MODULAR PRODUCTION OF RICH DIGITAL TALKING BOOKS

ıs Carric¸o, Carlos Duarte, Nuno Guimar

aes

Dpt. of Informatic, Faculty of Sciences, University of Lisbon

Campo Grande, Ediﬁcio C5, 1749-016 Lisboa, Portugal

Ant

onio Serralheiro, Isabel Trancoso

L2F INESC-ID

R Alves Redol 9

Keywords:

User Interface Generation, Model-based Tools, Accessibility, User Diversity

Abstract:

This paper presents a framework for automatic production of rich Digital Talking Books (DTB). The pro-

duction process converts existing audio tapes and OCR-based digitalization of text books into full-ﬂedged,

multiple synchronized, multimodal digital books. The framework deals with the content organization pro-

cesses and User Interface deﬁnition. The ﬁrst one identiﬁes content units and its relations. The latter, based on

abstract, yet DTB speciﬁc, pattern-based UI speciﬁcations, allows the deﬁnition of various forms of interaction

and presentation, required by the diversity and constraints of targets users (e.g. visually impaired persons) and

situations of use (e.g. learning). The framework also permits to balance the complexity and ﬂexibility of the

generated DTBs, in order to cope with the resources provided on the different execution platform.

1 INTRODUCTION

Audiotapes have served as an important medium,

and sometimes the only alternative, for print-disabled

reader’s access to books. In several public libraries,

as in the Portuguese National Library, a long time ef-

fort was made in speech recording of a large amount

of printed material. However, the limitations of this

analogue approach, even when compared with their

printed counterparts are noteworthy.

Digital Talking Books (DTBs) are a logical answer.

Work around these identiﬁes requirements and has re-

cently issued a standard speciﬁcation (ANSI/NISO,

2002). Nevertheless, it does not propose speciﬁc

solutions for interaction. In fact, the combination

of synchronization, structural navigation and anno-

tations management, using visual, audio, speech and

standard interactions, poses ambiguity and cognitive

problems that must be dealt with at the UI design level

(Carric¸o et al., 2003a; Morley, 1998). These issues

are stressed by the diversity of targeted users, their

particular disabilities and perspectives. Exploring and

evaluating distinct UIs for the same book, with dif-

ferent multimodal combinations, eventually enriched

with new media contents, is therefore mandatory.

This paper describes DiTaBBu (Digital Talking

Books Builder), a framework for the production of

rich DTBs based on media indexing, speech align-

ment and multimodal interaction elements. The work

was done in the context of the IPSOM project, joining

the Portuguese National Library, a speech processing

research group and multimedia interaction designers

and engineers. The framework draws its requirements

from: (1) the existence of large amounts of recorded

material; (2) the DTB standard; (3) the ﬂexibility

needed for generation of exploratory and adjustable

UIs; and (4) the ability to integrate new multimedia

units in the production process.

In the following section, the article presents the

requirements imposed by users, usage scenarios and

particular project goals, referring related work. Sec-

tion 3 points design decisions that had an impact

on the generated DTBs’ architecture and the execu-

tion platform. Next, the production framework is de-

scribed focussing on its modularity. Finally, conclu-

sions are made and future work is drawn.

2 REQUIREMENTS

The DiTaBBu framework results from requirements

emerged from the diversity of DTB target users, the

DTBs’ usage possibilities, in terms of situational con-

text, richness and support technology, its repurposing

and reuse, and from the characteristics of the available

source material.

158

Carriço L., Duarte C., Guimara es N., Serralheiro A. and Trancoso I. (2004).

MODULAR PRODUCTION OF RICH DIGITAL TALKING BOOKS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 158-163

DOI: 10.5220/0002643901580163

 SciTePress

2.1 Main Target Users

DTBs aim to provide easier access to books, for print-

disabled communities. Work done with those com-

munities, resulted in several guidelines (Daisy Con-

sortium, 2002). The following resumes a list of rec-

ommended navigation features (NISO, 1999a): (1)

support basic navigation (advancing one character,

word, line, sentence, paragraph or page at a time,

and jumping to speciﬁc segments); (2) fast forward

and reverse, and reading at variable speeds; (3) nav-

igation through table of contents or control ﬁle (to

obtain an overview of the book material); (4) read-

ing notes, cross-referencing, index navigation, book-

marks, highlighting, taking excerpts, searching. . . .

