TURNING THE WEB INTO AN EFFECTIVE KNOWLEDGE

REPOSITORY

ıs Veiga

INESC-ID / IST

Rua Alves Redol, 9, 1000 Lisboa, Portugal

Paulo Ferreira

INESC-ID / IST

Rua Alves Redol, 9, 1000 Lisboa, Portugal

Keywords:

world wide web, dynamic content management, web proxy, distributed cycles, distributed garbage collection.

Abstract:

The weight of dynamically generated content versus static content has progressed enormously. Preserving ac-

cessibility to this type of content raises new issues. However, there are no large-scale mechanisms to enforce

referential integrity in the WWW. We propose a system, comprised of a distributed web-proxy and cache ar-

chitecture, to access and automatically manage web content, static and dynamically generated. It is combined

with an implementation of a cyclic distributed garbage collection algorithm. It is scalable, correctly handles

dynamic content, enforces referential integrity on the web, and is complete with regard to minimizing storage

waste.

1 INTRODUCTION

To fulﬁll Vannevar Bush’s Memex (Bush, 1945) and

Ted Nelson’s Hyper-Text (Nelson, 1972) vision of a

world-size interconnected store of knowledge, there

are still quite a few rough-edges to solve. These

must be addressed before the world wide web can

be regarded as an effective and reliable world wide

knowledge repository. This includes safely preserv-

ing static and dynamic content as well as perform-

ing storage management in a complete manner. An

effective world wide knowledge repository, whatever

its implementation, should enforce some fundamental

properties: i) allow timely access to content, ii) pre-

serve all referenced content, regardless of how it was

created, and iii) completely and efﬁciently discard ev-

erything else.

There are no large-scale mechanisms to enforce

referential integrity in the WWW; broken links prove

this. For some years now, this has been considered a

serious problem of the web (Lawrence et al., 2001).

This applies to several types and subjects of content,

e.g., i) if a user pays for or subscribes some service

in the form of web pages, he expects such pages to

be reachable all the time, ii) archived web resources,

either scientiﬁc, legal or historic, that are still refer-

enced, need to be preserved and remain available, and

iii) dynamically generated content should also be ac-

This work was partially funded by FCT/FEDER.

counted and it should be possible to preserve different

execution results with time information.

Broken links, i.e., the lack of referential integrity

of the web, is a dangling-reference problem. With re-

gard to the web this has several implications: annoy-

ance, breach of service, loss of reputation and, most

importantly, effective loss of knowledge. When a user

is browsing some set of web pages, he requires such

pages to be reachable all the time. He/she will be an-

noyed every time he tries to access a resource pointed

to from some page, just to ﬁnd out that it has simply

disappeared.

As serious as this last problem, there is another one

related to the effective loss of knowledge. As men-

tioned in earlier works, broken links on the web can

lead to the loss of scientiﬁc knowledge (Lawrence

et al., 2001). We dare to say that, in the time to come,

this problem can affect legal and historical knowl-

edge, as these areas become more represented on the

web.

It is known that every single document in these

ﬁelds is stored in some printed or even digital form

in some library. But, if this knowledge is not easily

accessible, throughout the web, and its content pre-

served while it is still referenced (and it will be), it

can be considered as effectively lost because it will

not be read by most people who are not able, or will-

ing, to search for printed copies.

This is not, as yet, a serious situation but, as web

154

Veiga L. and Ferreira P. (2004).

TURNING THE WEB INTO AN EFFECTIVE KNOWLEDGE REPOSITORY.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 154-161

DOI: 10.5220/0002644401540161

 SciTePress

content gets older, it will become an important issue.

Nevertheless, solutions that try to preserve every and

anything can lead to massive storage waste. There-

fore unreachable web content, i.e. garbage, should be

reclaimed and its storage space re-used.

The weight of dynamically generated content ver-

sus static content has progressed enormously. From

a few statically disposed web pages, the WWW has

become a living thing with millions of dynamically

generated pages, resorting to user context, customiza-

tion, user class differentiation. Today, the vast ma-

jority of web content is dynamically generated, shap-

ing the so-called deep-web, and this has been increas-

ing for quite some time now (O’Neill et al., 2003;

Bergman, 2001). This content is frequently perceived

by users as more up to date and accurate, therefore

having more quality. Since this content is generated

on-the-ﬂy, it is potentially different every time the

page is accessed.

