Scalable Continuous Query System for Web Databases

Ather Saeed, Savitri Bevinakoppa

School of Computer Science and Information Technology, RMIT University,

Melbourne, Australia

Abstract. Continuous Queries (CQ) help users to retrieve results as soon as

they become available. The CQ keeps track of two important events. If there is

any change in the source information, it immediately notifies the user about

that particular change. Secondly, it also keeps track of the timer-based events,

in case information is required after a fixed period of time. Existing techniques

such as OpenCQ[1] and NiagaraCQ[2] are inadequate to optimise Continuous

Queries. These techniques focus on defining the semantics for execution of CQ

and much less effort was spent to define the tradeoffs required for evaluating

the specific condition and generating a cost-effective query evaluation plan

(QEP). The optimising scheme used in [1],[2] for information retrieval is not

appropriate for an environment like the Internet. This paper also provides a new

architecture and group optimisation strategy for the efficient retrieval of CQ on

the web.

1 Introduction

Continuous Queries (CQ) [1],[2],[3],[4] help users to obtain new results soon after an

update occurs in a system. Once a CQ is triggered, it will continuously run and moni-

tors a particular threshold value. Result will be sent whenever the desired value be-

comes true.

Successful CQ execution is a major challenge in distributed environments because

of the unpredictable behaviour of nodes connected to a network. Failure of CQ will

schedule the same query over and over again, which is I/O and resource intensive. If

an appropriate optimization strategy is not used latency would become extremely

high and it will slow down the information retrieval process on the Web.

NiagaraCQ [2] addresses group query optimization to some extent by providing a

comparison of pull-based and push-based approaches using signature matching and

query split scheme. This is not a cost-effective strategy to generate a highly efficient

global access plan necessary for CQ execution.

OpenCQ [1] address the problem of Continuous Queries and defines necessary

semantics for the sequential execution of each CQ.

OpenCQ[1] generates an execution plan for each CQ separately. If CQ fails, execu-

tion would be resource and I/O intensive especially in queries that involve large join

operations.

Saeed A. and Bevinakoppa S. (2004).

Scalable Continuous Query System for Web Databases.

In Proceedings of the 2nd International Workshop on Web Services: Modeling, Architecture and Infrastructure, pages 59-72

DOI: 10.5220/0002676500590072

 SciTePress

In this paper we address importance of web-based CQ in regards to the optimisation

problems with the existing Continuous Query systems [1],[2]. By performing

experiments, we also show that the scalability of a system is compromised when an

appropriate optimisation scheme is not used. This paper also provides analysis of the

two systems: OpenCQ[1] and NiagaraCQ[2] which highlights the limitations of the

existing optimization techniques used in both systems.

The remaining paper is organized as follows: Section 2 gives an overview of

problems with the existing Continuous Query systems. Section 3 describes our

proposed grouping technique. Section 4 describes the architecture of CQ system.

Section 5 describes cost parameters required for the cost analysis of a CQ-System.

Section 6 describes the experimental analysis. Section 7 describes related work.

Section 8 describes the conclusions and future work. Section 9 gives the Web CQ-

system overview. Finally section 10 contains references used in this paper.

2 Problems with Existing CQ Systems

Continuous Queries are standing and long running queries that monitor a particular

update based on the specified condition. Therefore it is hard to stop CQ in the middle,

particularly when the update frequency is very high. In highly dynamic environments

like the Internet, major challenge is to control trade-off between the specified

condition, such as the frequency of update and efficiency of the Query Evaluation

Plan (QEP).

The other challenge is to send the most accurate and up-to-date information in an

environment like the Internet, where source information is constantly changing and

the behaviour of node is highly unpredictable.

Therefore we need a new multi-query optimization approach that exploits the

commonalities among the sub-expression, present in queries, with a focus on

providing a shortest access path, which can be used for answering a particular query.

It is only possible if the global access plan is used to answer queries.

The problem with NiagaraCQ [2] is that, its major focus was on routing a huge

amount of data using XML-QL and retrieving information from the XML type files

and data integrity was not the major concern. We have observed through

experimentation that sometimes no result was retrieved at all but the cost for

generating a valid execution plan was also very high.

In NiagaraCQ [2], a query split scheme was used, which group queries by

matching signatures and consider it as a potential group, by ignoring the fact that it

might not be the potential solution or plan, which will further increase the cost of

scanning query evaluation plans. Beside that more appropriate strategy is required to

cache results in order to deal with the temporary materialized results.

