Diffusion
Behaviour of Cryptographic Primitives in
Feistel Networks
Vasilios Katos
Department of Information Systems and Computer Applications,
University of Portsmouth,
Burnaby Terrace, Portsmouth, PO1 3AE
Abstract. The concept of product encryption is resident in the majority of sym-
metric block ciphers. Along with product encryption, two properties were also
defined by Shannon, namely diffusion and confusion. In a product cipher such as
a Feistel Network (FN), or generally a Substitution Permutation Network (SPN),
diffusion is dependent upon two types of primitives, the nonlinear transformation
and the swapping scheme. Different approaches to diffusion analysis considered
either the topology of a FN, or the nonlinear transformation. This paper describes
a metric for diffusion in a way suitable for investigating the behaviour of the
underlying primitives of a FN.
1 Introduction
Since their invention, Feistel Networks (FNs) [1], [2] have been extensively studied and
analysed [3], [4]. The large research interest in FNs was due to several reasons:
– flexibility of the underlying non-linear primitive. The main non-linear function in-
volved in a FN, which is not required to be injective, in order to allow unambiguous
decryption;
– realisation of product encryption. FNs are excellent examples of product encryp-
tion. The concept of product encryption, introduced in [5], states that a chain en-
cryption of “weak” ciphers results into a much stronger one. In the same paper, the
notion of confusion and diffusion was introduced, which relate to the cryptographic
qualities of a cipher;
– the DES [6], which is probably the most analysed cipher, is a FN.
However, the bulk of the research in FNs is on homogeneous balanced FNs [3],
since the DES falls into this category. As a direct consequence, the research interest
focused on the construction and properties of the underlying non-linear function. In [3]
there is an investigation of the topology of a FN rather than the non-linear function.
In the same paper, confusion and diffusion were put into perspective and metrics such
as the diffusion rate and confusion rate where defined. A similar perspective is in [4],
but the methodology for examining the diffusion involved directed graphs. However,
although that a graph is an effective tool, the diffusion capability of a cipher is not
apparent as the complexity increases.
Katos V. (2004).
Diffusion Behaviour of Cryptographic Primitives in Feistel Networks.
In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 79-87
DOI: 10.5220/0002661300790087
Copyright
c
 SciTePress

The contribution of this paper is two-fold. First, it provides a step towards an alge-
braic description of the diffusion capacity of a FN round. This would allow investigation
of a much broader category of FNs, namely the unbalanced heterogeneous FNs. Second,
the proposed approach allows assumptions about the non-linear function which can be
experimentally evaluated. To demonstrate this, a randomness test is described and can
be used for evaluating the behaviour of the FN as a pseudorandom function [7],[8].
2 Diffusion instances and diffusion matrix
The idea behind the construction of the diffusion instances is related to the calculation
of the differential characteristic, which is the centrepiece of differential cryptanalysis
[9]. A block cipher can be viewed as a function with two independent input variables,
namely the plaintext (or ciphertext) and the encrypting (or decrypting) key, and one
dependent output variable, the ciphertext (or plaintext).
Diffusion is the property where a given input plaintext bit has the chance to af-
fect the output bits [5]. The higher the diffusion, the more output bits can be affected
by a certain input bit. In the described method, the diffusion instance is defined. The
diffusion instance is a snapshot of the diffusion capacity of a cipher.
The process for generating the diffusion instance is similar to the bitwise calcula-
tions used for the Strict Avalanche Criterion (SAC) investigation [10]. Given a random
plaintext p
0
∈
U
GF (2)
n
and a nonzero vector α = (1 0 0 ... 0), we compute:
ψ
j
= e
k
(p
0
) ⊕ e
k
(p
0
⊕ (α >> j)), 0 ≤ j ≤ n − 1 (1)
where (α >> j) represents the right shift of α by j bits.
If a[k] denotes the k-th bit of the binary string a, then matrix Ψ is defined as:
Ψ =





ψ
1
[0] ψ
1
[1] . . . ψ
1
[n − 1]
ψ
2
[0] ψ
2
[1] . . . ψ
2
[n − 1]
.
.
.
.
.
.
.
.
.
.
.
.
ψ
n
[0] ψ
n
[1] . . . ψ
n
[n − 1]





. (2)
The matrix Ψ would then be one diffusion instance. According to the definitions of
the characteristics of confusion and diffusion, for a cipher these characteristics are at
maximum if a (binary) swap of any of the input bits results to a swap of the output bits
with probability of 0.5 for every output bit. The diffusion instance represents the ability
of an input bit to affect an output bit, [11].
The diffusion matrix is calculated from the logical OR of the Ψ matrices:
Definition 1.
Let Ψ
i
, i = 1, 2, ... be the diffusion instances of a FN. The diffusion matrix
is defined as:
D =
_
i
Ψ
i
. (3)
80

