On the Role of the Inner State Size in Stream Ciphers

Erik Zenner

University of Mannheim (Germany)

Abstract. Many modern stream ciphers consist of a keystream generator and an

initialisation function. In ﬁelded systems, security of the keystream generator is

often based on a large inner state rather than an inherently secure design. As a

consequence, an increasing number of attacks on stream ciphers exploit the (re-

)initialisation of large inner states by a weak initialisation function.

In this paper, we propose a strict separation of keystream generator and initialisa-

tion function in stream cipher design. After giving lower bounds on the necessary

inner state size, we show how a secure stream cipher can be constructed from a

weak keystram generator. We introduce the notion of inner state size efﬁciency

and compare it for a number of ﬁelded stream ciphers, indicating that a secure

cipher can be based on reasonable inner state sizes. Concluding, we ask a number

of open questions that may give rise to a new ﬁeld of research that is concerned

with the security of initialisation functions.

Keywords: Stream cipher, keystream generator, initialisation, inner state.

1 Introduction

Background: Let m = (m

, m

, . . .) be a message consisting of blocks m

∈ {0, 1}

A stream cipher is a pair of efﬁcient algorithms, where encryption transforms a message

block m

into a ciphertext block c

∈ {0, 1}

and decryption implements the inverse

transformation. Both encryption and decryption run under the control of a key K and

a counter t. Note that the use of a counter is the critical difference between a stream

cipher and a block cipher.

A frequent building block for stream ciphers is a keystream generator, i.e. a ﬁnite

state machine that transforms K into a pseudorandom bitstream z = (z

, z

, . . .) with

∈ {0, 1}

. In most cases, z

is added bitwise to m

for encryption and to c

for

decryption.

While a large body of literature exists on the design of keystream generators (cf.

[33, 27]), the remaining aspects of stream cipher design are less well researched. Only

few guidelines exist for the choice of important parameters like key length, inner state

size, or the number of bits produced before re-keying. The same uncertainty exists with

respect to the key setup algorithm that transforms the key into a starting state for the

generator.

The consequences in practical stream cipher design are twofold. On one hand, an

increasing number of stream ciphers is broken not by attacking the keystream generator,

but by attacking the key setup algorithm (e.g. RC/4 as used in the WEP protocol [35], or

Zenner E. (2004).

On the Role of the Inner State Size in Stream Ciphers.

In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 237-250

DOI: 10.5220/0002676702370250

 SciTePress

A5/1 from the GSM standard [17]). There exist a few general attack techniques against

weak setup functions for stream ciphers (e.g. resynchronisation attacks [13, 23]), but no

design criteria for good initialisation functions. Considering recent research progress

on related key attacks for pseudorandom functions (see [6] and subsequent work), more

problems for stream ciphers designed in an ad-hoc manner are to be expected in the

future.

On the other hand, when a cipher is successfully attacked, a common solution is

to change the parameters while keeping the general design intact. Examples include

increasing the inner state size (e.g. for LILI-128 [9]) or decreasing the security level

(e.g. for Sober-128 [25]). For some ciphers, huge security margins for the parameters

are used in the ﬁrst place (e.g. more than 33,000 bit of inner state for SEAL [32]).

Paper outline: This paper intends to be a starting point for future research on the design

of stream ciphers. We consider the construction of such ciphers from two primitives:

a keystream generator and an initialisation function. Observe that the inner state of

the cipher forms the interface between those two primitives. While a large inner state

is advantageous for the security of the keystream generator, it makes the task of the

initialisation algorithm more difﬁcult. It also requires more memory, hampering the use

on a restricted computational device like a smart card. In many respects, inner state

bits are to stream ciphers what encryption rounds are to block ciphers: Given a large

number of them, almost any design can be secure while at the same time, performance

is suffering.

Our goal is to improve the understanding of the necessity and the limitations of the

inner state. To this purpose, in section 2, we introduce a formal model of the stream

ciphers considered. In section 3, we discuss the cryptographic relevance of inner states,

giving lower bounds on the minimum size as well as a construction for a secure stream

cipher when inner state size and initialisation time are not critical. In section 4, we

observe that the inner state size has to be limited in most practical stream ciphers. This

leads us to the deﬁnition of inner state efﬁciency, yielding a measure of how much the

inner state size actually contributes to the security of the keystream generator. We also

give concrete values of inner state efﬁciency for a number of practical stream ciphers.

Concluding, in section 5, our results are summarised, and a list of open questions for

future research on stream cipher design is presented.