Although OpenCQ[1] provides data integrity to some extent but it does not

provide a cost-effective solution to the problem of scalability because it sequentially

executes each CQ. Many researches such as [5],[6],[7] have shown that sequential

execution of queries is expensive compared to the global execution in many

circumstances. Especially when queries are routed to heterogeneous data sources with

large join expressions.

The major problem is to look at one fundamental question which is: How to deal

with the scalability issues in an environment like the Internet? Especially when the

query involves a large number of joins and triggered condition needed to check the

frequency of update is very high?

The answer to the above question lies in the new scalable architecture that optimises a

group of Continuous Queries together with a view to exploit commonalities by

providing a cost-effective solution to the evaluation of monotone or redundant

queries which will be discussed in the next section.

3 The Proposed Grouping Technique

Existing techniques [1],[2] for optimising CQ are not adequate, which is clear from

the above discussion. The technique is not suitable due to three reasons:

A group might not produce an optimal solution to the problem.

Unsuccessful execution of CQ will increase the latency rate of data retrieval on the

Internet due to which query evaluation cost would become extremely high.

Efficiency of query evaluation plan (qep) was not taken into account in order to get

cost-effective solution.

Our grouping strategy takes care of the above-mentioned problems by dynamic re-

grouping of CQ and generates a global access plan which is as follows:

A single query might have many plans; the role of an MQO optimiser is to find a

best plan with a minimum cost. For simplicity we will use the same notion mentioned

in many database research papers [5], [6], [7].

Suppose we have two plans, plan (A) is

><><

and plan (B) is

T, where

represents a join operation.

MQO (Multiple Query Optimisation) is a two-step process. In first step the

optimiser will decompose queries into sub queries to find common sub expressions,

then executes the partial plans and materialize the results as shown in fig.3.2. In the

second step it explore the search space using some heuristic algorithm and starts

merging the best plans and generates a global plan that will minimize the cost of a

query evaluation. Our optimiser will filter the timer-based queries and store the

temporary query-id (qid) in cache memory for a certain period of time. As joins are

the most expensive operation on any database system. The main purpose of the query

decomposition scheme is to reduce the query evaluation time by efficiently retrieving

results from the primary storage then incrementally evaluate each query before

sending it to the user on the Internet. The Join trees of Plan (A) and Plan (B) using a

bottom-up approach is shown below on the next page.

In the fig.3.1, leaf nodes represent relation and inner nodes represent join

operators. The whole query tree is not shown in the figure, because major goal was

just to show that many queries usually use the same base relations and contains

common sub-expressions.

Previous researches in MQO [5],[6] have shown that left-deep trees are more

efficient to execute, but due to the sensitive nature of continuous queries, as soon as

the optimiser finds the best plan, it starts merging them together and store the

temporary query-id (Qid) in the main memory for a certain period of time instead of

keeping the whole result in the main memory. Materialized Result (Mres) can be

added or deleted from the cache and copied to hard disk. In this case additional disk

I/O will be required. The aim is to reuse the same result for the next group when

required. Mres is also shown in result table fig.3.3 and Triggeri etc are triggers

defined on data soures.

Plan A Plan B

Fig. 3.1. Right deep join trees of Query plans

3.1 Grouping Strategy

Our grouping strategy will partially execute each Plan as follows:

Fig. 3.2. . Partial results of Plan A and Plan B

Global access plan for the plan A and plan B is shown on the next page. YZ and ZT

are the partial result of Plan A and Plan B, which is a DAG (Directed Acyclic Graph).

For simplicity we are showing the joins only. Our model is not limited to executing

joins. Although it holds the projection for a certain period of time until a global

access plan is finalized and passed to the optimiser.

In order to make our idea more general, the whole query tree of Plan A and Plan B is

not shown. More details can be found in [5],[7],[9]. The select operations are pushed

down the query tree in order to reduce the search space for efficient join processing.

Z Y

Y Z

Our MQO algorithm is an extension of [5],[7],[9]. These algorithms are used for

normal SQL-type queries, whereas we are dealing with event-driven and timer-based

Continuous queries.

Beside that algorithms [5],[6],[7] were not designed for an environment like the

Internet. In order to define the Multi-Graph strategy used in our model, we will use

somewhat similar graph definition used in [5],[6]. The Main objective is to find a new

technique that shows how to store, where to store and how to access the materialized

nodes in case of CQ?

