Inter-domain Authentication and Authorization

Mechanisms for Roaming SIP Users

Dorgham Sisalem, Jiri Kuthan

Fraunhofer Institute for Open Communication Systems (FhG Fokus)

Kaiserin-Augusta-Allee 31, 10589 Berlin, Germany

Abstract: To enable users to utilize the services of various providers of

multimedia services based on the session initiation protocol (SIP), some kind of

interaction is required between the foreign provider and the home provider of

the users. Such interaction is required for example to allow a user to utilize

services provided by a foreign service provider while the user is on travel. In

this paper we describe two possible approaches for exchanging authentication,

authorization and accounting (AAA) information between foreign and home

providers, namely: SIP dependent and independent inter-domain AAA

communication. In the SIP dependent scenario, SIP is used as the

communication protocol between the interacting providers and for carrying any

information that needs to be exchanged between the providers. With the SIP

independent scenario a special AAA protocol is used between the domains for

exchanging AAA related information. Both approaches will be described in

terms of message sequences that would be exchanged and will be analyzed in

terms of their efficiency, flexibility and security. The here described scenarios

present an overview of various efforts currently being followed in the

standardization groups and are based on standardized protocols. Our

contribution is to provide the details of the currently discussed concepts and

compare between them.

Introduction

The recent advances in the telecommunication market in the form of high speed

access networks and integration of messaging, VoIP, location-based services and

other multimedia services based on the session initiation protocol (SIP) 0 as well as

the availability of low-cost wireless access technologies, is leading to the emergence

of a new breed of network and service providers. Those providers not only differ in

their used access technology and provided services but also in their business models

and structures. Such providers can range from large providers such as the current

telecom providers offering multiple-services and covering large geographical areas

down to small providers offering certain services such as conferencing or messaging

only or covering small geographical areas such as a coffee shop or a shopping mall.

For such providers to offer their services in a profitable manner they need to have as

large user base as possible. Having to establish a contractual relation with each user

before offering him a service is usually a long and costly procedure.

Sisalem D. and Kuthan J. (2004).

Inter-domain Authentication and Authorization Mechanisms for Roaming SIP Users.

In Proceedings of the 3rd International Workshop on Wireless Information Systems, pages 89-99

DOI: 10.5220/0002668300890099

 SciTePress

The experience gained from the enormously successful pre-paid and call-by-call

charging models suggest that users appreciate the liberty of being allowed to choose

between different providers without having to establish a contractual relation with

those providers in advance. Transferring such a model would mean that a user could

use a VoIP service from a provider A to reach any location in Europe whereas he

would use a provider B to reach the USA. For such a model to function efficiently in

an all-IP environment, the service providers need to be able to establish trust relations

with their users and naturally be able to charge them. Identifying and authenticating a

user directly is in general a tedious task that is bugged by scalability and security

problems that have hindered until now the wide usage of public key infrastructures for

example. Therefore the common approach propagated in the all-IP environment is to

identify a home provider that has a contractual relation with the user and ask the home

provider to authenticate and authorize the user. Thereby the trust problem is reduced

to establishing trust relations between providers.

While in the current networking environment, a home provider of a user is

usually represented by a large telecom provider, in an all-IP environment, any

trustworthy entity such as an application provider, a banking entity or a credit-card

provider that is capable of authenticating the user and maintaining his usage profile

can act as a home provider. To provide a service to a visiting user some kind of

interaction between the foreign provider and the home provider is required. In this

paper we will be looking at two distinctive approaches for exchanging authentication,

authorization and accounting (AAA) information between foreign and home

providers, namely: SIP dependent and independent inter-domain AAA

communication. In the SIP dependent scenario, see Sec. 2, SIP is used as the

communication protocol between the interacting providers and is used for carrying

any information that needs to be exchanged between the providers. With the SIP

independent scenario, see Sec. 3, a special AAA protocol such as RADIUS 0 or

DIAMETER 0 is used between the domains for exchanging AAA related information.

Both approaches will be described in terms of message sequences that would be

exchanged and will be analyzed in terms of their efficiency, flexibility and security. In

Sec. 4 a general comparison between the two scenarios is presented.

1 General Overview of SIP

The most important SIP operation is that of inviting new participants to a call. To

achieve this functionality we can distinguish different SIP entities:

• Proxy: A proxy server receives a request and then forwards it towards the current

location of the callee -either directly to the callee or to another server that might

be better informed about the actual location of the callee.

