BUSINESS-DRIVEN ENTERPRISE AUTHORIZATION

Moving towards a unified authorization architecture

Tom Beiler

Strat Hollis Business Systems Trust & Security, Zürich, Switzerland

Keywords: Authorization, Enterprise Security, System Specification, Modelling Concepts

Abstract: Information systems of large enterprises experience a shift from an application-centric architecture towards

a focus on

process orientation and web services. The information system is opened to business partners to

allow for self-management and seamless cross-enterprise process integration. Aiming at higher flexibility

and lower costs, this strategy also produces great new challenges the security and administrative support

systems have to cope with. The security of the enterprise system has to keep up and scale with the new

qualitive level of the overall system. In this context we propose an enterprise authorization system model

which allows a unified treatment of the enterprise’s authorization issues, and permits the native integration

of authorization processes into the business system for greater synergy. The proposed model supports

information system architects to avoid that authorization becomes a major obstacle for the new architecture

strategy.

1 INTRODUCTION

As of today, large enterprises face a challenging

paradigm shift within their enterprise information

system architecture. No longer the enterprise system

consists of a number of monolithic applications,

individually interconnected and sharing only the

database level. Instead, the system’s business

functionalities are generalized and parametrized to

achieve a better synergy by shifting the component

reuse one level up within the system architecture. In

addition the enterprise information system is

increasingly opened for business partners and

customers, in order to integrate seamlessly their

business processes, and to allow for inline self-

management of the enterprise business partners. This

strategic direction aims at a reduction in effort and

costs of the business administration for both the

enterprise and its business partners, while it also

leads to a faster adoption of changed business

objectives. In contrast to the situation today,

applications will be light-weight, and concentrate on

presentation and the assembly of existing web

services providing the business functionalities.

Applications are tailored easily to the particular

needs of a multitude of user groups, and the

development cycles are fast and efficient.

The downside is that the gain in flexibility also

lead

s to a qualitative increase of complexity and

dynamics of the security system. For the

authorization system in particular this addresses the

mapping of users to services and applications, i.e, to

permissions within the enterprise information

system. The number of combinations significantly

increases, as well as the change frequency. For the

authorization in the information system this fact

imposes a heavy burden. More specifically, the

authorization system is required

— to cope with the massively increased

fre

quency of authorization change requests,

— to allow for self-management of users to

streamline

the administration processes,

— to seamlessly integrate with the business

ocesses in order to minimize administrational

efforts,

— to treat all system users with a unified

proach unless business or security reasons dictate

otherwise.

The typical situation of authorization in an

terprise today exhibits a mission-critical gap to

these requirements inherited with the new paradigm.

First, internal and external users are most often

treated completely different throughout the whole

information system. For each of both user groups, a

separate, specific authorization system is employed.

While for internal actors role-based access control

has been subject to research and development for the

Beiler T. (2004).

BUSINESS-DRIVEN ENTERPRISE AUTHORIZATION - Moving towards a uniﬁed authorization architecture.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 67-72

DOI: 10.5220/0002643100670072

 SciTePress

past decade, no similar, unifying effort has been

undertaken for system-external actors.

Secondly, authorization is disconnected from the

normal course of business processing. Authorization

logic is, with its larger and more complex aspects,

hard-wired within the application logic. Correct

implementation of the authorization logic is left to

the application developer. The authorization

processes are often semi-manual causing a large

administrative overhead. This inherently leads to

difficulties with the much higher change frequencies

and the expected self-management of users due to

the lack of proper automation and integration into

the business processes. This situation undermines

any effort of an effective treatment of authorization,

and may turn into a major obstacle for the web-

services strategy.

In this article we propose an integrative model

which enables the enterprise authorization system to

be viewed as one system, with the add-on that it

combines cleanly and reasonable with the business

production of the enterprise information system. In

the situation today enterprise authorization trivially

consists of the sum of isolated system fragments

covering particular aspects. Therefore we advocate a

conceptual model which covers the future directions

of authorization, as well as allowing a feasible

migration from the current landscape towards a

unified, centralized authorization system which is

appropriate for a web-services architecture.

Technically, the model is composed from three

layers, including authorization policies, an

authorization language which allows the formulation

of the authorization logic and policies, and a virtual

access matrix which encapsulated the different,

system-specific access control systems within the

enterprise information system’s components.