Result

Table

Fig. 3.3. Global Access Plan

3.2 IE-CQ Algorithm

Input: Multi-Query Graph G(V,E,L,

res

), where V is vertex, E is edge, L is label of

vertex

and

res

contains the materialized result in an intermediate file.

Decompose the queries into sub-queries, so that partial results of a query can be

temporarily stored. If the query has any of the three conditions:

File Scan

Y Z

res

---- ----

.....

res-j

res-i

Trigger

MQO

If a query shares common base relation

If query is identical or similar

If query subsume another query (as in [6])

materialize the node and generate a new arc that represents an edge of a vertex

Generate an arc from

apply the merge (similar to [6]) operation as shown in

fig.3.2 and materialize the node.

Store

and cache result into an intermediate file

res,

Starts assembling the result

of queries in regards to there Cqid and send it to the CQ-Scheduler as shown in

fig.4.1. Continue the process for the next group and perform the process for

n-1

number of queries.Compare new group of queries with previous group plan, if the

res

can be shared. Always select plan with a minimum cost until no common expression

exists in a group

3.3 Caching Technique

In our MQO, caching improves the performance of query evaluation plans by putting

the materialized results in the main memory.

For simplicity we are using LRU-K [8] type caching technique. Due to the ad-

vancement in technology, we assume that main memory is large enough to hold re-

sults of queries for certain period of time as shown in the fig. 3.2. After the execution

of a particular group, stored results and plans will be transferred to the disk in the

form of small delta file somewhat similar to NiagaraCQ[2], which further involves

additional I/O cost.

Benefit is that the next group might share results from the previously materialized

nodes. This process will be continued for a certain period of time say from 24 to 36

hours. If new groups are getting benefit from the cached results and plans which are

materialized for a particular time then it can be used for other newly created groups.

Main objective is to reduce the number of hits to data sources as much as possible

and evaluate results incrementally.

4 Web CQ System Architecture

Details about each component in the Continuous Query system is described as fol-

lows and is shown in fig.4:

4.1 CQ-Scheduler

The Continuous Queries are content sensitive and event driven {same term is used by

Ling Liu}in [1], therefore the global plan created by the plan merger cannot be

discarded because of the specified triggered condition. We are assuming that there is

enough memory to hold the materialised results at least for one hour, if the query

needs a time greater than one hour it can be written to disk and will be activated,

which will incur additional I/O cost. It schedules each query when the triggered

condition becomes true.

4.2 Time Extractor

It will assign a unique ID to each query by extracting the time, before sending it to

the global optimizer, which will be reassembled again before sending the result of a

query to user.

4.3 CP- Analyzer

The Common Part analyser (CP-Analyser) is the most important part of the query

optimiser that analyse all queries present in a particular group and exploits the

commonalities with a view that result of a common sub-expression can be used for

answering other queries. The

will be cached and partial results of a query will be

stored in a result table for certain time as shown in fig.3.2.

4.4 Cost Estimator

The main purpose of this module is to estimate the cost of generating a valid CQ

execution plan (QEP) before sending to the data source. A valid plan is necessary to

achieve scalability. we have already discussed above that if the query evaluation Plan

is not valid then efficiency of the system will be compromised, which ultimately

results in high latency.

4.5 Incremental Evaluator

The role of this particular module is to incrementally evaluate each query in order to

avoid repetitive computation and has similarities with the techniques discussed in

OpenCQ[1] and NiagaraCQ[2].

4.6 CQ-Client Interface

This section provides an interface, where user will be able to add or delete the

Continuous Queries. This module will work as a front-end to Web CQ-System. It also

assist users in writing XML and XSQL type queries.

4.7 Data Handler

The role of a Data handler module is to analyse the type of data request coming from

a source on the Internet, whether it is a text file, XML type files or database systems,

it retrieves the information and sends result in a required format to the user.

Table 1. Cost Parameters

Fig. 4. Web CQ-System Architecture

5 Cost Parameters

∆

s∆

and

t∆

are the update, insert or delete event on a relation R. In our experi-

mental analysis, we are separately storing the three possible events that can occur on

a database system, which is not done in [1][2]. The benefit is less chances of getting

errors, while sending final results to the CQ-scheduler. Keeping the whole snapshot

of delta files [2], is not a cost-effective strategy. It is better to keep the delta file as

small as possible.

The benefit of using IE-CQ algorithm is that, it can decompose a single query into

multiple queries. Finally by using some graph traversal strategy like depth-first search

somewhat similar to [6], we can prune the redundant nodes in a graph. Cost

parameters are shown in the Table.1.