• Redirect: A redirect server receives a request and informs the caller about the

next hop server. The caller then contacts the next hop server directly.

• User Agent: A logical entity in the terminal equipment that is responsible for

generating and terminating SIP requests.

• Registrar: To assist SIP entities in locating the requested communication

partners SIP supports a further server type called register server. The register

server is mainly thought to be a database containing locations as well as user

preferences as indicated by the user agents.

•

In SIP, a user is identified through a SIP URI in the form of user@domain. This

address can be resolved to a SIP proxy that is responsible for the user’s domain. To

identify the actual location of the user in terms of an IP address, the user needs to

inviting a user, the caller sends his invitation to the SIP proxy responsible for the

user’s domain, which checks in the registrar’s database the location of the user and

forwards the invitation to the callee. The callee can either accept or reject the

invitation. The session initiation is then finalized by having the caller acknowledging

the reception of the callee’s answer. During this message exchange, the caller and

callee exchange the addresses at which they would like to receive the media and what

kind of media they can accept. After finishing the session establishment, the end

systems can exchange data directly without the involvement of the SIP proxy.

For authenticating a user SIP uses the digest authentication mechanisms, which is

based on a challenge/reply approach. In our discussion we will be assuming that a

roaming user is supposed to contact a local SIP proxy in the foreign network. This is

especially needed when the local proxies offer some kind of local services such as

emergency calls or are used to enforce local policies, as is the case with 3GPP IMS

networks 0.

2 SIP Dependent Inter-Domain AAA Communication

In this scenario the SIP signalling messages are used for initiating and controlling the

communication sessions as well as negotiating AAA aspects among the providers.

Here we assume that both the caller and callee are present in foreign networks. The

approach depicted in Figure 1 is very close to the one used in the IP multimedia

system (IMS) of 3GPP0, for more information.

In our presentation we assume that the INVITE message always includes the SDP

part, which could also have been carried in a following message. We also assume

that the session establishment consists of the exchange of an INVITE, 200 OK and

ACK messages. In the 3GPP model in which QoS reservation is integrated into the

session establishment, a row of other messages needs to be exchanged as well, for

instance 183 Session Progress, PRACK followed by 200 OK for acknowledging the

reception of the 183 message, an UPDATE message followed by 200 OK indicating

the status of the QoS reservation and only then the final 200 OK and ACK for the

session establishment0. Note however, that those further messages are not involved

in the authorization procedure and hence their inclusion would only complicate the

scenario without added benefit.

UAc

cFP

cAAAf

cHP

cAAAh

sHP

sAAAh

sFP

sAAAf

UAs

1 INV

2 Auth.

3 INV

6 Auth.

5 INV

7 INV

4 Auth.

8 Auth.

9 INV

10) 200 OK

11) Auth.

12) 200 OK

13) 200 OK

14) 200 OK

15) Auth.

16) 200 OK

17) ACK

Figure 1 SIP dependent inter-domain AAA exchange

Abbreviations:

• UAc: user agent client (caller)

• cFP SIP proxy in the foreign domain in which the client is

present

• cAAAf: AAA server in the foreign domain in which the client is

present

• cHP: home proxy of the client

• cAAAh: AAA server in the home domain of the client

• sHP: Home proxy of the user agent server

• sAAAh: AAA server in the home domain of the server

• sFP: SIP proxy in the foreign domain in which the server is

present

• sAAAf: AAA server in the foreign domain in which the server is

present

• UAs: user agent server (callee)

The authorization is realized in this scenario in the following steps:

1. The caller issues an INVITE towards the local proxy in the foreign domain

(cFP). The address of this proxy is configured while assigning the host with an

IP address using DHCP for example 0. The INVITE message indicates the

characteristics of the call in the SDP part (which codecs and media type and

whether QoS reservation is required)

2. The cFP consults with a local AAA server to check local policies regarding

initiating calls and whether this user is eligible for initiating calls with the given

parameters (is the required bandwidth is reasonable for instance). If not, the call

is rejected or the session description is modified by deleting codecs or media

styles the user is not allowed to use. To make sure that all subsequent requests

pass this proxy a Record-Route entry can be added to the SIP message.

