Fair Trading Protocol With Off-line Anonymous

Credit Card Payment

Weiliang Zhao

, Vijay Varadharajan

1,2

, and George Bryan

Center for Advanced Systems Engineering

University of Western Sydney,

Locked Bag 1797

Penrith South DC, NSW 1797, Australia

Department of Computing,

Macquarie University,

NSW 2109, Australia

Abstract. A fair trading protocol with off-line anonymous credit card payment

is proposed in this paper. The fair trading protocol provides an overall solution

for a trading process with off-line anonymous credit card payment. The fairness is

achieved for both the involved client and merchant. The client information about

credit card is anonymous in the protocol. The proposed protocol is based on the

general optimistic protocols for fair exchange with an off-line Trusted Third Party

(TTP). The ﬁnancial institution for credit card service can be off-line in the fair

trading protocol. The TTP and the ﬁnancial institution for the credit card service

are not involved in normal transactions and the running cost will be reduced.

1 Introduction

With the exploding growth of electronic commerce on the Internet, the issue of fairness

[1,2] is becoming increasingly more important. Fair exchange protocols have already

been broadly used for applications such as electronic transactions [3,4], electronic mails

[5,6], and contract signing [7]. The fairness is one of critical issues in on-line transac-

tions and related electronic payment systems. Many electronic payment systems have

been proposed for providing different levels of security to ﬁnancial transactions, such

as iKP [8], SET [9], NetBill[10] and NetCheque [11]. In a normal electronic commerce

transaction, there is always a payer and a payee to exchange money for goods or services

with each other. At least one ﬁnancial institution, normally a bank, should be present in

the payment system. The ﬁnancial institution will play the role of issuer for the payer

and the role of acquirer for the payee. An electronic payment system must enable an

honest payer to convince the payee of a legitimate payment and prevent a dishonest

payer from making other unsuitable behaviors. At the same time, some additional secu-

rity requirements may be addressed based on the nature of trading processes and trust

assumptions of the system. Payer, payee and the ﬁnancial institution have different in-

terests and the trust between two parties should be as little as possible. In electronic

commerce, the payment happens over an open network, such as the Internet, the issue

Zhao W., Varadharajan V. and Bryan G. (2004).

Fair Trading Protocol With Off-line Anonymous Credit Card Payment.

In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 186-195

DOI: 10.5220/0002673801860195

 SciTePress

2 Weiliang Zhao et al.

of fairness must be carefully addressed. There is no fairness for involved parties in the

existing popular payment protocols. One target of this paper is to address the fairness

issue in the credit card payment process. In the existing credit card protocols, the ﬁnan-

cial institution that provides the credit card service plays a role of on-line authority and

will be actively involved in a payment. To avoid the involvement of ﬁnancial institution

in normal transactions and reduce running costs, some credit card based schemes with

off-line ﬁnancial authority has been proposed [12]. Another target of this paper is to

avoid the on-line ﬁnancial institution for credit card service in the normal transactions.

In this paper, we propose a fair trading protocol with off-line anonymous credit card

payment. The protocol addresses the fairness and privacy of the trading process and its

associated payment. The credit card is anonymous and an on-line credit card service

from a ﬁnancial institution is not necessary during the processing of a payment. The

TTP and ﬁnancial institution for credit card can be both off-line, the proposed proto-

col has better availability and reliability and is more efﬁcient than other solutions with

more on-line components. The technique of proof of equivalence of discrete logarithm

to discrete log-logarithm [13] is the essential tool in the constructing of our fair trad-

ing protocol. In section 2, the electronic payment with off-line anonymous credit card

is discussed. In section 3, we propose a fair exchange protocol with off-line anony-

mous credit card based payment. Finally, section 4 concludes the paper with some ﬁnal

remarks.

2 Electronic Payment With Anonymous Off-line Credit Card

Credit card payment is currently the most popular of all on-line payment methods.

There are at least three parties involved in this kind of payments: Client, Merchant and

Bank. The client is the buyer or service user who will make the payment. The merchant

is the goods or service provider who will receive the payment. The bank is the ﬁnancial

institution that provides credit card service and guarantees the transfer of money value

from the client to the merchant. The bank acts as the issuer of credit cards to clients and

acquirer of payment records from merchants. For one payment, the issuer and acquirer

can be same or different, clearing between the issuer and the acquirer will be done

using existing ﬁnancial networks. There is an on-line ﬁnancial authority in the existing

electronic credit card protocols [8–11]. The authors in [12] have proposed a credit based

payment scheme in which the ﬁnancial institution is not necessary on-line. Merchant

can ensure the authenticity of the credit cards without the help of an on-line authority

organization. Firstly, the client applies for a digital credit card from the bank. After the

credit check, if the client is approved to have it, the digital credit card is delivered to the

client through a secure channel. The credit information of the client is anonymous with

the technique of no-interactive equality proof [16].