Parameters

Values

Network bandwidth

100 (mbps)

QEP evaluation time Milli (secs)

Update frequency of node Dynamic

Number of tuples 100-5000

R,S,T are XML, RDBMS

and text files

400 rows in each data

soruce.

∆

delta file for R,S,T

Cost of global access plan.

Cost of evaluating each CQ

Total number of queries 200-2000

cq, and

Details section-6

2, ……

WWW DataSources

Parser

MQO Optimizer

Data Handler

Plan Evaluator

CP-Anal

Event Han-

-Schedule

XML

Text

RDBMS

-Client GUI

Continuous

ueries

Time Extractor

5.1 CQ Cost Estimation

Join based decomposition of CQ has similarity with the selection base decomposition.

IE-CQ decomposes and assembles the results of

queries using very similar cost

estimation scheme as mentioned in [5],[9],[10] for evaluating group of queries.

res

(

)><

res

(

) ><

n-1

res

(

n-2

) ><

(

res

(

n-1

))) .

(1)

If the

is of type [

(

(>< (RELATIONS)] then materialized result (

res

) of a query

can be assembled as shown in equation (1). The above query evaluation as shown in

(1) has similarity with [5], [6], [7], [9] and [10], but these schemes were never used in

the context of CQ. In case of subsumption, if

is strongly related to

n-1 then

n-1

can be used to answer

or it contains a partial answer to query

Final result of a

can be retrieved by scanning

∆ with regards to the change in

data source. In our model we are assuming that queries share a large number of com-

mon sub-expressions and that partial results of a query can be assembled using join

based decomposition strategies as mentioned above, which is very similar to the strat-

egy mentioned in [5], [6], [10].

We also assume that some queries might be answered by simply intersecting some

previously stored intermediate results or could be obtained from the union of some

previously stored results.

Our model provides a new approach to optimize Continuous Queries by generat-

ing a global access plan instead of blindly generating a plan by matching signature

and consider it as a potential group such as in [2]. The major problem would be that;

delta files will become bigger due to unnecessary information, which was not re-

quired to answer a particular query. In the worst case it might not be a potential solu-

tion to a particular group.

The cost of CQ is sum of five components; which can be obtained by slightly

modifying the cost formula as mentioned in [5], [10].

Cost of scanning Relation: R

(CQ)

Cost of materializing nodes:

res

(CQ)

Cost of scanning materialized nodes:

res

(CQ)

Cost of re-scanning data source:

Cost of retrieving results of

Where

is the ratio of update frequency with regards to the change in data sources.

Cost

(CQ)

R(CQ)

+ 2

res

(CQ)

(2)

As the group part of a query is executed only once, therefore global plan can be ob-

tained as follows:

Cost

(MQO)

∑

i 1

qep

(CQ

) +

∑

j 1

qep

(CQ

) .

(3)

Where

qep

is the partial query evaluation plans which is individually evaluated and

qep

is the group QEP, which is evaluated only once in an

integrated way when the triggered condition becomes true.

6 Experimental Analysis

The experimental analysis of the technique for group optimization strategy mentioned

in section 3 will be discussed in the following section:

The experiments are performed using Pentium IV 2400 MHz machines with 1GB

RAM, 40GB Hard disk and running Windows 2000 / XP / NT.

The initial prototype of a system was designed in J2ee and Java XSQL Servlet

API for the server side scripting such as CGI related tasks. Oracle 9i and MS SQL

Server 2000 were used as database servers for retrieving and storing XML, text and

SQL type data.

The types of Continuous Queries performed on Oracle 9i and MS SQL-Server

2000 data sources are described below.

Type-1: Notify me when Passenger No:2 and Passenger No:15 arrive at termi

nal 10.

This type of query is important in tracking a passenger if the message for them is of

high importance.

Type-2: Notify me when plane B707 takes-off from the USA and arrives in

Canada.

This type of query needs a partial execution between a two specific time interval such

as departure and arrival. Arrival might be after 10 hours in Canada. Therefore partial

plan of a query will be saved in an intermediate file and sent to CQ-Scheduler as

shown in the fig.4.1 Finally after the arrival whole plan will be executed.

Type-3: Notify me every 10 minutes about the current position of the plane

B707.

This type of query will be scheduled after every 10 minutes and notify about

the current position of plane, which is a timer-base query.

