INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION
OF JOB SEEKERS TO THE LABOUR MARKET.
Paraskeuas P. Chatzidiakos
Department of Electronics, Technological Educational Institute of Athens, Athens, Greece
Christos Skourlas
Department of Informatics, Technological Educational Institute of Athens, Athens, Greece
Theodoros Alevizos
Dept. of Industrial Informatics, Technological – Educational Institute of Kavala, Kavala, GREECE
Keywords: System Integration, System Interconnection, Data Mart, Cross Lingual Information Retrieval.
Abstract: In this paper, the interconnection and integration problem of disparate Inform
ation sources including
multilingual information related to the Unemployed and Business is analyzed. A possible solution based on
the use of the European curriculum vitae and the creation of Data Marts is briefly described. The approach
is also influenced by well-known Cross-Lingual Information Retrieval (CLIR) techniques. We also focus on
the creation of a pilot Information System for the Institute of Labour (INE) of the Greek General
Confederation of Labour (GSEE). Eventually, our experience and a first evaluation of the system are
discussed.
1 INTRODUCTION
There are various organisations (e.g. EURES –The
European Employment Services for the Job
Mobility, Information Offices for the Unemployed
and Businesses, National Employers' Organisations,
National Trade Unions) that are interested in
vocational training and employment. The
interconnection / integration of operational,
disparate Information sources, which have been
established to cover the needs of such organisations
is a difficult problem, in general.
The technical framework for solving the
problem
,
today, is related to traditional methods and
techniques of system analysis and, also, new
concepts (e.g., data warehouse, data mining),
techniques (e.g. Information / Text Retrieval
techniques), tools (e.g. OLAP, Document
Management tools) and standards (e.g. Z39.50).
1.1 Standardised individuals’ data.
The basis of an Information System for supporting
the inclusion of unemployed individuals to the
labour market is a comprehensive standardised
overview of education attainments and work
experience of the individuals.
It is, also, impossible to improve the
m
a
nagement and support decisions that are related to
the problem of the unemployment without having a
common pool of "unified" data.
1.2 Cedefop
Cedefop (Centre Europeen pour le Developpement
de la Formation Professionnelle) is the European
agency that helps policy-makers and practitioners of
the European Commission, the Member States and
social partner organisations across Europe make
informed choices about vocational training policy. It
617
P. Chatzidiakos P., Skourlas C. and Alevizos T. (2004).
INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.
In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 617-624
DOI: 10.5220/0002657206170624
Copyright
c
SciTePress
was established as a non-profit making body,
independent of the Commission, to help rethink the
direction and requirements of vocational training
and assist the Commission in promoting the
development of vocational training.
1.3 The European Curriculum Vitae
The European Curriculum vitae (CV) (Cedefop) is
recommended by CEDEFOP to provide information
on: language competences, work experience,
education and training background, additional skills
and competences acquired outside formal training of
the individual. The CV format is available in 13
languages and can be download in various formats
(MS Word, rtf, pdf). Download examples of filled in
CVs are also available.
1.4 The Case of the Greek Institute of
Labour
The Greek General Confederation of Labour
(GSEE), the leading employees' organization, was
founded in 1918. Members of the GSEE are the
second level trade union organisations (union
federations and Labour Centres). The Institute of
Labour (INE) of the GSEE was established in
December 1990. INE GSEE is a non profit making
company and is organised also at the regional level
(based on 13 administrative regions) and at the
branch level (based on 22 branches of economy
activity. It aims at the scientifically supported
intervention of the trade union movement in the
following areas of action:
Research, studies and data gathering.
Planning, implementation and development of
appropriate schemes for vocational training.
Development of systems related to trade union
education and training.
The Information Office for the Unemployed and
Businesses was also established in 2000 by GSEE
with the aim to provide information about labour
relations, insurance legislation, immigration policy,
employment, education and training.
A pilot Information System was established to
study the current situation, gain experience, provide
information about employment, education and
training and facilitate one’s inclusion to the
labour/job market.