3. After receiving a positive answer the INVITE is forwarded to the home proxy of

the caller. To make sure that all subsequent requests pass this proxy a Record-

Route entry can be added to the SIP message. The home proxy of the user can

be discovered in one of two ways:

• Based on the domain name part of the FROM header in the INVITE

• In 3GPP, see 0, the route is decided during an initial registration phase in

which the domain part of the Request-URI is used to identify a proxy

(ICSCF) in the home domain. At the home domain, a serving proxy

(SCSCF) is identified and added to a header called the P-Service-Route 0

header, which is then mirrored in the reply. The routes included in the P-

Service-Route header are then used to guide the proxies of where to direct

the SIP messages.

4. The home proxy checks with its AAA server whether the user is eligible for

initiating a session with the characteristics indicated in the INVITE. If not the

call is rejected or the session description is modified by deleting codes or media

styles the user is not allowed to use.

5. The INVITE is forwarded to the home proxy of the callee.

6. The home proxy of the callee might check with its local AAA server (sAAAh)

whether the user is allowed to receive calls with the indicated characteristics. If

not the call is rejected or the session description is modified by deleting codecs

or media styles the user is not allowed to use. The home proxy also checks with

its registration database the current location of the user and adds a Record-Route

entry as well.

7. The message is forwarded to the SIP proxy in the foreign domain in which the

user is currently present. This proxy can be discovered in the following manner:

• The user might indicate in his REGISTER message the domain in which

he is currently in.

• With the 3GPP approach a special header is added to the REGISTER

message, the PATH header 0, in which, traversed proxies during the

registration step indicate whether they should be contacted for incoming

requests to the user.

8. The sFP might need to check with the local AAA server (sAAAf) to check local

policies and whether the user is eligible for receiving calls. If not the call is

rejected or the session description is modified by deleting codecs or media

styles the user is not allowed to use.

9. The INVITE is forwarded to the callee.

10. The callee replies with a 200 OK including its media and QoS preferences to the

sFP

11. The sFP has now the entire session data (IP addresses and port numbers as well

as exchanged media for both communicating end systems) and can authorize the

session. That is the AAA server creates an entry for this session describing the

involved end systems and the compression style, bandwidth and media the

communicating end systems are allowed to use.

12. Based on the VIA list in the SIP header the 200 OK is forwarded to the sHP

13. Based on the VIA list in the SIP header the 200 OK is forwarded to the cHP

14. Based on the VIA list in the SIP header the 200 OK is forwarded to the cFP

15. The cFP can now authorize the session based on the complete knowledge of the

communication parameters (IP addresses and port numbers as well as chosen

media). That is the AAA server creates an entry for this session describing the

involved end systems and the compression style, bandwidth and media the

communicating end systems are allowed to use.

16. 200 OK message is forwarded to the caller

17. The session is established by sending an ACK message to the callee. The ACK

will traverse proxies traversed by the INVITE due to the Record-Route entries

added during the invitation part.

From the description of this authorization interaction it is clear that the inter-domain

exchange of AAA information is implicit in nature. That is, the foreign provider

considers a non-negative reply that has passed the home provider as an indication that

the user is allowed to establish a session in the form indicated in the signalling

messages. On the other side, the home provider considers a request originating from a

foreign provider as authorized by that provider.

2.1 Evaluation of the SIP Dependent Inter-Domain AAA

Communication

• Complexity: Each provider can use his own proprietary AAA servers. All inter-

domain communication is then realized based on the standardized SIP messages.

That is, no separate inter-domain AAA communication is required. This reduces the

complexity of the provider’s infrastructure. However, this increases the complexity

of the SIP signalling itself. Authentication and authorization information are of

utmost importance as they might reveal information about the monetary status of a

user and his allowed services. Any tampering of that information might allow an

interceptor to establish communication sessions on the costs of other users. Due to

this the SIP messages need to be specially protected to prevent such misuse, which

increases the complexity of using SIP.

• Performance: Application signalling needs always to traverse the home provider

even if it would have been possible to signal some session directly to the called

party without going through the home provider’s network first. This would in

general mean longer round trip delays. Further, updates to the used resources, i.e.,

accounting information, must be also sent to the home provider. This can be

achieved either by using a special protocol between the foreign and home network

or by carrying the information in the SIP messages. Using a special protocol would

diminish the advantage of having only one protocol to worry about, i.e., SIP. On the

other hand carrying accounting information with SIP, means that SIP message are

used to carry information that is only of interest to certain proxies. In this scenario,