It is clear that this type of content cannot be pre-

served by simply preserving the scripting ﬁles that

generate it. This is specially relevant with content

changing over time. It is produced by scripting

pages that, although invoked with the same parame-

ters (identical URL), produce different output, at ev-

ery invocation, or periodically. Examples of these in-

clude stock tickers, citation rankings, ratings of every

kind, stocks inventories, so called last-minute news,

etc. So, changes in produced output, or in the un-

derlying database(s), should not prevent users from

preserving content of interest to them, and keep easy

access to it.

In fact, data is only lost when actual data sources

(e.g. database records) are deleted. Nevertheless, it

could become otherwise unavailable causing effective

loss of information, because the data would still reside

somewhere but inaccessible, since the exact queries

to extract it would not be known. Thus, dynamic con-

tent, in itself, must also be preserved while it is still

referenced and not just the script/pages that generate

it. Furthermore, other pages pointed by URLs in-

cluded in every reply of these dynamic pages must be

preserved, i.e., content dynamically referenced must

be also preserved while it is reachable.

1.1 Shortcomings of Current

Solutions

Current approaches to the broken-link problem on the

world wide web are not able to i) preserve referen-

tial integrity supporting dynamically generated con-

tent and, ii) minimize storage waste due to memory

leaks in a complete manner. Therefore, the web is not

effectively a knowledge repository. Useful content,

dynamic and/or static, can be prematurely deleted

while useless, unreachable content wastes systems re-

sources throughout the web.

Nowadays, content in the WWW is more intercon-

nected than ever. What initially was comprised of a

set of almost completely separated sites with few links

among them has become a through highly connected

web of afﬁliated sites, portals, ranging from entertain-

ment to public services. It is not uncommon to notice

web sites that besides their in-house generated con-

tent, link, many times as part of a subscribed service

(payed or not), to content produced and maintained

in different sites. These referring sites should have

some kind of guarantee, in terms of maintenance, that

this referred content will still be available as long as

there are subscribers interested in it, i.e., some kind of

referential integrity should be enforced.

Current solutions to the problem of referential in-

tegrity (Kappe, 1995; Ingham et al., 1996; Moreau

and Gray, 1998) do not deal safely with dynamic con-

tent and are not complete, since they are not able to

collect distributed cycles of unreachable web data.

Some previous work (Creech, 1996; Kappe, 1995),

while enforcing referential integrity to the web, im-

pose custom-made (or customized) authoring, visu-

alization or administration schemes. However, for

transparency reasons and ease of deployment, it is

preferable to have a system that enforces referential

integrity on the web, to content providers and sub-

scribers, in a mostly transparent manner, i.e., based

solely on proxying with minor server and/or client ex-

tensions.

Previous approaches (Reich and Rosenthal, 2001)

to the broken-link problem, replicate web resources

in order to preserve them, in an almost indiscriminate

fashion, wasting storage space and preserving content

no longer referenced. This stems from the goal that

included to provide high availability of web content

but not to manage storage space efﬁciently. Thus, they

are not complete with regard to storage waste, i.e.,

they do not reclaim useless data.

Thus, only some of the existing solutions attempt

to enforce referential integrity on the web and also re-

claim content which is no longer referenced from any

root-set (these root-sets may include bookmarks, sub-

scription lists, etc). These solutions (Ingham et al.,

1996; Moreau and Gray, 1998), however, are either

unsafe in the presence of dynamically generated con-

tent, or they are not complete.

1.2 Proposed Solution

The purpose of this work is to develop a system that:

• enforces referential integrity on the web. It pre-

serves, in a ﬂexible way, dynamic web content as

seen by users; and preserves resources pointed by

references included in preserved dynamic content.

• performs complete wasted storage reclamation, i.e.,

TURNING THE WEB INTO AN EFFECTIVE KNOWLEDGE REPOSITORY

155

it is able to reclaim distributed cycles of useless

web content.

• integrates well with the web architecture, i.e., it is

based on web-proxies and web-caching.

These properties must be correctly and efﬁciently

combined. We propose a solution, based on extending

web-proxies, web-server reverse proxies, and a dis-

tributed cyclic, i.e. complete, garbage collection algo-

rithm, that satisﬁes all these requirements. It enforces

referential integrity on the web and minimizes stor-

age waste. Furthermore, this solution scales well in a

wide area memory system as is the case of the web,

since it uses an hierarchical approach to distributed

cycle detection.