In this paper the problem of integration of
information collected / gathered “in house” and
information, partially extracted, from other
(external) information systems for the Unemployed
and Businesses is presented and discussed. In the
following section 2 the problem’s solution is
formulated following various directions
(perspectives): Data Warehouse / Data Mart,
information extraction based on the European CV
and Document / Text Retrieval. In section 3 we
present a first solution of the problem in the case of
the INE. Eventually, in section 4 we discuss our first
estimations. Conclusions and future activities are
presented in section 5.
2 PROBLEM SOLUTION
There are many aspects of the problem related to the
various requirements not only of an information
office but also of the entire parent organisation.
2.1 The Perspective of the Data Mart
National organisations usually have invested money
in "legacy" systems and disparate databases. Thus, if
new needs must be covered they often build some
structure on top of the existing systems, a data
warehouse, where information of many databases is
copied to a central database. If there are also
information needs for an updateable new system
usually for a specific topic we prefer to design and
operate Data Mart.
Data warehousing and Data Marts arose for two
main reasons: First, the need to provide single,
clean, consistent source of data for decision support
purposes; second, the need to do so without
impacting operational systems.
There are potential users that prefer to use office
automation software for writing documents (e.g.
CVs of individuals out of employment, companies’
profiles). We have to collect and organise all these
kinds of information. In some cases there is also a
need to handle images, drawings etc. Text and
Document retrieval and text mining can offer the
appropriate techniques.
An emphasis must be given to the fact that the
design, construction, and implementation of the data
warehouse / data mart is an important and
challenging consideration that should not be
underestimated (e.g. (Karanikolas, 2003)).
Lechtenborger and Vossen (Lechtenborger,
2003) stress that the warehouse design is a non-
trivial problem. They present a sequence of
multidimensional normal forms and discuss how
these forms allow reasoning about the quality of
conceptual data warehouse schemata. Lu and
ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
618
Lowenthal (Lu, 2003) examine strategic
arrangements of fact data in a Data Warehouse in
order to answer analytical queries, efficiently, and
improve query performance.
2.2 Using Z39.50 protocol
There are various Standards operating in the domain
under consideration to provide the framework for the
access, exchange, management and integration of
data that support information needs and the
management, delivery and evaluation of related
services. One promising specification adopted by the
ISO (ISO 23950) is the NISO Z39.50 protocol, the
international standard for information retrieval. This
protocol could also be seen as an interoperability
standard enabling disparate applications to access
and exchange a wide array of information resources
and databases.
The typical scenario for Z39.50 applications,
today, has much impact on libraries and information
retrieval communities. ZING (Z39.50 International:
Next Generation) is the umbrella name used to
describe several experiments that focus on making
the protocol more amenable to and usable by the
Web-based community (Needleman, 2002).
The protocol could support such functions as
security checks, participants’ identification,
availability checks, exchange mechanism
negotiations and, most importantly, data exchange
structuring. As an example, in the GAIA project, in
Electronic Brokerage, customers are provided with a
uniform way of accessing heterogeneous suppliers
without changes in the supplier software and Z39.50
is used for discovery of a resource or product etc
(RFC 2525), (Hands, 2002).
Finally, the Standard is mature and stable, has
been widely implemented (mainly in the library
world) and there are available not only commercial
products but also freely available code packages that
can be used to build applications (Needleman,
2002).
Analysing this situation we have to study the
related standard that seems to offer a key structural
basis for solving the access and interconnection
problem.
2.3 Document storage and retrieval
The similarity of a document against a submitted
query has been the field of continuing research for
many years. In the popular vector space model a
data set of n unique terms is specified, called the
index terms of the document collection, and every
document can be represented by a vector (T1, T2,
…, Tn), where Ti=1, if the index term i is present in
the document, and 0 otherwise.
