ADDING SPATIAL COMPONENTS TO SCIENTIFIC DATA

WAREHOUSES

Khaled K. Deeb, Ph.D.

Department of Information Technology, Barry University, 11415 NE 2nd Ave, Miami Shores Florida, 33161

Susan Molina, M.S.

Southeast Fisheries Science Center, National Oceanic and Atmospheric Administration Fisheries

75 Virginia Beach Drive, Miami, Florida 33149

Pam Luckett, Ph.D.

Department of Information Technology, Barry University, 11415 NE 2nd Ave, Miami Shores Florida, 33161

Keywords: Warehouse, Data retrieval, Spatial d

ata components

Abstract: Data warehousing architecture should generally protect the confidentiality of data before it can be published,

provide sufficient granularity to enable scientists to variously manipulate data, support robust metadata

services, and define standardized spatial components. Data can then be transformed into information that

would make them readily available in a common format that is easily accessible, fast, and bridges the

islands of dispersed information. The benefits of the warehouse can be further enhanced by adding a spatial

component so that the data can be brought to life, overlapping layers of information in a format that is easily

grasped by management, enabling them to tease out trends in their areas of expertise.

1 INTRODUCTION

Data are meaningless until they are transformed

into information. Over the years many

organizations have collected millions of rows of

data that, when properly analyzed, translate into

useful and profitable information that will assist in

deciding the course of future market strategies, the

creation of new products, or the retooling of

existing production lines to meet consumer

demands. In the scientific community, these data

are often used to set new policies that can later be

made into laws to protect the environment,

promote advances in the medical field, or find new

natural resources. Since these vast numbers of data

can take many hours to process, the databases that

house them must meet certain requirements that

are often at odds with traditional online

transaction processing databases (i.e., OLTP)

which require real time access and validation.

Hence the birth of the data warehouse, a database

that provides mechanisms for synchronizing and

updating information obtained from OLTP

databases and other external sources, as well as

supporting the performance requirements to

process and load large volumes of data. The

benefits of the warehouse can be further enhanced

by adding a spatial component so that the data can

be brought to life, overlapping layers of

information in a format that is easily grasped by

management, enabling them to tease out trends in

their areas of expertise.

2 WHAT IS SO SPECIAL ABOUT

WAREHOUSE?

Normalized data models evolved to solve the needs

of online transactional processing (OLTP) systems

that focused on speed of data entry, ease of editing,

protection of data integrity by reducing

redundancy, and immediate point of entry

validation. This model served to solve the

problems of the batch processing environment, in

629

K. Deeb K., Molina S. and Luckett P. (2004).

ADDING SPATIAL COMPONENTS TO SCIENTIFIC DATA WAREHOUSES.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 629-633

DOI: 10.5220/0002668406290633

 SciTePress

which data were updated through batches of

records that included codes to add, change, or

delete from the master flat file. Whenever coding

changes were required, the IT group, then called

"data management," had to be methodical enough

to make sure all occurrences of the offending

code where replaced with the new value.

Even though the old flat files were difficult to

quality assure, they were very easy for most users

to query. Reports generally represented little more

than sums across records of data with some

additional programming to convert cryptic codes

into their more legible legends. Conversely, the

OLTP model is perceived as a nightmare for most

users who must now write multi table joins across

seven or eight tables. Suddenly, the old flat file

legacy systems seemed much more desirable. To

compound matters, while information technology

groups spent their resources designing and

deploying elegant data models touting the ease of

use of SQL (i.e., Structured Query Language), the

user community was left unable to understand the

complexities of SQL when confronted with highly

normalized designs, and represented to their own

management that their data was no longer

accessible.

Clearly, there is a need for some compromise

between the elegance and efficiency of the OLTP

systems, and the needs of the end users to analyze

the data that cost so many dollars to capture and

ingest. The solution to this dilemma is the data

warehouse. Although it raises some brows with

apprehension, the data warehouse can be created

using the same RDBMS used to house the OLTP

database. In fact, a data warehouse is nothing more

than a database that has been optimized for

retrieval. The main concern of its architects is the

delivery of data in a consistent, easy to access

format. The emphasis of the design is speed of

retrieval.

3 FACTORS THAT MAKE A DATA

WAREHOUSE EFFICIENT

As mentioned earlier, a data warehouse must

provide good performance, manage large amounts

of data, and provide quick ways in which to load

large volumes of OLTP data. To support these

operations, the manufacturers of data

warehousing software have created the following

strategies:

Range, Hash, and Composite partitioning:

Partitioning involves separating objects into pieces

so that they can be managed more easily.

