SOLVING TRANSACTIONAL CONTROL IN CURRENT

MANAGEMENT FRAMEWORKS

Vitor Roque

Polytechnic Institute of Guarda, ESTG, Guarda – Portugal

José Luís Oliveira

University of Aveiro, DET, Aveiro – Portugal

Rui P. Lopes

Polytechnic Institute of Bragança, ESTiG, Bragança – Portugal

Keywords: Policy based management, policies, network management, transactions.

Abstract:

Policy Based Network Management has been presented as a paradigm for efficient and customisable

management systems. The IETF has provided a framework to describe the concept but some aspects still

open like transactional control. In fact transactional control mechanisms are receiving today great attention

in the scope of network management. In here, we identify the lacks of current management paradigms

concerning transactional control and we propose a policy-based network management system that allows

specify operations over aggregations of agents and that provides high-level atomic transactions.

1 INTRODUCTION

Today’s information systems are typically based on

a large numbers of heterogeneous computing

devices connected through communication

networks, and joining together various resources,

services, and user applications. These resources and

applications are now indispensable to organizations,

but as the whole system becomes increasingly larger

and more complex, also a higher number of elements

can be the source for the disruption of critical

business operations. In fact, network management

has gained in the last years great importance due the

increased dependence of the enterprises on their

computer systems, networks and networked

applications. This dependence has made availability

and performance of the network infra-structure and

network services more critical than ever. In addition,

the growth in size and complexity of modern

networks increases the need of standard

configuration mechanisms for an efficient network

management. It is expected that these mechanisms

are strongly related to fault-tolerance systems as

well with performance management systems. The

concept of policy-based management has emerged

during the last years as an adequate paradigm to deal

with this type of requirements and this concept has

been widely supported by standards organizations

such as the IETF and DMTF. In fact the Policy

Working Group is chartered to define a scalable and

secure framework for policy definition and

administration.

The development of policy-based management

appl

ications, due to the diversity and type of

equipments, can be very complex in structure, with

complex relationships between their constituent

parts. Because of these, the success of network

operations (configuration operations and others) is a

critical issue in network management thus deserving

great attention. In fact transactional control

mechanisms are receiving today great attention in

the scope of network management. In here, we

identify the lacks of current management paradigms

concerning transactional control and we propose a

policy-based network management system that

allows specify operations over aggregations of

agents and that provides high-level atomic

transactions.

523

Roque V., Luís Oliveira J. and P. Lopes R. (2004).

SOLVING TRANSACTIONAL CONTROL IN CURRENT MANAGEMENT FRAMEWORKS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 523-526

DOI: 10.5220/0002644305230526

 SciTePress

2 NETWORK MANAGEMENT

PBNM technologies have been developed to reduce

the configuration complexity of the network and its

nodes. It is desirable that a network management

system technology will be provided with the ability

to automatically manage the network configuration

based upon high-level rules, more or less in the same

way business-oriented requests are issued (Sloman

1994). In fact, policies definition aim at replacing

the dependency on vendor and device specific

configuration commands, thus making network

management a homogenous task independent of the

installed equipment. For example, a management

system should be capable, in a specific management

situation, of offering facilities to reconfigure the

whole system without the network administrator

having to worry about the configuration details of

network equipment.

The policy concept is quite wide (Moore,

Ellesson et al. 2001) – policies can be applied in

QoS management, access control, security or other

areas. Policies are defined by users, such as network

administrators or operators, stored and handled in

policy servers, and deployed on network nodes. The

execution of a policy depends on the evaluation of a

check-action rule that is activated when the implicit

condition or conditions are verified. Although the

main ideas are simple, the development and wide

adoption of policy-based management applications

have been complex. Issues such as policy format,

enforcement mechanisms, conflict avoidance, low

level protocol mapping, user-interface representation

and edition, just to name a few, are being a mater of

research and standardization. Today several

standardization organizations are working on this

subject, namely IETF and DMTF. As the result of

their work new proposals have been developed such

as COPS (Durham, Boyle et al. 2000; Chan,

Seligson et al. 2001), SNMP for Configuration

(MacFaden, Partain et al. 2003), PCIM (Moore,

Ellesson et al. 2001).

