Learning Text Extraction Rules, without Ignoring Stop

Words

João Cordeiro

and Pavel Brazdil

Department of Informatics, University of Beira Interior, Rua Marquês d’Ávila Bolama,

Covilhã, Portugal

Artificial Intelligence and Computer Science Laboratory (LIACC), U. Porto, Portugal

Faculty of Economics of University of Porto, Porto, Portugal

Artificial Intelligence and Computer Science Laboratory (LIACC), U. Porto, Portugal

Abstract. Information Extraction (IE) from text /web documents has become

an important application area of AI. As the number of web sites and documents

has grown dramatically, the users need an easy, fast and flexible ways of

generating systems that can carry out specific IE tasks. This can be achieved

with the help of Machine Learning (ML) techniques. We have developed a

system that exploits this strategy. After training the system is capable of

identifying certain relevant elements in the text and extracting the

corresponding information. As input, system takes a collection of text

documents (in a certain domain), that have been previously annotated by a user.

This is used to generate extraction rules. We describe a set of experiments that

have been oriented towards the domain of announcements (in Portuguese)

concerning house/flat sales. We show that quite good results overall can be

achieved using this methodology. In previous work some authors argue that

stop words should really be eliminated before training. We have decided to re-

examine this assumption and present evidence that these can be quite useful in

some sub-tasks.

1 Introduction

Thanks to Internet, an enormous amount of information is available to us nowadays.

To be able to exploit this we need automatic tools to help to identify the relevant

information. This is why Information Extraction (IE) from text /web has become a

very important research area.

In the earlier days of Information Extra

ction research, the IE systems (often

referred to as wrappers), were created manually and were oriented towards specific

tasks. Broadly speaking, these systems implement a set of patterns or rules that can be

used to process particular documents and extract the elements of interest [1].

Typically, the output is represented as entries in a table, where each line corresponds

to one particular case and the columns represent different elements of interest.

In recent years the interest has turned to systems that could be easily adapted to

ew tasks. It has been shown that the required extraction patterns (or rules) can be

Cordeiro J. and Brazdil P. (2004).

Learning Text Extraction Rules, without Ignoring Stop Words.

In Proceedings of the 4th International Workshop on Pattern Recognition in Information Systems, pages 128-138

DOI: 10.5220/0002681601280138

 SciTePress

obtained with the help of inductive or Machine Learning (ML) techniques [2], [3].

Our work described here exploits the ML approach.

Our main aim is to consider a collection of text documents in a certain domain –

for instance, announcements concerning houses/flats on sale - and extract certain

relevant information. So for instance we may be interested in details concerning price,

type

and location of different houses/flats.

Our system requires a set of annotated documents in which the elements of interest

are duly identified. The annotated documents are used to generate a training set,

which in turn is used to generate extraction rules

. These rules can then be applied to

new, unseen documents.

In the next section (2) we present an overview of the system. Section 3 gives more

details on how the training data is obtained from a set of annotated documents. In that

section we discuss also the issue of selecting relevant attributes. Section 4 discusses

how the induced extraction rules are generated and used to carry out IE tasks. Section

5 describes the results. Section 7 is dedicated to relation to other relevant work.

Finally, Section 6 concludes this paper.

2 Overview of the System

In this section we present a brief overview of the system. Basically, it comprises the

following three phases. First it is necessary to prepare the data needed later. This

phase is carried out by the user. Once this has been done, we can proceed to use a

chosen ML to identify relevant documents generate text extraction rules. Finally, the

extraction rules can be applied to new contexts. More details are given below.

Phase 1: Data Preparation

This phase comprises two steps, both of which need to be carried out by the user.

Phase 1.1: Consider certain set of documents and identify (label) those that are of

interest, for a particular IE task. If our aim is to extract information from

advertisements concerning house / flat sales, we need a sample of documents

which includes both some relevant documents (those on sales) and some irrelevant

ones. This set needs to be labelled (classified)

Phase 1.2 Identify the relevant elements in the relevant documents. Identify attributes

and generate training instances.

