CONTEXTS FOR ORGANIZATIONAL INFORMATION SYSTEM

DESIGN AND IMPLEMENTATION

Salvador Abreu

Universidade de

Evora and CENTRIA

Portugal

Daniel Diaz

Universit

e de Paris I and INRIA

France

Keywords:

Information Systems Applications, Modules, Object-oriented Programming, Contextual Logic Programming.

Abstract:

In this article we sustain that Contextual Constraint Logic Programming (CxCLP for short) is a useful

paradigm in which to specify and implement Organizational Information Systems, particularly when inte-

grated with the ISCO mediator framework. We brieﬂy introduce the language and its underlying paradigm,

appraising it from the angle of both of its ancestries: Logic and Object-Oriented Programming. An initial

implementation has been developed and is being actively used in a real-world setting – Universidade de vora’s

Academic Information System. We brieﬂy describe both the prototype implementation and its ﬁrst large-scale

application. We conclude that the risk taken in adopting a developing technology such as the one presented

herein for a mission-critical system has paid off, in terms of both development ease and ﬂexibility as well as

in maintenance requirements.

1 INTRODUCTION

In the process of devising a strategy for the grad-

ual design and deployment of SIIUE, an organiza-

tional information system for Universidade de vora,

we were faced with hard choices: as there are really

no available ready-to-use solutions, some measure of

in-house development was inevitable: Academic or-

ganizations have several speciﬁcities which are not

well catered for by existing ERP products. The adop-

tion of an existing methodology based on existing

(commercial) tools was considered, but deemed to be

rather inﬂexible and ultimately expensive in the long

run, moreover, it would hardly build on the known-

how acquired through the developments which had

been locally initiated over the preceding years.

Our explicitly assumed option was to rely on open-

source software as much as possible, in order to avoid

vendor lock-in and to ensure that future developments

could always be effected using in-house competence.

In doing so, we had to be very careful in order to pick

the most appropriate tool for each particular aspect

of the project, always making sure that everything

should ﬁt harmoniously.

The overall coordination of the various software

components of such a mixed system was critical to the

success of the project: this is where Logic Program-

ming appears to be a very interesting and promis-

ing choice. Early work on the design and develop-

ment of SIIUE already indicated that it would ben-

eﬁt from Logic Programming tools playing an in-

creasingly central part in the system. This observa-

tion, later conﬁrmed by further developments (Abreu,

2001), led to incrementing the investment in the tech-

nology which was at the base of the entire project:

Prolog as the foundation of an Organizational Infor-

mation System speciﬁcation and implementation lan-

guage.

The beneﬁts of Logic Programming are well

known: the rapid prototyping ability and the relative

simplicity of program development and maintenance,

the declarative reading which facilitates both devel-

opment and the understanding of existing code, the

built-in solution-space search mechanism, the close

semantic link with relational databases, just to name

a few. The realization that Logic Programming is

a promising tool with which to address this type of

problem is not exclusive to Universidade de vora’s

project.

Our choice of GNU Prolog as the basic tool with

which to develop our system was due to several fac-

tors, not the least of which is its inclusion of a comple-

mentary problem-solving paradigm: constraint pro-

gramming. Constraints strengthen the declarative

227

Abreu S. and Diaz D. (2004).

CONTEXTS FOR ORGANIZATIONAL INFORMATION SYSTEM DESIGN AND IMPLEMENTATION.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 227-232

DOI: 10.5220/0002649202270232

 SciTePress

programming facet of Prolog, providing an a-priori

search-space pruning model which complements the

depth-ﬁrst backtracking of classical Logic Program-

ming.

Nevertheless, the Prolog language suffers from a

serious scalability issue when addressing actual ap-

plications. There have been several efforts over the

years to overcome this limitation: one which took

many years to shape is the ISO standard formula-

tion of modules for Prolog. This standard can hardly

be considered satisfactory, being heavily inﬂuenced

by previously existing and conﬂicting implementa-

tions: it can be argued that it essentially introduces

the concept of “separate predicate spaces,” which are

reminiscent of ADA modules. Moreover, the stan-

dard is syntactically very verbose, which in itself is

a very questionable departure from what we perceive

to be one of Prolog’s strengths: its syntactic simplic-

ity. Moreover, it is our opinion that the standard com-

pletely misses the oportunity it had of assimilating

closely related yet well established and vastly more

powerful concepts, such as the notions of Object and

Inheritance.