The authorization system is connected to the

business system by means of an event-based

mechanism, similar to a model-view-controller

mechanism where the business system is the model

while the authorization system constitutes the view.

This choice permits a clean separation from the

business system in the specification of authorization

policies.

We compare our approach with the Single Sign-

On initiative which has established in the practice of

enterprise information systems. Before Single Sign-

On, authentication has been solved isolated for each

application. As the application landscape grew

complex, the management of the variety of

authentication methods and means has no longer

been feasible. Furthermore, with opening the

enterprise for the web, the security requirements

grew, and the need for stronger authentication means

became urgent. With Single Sign-On, authentication

is a centralized service of the information system’s

security infrastructure. We postulate that

authorization experience a similar development from

isolated, application specific solutions towards a

centralized, unified, and mature authorization

system.

The article is organized as follows. Section 2

provides a description of the proposed authorization

system model in more detail with a black-box/white-

box approach and the three system layers. With

section 3, a conclusive discussion is given, while

section 4 relates our approach to current research.

This article is based on the authorization system

reference model which serves as a conceptual

foundation for related consulting cases at Strat

Hollis.

2 SYSTEM MODEL

In our model, we define an enterprise authorization

system as that particular subsystem of the enterprise

business production system which decides, for all

actors within the business system, on the actors’

permissions within that system. The term

‘permission’ refers to any kind of system resource

which is to be protected with acess control, being

combined with the particular actions using or

manipulating the referenced object. We explicitly

state that the system also includes those parts of the

authorization processes which are not implemented

in terms of IT, like semi-manual or paper-based

authorization processes. In contrast to the

authorization system, we identify the access control

system as that particular subsystem of the

information system which enforces the

authorizations produced by the authorization system

during information system operation. We continue

the system description with a blackbox approach

characterizing the connected components in terms of

consumers and producers, followed by a whitebox

description of the system components. Figure 1

illustrates the model description.

Two types of producers, distinguished by their

application times, contribute input to the

authorization system. At development time, policy

providers provide the system with the authorization

policies to determine the decision behaviour of the

authorization system according to their respective,

domain-specific requirements. Typical authorization

policy domains are the enterprise organisation and

role model, enterprise security policies, and legal

obligations. The union of these domain-specific

authorization policies constitutes the authorization

specification of the enterprise authorization system.

Authorization policies are subject to change cycles

and continous development.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

Enterprise Organisation

Information Security

Authorization Requests

Authorization

System Core

Service

Authorization Language

Virtual Access M atrix

Domain-Specif ic Policies

Authorization Policy Domains

Business Processes

Business Service

Agreements

Legal Obligations

Authorization-Relevant Events

State Retrieval

Presentation

Global State

Business Production System

(Enterprise Information System)

Event Receiver / State Observer

Development Time

Deployment Time

Actors

Level 2

Level 1

Level 0

Enterprise Organisation

Information Security

Authorization Requests

Authorization

System Core

Service

Authorization Language

Virtual Access M atrix

Domain-Specif ic Policies

Authorization Policy Domains

Business ProcessesBusiness Processes

Business Service

Agreements

Legal Obligations

Authorization-Relevant Events

State Retrieval

Presentation

Global State

Business Production System

(Enterprise Information System)

Event Receiver / State Observer

Development Time

Deployment Time

Actors

Level 2

Level 1

Level 0

The second kind of input refers to the

deployment time, i.e., the runtime of the productive

authorization system. During the course of operation

of the business production system the authorization

system receives authorization requests, and

subsequently reconfigures the authorization state

accordingly. The authorization system is connected

to the business production system by an event

observer which allows to observe business processes

as they are relevant for authorization. The

mechanism allows to declare the events of the

business system which are relevant for authorization,

and follows the event/condition/action paradigm of

statecharts: on occurrence of an authorization-

relevant business event (the event), the configuration

of the authorization state is recomputed (the action)

in compliance with the authorization policies (the

conditions). The business system ideally never stops

its service, so the authorization system also never

stops, and parallelizes both development and

deployment time.

The most prominent consumer of the

authorization state is the access control subsystem of

the productive business system. The access control

system retrieves the authorization state from the

authorization system for a given access request, and

additionally ensures that access control can not be

circumvented. Also other subsystems may retrieve

the authorization state, e.g., reporting, auditing and

logging, user navigation for better convenience.