Although to the database the object is logically the

same, each piece is physically stored separately.

Range partitioning is useful when separating data

in ranges, such as by year, or by state. On the

other hand, when the data cannot be separated into

discrete meaningful groups, the data can be

separated using a hashing algorithm that ensures

that the data will be distributed evenly. The

combination of the two partitioning methodologies

is called composite partitioning and it uses range

partitioning first, while dividing the results using

hash partitioning to create sub-partitions (Scherer,

2000, p.145). With any of these techniques, the

database designer must analyze both the kinds of

data that will be stored in the warehouse, as well

as the ways in which the data will be used.

Partitioning data based on year may not be

effective if the organization typically analyzes data

aggregated by state, crossing over multiple years.

Transportable tablespaces: Tablespaces are

logical units that hold database objects. Each

tablespace may be composed of one or many

physical data files. Since data warehouses are

used to manage large numbers of data, it may be

necessary to move these tablespaces to supply

data to a different database or data mart, archive

data, or to share data with other databases.

Because the tablespaces are based on physical

files, there are certain limitations to this

capability. These limitations include the

requirement that tablespaces be transported only

between databases on the same platform, the

platform's block size must be the same, and they

must use the same character set (Scherer, 2000,

p.162).

The star schema: Data warehouses are

frequently designed using a dimensional data

model called the star schema. In this type of

design, there is a central table called a fact table

that is related to several look-up tables called

dimensions (Silverston, 1997). Fact tables tend to

be very large with millions of records and

gigabytes to terabytes of data and contain

quantitative data. On the other hand, dimension

tables tend to be much smaller and contain

descriptive data. Both must have a primary key,

which for fact tables are usually composites of the

foreign keys to the dimension tables. To access

tables in this formation, a star query is used, which

in turn uses what is referred to as a start join

(Scherer, 2000, p. 164). Most RDBMS (i.e.,

Relational Database Management System) allow

developers to use a mechanism called "cost-based

optimizer" to allow the computer to optimize the

query performance. This is done by regularly

compiling statistics on the data and then specifying

the "star" hint, which if possible, will cause the

database engine to position the largest table, or fact

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

630

table, last in the query to reduce the number of

rows read with each join (Scherer, 2000 pp. 164-

165).

Summary Management and Materialized

views: Two important problems faced by data

warehousing designers are the aggregation of data

across multiple dimensions to hide the complexity

of queries, and ensuring that the data are kept up to

date when they must be available at all times.

Through the use of summary management,

performance can be greatly improved by keeping

joined and summarized data in objects called

materialized views (Scherer, 2000, p.166). In

general, a view is a different way in which to look

at data. It can be as simple as a single table in

which some columns have been renamed or

dropped, or as complex as the combination of

multiple tables and the creation of summaries. The

problem with views is that when they are

accessed, the query that they represent must be

performed and, depending on its complexity, they

can take a long time to execute. On the other hand,

materialized views physically store data in this

joined and aggregated format, so that when a query

is performed, the execution time is minimized to

the amount of data stored in the materialized view.

With sophisticated RDBMS tools, after statistics

have been gathered, the database can recommend

which views should be materialized and will even

re-write queries if there are materialized views to

satisfy a query. The summary management

component provides methods to update and

propagate the data that make up the materialized

view whenever the base tables are updated

(Scherer, 2000, p.166).

Before defining the architecture of the geospatial

data warehouse it is important for analysts to

locate existing stores of data. Especially in large

organization, islands of information tend to form

and similar data are stored in different formats

making the ingestion of data a laborious and time

consuming task that detracts from the business of

science. Defining the scope of a design effort is

critical, since it will lay the ground work for the

ultimate design of the warehouse.

4 WHAT IS SO SPATIAL?

The scientific community is becoming increasingly

dependent on Geographic Information Systems

(GIS). According to J. Michael Fay, GIS experts

hold the "key to the future," because by

understanding the landscape they can effect

positive change on the environment (qtd. In Pratt,

2001). Furthermore, Jack Dangemond, President of

ESRI, states that "[t]he application of GIS is limited

only by the imagination of those who use it (atd in

GIS, 2002). In a nutshell, GIS involves applying

layers of information (What is, 2002), whether

information about a location's temperature, depth,

species of fish caught, number of fishing vessels,

any information that can be combined to enable

analysts to easily discern patterns in the data. The

presentation Geography Matters (2002) explains

that GIS is not just about maps, but it is the special

relationship between data, location information,

and the people that manage it. This makes the

incorporation of spatial elements into the enterprise

data warehouse not just a desirable but a necessary

component.