An interesting alternative solution to the same

problem is that of Contextual Logic Programming

(CxLP), a model introduced in the late 1980’s. In-

formally, the main point of CxLP is that programs are

structured as sets of predicates (units) which can be

dynamically combined in an execution attribute called

a context. Goals are seen just as in regular Prolog, ex-

cept for the fact that the matching predicates are to

be located in all the units which make up the current

context.

We extended CxLP to attach arguments to units:

these serve the dual purpose of acting as “unit-global”

variables and as state placeholders in actual contexts.

CxLP clearly carries a higher overhead than reg-

ular Prolog, as the context must be searched at run-

time for the unit that deﬁnes a goal’s predicate, a pro-

cess which requires at least one extra indirection com-

pared to straight Prolog; this kind of situation has be-

come more usual and less of a performance issue in

recent systems, in Object-Oriented and even in pro-

cedural languages, for instance as a result of using

dynamically-loaded shared libraries. We have built

a prototype implementation of a Contextual Logic

Programming language, GNU Prolog/CX, which has

surprisingly good performance, considering we aren’t

performing any optimization.

Finally, we used GNU Prolog/CX to implement

the newer components of SIIUE: the Academic Ser-

vices subsystem. This article reports on the outcome

of this initiative.

The rest of this paper is organized as follows: In

section 2 we brieﬂy present Universidade de vora’s

Academic Information System (SIIUE.sac) and how

it beneﬁts from GNU Prolog/CX. Section 3 explores

the link between contexts and Object-Oriented Pro-

gramming. Section 4 brieﬂy describes our implemen-

tation on top of GNU Prolog. A short conclusion

ends the paper.

2 UNIVERSIDADE DE

EVORA’S

ACADEMIC INFORMATION

SYSTEM

GNU Prolog/CX has already seen actual use in a

real-world application: Universidade de vora’s sec-

ond generation Academic Information System, which

is a project that got under way in March 2003 and, at

the time of this writing (October 2003), is already in

production. This initiative was spurred by the Univer-

sity’s decision to simultaneously reorganize all of its

undergraduate offerings, to comply with the “Bologna

principles,” a goal which could not be met by the ex-

isting system without very signiﬁcant and resource-

consuming overhauls.

The Academic Information System (SIIUE.sac) is

part of Universidade de vora’s Integrated Information

System (SIIUE), being its latest component and a use-

ful and diverse testbed for the ISCO language.

2.1 ISTO: Evolving the ISCO

Programming Language

ISCO (Abreu, 2001) is a Logic Programming lan-

guage geared towards the development and mainte-

nance of organizational information systems. ISCO

is an evolution of the previous language DL and is

based on a Constraint Logic Programming framework

to deﬁne the schema, represent data, access hetero-

geneous data sources and perform arbitrary computa-

tions. In ISCO, processes and data are structured as

classes which are represented as typed

Prolog pred-

icates. An ISCO class may map to an external data

source or sink, such as a table or view in a relational

database, or be entirely implemented as a regular Pro-

log predicate. Operations pertaining to ISCO classes

include a query which is similar to a Prolog call as

well as three forms of update.

We are presently evolving ISCO to endow it with

an expressive means of representing and implicitly us-

ing temporal information (Nogueira et al., 2003), the

resulting language is called ISTO. In the course of de-

signing ISTO, it was our goal to make further use of

contexts, as an implementation became available.

The type system applies to class members, which are

viewed as Prolog predicate arguments.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

228

2.2 The Academic Information

System; SIIUE.sac

The ISCO architecture for the Academic Information

System can be summarized as follows: three different

layers correspond to actual physically different net-

works, interfacing each pair of layers which have con-

tact. The physical separation is provided to ensure

that access to higher-numbered layers is exclusively

performed by hosts on the layer immediately below.