These works also stimulate the definition of the

policy framework architecture, composed of four

functional entities namely the Policy Management

Tool (Policy Console), the Policy Repository, the

Policy Decision Point or Policy Server (PDP) and

the Policy Enforcement Points (PEP) (Kosiur 2001).

This model describes the key components but it

does not prescribe any kind of implementation

details such as distribution, platform or language.

Policies and Transactions

The configuration activity and policies execution

causes state changes in network elements and it is

critical that this operation is executed atomically to

maintain the network elements in a consistent state.

PBNM systems must have mechanisms that in

case that the configuration of any equipment fails,

all the other network equipment which is involved in

that configuration must return to the last good

configuration installed.

Considering this situation, PBNM systems must

implement the ACID properties of Distributed

System theory, i.e., the applications must have the

capability of monitoring the execution of

configuration operations. If an operation would

compromise one of the ACID properties the system

must have the ability to return to the previous

configuration state (Gray and Reuter 1994;

Coulouris, Dollimore et al. 2001). We can associate

the term transaction with the term policy, i.e., we

may consider a policy as a transaction, where we

must execute all of the operations (rules –

conditions/actions) or none, in case something fails.

The definition of a transaction mechanism is also

necessary due the wide-nature of the networks, i.e.,

in large networks the time necessary to configure the

whole network, all the network elements, could be

long, running for minutes, hours or even days.

Although the network transportation protocols have

mechanisms, like “timeout” and “keep alive”

messages on COPS, to control the fault-tolerance,

this mechanisms/functions seems to be insufficient

because in certain situations the configuration effort

is too valuable to be undone.

Figure 1: Flow of the proposed fault-tolerance mechanism.

send

policy

start

examine

policy

test

policy

execute

policy

undo

clean

end

start

transaction

end

transaction

not ok

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

524

3 A MECHANISM FOR

TRANSACTIONAL CONTROL

The definition of a mechanism for transactional

control on PBNM systems is essential because the

trust on transactional integrity at the protocol level

seems insufficient (MacFaden, Partain et al. 2003).

The mechanism here proposed uses the concepts of

server (PDP) and agent (PEP) of the IETF

conceptual policy model. The communication model

adopted is unidirectional, from PDP to PEP, because

the network management will be done in a

centralized way at the PDP, which will also have the

responsibility of querying the PEPs concerning the

policies installation. In this mechanism the

configuration process is based on five basic

commands: (1)

examine (PDP->PEP) – Tells the

agent to carry out the operations related to the policy

without applying them; (2)

test (PDP->PEP) – this

command is issued by the server to ask the agent if

the policy installation can be applied with success;

(3)

execute (PDP->PEP) – it is indicated to the

agent that it must install the policy; (4)

undo (PDP-

>PEP) – if error, this command is issued by the

server to indicate agent to forget about the policy

installation and (5)

clean (PDP -> PEP) – it will be

issued by the server to indicate that the agent should

release the resources used by the temporary storage

of the policy.

The working mode of this mechanism is the

following: suppose that is planned to install a policy

on the network elements of an administrative

domain. In this mechanism it is assumed that the

PDP is the central element in the policies

distribution and the PEP´s (agents) must be always

in a listening state, waiting to be contacted by the

server. The configuration information (policies) is

sent to the various agents through the

examine

command, and it is of the responsibility of the agent

to verify if the policies can be installed, i.e., if there

is no incompatibility concerning the possibility of

policies installation. Next, the server issues the

test

command, to verify if no problems were detected

and that the policies are prepared to be installed in

the agent. This process is repeated in all agents of

the PEPs in the administrative domain. On the next

phase, the server (PDP) requests to all agents (PEPs)

execute the command – the effective installation

of the policy. If the query made to the

test command

was affirmative by all the agents, the server issues

the clean command for the agents to release the

resources allocated during the operations. In the case

of non affirmative answer by one or more agents to

the

test command, the server issues the undo

command for the reposition of the precedent state

configuration. Finally, the server issues the

clean

command to all the agents, telling them to release

the resources allocated during the operations. On

Figure 1 it is represented the flow information

diagram of the mechanism proposed.