2 Terminology

2.1 Keystream generators

Basic model: In [33], Rueppel deﬁned a

keystream generator

as consisting of the fol-

lowing components (see the box in ﬁgure 1):

(a) An inner state S

∈ S with S ⊆ {0, 1}

(b) an update function f : S → S that modiﬁes the inner state with each clock, and

→ {0, 1}

, w ≤ v ≤ n, that uses the inner state to

compute w keystream bits with each clock.

(d) a Boolean predicates C : S → {0, 1}, such that an inner state S is a valid starting

state iff C(S) = 1.

238

t t

w w

Fig. 1. General model of a keystream generator

Deployment in stream ciphers: Keystream generators are often used in cryptography to

implement efﬁcient stream ciphers. A wide-spread design requires the following addi-

tional components:

(A) A secret

key

K ∈ {0, 1}

that is not necessarily identical to the inner state,

(B) an

initialisation function

h : {0, 1}

× {0, 1}

→ S that derives a starting state

from the key K and m bit of additional information (like an initial value or a

nonce), such that C(S

) = 1.

xor-function

⊕ : {0, 1}

× {0, 1}

→ {0, 1}

which adds the keystream

bitwise modulo 2 to the plaintext, generating the ciphertext

2.2 Inner state size:

A na

ıve candidate for the inner state size is the parameter n, denoting the length of

the inner state representation. There is, however, the obvious problem that the same

generator may be represented in different ways, yielding different values of n depending

on the concrete implementation.

Instead, in order to derive a unique deﬁnition of the inner state size, we consider an

autonomous ﬁnite state machine

(AFSM) implementing the generator

. Such an AFSM

consists of a set S of inner states, and for each inner state S ∈ S, there exists

– a

transition rule

that deﬁnes the next state f(S) for S, and

– a

label

deﬁning the output g(S) generated from S.

In addition, each ﬁnite state machine needs a set S

of valid

starting states

Note that there exists an inﬁnite number of AFSM describing the generator. In par-

ticular, the size of the AFSM (i.e. the number of inner states) can vary arbitrarily. Thus,

in order to ﬁnd a unique value for the number of inner states, we need to revert to the

notion of the

minimal AFSM

describing the generator.

In fact, other functions like addition modulo 2

are also possible, but rarely used.

For a full discussion of this topic, cf. [37]

239

An AFSM is said to

generate

an (inﬁnite) output sequence z = (z

, z

, . . .) if there

exists a starting state S

∈ S

such that z

= g(f

)). Two AFSM A and B are

said to be

equivalent

if all (inﬁnite) output sequences produced by A are also produced

by B, and vice versa. As a consequence, all AFSM that describe a given keystream

generator are equivalent. An AFSM is said to be

minimal

if no equivalent AFSM of

smaller size exists. Thus, if a minimal AFSM for a given generator can be found, its

size yields the minimal number of inner states required to implement the generator.

Having introduced these notions, we can deﬁne the unique inner state size of the

generator as follows:

Deﬁnition 1. Let G be a keystream generator as deﬁned above, and let A be a minimal

AFSM implementing G. Then the inner state size of the generator G is deﬁned as ˆn :=

dlog

(|A|)e, where |A| is the number of inner states of A.

2.3 Attacker model

Prior knowledge: The attacker is assumed to know everything about the stream cipher

with the exception of the key K and the current inner state S

. In particular, he is aware

of the set S of possible inner states and of the functions f, g and h. He also knows (or

even controls) the m bit of public information that are used, along with the key, to set

up the inner state S

Class of attack: We consider a known-plaintext attack. Since knowledge of plaintext

and ciphertext implies knowledge of the keystream, it can be assumed that the attacker

has L ¿ 2

known keystream bits at his disposal.

Computational resources: The attacker can do any computation that requires less steps

than a complete search over the key space. This bound holds both for the precomputa-

tion and the actual attack phase, implying a bound of strictly less than 2

bits of memory

that can be used.

Notion of success: An attacker is considered successful if he can correctly predict

previously unknown keystream bits, or if he can distinguish the output of the keystream

generator from truly random bits. We say that the keystream generator is broken if there

exists an attacker whose success probability differs signiﬁcantly from pure guessing.

Note that in particular, reconstruction of a correct tupel (t, S

) or of the key K implies

a successful attack in the above sense.