There is the requirement that, since all validation

and authorization is performed by the ISCO layer,

the layers above only access any application data via

ISCO, hence the application must have three lay-

ers (web interface, ISCO and DBMS). The ISCO

(GNU Prolog/CX executable) processes come from

a pool where they perform initialization tasks before

becoming available as query processors, thereby by-

passing the overhead of some initialization chores,

such as connecting to database servers. It should be

noted here that GNU Prolog’s architecture is very

favourable to its usage as a Prolog implementation

for this type of usage, because even complex pro-

grams

load very fast, as they’re mostly native exe-

cutable code by virtue of the compilation approach,

therefore shared by all instances of the program.

ISCO programs may access relational data

through ODBC using a GNU Prolog interface with

unixODBC, which has been developed within the

SIIUE project: this allows for accessing legacy data

transparently. The executables are used from within

PHP wrapper scripts in web-based interfaces: the

PHP extensions have also been developed speciﬁcally

for use with ISCO.

Although most of the relational databases used are

built in PostgreSQL, other relational database engines

where considered. This requires ISCO to be indepen-

dent from the speciﬁc RDBMS engine being used.

The ISCO compiler is aware of the differences be-

tween relational database engines, and generates SQL

code appropriate to the speciﬁc back-end being used,

through the use of different units for each known

database back-end, building on similarities between

some to exploit multi-level specialization schemes

provided by Contextual Logic Programming, as for

example in dealing with different versions of the sama

RDBMS engine.

We fully integrated ISCO with the PiL-

LoW (Cabeza and Hermenegildo, 2001) library,

a Prolog library for HTML/XML/SGML output

and form handling, which is used for web-based

development. PiLLoW has been ported to GNU

Prolog.

In this case, a typical SIIUE.sac user interface program

has around a hunded thousand lines of code.

2.3 SIIUE.sac from a Software

Engineering Perspective

Universidade de vora’s commitment to develop the

SIIUE.sac project was ascertained in early 2003 and

the project itself got under way in March 2003 with a

team of three experienced programmers. At that time,

a complete rewrite of the ISCO tools and GNU Pro-

log/CX had just recently been rendered operational

and the development team had no experience with ei-

ther Contextual or Constraint Logic Programming, al-

though they had done a few toy projects with Prolog.

The project was then scheduled with quarterly mile-

stones which targeted roughly:

1. The academic services internal use (e.g. graduation

plans),

2. The student’s use (e.g. course registrations) and

3. The faculty members’ use (e.g. grading)

It was important that the schedule be met because this

endeavour was considered mission-critical, as it in-

volved unknowns at various levels: the technology

and tools were very new and the development team

was not familiar with the approach.

At the time of this writing, the ﬁrst two phases had

completed successfully and were in production, hav-

ing been stress-tested with both the introduction of

around 40 different graduation plans ranging from Vi-

sual Arts to Veterinary Medicine, some with very in-

tricate structures, and the registration for individual

courses by approximately 6000 students, averaging

10 courses per student. We only had very minor prob-

lems in the ﬁrst day of the registration period, due to

the load peak and which were resolved in under one

hour. The third phase was progressing according to

plan.

The experience we drew from the deployment of

this ﬁrst application can be summed up in a few

points:

• The re-use, whenever appropriate, of existing well-

established software components such as Apache,

PHP, PiLLoW and L

X was essential as it saved

us a lot of speciﬁcation and implementation effort.

• Contextual Logic Programming played a key role

in the overall incremental design and implementa-

tion process; a few aspects deserve explicit men-

tion:

– The representation of user sessions as contexts

was a signiﬁcant success, as the concept of ses-

sion can very naturally be expressed as a context.

– Role-based authorization and interface genera-

tion gained plenty of ﬂexibility and reliability

from the systematic use of contexts.

– Coding the “business logic” as units that respond

to standardized messages (e.g. the item/1

CONTEXTS FOR ORGANIZATIONAL INFORMATION SYSTEM DESIGN AND IMPLEMENTATION

229

predicate) enabled us to design compositionally

and made it relatively easy to rework implemen-

tations and restructure processes while preserv-

ing an unchanging interface.