DTBs recommendations also point different com-

binations of media, with emphasis on the audio com-

ponent. Here, one should consider the limitations of

audio. Alone, its one-dimensional nature can present

only few items at a time. Combining visual and

spoken presentation requires accurate synchroniza-

tion or speciﬁc visual marking (Duarte et al., 2003).

Methods for conveying structure and assist naviga-

tion, in a non-visual environment, have been re-

searched: 3D audio (Goose and Moller, 1999), audi-

tory icons (Gaver, 1993), multiple speakers and sound

effects (James, 1997), among other techniques. For

DTBs with multiple media presentations, the use of

contextual information (such as containing sentence,

paragraph or section), when navigation or continuous

presentation occurs, was evaluated as well (Carric¸o

et al., 2003a) - results point to the need for differ-

ent contextual units (e.g. the further the navigation

“jump” the bigger the required context). Most of the

studies, however, are not yet conclusive. Exploring

these and other techniques and comprehending the ac-

tual need of visually-impaired people must be still a

subject of evaluation.

2.2 Usage and Playback Devices

The NISO Committee characterizes three types of us-

age and playback devices for DTBs (NISO, 1999b):

(1) basic - portable with simple playing digital au-

dio capabilities (no access to full-text and aims pri-

marily to play continuous audio); (2) advanced - also

portable but should allow to access documents ran-

domly, with navigation possibilities, bookmark set-

ting, etc.; and (3) computer-based - complete and so-

phisticated features. The Daisy Consortium expands

these further, in terms of media combination (Daisy

Consortium, 2002): (1) full audio with title element

only; (2) plus navigation control; (3) plus partial text;

(4) full audio and text; (5) full text and some audio;

and (6) text and no audio. All these should be sup-

ported under the DTB umbrella, which means that

same book ”edition”, and to some extent the same

book (structure and content), could be presented and

interacted in different ways, using more or less re-

sources, and different media and mode combinations.

Consequently, the DTB production mechanism or

execution platform should build on an architecture

that promotes a clear separation between the books’

content and user interface (UI). This will reinforce the

coherence among several usage settings of the same

book. Modularity is further emphasized when con-

sidering a distributed usage (e.g. access to digital li-

braries through remote ”reading places”).

The standard (ANSI/NISO, 2002) identiﬁes a set

of DTB modules (Content, Navigation, Media, Syn-

chronization, Resources, . . . ), for which XML DTDs

are deﬁned. Presentation is handled with style sheets

(CSS or XSL) and SMIL 2.0 (synchronization). This

architecture enables different presentation designs,

and the choice of web-based technology ensures the

required wide dissemination. However, content and

presentation are still intermixed at the same level. For

example, for book’s content, the media correspon-

dence and the presentation sequence are both deﬁned

in the Synchronization ﬁle. This one-level modular-

ity, although coping with several conﬁgurations for

the same book (a DTB for each conﬁguration), hardly

embraces the intrinsic correspondence among them.

It can (as a standard) be used as a ﬁnal format for

DTBs, but a clearer separation of content and UI is

required, on DTB production frameworks and DTB

architectures that provide an enhanced ﬂexibility or

adaptability (Duarte and Carric¸o, 2004).

The use of the DTB standard format has recently

gained momentum (Dolphin Audio Publishing, 2003;

Innovative Rehabilitation Technology inc., 2003; Vi-

suAide, 2003). Nevertheless, other web-standard so-

lutions should be envisaged, if a wider dissemina-

tion and ease of evolution is pursued. Formats fully

compatible with common Web browsers, executing in

general mobile devices, should deﬁnitely be available.

2.3 Reediting and Repurposing

Beyond these ”problem-oriented” proposals, a rich

framework for multimodal interaction opens the way

for information repurposing and creative combination

of elementary media (Carric¸o et al., 2003a). This

broader view of DTBs further affects the modularity

of DTB production and architecture. Along this rich

DTBs construction, multimedia units must be iden-

tiﬁed and classiﬁed, and later reused in the author-

ing of new books or general documents. The stress,

apart from the separation of UI and content, is now on

the modularity of the content itself. Meta-information

and classiﬁers must be introduced, either explicitly or

(preferably) using content analysis techniques. A pro-

duction framework that facilitates this authoring pro-

cess is also further emphasised.

MODULAR PRODUCTION OF RICH DIGITAL TALKING BOOKS

159

2.4 Source Material

The Portuguese National Library provides services

for visually-impaired persons. It has a large amount

of analogue spoken books (audio tapes) and it is also

committed to build digital versions of the books -

scanned, within a XML/HTML envelope. A need for

its integration and the introduction of DTB function-

alities, was clearly felt, particularly by the visually-

impaired community.

