B2C Internet Authentication Method using Statistical

Keystroke Biometrics

Marino Tapiador

, Juan A. Sigüenza

IBM Global Services and Universidad Autónoma de Madrid,

Escuela Politécnica Superior, Spain

Universidad Autónoma de Madrid,

Escuela Politécnica Superior, Spain

Abstract. This paper is focused on biometric user authentication on the Internet

using keystroke dynamics. This work describes the advantages of using key-

stroke biometrics in B2C Internet applications, and also it shows the problems

and techniques related to sampling the typing pattern in the Internet. This re-

search work is presented applied to a real experimental system that implements

a keystroke dynamics login mechanism based on interkey and holdkey typing

times. Several experiments are described and as a result of these experiments, a

statistical pattern-recognition model based on mixed typing times and the aver-

age normalization technique is presented in this work. Internet open platform

technologies are used.

1 Introduction

In the work presented in this paper, we have developed a system based on behavioral

biometrics (see [1]) to provide authentication in a secure Internet application: a busi-

ness-to-customer (B2C) e-commerce system. The system uses the keystroke dynamics

to learn which is the user’s behavior when he/she types a sequence of fixed characters

in the keyboard. Several works on keystroke dynamics authentication can be found,

but not considering the specific characteristics of typing in Internet applications: for

instance, the preliminary work of Gaines and Lisowski [2], the password experiments

of Monrose and Rubin [3], or the authentication studies of Obaidat and Sadoun [4].

Keyboard is a common hardware that comes in useful to authenticate a user in the

Internet because nowadays is the common input device in each terminal in the net-

work. This is a key point for e-commerce systems which main objective is to get a big

number of customers i.e. in B2C systems. It also implies no extra-hardware needed,

that also increases the number of potential users of the system in the Internet. This

kind of biometric control in a web application already has a minimal cost because it

only needs new software, not extra-hardware.

Tapiador M. and A. Sigüenza J. (2004).

B2C Internet Authentication Method using Statistical Keystroke Biometrics.

In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 73-78

DOI: 10.5220/0002661100730078

 SciTePress

2 Method

2.1 Data Collection Mechanism for Typing Samples

A ‘sample’ in keystroke biometrics can be information related to: typing difficulty,

interkey times (latencies), holdkey times (durations) or others like the number of keys

involved on the character generation, keystroke overlaps, etc. Our work is focused on

measuring typing times i.e. latencies and durations. In the Internet the problem is to

do this sampling process in a platform-independent manner i.e. independently of the

CPU frequency where the user is typing.

The prototype developed in this work is based on machine cycles in order to be

able to fetch the holdkey times and get maximum sampling precision. Machine cycles

can be measured using low-level programming languages or assembler. However this

kind of languages depend on the hardware platform –kind of computer- been used, so

that it is not a valid approach for a B2C Internet application. This type of application

is going to run in the Internet where a lot of different hardware platforms are con-

nected. This requirement implies to use an open-platform language to capture the

keystroke biometric data: Java language. With this high-level language we can meas-

ure the machine cycles in an indirect way, using machine pseudocycles using an

event-based technique where a counter-thread is continuously increasing the value of

a variable i.e. this value is the number of machine cycles multiplied by a constant

factor equal to the number of machine instructions involved in the adding loop im-

plemented in Java language.

The machine pseudocycles are also dependent on the computer frequency where

the user is typing. The idea is we also need to identify the user independently which

computer is been used by him/her. In the Internet the user could be using our applica-

tion from different terminals at different times. Therefore, in order to assure a pattern-

recognition algorithm is able to identify the genuine user between different hardware

platforms, the biometric samples need to be normalized to be CPU frequency-

independent. In this case, a normalization technique by the average value is used. It

means the average time of the typed sequence is used as reference time to normalize

all the times in the sequence.

2.2 Statistical Model for Typing Recognition

The prototype is a typical three-tier Internet architecture. In our experiments the key-

stroke pattern-recognition prototype consist of a database with biometric information

that is checked with a server program (CGI in C++) when a user does a login into a

simulated web system i.e. an HTML page with a Java applet.

When the user tries to access to the website, the system sends a form (the Java applet)

where the user must type his/her userId and password. At the same time the system is

registering this information, it is also registering biometric data related to the key-

stroke dynamics of the user, and this information is sent to the server through Inter-

net. The server receives the biometric data and runs a CGI program with the logic

related to the pattern-recognition algorithms to try to identify or authenticate to the

user by his/her typing rhythm. The CGI compares the information with the informa-

tion stored into a database of files in the hard disk. This files come from the user

registration process in the system (training).