Theoretically, in order to obtain the actual diffusion matrix of a FN, all plaintexts
must be considered. In practice, for a FN with a 64 bit input, it appeared that 10 random
plaintexts (and therefore 10 diffusion instances, accounting to a total of 640 plaintexts)
would suffice for determining the diffusion matrix. More analytically, after combining
10 diffusion instances, there was no change in the resulting diffusion matrix with each
additional diffusion instance. Furthermore, for a block cipher with maximum diffusion
capabilities, all entries of its diffusion matrix were equal to one, in the neighbourhood
of 10 diffusion instances. Considering a potentially strong block cipher with maximum
diffusion capabilities, it is expected that each diffusion instance would include (1/2)∗n
ones. Therefore, the ith diffusion instance would be expected to contribute with (1/2)
i
∗
n ones in the diffusion matrix. Alternatively, the probability that the calculated diffusion
matrix for a potentially strong block cipher is not the actual one, would be (1/2)
i
. It
should also be highlighted that since the key information is not considered, the proposed
approach is applicable only on block ciphers where their structure is not dependent on
the key.
The diffusion matrix shows if a pairwise relation exists between input and output
bits - that is, if a change of a particular input bit has the chance to affect a particular
output bit. The diffusion matrix is very helpful in examining product ciphers, because
it has the following property:
Lemma 1. Let C be a FN of j rounds. The diffusion matrix of the cryptosystem is equal
to:
D
C
= β(D
1
· D
2
· . . . · D
j
) (4)
where D
i
is the diffusion matrix of the ith round and β(·) : N → {0, 1} is defined as:
β(n) =
(
1, if n 6= 0
0, if n = 0
. (5)
Proof.
The case of a two round FN is shown, that is D = β(D
1
· D
2
). Let [·] be a
boolean evaluation, which evaluates the expression within the brackets to one if it is
true and to zero is it is false, such as [p is prime]. The elements of D, D
1
and D
2
are
denoted by δ
ij
, δ
0
ij
and δ
00
ij
respectively. Note that the output of round one is equal to
the input of round two. For the first leftmost input bit it is:
[input bit 1 is related with round-1 output bit j] = δ
0
1j
, 1 ≤ j ≤ n (6)
from the definition of the diffusion matrix. Similarly, for the first leftmost output bit:
[output bit 1 is related with round-2 input bit j] = δ
00
j1
, 1 ≤ j ≤ n . (7)
Combining (6) and (7) we obtain:
[input bit 1 is related with output bit 1] = δ
0
11
· δ
00
11
+ δ
0
12
· δ
00
21
+ . . . + δ
0
1n
· δ
00
n1
(8)
where the right-hand-side is a boolean expression, i.e. . + . denotes the boolean OR and
. · . denotes the boolean AND. If this is repeated for all input and output bits it gives:
[input i is related with output j] = δ
ij
= δ
0
i1
·δ
00
1j
+δ
0
i2
·δ
00
2j
+. . .+δ
0
in
·δ
00
nj
, 1 ≤ i, j ≤ n
81

or equivalently,
D = β(D
1
· D
2
) . ¤
From the diffusion matrix, we can calculate the diffusion, which is defined as the ratio
of ones:
Definition 2.
The diffusion of a block cipher with a diffusion matrix D of size (n × n)
is the quantity:
D
∆
=
#{δ
ij
|δ
ij
= 1, 1 ≤ i, j ≤ n}
n
2
. (9)
Obviously, D ∈ [0, 1]. This definition of diffusion, combined with Lemma 1 can be
used for assessing the diffusion of any product block cipher, provided that the diffusion
matrices of the underlying rounds are known. We will demonstrate this by applying it
onto FNs.
2.1 FN analysis
The diffusion matrix of a one round balanced FN would look like:
D =
·
O
n/2
I
n/2
I
n/2
F
¸
(10)
where O
n/2
is a zero square submatrix, I
n/2
is the identity submatrix and F is the
diffusion matrix of the round function. In a balanced FN, all submatrices are of size
n/2. The diffusion of this round would be equal to:
D
1
=
4n + n
2
D
f
4n
2
(11)
where D
f
is the diffusion of the round function. It can bee seen that the diffusion of a
one round balanced FN is upper bounded by (4 + n)/4n and therefore it cannot offer
complete diffusion. To calculate the diffusion of a two round balanced FN, we apply
Lemma 1:
D
2
= β(D
1
· D
1
) =
·
I
n/2
F
F β(F · F)
¸
(12)
where it can be seen that the diffusion for a two round balanced FN can be at most
(3n
2
+ 2n)/4n
2
. For a three round balanced FN, the diffusion can reach its maximum
value, 1.
We observe that no matter how strong the round function is, the diffusion of a two
round balanced FN is limited by the boundary 3/4. The reason for this is the structure
of the diffusion matrix. The permutation of the columns of the matrix is directed by the
Swapping Scheme, SS, which appears after the nonlinear transformation in a Feistel
round. Although that the SS does influence the diffusion of the FN, it does not actually
82