Coherence and the huge amount of existing mate-

rial require an ”as automated as possible” form to pro-

duce the DTBs. Such framework should handle: (1)

the expedite identiﬁcation of speech excerpts that cor-

respond to the textual units (alignment); and (2) an

easy speciﬁcation of different UIs and UI patterns for

a book content. The ﬁrst problem is generally handled

by speech recognition technology. The latter is related

with transformation tools and UI generation. Here,

model-based approaches were adopted to handle gen-

eration of UIs for different users and devices (Patern

2000), the creation of UIs for multiple devices (Eisen-

stein et al., 2001; Ali and P

erez-Qui

nones, 2002; Lin

and Landay, 2002) or its adaptation to different de-

vices (Calvary et al., 2001). This is a ﬁeld where the

transition to the commercial software world has not

occurred, in part because of the abstraction level used

in the speciﬁcation. However, in the case of DTB pro-

duction, with the particularities of the domain, there

is not such a great emphasis on abstraction, and the

generation process can be more easily adopted.

3 DESIGN OPTIONS

In view of the stated requirements, the work con-

ducted within the IPSOM project has evolved through

a series of design options presented next.

3.1 Navigation Features

The navigation functionalities are fully considered in

the built DTBs, except for the variable speed-reading

and the thinner (character and word-based) basic nav-

igation support. The ﬁrst requires a complete speech

model in order to maintain low voice distortion and

was not considered. An alternative, currently un-

der evaluation, is the reduction or extension of sen-

tence separation (silence, or breathing times), com-

bined with small speed changes. The second feature

strongly depends on the ability to isolate character

and word sounds from the continuous speech record-

ing. However, tests made with word-based navigation

generated incomplete sounds, that users felt displeas-

ing in evaluation studies (Duarte et al., 2003). An al-

ternative may be the introduction of speech synthesis.

Pertaining to DTB categories all variants are sup-

ported, from full audio and text, to plain audio or plain

text. Here, the DiTaBBu production framework facil-

itates the several versions’ maintenance and provides

the means for exploratory modality combinations.

3.2 Architecture and Platform

Based on DTB recommendations, Web-based tech-

nology was adopted. Several DTB formats and ar-

rangements are possible. The architecture includes:

• An XML-based content speciﬁcation without refer-

ences to UI issues. Content includes text and other

media (in speciﬁc formats), media anchoring points

and correspondence (to text or between media), and

structure. Navigation facilities, bookmarking and

annotations, margin notes and other secondary con-

tent follow a similar approach, whenever possible,

close to the DTB standards. No presentation or

synchronization are considered at this level.

• One or more XSLT-based translation speciﬁcations

enabling the creation of UIs for the content.

• The UI, including speciﬁc interaction objects when

required. Presentation could use several formats

and arrangements, from plain SMIL (plus CSS), to

versions fully compliant with the DTB standard.

The introduction of the XSLT level permits to build

different UIs, using alternative DTB formats, and still

maintaining the coherence towards books’ content. It

also allows to balance the generation of the UI, be-

tween the production framework and the execution

platform (ﬁg. 1). The framework generates XML

and XSLT documents (plus target language templates,

CSS, . . . ) representing the DTB and the UI build-

ing rules. If the execution platform is able to process

XSLT, a book following the above three-layer organi-

zation can be used. Alternatively, if performance is

an issue or the platform does not support it, DiTaBBu

could generate the ﬁnal (one or two-layer) DTB con-

ﬁgurations (e.g. a DTB fully compliant with the stan-

dard or a SMIL version, in any DTB category).

Raw

Digital

Sound

Raw

Digital

Text

UI-patterns

Scripts,

CSS, …

Transf

XSLT

Content

XML,

WAV, …

Actual UI

(e.g. SMIL

+ CSS + …)

Content

XML,

WAV, …

Actual UI

(e.g. SMIL

+ CSS)

DiTaBBu Framework

Browser

Figure 1: Balancing performance and ﬂexibility.