3 Cryptographic strength from large inner states

3.1 The necessity of large inner states

In the following, let l denote the key length, ˆn the inner state size and n the length of the

inner state representation (n ≥ ˆn). For most practical stream ciphers, it can be observed

that n > l holds. We will brieﬂy discuss that this is in fact a necessary condition for

secure stream ciphers.

240

First lower bound: The main design goals of practical stream ciphers are security and

efﬁciency. In order to achieve the efﬁciency goal, the functions f, g and h are chosen to

be as simple as possible. In particular, g : {0, 1}

→ {0, 1}

is constructed such that

w ≤ v < min{l, n}.

Lemma 1. Let the output function g depend on v < l inner state bits and let the output

be balanced. Then the keystream generator can not be secure if n < l + w.

Proof. For such a generator, a divide-and-conquer attack can be mounted: The attacker

guesses all v bits of the inner state representation that are input to g (since v < l, this

is feasible in our attack model). He then veriﬁes whether the output of g matches the

observed value z

. Since g is balanced, only 2

−w

of all assignments meet this criterion,

strongly reducing the search space. The attacker can now mount a complete search over

the remaining assignments, yielding an attack in 2

n−w

steps. If n < l + w, this attack

would be more efﬁcient than brute force search over the key space of the stream cipher.

Since the value n depends on the implementation and is thus not under the control of the

cipher designer, the inner state size must be chosen such that the above attack becomes

infeasible for all implementations.

Corollary 1. If v < l, a necessary condition for a secure keystream generator is ˆn ≥

l + w.

Note that for many ciphers, this attack can be extended using a backtracking approach

[21, 38, 36], yielding an even greater lower bound on the minimum size of the inner

state.

Second lower bound: The requirement for a large inner state gets even stronger if the

attacker has a large amount of keystream bits at his disposal. In this case, time-memory-

data tradeoff attacks have to be taken into account, as follows.

Lemma 2. Let L be the number of keystream bits available to the attacker. Then the

keystream generator can not be secure if n < l + log(L).

Proof. A general time-memory-data tradeoff [3, 21, 7] for w = 1 can be conducted as

follows:

–

Precomputation phase:

The attacker draws a large sample (say, 2

l−²

) of inner states

at random from S. For each sample state S

, the generator is run to produce an l-bit

output z

. The tuple (z

, S

) is stored in a table, indexed by z

–

Attack phase:

The attacker segments the known output stream into roughly L over-

lapping frames ˜z

of l bits

. For each frame, he checks whether ˜z

is contained in

the table, and if yes, he extracts the inner state S.

To be exact, there are L − l + 1 such frames.

241

By the birthday paradox, there is high probability for a collision between the set of

samples z

in the table and the set of observations ˜z

in the keystream if 2

l−²

· L ≈ 2

Since this attack requires 2

l−²

precomputations and L table-lookups, it is feasible for

the attacker if n ≈ l + log(L) − ², where ² is small.

Note that this proof can be generalised for arbitrary values of w by using frame lengths

that are multiples of w, yielding the same result. 2

Again, the cipher designer can not control n, but only the inner state size ˆn. Remem-

bering that an attacker who is restricted to 2

operations can read at most L = 2

output

bits, we obtain the following lower bound:

Corollary 2. If the generator produces arbitrarily large output streams, a necessary

condition for a secure keystream generator is ˆn ≥ 2l.

3.2 A generic construction

We have seen that for efﬁcient and secure stream ciphers, the inner state size ˆn must be

strictly larger than the key size l. An obvious question is: What happens if we increase

ˆn further? An interesting observation is that a large inner state can be used to make up

for the deﬁciencies of a relatively weak keystream generator.

Constructing the stream cipher: Let H = {H

| n ∈ N} be a family of cryptograph-

ically secure hash functions H

: {0, 1}

∗

→ {0, 1}

. Let G = {G

| n ∈ N} be a

family of keystream generators with n = ˆn.

Furthermore, let the generator be such

that the mapping from state space to the ﬁrst n keystream bits is bijective. Finally, we

assume that there exists a known parameter c, 0 < c < 1, such that for any generator

∈ G and given n bits of output stream, predicting additional output bits will require

at least 2

computational steps for all but O(1) cases.

Given these building blocks, we can construct a stream cipher with security level l

as follows. First, choose n such that c · n > l, and use G

as keystream generator. The

n bits of inner state for generator G

are initialised using the matching hash function

: {0, 1}

× {0, 1}

→ {0, 1}

Security against inversion: It can be shown that such a stream cipher is secure against

inversion attacks, as long as no assumption about G

and H

is violated.