• The choice of relegating the relational database to

the role of persistency provider for ISCO seems to

have been the correct one. This became particularly

obvious at one stage, where an “SQL-like” design

(structures represented as a collection of tuples or

facts) was replaced with a more “Prolog-like” one

(structures represented as a single large term): per-

formance on a particular benchmark went up by a

factor of 10 to 100 with that single change, mostly

attributable to reduced database trafﬁc.

• The relative ease with which programmers used

to procedural languages and SQL adopted a little-

documented paradigm and still very experimental

development tools was surprising, as they became

productive early in the development cycle.

3 CONTEXTS AS OBJECTS WITH

STATE

The integration of the Object-Oriented and Logic Pro-

gramming paradigms has long been an active research

area since the late 1980’s; take for example Mc-

Cabe’s work (McCabe, 1992). The similarities be-

tween Contextual Logic Programming and Object-

Oriented Programming have been focused several

times in the literature; see for instance the work by

Monteiro and Porto (Monteiro and Porto, 1993) or

Bugliesi (Bugliesi, 1992).

Other than the implementation-centered reports,

previous work on Contextual Logic Programming fo-

cuses largely on issues such as the policy for context

traversal, what the context becomes once a unit satis-

fying the calling goal is found, what to do when multi-

ple units provide clauses for the same predicate, how

to automatically tie several units together or how to

provide encapsulation and concealment mechanisms.

To the best of our knowledge, no published work

earlier than (Abreu and Diaz, 2003) builds on the no-

tion of context arguments and their widespread use,

even though Miller’s initial work (Miller, 1989) al-

ready mentions the possibility of using module vari-

ables. This feature was present as a “hack” in the ﬁrst

C-Prolog based implementation of Contextual Logic

Programming but was a little let down, possibly for

lack of an adequate formalization and the nonexis-

tence of convincing examples.

Instead of viewing a context as an opaque execution

attribute, as happens in CSM (Natali and Omicini,

1993) for instance, we choose to regard it as a ﬁrst-

class entity, i.e. as a Prolog term. Not only is the con-

text accessible from the program, but it is intended

that it be explicitly manipulated in the course of a pro-

gram’s regular computation. The performance impact

of this option will be succinctly analyzed in section 4:

at this point we shall concentrate on the possibilities

it allows from an expressiveness point of view, relat-

ing Contextual Logic Programming examples to other

paradigms whenever appropriate.

3.1 Contexts and Object-Oriented

Languages

The following table establishes some parallels be-

tween Contextual Logic Programming (CxLP) and

Object-Oriented Programming (OOP) terminology,

pointing out how units, contexts and context argu-

ments can relate to OOP concepts. The most notable

OOP (Class) OOP (Object) CxLP

Object Object Context

Message Message Goal

Instance variable Named slot Unit argument

Method Method Predicate

difference between the CxLP and the OOP paradigms

has to do with the concept of inheritance: instead of

being statically deﬁned as in the Class-based Object-

Oriented languages, it is completely dynamic for each

context (i.e. “object”), as it deﬁnes its own structure

and, implicitly, its behaviour wrt. messages.

CxLP enables design approaches stemming from

both class-based and prototype-based languages (an

early example of which is Self (Ungar and Smith,

1987)) in that a unit can be seen as akin to a class

as it deﬁnes partial state and behaviour and a context,

as a self-sufﬁcient object can serve as the basis for the

creation of further contexts, either via the extension

mechanism or by explicit manipulation of the context

term (e.g. a copy).

3.2 Encapsulation and Concealment

These issues are central in Object-Oriented Program-

ming and critical from the Software Engineering point

of view. Earlier approaches in Contextual Logic Pro-

gramming languages proposed several distinct mech-

anisms, along the lines of having an annotation of

some sort to indicate that a given predicate was to be

considered “visible” or “hidden”, in the sense that a

context traversal would see it or not.

Our approach of relying on deep contexts and unit

arguments, made possible by the relative efﬁciency of

the prototype implementation, as described in (Abreu

and Diaz, 2003), allows us to shun the introduction of

yet another set of predicate annotations, because sim-

pler constructions are effectively available, through

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

230

the use of unit arguments and the context switch op-

eration: all that is necessary is that the context argu-

ments supply sufﬁcient information for a new con-

text to be built, in order to implement the requested

method without disclosing the details to the invoking

context.