The construction of the authorization core

system is layered into three levels following the

abstraction sequence of common computer programs

with runtime system and environment, programming

language, and programs on top to solve particular

problems respectively manipulate data. At level 0,

the lowest level, resides the virtual access matrix.

The access matrix provides consumers with the

current authorization state, i.e., the current set of

valid authorization decision results for any given

access request. The virtual access matrix

encapsulates the local, existing access control

systems of the business production and is

responsible for the timely propagation of the

authorization state to the consuments.

Figure 1: Overview of the Authorization System Model.

Level 1 of the authorization core system

provides a set of basic authorization policy

primitives which are useful and common for the

policy domains. In this sense, level 1 forms an all-

purpose authorization language. The primitives of

this language include grouping constructs,

delegation, logical inclusion and exclusion (for

example for separation of duties), conflict resolution

strategies.

Level 2, the top layer, hosts the authorization

policies from the authorization policy domains. The

policies of respective domain form a compartment

by their domain, though they are not strictly

separated and may again build interaction and

abstraction structures. This, however, depends on the

specific circumstances of an enterprise.

BUSINESS-DRIVEN ENTERPRISE AUTHORIZATION - MOVING TOWARDS A UNIFIED AUTHORIZATION

ARCHITECTURE

2.1 Virtual Access Matrix

The virtual access matrix provides consumers with

the authorization state, i.e., the permissions, for

retrieval. Conceptually, the access matrix

implements simply a look-up table for all system

permissions. With an ideal access matrix, the

current, correct permissions can be consumed at any

place in the production system, and the retrieval is

very fast. In reality a multitude of access control

systems which are specifically bound to the

information system components are found. These

systems have to be consistently coordinated to allow

an approximation of this idealized access matrix. To

achieve this, the virtual access matrix utilizes a lazy

evaluation mechanism with intelligent caching

which transports the authorization state into the

concerned access control system. In one variant this

mechanism loops into the access requests and

triggers a reconfiguration if necessary. The results

are cached for reuse, taking into account the

structure of the local access control storages. The

other variant pushes a state change actively into the

local stores. A heuristics of the change/request ratio

is used for efficient determination of the

reconfiguration time.

The maximal materialization time, i.e., the

latency from an authorization-relevant until it is

effective in the access control, is specified together

with the event itself since the tolerated delay

naturally depends on the event type.

The virtual access matrix allows not only

retrieval of singular access requests but also

provides query support for access sets. This feature

is useful for reporting and audit, and for user

navigation in congruence with the user’s actual

permissions.

2.2 Authorization Language

The authorization language constitutes the

programming formalism with which the

authorization domains express their authorization

requirements and constraints (authorization

policies). The language contains grouping constructs

and operations as the basic collection structure,

letting a group name representing its members.

Grouping is the base for higher structures like

hierarchical inclusion or other, more complex

structures. Logical inclusion respectively

implication, and exclusion allows the relating of

groups. Groups can be dynamically specified by a

predicate which is evaluated on specified events to

determine group membership. For better

convenience, also a single item can be treated as a

group one-member, (singleton). The grouping

mechanism allows the expression of role models,

and of organisational units. More complex structures

can also be built on grouping.

The authorization language supports delegation

(grant and revoke). Delegation is the base

mechanism for decentralizing the administration of

permissions. Moreover, delegation is not an

administrational convenience, but is a natural

authorization construct. The trivial illustration is

object ownership where the object owner determines

the access rights for other actors, which in turn may

delegate the right. Delegation can become complex

whenever rights are passed on from actor to actor. In

case of cascaded revocationn, the whole path has to

be traced to render the authorization invalid.

Delegation is a prerequisite for the automation of

privileges management.

Basic conflict resolution strategies are required

to handle conflicting authorizations as they arise

from non-monotonous authorization policies. The

nodes of the policy decision graph may also be,

beside conflict resolution strategies, associated with

a substitution or priority strategies. If as resolution is

not possible or undesired, an exception is passed

back.

Priorities may be set for overriding

authorizations, negative or positive, of lower

priority. A priority may be induced by an

authoritative actor expressing an authorization

exception: for example, a client advisor may

exceptionally assign a certain service to a premium

customer in an informal manner. Also policies are

associated with priorities. For example, the security

policy overrules positive authorizations from a role

model.