Lemma 3. If the stream cipher (G

, H

) can be inverted in less than 2

steps, then the

hash function H

can be inverted in less than 2

+ n steps.

Proof. Assume that there exists an attacker A who, given the description of (G

, H

)

and at least n bit of cipher output z, can invert the stream cipher in less than 2

steps.

Then we can construct an inverter A

who, given a valid output y of the hash function

, ﬁnds a corresponding input x such that H

(x) = y.

Many keystream generators are of that kind, e.g. many LFSR-based combination and ﬁlter

generators or clock-controlled generators.

242

– A

runs the keystream generator on inner state representation y, producing n bit of

cipher output z = G

(y).

– A

invokes attacker A with input z and obtains a key k with G

(k)) = z.

– A

outputs k.

Note that k meets the condition G

(k)) = z. Since G

is injective, there exists

only one intermediate value y with G

(y) = z, implying that H

(k) = y. Thus, A

has

inverted the hash function, using 2

+ n computational steps. 2

Security against prediction: Analogously, it can be shown that the stream cipher is

secure against prediction attacks, as long as the output of keystream generator G

can

not be predicted in less than 2

computational steps in all but a small number of cases.

Lemma 4. If the stream cipher (G

, H

) can be predicted in less than 2

steps, then

the keystream generator G

can be predicted in less than 2

steps on a signiﬁcant subset

of its inputs.

Proof. Assume that there exists an attacker A who, given the description of (G

, H

)

and output bits (z

, . . . , z

n−1

), can predict output bits (z

, . . . , z

n+d−1

) correctly in

less than 2

steps. Then we can construct a trivial predictor A

who, given a valid output

, . . . , z

n−1

) of G

, can predict the subsequent output bits (z

, . . . , z

n+d−1

) in at

least 2

different cases.

– A

runs A on input (z

, . . . , z

n−1

) and obtains bits (z

, . . . , z

n+d−1

– A

outputs (z

, . . . , z

n+d−1

Note that due to the injectivity of G

, (z

, . . . , z

n−1

) was generated from a unique

starting state S

. For the analysis, we have to distinguish two cases:

(a) If S

is a possible output of H

, the sequence (z

, . . . , z

n−1

) is a correct output of

the stream cipher (G

, H

). Thus, if A predicts correctly for the stream cipher, A

predicts correctly for the generator.

(b) If, however, no key k exists such that H

(k) = S

, the behaviour of A (and thus of

) is undeﬁned - the prediction may or may not be correct.

In any case, the running time of A

is identical to the running time of A, yielding an

effort of less than 2

steps. Note that the algorithm is always right if case (a) occurs,

yielding a correct prediction in at least 2

(out of 2

) cases. 2

4 Inner state efﬁciency

4.1 Disadvantages of large inner states

In practice, stream ciphers often use a relatively weak keystream generator and rely on

the inner state size and the key schedule algorithm for security. Since constructing a

cipher in the above way is tempting, why not use it as a general design rule?

With all their advantages as demonstrated in sections 3.1 and 3.2, there are also three

arguments against large inner states. The ﬁrst (and most obvious) one is that memory

243

is not for free. While on a modern PC, sufﬁcient memory should be available, other

platforms like encryption hardware or smartcards may require a more economical use

of resources. A second problem is that cryptographic memory must be protected from

observation (both on general purpose and specialised hardware), and that an increase in

memory size increases the options of an attacker, e.g. for side-channel attacks.

But there is third, more subtle reason why large inner states do not only provide

advantages: most practical stream ciphers have to be re-initialised on a regular basis;

i.e. after producing a ﬁxed number of output bits, a new inner state is computed from

the same key K, but with different additional information. This can be for synchroni-

sation purposes, but also due to cryptographical reasons.

However, for a stream cipher

with a large inner state, either performance or security of the initialisation procedure is

impaired.

If the cipher re-initialises rather often, the function h must be computable

in as few computational steps as possible. On the other hand, a good mixing of key

and nonce into the starting state can not be obtained in a small number of computa-

tional steps. The lack of widely accepted design criteria for such initialisation functions

further complicates the problem.

4.2 Efﬁcient inner state size

For all of the above reasons, the inner state size must not be too large, even though

a certain minimum size for the inner state is necessary, as shown in subsection 3.1.