the end systems could generate SIP requests (the INFO message would be a

candidate), the foreign proxy would retrieve accounting data from the local AAA

server and add the information to the INFO and forward it to the home proxy of the

user. The home proxy retrieves the accounting data, deletes them from the message

and informs its local AAA server about the received accounting data. This naturally

raises the question of how the providers would act if the end systems did not

generate these INFO messages. On the one hand this increases the complexity of

SIP proxies and reduces the performance as it increases the size of the SIP

messages. Another option is for the home provider to subscribe to the accounting

state of the foreign provider. With this option, the foreign provider would generate

an event describing the current accounting state of the user after each change of this

state. This incurs further message exchange to establish the subscription, updates it

and deletes it at the end of the communication session in addition to the

notifications themselves. Note that this approach is already being standardized for

the usage of SIP in 3GPP 0with the goal of providing home networks the possibility

of terminating sessions of their subscribers currently located in a foreign network.

• Convenience: Convenience here indicates the convenience to the home provider.

With this scenario, the home providers can check the eligibility of the user’s

requests during each action and directly take actions by rejecting a request for

example or changing the session description. This gives the home provider a better

view of and control on the user’s actions.

• Security: For the foreign network to accept the AAA data generated by the home

network and vice-versa some kind of security association between the two networks

needs to be established. This might still need some integration of the providers with

a PKI infrastructure or some security broker to dynamically establish such an

association, especially when dealing with a large number of providers.

• Flexibility: With this scenario, an authorative provider, i.e., a provider that can

authenticate the user and which maintains the user’s profile and authorization

information, must be reachable through SIP. That is, this authorative provider must

have a SIP infrastructure consisting of proxies and registrars beside the AAA

servers and the users would have the name of the provider as part of their SIP

address. This increases the hurdles for an independent provider such as a banking

entity to act as an authorative provider.

3 SIP Independent Inter-Domain AAA Communication

UAc

cFP

cAAAf cHP

cAAAh

sHP sAAAh

sFP

sAAAf

UAs

1) INV

2) Auth.

5) INV

6) Auth.

7) INV

3) Auth.

8) Auth.

11) INV

12) 200 OK

13) 200 OK

14) 200 OK

16) ACK

15) 200 OK

4) Auth.

9) Auth.

10) Auth.

9) Auth.

3) Auth.

Figure 2 SIP independent inter-domain AAA exchange with SIP dependent intra-

domain authorization

In this scenario the AAA data is exchanged using special protocols between AAA

entities. This approach utilizes the AAA infrastructure defined by the IETF, see 0 and

0 and is also deployed by the Mobile-IP protocol, see 0. That is during the application

signalling phase, an entity in the foreign network would ask the home AAA server of

the user through a dedicated AAA protocol for authentication and authorization data

of the user.

As depicted in Figure 2 the message flow is rather different than in the SIP

dependent scenario:

1. The session starts with the user issuing an INVITE message towards the local

proxy (cFP).

2. The cFP asks its local AAA server whether the user is allowed to continue the

call. Note that this step is only relevant if the foreign provider wants to charge the

user for some service or needs to authenticate him.

3. In this step the local AAA server consults another AAA server to authorize the

call. Here we can distinguish two cases:

a. Call paid by the caller: The local AAA server contacts the home AAA

server of the caller (cAAAh) to authenticate the user and authorize the call.

b. Call paid by callee: The local AAA server contacts the home AAA server of

the callee (sAAAh) to authorize the call.

This choice can be implemented in the form of a policy entry driven for example

by the identity of the caller and/or callee. Further in some cases both steps might

be needed. This is the case, when the foreign network wants to authenticate the

caller and still charge the callee for the call. Note that the cAAAh and sAAAh do

not necessarily need to have a relation with the home SIP providers (cHP and

sHP). Actually any entity, which is reachable over the used AAA protocol and is

capable of authenticating and authorizing the user and can be trusted by the

asking provider, can take the role of the AAAh server. However, SIP messages

usually only carry the SIP identity of the caller and callee in the form of the

FROM, To and R-URI header. Therefore, to instruct the cAAAf server to contact

a special AAA server a new SIP header needs to be added to the SIP messages

indicating the name of this AAA server. Thereby the cAAAf would contact the

AAA server indicated in the SIP messages and ask for authentication and

authorization information of the user. The user might be represented with his SIP

name (FROM header) or yet another entry to be added to the SIP messages.

4. The result of the inter-domain AAA exchange as well as the local AAA actions is

sent to the proxy (cFP).