The digital credit card contains at least the following information:

– client’s ID

– h

= g

mod q, i =1, 2,...,l, where g

∈ Z

∗

are the common generators, x

contains the credit card number, PIN number, other conﬁdential information and

salt.

– credit amount A

187

Fair Trading Protocol With Off-line Anonymous Credit Card Payment 3

– expiry date E

The digital credit card token is of the form C = <C,h

, ···,h

,E,A >

skb

.It

has the signature of the bank. If a client sends his digital credit card to a merchant, the

merchant can know the credit amount, the expiry date and can check the signature of

the bank but can not know the credit card number and PIN number. The client must

prove to the merchant that he knows the secret (credit card number, PIN number and

other conﬁdential information in the credit card) without revealing the secret to the

merchant. Using the technology of equality proof of knowledge, the client chooses a

random number r, r ∈ Z

∗

to compute a

= g

mod p for all i =1, 2,...,l. The pair

{c, z} is calculated as:

c = H(g

||g

||···||g

||a

||···||a

||h

||···||h

z = cx + r mod p.

The client will send {c, z, p, g

,...,g

,...,a

,...,h

} to the merchant and the

merchant can use the following equation to check the validity of the digital credit card.

= h

mod p.

In any case, the merchant has the option to get conﬁrmation from the authority orga-

nization for higher level of assurance. The credit card is anonymous and the ﬁnancial

authority is normally off-line.

3 Fair Trading Protocol with Off-line Anonymous Credit Card

Payment

Based on the well-known optimistic protocol for fair exchange[14, 15, 17], we will pro-

pose a generic fair trading protocol with off-line anonymous credit card payment. The

proposed protocol is an overall solution with the off-line TTP and off-line ﬁnancial in-

stitution for credit card service. The credit information of the client is anonymous in the

protocol.

3.1 Notations

Here we give the general notations which will be used in the description of the fair

trading protocol.

(1) Parties:

– C: Client

– M: Merchant

– TTP: Trusted Third Party

– B: Bank (Financial Institute for Credit Authority)

(2) Public Key Cryptosystems:

188

4 Weiliang Zhao et al.

– PKX: Public key of user X.

– SKX: Private key of user X.

– P

enc

(PKX,m): Encryption of message m with public key PKX.

– P

dec

(SKX,c): Decryption of ciphertext c with private key SKX.

(3) Digital Signature Schemes:

– pkx: Verifying key of user X.

– skx: Signing key of user X.

– < m >

skx

: Creation of signature of m under signing key skx.

– S

veri

(pkx, < m >

skx

, m): Veriﬁcation of signature < m >

skx

on message m, true

for valid and false for invalid.

(4) Other items:

– t

: Timestamp generated by party X.

– H(m): Hash function on message m.

3.2 System Setup

There are four parties in our protocol, they are Client, Merchant, TTP and Bank. Client

has a pair of public and private keys: PKC and SKC, and a pair of signing and ver-

ifying keys: skc and pkc. Merchant has a pair of public and private keys: PKM and

SKM and a pair of signing and verifying keys: skm and pkm. TTP has a pair of public

and private keys: PKT and SKT. We will employ the technique of proof of equiva-

lence of discrete logarithm to discrete log-logarithm. The above key pairs must follow

some overall rule of the whole system. This means that these key pairs must be setup

based on the same set of algorithms and parameters. If necessary, the signature scheme

of TTP, public key cryptosystem of bank and signature scheme of bank can be deﬁned

independently. They need not follow the same set of algorithms and parameters.

At ﬁrst, we choose three primes to set up the system. The three primes are p, q

and q



, which are of the form p =2q +1and q =2q



+1. We will use ElGamal

cryptosystem for encryption and decryption and a DSA-like scheme for signature.

Public Key Cryptosystems q is the prime number for the ElGamal cryptosystem. Z

∗

is a intractable multiplicative group with order q − 1. G is a generator of Z

∗

. SKX

is the private key and PKX is the public key. PKX = G

SKX

mod q and SKX ∈

{1, 2,...,q− 2}. The ciphertext of m under PKX is:

cx = P

enc

(PKX,m)=(W, V )

where W = G

mod q and V = m(PKX)

mod q, w is randomly chosen from

{1, 2,...,q− 2}. The message after decryption is:

m = V · W

−SKX

mod q

189

Fair Trading Protocol With Off-line Anonymous Credit Card Payment 5

Digital Signature Scheme p is the prime number for the DSA-like digital signature

scheme. Z

∗

is a intractable multiplicative group with order p − 1. g is a generator of

∗

. skx is the signing key and pkx is the verifying key. pkx = g

skx

mod p and

skx ∈{1, 2,...,q− 2}. The signature of m under pkx is :

<m>

skx

=(r, s)

where r = g

mod p and s = k

−1

(h(m)+r · skx)mod q. k is randomly chosen from

{1, 2,...,q− 2} and h(...) is the hash function.

For veriﬁcation of signature, S

veri

(pkx, < m >

skx

, m) is to check

= g

h(m)

· (pkx)

mod p

Construction of Important Tokens In this section, we will give details of digital to-

kens used in our fair exchange protocol with credit card based payment.

(1) Credit Card

The token for credit card is of the form

C = <C,l,h

, ···,h

,E,A>

skb

The credit token contains the client’s identity C, the conﬁdence level l, the expiry date

E, maximum credit amount A and h

= g

mod p, where g

∈ Z

∗

are common genera-

tors for i =1, 2, ···,l, where x is the concatenation of PIN number, credit card number

and salt. The credit token is signed by the bank using its private key skb.

(2) Payment Slip

The data in the payment slip is

SlipData = C,M,O,$,tc, H(C,M,O,$,tc),

where M is ID of merchant, O is the order, $ is the amount of money and currency type

and t

is the timestamp generated by the client C.

The payment slip token has the form

Slip =<SlipData>

skc

The payment slip is signed by the client with private key skc.

(3) Encrypted Payment Slip

The encrypted payment slip token is

= P

enc

(PKT,Slip).

The client’s payment slip is encrypted under the TTP’s public key PKT. If necessary,

TTP can open it with its private key SKT.

(4) Certiﬁcate of Encrypted Payment Slip

Cert is the token to prove C

is a ciphertext of S without disclosing the signature.

190

6 Weiliang Zhao et al.

Here, we will give all the details of construction C

and C

Cert. p and q are the two

prime numbers used in our system. The client has a pair of signing key and verifying

key {skc, pkc}, g is a generator of Z

∗

and pkc = g

skc

mod p. The TTP has public key

and private key {PKT,SKT}, G is a generator of Z

∗

and PKT = G

SKT

mod q.

For encryption of message m, we have the following:

enc

(PKT,m)=(W, V ) mod q,

where W = G

and V = m(PKT)

, w ∈{1, 2, ···,q − 2} is a randomly chosen

number.

The signature scheme works as follows: Choose a random k ∈ Z

∗

, the signature

has the form

Slip =<SlipData>

skc

≡ (r, s)

where r = g

mod p and s = k

−1

(H(m)+r × skc) mod q and pkc = g

skc

mod p.

Slip is the payment slip.

Encrypting the above payment slip Slip with PKT,wehave,P

enc

(PKT,Slip)=

(W, V ). The encrypted payment slip with signature is then given as follows:

= {r, W, V },

where W = G

mod q, V = s(PKT)

mod q.

With transformation x = G, y = W

−1

mod q, z = PKT, X = r

mod p,

Y = g

H(S)

(pkc)

mod p and α = −w, choose w

∈{1, 2, ···,q− 2}, then

t(x

)=x

mod q, t(X

)=X

mod p

and

c = H

(x||y||z||X||Y ||t(x

)||t(X

)||···||t(x

)||t(X

))

c = c

···c

= w

− c

α mod q − 1

(R, c) is the certiﬁcate C

Cert for C

The process of veriﬁcation is to check,

c = H

((x||y||z||X||Y ||u

||U

||···||u

||U

)

where u

= x

mod q, and



mod pif c

3.3 Fair Trading Protocol

Based on the tokens deﬁned in the last subsection, our fair trading protocol is con-

structed. The fairness of the trading between a client and a merchant is guaranteed.

191

Fair Trading Protocol With Off-line Anonymous Credit Card Payment 7

Fair Trading Protocol

Merchant Client

1. <offer>

skm

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− →

2.P

encr

(P KM, SlipData),C

Cert

←−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −

3.P

encr

(P KC, <Goods>

skm

)

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− →

4.P

encr

(PKM, Slip)

←−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −

For the above protocol, if both the client and the merchant perform properly, the TTP

will not be involved. The details of the protocol are as follows:

1. In step one, the merchant sends his signed offer to the client. The offer should

contain the description of the Goods and related trading information, such as price,

valid date etc. The client checks the offer, and if client is not satisﬁed with the

offer, he can quit the protocol, and therefore it is fair for both parties.

2. In step two, the client sends the merchant his credit card C, order information O,

amount of money and currency type $ and time stamp t

, encrypted payment slip

and the certiﬁcate C

Cert. The encrypted payment slip C

is encrypted with

TTP’s public key. The merchant checks the validity of the above data, and espe-

cially, the credit information and encrypted payment slip.

(1) The merchant checks credit information with equality proof of knowledge (see

section 2).

(2) The merchant uses C

Cert to check C

is the ciphertext of the payment slip

Slip signed by the client (see section 3.2).

If the merchant ﬁnds anything wrong in the above veriﬁcation, he will quit the

protocol, and the protocol will be fair for both parties.

3. In step three, the merchant sends P

encr

(PKC,< Goods >

skm

) to the client. If

the Goods is consistent with the offer, the client will continue the protocol. If the

Goods is inconsistent with the offer, the client quits the protocol. If the merchant

believes that it is not fair, he needs to require TTP to run the resolve protocol.

4. In step four, the client sends P

encr

(PKM,Slip) to the merchant. If the merchant

can not get the payment, the merchant will ask TTP to run resolve protocol.

If the merchant can not get the payment, the merchant will ask TTP to run the following

resolve protocol:

192

8 Weiliang Zhao et al.

Merchant TTP Client

<offer>

skm

, SlipData, C

, <Goods>

skm

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−→

if unf air to merchant then con-

tinue else abort

encr

(PKM, Slip)

←−−−−−−−−−−−−−−−−−−−

encr

(P KC,<Goods>

skm

)

−−−−−−−−−−−−−−−−−−−→

In the completion of the resolve protocol, the merchant has the payment and the client

has the goods.

3.4 Properties of Fair Trading Protocol

Some general properties of cryptographic protocols such as integrity and conﬁdential-

ity are not included in this section, even our fair trading protocol have these properties

and can satisfy the related security requirements. Our discussions here only focus on

the properties we have emphasized in the design and construction of the fair trading

protocol. The fair trading protocol has perfect fairness and high efﬁciency and provides

good availability & reliability of the involved services. The sensitive information (credit

card) has untraceability & privacy in the fair trading protocol.

(1) Fairness

If both the merchant and the client behave according to the fair trading protocol, when

protocol has completed, client has received the goods and merchant has received the

payment. For the client, if something is wrong, he can quit the trading protocol after

step three and the whole protocol is fair. For the merchant, if something is wrong after

step three, he can bring offer, SlipData, C

, Goods to TTP. TTP will check the sta-

tus. If it is really unfair to merchant, TTP will send the Goods to the client and send the

Slip to the merchant. The protocol is fair against cheating attempts by either merchant

or client. The protocol is fair in case of system failures as well. The fair trading protocol

and the associate resolve protocol can guarantee the trading protocol to be fair in any

case.

(2) Efﬁciency

In normal case, the TTP is off-line and the credit card service from a ﬁnancial in-

stitution is off-line as well. The TTP is only involved when one party misbehaves or

system failure happens. The protocol is more efﬁcient than protocols with more on-line

components. Computation and communication overheads are reduced to the minimum.

(3) Availability and Reliability

We compare two protocols A and B. If protocol A has one more on-line component than

193

Fair Trading Protocol With Off-line Anonymous Credit Card Payment 9

protocol B and all other parts of the two protocols are the same, the on-line component

of protocol A has some chance to be unavailable or unreliable because of network prob-

lem, system failure or evil behaviors from involved parties or other attackers. Protocol

A has less availability and reliability than protocol B. In the fair trading protocol in this

paper, TTP and credit card service from a ﬁnancial institution are off-line in normal

case, the protocol is more available and reliable than other protocols with more on-line

components (TTP is on-line, the credit card service is on-line or both of them are on-

line).

(4) Untraceability and Privacy

The client uses the credit card to pay on the Internet in the fair trading protocol. Un-

traceability of the credit holder is a necessary or desirable characteristic of this kind

of trading protocols. In our fair trading protocol, the credit card is anonymous, the un-

traceability and privacy of the card holder is achieved.

4 Concluding Remarks

We have introduced our fair trading protocol with off-line anonymous credit card pay-

ment over the Internet. The fairness for involved client and merchant is achieved in the

protocol and the client is anonymous in the credit card payment. The TTP is off-line and

the ﬁnancial institution for credit service can be off-line as well. The details of digital

constructions for credit card payment and fair trading process are provided in this paper.

The technique of proof of equivalence of discrete logarithm to discrete log-logarithm is

employed as the main building block to construct the protocol. The protocol provides a

generic overall solution for fair on-line trading with credit card payment. The involve-

ment of TTP and the on-line ﬁnancial institution for the credit card service is reduced

to the minimum. Our protocol has better efﬁciency and availability than protocols with

more on-line components. The protocol can be used as the starting point to build some

complicated protocols in on-line environment, such as on-line gambling protocols.

References

1. F. C. Gartner, H. Pagnia and H. Vogt, “Approaching a formal deﬁnition of fairness in elec-

tronic commerce”, In Proceedings of the International Workshop on Electronic Commerce

(WELCOM’99), Lausanne, Switzerland, Oct. 1999.

2. V. Shmatikov and J. C. Mitchell, “Analysis of a fair exchange protocol”, Proceedings of the

1999 FLoC Workshop on Formal Methods and Security Protocols, 1999.

3. B.Cox, J.D.Tygar and M.Sirbu, “NetBill security and transaction protocol”, Proc. 1st USENIX

Workshop on Electronic Commerce, pp. 77-88, 1995.

4. S.Ketchpel, “Transaction Protection for Information Buyers and Sellers”, Proceedings of the

Dartmouth Institute for Advanced Graduate Studies ’95: Electronic Publishing and Informa-

tion Highway, 1995.

5. A.Bahreman and J.D.Tygar, “Certiﬁed electronic mail”, Proc. Internet Society Symposium on

Network and Distributed Systems Security, pp. 3-19, 1994.

194

10 Weiliang Zhao et al.

6. R.H.Deng, Li Gong, A.A.Lazar and Weiguo Wang, “Practical protocols for certiﬁcated elec-

tronic mail”, J.Network and Systems Management, 4(3) pp. 279-297, 1996.

7. N.Asokan, V.Shop and M. Waidner, “Asynchronous protocols for optimistic fair exchange”,

Proc. IEEE Symposium on Research in Security and Privacy, pp. 86-99, 1998.

8. R. Hauser, M. Steiner and M. Waidner, “Micro-payments based on iKP”, Technical Report

2791 (No. 89269), June 1996.

9. “SET Secure Electronic Transaction 1.0”, Technical Report, Mastercard, May 1997.

10. M. Sirbu and J. D. Tygar, “Netbill: An Internet commerce system optimized or network

delivered services”. ¡http://www.ini.cmu.edu/netbill¿.

11. B. C. Neuman and G. Medvinsky,“Requirements for network payment: The netcheque per-

spective”, Proceedings of IEEE CompCon’95, March 1995.

12. Y. Mu and V. Varadharajan, “A new scheme of credit based payment for electronic com-

merce”, the Proceedings of 23rd Local Area Networks Conference, IEEE Computer Society,

October, Boston, pp.278-284, 1998.

13. M. Stadler, “Publicly veriﬁable secret sharing”, Proceeding of Eurocrypto’ 96, LNCS 1070,

Springer-Verlag, pp.190-199, 1996.

14. N. Asokan, M. Schunter and M. Waidner, “Optimistic protocols for fair exchange”, Proceed-

ings of 4th ACM Conference on Computer and Communications Security, Zurich, Switzer-

land, pp.6-17, pp.6-17, 1997.

15. F. Bao, R. Deng and W. Mao, “Efﬁcient and Practical Fair Exchange Protocols with Off-line

TTP”, 1998 IEEE Symposium on Security and Privacy, pp.77-85, 1998.

16. J. Camenisch, “Efﬁcient and generalized group signatures”, Advances in cryptology - EU-

ROCRYPT’97, Lecture Notes in Computer Science 1233, Spring-Verlag, Berlin, pp.465-479,

1997.

17. Indrakshi Ray and Indrajit Ray, “An Optimistic Fair Exchange E-commerce

Protocol with Automated Dispute Resolution”, EC-Web, pp. 84-93, 2000.

http://citeseer.nj.nec.com/462055.html.

195
