FOUNDING ENTERPRISE SYSTEMS ON ENTERPRISE

PERFORMANCE ANALYSIS

Ian Douglas

Learning Systems Institute and Department of Computer Science, Florida State University, 320A, 2000 Levy Avenue

Innovation Park, Tallahassee, Florida, 32310, USA.

Keywords: Domain analysis, Service-oriented computing, Reuse

Abstract: Information, knowledge and lear

ning systems are developed with the implicit belief that their existence will

lead to better performance for those using them, and that this will translate into better performance for the

organisations for which the user works. One important activity that must occur prior to requirements

analysis for such systems is organisational and human performance analysis. One key software application

that is missing from most organisations is an integrated enterprise system for analysing performance needs,

determining appropriate support solutions, monitoring the effect of those solutions, and facilitating the reuse

and sharing of the resulting knowledge. A model for such a system is presented, together with a prototype

demonstrating how such a system could be implemented.

1 INTRODUCTION

The developers of information systems normally go

about their work with the belief that the deployment

of such systems will result in an improvement in the

operation of an organisation and the results it

achieves. There are many instances when this does

not prove to be the case. In his analysis of software

failure, Flowers (1996) locates the main cause not in

software development, but rather in its conception.

Managers often suppose that a computer system is a

cure-all for operational problems in business

practice. In many instances, there is a rush to

develop a solution before there is an understanding

the problem.

While information systems are one solution type

that can be

used to improve the performance of

humans and organisations, other systems also

promise such improvement, e.g. business process re-

engineering, training, job aids, e-learning,

knowledge management. Many of these solutions

are also implemented without careful analysis of

their contribution to supporting organisational need.

The entire organisational system, not just the

com

puter components, must be considered prior to

solution selection. It is crucial for an enterprise to

understand how the performance of its individual

employees and teams contributes to its goals and

results prior to the development of any solution

system. The “solutions-oriented” thinking in many

organisations needs to be replaced by more holistic

“problem-oriented” thinking. Traditionally, when

“analysis” is done, it is often framed with a

particular solution in mind. Performance analysis

and human performance technology have emerged

as means of focussing on the overall performance of

organisational systems (Gilbert, 1996, Robinson and

Robinson, 1995, Rosset, 1999). Underlying this

approach is general systems thinking (Wienberg,

2001).

There is a great deal of technology available to

assi

st solutions design and construction, e.g.

software engineering case tools, but there is

relatively little available to assist performance

analysis. Such technology facilitates understanding

of the organisational performance factors that the

solution is intended to address, prior to the

development of any solution, and also facilitates the

collection of baseline metrics required to determine

additional value created by any solution that is

implemented.

Douglas and Schaffer (2002), present a

ethodological framework for technology supported

organisational performance improvement. The

framework requires the reporting of the analysis in

terms of reusable knowledge components, which are

stored in repositories. The framework also

incorporates the need for visual modelling of

performance, collaborative analysis, rationale

management and configurable support systems.

588

Douglas I. (2004).

FOUNDING ENTERPRISE SYSTEMS ON ENTERPRISE PERFORMANCE ANALYSIS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 588-591

DOI: 10.5220/0002657105880591

 SciTePress

Anal

sis S

stem S

ecific Services

Interfaces

Reusable

Analysis

Repository

Reusable

Solution

Repository

Visual M odelling

Performance Data Entry

Rationale Management

User Support

Collaboration

User Management

Performance

Analysis

Project

Databases

Enterprise Gatekeeper

Data

Handling

Enter

rise-Wide Services

Figure 1: Architecture for the performance analysis support software

This paper describes a model for the technology

support for the framework and a prototype system

which demonstrates how performance analysis can

be facilitated by a web-based enterprise software

system. The system is focussed first on the goals of

the organisation, what processes need to occur to

meet these goals, and what roles are defined to carry

out the activities involved in a process. The analysis

system is used to determine the need for support and

help in the selection of the appropriate solutions

(e.g. computer programs, training courses, job aids).

A repository of this analysis knowledge would

be created which is organised by discrete

performance goals identified in analysis. The

analysis repository can be linked to a repository of

reusable solution components. Thus, if a new project

discovers in the analysis repository some prior

analysis of relevance to the current problem, they

will also discover any solutions that resulted from

the analysis.