Note that the lower bound on the required inner state size depends on the quality of

the keystream generator. In order to make comparisons between different generators

possible, we introduce a measure of inner state efﬁciency, much in analogy to the well-

known efﬁcient key size.

Deﬁnition 2. Let G be a keystream generator, and let A be the best known attack

against G. The

efﬁcient inner state size

of G is a number σ ∈ R such that execut-

ing A takes as many computational steps as a brute force search over 2

starting states

of G. The quotient γ = σ/ˆn is denoted as the

inner state efﬁciency

and is a measure

for the quality of the keystream generator G.

4.3 Comparison of ﬁelded stream ciphers

For an arbitrary generator, the inner state efﬁciency lies in the range of 0 ≤ γ ≤ 1.

However, using the time-memory-data tradeoff technique presented in subsection 3.1,

it can be shown that for a generator that produces at least 2

ˆn/2

output bits, the inner

state efﬁciency is restricted to 0 ≤ γ ≤ 0.5. But what values of γ are encountered in

practice?

In table 1, the efﬁciency δ of inner states is compared for a number of contemporary

stream ciphers. We denote by l

max

the maximum key length of the overall stream cipher.

Note that once the number of keystream bits available to the attacker gets large, most keystream

generators become vulnerable to a wide range of cryptanalytic techniques, like time-memory-

data tradeoffs, correlation attacks, differential attacks, or algebraic attacks.

This line of research was ﬁrst proposed to us by W. Meier [31].

244

Cipher

max

ˆn σ γ

A5/1 [8]

64 64 32.0 0.5000

Lili-128 [14]

128 128 48.0 0.3750

[1]

128 132 49.0 0.3712

Sober-t32 [26]

256 576 158.0 0.2743

SNOW 1.0 [15]

256 576 100.0 0.1736

Scream [24]

128 4,116 100.0 0.0243

RC4 (8bit) [29]

256 1,700 30.6 0.0180

Leviathan [30]

256 6,784 39.0 0.0057

Seal 3.0 [32]

160 33,036 43.0 0.0013

Table 1. Keystream generators of ﬁelded stream ciphers (details: appendix A)

Note that σ represents the most efﬁcient attack that (a) has been published at the moment

and that (b) targets the keystream generator only. Also note that runtime estimates for

cryptographic attacks are always somewhat tricky, but the order of magnitude should

be correct. In appendix A, a short description is given on how values ˆn and σ have been

derived.

It can be observed that the stream ciphers with particularly large internal states have

very low inner state efﬁciencies. It could be argued that the attacks that determined σ

for these ciphers are distinguishing attacks, and that in all cases, it is not known how to

transform them into prediction or key reconstruction algorithms.

But then again, dis-

tinguishing attacks could be mounted against the ciphers with smaller inner states, too,

with less drastic results. As a consequence, the ciphers with large inner states do not

seem to enjoy a real advantage over ciphers with small values for ˆn. In other words: It

should be possible to construct a secure stream cipher from a generator with a reason-

able inner state size.

5 Conclusions and research directions

Directions for future research: The following is an incomplete list of open questions

that might be of interest for a more thorough understanding of stream cipher design.

– How much inner state is required to make a stream cipher secure?

– What is the right cryptographic primitive for a key schedule algorithm? Is a full-

scale pseudorandom function generator required, or can we get away with a less

strict security requirement?

– What constructions for provably secure stream ciphers can be given, in particular

in the concrete security setting [5]?

– Can a set of practical design guidelines for key schedule algorithms be developed,

in analogy to the design guidelines for block ciphers or keystream generators? What

In addition, these ciphers are not meant to be re-synchronised frequently. Thus, they can indeed

afford larger internal states under running time considerations, since re-initialisation is required

only rarely.

245

knowledge about key schedule algorithms from block ciphers can be re-used for

stream cipher initialisation?

– What are the conditions for a direct attack on the key? What can be said about the

relationship between the keystream generator and the key schedule? Is it possible to

develop a good stream cipher by using generic keystream generators and key setup

algorithms independently? Or should both algorithms be chosen in an orthogonal

way, being dependent on one another?

Summary: We have have shown that for a wide-spread type of stream ciphers, an in-

crease in inner state size can increase the security of the keystream generator used, but

at the same time can slow down or even weaken the initialisation function. As a conse-

quence, we propose to evaluate the strength of the keystream generator used relative to

its inner state size. To this end, the notion of

inner state efﬁciency

was introduced. In an

ad-hoc survey of practical stream ciphers, ciphers with large inner states displayed no

cryptographical advantage over those with small inner states. This is an indication that

efﬁcient use of inner states is not just a theoretical claim, but is feasible in practice. To

this end, we gave a number of questions that may be addressed by future research.