5. The INVITE is forwarded to the home proxy of the callee.

6. The home proxy of the callee (sHP) checks with its local AAA server whether the

callee is allowed to receive calls with the signalled content. Note that this step

might be skipped if the sAAAh was already contacted in step 3.

7. The sHP checks in its registration database the current location of the user and

forwards the INVITE either directly to that location or to the foreign proxy

serving the current domain of the user (sFP).

8. The sFP checks with its local AAA server (sAAAf) whether the callee is eligible

for receiving calls with the parameters signalled in the INVITE message.

9. In case the incoming call incurs certain costs in the foreign network in which the

callee is currently located the local AAA server (sAAAf) needs to contact some

other AAA server to authorize the call. Depending on who is paying for the call

the sAAAf can contact one of three possible AAA servers:

a. Call paid by caller: In this case the sAAAf would contact the cAAAh and

check the eligibility of the caller to make such a call.

b. Call paid by foreign provider: In this model, the caller would pay the

foreign network of the UAs indirectly. In this case the sAAAf would contact

the cAAAf to check whether that foreign provider of the UAc is willing to

pay for the call that originated from its domain. The foreign provider of the

caller would then add the costs for the resources in the foreign network of

the UAs to the costs incurred in its own network to the bill of the caller.

c. Calls paid by callee: In this case the sAAAf contacts the AAA server of the

callee to check the eligibility of the callee to receive this call.

The choice of which AAA server to contact can be made twofold

• Local policy: Based on some local policies such as all calls coming to

foreign users are to be charged by those users or that based on the identity of

the users a certain AAA server is to be contacted.

• Authorization tokens: An authorization token can be used to indicate that

the call was authorized by a AAA server and that this AAA server should be

contacted for any further questions with regard to the eligibility of this call.

Thereby, such a token might include some information characterizing the

call such as the call-ID and FROM and TO headers signed by the public key

of the authorizing AAA server. Further, the token needs to contain

information readable by any proxy indicating the name of the authorizing

proxy so as to be contacted if needed. Thereby, in step 3 the cAAAf, cAAAh

or the sAAAh might generate such a token that would then be handed to the

SIP proxy, which would include it in the forwarded SIP INVITE. The proxy

needing to authorize a call would check this token, contact the AAA server

indicated in it and send it the session information encrypted in the token as

well as the list of resources requested by the call. The contacted AAA server

would then reply on whether the user is allowed to utilize those resources,

see 0 for a variation of this approach.

10. The final authorization decision is now made based on the local policy of the

sAAAh as well as the exchanged AAA information with another AAA server as

described in step 9.

11. The INVITE is forwarded to the user agent server.

12. The UAs answers with an OK 200 sent to the sFP.

13. The sFP forwards the 200 OK to the sHP.

14. The sHP forwards the 200 OK to the cFP.

15. The cFP forwards the 200 OK to the user agent client.

16. The client finishes the session establishment by sending an ACK message.

Unless the home proxy of the callee (sHP) wants to be on the path of all future

requests by adding a Record-Route entry in the first INVITE message, requests can

now be exchanged directly between the foreign proxies, i.e., form cFP to sFP.

3.1 Evaluation of SIP Independent Inter-Domain AAA

Communication

• Complexity: While different application level protocols might provide varying

degrees of secure communication a well-designed AAA protocol must have these

features. This might allow for simpler application protocols that trust that the

providers are using a secure AAA protocol for exchanging user data. That is, in this

case, the security requirements on the SIP messages can be reduced. However, the

providers need to support yet another protocol and standardized components.

• Performance: Only the AAA data need to be exchanged between the foreign and

home network whereas the application signalling data can be exchanged directly

between the caller and callee. This reduces the load on the home provider’s proxies

and reduces the signalling delay. Accounting data can also be exchanged over the

AAA infrastructure without having the need for a separate protocol or the need for

integrating the data with the application signalling protocols. In case the SIP home

providers need to be on the signalling path in order to provide the users with some

services, the SIP independent AAA exchange would be wasteful as inter-domain

communication between the home and foreign providers would be triggered twice:

once for the SIP signalling and once for the AAA exchange.

• Convenience: For the home provider to be able to control each action of the users

the SIP signalling messages need to traverse the home provider which would

diminish the performance benefits that could be obtained by having the SIP

messages exchanged directly between the communicating end systems. Another

option would be to use the AAA infrastructure to inform the home provider about

the actions of the user. This would, however, increase the load on the AAA

infrastructure.