We can distinguish two types of index terms (or
key phrases): Keywords, Uncontrolled terms. The
difference between Keywords and Uncontrolled
terms is that keywords are phrases that belong to a
specific authority list e.g. a specific Classification
Coding scheme (or a thesaurus). Uncontrolled terms
are usually given by individuals (e.g. authors) or
extracted using specific Information extraction
techniques. Hence, we can form a list of UTs and
eventually using various methods and experts (e.g.
information officers) to form an authority list of
keywords in the future.
A query is a document and can be represented in
the same manner. The document and query vectors
can be envisioned as an n-dimensional vector space.
A vector matching operation, based on the cosine
correlation used to measure the cosine of the angle
between vectors can be used to compute the
similarity. Hence, the following equation (e.g.
(Karanikolas, 2000)) gives us a well-known method
to measure the similarity of document Di against
query Q:
SD Q
qt
qt
qt
LL
i
jij
j
n
jij
j
n
j
n
jij
j
n
QD
i
(,)=
=
=
=
=
1
22
11
1
where n is the number of index terms used in the
collection, tij is the weight of term j in document Di
and qj is the weight of term j in the query.
The following two equations can be used to
measure the terms tij and qj:
t
F
F
ij
ij
i
=+05 05..
max
q
N
DOCFREQ
j
j
=
log
2
where Fij is the frequency of term j in document Di,
maxFi is the maximum frequency of the terms in
document Di, N is the number of documents in the
collection and DOCFREQj is the number of
documents that include the index term j.
INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.
619
2.4 Phrase extraction.
Phrase extraction is the subject of interesting
research accompanied by various experimental (and
not only) tools. As examples we can mention KEA
system which implements in Java simple algorithms
for extracting phrases from English text (Witten,
2000) (Witten, 1977).
It is worth mentioning here that such research
works and tools are usually oriented towards the
extraction of information from Web applications
Especially in the case of some languages (e.g.
the Greek language) there is a rich inflectional
(grammatical) system that implies further difficulties
in the extraction process. Prerequisites for a serious
work in handling Cross Lingual text are the use of a
list of stop-words, some morphological analysis,
stemming, etc. It is also interesting to see the
research works attacking the problem of extracting
phrases from texts written in languages with rich
inflectional system (e.g. (Ahonen, 1977) (Alevizos,
1989)).
We must also stress the importance of n-grams
for extracting keywords and the free-text searching
process.
Using these extracted phrases human experts can
form a list of Uncontrolled Terms (phrases), which
is some kind of controlled vocabulary, and can be
used as terms characterising the document.
Then, we can use such terms for classifying (or
indexing of) the document.
3 INFORMATION EXTRACTION
BASED ON EUROPEAN CV
European CVs (Cedefop) share a common structure
(form). They include information organised in text
mode having the following fields (and sub-fields):
Personal Information: Name, Address,
Telephone, E-mail, Nationality, Date of birth
Work Experience: Dates, Name and address of
employer, Occupation or position held, Main
activities and responsibilities.
Education and training: Dates, Name and type
of organisation providing education and
training, Title of qualification awarded,
Principal subjects / occupational skills covered,
Thesis Title and short comments.
Personal skills and competence: Mother
Tongue, Other Languages (Reading skills,
Writing skills, Verbal skills)
Social skills and competence: Team work,
Mediating skills, Intercultural skills
Organisational skills and competence
Technical skills and competence
Additional Information Publications
Personal Interests
All CVs form a potential source for extracting
information e.g. the classification codes related with
the employment.
Figure 1 shows a portion of the Entity
Relationship model that illustrates the implemented
database. The information is well structured, in
general, but there are also fields (or sub-fields)
written in plain text. To clarify things let us consider
the Work Experience field that is a key text field for
our study. Examples of values of such a field could
be the following (Cedefop):
• Dates: March – July 2002
• Name and address of employer: Youth Unit,
DG Education and Culture, European Commission
200, Rue de la Loi, B-1049 Brussels
• Occupation or position held: Independent
consultant
• Main activities and responsibilities:
1. Evaluating youth training programmes and the
Partnership between the Council of Europe and
European Commission
2. Organizing and running a 2 day workshop on non-
formal education for Action 5 large scale projects
focusing on quality, assessment and recognition.