Acknowledgements

The author wishes to thank Frederik Armknecht, Stefan Lucks, Willi Meier, and Greg

Rose for encouragement and inspiring discussions.

References

1. Bluetooth Speciﬁcation v1.1, 1999. www.bluetooth.com.

2. F. Armknecht and M. Krause. Algebraic attacks on combiners with memory. In D. Boneh,

editor, Proc. Crypto 2003, volume 2729 of LNCS, pages 162–175. Springer, 2003.

3. S. Babbage. A space/time tradeoff in exhaustive search attacks on stream ciphers. In Eu-

ropean Convention on Security and Detection, volume 408 of IEE Conference Publication,

May 1995.

4. S. Babbage, C. De Canni

ere, J. Lano, B. Preneel, and J. Vandewalle. Cryptanalysis of Sober-

t32. In T. Johansson, editor, Proc. Fast Software Encryption 2003, volume 2887 of LNCS,

pages 111–128. Springer, 2003.

5. M. Bellare. Practice-oriented provable security. In I. Damg

ard, editor, Lectures on Data

Security, volume 1561 of LNCS, pages 1–15. Springer, 1999.

6. E. Biham. New types of cryptanalytic attacks using related keys. In T. Helleseth, editor,

Proc. Eurocrypt ’93, volume 765 of LNCS, pages 398–409. Springer, 1993.

7. A. Biryukov and A. Shamir. Cryptanalytic time/memory/data tradeoffs for stream ciphers.

In T. Okamoto, editor, Proc. Asiacrypt 2000, volume 1976 of LNCS, pages 1–13. Springer,

2000.

8. M. Briceno, I. Goldberg, and D. Wagner. A pedagogical implementation of A5/1.

http://www.scard.org/gsm/a51.html.

9. A. Clark, E. Dawson, J. Fuller, H.-J. Lee J. Dj. Goli

c, W. Millan, S.-J. Moon, and L. Simpson.

The LILI-II keystream generator. In L. Batten and J. Seberry, editors, Proc. ACISP 2002,

volume 2384 of LNCS, pages 25–39. Springer, 2002.

246

10. D. Coppersmith, S. Halevi, and C. Jutla. Cryptanalysis of stream ciphers with linear masking.

In M. Yung, editor, Proc. Crypto 2002, volume 2442 of LNCS, pages 515–532. Springer,

2002.

11. N. Courtois. Fast algebraic attacks on stream ciphers with linear feedback. In D. Boneh,

editor, Proc. Crypto 2003, volume 2729 of LNCS, pages 176–194. Springer, 2003.

12. P. Crowley and S. Lucks. Bias in the LEVIATHAN stream cipher. In M. Matsui, editor, Proc.

Fast Software Encryption 2001, volume 2355 of LNCS, pages 211–218. Springer, 2002.

13. J. Daemen, R. Govaerts, and J. Vandewalle. Resynchronisation weakness in synchronous

stream ciphers. In T. Helleseth, editor, Proc. Eurocrypt ’93, volume 765 of LNCS, pages

159–167. Springer, 1994.

14. E. Dawson, A. Clark, J. Goli

c, W. Millan, L. Penna, and L. Simpson. The LILI-128

keystream generator.

http://www.isrc.qut.edu.au/resource/lili/

lili

nessie

workshop.pdf.

15. P. Ekdahl and T. Johansson. SNOW - a new stream cipher.

http://www.it.lth.se/cryptology/snow/. NESSIE project submission.

16. P. Ekdahl and T. Johansson. A new version of the stream cipher SNOW. In H. Heys and

K. Nyberg, editors, Proc. SAC 2002, volume 2595 of LNCS, pages 47–61. Springer, 2002.

17. P. Ekdahl and T. Johansson. Another attack on A5/1. IEEE Trans. Information Theory,

49(1):284–289, 2003.

18. H. Finney. An RC4 cycle that can’t happen. Newsgroup post to sci.crypt, September 1994.

19. S. Fluhrer. Cryptanalysis of the SEAL 3.0 pseudorandom function family. In M. Matsui, ed-

itor, Proc. Fast Software Encryption 2001, volume 2355 of LNCS, pages 135–143. Springer,

2002.