For ease of deployment, this solution requires no

changes in browsers or servers core application code.

It just needs deployment of extended web-proxies that

intercept server-generated content, provide it to other

proxies or to web servers, and fulﬁll the distributed

garbage collection algorithm. Users are still able to

access any other ﬁles available on the web.

Thus, our approach makes use of a cyclic dis-

tributed garbage collector, combined with web-

proxies in order to be easily integrated in the web

infrastructure. It intercepts dynamically generated

content in order to safely preserve every docu-

ment/resource referenced by it.

We do not address the issue of fault-tolerance, i.e.

it is out of the scope of the paper how the algorithm

used behaves in the presence of communication fail-

ures and processes crashes. Nevertheless, the algo-

rithm is safe in case of message loss and duplication.

Therefore, the contribution of this paper is a sys-

tem architecture, integrated with web-proxy facilities,

that ensures referential integrity, including dynamic

content, on the web. It minimizes storage waste in a

complete manner, and scales to wide area networks.

The remaining of this paper is organized as follows.

In Section 2 we present the proposed architecture.

The distributed garbage collection (DGC) algorithm

used is brieﬂy described in Section 3. Section 4 high-

lights some of the most important implementation as-

pects. Section 5 presents some performance results.

The paper ends with some related work and conclu-

sions in Sections 6 and 7, respectively.

2 ARCHITECTURE

In order not to impose the use of a new, speciﬁc,

hyper-media system, the architecture proposed is

based on regular components used in the WWW or

widely accepted extensions to them. The system is

designed using a client-server architecture, illustrated

in Figure 1, includes:

SRP

Browser

BrowserBrowser

EWP

BrowserBrowser

Server

ServerServer

EWP

SRP

EWP

Browser

rest of the

WWW

EWP

Server

Figure 1: General architecture of system deployment. Ob-

viously, any number of sites is supported: servers, proxies

and browsers.

• web servers provide static and dynamic content.

• clients - web browsing applications.

• extended web-proxies (EWPs) - these manage

clients requests and mediate access to other prox-

ies.

• server reverse-proxies (SRPs) - intercept server

generated content and manage ﬁles.

The entities manipulated by the system are web re-

sources in general. These come in two ﬂavors: i) html

documents that can hold text and references to other

web resources, and ii) all other content types (images,

sound, video, etc.). Resources of both types can be

accessed and are preserved while they are still reach-

able. Html documents can be either static or dynami-

cally generated/updated. Other web resources, though

possibly dynamic as well, are not considered for ref-

erences to other resources and are viewed, by the sys-

tem, as leaf-nodes in a web resources graph. Thus,

memory is organized as a distributed graph of web

resources connected by references (in the case of the

web, these are URL links).

We considered, mainly, as cases of web usage:

• web browsing without content preservation, i.e.,

standard web usage.

• web browsing with book-marking desired explic-

itly by the user, either in a page-per-page basis or

transitively.

From the user point of view, the client side of the

system is a normal web browser with an extra toolbar.

This toolbar enables book-marking the current page

or a URL included in a page as a root page and in-

form the proxy of such. Nothing prevents running the

extended web-proxy in the same machine as the web

browser though it would be obviously more efﬁcient

to install a proxy hierarchy.

A typical user in S1 browses the web, accesses

and bookmarks some of the pages from, for exam-

ple, web-server at site S2 (see Figure 1). Once book-

marked, these pages may hold references to other (not

book-marked) web resources in site S2. Thus, it is

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

156

A.html

B.html

X.php?a=37

WebServer

C.html

E.html

X.php?a=197

D.html

G.html

F.html

Server Reverse Proxy

(SRP)

code

X.php?a=37

X.php?a=197

Figure 2: Example web graph with several versions of previously dynamically generated content.

desirable that such resources in site S2 remain avail-

able as long as there are references pointing to them.

Web resources in other servers (e.g. site S3), targeted

by URLs found in content from site S2 are also pre-

served, while they are still referenced.

The system ensures that web resources in sites re-

main accessible, as long as they are pointed (either

directly or indirectly) from a root-set (see Section 3).