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

160

Internet Explorer 6 was adopted as a base, yet

powerful, execution platform. This choice enabled

the use of HTML+TIME (and CSS), a representa-

tive of a SMIL 2.0 proﬁle, and Microsoft’s variant

of VoiceML, for voice interaction. Both architectural

arrangements are supported, since the browser pro-

cesses XSLT. In the simplest form, the digital book

is a (set of) HTML+TIME, CSS and media ﬁles. For

voice interaction with DTBs, off-the-shelf products,

recognizing Portuguese language, were initially used

with very bad performance results. The Microsoft’s

implementation of VoiceML, provided better results,

but using English as interaction language. Currently,

Portuguese speech recognition software, developed

within the IPSOM project’s teams, is being integrated.

3.3 Automation and Initial Corpus

The initial pilot corpus was the ”O Senhor Ventura”

(a novel by Miguel Torga). Since the audio quality

of the existing tape was very poor, both in terms of

noise and diction, a clean audio stream was recorded

on a soundproof booth, using a professional reader.

Other books were also used (Serralheiro et al., 2003).

For the moment, however, the automation process re-

quires fairly good audio recording, making it difﬁcult

to use the original audio tapes. Reﬁnement of the

speech alignment component is currently under work,

in order to circumvent audio tapes quality.

4 THE FRAMEWORK

The DiTaBBu framework generates DTBs through

an automatic production process, conﬁgured by a set

of speciﬁcation ﬁles that allow the required ﬂexibil-

ity. Internally the framework is decomposed into two

main phases: content organization and UI-generation.

4.1 Content Organization Phase

This phase (ﬁg. 2) is responsible for the integration of

media ﬁles and auxiliary content (margin notes and

indexes) with the main book content. The phase in-

cludes a set of modules for speciﬁc media processing,

a structuring module and a set of linker modules. All

modules generate ﬁles according to particular XML

dialects. The phase result is: (1) a content description

ﬁle, compliant with the DTB standard and containing

the book text and other information extracted from the

media ﬁles (e.g. ”Part I” sounds like ”part one”); (2)

a set of media and linking ﬁles that establish the cor-

respondence between content and media; (3) a set of

auxiliary components (not in the ﬁgure) also linked

with the content. The modules are:

• The media-processing modules generate indexa-

ble-media components, with media and media-

anchoring ﬁles. These describe the media content

and a set of anchor points that enable direct ac-

cess to locations within the speciﬁc media (Dexter

components). For example, an image-processing

ﬁle could contain anchors to regions - ”<region

id=’1’ position=’3:5’ size=’10:20’>A BARKING

DOG</region>” - of an image ﬁle (e.g. a JPG).

• The structuring module (re)introduces the book

structure into the main content. The result is a DT-

Book.DTD compliant ﬁle. The module input is the

raw digital text, a set of rules to extract structure

and speciﬁc structure deﬁnition if needed.

• The linker modules draw information from the

above results, enrich the textual content description

and structures, and convert the media-anchoring

ﬁles into link speciﬁcation ﬁles. Speciﬁc linker

modules link auxiliary content with the main con-

tent. The process is similar to media integration

except that input ﬁles may be composed of several

media (e.g. margin notes with text and audio).

Figure 2: DiTaBBU: content organization phase.

As an example of media-processing module, con-

sider speech alignment (ﬁg. 3). This module is re-

sponsible for locating word limits on the speech au-

dio signal and generating the indexable-media com-

ponent. It is built of four sub modules: a striper, a

characteristics extractor, a forced aligner and a tag-

ger. The ﬁrst extracts punctuation and expands abbre-

viations, in order to feed a stream of words, similar to

the audio version, into the forced aligner.

Extractor and forced aligner form a speech recog-

nizer. The latter is based on Weighted Finite State

Transducer (WFST) (Mohri et al., 1998), as its search

space is deﬁned by a distribution-to-word transducer

built outside the decoder. It can be used with and

without phonological rules (Trancoso et al., 2003).

The rules cover vowel devoicing, deletion and coales-

cence, voicing assimilation, and simpliﬁcation of con-

MODULAR PRODUCTION OF RICH DIGITAL TALKING BOOKS

161

Figure 3: DiTaBBU: speech alignment module.

sonantal clusters, both within and across word bound-

aries. All rules are optional and compiled into WF-

STs. The search space comprises a phone topology,

a lexicon and a language model. The phone topol-

ogy uses hybrid acoustic models, combining the tem-

poral modelling capabilities of Hidden Markov Mod-

els (HMM) with the pattern classiﬁcation capabilities

of Multi-Layer Perceptrons (MLP). Three MLPs are

given the acoustic parameters and the streams of prob-

abilities are then combined using an appropriate algo-

rithm. The language model is the sequence of words

that constitute the orthographic transcription of the ut-

terance. The lexicon is extracted from that sequence.