20. S. Fluhrer and D. McGrew. Statistical analysis of the alleged RC4 keystream generator.

In B. Schneier, editor, Proc. Fast Software Encryption 2000, volume 1978 of LNCS, pages

19–30. Springer, 2001.

21. J. Goli

c. Cryptanalysis of alleged A5 stream cipher. In W. Fumy, editor, Proc. Eurocrypt

’97, volume 1233 of LNCS, pages 239–255. Springer, 1997.

22. J. Goli

c. Linear statistical weakness of alleged RC4 keystream generator. In W. Fumy, editor,

Proc. Eurocrypt ’97, volume 1233 of LNCS, pages 226–238. Springer, 1997.

23. J. Goli

c and G. Morgari. On the resynchronization attack. In T. Johansson, editor, Proc. Fast

Software Encryption 2003, volume 2887 of LNCS, pages 100–110. Springer, 2003.

24. S. Halevi, D. Coppersmith, and C. Jutla. Scream: A software-efﬁcient stream cipher. In

J. Daemen and V. Rijmen, editors, Proc. Fast Software Encryption 2002, volume 2365 of

LNCS, pages 195–209. Springer, 2002.

25. P. Hawkes and G. Rose. Primitive speciﬁcation for Sober-128.

http://www.qualcomm.com.au/Sober128.html.

26. P. Hawkes and G. Rose. Primitive speciﬁcation and supporting documentation for Sober-t32.

NESSIE project submission, October 2000.

27. S. Jiang and G. Gong. Cryptanalysis of stream cipher - a survey. Technical Report CORR-

2002-29, University of Waterloo, 2002.

28. T. Johansson and A. Maximov. A linear distinguishing algorithm on Scream. Presented at

ISIT 2003, available at

http://www.it.lth.se/movax/Publications/2003/Scream/

disting.pdf.

29. Itsik Mantin. Analysis of the stream cipher RC4. Master’s thesis, Weizmann Institute of

Science, Rehovot, Israel, November 2001.

30. D. McGrew and S. Fluhrer. The stream cipher Leviathan. NESSIE project submission,

October 2000.

247

31. W. Meier. personal communication, August 2003.

32. P. Rogaway and D. Coppersmith. A software-optimized encryption algorithm. Journal of

Cryptology, 11(4):273–287, Fall 1998.

33. R. Rueppel. Stream ciphers. In G. Simmons, editor, Contemporary Cryptology - The Science

of Information Integrity, pages 65–134. IEEE Press, 1992.

34. M.-J. Saarinen. A time-memory tradeoff attack against LILI-128. In J. Daemen and V. Rij-

men, editors, Proc. Fast Software Encryption 2002, volume 2365 of LNCS, pages 231–236.

Springer, 2002.

35. A. Stubbleﬁeld, J. Ioannidis, and A. Rubin. Using the Fluhrer, Mantin and Shamir attack to

break WEP. Technical Report TD-4ZCPZZ, AT&T labs, August 2001.

36. E. Zenner. On the efﬁciency of clock control guessing. In P. J. Lee and C. H. Lim, editors,

Proc. ICISC ’02, volume 2587 of LNCS, pages 200–212. Springer, 2003.

37. E. Zenner. On the role of the inner state size in stream ciphers. Technical Report Informatik

TR-04-001, University of Mannheim (Germany), January 2004. available at

http://www.informatik.uni-mannheim.de/techberichte/

html/TR-04-001.html.

38. E. Zenner, M. Krause, and S. Lucks. Improved cryptanalysis of the self-shrinking generator.

In V. Varadharajan and Y. Mu, editors, Proc. ACISP ’01, volume 2119 of LNCS, pages 21–35.

Springer, 2001.

A Deriving ˆn and σ

In the following, the inner states and best known attacks for the keystream generators in

section 4.3 are discussed. In most cases, inner states can be subdivided into a linear part

(i.e. inner states whose update function is linear), a nonlinear part, and key-dependent

S-boxes which may or may not be bijective.

Note that for each stream cipher, only those attacks that target the keystream gener-

ator directly are considered.

–

A5/1:

The inner state is purely linear, consisting of 64 bit.

Numerous attacks have been proposed against the full A5/1 stream cipher, all taking

into account that in practice, only a small number of output bits is available to the

attacker. If, however, we assume an arbitrary amount of output bits, the generic

time-memory-tradeoff attack is most efﬁcient, yielding σ = 32.

–

The inner state consists of a 128-bit linear part and a 4-bit nonlinear part.