In addition, web resources, which are no longer refer-

enced from the root-set, are automatically deleted by

the garbage collector. This means that neither broken

links nor memory leaks (storage waste) can occur.

Figure 2 presents an example web graph, with dy-

namically generated web content (the two dynamic

URLs) preserved several times, represented like pages

over pages. These preserved dynamic pages hold

references to different html ﬁles, depending on the

time (and session information) when they were book-

marked. Preserved dynamic content is always stored

at the SRP to maintain transparency with regard to the

server.

3 STORAGE MANAGEMENT

To enforce referential integrity and reclaim wasted

storage we made use of a cyclic distributed garbage

collector for wide area memory (Veiga and Ferreira,

2003) and tailored it to the web.

Brieﬂy, the DGC algorithm is an hybrid of tracing

(local collector), reference-listing (distributed collec-

tor) and tracing of reduced graphs (cycle detection).

Thus, it is able to collect distributed cycles of garbage.

Tracing algorithms transverse memory graphs from a

root-set of objects and follow, transitively, every refer-

ence contained in them, to other objects. Reference-

listing algorithm register, for every object, what ob-

jects in other sites, are referencing it.

In each proxy there are two GC components: a lo-

cal tracing collector and a distributed collector. Each

site performs its local tracing independently from

any other sites. The local tracing can be done by

any mark-and-sweep based collector, e.g., a crawl-

ing mechanism. The distributed collectors, based on

reference-listing, work together by exchanging asyn-

chronous messages. The cycle detectors receive re-

duced, optimized graph descriptions from a set of

other sites and safely detect distributed cycles com-

prised within them.

The garbage collector components manipulate the

following structures to represent references contained

in web pages:

• A stub describes an outgoing inter-site reference,

from a document in the site to another resource in

a target site.

• A scion describes an incoming inter-site reference,

from a document in a remote source site to a local

resource in the site.

It is important to note that stubs and scions do not

impose any indirection on the access to web pages.

They are simply DGC speciﬁc auxiliary data struc-

tures.

The root-set of documents for both the local and

distributed garbage collectors in each site is com-

prised of local roots and remote roots: i) local roots

are web documents, located in the site and referenced

from a special html ﬁle managed by the system; ii)

remote roots are all local web documents that are re-

motely referenced, i.e., protected by scions. These

web resources must be preserved even if no longer lo-

cally reachable, i.e., reachable from the local root-set.

TURNING THE WEB INTO AN EFFECTIVE KNOWLEDGE REPOSITORY

157

The root-set of the whole system corresponds to the

union of the root-sets in all sites. This way, reachabil-

ity is deﬁned as the transitive closure of all web docu-

ments referenced, either directly or indirectly, from a

web document belonging to the root-set just deﬁned.

Every other document is considered unreachable and

should be reclaimed.

3.1 Local Collector

The local garbage collector (LGC) is responsible

for eventually deleting or archiving unreachable web

content. It must be able to crawl the server contents.

The roots of this crawling process are deﬁned at each

site. They include scion information provided by the

distributed collector (see Section 3.2). Crawling is

performed only within the site and lazily, in order to

minimize disruption to the web server. The crawler

maintains a list of pages to visit. These pages are

parsed and references, found within them, to pages

in the same server, are added to this list. References

found are saved in auxiliary ﬁles. These can be re-

used later by the crawler, when it re-visits the same

page, in another crawl, if the page was not modiﬁed.

Once created in some site, web resources must be-

come reachable in order to be accessible for brows-

ing. This can be done in two ways: i) add a reference

to the new resource in the local root-set, or ii) add

a reference to the new resource in some existing and

reachable document.

If it is necessary to update a page content (static

page change or programmatic page update), the page

will then be locked and the crawler must wait and will

need, for safety reasons, to re-analyze it. This is per-

formed following the links included in both versions

(the previous and the new one). Then, after the whole

local graph has been analyzed, the new DGC struc-

tures replace (ﬂip) the previous ones. Unreachable

web pages can then be archived or deleted.

To prevent race conditions with the LGC, newly

created resources are never collected if they are more

recent than the last collection, i.e., new ﬁles always

survive at least one collection before they can be

reclaimed. Possible ﬂoating-garbage in consecutive

collections, is minimum, since creation of web re-

sources is a task performed not that intensively.