A statistical model provides the pattern-recognition mechanism, and it consists of a

parameter-based estimation. We can consider each holdkey or interkey time as the

result of a random experiment. That result is a normalized -by the average- time value

t in Ω = (0, +∞). Let be the hypothesis “each user types with some regularity rate”,

we can expect the time values generated by the user will be concentrated around some

average value, and with small deviations from it. These deviations are minimum

when the user is very regular. That behavior is well-modeled by a gaussian function

i.e. a normal density N(µ,σ²) with µ average and σ² variance. The analytic expression

of this function is well known:

N(µ,σ²) Æ f(x) = (1/√2 σ²π) exp( (-1/2 σ²) · (x- µ)² )

(1)

The f(x) corresponds to a normal distribution but we don’t know its exact parame-

ters (µ,σ²). The technique of maximum likelihood shows that the best estimators are:

µ = (1/n) Σ x

σ² = (1/n) Σ (x – µ )²

(2)

Thus with this technique we get a punctual density estimation following the time

distribution for a specific typing. Let be a T

time which estimated distribution is

(µ,σ²), the probability of getting that T

is defined by the density f

;µ,σ²). This T

point probability is used as a scoring function for the T

point by the system.

During the training phase (ten samples) the user generates the samples composing

a template that consist of the sample estimators for the average µ and variance σ² for

each time interval in the characters sequence. In production time, when a new T

generated in a sequence, its probability to occur is calculated using a maximum like-

lihood estimation by the sample estimators stored into the cited template. Therefore

that probability P

for T

is obtained based on its distribution estimation N

(µ,σ²) cal-

culated during the training phase i.e. f

;µ,σ²) = P

. If P

is too low it means is

highly probability the user has not generated the time, so he/she is a potential fake.

The opposite implies the user is probably the genuine user. In order to get this evalua-

tion in a [0,1] rate, it is normalized the density function by its maximum value and it

generates this scoring function:

S(x) = (1 / S

max

)· f

(x; µ,σ²) ,

S(x) = (√2 σ²π)· (1/√2 σ²π) exp( (-1/2 σ²) · (x- µ)² ) ,

S(x) = exp( (-1/2 σ²) · (x- µ)² )

(3)

During the training phase the sample estimators included in the statistical template

are calculated each time using this procedure:

(1st) Average, sample estimator:

= ( 1 / k ) · (n·µ

+ X

), k = n + 1; µ

= (1 / n) Σ X

, i = 1,2, ... n

(4)

(2nd) Variance, sample estimator:

² = ( (1 / (n + 1)) Σ X

² ) – µ

², i = 1,2, ... n + 1;

² = (1 / n) Σ ( X

- µ

)² = ( (1 / n) Σ X

² ) - µ

², i = 1,2, ... n

(5)

Where µ

is known because it was previously calculated, and the other term can be

also calculated due it depends on Σ X

² and occurs that:

² = (1 / n) Σ X

² - µ

² Æ (σ

² + µ

²) · n = Σ X

², i = 1,2, ... n; and thus:

² = ( ((σ

² + µ

²)·n+X

²) / k ) – µ

², k = n + 1

(6)

So this equations are used to calculate again the sample estimators for the average

and the variance each time a new sample is received during the training process, and

starting from an initial sample corresponding to the user registration into the system.

That first sample is used for the initial averages, and the initial variances are set to

zero. This statistical model is used in the same way for interkey times and for holdkey

times, just considering the different sequence lengths.

3 Experimental results

In the experiment the samples are composed of interkey times only, or holdkey times

only, or both of them i.e. mixed times. The statistical recognition model previously

described was used with one simple userId/password sequence (“autonoma” / “inter-

net”). Previous work in this area showed a better recognition rate using simple char-

acter sequences (see [5]). The main objective was to compare interkey times versus

holdkey times, and mixed times, and to measure the recognition rates. The experiment

was performed with a group of men and women with ages between 21 and 48 years

old. Netscape and MS-IExplorer v4+ were used under Windows platform.

The Table 1 resumes the results of the experiment and allows comparing the per-

formance of using the three time approaches. The table shows that comparatively the

recognition performance is better for mixed times. The figures in Table 1 show the

real user typing versus all the possible users included him/her, therefore each figure

should present a ‘diagonal effect’ i.e. a diagonal of maximum score values: diagonal

points are where the real user is the supposed user. The best performance is associ-

ated to the mixed times figure in the sense of it has a more clearly defined ‘diagonal

effect’.