Another situation is where we wish to implement a

unit with a particular interface, similar to that of an-

other unit but with some predicates omitted. This can

be achieved via a deﬁnition for context/1 as pre-

viously suggested, to ensure that the remaining goals

will execute in a controlled context.

3.3 Contexts as Implicit

Computations

ISTO is a development of ISCO (Abreu, 2001), a

Prolog-based mediator language which can transpar-

ently access several kinds of information sources,

namely relational databases. ISTO relies on GNU

Prolog/CX as its compiler’s target language and is

further described by means of an application in sec-

tion 2.

Consider a unit person(ID, NAME,

BIRTH

DATE) which deﬁnes the following predi-

cates:

• item/0 which returns, through backtracking, all

instances of the person/3 database relation by

instantiating unit arguments,

• delete/0 which nondeterministically removes

instances of the person/3 database relation, as

restricted by the unit arguments,

• insert/0 which inserts new instances into the

person/3 database relation, taking the values

from the unit argument.

Accessing an “object” speciﬁed by a context is always

done via one of these predicates, which are to be eval-

uated in a context which speciﬁes the relation (in this

case person/3). Assume that there are also predi-

cates with the same name and one argument, which

represents the relevant unit with bound arguments,

i.e. item/1, delete/1 and insert/1. An actual

implementation of these predicates could rely on the

standard Prolog built-ins clause/1, retract/1

and assertz/1 or access an external database, as is

done in the ISCO compiler (Abreu, 2001).

4 OVERVIEW OF THE

PROTOTYPE

IMPLEMENTATION

In order to experiment programming with contexts

we have developed a ﬁrst prototype inside GNU Pro-

log (Diaz and Codognet, 2001). Our main goal was

to have a light implementation modifying the current

system as little as possible. Due to space restrictions

we only give here an overview, the interested reader

can consult (Abreu and Diaz, 2003) for more details.

The main change concerns a call to a given pred-

icate P/N. If there is no deﬁnition for P/N in the

global predicate table (containing all built-in predi-

cates and predicates not deﬁned inside a unit) then the

context must be scanned until a deﬁnition is found.

To evaluate the context implementation, we fol-

lowed a methodology similar to that of Denti et

al. (Denti et al., 1993): a goal is evaluated in a context

which is made up of a unit which implements the goal

predicate, below a variable number of “dummy” units

which serve to test the overhead introduced by the

context search. We used the exact same methodology

as in (Denti et al., 1993). The observed relative per-

formance is much better in GNU Prolog/CX: even in

CSM’s most favorable situation (the modiﬁed WAM),

there is a 50% performance hit as soon as there are 5

“dummy” units in the context. Finally note that the

“50% performance degradation” threshold is reached

when the context comprises about 40 dummy units.

This demonstrates the effective ability to extensively

use deep contexts in actual applications, and is a sine

qua non requirement for the practical use of such a

language feature.

5 CONCLUSIONS AND FUTURE

DEVELOPMENTS

The conclusions we can draw from the experience

we’ve had so far include:

• A large application such as SIIUE.sac can bring out

fragilities in the implementation of the tools it uses:

such was the case, for instance, with GNU Pro-

log/CX in which a few hitherto unnoticeable bugs

became manifest (and were ﬁxed.)

• The in-development status of some of the tools,

most notably GNU Prolog/CX, turned out not to

be a very serious hindrance, as the design discipline

made up for the lack of features such as an effective

debugger.

• GNU Prolog/CX is well suited to o incremental

OO design, as a system can become operational

even while still incomplete and underspeciﬁed.

• Optimal complex SQL code generation is not as

important a goal as we thought it would as it can

largely be compensated by the judicious use of the

result of simple queries.

• The gradual adoption of Contextual Logic Pro-

gramming as a design and programming paradigm

CONTEXTS FOR ORGANIZATIONAL INFORMATION SYSTEM DESIGN AND IMPLEMENTATION

231

has exhibited not too steep a learning curve and is

allowing us to further our sensitivity to its differ-

ent applicability situations and program patterns.