Explicit deletion of web resources is extremely

error-prone and, therefore, it should not be done. Web

resources should only be deleted as a result of be-

ing reclaimed by the garbage collector. This happens

when they are no longer reachable both locally and

remotely.

3.2 Distributed Collector

The distributed garbage collector is based on

reference-listing (Shapiro et al., 1992) and is respon-

sible for managing inter-site references, i.e., refer-

ences between local pages to pages placed at other

sites (both incoming and out-going). This informa-

tion is stored in lists of scions and stubs organized,

for efﬁciency reason, by referring/referred site.

The algorithm obeys to the following safety rules:

• Clean Before Send: When a SRP replies to a

HTTP request for a page whose content should be

preserved, every URL enclosed in it, must be inter-

cepted, i.e., parsed. A corresponding scion to each

URL enclosed must be created, if it does not exist.

• Clean Before Send: When a EWP receives a re-

sponse to a HTTP request for a page whose con-

tent should be preserved, every URL enclosed in it,

must also be intercepted. A corresponding stub to

each URL enclosed must be created, if it does not

exist.

From time to time, the distributed collector running

on a site sends, to every site it knows about, the list of

stubs corresponding to the pages, in the destination

site, still referenced from local pages. These lists are

sent lazily.

Conversely, the distributed collector receives stubs

lists from other sites referencing its pages. Then, it

matches stub lists received with corresponding scion

lists it holds. Scions without stub counterpart indi-

cate incoming inter-site references that no longer ex-

ist. Therefore, the corresponding scion is deleted in-

dicating the page is no longer referenced remotely.

Once a page becomes unreachable both from the

site local root and from any other site, it can be deleted

by the local collector.

The distributed collector co-operates with the local

garbage collector in two ways: i) it provides the LGC

a set of pages (target of inter-site references) that must

be included in the LGC root-set, and ii) every time

the LGC completes crawling the site, it updates DGC

structures regarding out-going references (stub lists).

This update information will be sent later, by the local

collector, to the corresponding sites.

3.3 Distributed Cycles

Based on work described in (Richer and Shapiro,

2000), we can estimate the importance of cycles in the

web. This research about the memory behavior of the

web, revealed that a large proportion of objects are

involved in cycles but they amount to a limited, yet

not negligible, fraction of storage occupied. We be-

lieve that, as the degree of inter-connectivity (its true

richness) of the web increases, as well as due to more

dynamic content, the number, length, and storage oc-

cupied by cycles is also expected to rise.

Cycle detection processes (CDPs), receive infor-

mation from participating sites (running EWPs and/or

SRPs) and detect cycles fully comprised within them.

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

158

Several CDPs can be combined into groups. These

groups can also be combined into more complex hi-

erarchies. This way, detection of cycles spanning a

small number of sites, does not overload higher-level

CDPs dealing with larger distributed cycles.

To minimize bandwidth usage and complexity,

CDP works on a reduced view of the distributed

graphs that is consistent for its purposes. This view

may not correspond to a consistent cut, as deﬁned

by (Lamport, 1978), but still allows to safely detect

distributed cycles of garbage. These distributed GC-

consistent-cuts can be obtained without requiring any

distributed synchronization among the sites involved

(Veiga and Ferreira, 2003).

They are built by carefully joining reduced versions

of graphs created in each site. These reduced graphs

simply register associations among stubs and scions,

i.e., they regard each site as a small set of entry (scion)

and exit (stub) objects. This is enough to ensure safety

and completeness. Graph reduction is performed, in-

crementally, in each site.

Once a cycle is detected, the cycle detector in-

structs the distributed collector to delete one of its en-

tries (a scion) so that the cycle is eliminated. Then,

the distributed collector is capable of reclaiming the

remaining garbage objects.

3.4 Integration with the web

The WWW owes a signiﬁcant part of its success until

now, to the fact that it allows clients and servers to be

loosely coupled and different web sites to be admin-

istrated autonomously. Following this rationale, our

system does not impose total world-wide acceptance

in order to function. Integration with the web can be

seen from two perspectives, client and server.

Regular web clients can freely interact with server

reverse-proxies, possibly mediated by regular prox-

ies, to retrieve web content. However, they cannot

preserve web resources or interfere with the DGC

in anyway. Thus, browsing and referencing content

will not prevent it from being eventually reclaimed,

since these references can be regarded only as weak-

references. References contained in indexers are a

particular case of these weak-references.