Some portions, as Occupation and Employers’
sub-fields could be structured and some coding
scheme could also be used. Unfortunately, Main
activities and responsibilities are usually written as a
plain text. Such a text could only be retrieved using
free text searching techniques and keywords or
uncontrolled terms summarizing the previous work
experience of the individual and the current
occupation.
The Education and Training field is another key
text field for our study. Examples of the values of
such a field could be the following (Cedefop):
• Dates: 1997-2001
• Name and type of organization: Brunel
University, London, UK, Funded by an Economic
and Social Research Council Award
• Title of qualification awarded: Ph.D.
• Principal subjects/occupational skills covered:
Thesis Title: 'Young people in the Construction
of the Virtual University’, Empirical research that,
directly, contributes to debates on E-learning.
• Dates: 1993- 1997
• Name and type of organization: Brunel
University, London, UK.
ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
620
• Title of qualification awarded: Bachelor of
Science in Sociology and Psychology.
• Principal subjects/occupational skills covered:
Sociology of Risk, Sociology of Scientific
Knowledge / Information Society, E-learning and
Psychology, Research Methods.
The name and the type of organizations and the
title of qualification have to be imported from
external Information Systems or standardized using
coding schemes, in house. Subjects and occupational
skills have to be handled using two complementary
approaches: Subject Headings (or Thesaurus) and
Uncontrolled phrases. The Uncontrolled phrases
(index terms) must be given by the applicants while
the controllable terms are assigned by experienced
information officers.
Dissertation titles and the related short abstracts
form some kind of bibliographic data and can be
handled using standard procedures. However, this
approach (these handling procedures) makes sense
only in the case of a system oriented towards the
support of scientific CVs.
Skills and competence are also potential sources
of critical information but, in general, is difficult to
be handled using (even semi) automated methods.
A possible solution for the retrieval of CVs
seems to be classification based on training sets.
Hence, intuitively, we propose the use of a
document collection (collection of portions extracted
from specific CVs that is the “training” set) as a
basis. Each new document (portion of the CV) could
be seen as a query submitted for extracting “similar”
documents from the collection. The document
collection is also characterized by a number of Index
Terms (Uncontrolled Terms). For each document in
the collection the existing Index terms in the
document can have weight, frequency etc. This
approach has an advantage because such text
retrieval techniques are well known and have been
tested for many years.
Reviewing the process we can select new
documents classified and improve the document
collection (the “training” set).
Hence, for each new document we can extract
the key-phrases for possible future utilization in the
list and identify the UTs that exist in the text. Then
the vector for the document is constructed and the
similarity of the document with the documents of the
training set is calculated using the above measure.
Then a discretization table (with ranges) could
be used to propose possible Classification Codes
(CC) for the indexing of the document.
4 DISCUSSION
Main target of this paper is to discuss techniques that
could offer to the information officers the
opportunity to extract CVs and companies’ profiles
from various sources, store them in a Data Mart
system and automatically or semi-automatically
match (retrieve) the appropriate information in the
future. Hence, such cross lingual documents could
be classified by using codes contained in a Standard
Classification Scheme – SCS. The STEP list
(EKEPIS), a statistical classification list of jobs, was
used in our system. Eventually, the information
officer can focus on an information extraction
process, from various sources and documents, which
is based on phrases from a loosely controlled
vocabulary and codes from a specific SCS.
The proposed method is based on the following
process:
1) A set of documents is formed by extracting
(and storing) documents from various sources. These
documents play the role of a “training” set for the
whole Corpus of the documents in the future.
2) The traditional IR process is applied as a first
step to automatically or semi - automatically focus
on some information extraction; in other words to
extract potential terms describing documents.
