publishers

Vaisman, A., Mendelzon, A., Ruaro, W., Cymerman, S.,

2002. Supporting Dimension Updates in an OLAP

Server, CAiSE'02

Wijsen, J., Ng, R.T., 1999 Temporal Dependencies

Generalized for Spatial and Other Dimensions, Proc.

Spatio-Temporal Database Management

Wijsen, J., Bès A., 2003, On query optimization in a

temporal SPC algebra, Data & Knowledge

Engineering, Volume 44

Yang, J., Widom, J., 2000. Temporal View Self-

Maintenance in a Warehousing Environment,

EDBT’00

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

424