A number of attacks against the E

generator have been proposed in literature.

For the time being, the algebraic attack technique proposed by Courtois [11] using

equations developed by Armknecht and Krause [2] seems to be the most efﬁcient,

requiring roughly 2

computational steps. The attack does, however, require more

consecutive output bits than the cipher produces between two re-initialisations.

–

Leviathan:

The inner state consists of a 48-bit counter and 4 permutation tables

over {0, 1}

. Thus, the overall inner state size is 16 + 4 · 1, 684 = 6, 784 bit.

The best known attack against Leviathan is a distinguisher by Crowley and Lucks

[12], requiring 2

bits of output and a similar work effort.

–

LILI-128:

The inner state consists of two independent linear states of sizes 39 and

89 bit, respectively, yielding a total inner state size of 128 bit.

Given the construction of the cipher, a security level of 128 bit was not achievable

248

in the ﬁrst place due to lemma 1. As a consequence, a number of attacks on LILI-

128 have been published, the most efﬁcient one being a specialised time-memory

attack by Saarinen [34] that requires roughly 2

computational steps. Note that the

attack proposed by Courtois in [11] formally requires less computational steps, but

needs 2

output bits.

In the meantime, a successor LILI-II has been published [9]. The inner state size

has been almost doubled to 255 bits, with the allowed key size still at 128 bit. No

cryptanalysis of LILI-II has been published so far.

–

RC4 (8-bit version):

The inner state size of RC4 is difﬁcult to analyse. It consists

of two 8-bit state variables and a table that implements a permutation {0, 1}

that

changes over time. Normally, this would yield an inner state size of 16 + 1, 684 =

1, 700 bit. However, the starting values for the state variables are key-independent,

and it was shown by Finney [18] that a fraction of 1/256 states can never be

reached. Experiments on smaller versions of RC4 seem to indicate that the frac-

tion of non-reachable states is even larger but still small enough that 1, 700 is a

good approximation of the inner state size.

Numerous attacks against RC4 have been described. A particularly strong attack

against its keystream generator was proposed by Goli

c [22] and improved by Fluhrer

and McGrew [20]. The attack is a distinguisher that requires 2

30.6

output bits and a

similar amount of work.

–

Scream:

The generator uses an evolving state of 128 bit, a round key of 256 bit,

a mask table (16 times 16 bytes) of 2,048 bit, and an S-Box that implements a

permutation over {0, 1}

(1,684 bit). Thus, the inner state size is 4,116 bit.

The best attack against Scream that we are aware of is a linear distinguisher by

Johansson and Maximov [28]. It requires about 2

100

output bits and a similar work

effort. Note, however, that Scream has been published only quite recently, i.e. it has

not yet received the full cryptanalytic consideration.

–

Seal 3.0:

The generator uses a 12 bit counter, 8 32-bit state words, and a set of

lookup tables consisting of 1024 32-bit words, contributing up to 32, 768 bit to the

inner state. Thus, the inner state size of the generator is 33, 036 bit.

While the state words are re-initialised every 2

· 2

= 2

output bits, the ta-

bles are re-initialised once every 2

output bits. Thus, SEAL has two initialisation

functions h

and h

, and can be seen considered as a stream cipher (H, G) =

((h

, h

), g). Note that the best known attack - a distinguishing attack by Fluhrer

[19] that requires rougly 2

computational steps - is only applicable if (h

, g) is

considered as the keystream generator.

–

Snow 1.0:

The linear part contributes 16 32-bit words to the inner state, while the

nonlinear part adds another 2 32-bit words, yielding a total inner state size of 576

bit.

Amongst the attacks proposed against Snow 1.0, the most efﬁcient is a distinguisher

by Coppersmith et al. [10], requiring about 2

100

computational steps.

An updated version Snow 2.0 with equal inner state size has been proposed [16],

but no cryptanalytic results are available yet.

The inner generator g is in fact a one-time pad: Without additional knowledge about the ini-

tialisation function, it is secure in an information-theoretical sense.

249

–

Sober-t32:

Here, the inner state consists of 17 linear 32-bit words and one 32-bit

constant. Thus, the inner state size is 576 bit.

The most efﬁcient attack against full Sober-t32 is a distinguisher presented by Bab-

bage et al. [4], requiring 2

153+5

= 2

158

output bits and a similar work effort.

Recently, a new version Sober-128 with equal inner state size but reduced key

length was published [25]. However, no cryptanalytic results are available for the

time being.

250