6.1 CQ Installation Semantics

Our semantics for the execution of CQ are very similar to [1], [2] only the optimiza-

tion approach is different as discussed above:

CQ-Install: Airline-DB SQL-query

Query: SELECT <attr> FROM <source>

WHERE <join-condition-evaluation>

Trigger: <specified-condition>

Stop: <minutes><daily><monthly>

The XSQL type query format the results in XML before sending it to the CQ-

Scheduler as:

CQ-Install: XSQL-Query for xml DTD

<?xml version=1.0?><xsql:query

xmlns:xsql=urn:oracle-xsql>

SELECT <attr> FROM <XML-Schema>

WHERE<join-condition-evaluation>

Trigger: <specified-condition>

Stop: <minutes><daily><monthly>

Changes to the data sources are made artificially in order to simulate the results of a

query. Simulation results are shown in fig.6.1 and fig.6.2 graphs.

The purpose of simulation was to observe the behavior of grouping technique in

regards to the sequential execution of Continuous queries, when it involves large join

operations.

The graphs are based on results obtained from web CQ-System by applying type-

1, type-2 and type-3 queries. In fig.6.1 following parameters are considered:

c =

200 and

< 10, where

are the triggered CQ and

c are changed-base triggers

which are fired in case of any change occurred in the data source.

is the total num-

ber of joins operation permitted. In fig.6.1 and fig.6.2 the only parameter that is

changed was the join parameter such as

>10 and the curve obtained was almost a

straight line. One can easily observe that curve obtained was highly skewed in case of

traditional non-grouped approach, which shows that our grouped approach for global

evaluation of CQ is outperforming the existing ones mainly due to the following three

reasons. 1) The global optimization approach that incrementally evaluate each query

before sending to the user. 2) It takes care of operations, which involve large number

of joins. 3) Our system also provides data integrity, which was not the major concern

in [2].

LRU-K [8] type caching algorithm was used to store and transfer results to the

secondary storage after a certain period of time. Discussion about LRU-K techniques

for caching is beyond the scope of this paper and cannot be explained due to space

limitation.

10 0

150

200

250

300

350

400

Queries

Execution Time (s)

Group

NonGroup

100

200

300

400

500

700

1600

Queries

Time (s)

Group NonGroup

Fig. 6.1. Group and Non-grouped CQ Fig. 6.2. Group and Non-grouped CQ

7 Related Work

A huge amount of research has already been done in the area of Continuous Queries.

OpenCQ [1], provides semantics necessary for the execution of CQ in the form of

triplet (Query, Trigger-Condition, Stop-condition), which also provides an optimiza-

tion strategy for the sequential evaluation of CQ.

NiagaraCQ [2], provides a group optimization strategy using query split scheme, in

which they match the signature and put it in a group. It also provides an incremental

evaluation strategy so that repetitive computation of queries can be avoided.

D.Terry [3], had first provided the notion of Continuous Queries on Append-only

databases, which restricts the evaluation of CQ only to append-only and also provides

strategy to incrementally evaluate each query in order to get the most up-to-date re-

sult and avoids repetitive computation.

Simiarly goal of TriggerMan [11] system was also to create scalable triggers that

identify unique experission signature and group predicate using trigger condition. The

approach was very similar to the rules used in Active database systems using ECA

(Event-Condition-Action) type rules.

Our research is different from above-mentioned work, because its main focus is on

scalability problem and the efficient retrieval of information on the Internet from

various data sources such as text, XML and database systems by providing high accu-

racy and data integrity.

Global optimization of queries is also one of the most active areas of research.

[5],[6],[7], it provides an optimization strategy by exploiting similarities among the

common sub-expressions present in a query and generates a global access plan by

merging them together and showed that global optimization can significantly improve

the performance as compared to the individual query execution plan.

We have some similarity in regards to the above-mentioned approaches but our

proposed group optimisation strategy is different from the approaches for group op-

timisation discussed in [2],[5],[6],[7],[10] due to the following two aspects: 1) None

of them were on Continuous Queries, which are highly sensitive. 2) None of them

were aimed for an environment like the Internet.

The major goal of this paper is to show some experimental analysis that can pro-

vide valid arguments on problems with the existing optimization techniques. It also

shows the need for a new architecture that can solve the scalability and adaptability

problems on the Internet.

8 Conclusions and Future Work

Our proposed model has significantly improved the scalability problem, which has

not been addressed in the existing Continuous Query systems due to the following

two reasons:

The global optimization approach, to minimize the cost of evaluating queries that

involve large join operations.