3) The creation of an authority list follows. All
the extracted UTs are submitted to the information
officer(s) to select the appropriate ones to
characterize the documents.
4) A Study of the distribution of UTs in the
corpus of the documents can be conducted to form
the "training set".
5) A vector is created for each document of the
training set. Each item (of the vector) has two
possible values (true, false) representing the
existence or not of the corresponding UT in the
document. The last item of each vector has the
classification code (e.g. the STEP code) that
characterizes the document (the class of document).
Hence, there are some critical points for the
method:
Extract key-phrases. As an example, we can
adapt a method (e.g. Naïve Bayes technique)
used in (Witten, 1977) for selecting key-phrases
from a new document.
Using the extracted phrases from the text the
experts can form a list of Uncontrolled Terms.
The STEP list could be used for the indexing of
documents.
A Knowledge Discovery “mapping” between
UTs and classification codes must be supported.
INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.
621
4.1 Training set and documents’
representation
We introduce an ordered set (a sequence) of
Uncontrolled terms (UTs):
UTs
= UT
1
, UT
2
, …, UT
n
and the ordered set (sequence) of the Classification
Codes (CC):
CCs
= CC
1
, CC
2
, …, CC
k
For each document (e.g. CV, company’s profile) we
have to itemize all the appropriate terms.
Such a representation, as the above one, could be
implemented using various techniques. True
indicates the existence of the related UT in the
document and False means the nonexistence.
Alternative representations could also be
implemented and easily expand to include
frequencies etc. Further refinement is possible in
various directions and depth e.g. some weights could
be added for each term existing in the document.
The vector representations could be used as vehicle
for extracting a variant of association rules useful for
classifying documents.
4.2 Classification Rules - A Data
Mining approach
The training set could be defined as a relation
(matrix) of the form:
CC UT
1
… UT
n
CC
s
T)rue F)alse T)rue
e.t.c.
Figure 2
Classification rules of the following form are
easily produced (Karanikolas, 2002):
(Α
λ1
=ν
λ1
)^(Α
λ2
=ν
λ2
)^. . .^(Α
λj
=ν
λj
) (A
m+1
=B) where
1 λ
1
< λ
2
< . . . < λ
j
m for each attribute Α, m is
the number of UTs in the authority list, ν
i
{true,
false} and B {b | b is any valid classification
code}
5 CONCLUSION
The integration of existing, separately operated
Information Systems, which have been established
to cover the needs of the same enterprise, is a
complex and difficult problem to be solved. The
problem is even harder if a new system has to be
based on information extracted from in-house and
external information systems. Another complex
requirement is the need for supporting cross-lingual
information within the framework of the new
system.
As a first conclusion, from a technical point of view,
the interconnection of existing systems in GSEE etc
is possible. The proposed solution of using the
Z39.50 protocol for the interconnection problem is
technically valid and reliable.
There is a need for extracting and classifying
information, (semi) automatically. As an example
companies’ profiles form a potential source of
information for extracting classification codes
related with their activities. Data / Text mining can
offer the appropriate techniques (Deal, 2001). Fuzzy
sets can also be used for the mining of useful
information (Hong, 2003).
We have suggested methods for (semi) automatic
classification of CVs based on information retrieval
and knowledge discovery in databases.
Apart from the above mentioned and discussed
general structure of a CV there are also some other
fields of such a document that are case dependent
(e.g. training’ certification, organizational skills and
related fields). We shall focus on results related to
this analysis in the near future. There is also a plan
to extent the existing IS to “reflect” the new
understanding of information.
Legal aspects will also be examined in the future.
Acknowledgements: Mr Harry Papanikos has
developed a first prototype of the system
REFERENCES
Cedefop - Centre Europeen pour le Developpement de la
Formation Professionnelle
www.cedefop.eu.int/transparency/CV.asp
GSEE - Greek General Confederation of Labour:
www.gsee.gr
Karanikolas, N., Skourlas, C., 2003, Shifting from legacy
systems to a data mart and computer assisted
information resources navigation framework, In
ICEIS’03, 5th International Conference on Enterprise
Information Systems, ICEIS Press
Lechtenborger, J., Vossen, G., 2003, Multidimensional
normal forms for data warehouse design, Information
systems, No 28, pp 415-434.