Regular web applications in servers do need not

be modiﬁed to make use of referential-integrity and

DGC services. However, once a ﬁle is identiﬁed as

garbage, the proxy must have some interface with the

server machine to actually delete or archive the ob-

ject. If proxy and server reside on the same machine,

this interface can be the actual ﬁle system.

Distributed caching is widely used on the web to-

day. It is a cost-effective way to allow more simulta-

neous accesses to the same web content and preserve

content availability in spite of network and server fail-

ures. Caching is performed, mainly, at four levels: i)

web servers, e.g. dynamically generated and periodi-

cally updated content, ii) proxies of large internet ser-

vice providers, iii) proxies of organizations and local

area networks (several of these can be chained), and

iv) the very machine running the browser. Due to this

structure, the web relies on caching mechanisms that

have an inherent hierarchical nature. This can be ex-

ploited to improve performance (Chiang et al., 1999).

Hosts performing levels II and III caching are trans-

parent, as far as the system is concerned. They can be

implemented in various ways provided they fulﬁll the

HTTP protocol. To perform level I, we propose a so-

lution based on analysis of dynamic content. Server

replies are intercepted by the SRPs and URLs con-

tained in them are parsed, before the content is served

to requesting clients and proxies. This is intrusive nei-

ther for applications nor for users. Similar techniques

have already been applied, as part of marketing-

oriented mechanisms (e.g. bloofusion.com). These

convert dynamic URLs in static ones, to improve site

ratings in indexers like google.com. They also allow

web crawlers to index various results from different

executions of the same dynamic page.

4 IMPLEMENTATION

The prototype implementation was developed in Java,

mainly for ease of use when compared with C or

C++. It simply deploys a stand-in proxy that inter-

prets HTTP-like custom requests to perform DGC

operations and relies on a ”real”, off-the-shelf web-

proxy, running on the same machine, to perform ev-

erything else.

Preserving dynamically generated content raises a

semantic issue about browser, proxy and server be-

havior. When a dynamic URL, previously preserved,

is accessed, two situations can occur, depending on

session information shared with the proxy: i) the con-

tent is retrieved as a fresh execution , or ii) the user is

allowed to decide, from previously accessed and pre-

served content, which one he wants to browse.

Dynamic content selection is implemented allow-

ing two conﬁgurable default behaviors: i) when a

dynamic URL is requested, the browser receives an

automatically generated HTML reply, with a list of

previously preserved content, provided with date and

time information, and ii) the very HTML code, imple-

menting the link to the dynamic URL, is replaced with

code that implements a selection box, offering the

same alternatives as the ﬁrst option. The ﬁrst behav-

ior is less computationally demanding on the proxies

but the second one is more versatile, in terms of user

experience.

Server-side proxies perform URL translations to

access corresponding ”invisible” ﬁles that hold the ac-

TURNING THE WEB INTO AN EFFECTIVE KNOWLEDGE REPOSITORY

159

100

125

150

175

200

225

250

120

150

180

210

240

270

300

330

360

390

420

450

480

510

540

570

600

number of links

number of files

Reuters

BBC

Figure 3: Distribution of links per ﬁle for two web sites.

tual preserved content. We are currently modifying a

widely used open-source web proxy in order to facil-

itate deployment in several networks.

5 PERFORMANCE

Global performance, as perceived by users, is just

marginally affected. In the case of URL-replacing

mechanisms mentioned before, they are already in

practice in several web sites, and users do not perceive

any apparent performance degradation. Our system

makes use of similar techniques to parse URLs in-

cluded in dynamic web content. We should stress that,

in terms of performance, this is a much lighter opera-

tion that URL-replacing.

To assess increased latency in web-servers replies,

due to processing in the SRPs, we performed several

tests with two widely accessed sets of ﬁles, parsing

the URLs included in them. These sets were obtained

by crawling two international news sites: bbc.co.uk

and www.reuters.com with a depth of four. These sets

of ﬁles include both static and dynamically generated

content. A Pentium 4 2.8 GHz with 512MB was used.

The distribution of ﬁles, from both sites, according

to the number of URLs enclosed, is shown in Figure 3.