The main advantage of this approach is that no re-

strictions are placed on the construction of the search

space. The result is a table with the audio stream tim-

ing for each of the spoken words.

The tagger normalizes the table into a XML media-

anchoring ﬁle, including a general speech description

(e.g. reader, full audio time) and anchors for each

aligned word.

4.2 UI-generation Phase

In the initial steps of the UI-generation phase (ﬁg. 4,

DiTaBBu presents a set of interpreter modules. Each

module receives XML-based ﬁles with content, and

a speciﬁcation ﬁle describing the patterns and rules

to be applied. Those speciﬁcation ﬁles follow XML-

based dialects dependent on the module. Internally

it also uses XSLT code and XSLT templates that are

selected and adjusted according to the speciﬁcation,

in order to generate the output (XML and XSLT).

Two groups of interpreters can be identiﬁed, relat-

ing to primary and secondary material. The primary

material modules are the playback and navigation in-

terpreters. They deal with the main content, not con-

sidering footnotes, margin notes and navigation auxil-

iaries (indexes, tables of content, . . . ). The respective

dialects handle the visual and audio logical markup

and their synchronization. For example:

• <showsync delay=‘2s’ sunit=‘silence’/> means

that playback will show visual synchronization

marks (the visual effect is speciﬁed later in the

Figure 4: DiTaBBU: UI-generation phase.

CSS) delayed by 2 seconds and using the words

between reading silences as a unit - the whole unit

is marked (e.g. underlined) as narration evolves;

• <onsearch sunit=‘word;paragraph’ base-

don=‘paragraph,section’ /> means that in result of

a search, the narration (sound) should start on the

word found or on the beginning of the paragraph

containing that word, depending on how distant

(paragraph of section) from the current reading

position the searched text is.

The secondary modules handle auxiliary naviga-

tion structures, user annotations, etc. Apart from the

speciﬁcity of their dialects (e.g. <show summary>

on annotations), the synchronization rules with the

primary content are also speciﬁable.

The remainder steps of the UI-generation phase

provide: (1) the integration and ﬁltering of the above

outputs; and (2) the (optional) generation of the ﬁnal

presentation. The former generates a set of XSLT and

XML content ﬁles that can be also interpreted by the

execution platform.

5 CONCLUSIONS

This paper presented DiTaBBu, a framework for the

production of DTBs. We have described the require-

ments and the related work, and consequent options

taken for the framework design, the generated books’

architecture and the execution platform. The pro-

duced DTBs provide the functionalities intended in

the standards literature, including audio and text syn-

chronization, annotations, navigation through mouse,

keyboard and voice commands. Description and us-

ability evaluation tests of the multifaceted DTBs can

be seen elsewhere (Carric¸o et al., 2003a; Duarte et al.,

2003). These studies focused on UIs variants, gen-

erated by DiTaBBu from the same book (”O Senhor

Ventura”). Different synchronization units, visual and

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

162

audio marking of navigation anchors, playback and

annotation synchronization were used, as well as dif-

ferent forms of interaction.

The modularity of the platform’s architecture en-

ables the ﬂexibility required for the creation of such

multiple UIs for DTBs, maintaining a mostly auto-

matic production and reinforcing coherence towards

the books’ contents. The use of rule based mod-

ules and templates stresses that ﬂexibility, permitting

that speciﬁcation languages are maintained at a con-

venient high level, focussed on DTB publishing.

As ongoing work, we are conceiving tools for

graphical speciﬁcation of the modules conﬁguration

ﬁles. In line of hypermedia related works (Carric¸o

et al., 2003b; Kraus and Koch, 2002) it is being de-

ﬁned an UML description of those speciﬁcation di-

alects, that in turn will generate the XML speciﬁ-

cations. Work is also being done in the integration

of images: an image-processing module and image-

linker modules for textual and speech-based descrip-

tion of such images.

REFERENCES

Ali, M. F. and P

erez-Qui

nones, M. A. (2002). Using

task models to generate multi-platform user interfaces

while ensuring usability. In Proceedings of Human

Factors in Computing Systems: CHI 2002 Extended

Abstracts, pages 670–671, Minneapolis, MN.

ANSI/NISO (2002). Speciﬁcations for the digital talking

book. http://www.niso.org/standards/resources/Z39-

86-2002.html.