Some of these reﬂect back onto the language itself.

• The developers did have to rid themselves from

SQL and procedural language habits, namely in

what concerns the manipulation of more complex

data structures, in order to extract acceptable per-

formance from the system.

Some directions for future work:

• The removal of some implementation-speciﬁc lim-

its (e.g. area sizes).

• The dynamic loading of compiled Prolog code,

which will allow for on-the-ﬂy extension of com-

piled applications.

• Multi-thread execution.

• The development of a Graphical interface (Gnome-

Prolog).

• The generic web-based relation browser, as this

will greatly decrease interface development time.

• Automatic caching of external database relations,

and

• A more extensive performance analysis and tuning

under load.

ACKNOWLEDGEMENTS

The work described herein was partly made possible

by the bilateral INRIA/GRICES project “Extensions

au Logiciel Libre GNU Prolog.” Universidade de

vora is acknowledged for supporting and funding the

SIIUE.sac project.

REFERENCES

Abreu, S. (2001). Isco: A practical language for heteroge-

neous information system construction. In Proceed-

ings of INAP’01, Tokyo, Japan. INAP.

Abreu, S. and Diaz, D. (2003). Objective: in Minimum

Context. In Palamidessi, C., editor, Proceedings of the

Eighteenth International Conference on Logic Pro-

gramming, volume 2916 of LNCS, Mumbai, India.

Springer-Verlag. (forthcoming).

Bugliesi, M. (1992). A declarative view of inheritance in

logic programming. In Apt, K., editor, Proceedings

of the Joint International Conference and Symposium

on Logic Programming, pages 113–127, Washington,

USA. The MIT Press.

Cabeza, D. and Hermenegildo, M. (2001). Distributed

WWW programming using (Ciao-)Prolog and the

PiLLoW library. Theory and Practice of Logic Pro-

gramming, 1(3):251–282.

Denti, E., Lamma, E., Mello, P., Natali, A., and Omicini,

A. (1993). Techniques for implementing contexts in

Logic Programming. In Lamma, E. and Mello, P., ed-

itors, Extensions of Logic Programming, volume 660

of LNAI, pages 339–358. Springer-Verlag. 3rd Inter-

national Workshop (ELP’92), 26–28 February 1992,

Bologna, Italy, Proceedings.

Diaz, D. and Codognet, P. (2001). Design and implementa-

tion of the gnu prolog system. Journal of Functional

and Logic Programming, 2001(6).

McCabe, F. G. (1992). Logic and Objects. Prentice Hall.

Miller, D. (1989). A logical analysis of modules in logic

programming. The Journal of Logic Programming,

6(1 and 2):79–108.

Monteiro, L. and Porto, A. (1993). A Language for Con-

textual Logic Programming. In Apt, K., de Bakker,

J., and Rutten, J., editors, Logic Programming Lan-

guages: Constraints, Functions and Objects, pages

115–147. MIT Press.

Natali, A. and Omicini, A. (1993). Objects with State in

Contextual Logic Programming. In Bruynooghe, M.

and Penjam, J., editors, Programming Language Im-

plementation and Logic Programming, volume 714 of

LNCS, pages 220–234. Springer-Verlag. 5th Interna-

tional Symposium (PLILP’93), 25–27 August 1993,

Tallinn, Estonia, Proceedings.

Nogueira, V. B., Abreu, S., and David, G. (2003). Using

Contextual Logic Programming for Temporal Reason-

ing. In Pimentel, E. and Brisaboa, N. R., editors, VIII

Conference on Software Engineering and Databases

(JISBD 2003), Alicante, Spain.

Ungar, D. and Smith, R. B. (1987). Self: The Power of Sim-

plicity. In Meyrowitz, N. K., editor, Conference on

Object-Oriented Programming Systems, Languages,

and Applications (OOPSLA’87), October 4-8, 1987,

Orlando, Florida, Proceedings, volume 22 of SIG-

PLAN Notices, pages 227–242.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

232