More details concerning this are given in Section 3.

Phase 2: Generating Text Extraction Rules

Phase 2.1: The documents obtained in Phase 1.1 are used to train a system to identify

the relevant ones. In this phase we have used an enhanced Naïve Bayes [4].

Phase 2.2: The documents obtained in Phase 1.2 are used to train a system to

identify/extract the relevant elements. Each element type is handled separately.

The item “type” is used to describe how many rooms the house / flat has.

Here we have used documents that appeared at the News Group “pt.mercado.imobiliario”.

129

That is, a separate training is done to extract e.g. the element price. This is

repeated for the other element types.

Section 4 gives more details concerning how this is done.

Phase 3: Processing New Documents

Phase 3.1: The system generated in Phase 2.1 is used to classify new documents.

Those that are classified as relevant are passed to the next phase.

Phase 3.2: Different text extraction rules are applied to the documents identified

above to extract the relevant information.

Section 5 describes the results obtained with our system on a new set of documents

(documents that were not used in training).

3 Generating the Training Data

The issue of generating appropriate training data is a non-trivial issue [5], [6]. In this

section we describe how this is done.

Each particular element type is handled separately. Let us assume, for instance,

that we are concerned with the element type price (representing prices of houses /

flats).

The aim of Phase 1.2 is to identify the relevant elements (i.e. price in our case) in

each document. This is done using XML tags which are supplied by the user. An

example showing such tags is given in Fig. 1. The tags <preço>

and </preço> mark

the beginning and the end of the element price, which in this case is “117 500”.

--------------------------------------------------------------------

“... uso de apenas seis meses. O motivo da venda está

relacionado com trabalho no estrangeiro e o preço pedido é:

<preço>117 500</preço> euros (negociável).

Contacto

: Armando Vieira 934592123 ...”

--------------------------------------------------------------------

Fig. 1. Occurrence of the price element

The next problem is how we can generate a training example for the chosen

Machine Learning (ML) system. The basic idea is to consider the words in a certain

neighbourhood of the given element (i.e. price). Here we refer to the neighbourhoods

as contexts. We distinguish between the left context (the one preceding the element)

and the right context (the one succeeding the element). Each context has a certain size

(e.g. 3 words on the left). In Fig. 1 both contexts have the same size and are identified

by underlining.

As the example shows certain words appear in the each context. In our example the

left context includes the words “preço”, “pedido” and “é”. These words are then

considered as candidate attributes, together with all the other words that appear in the

other annotated examples

The tag word shown represents the Portuguese word for “price”.

All words have been stripped off the punctuation marks and converted to lower case.

130

Later we will discuss the issue of stop words and usage of generalized concepts

that are often used in IE systems. For now, let us say that each context is represented

as a bag-of-words. That is, we do not care about in which position a particular word

appears. All we care about is whether a particular word is present (or absent) in the

given context. This is represented by values true/false.

Obviously, if we consider many annotated examples, the resulting set of candidate

attributes can be quite large. Therefore we need some ways of selecting the relevant

attributes from this set.

3.1 Selecting Informative Attributes

Many different methods exist that can be used to select a subset of attributes from a

given set. Here we use the Information Gain (IG) measure [5] to calculate the IG

value for all possible attributes. All attributes can thus be ranked and the most

informative ones selected. If we use this measure in conjunction with the attributes

originating

in the left context of the element price, we obtain the result shown in Fig.

Attribute (word) Information Gain (IG)

preço 0.200

valor 0.170

venda 0.124

por 0.070

assunto 0.065

de 0.005

o 0.003

a 0.002

… …

Fig 2. Ranking of attributes appearing in different left contexts of the price element.

Having ordered the attributes, we can select the best ones, that is, for instance those

that satisfy IG > ε (where ε is pre-fixed value). If, for instance, the limit were 0.010

then the first 5 attributes in Fig. 2 would be chosen and the others dropped.