increase it; the increase is due to the application of the non-linear transformation. Typ-
ically, a SS is a permutation of the input bits. In a balanced FN the permutation is the
swap between the n/2 leftmost bits and the n/2 rightmost bits. This swap is responsible
for the symmetry in the diffusion matrix. However, each application of SS would not
increase the diffusion:
Corollary 1. The product encryption of a block cipher with diffusion equal to D and a
SS, results to a cipher with the same diffusion (D).
The proof follows from the fact that the diffusion matrix of the SS is a matrix with
exactly n nonzero elements, arranged in a way that every row has exactly one nonzero
element (i.e. the rank of the matrix is n). The identity SS is an instance of a SS where
the diffusion matrix is the identity matrix.
The inherent structure of the FN diffusion matrix reveals the limitations of its dif-
fusion capacity. Since the diffusion D measures the density of ones in the matrix, it
follows that 1 − D would correspond to the density of zeros. It is therefore desirable
that 1 − D reaches zero, in order to attain maximum diffusion. As observed above, in
a two round FN with the ”traditional” swapping of the left and right input blocks, the
number of zeros would be at least 1−(3n
2
+2n)/4n
2
, i.e. it would reach asymptotically
1/4 as n increases.
We now consider a two round Substitution Permutation Network, SPN [2], [12],
where each round includes a non-linear function of the same diffusion D
1
as our FN
above. For simplicity, it is assumed that these two rounds include different nonlinear
functions, although their diffusion is the same, D
1
= D
2
. We also consider the per-
mutation to be a random SS, i.e. a random permutation of the input bits, rather than a
tidy swapping of the left and right input block. The diffusion of the one round instances
would be:
D
1
= D
2
=
4n + n
2
D
f
4n
2
(13)
where D
f
denotes the diffusion of the underlying nonlinear function. However, in a
SPN construction it is possible that the zeros are placed randomly in the diffusion ma-
trix. Therefore, the expected zeros in the diffusion matrix of the two round SPN for
D
f
= 1 would be (for the proof see Lemma 2, section 3):
(2(1 − D
1
) − (1 − D
1
)
2
)
n
=
µ
15n
2
− 56n + 16
16n
2
¶
n
(14)
which is small (< 0.006) for most values of n (n ≥ 6). From this result the inefficiency
of FNs with respect to diffusion is apparent.
As mentioned above, Lemma 1 is useful when analysing the diffusion of product
ciphers. For instance, FEAL-4 [13] is a four round FN with the characteristic that the
leftmost half input is added (modulo 2) to the rightmost half input, before the first FN
round. Considering the product encryption of the first addition and the first round, the
diffusion at the end of the first round would be:
β(
·
I
32
O
32
I
32
I
32
¸
·
·
O
32
I
32
I
32
F
¸
) =
·
O
32
I
32
I
32
F
¸
(15)
83