The authorization language is equipped with

process flow constructs to implement authorization

processes, and which can also be interleaved with

non-authorization workflows, e.g., for call back to

the authorization requester. The process component

allows a loop-in of authorization dialogues into the

non-authorization processes, for example a

disclaimer interaction. Workflow is a precondition

for a smooth integration of authorization into non-

authorization administration processes up to the

level of sharing the user interface forms. The process

aspects of authorization are not different from other

processes besides that they concerned with

authorization.

The authorization language also provides

atomicity constructs to declare a set of primitives as

one coherent unit with transactional semantics. The

system must handle concurrent authorization

requests and still has to preserve consistency.

In its essence, the authorization language is a

logic programming system, such as Prolog is the

classic representative, or such as the upcoming class

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

of business rule systems may implement. Logical

programming languages are declarative, meaning

that a request is formulated to the system without

being concerned with the implementation of how the

result is computed. To compute the result, the logic

system evaluates a set of rules where the system

selects and iterates the rules automatically based on

a thorough mathematical-logical calculus. However,

though being declarative at the frontend, the system

still has to be fed with logical rules. This is the task

of the authorization policy providers and domains.

2.3 Authorization Policy Domains

At Level 2, the enterprise authorization requirements

of the business units are reflected in terms of

authorization policies. In the following we give a

heuristic base canon of policy domains. Refinement

and extension depend on the specific circumstances

and needs of the enterprise. We identify the

following authorization logic domains:

— Enterprise organization structure. This

domain includes the enterprise role model as the

most prominent structure, and the decomposition of

an enterprise into organizational units. Further

structures may refer to projects, and to customer

groups.

— Business processes and their definitions.

From the definitions of business processes and

workflows immediately result authorization

specifications. Besides authorizing actors for the

respective steps in the process sequence, this also

covers more complex specifications as the four-

eyes-principle and separation of duties.

— Legal obligations. This domain represents the

enterprise guidelines on service usage and system

access. For example, customer access to the

information system via internet is not allowed from

any arbitrary countries. Also upcoming privacy-

related obligations reside in this domain.

— Business service agreements. This domain

represents the obligations side of authorizations: If

the enterprise promises its business partners the

availability of certain services, possibly bound to a

contract, the authorization must ensure the

corresponding authorizations. The logic of this

domain refers to the services and the product

structure of the enterprise.

— Information security. This domain provides

the authorization system with the enterprise security

policies. These policies constrain the logic in a

mandatory manner.

Note that the authorization logic domains are not

separated strictly. Moreover there may again be a

structure relating the policies, possibly building

further layers.

2.4 An Illustrating Example

We illustrate the model with the following example.

Assume that, in a bank, a customer may access a

brokerage service. Usage of this service is, due to

legal restrictions, allowed only for customers whose

domicile is in a country included within a particular

country list of the legal department. To determine a

customer’s permission for this service, the

customer’s domicile is required within a certain

predicate of one of the legal policies. The predicate

compares the individual domicile’s country with the

country list. To do this, the predicate retrieves this

information from the CRM-system.

Whenever either a customer’s domicile changes

within the CRM-system or the country list changes,

a recomputation of the permission value is required

before the next access request. The permission may

either not change, may change from positive to

negative, or vice versa. The virtual access matrix

determines the evaluation strategy for the change.

Since in the case the change/access ratio is low, the

reconfiguration is computed immediately and

pushed into the access control systems of the web

and application servers. In the second case where the

country list changes it is of advantage to schedule

the recomputation at a time of low load in the night.

This is allowed because the maximal materialization

delay is specified as ‘within 24 hours’.

Before the first use of the brokerage service the

customer is required to accept a disclaimer as an

enabling precondition. This again is implemented by

means of an active predicate which this time loops

into the brokerage service call. An acceptance is

stored within the authorization system, and the

disclaimer process is not looped-in anymore. But

nevertheless, if the disclaimer text itself changes, the

process automatically starts again with the new

disclaimer.

3 CONCLUSION

In this article we have presented an authorization

system model which enables enterprise system

architects to face the web services challenge from

the authorization perspective. The model provides a

conceptual reference for planning the future

authorization system in order to shift this security

system up to the level the web services paradigm

demands. Though the proposed system yet is

conceptual model, we believe that future products

will be close to this model. To ensure this, the model

combines recent research streams in the field of

authorization, such as policy frameworks and the

utilization of logic languages, with modern system

BUSINESS-DRIVEN ENTERPRISE AUTHORIZATION - MOVING TOWARDS A UNIFIED AUTHORIZATION

ARCHITECTURE

design and architecture. As of today, the system

model can be implemented to certain degree with

existing products such as IBM Tivoli Identity

Manager, Access Manager, and Privacy Manager are

suitable candidates. In that sense the proposed model

provides guidance for a meaningful application of

these products.