• Flexibility: Defining the business relations between the different providers might

be simplified. As described in Figure 2 the specification of who is to pay for which

call can be signalled during the call establishment without requiring pre-defined

and static roaming agreements. Also, the definition of a home provider is broadened

here. Any entity providing a AAA server can act as an authorative home provider

without necessarily having to offer a SIP infrastructure.

4 General Performance Comparison between SIP Dependant and

Independent Inter-Domain AAA Communication

In terms of delay if we assumed that the round trip delay between two components

inside the same domain can be set to 0.5 T unit, with T as some amount of time, and

the round trip delay between two components in different domains is set to T then the

SIP independent scenario described in Figure 2 would consume 7.5 T units to finish

the session establishment. The SIP dependent scenario requires between 6 and 7 T

units depending on whether all the AAA servers possibly involved are contacted and

whether the cFP is contacted before forwarding the INVITE.

In general, we can also add that both schemes show a considerable level of

complexity. Thereby, when actually introducing the one or the other, the

implementers need to consider the exact communication scenario and base their

choice of which approach to use on that scenario.

5 Summary

In this paper we described two different approaches for authenticating and authorizing

roaming users wanting to use SIP-based services. In the description of the scenarios

we used simplified signalling scenarios to reduce the complexity of the description.

On the one hand, this allowed us to better describe the scenarios in an understandable

manner and provided us with a qualitative impression of the advantages and

disadvantages of each approach. However, on the other hand this prevented us from

achieving a completely accurate comparison in terms of number of used messages and

message sizes. This can only be realized after a detailed definition of the

communication scenario and AAA protocols and infrastructure used. Nevertheless,

this brief overview already gives a clear picture of the pros and cons of each

approach. Probably the most valuable result obtained here is that all scenarios have

their pros and cons and which one to use can only be decided based on the usage

scenario, the supported services and the current infrastructure of the provider.

References

1. J. Rosenberg, H. Schulzrinne, G. Camarillo, A. Johnston, J. Peterson, R. Spark, M. Handley,

E. Schooler, “Session Initiation Protocol”, RFC3261

2. 3GPP Technical Specification 3GPP TS 33.102 V3.6.0: "Technical Specification Group

Services and System Aspects; 3G Security; Security Architecture (Release 1999)", 3rd

Generation Partnership Project, November 2000

3. Pat R. Calhoun, et al.; ”Diameter Base Protocol”, RFC 3358, September 2003

4. Rigney, C., Willens, S., Rubens, A. and W. Simpson, "Remote Authentication Dial In User

Service (RADIUS)", RFC 2865, June 2000.

5. H. Schulzrinne, “Dynamic Host Configuration Protocol (DHCP-for-IPv4) Option for

Session Initiation Protocol (SIP) Servers” RFC 3361, August 2002

6. D. Willis, B. Hoeneisen, “Session Initiation Protocol (SIP) Extension Header Field for

Service Route Discovery During Registration “, RFC 3608, October 2003

7. 3GPP Technical Specification 3GPP TS 24.228 " Technical Specification Group Core

Network; Signalling flows for the IP multimedia call control based on SIP and SDP", 3GPP,

2003

8. J. Vollbrecht, P. Calhoun, S. Farrell, L. Gommans, G. Gross, B. de Bruijn, C. de Laat, M.

Holdrege, D. Spence: AAA Authorization Framework; IETF, RFC 2904, August 2000.

9. J. Vollbrecht, P. Calhoun, S. Farrell, L. Gommans, G. Gross, B. de Bruijn, C. de Laat, M.

Holdrege, D. Spence: AAA Authorization Application Examples; IETF, RFC 2905, August

2000.

10. S. Glass, T. Miller, S. Jacobs, C. Perkins, “Mobile IP Authentication, Authorization, and

Accounting Requirements”, IETF, RFC 2977, October 2000

11. W. Marshall, F. Andreasen, D. Evans, “Private Session Initiation Protocol (SIP) Extensions

for Media Authorization”, RFC 3312, January 2003

12. Sinnreich, Rawlins, Gross, Thomas, "QoS and AAA Usage with SIP based IP

communication", Internet Draft, Internet Engineering Task Force, October 2001

13. Camarillo, et al., “Integration of Resource Management and SIP”, RFC 3312, October 2002