Calvary, G., Coutaz, J., and Thevenin, D. (2001). A unify-

ing reference framework for the development of plas-

tic user interfaces. In Proceedings of Engineering

for Human-Computer Interaction: EHCI 2001, pages

173–192, Toronto, ON, Canada. Springer Verlag.

Carric¸o, L., Guimar

aes, N., Duarte, C., Chambel, T., and

Sim

oes, H. (2003a). Spoken books: Multimodal inter-

action and information repurposing. In Proceedings

of HCII’2003, International Conference on Human-

Computer Interaction, pages 680–684, Crete, Greece.

Carric¸o, L., Lopes, R., Rodrigues, M., Dias, A., and An-

tunes, P. (2003b). Making XML from hypermedia

models. In Proceedings of WWW/INTERNET 2003,

Algarve, Portugal.

Daisy Consortium (2002). Daisy structure guidelines.

http://www.daisy.org/publications/guidelines/sg-

daisy3/structguide.htm.

Dolphin Audio Publishing (2003). EaseReader - the

next generation DAISY audio eBook software player.

http://www.dolphinse.com/products/easereader.htm.

Duarte, C. and Carric¸o, L. (2004). Identifying adaptation

dimensions in digital talking books. In Proceedings of

IUI’04, Madeira, Portugal.

Duarte, C., Chambel, T., Carric¸o, L., Guimar

aes, N., and

Sim

oes, H. (2003). A multimodal interface for digital

talking books. In Proceedings of WWW/INTERNET

2003, Algarve, Portugal.

Eisenstein, J., Vanderdonckt, J., and Puerta, A. (2001). Ap-

plying model-based techniques to the development of

UIs for mobile computers. In Proceedings of the In-

ternational Conference on Intelligent User Interfaces:

IUI 2001, pages 69–76, Santa Fe, NM. ACM Press.

Gaver, W. (1993). Synthesizing auditory icons. In Proceed-

ings of INTERCHI’93, pages 228–235, Amsterdam,

The Netherlands.

Goose, S. and Moller, C. (1999). A 3d audio only interac-

tive web browser: Using spatialization to convey hy-

permedia document structure. In Proceedings of the

7th ACM Conference on Multimedia, pages 363–371,

Orlando, FL.

Innovative Rehabilitation Technology inc. (2003).

eClipseReader. http://www.eclipsereader.com/.

James, F. (1997). Presenting htlm structure in audio: User

satisfaction with audio hypertext. In Proceedings of

ICAD’97, pages 97–103, Palo Alto, CA.

Kraus, A. and Koch, N. (2002). Generation of web appli-

cations from UML models using an XML publishing

framework. In Proceedings of the 6th World Con-

ference on Integrated Design and Process Technology

(IDPT).

Lin, J. and Landay, L. (2002). Damask: A tool for early-

stage design and prototyping of multi-device user in-

terfaces. In Proceedings of the 8th International

Conference on Distributed Multimedia Systems, pages

573–580, San Francisco, CA.

Mohri, M., Riley, M., Hindle, D., Ljolje, A., and Pereira, F.

(1998). Full expansion of context-dependent networks

in large vocabulary speech recognition. In Proceed-

ings of ICASSP 98, Seattle, Washington.

Morley, S. (1998). Digital talking books on a pc: A usability

evaluation of the prototype daisy playback software.

In Proceedings of ASSETS’98, pages 157–164, Ma-

rina Del Rey, CA.

NISO (1999a). Document navigation features list.

http://www.loc.gov/nls/z3986/background/naviga-

tion.htm.

NISO (1999b). Playback device guideline.

http://www.loc.gov/nls/z3986/background/features.htm.

Patern

o, F. (2000). Model-Based Design and Evaluation of

Interactive Applications. Springer Verlag.

Serralheiro, A., Trancoso, I., Caseiro, D., Chambel, T.,

Carric¸o, L., and Guimar

aes, N. (2003). Towards a

repository of digital talking books. In Proceedings of

Eurospeech 2003.

Trancoso, I., Caseiro, D., Viana, C., Silva, F., and Mas-

carenhas, I. (2003). Pronunciation modeling using ﬁ-

nite state transducers. In Proceedings of ICPhS’2003,

Barcelona, Spain.

VisuAide (2003). Victor reader. http://www.visuaide.com.

MODULAR PRODUCTION OF RICH DIGITAL TALKING BOOKS

163