A controlled trade-off mechanism that checks the specified condition and use the

shortest access path that exists in the global query evaluation plan to evaluate query.

Our future work involves the optimization of CQ using Evolutionary approach, so it

can support 1000’s and millions of Continuous Queries efficiently.

The current CQ-System prototype is at preliminary stage and also needs some

improvements in the design of the Client Interface. Time and event algebra is also not

inculded in this paper on which we are currently working.

9 Web CQ-System Overview

The output from Web-based CQ-System written in Java, J2ee, XSQL Servlet

using XML schema API and the Client-interface is shown above: A client can re-

trieve information using Web CQ-System Client interface. Triggers and timer can be

added by clicking on the buttons shown in the fig.9. Actual processing strategy is also

shown in the fig.9. Current simulation deals with four types of data sources such as:

Oracle 9i, MS SQL-Server 2000, XML and text. As soon as the query passes through

the web server, it is passed to the MQO optimizer for further processing, details about

the grouping strategy is already discussed above. XSQL servlet formats the data in

XML, XHTML etc before sending it to CQ-Scheduler, which then send result of

queries to various clients on the Internet. Oracle XSQL template also enables to write

dynamic XML data pages by traslating schema into required DTD. CQ-Scheduler can

communicate directly with the group optimizer as well as with J2ee-Server depending

on needs of the client. Triggers can dynamically added or deleted by clicking on

appropriate button as shown in fig.9 on the next page.

References

1. Ling Liu, Calton Pu, W.,Tang,.: Continuous Queries for Internet Scale Event-Driven

Information Delivery. IEEE Transactions on Knowledge and Data Engineering. Vol.

11 (1999) 610-628

2. J.Chen, David, J. ,D.,DeWitt, F.,Tian, Y., Wang.: NigaraCQ: A Scalable Continuous

Query System for Internet Databases. Proceedings of the ACM SIGMOD International

Conference on Management of Data. Dallas, TX, New York (2000) 379-390

3. Douglas Terry, David Goldberg, David Nichols, Brian Oki.: Continuous Queries Over

Append-Only Databases. Proceedings of the 1992 ACM SIGMOD International

Conference on Management of data, San Diego, California Vol. 21. (1992) 321-330

4. Ling Liu, Pu, C.,Barga, R.., T., Zhou, Differential Evaluation of Continuous Queries.

Proceedings of the 16th International Conference on Distributed Computing Systems

(ICDCS), ACM, New York (1996) 458 –465

5. Martin.,L.,.Keresten, M.F.N., Boer,.: Query Optimization Strategies for Browsing

Sessions. Proceedings of 10th International Conference on Data Engineering, Houston

Texas, USA (1994)

6. T.K.,.Sellis.: Multiple Query Optimization. ACM Transaction on Database Systems,

Vol..13. (1988) 23 – 52

7. Fa.,Chung, Fred Chen, M.H.,Dunham.: Common Subexpression processing in

Multiple-query Processing. IEEE Transaction on Knowledge and Data Engineering,

Vol. 10. (1998) 493-499

8. Elizabeth J.O’Neil, P.E.O.,Neil, G.,Weikum.: The LRU-K Page Replacement

Algorithm for Database disk buffering. Proceedings of the ACM Sigmod International

Conference on Management of Data, Washington D.C., USA, (1993)

297– 306

9. P.,Roy, S.,Sudarshan, S.,Bhobe.: Efficient and Extensible Algorithm for Multi-

Query Optimization. ACM SIGMOD Conference on Management of Data, TX,

USA (2000) 249-260

10. On Multi-Query Optimization - Choenni, Kersten,, v., Den, Akker, Saad,

Wiskunde en Informatica, REPORTRAPPORT J.F.P. van den Box 94079, 1090

GB Amsterdam, The Netherlands, Department of Computer Science, Alexandria

www.cwi.nl/ftp/CWIreports/AA/CS- (1996) R9638.ps.Z

11. Hanson, E. N., Carnes, C., Huang, L., Konyala, M., Noronha, L., Parasarathy, S.,

Park, J., & Vernon, A.,: Scalable Trigger Processing. Proceedings of Interna-

tional Conference on Data Engineering, IEEE Computer Society, Los Alamitos,

CA, March (1999) 266-275

Fig. 9. Web CQ-System Overview

Web

Server

MQO

timize

Oracle 9i/

XSQL

SQLServer/

XML-SQL

XML/XSLT

XDR/DTD

……….

Web data sources

J2EEServ