Although GIS has been available for many

years, acquiring spatial data layers has not always

been simple. Furthermore, the existing GIS

analytical tools required levels of expertise that

could not be mastered easily by casual users

requiring a simple geographical representation of

their data. By making spatial shape files available

at the enterprise level, scientists will be able to

perform comparative studies and visually represent

"what-if 'scenarios without expending inordinate

amounts of time in the process of ingesting data.

Spatially enabling the warehouse is an ideal

solution to provide GIS services to the enterprise.

The many standardized layers such as bathymetry

and land contours, are generally static and can be

loaded one time and remain accessible to all data

warehouse customers. This process will result in a

great cost savings since currently, since scientists

acquiring the data on their own, are loading it into

their own databases, and are neither sharing the

costs nor the expertise in solving the problem of

data ingestion.

Unfortunately, according to Daniel R. Dolk in

his paper Introduction to Modeling Technology and

Intelligent Systems Track, GIS has been largely

neglected by IT management and therefore has

not benefited from MIS research (Dolk, 1999).

Bringing spatial data into the data warehouse

represents a unique opportunity for providing

benefits to the users by enabling them to share

shape files across the enterprise, but they will also

benefit from the extensive expertise of their IT

department that can leverage existing investments

in data acquisition while optimizing the data

warehouse.

Large database vendors such as Oracle with its

9i Enterprise RDMS offer a spatial option that

enables the storage of spatially enabled data, that is,

data that can be interpreted by native SQL and GIS

tools. Line geometry can be stored in spatial data

object data types that turn the spatial object into a

regular field that can be queried using native SQL.

ADDING SPATIAL COMPONENTS TO SCIENTIFIC DATA WAREHOUSES

631

For more complex shape files such as raster data,

there is still no support. However, these shape files

can still be stored in the data warehouse using

binary data types, or, in specialized containers such

as Oracle Intermedia, that allow third party

products such as E-Spatial to access the data

directly from the database. Data stored in binary

data format can be easily read by such powerful

GIS tools as those produced by the ESRI.

The reason it is important to keep data in a

virtual central location (i.e., the warehouse) is that

the problem of acquisition is solved a priori by the

IT staff in conjunction with the data managers, and

last minute research problems the week before

presentations at symposia largely go away. By

bringing GIS to the warehouse the entire enterprise

benefits.

5 DESIGNING THE ETL

ETL or Extract, Transform, and Load procedures

are the three steps necessary to populate the data

warehouse. Although difficult to set up initially,

once the methods are established, the business of

synchronizing the transactional database with the

warehouse occurs automatically, making the

process transparent. Unfortunately,

synchronization is slightly more complicated for

the scientific community than it is in the business

world. The most significant difference is that the

sources of scientific data are frequently in the form

of data submitted by the owners and is not

immediately validated. Depending on the volume

of data and the workload of the data management

team, it may take from several weeks to several

months to make the data ready for the warehouse.

Even after the initial constraints are met,

specialized analysts can identify outliers that must

be corrected in the data warehouse. This presents a

problem for ETL, because now the OLTP data

needs to be compared with the warehoused data to

ensure that the most current version is now

available before it is loaded. Therefore, although

older data may be archived in the warehouse, it

needs to be compared periodically to ensure

accuracy. Jaideep Srivastava and Ping-Yao Chen,

authors of Warehouse Creation - A Potential

Roadblock, consider the issue of data loading so

important that they have named it a road-block

(1999). They have found that generally custom

tools must be developed by specialized consultants

to handle the ETL issue. It is important to note,

however, that once the procedures are put in place,

the process of synchronizing the warehouse with

the OLTP database occurs automatically.

6 SERVING THE DATA:

RETRIEVAL ALTERNATIVES

Using a data warehousing tool that is open and

platform independent, affords architects and

analysts the capability of opening the data to

different tools. Once the data are warehoused,

Online Analytical Processing tools can be used to

access the data. It is especially important to note

that a range of users can be serviced. From the less

computer-savvy congressperson who needs broad

summarizations to support the passing of

legislation, to the expert GIS user who needs

granular data to a tenth of a degree, all can benefit

from the data stored in the warehouse.