i.e. the additional complexity of the initial addition is completely redundant and unnec-
essary from a diffusion perspective, since for FEAL D
f
= 1.
3 The diffusion randomness test
Statistical tests for randomness [14]-[16] are of a particular interest in cryptography,
since they are one of the approaches for assessing the cryptographic strength of a cipher.
This section describes a randomness test utilising the diffusion instances, Ψ.
For a potentially strong cipher, the number of zeros must be equal to the number
of ones in every row of the diffusion instance. Furthermore, for a potentially strong
cipher, (statistically) all runs of Ψ table constructions should result to having the number
of ones equal to the number of zeros. However, such an examination does not give
any indication about existing linear relations between the elements in the matrices. For
instance, if ψ
2
[1] = ψ
3
[2] with probability different to 0.5, there is a linear relation
between input bits 1 and 2 [17].
The diffusion randomness test deals with the similarities of the diffusion instances,
Ψ. For a potentially strong cipher the following criteria for the Ψ matrices are set:
–
the number of ones should be equal to the number of zeros,
– the ones (and zeros) should be randomly distributed in the matrix,
–
Ψ
i
and Ψ
j
should not be similar for i 6= j.
The first criterion denotes that the cipher is not biased toward ones or zeros. This
is inherently related to the confusion of a cipher, where it is desirable that the chance
of an output bit inverting is 0.5, given an inversion of an input bit. Published statistical
tests for randomness, such as the frequency test [14] can be used.
The second and third criterion include arbitrary terms and need to be quantified. The
test described in this paper attempts to provide means for measuring the randomness
and similarity of the matrices as follows. The randomness test is based on the following
Lemma.
Lemma 2. Let A and B be two square matrices and p
a
and p
b
be the densities of zeros
in each matrix respectively. If the zeros are distributed randomly in the matrices, then
the expected density of zeros in their product C = A × B would be:
p
c
= (p
a
+ p
b
− p
a
p
b
)
n
(16)
where n is the dimension of the matrices and the multiplication operation is performed
in the set of integers.
Proof.
For A, the density of zeros would be:
p
a
= P (a
ik
= 0) =
#(zeros in A)
n
2
(17)
Similarly, for B:
84

p
b
= P (b
kj
= 0) =
#(zeros in B)
n
2
. (18)
For every element in C, the following relation holds:
c
ij
=
n
X
k=1
a
ik
b
kj
. (19)
The probability to obtain a zero is obtained from (19):
P (c
ij
= 0) =
Q
n
k=1
P (a
ik
= 0 ∪ b
kj
= 0) = (p
a
+ p
b
− p
a
p
b
)
n
. ¤
By comparing the actual and estimated values, it is tested whether a cryptographic
primitive behaves as a random source when generating the Ψ matrices. That is, in the
case of a random source the zeros will be randomly placed in the matrices and there
would be no consistent placement whatsoever. We argue that if the actual and estimated
values are (statistically) different, then the underlying cryptographic primitive does not
yield a pseudorandom function. The opposite is not necessarily true; a primitive passing
the test does not imply that it is a pseudorandom function, since the test does not provide
any indication about the computational indistinguishability of the primitive [18].
diff_rand_test(A,B){
p_a = zeros_density(A);
p_b = zeros_density(B);
p_c = zeros_density(A*B);
if (abs(p_c-(p_a+p_b-p_a*p_b)ˆn)>significance_level )
then return (’fail’)
else return (’pass’) }
Unfortunately for a relatively large n (n > 40) and p
a
, p
b
< 2/3, the density of
zeros is negligible for both expected and actual values and therefore the randomness
test would not produce significant results. Therefore it is suggested that the Ψ matrices
are partitioned and the test is applied onto the partitions (submatrices). This is particu-
larly applicable in FNs, where there are emerging submatrices due to the non uniformal
treatment of input and output bits.
For the case of a balanced FN, the Ψ matrix would consist of four submatrices Q
i
as follows:
Ψ =
·
Q
1
Q
2
Q
3
Q
4
¸
(20)
and the test would then run as: diff
rand
test(Q
i
,Q
j
), where i 6= j. It is expected that
a three round balanced FN with an underlying round function being a pseudorandom
function would pass the test, although that passing the test would not imply that the
round function is pseudorandom. Applying this assumption to the well studied DES, it
was established that the three round FN with the DES primitive did not pass the test,
confirming the validity of the test (Table 1). The fact that DES could not pass the test
is a direct consequence of the the inability of DES to reach complete diffusion in three
rounds.
85

Table 1. Significant differences in DES
product expected actual difference diff
rand
test()
Q
1
× Q
2
0.241739 0.216797 2.5 fail
Q
1
× Q
3
0.204115 0.179688 2.4 fail
Q
1
× Q
4
0.126188 0.077148 4.9 fail
4 Conclusions
Clearly the reason to adopt a FN structure in a block cipher is mainly due to the con-
venience it offers, such as ease of moving between encryption and decryption, and less
due to its diffusion capabilities. High diffusion in a product cipher implies that the input
bits are be treated uniformly in every round. Since this is not the case for a FN, addi-
tional complexity (e.g. more rounds) would be required. The proposed description and
metric of diffusion enables both the investigation of the topology (structure) of a FN
as well as the underlying non-linear function(s). This would allow the investigation of
FNs consisting of different round functions, with varying input and output lengths as
well as different swapping schemes (unbalanced heterogeneous FNs).
Although that the proposed approach initially aimed for studying FNs, most product
block ciphers can benefit from such an analysis.