Table 1. Experiment results of the three kind of times.

= Scoring. (X-axis: real user. Y-axis: supposed user.)

Statistical Model

Interkey times Holdkey times Mixed times

Thus, considering the winner mixed times only, the Table 2 illustrates with more

detail the scoring rates (%) achieved by this recognition model. The real users typing

are represented by the ‘X’ items and the supposed users or templates used are the ‘Y’

items. The ‘diagonal effect’ can be clearly observed and only one error is presented in

cell Y12-X9 i.e. a case where the maximum recognition value is obtained with a user

different to the genuine user.

Table 2. Experiment results of mixed times.

4 Conclusions

Considering the final results resumed in Table 1, the accuracy obtained is 99% for

mixed times versus a 97% for interkey times and a 94% for holdkey times. Thus, it is

observed that mixed times work better than each other separately. In terms of False

Accept Rate (FAR) and False Rejection Rate (FRR) the system showed a 0.6% of

FAR and a 7% of FRR (for details on FRR/FAR see the work of Wayman [6]).

Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 Y10 Y11 Y12 Y13

62 38 53 46 47 55 56 37 56 58 47 54 56

70 52 46 44 62 57 47 54 49 49 57 48

35 30

55 33 28 37 39 34 40 33 36 53 37

52 48 53

65 56 54 58 46 61 53 56 54 52

48 44 49 41

71 57 53 40 52 48 53 46 47

52 47 59 45 47

80 61 44 61 52 41 58 53

42 42 65 34 39 62

71 42 57 48 36 65 47

36 43 44 42 39 57 48

66 51 46 39 56 42

46 42 62 38 39 62 61 49

66 51 39 69 50

X10

53 47 62 40 51 61 59 45 57

70 46 54 56

X11

54 52 54 51 59 56 61 46 62 56

69 57 46

X12

30 27 42 22 21 39 43 37 39 33 25

76 32

X13

36 31 39 28 34 39 43 35 39 37 23 40

The experiments suggest that keystroke biometric devices can be developed for the

Internet using the average normalization technique to separate the typing samples

from the computer platform used to generate them. These keystroke biometric devices

can use open-platform tools like Java Applets or CGI programs. Multi-thread Java

programming techniques can already be used to capture the user typing rhythm with-

out intrusive impact i.e. not using ‘heavy’ components as e.g. ActiveX which need

special security permissions in order to access to low-level features of the machine.

Nowadays, the systems alerts to the user in order to close other applications running

during the login process in the website because the program could get varying

amounts of processor time, due the counts depend heavily on the other processes on

the machine. Future work could be focused on solving this issue.

The presented system is good for the B2C e-commerce model where we want to

reach a broad market i.e. it is good because it is a way to increase the security related

to the authentication process without requiring special biometric hardware devices

like fingerprint readers and so. The prototypes developed in our work have a low cost

in hardware and software in comparison to other traditional biometric devices (fin-

gerprint, iris-scan, etc.) and ‘brute force’ attacks are useless against them because

they should generate also the interkey/holdkey times in each password typing

(sample).

References

1. Bolle,R., Jain,A., Pankanti,S. Biometrics. Personal Identification in Networked Society.

Kluwer Academic Publishers. (1999)

2. Gaines,R., Lisowski,W., Press,S., Shapiro,N. Authentication by keystroke timing: some

preliminary results. In Rand Report, R-256, NSF, Rand Corp., Santa Monica, CA. (1980)

3. Monrose,F., Rubin,A.D., Keystroke dynamics as a biometric for authentication. Elsevier

Science Direct, 16, (no.4):351-359. (2000)

4. Obaidat,M.S., Sadoun,B. Verification of computer users using keystroke dynamics. IEEE

Trans. on Systems, Man and Cybernetics. Vol.27, No.2, 261-269. (1997)

5. Tapiador,M., Sigüenza,J. Fuzzy Keystroke Biometrics on web security. In AutoID’99

Proceedings: workshop on Automated Identification Advances Technologies, Summit,

New Jersey, USA, October 1999, IEEE Robotics and Automation Society, 133-136.

(1999)

6. Wayman, J.L. Technical Testing and Evaluation of Biometric Identification Devices. In

Biometrics. Personal Identification in Networked Society. 345-368. Kluwer Academic

Publishers. (1999)