One of the strengths of the data warehouse is its

ability to empower end users to perform their own

analysis. Historically, users were dependent on the

information technology (IT) team to produce

inflexible reports that sometimes took months to

produce. If an analyst wanted to pivot the report

(i.e., turn the report on its side so that the rows in

the report become column headings), drill down to

the records that contributed to summary data, or

simply aggregate data in a different way, another

request-for-service document needed to be written,

approved, and then submitted to the IT queue until

resources became available. On-Line Analytical

Processing tools enable users to access

multidimensional data on their own, freeing IT

resources for other more vital tasks.

Unfortunately, many data warehousing ventures

fail because they lose focus on their ultimate goal,

which is to serve data to the user community. Joe

Kopetsky and Sally Ting of Arcplan Inc. identified

three different success factors that will ultimately

result in user buy-in:

ability, can the stakeholders

use the system;

willingness, are the users willing to

use the system, and

knowledge, are the users

familiar with how the system works (Kopentsky,

2002). Selecting an OLAP tool that meets these

goals and makes the users feel confident that they

can get to the data they want, the way the want it,

will go a long way to ensuring customer

satisfaction.

Serving GIS data poses its own challenges, and

these must be met by giving access to the

warehoused data at many different levels. There

must be simple tools that will enable the entry of

natural language queries so that geographic

representation of data can be made to management

without many hours of labor, while at the same

time preserving the expert's ability to use the tools

that they have become familiar with over the

years.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

632

7 CONCLUSION

Data warehousing solves the problem of data

accessibility. Unconcerned with transactional

changes, the warehouse architects can concentrate

instead on providing a streamlined pipeline to data

that can be analyzed expertly. Scientists can

benefit from data captured by other scientists

without investing the time to locate and reformat

the data to make it homogeneous. The warehouse

architect does this for them. The traditional

relational model, while adequate in managing

online transaction processing, falls short when

large volumes of data need to be analyzed. To

improve accessibility, data warehouses have

specific storage and management requirements,

such as partitioning, transportable tablespaces, star

schema queries and joins, and summary

management. Spatial data layers can simply be

added to the mix to increase the level of service to

the data analysts. As a logical consequence of the

need to mine these huge volumes of data, On-Line

Analytical Processing tools have been developed to

facilitate decision support and obtain business

performance metrics. A spatially enabled data

warehouse will move cooperative data sharing to a

new level by allowing scientists and analysts to

manipulate the data for results, rather than as a

painful preliminary step to each new study.

REFERENCES

Dolk, D. (March, 1999), Introduction to Modeling

Technology and Intelligent Systems Track. Paper

Presented at the 32"

Hawaii International Conference

on System Sciences. Abstract retrieved March 11,

2003 from

http://computer.org/proceedings/hicss/0001

/00016/00016001.PDF.

ESR1, GIS & mapping software. Retrieved March 11, 2003

from http://w

ww.esri.com/

Geography Matters. Geographic Information Systems..

Retrieved March 11, 2003, from

http./Iwww.gis.com'whatisgis/whatisgis.pdf.

Kopetsky, J. and Ting, S. (2002), If you build it, will they

come? The Data Warehousing Institute. Retrieved

March 11,2003, from

http:/lwww.dw-

institute.comfresearch/display.asp?id=5446

Pratt, M (2001, October-December). Real hero gives

keynote address. .4rcUser. 4 (4),

Scherer, D., Gaynor, W., Valentinsen, A., & Cursetjee, X.

(2000). Oracle 81 Tips and Techniques (pp. 143-188),

Berkeley: Oracle Press/McGraw-Hill.

Silverston, L.,Inmon W.H., & Graziano,K. (1997). The

Data Model Resource Book. (pp. 269-270). New

York: Wiley Computer Publishing.

Srivastava, J. and Chen, P. (1999) Warehouse Creation- A

Potential Roadblock to Data Warehousing, Abstract

retrieved March 11, 2003 from

http://computer.org/TKDE/tkl999/kOll8abs.htm, 118-

126.

What is GIS? (2002). Retrieved March 11, 2002 from

http://

www.gis.com/whatisgis/index.html

ADDING SPATIAL COMPONENTS TO SCIENTIFIC DATA WAREHOUSES

633