The www.reuters.com test-set comprised 313 ﬁles, in-

cluding 57856 URLs. On average, each ﬁle included

184 URLs, with a minimum of 49 and a maximum of

637. It took, on average, 12.7 milliseconds more to

serve HTTP requests due to parsing. The bbc.co.uk

test-set comprised 439 ﬁles, including 70401 URLs.

On average, each ﬁle included 160 URLs with a min-

imum of 114 and a maximum of 440. On average, it

took 11.8 milliseconds to parse each ﬁle.

Figure 4 shows, for each web-site, the distribu-

tion of time spent in parsing versus the number of

URLs found in each ﬁle. Linear regression allows dis-

card of outstanding results. Differences in tendency

lines reﬂect mainly different density of URLs in ﬁles.

Broadly, ﬁles from site bbc.co.uk have higher density

of URLs. In this site, a larger fraction of ﬁle content

represents URLs, since the average cost of parsing the

whole ﬁle, amortized for every URL, is smaller.

0,00

10,00

20,00

30,00

40,00

50,00

60,00

70,00

80,00

90,00

100,00

0 100 200 300 400 500 600 700

number of links

parsing time (ms)

Reuters

BBC

Linear (BBC)

Linear (Reuters)

Figure 4: File scattering based on links and parsing time.

6 RELATED WORK

The task of ﬁnding broken links can be an auto-

mated using several applications (HostPulse, 2002;

LinkAlarm, 1998; XenuLink, 1997). However, these

applications do not enforce referential integrity be-

cause they cannot prevent them from occurring nor

reclaim wasted storage. Furthermore, they are not

able to handle dynamically generated content in a safe

manner. Enforcing referential integrity on the web

has been a subject of active study for several years

now (Lawrence et al., 2001). There are a few systems

that try to correct the broken-link problem and, thus,

enforce referential integrity, preserving web content

availability.

In (Swaminathan and Raghavan, 2000), dynamic

web content is pre-fetched, i.e., cached in advance,

based on user behavior identiﬁed and predicted using

genetic algorithms. Results show that pre-fetching

is effective mainly for ﬁles smaller than 5000 bytes.

Such techniques could be combined with our system

in order to handle dynamic content more efﬁciently

while enforcing referential integrity.

LOCKSS (Reich and Rosenthal, 2001) is a open-

software based system that makes use of replication,

namely spreading, in order to preserve web content. It

has been tested in a large environment and it stresses

three important requirements: i) future availability

of information, ii) quick and easy access to informa-

tion and iii) reservation of access only to subscribers.

There are some fundamental differences w.r.t. our

work: much work has been devoted in LOCKSS

to ensure replica consistency, namely using hashing

for each document. Storage reclamation is not ad-

dressed in LOCKSS since all documents in the sys-

tem are considered important enough to be preserved

forever. Dynamic content is also not addressed. In

LOCKSS, the system tries to preserve everything con-

sistent. Ours tries to prevent memory leaks while

preserving referential integrity although allowing dis-

crepancy among cached copies of dynamic content.

Author-Oriented Link Management (Creech, 1996)

is a system that tries to determine which pages point

to a certain one. It describes an informal algebra

for representing changes applied to pages, like migra-

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

160

tion, renaming, deletion, etc. It relies on the usage

of custom-made, or customized authoring tools, i.e.,

referential integrity is not transparently provided to

the user or developer. It allows little parallelism and

admits manual re-conciliation of data. So, it is more

addressed at helping web developers than to preserve

referential integrity on a wide scale basis. It does not

try to reclaim storage space occupied by useless, i.e.,

unreachable documents.

Hyper-G (Kappe, 1995) is a ”second-generation”

hyper-media system that aims to correct web deﬁ-

ciencies and provide a rich set of new services and

features. With regard to referential integrity, it is en-

forced using of a propagation algorithm that is de-

scribed as scalable. Hyper-G is proposed as an alter-

native to the WWW. Our system is integrated within

and mostly transparent to the current WWW architec-

ture.

The W3Objects (Ingham et al., 1996) approach is

also based on the application of a distributed garbage

collector to the world wide web. It also imposes a new

model extending the WWW based on objects. There-

fore it also lacks transparency. It is not complete, i.e.,

it is not able to reclaim distributed cycles of garbage.