3.2 Note on Stop Words

Stop words are by definition common words, like conjunctions (e.g. “and”, “or” etc.),

prepositions (“with”, “without”, “from” etc.) or other similar categories. One of

generally accepted beliefs in Information Retrieval is that these words are quite

irrelevant and have no effect on the final results [7], [4]. As a consequence, many

systems use a pre-defined list of stop words for the particular language in question.

The list is used to remove potential word attributes from consideration. A question

arises whether this strategy is right.

We verified that, in our domain, some stop words may represent important pieces

of information. One example can be seen in Fig. 2. The Information Gain (IG) value

131

of the attribute “por” is not negligible. We can explain why this is so. This

preposition is commonly being used in Portuguese to indicate the price (“por 1100”

means “for 1100”).

Other examples of stop words can be seen Fig. 5, which shows examples of some

extraction rules generated. We note that some stop words are present there. One of

them is the preposition “em” in one of the rules used for extraction of “local”

(location). We note again that this makes sense because it is usual to use the word

“em”

before the name of a place (as in “em Lisboa”, “em Sintra” etc).

We have verified that the performance figures (see Section 5) would decrease, if

the stop words were simply eliminated. So we do not do that, but rather rely on the IG

measure to determine which attributes should be retained or dropped.

3.3 Characterizing the Focus Element

Apart for left and right contexts, we also consider the textual expression appearing

between the two tags, which is used in the extraction of the relevant information.

Here we refer to it as f (the focus element). Let us consider again Fig.1 shown

earlier. The focus element in this example is “117 500”.

The system tries to generalise the string found, using a pre-defined generalisation

rules provided by the user. So, for instance, “117 500” would be generalized into

“N

UMBER”. Similarly, “100 mil”

would be generalized into “NUMBER mil” etc.

A similar strategy would be used in other extraction tasks. So when dealing with

extraction of local (location), the string “Porto” would be generalized into “LOCAL”.

Similarly, for instance, “Rua S. Catarina no Porto” would be substituted by “LOCAL

no LOCAL” etc. Here again the system uses domain-specific generalization rules

(provided by the user). Besides, it uses also the list of many existing locations in

Portugal (towns, villages, streets), available at one of the existing web sites. The list

of locations is used to recognize the corresponding names in the text.

Let us refer to a particular generalized focus elements as f*. In general a particular

focus element f may give rise to different generalizations f*.

The generalisations encountered in different training examples are stored for

further use. Here we will refer to this set as F*. Fig. 3 shows a set of generalized

elements relative to the element local.

“em” means “in” as “in Lisbon”.

The word “mil” means “thousand”, in Portuguese.

132

-------------------------------------

“quinta do s.joão”,

“s.joão do LOCAL”,

“LOCAL LOCAL”,

“praia da LOCAL”,

“quinta do LOCAL”,

“sta LOCAL”,

“LOCAL”,

“LOCAL do bosque”,

“stª eulália”,

“LOCAL do LOCAL”,

“LOCAL da LOCAL”,

“s.b. LOCAL”,

“praceta quinta de s. joão”,

“stºovideo”,

“vn LOCAL”,

“s. LOCAL”

-------------------------------------

Fig.3. Generalized elements used in the extraction of local

3.4 Examples of Training Instances

In this section we present some examples of actual training instances, complementing

the explanation given above. First, let us examine an example of a source text shown

in Fig. 4.

-------------------------------------------------------------

No Cacem, na freguesia do Cacem, concelho de Sintra, vendo

apartamento t3, junto da estação da CP, com quartos 15,19 m2;

15,66 m2; 18,56 m2 e sala

<¬preço>31,10</¬preço> m2, ainda está em estuque nunca foi

pintada, é espectacular; belíssima vista desafogada, muito

soalheira.

Boa oportunidade!