2 A PERFORMANCE ANALYSIS

SUPPORT SYSTEM

A working prototype of an organisational

performance analysis system has been completed

and is under evaluation with both the US army. The

prototype is entirely web-based and supports all the

elements of the framework noted in the introduction.

An important concept embedded in the design of the

prototype is configurability (Cameron, 2002), i.e.

tools should not be fixed to a particular

methodology, but be adaptable to the specific needs,

methodologies and terminology used in different

organizations and groups. The intention is to create a

set of configurable tools and methods, which have a

shared underlying representation of performance

analysis knowledge. The system architecture is

based on the emerging new paradigm of service-

oriented software (Yao, Lin and Mathieu, 2003).

This allows custom interfaces to a continuously

refined shared repository of knowledge on human

performance. Each version of the performance

analysis system will have core components (see

figure 1), but the specific version of the components

will vary from organization to organization. In the

current system a third party collaboration tool called

Collabra has been tied into the systems to handle the

collaboration component. If a different organization

used a different collaboration tool this would be ‘

plugged in’ in place of Collabra. Likewise if

different data types were collected in another

organizations methodology (or different terminology

used), different data entry templates could appear.

The user support component can be tailored to the

specific methodology employed by an organization.

The components of an analysis (models, data and

rationale) are stored in a project specific database

from which analysts and stakeholders can retrieve,

view and comment on the contents. These can then

be transferred to a repository of performance

analysis knowledge. Some organizations may wish

to have a gatekeeper function to check the quality of

the components entered into the central repository.

An integral part of the tool is an automated search of

this repository. Thus, as soon as an analysis team on

a new project begins to enter data, it is matched

against existing data in the analysis repository to

alert the user to possible sources of existing

knowledge. Ye and Fischer, (2002) argue for the

need for this type of automated task-aware, context-

sensitive search to encourage reuse. It is likely that

FOUNDING ENTERPRISE SYSTEMS ON ENTERPRISE PERFORMANCE ANALYSIS

589

Figure 2: Screenshots of one instance of an analysis tool conforming to the framework

the user will be discouraged from using a resource

that requires a lot of browsing in order to determine

if relevant information exists.

Figure 2, illustrates the prototype that has been

constructed to demonstrate one instance conforming

to the framework and the architecture illustrated in

figure 1. The modelling component is a key focal

point and provides a shared reference and navigation

aide throughout a project. The current prototype uses

performance case modelling, which is an adaptation

from unified modelling language (UML) Use Case

notation is widely used in object-oriented software

systems analysis (Cockburn, 1997) and has been

adapted for more general systems analysis

(Marshall, 2000). Performance case notation

provides a simple, end-user understandable means of

defining a problem space.

A performance diagram is a graphic that

illustrates what performers do on the job and how

they interact with other performers to reach

performance goals. A role is a function that someone

as part of an organizational process (e.g., mission

commander, radio operator, vehicle inspector).

A primary role is the focus of a project.

Secondary roles are entities that interact with the

primary role, and may be included when looking at

team performance. The primary role is likely to

achieve several performance goals, e.g. a mission

commander would have to successfully plan, brief,

execute and conduct an after action review. High

level performance goals decompose into lower level

diagrams containing sub-goals. Performance goals

represent desired performance at an individual level

and each should be directly linked to an

organisational level performance goal.

Facilitated by the groupware component the

analysis team works collaboratively to create and

edit the performance diagram. The analysis team

will use the diagram to develop a shared

understanding of a domain and identify performance

cases where there is a gap between desired on-the-

job performance and current on-the-job

performance. It allows the organization to pinpoint a

specific performance discrepancy that could be

costing time, money, and other resources. Those

performance cases will be subject to a more detailed

analysis.

There are a variety of data collection templates

that could be attached to the performance case to

assist in this. The current version of the prototype

uses a gap analysis template (see right side of figure

2) in which data is collected about current and

desired performance in the tasks that are carried out

in pursuit of a performance goal. Where a gap is

found, for example if 100% accuracy is required on

a task and only 60% of those assigned to the task are

able to achieve this, then a cause and solution

analysis will be initiated. The ultimate goal of

problem-solving analysis is to close or eliminate this

gap in the most cost-effective manner. In a cause

analysis, stakeholders review gap data, brainstorm

Figure 3: An automatically generated rationale diagram

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

590

possible causes, put them into cause categories, rate

them by user-defined criteria, and select which ones

to pursue. The prototype allows users to categorize

causes so the recommended solutions are more

likely to address the underlying causes. The specific

process used in this version is described in more

detail in Douglas et al, 2003.