In (Moreau and Gray, 1998) a community of agents

is used to maintain link integrity on the web. As

in our work, they do not attempt to replace the web

but extend it with new behavior. Agents cooperate to

provide versioning of documents and maintain links

according to a distributed garbage collector. Each

site manages tables documenting import and export

of documents. It does not address the semantic issues

raised when preserving dynamic content.

Thus, existing solutions to referential integrity ei-

ther do not aim at recycling unreachable documents

or are not correct concerning dynamic content or are

not integrated with the standard web.

7 CONCLUSIONS AND FUTURE

WORK

In this paper we presented a new way of enforcing ref-

erential integrity in the WWW, including dynamically

generated web content. The fundamental aspects of

the system are the following: i) it prevents storage

waste and memory leaks, deleting any resources no

longer reachable, namely, addressing the collection

of distributed cycles of unreachable web content; ii)

it is safe concerning dynamically generated web con-

tent; iii) it does not require the use of any speciﬁc

authoring tools; iv) it integrates with the hierarchical

structure of today’s web-proxies and caching; v) it is

mostly transparent to user browsers and web servers.

Concerning future research directions, we intend

to address further the fault-tolerance of our system,

i.e., which design decisions must be taken so that it

can remain safe, live and complete in spite of process

crashes and permanent communication failures.

REFERENCES

Bergman, M. K. (2001). The deep web: Surfacing hidden

value. The Journal of Electronic Publishing, 7(1).

Bush, V. (1945). As we may think. The Atlantic Monthly,

(July).

Chiang, C.-Y., Liu, M. T., and Muller, M. E. (1999).

Caching neighborhood protocol: a foundation for

building dynamic web caching hierarchies with proxy

servers. In International Conference on Parallel Pro-

cessing.

Creech, M. L. (1996). Author-oriented link management.

In Fifth International WWW Conference, France.

HostPulse (2002). Broken-link checker,

www.hostpulse.com.

Ingham, D., Caughey, S., and Little, M. (1996). Fix-

ing the “Broken-Link’’ problem: the W3Objects ap-

proach. Computer Networks and ISDN Systems, 28(7–

11):1255–1268.

Kappe, F. (1995). A Scalable Architecture for Maintaining

Referential Integrity in Distributed Information Sys-

tems. Journal of Universal Computer Science, 1(2).

Lamport, L. (1978). Time, clocks, and the ordering of

events in a distributed system. Communications of the

ACM, 21(7):558–565.

Lawrence, S., Pennock, D. M., Flake, G. W., Krovetz, R.,

Coetzee, F. M., Glover, E., Nielsen, F. A., Kruger, A.,

and Giles, C. L. (2001). Persistence of web references

in scientiﬁc research. IEEE Computer, vol 34(2).

LinkAlarm (1998). Linkalarm, http://www.linkalarm.com/.

Moreau, L. and Gray, N. (1998). A community of agents

maintaining link integrity in the world wide web. In

Proceedings of the 3rd International Conference on

the Practical Applications of Agents and Multi-Agent

Systems (PAAM-98), London, UK.

Nelson, T. H. (1972). As we will think. In On-line 72 Con-

ference.

O’Neill, E. T., Lavoie, B. F., and Bennett, R. (2003). Trends

in the evolution of the public web 1998 - 2002. D-Lib

Magazine, 9(4).

Reich, V. and Rosenthal, D. (2001). Lockss: A permanent

web publishing and access system. D-Lib M’zine, 7.

Richer, N. and Shapiro, M. (2000). The memory behavior

of the WWW, or the WWW considered as a persistent

store. In POS 2000, pages 161–176.

Shapiro, M., Dickman, P., and Plainfoss

e, D. (1992). Ro-

bust, dist. references and acyclic garbage collection.

In Symp. on Principles of Dist. Computing, pages

135–146, Vancouver (Canada). ACM.

Swaminathan, N. and Raghavan, S. (2000). Intelligent

prefetch in www using client behavior characteriza-

tion. In 8th International Symposium on Modeling,

Analysis and Simulation of Computer and Telecom-

munication Systems, pages 13–19.

Veiga, L. and Ferreira, P. (2003). Complete distributed

garbage collection, an experience with rotor. In IEE

Research Journals - Software, number 150(5).

XenuLink (1997). Linksleuth http://home.snafu.de/tilman/.

TURNING THE WEB INTO AN EFFECTIVE KNOWLEDGE REPOSITORY

161