The configuration information is sent in a high-

level file format, following the Extensible Markup

Language (XML) (W3C 2003). This file content is

then translated in accordance with the language and

protocol used by the PEP. All these tasks are of the

responsibility of the server (PDP) and are

independent of the transactional control mechanism

proposed. If the transaction was successful, it is

possible to assure, that the network has passed from

one consistent state to another consistent state.

4 TRANSACTIONS

REPRESENTATION

Transactions, or the definition of atomic sets of

policies, should be easy to define, in a graphical user

interface. The purpose of this mechanism is related

GUI - Policy

Editor

Converter

specific management

data

Policy

XML

validator

XML data

network

element 1

network

element n

...

managed objects

XML -

DTDs and

Schemas

Transactional

Control

Mechanism

no XML data

XML data

Figure 2: XML model for policies.

SOLVING TRANSACTIONAL CONTROL IN CURRENT MANAGEMENT FRAMEWORKS

525

with the previous work, namely the build of a

prototype for policy representation in a graphical

way (Roque, Oliveira et al. 2003).

With the development of this mechanism it will

be possible to endow the visual policy editor with

transactional control, i.e., to make available the

interfaces of the transactional mechanism to be used

by the application (visual policy editor), keeping in

this way the separation between application –

mechanism.

The policy editor allows the user to define

policies using a single specification language: XML.

The resulting information is then transferred to the

network elements using a common syntax. The

XML file must follow the rules defined in a standard

template (DTD/Schema) where it is referred all the

relevant information that the policy must have. After

validation, the policy must be sent to the network

elements (Figure 2). If the network elements

(agents) are XML compatible, the policy is

immediately delivered through the transactional

control mechanism, in the case that network

elements do not support XML, the policy will have

first to pass through a converter. The converter will

transform the XML policy into a specific language

that the network element could understand. After the

transformation the policy is delivered to the network

element by the transactional mechanism.

Having the network elements (agents) received

the policies, the transactional mechanism grantees

that the policies are manipulated in accordance with

the ACID properties.

5 CONCLUSIONS

Policy-Based Configuration Management is a

methodology wherein configuration information is

derived from rules and network-wide objectives, and

is distributed to many potentially network elements

with the goal of achieving a consistent network

behaviour.

The configuration activity causes state changes

in the network elements and it is critical that the

configuration system treats all the configuration

operations atomically.

The development of a transactional mechanism

for the management of policies installation in the

various network elements, is because on the work

that comes being developed, we discovered some

gaps in the existing management models about this

matter, i.e., this kind of work is left to the central

management systems, that will have to handle, case

by case, its implementation.

Within this paper we made some considerations

about the importance of the transactional

mechanisms at the level of policies specification and

presented some solutions that could be used in today

systems. The definition of this mechanism is based

on the supposition that simple commit/rollback

semantics of an ACID transaction is enough. With

this supposition, even in the presence of failures, the

state transition of the network elements is guarantee

by the atomicity of the transactions.

REFERENCES

Chan, K., J. Seligson, et al. (2001). COPS Usage for

Policy Provisioning (COPS-PR) - RFC3084, IETF.

Coulouris, G., J. Dollimore, et al. (2001).

Distributed

Systems - Concepts and Design, Addison-Wesley.

Durham, D., J. Boyle, et al. (2000). The COPS (Common

Open Policy Service) Protocol - RFC2748, IETF.

Gray, J. and A. Reuter (1994).

Transaction Processing:

Concepts and Techniques, Morgan Kaufmann.

Kosiur, D. (2001).

Understanding Policy-Based

Networking, Wiley.

MacFaden, M., D. Partain, et al. (2003). Configuring

Networks and Devices With SNMP - RFC3512, IETF.

Moore, B., E. Ellesson, et al. (2001). Policy Core

Information Model Specification v1 - RFC3060, IETF.

Roque, V., J. Oliveira, et al. (2003).

Visual Composition

of Management Policies. 4th Conference on

Telecommunications (ConfTele2003), Aveiro -

Portugal.

Sloman, M. (1994). "Policy driven management for

distributed systems."

Journal of Management

Information Systems 2(4): 333-360.

W3C (2003). W3C XML Documents.

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

526