The focus of this system is the actual roles

people perform in an organisation (as opposed of

their position titles) and the goals they are expected

to achieve. This is modelled in an analysis system

with the models providing a framework for

performance metrics. The gaps in organisational

performance evident in these metrics are used to

initiate support systems development (software

tools, training courses).

Rationale management (Moran and Carroll,

1996, Burge and Brown, 2000) is integrated into the

system. Rationale management allows auditing of

decision making when solutions resulting from

analysis fail to make an impact on organisational

performance. In addition to the capture of informal

rationale information, through archiving of online

discussions, a rationale diagram can be

automatically generated from the data entered into a

system. Figure 3 illustrates the rationale diagram

generated by the current prototype. For each

performance goal, gaps in performance leading to

the goals are entered, and those selected for further

analysis are indicated by a tick. For each gap

selected, the potential causes for the gap are

indicated. For each selected cause for the gap, the

potential solutions considered are indicated, and a

tick will show the solutions chosen for

implementation.

3 FUTURE WORK

The concept of configurability is an important part

of the work carried out to date. The framework on

which the model is based is meant to provide a

structure for a variety of methods that can be tailored

to specific groups or situations. The same is true for

software architecture. A fixed tool based on one

specific methodology is likely to be of limited use.

This concept is difficult to demonstrate and test

when there is only one instance conforming to the

model. A second prototype is being constructed,

which is conformant to the framework, but is

customised to the specific data collection methods,

terminology and collaborations tools used by the US

Coast Guard’s Human Performance Technology

Centre. Once more than one instance of an

organisational performance analysis tool is

available, it will be possible to investigate the

possibility of translating performance analysis data

between different tools conformant to the

framework. Domain ontology will be used to

facilitate this.

REFERENCES

Burge, J. and Brown, D. C., 2000. Reasoning with design

rationale. In John Gero (ed.) – Artificial Intelligence

in Design ’00, Kluwer Academic Publishers,

Dordrecht, The Netherlands, 611-629.

Cameron, J., 2002. Configurable development process.

Communications of the ACM. (Vol. 45, No. 3), 72-77.

Cockburn. A., 1997. Structuring use cases with goals.

Journal of Object Oriented Programming, 10 (7), 35–

40.

Douglas, I., Nowicki, C., Butler, J. and Schaffer S., 2003.

Web-based collaborative analysis, reuse and sharing of

human performance knowledge. Proceedings of the

Inter-service/Industry Training, Simulation and

Education Conference (I/ITSEC). Orlando, Florida,

Dec.

Douglas, I. and Schaffer, S., 2002. Object-oriented

performance improvement. Performance Improvement

Quarterly. 15 (3) 81-93.

Flowers, S., 1996. Software failure: management failure.

Amazing stories and cautionary tales. Chichester,

New York: John Wiley.

Gilbert, T., 1996. Human competence: Engineering

worthy performance (Tribute Edition). Amherst, MA:

HRD Press, Inc.

Marshall, C., 2000. Enterprise Modeling with UML:

Designing Successful Software through Business

Analysis. Reading, MA: Addison-Wesley.

Moran, T.P. and Carroll, J.M., 1996. Design rationale:

concepts, techniques, and use. Mahwah, NJ: Lawrence

Erlbaum Associates.

Robinson, D. and Robinson J.C., 1995. Performance

Consulting: Moving Beyond Training. San Francisco:

Berrett-Koehler. References

Rossett, A., 1999. First Things Fast: A Handbook for

Performance Analysis. San Francisco: Jossey-Bass

Pfeiffer.

Weinberg, G., 2001. An introduction to general systems

thinking. New York: Dorset House.

Yao, C., Lin, K.J., and Mathieu R.G., 2003. Web Services

Computing: Advancing Software Interoperability.

IEEE Computer, October, 36 (10), 35-37.

Ye, Y., and Fischer, G., 2002. Supporting reuse by

delivering task-relevant and personalized

information. Proceedings of the Twenty-fourth

International Conference on Software

Engineering, 513-523.

FOUNDING ENTERPRISE SYSTEMS ON ENTERPRISE PERFORMANCE ANALYSIS

591