The given distinction of authorization and access

control follows the typical responsibilities within an

enterprise organization. We believe that the naive

distinction in which any process at access time is the

access control, and any other process changing

permissions is authorization leads to confusion since

access control products, e.g., Tivoli Access

Manager, feature local portions authorization logic

which clearly must be considered in the specification

of the authorization policies, and should not be left

to the pure access control domain.

A point of discussion is that logic programming

is uncommon in enterprise development units.

Nevertheless we believe that the new class of

business-rule systems may break ground. The

criticism that logic programs increase the system

complexity is invalid since this complexity is only

the reflection of the overall complexity induced by

the web services paradigm.

4 RELATED WORK

Woo and Lam demand in 1993 that authorization be

a system and language in its own respect, which is

distributed, can handle conflicts, and is logic-

oriented (Woo, Lam, 1993). They argue that

authorization is an independent semantic concept,

and criticise that authorization is mainly low-level

and system-specifically addressed. Up to the authors

knowledge, this issue has not been picked up in

terms of a unified system model since. However,

Varadharajan, Crall, and Pato (1998) give a practive-

oriented approach for authorization in a full

enterprise context.

Jajodia Samarati, Sapino, and Subrahmanian

have proposed a framework in which different

access control policies coexist (2001). This is a

necessary prerequisite for complex authorization

systems. The framework is specified in terms of

logic programs. Bertino et al. (2001) also investigate

authorization logics, based on the logic language

Datalog from deductive databases. Ribeiro and

Guedes (1999) provide an authorization language

using the policy approach.

Karjoth and Schunter (2002) describe a privacy

model in the enterprise context. This model

integrates with our authorization model as a policy

provider. Karjoth (2001) also gives an account on

the Tivoli Access Manager which in our model

would form part of the virtual access matrix, but

which also contains authorization logic. (Sandhu et

al., 1996) and (Sandhu, Ferraiolo, Kuhn, 2001)

provide the original treatise on role-based access

control models. Zhang, Ahn, and Chu extend the

role-based model with delegation (2001).

REFERENCES

Bertino, E., Catania, B., Ferrari, E., Perlasca, P., 2001. A

logical framework for reasoning about access control

models, Symposium on Access Control Methodologies

and Techniques (SACMAT).

Dai, J., Alves-Foss, J., 2000. Logic based authorization

policy engineering, available at:

citeseer.nj.nec.com/596575.html.

Jajodia, S., Samarati, P., Sapino, M.L., Subrahmanian,

V.S., 2001. Flexible support for multiple access

control policies, ACM Transactions on Database

Systems, vol. 26, no 2.

Karjoth, G., 2001. The authorization model of Tivoli

Policy Director, Proceedings of the 17

Annual

Computer Security Applications Conference (ACSAC),

New Orleans, Louisiana, pages 319–328.

Karjoth, G., Schunter, M., 2002. A privacy model for

enterprises, Proceedings of the 15

IEEE Computer

Security Foundations Workshop.

Sandhu, R.S., Coyne, E.J., Feinstein, H.L., Youman, C.E.,

1996. Role-based access control models, In IEEE

Computer, vol. 29, no 2.

Sandhu, R., Ferraiolo, D., and Kuhn, R. 2001. The NIST-

model for role-based access control: Towards a unified

standard, Proceedings of 5

ACM Workshop on Role-

Based Access Control, Berlin, Germany.

Varadharajan, V., Crall, C., Pato, J., 1998. Authorization

in enterprise-wide distributed system: a practical

approach, 14th Annual Computer Security Application

Conference (ACSAC).

Woo, T.Y.C., Lam, S.S., 1993. Authorization in

distributed systems: a new approach. Journal of

Computer Security, vol. 2, no. 2–3, pages 107–136.

Zhang, L., Ahn, G.J., and Chu, B.T., 2001. A rule-based

framework for role-based delegation, 6

ACM

Symposium on Access Control Models and

Technologies (SACMAT), Chantilly, Virginia.

Ribeiro, C., Guedes, P. 1999. SPL: An access control

language for security policies with complex

constraints, Technical Report RT/0001/99, INESC.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION
