Hold the Sources: A Gander at J2ME

Optimisation Techniques

Patrik Mihailescu, Habin Lee, and John Shepherdson

Intelligent Systems Lab, BT Exact

B62 MLB1/PP12 Adastral Park, Martlesham Heath, IP5 3RE, UK

Abstract. With the advent of the Java 2 Micro Edition platform, de-

velopers have the ability to develop Java based mobile applications that

beneﬁt from features such as device independence, and memory abstrac-

tion. However, applications also inherit many limitations such as slow ex-

ecution, and excessive memory usage that impact on overall application

performance and usability. The aim of this paper is to present and eval-

uate six known optimisation techniques for improving the performance

and usability of Java based mobile applications. Some of these techniques

are dependent on features provided within the IBM WebSphere Studio

Device Developer IDE. A real life multi-agent based mobile application

is presented to demonstrate the performance and usability improvements

that have been gained through applying these optimisation techniques.

1 Introduction

In the past, developing applications for mobile computing devices has typically

been diﬃcult due to proprietary development tools that required developers to

have an intimate knowledge of the device and/or Operating System (OS) func-

tionality. This is now changing with the advent of the Java 2 Micro Edition

(J2ME) platform [1]. The J2ME platform provides developers with an alterna-

tive approach for developing mobile applications through the use of a common

object-oriented programming language that hides the complexity and features

of the underlying OS and device.

The J2ME platform is targeted at a wide spectrum of mobile computing

devices such as mobile phones, household appliances, and Personal Digital As-

sistants (PDAs). To cater for the diﬀerent levels of device functionality, where for

instance, devices may provide anywhere between 64KB to 1MB of heap memory,

the J2ME platform deﬁnes the concept of proﬁles [1]. A proﬁle deﬁnes a set of

APIs that are applicable for a similar group of devices, such as mobile phones.

Using this approach, each proﬁle can be optimised for a speciﬁc device group by

only including APIs that are relevant to the available features and functionality

of the device. However, each proﬁle must also provide support for a common set

of APIs that are core to the Java programming language.

Due to the interpreted nature of the Java programming language, the J2ME

platform suﬀers from a number of limitations that aﬀect the overall application

Mihailescu P., Lee H. and Shepherdson J. (2004).

Hold the Sources: A Gander at J2ME Optimisation Techniques.

In Proceedings of the 1st International Workshop on Ubiquitous Computing, pages 73-82

DOI: 10.5220/0002674600730082

 SciTePress

performance. This includes slow execution, low heap memory, non-predictable

garbage collection, memory fragmentation, and varying performance on diﬀerent

mobile computing devices.

These limitations, when combined with others, can have a confounding eﬀect

on the usability of mobile applications. Typically users of mobile computing de-

vices only interact for very short periods of time with applications, therefore any

start-up delays or slow application responses have a negative impact on users.

The aim of this paper is to present and evaluate six known optimisation tech-

niques for improving both the performance and usability of J2ME based mobile

applications. Although several of these optimisation techniques are dependent

on the features provided within the IBM WebSphere Studio Device Developer

(WSDD) IDE, they can still be applied to other IDEs that provide equivalent

features. We apply these optimisation techniques to a real life multi-agent based

mobile application to measure the actual performance improvements.

The outline of this paper is as follows; in the next section we provide an

overview of related work and in section 3 we provide information regarding each

of the six optimisation techniques. In section 4, we apply these techniques to

the real-life multi-agent based mobile application, and evaluate the performance

improvements. Finally, in section 5, we conclude this paper.

2 Related Work

There is a wealth of information available on general optimisation techniques

for the Java programming language, and those speciﬁc to the J2ME platform.

Techniques include [11] [13]: minimizing inheritance, reusing objects, using alter-

native approaches to method synchronisation, eliminating inner classes, avoiding

string concatenation, using shorter method/class names, using lazy class load-

ing, etc. The diﬃculty in applying these optimisation techniques is the ability to

pinpoint exactly which technique has improved performance and by how much.

The majority of these techniques are typically applied during the design and

coding stages of application development. Whereas the optimisation techniques

presented in this paper are applied during the testing and deployment stages of

application development and each can be individually measured to work out the

actual performance gains achieved.

[8] provides a performance comparison between the CDC speciﬁcation (part

of the J2ME platform), Java 2, and Java 1.1. The static and dynamic footprint

of each VM was measured, including six individual tests that measured areas

such as object creation, threading, and I/O. Our work diﬀers in that we provide

optimisation techniques that are designed to improve the performance of a J2ME

based mobile application.

3 Optimisation Techniques Overview

The optimisation techniques presented within this paper are aimed at optimis-

ing an application without modifying the source code. These techniques can be

grouped into three levels: 1) VM, tailoring a VM for a particular target environ-

ment, 2) Deployment, optimising an application through techniques such as code

reduction, and 3) Runtime, ﬁne-tuning the operational performance of both the

VM and application. All three levels can be viewed as part of an optimisation

stack, where each level focuses on speciﬁc optimisation techniques that can be

applied independently or combined together. An additional level can be added

that applies the techniques mentioned in the related work section.

Several of the techniques presented within this paper are dependent on the

features provided within the IBM WSDD IDE [4]. The WSDD IDE enables the

development of applications based on the J2ME platform. This IDE supports

development for a diverse set of mobile OS’s such as the Palm OS, and the QNX

OS. For each OS, a customisable VM is provided which can be tailored to suit

both the target environment, and application requirements.

The WSDD IDE supports the majority of the J2ME proﬁles currently de-

ﬁned within the Java Community Process (JCP) such as the Foundation proﬁle

[3], and the Mobile Information Device Proﬁle (MIDP) [2]. In addition, a supple-

mentary set of custom proﬁles (which have no relationship to the J2ME proﬁles)

is included. Custom proﬁles can be used within environments, which require full

customisation over the APIs bundled with the VM due to the limited availability

of computing resources.

The optimisation techniques that are not dependent on the context of an

application have been tested on an O2 XDA running the Pocket PC OS. Before

an optimisation technique was tested, the XDA was reset. Each test was per-

formed forty times, unless otherwise stated. Finally, we used version 5.5 of the

IBM WSDD IDE. We will now discuss the optimisation technique within the

VM level, followed by those within the deployment level, and conclude with the

runtime level techniques.

3.1 VM Level Optimisation: Customising the VM

Mobile computing devices diﬀer signiﬁcantly from each other in terms of not

only their hardware, and OS functionality but also their physical appearance,

and usability properties. Therefore, a general purpose VM that contains a set

of generic APIs is not suitable, and will impact on the overall performance and

usability of an application. This optimisation technique is focused on customising

the VM for both the target environment and application.

As mentioned, the WSDD IDE provides a customisable VM for each OS,

whichcanbemodiﬁedintwoways:i)VM functionality and ii) API set.De-

pending upon the target OS, each VM is comprised of an initial set of ﬁles that

provide minimum level functionality such as dynamically loading Java classes.

By default, a VM is not conﬁgured to use any particular proﬁle. Each proﬁle

is comprised of two parts: i) a ﬁle of classes (in JAR format) containing all the

Java APIs, and ii) a corresponding DLL containing the native implementation.

There is no ﬁxed limit on the number of proﬁles that can be bundled with a VM.

To demonstrate the beneﬁts of this optimisation technique we measured the

start-up time and static footprint size of three customised VMs. Two of the VMs

have been customised for a single proﬁle, while the third VM has been set-up to

use any proﬁle type. All three VMs contain the same level of VM functionality.

The results of this test are presented in Table 1. The ﬁrst two rows contain

the results for a VM that has been customised for a single proﬁle: 1) JCL Xtr,

(a custom proﬁle), and 2) Foundation. The last row contains the results for a

VM that can use any type of proﬁle; in this case, it has been bundled with the

Foundation proﬁle. The results show that customising the VM can not only save

storage space, but also signiﬁcantly reduce an application’s start-up time.

Table 1. Test results from customising the VM optimisation technique.

Proﬁle type Static footprint VM start-up

JCL Xtr 656KB 799ms

Foundation

1689KB 1962ms

Foundation (Generic VM)

1986KB 2172ms

By using a smaller proﬁle (JCL Xtr), a storage space saving of 61% was

achieved, and the VM start-up time was also reduced by 59%, when compared

to using the Foundation proﬁle (row two). If it is not possible to use a smaller

proﬁle, a saving can still be gained by customising the VM to a speciﬁc proﬁle

when compared to just using a generic VM (row three). A saving of 15% on

storage space, and a 9.5% reduction in VM start-up was achieved.

3.2 Deployment Level Optimisation (1): Application Deployment

Eﬀectively deploying applications on mobile computing devices is an important

issue that not only aﬀects an applications performance but also its usability.

Lack of storage space, and application start-up delays are just two issues that

need to be addressed.

Instead of using the JAR format, this optimisation technique utilises an al-

ternative deployment format provided by the WSDD IDE, JXE (J9 Executable

format) [7]. The JXE format reduces the delay when launching an application,

and lowers the resource usage of the VM when loading Java classes. This is

achieved initially by converting all the classes required by an application into a

JXE speciﬁc format, and then ROMizing them into a single image. Within this

image, all the classes have been resolved, and their locations (address) and those

of their methods have been determined. Therefore, at runtime the level of pro-

cessing required by the VM during the class loading process can be substantially

reduced.

An additional beneﬁt of the JXE format is the ability to create Execute-

In-Place (XIP) applications. XIP applications can be placed into ROM, where

they can be directly executed, thereby eliminating the need to keep two copies

of the same class in memory. To demonstrate the beneﬁts of this optimisation

technique, we compared the start-up time of a VM that is customised for the

Foundation proﬁle which has its classes packaged in both JAR and JXE format.

The results of this test are presented in Table 2, which shows that while the JAR

format achieved a better compression ratio by 19.5%, the JXE format reduced

the VM start-up time by 25%.

Table 2. Application deployment optimisation number one test results.

Deployment format Proﬁle class storage space Start-up time

JAR 990KB 1963ms

JXE

1149KB 1464ms

3.3 Deployment Level Optimisation (2): Code Optimisation

The second deployment level optimisation is aimed at reducing the overall size of

an application, and improving (in certain parts) its execution. This is achieved

by applying known code reduction and code optimisation techniques.

Code reduction involves removing unused classes, methods or ﬁelds from an

application. Furthermore, techniques such as code obfuscating, compression, and

stripping debug information from classes can also be applied. Code optimisation

involves improving the performance of certain parts of an application’s code

through techniques such as:

– In-lining methods [12], to reduce the overhead during method invocation.

– Call site devirtualization [6], which can be applied to reduce the overhead

when invoking interface methods by replacing them with static methods.

This can only be applied to methods, which at compile time always refer to

the same methods at runtime.

– Reducing the level of sub-classing and method overloading through analysis

techniques to determine which methods/classes can be declared as ﬁnal.

– Pre-compiling classes/methods to native code using Ahead of Time (AOT)

compilation [10]. This is discussed further in section 3.5.

The WSDD IDE supports all of the techniques presented above.

3.4 Runtime Level Optimisation (1): Persistent VM

To enable ’instant on’ applications, this technique focuses on further reducing

the start-up delay experienced when launching an application. This technique

ensures that only one instance of the VM is loaded, and that all applications

are executed within this single instance. Typically on mobile computing devices,

Java applications are launched via a shortcut that invokes the VM executable

and passes additional parameters such as the name of the main application class.

This optimisation technique introduces an alternative approach to launching

a Java application. This involves developing a native application to act as a Java

application launcher. This native application will ensure that only one instance

of the VM is created, and that all Java applications are executed within this

single instance. To work out if an instance of the VM is available, a dedicated

background Java process will need to be launched within the VM, the ﬁrst time

the VM is created. This running process is known as the VM registry, and is

responsible for loading Java applications when requested by a Java application

launcher.

Both the Java application launcher and the VM registry process use the

Windows messaging API to communicate with each other. An example of how

this optimisation technique works is provided below:

1. The ﬁrst time an application (A) is started, its application launcher (La)

will need to create an instance of the VM (as none is available), and provide

it with two arguments: 1) the main class of the VM registry process, and 2)

the main class of the Java application.

2. Once the VM registry process is started, it will use the second argument

provided by application launcher (La) to load the requested Java application.

3. If another application (B) is launched, its application launcher (Lb) will

attempt to ﬁnd a running instance of the VM by using the ’FindWindow’

API to obtain a handle to the VM registry process.

4. Once the VM registry process is located, application launcher (Lb) sends it

a message using the ’SendMessage’ API requesting that it loads application

(B). Within this message, the main class of application (B) is provided.

5. Upon receiving this message, the VM registry loads application (B).

3.5 Runtime Level Optimisation (2): Ahead of Time Compilation

A common technique for improving the performance of a Java application is

through the use of a Just-in-Time (JIT) compiler. A JIT compiler is used to

dynamically convert frequently interpreted bytecode into native code during the

execution of an application. However, in certain environments, a JIT compiler

may be unsuitable due to the additional computing resources required for its

inclusion and subsequent execution. For example on the Pocket PC OS, the JIT

compiler requires at least 1046 kb of storage memory.

This optimisation technique makes use of an alternative approach for con-

verting bytecode into native code, which is known as Ahead of Time (AOT)

compilation [10], available as part of the WSDD IDE. AOT can be used at

build-time to convert speciﬁc parts of an application’s code into native code,

which can then be directly executed at runtime by the VM without the need

for a JIT equivalent compiler. Typically, only a small portion of an applica-

tion should be converted into native code using AOT compilation, as with each

converted method the overall application size increases. Therefore, this may be

unsuitable for environments where storage space is a premium.

Unfortunately due to a problem with the current version of the VM for the

Pocket PC OS, AOT compiled classes are not handled, and as such we are unable

to measure the beneﬁts of this technique.

3.6 Runtime Level Optimisation (3): VM Runtime Settings

Under each OS, a set of default runtime settings is provided to the VM that

determines its operational settings. The default values provided are general in

nature and may hinder application performance. Examples of the type of settings

that can aﬀect application performance include:

-Xmca: This setting determines the unit of growth for RAM memory when

more memory is required to load classes. A high value is useful for applica-

tions with a large set of classes.

-Xmco: This is similar to the -Xmca setting, except it is used for ROM memory.

-Xmx: This setting represents the maximum amount of RAM memory that can

be consumed by the VM during its execution.

-Xmoi: This setting determines the unit of growth for RAM memory when more

heap memory is required.

-Xmo: This setting represents the initial size of heap memory available for an

application. Once this value is reached, garbage collection is performed, and

if no memory can be freed then the size of this memory space is increased

based on the value of the -Xmoi setting. Depending upon the application

context/requirements, a high value may be set to avoid garbage collection,

thereby maintaining application responsiveness.

-Xmn: This setting determines the memory space size where an application’s

newly created objects are placed within. Once an object survives the garbage

collection process ten times, it will be placed within the application’s heap

memory. Setting this to a high value will increase the length of time taken

by the garbage collector to free unused objects.

-Xiss: This setting represents the initial stack size of a Java thread. This is

useful for applications that create a large number of threads.

4 Real Life Application

We have applied these optimisation techniques to improve the performance and

usability of a real life multi-agent based mobile application. This application

provides a team-based approach for job management in the ﬁeld of telecom-

munications service provision and maintenance. Jobs are assigned to teams of

engineers based on pre-deﬁned business rules which use information such as an

engineer’s geographic location and skill set. A variety of services are available

that include: real-time job updating, job trading, job delivery (both push and

pull mode), and travel planning. Further details regarding this application are

provided within [9].

The underlying multi-agent platform used within this application is the JADE-

LEAP platform [5]. The JADE-LEAP platform is an optimised version of the

JADE platform that has been designed to run on a variety of mobile comput-

ing devices. An agent execution environment known as a lightweight container

is provided that includes services such as messaging, service management, and

task scheduling to locally executing agents.

Engineers run this application on a mobile computing device such as an XDA,

and connect back to an Intranet via a secure Virtual Private Network (VPN)

connection over a GPRS network where they can access services such as job

retrieval and job update. In the following sub-sections, we evaluate the perfor-

mance improvements gained as a result of applying the presented optimisation

techniques.

4.1 Application and VM Deployment

We applied the deployment level one (JXE format) and two (code reduction)

optimisation techniques to our application. For the deployment level two tech-

nique, we used most of the code reduction/optimisation techniques on two ﬁles:

1) JADE-LEAP platform classes, and 2) application classes. We did not optimise

the Foundation proﬁle’s classes.

For both ﬁles we applied three common code reduction techniques: 1) com-

pression, 2) omitting debug information, and 3) removing unused classes, meth-

ods and ﬁelds. We also applied one code optimisation technique, in-lining meth-

ods. We only applied the Call site devirtualization and class/method ﬁnal decla-

ration technique to our application’s classes. Approximately 68 methods were in-

lined within our application, and 368 within the JADE-LEAP platform. Lastly,

61 methods were declared ﬁnal and 826 methods were devirtualized within our

application’s classes.

Table 3 provides details as to the storage requirements for our application,

the JADE-LEAP platform and the Foundation classes. The ﬁrst row shows the

storage size for each ﬁle that has been optimised through the above mentioned

techniques. The second row shows the storage size for each ﬁle when deployed in

JAR format. Both the JADE-LEAP platform and our application classes have

been optimised through two common code reduction techniques: 1) compression,

and 2) omitting debug information. We also removed unused classes/methods

from the application classes. NOTE: When applying the VM level optimisation

technique one, we customised the VM speciﬁcally for the Foundation proﬁle.

4.2 VM Runtime Conﬁguration

To meet both the operational and usability application requirements, we made

a number of modiﬁcations to the VM runtime settings. These include:

-Xmca: This value was doubled to 32K, as both the underlying JADE-LEAP

platform and our application load a number of classes dynamically.

Table 3. Storage requirements for our application.

Application JADE-LEAP platform Foundation proﬁle

JXE 353KB 633KB 1149 KB

JAR

284KB 756KB 900KB

-Xmx: This value was increased from 8MB to 32MB, to improve the responsive-

ness of the user interface, and to ensure that adequate memory was available.

-Xmoi: This value was increased from 64K to 96K for similar reasons as the

previous setting.

-Xmno: This value was increased from 256K to 328K, to provide adequate

memory for newly created objects.

-Xmn: This value was increased from 256K to 328K, to minimize the number

of times required to grow the application’s heap memory.

-Xiss: This value was doubled to 4K as the underlying network subsystem of

the JADE-LEAP platform is heavily multi-threaded.

4.3 Application Start-up Reduction (1)

To measure the start-up performance improvements gained through applying

the optimisation techniques mentioned in the previous section, we compared the

time taken to load the two versions of our application. The results from this

test are shown in Table 4. To reduce the aﬀects of network ﬂuctuations for each

result, we eliminated the highest two values, and lowest two values. Through

applying the deployment level one, two and VM level optimisation technique we

reduced the application start-up time by approximately 9.6%, equivalent to 1.9

seconds.

Table 4. Results for improving the start-up time of our application.

Type VM start-up Platform start-up Application start-up

JAR 2234ms 13904ms 3677ms

JXE

1953ms 12261ms 3684ms

4.4 Application Start-up Reduction (2), and Usability Improvement

As shown in Table 4, a signiﬁcant amount of time of the overall application start-

up time is spent in loading the underlying JADE-LEAP platform. Therefore to

eliminate this delay, we not only applied the runtime level optimisation technique

number one, but we also modiﬁed our application launch routine. Within the

application launch routine, a check is performed to locate a running instance

of the JADE-LEAP platform, and if an instance is found the application is

attached to it (else one is created). Using this technique, we were able to reduce

the start-up time of our application to approximately under four seconds.

An additional advantage of this optimisation technique was that it improved

the usability of the application by ensuring that only a single instance of the

application was executed. Within the Pocket PC OS, there is no easy way for

a user to switch between multiple running applications. Typically users will re-

select the application icon, which for a Java appplication results in launching

another application instance. Within the Java application launcher if the user

re-selects the application icon the launcher will attempt to locate a running

instance of the application and if found, the application’s window is displayed.

5 Conclusion

Within this paper we have presented a set of optimisation techniques for improv-

ing the performance and usability of J2ME based mobile appliations. Within the

set, individual optimisations were provided that can be used independently or

combined. We applied these techniques to a real world mobile application and

demonstrated the performance improvements that were gained.

Future work includes evaluating the beneﬁts of AOT compilation, and inves-

tigating other techniques that can address performance issues such as memory

usage, network bandwidth, and battery power.

References

1. Java 2 platform, micro edition, Frequently Asked Questions, January 2004.

http://java.sun.com/j2me/reference/faqs/index.html.

2. JSR 118 Mobile Information Device Proﬁle 2.0, January 2004.

http://jcp.org/en/jsr/detail?id=118.

3. JSR 46 J2ME Foundation Proﬁle, January 2004.

http://jcp.org/en/jsr/detail?id=46.

4. Websphere Studio Device Developer Websphere software, January 2004.

5. M. Berger, S. Rusitschka, M. Schlichte, D. Toropov, and M. Watzke. Porting

Agents to Small Mobile Devices - the Development of the Lightweight Extensible

Agent Platform. EXP in search of innovation special issue on JADE, 3(3):32–41,

2003.

6. K. Ishizaki, M. Kawahito, T. Yasue, H. Komatsu, and T. Nakatani. A study of

devirtualization techniques for a Java Just-In-Time compiler. In Proceedings of

the 15th ACM SIGPLAN conference on Object-oriented programming, systems,

languages, and applications, pages 294–310, 2000.

7. M. Kok. Developing a DB2 Everyplace Java Application

using WebSphere Studio Device Developer., January 2002.

http://www-106.ibm.com/developerworks/websphere/registered/tutorials/0212_kheng/kheng.html.

8. M. Laukkanen. Java on Handheld Devices - Comparing J2ME Cdc to Java 1.1 and

Java 2, January 2004.

http://citeseer.nj.nec.com/473890.html.

9. H. Lee, P. Mihailescu, and J. Shepherdson. A Multi-Agent System to Support

Team-Based Job Management in a Telecommunications Service Environment. EXP

in search of innovation special issue on JADE, 3(3):96–105, 2003.

10. G. Muller, B. Moura, F. Bellard, and C. Consel. Harissa: a Flexible and Eﬃcient

Java Environment Mixing Bytecode and Compiled Code. In Proceedings of the

Third USENIX Conference on Object-Oriented Technologies and Systems, 1997.

11. J. Shirazi. Java Performance Tuning (2nd edition). O’Reilly and Associates, 2003.

12. P. Tyma. Tuning Java Performance, January 2004.

http://www.ddj.com/documents/s=962/ddj9604e/.

13. S. Wilson and J. Kesselman. Java Platform Performance: Strategies and Tactics.

Addison-Wesley Pub Co, 2000.