Lu, X., Lowenthal, F., 2003, Arranging fact table records
in a data warehouse to improve query performance,
Computers and Operations Research.
ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
622
Needleman, M.., 2002, ZING Z39.50: Next Generation,
Serials Review, pp 248-250
RFC 2525, 1999, Architecture for the information
brokerage in the ACTS project GAIA, Blinov,
Bessonov, Clissmann
Hands et. al., 2002, An exclusive and extensible
architecture for electronic brokerage, Decision
Support Systems, vol. 29, pp 305-321
Karanikolas, N., Skourlas, C., 2000, Computed Assisted
Information Resources Navigation, Medical
Informatics and the Internet in Medicine, vol.25, No 2.
Witten, I., Frank E., 2000, Data Mining: Practical
Machine Learning tools and techniques with Java
Implementations, Morgan Kaufmann
Ahonen et. al., 1977, Mining in the phrasal frontier, In
Principles of knowledge discovery in Databases
conference, Springer - Verlag.
Alevizos et. al., 1989, Information Retrieval and Greek-
Latin text, 12th International ONLINE Information
EKEPIS - National Accreditation Centre of Vocational
Training Structures and Accompanying Support
Services: www.ekepis.gr/frame.html
Karanikolas, N., Skourlas C., 2002, Automatic Diagnosis
Classification of patient discharge letters. In MIE
2002, XVIIth International Congress of the European
Federation for Medical Informatics.
Deal, DC, 2001, Techniques of Document Management:
A review of Text Retrieval and related technologies.
Journal of Documentation 57, pp 192-217.
Hong, Tzung-Pei et. al., 2003, Fuzzy data mining for
interesting generalized association rules, Fuzzy sets
and systems.
Witten et. al., 1999, KEA: Practical automatic key
phrases extraction, Proceedings of the fourth ACM
conference on Digital Libraries.
INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.
623
APPLICANT
COMPANY
looks for
M
N
has
EXPERIENCE
1
N
CP_Street
CP_Number
CP_Name
Emp_Phone
Bike_Licence
Car_Licence
NameSex
Birth
Password
Username
App_No
1
M
knows
ISO_LANGUAGE
SEMINAR
Inst_Name
Sem_Skills
Duration
Start_Date
Ser_No
R_Skills
Lang_Title
W_Skills
V_Skills
Street
City
Phone
CP_Town
CP_Post_Code
CP_Region
CP_Fax
Street_No
Post_Code
Mobile
Fax
E_Mail
MName
LName
FName
Ser_No
Start_Date
End_Date
Emp_Name
Emp_street
Emp_Number
Emp_City
Emp_Fax
Emp_Mail
Emp_Site
Position
Activities
has attended
N
Language
Language_Code
CP_Job
CP_Phone
CP_Mail
ISO_COUNTRY
has nationality
N
1
VAT_No
Comp_Name
Comp_Site
resides at
1
N
Country
Country_Code
N
has maternal
language
N
1
reside at
N
1
gained working
in
1
N
N
M
EDU_TRAINING
is provided with
N
Ser_No
Start_Date
Gradu_Date
Edu_Name
Edu_Title
Edu_Skills
Edu_Level
EMPLOYER_TYPE
having horked in
the sector of
N
1
Emp_Type
Emp_Type_Code
INSTITUTE_TYPE
Edu_Type
Edu_Type_Code
belongs to the
rung
N
1
is activated in
the sector
N
1
CP_LName
CP_FName
CONTACT_INFO
CONTACT_PERS
ON
has
1
represents
1
N
Acc_No
Acc_No
Fi
g
ure 1: Portion of the Entit
y
-Relationshi
p
model
ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
624