PREÇO: <preço>128.440,00</preço> euros

mais informações

tel. 219136000, tlm. 917621828

-------------------------------------------------------------

Fig 4. Example of source text for the extraction of local.

The next figure presents some training instances generated, relative to the price

element. One is positive (the value of the class “Extract” is T) and the other negative

(the corresponding value is F).

133

preço

∈ l

valor

∈ l

vendo

∈ l

por

∈ l

euro

∈ r

Extract

T F F F T NUM

F F F F F NUM

Fig 5. Examples of training instances generated

The first line contains the word attributes. It includes, for instance, the attribute

“preço ∈ L”, among others. This attribute is true (T), if the word “preço” appears in

the left context (l).

The actual attribute values relative to the positive instance are shown on line 2. As

the word “preço” is present in the left context, the value of the corresponding attribute

is T. Also, we note that the word “euros” appears in the right context (r) and so the

value of the corresponding attribute is also T.

The value of the f* attribute (generalized focus) is “NUM”, meaning the element

is a number.

After the positive instances have been generated, the system proceeds to generate

negative instances, using a near-miss strategy [8]. This amounts to searching for

patterns in the text that are similar to the positive examples, but are not classified as

such. Concretely, we search for occurrences of f* attribute elsewhere in the text. One

such situation is identified by the tags

<¬preço> and </¬preço> in Fig. 4. This

corresponding text string gives rise to the negative instance shown in Fig. 5.

4 Generating Extraction Rules

The set of instances obtained from the annotated text documents are submitted to

system C5, or more precisely, to C5rules [9], to generate the extraction rules.

For every relevant element there is a separate set of training instances (each

including both positive and negative ones). Each set is used to generate the extraction

rules.

Fig. 6 shows examples of some rules generated. The rules in part (a) are relative to

the extraction of price (preço), while the rules in part (b) are oriented to location

(local). The symbols l and r refer to the left and right contexts.

The condition f*∈ F* is interpreted as follows. The condition is true if the

generalized focus element (f*) is one of the items in F* (stored there during training).

134

-----------------------------------

IF (“preço” ∈ l ) AND (f*∈ F*) THEN Extract

IF (“euros” ∈ r ) AND (f*∈ F*) THEN Extract

(a) Rules for the extraction of price.

IF (“vendo” ∈ l ) ∧ (f*∈ F*) THEN Extract

IF (“em” ∈ l ) ∧ (“com” ∉ l) ∧ (“e” ∉ l ) ∧

(“e” ∉ r ) ∧ (f*∈ F*) THEN Extract

(b) Rules for the extraction of location.

-----------------------------------

Fig 6. Examples of extraction rules generated

4.1 Applying the Extraction Rules

The extraction rules are applied to new text as follows. The text is considered as a

string of words. The system moves through this string and tries to identify places

which satisfy the condition of the focus element (i.e. f*∈ F*). Let us assume that our

aim is to extract the location using the rules shown in Fig.6 and that the text being

considered is:

“assunto: vendo no Porto, apartamento t3 como novo”

The condition f*∈ F* is true, as the word “Porto” is generalized into “LOCAL”

and this is one of the items of F* (see Fig. 3). As “vendo” appears in the left context,

the rule

IF (“vendo” ∈ l ) ∧ (f*∈ F*) THEN Extract

is satisfied and consequently the extraction takes place.

5 Results

We have evaluated our system on 200 documents, all from the domain described

earlier (house / flat sales). The documents were divided into two groups, referred to as

A and B. Both contained various occurrences of the elements of interest. Fig. 7 gives

the details.

Group A Group B

preço 62 92

tipo 138 211

local 187 220

Fig 7. Numbers of elements in each group

135

We have carried out two evaluations. In one, the documents in Group A were used

to train the system, while those in B were used to evaluate it. In the second one, the

two groups were interchanged (i.e. B was used for training and A for testing).

Here we have used precision, recall and F-measure that are usually used in IE to

evaluate the performance [10]:

precision = TP / (TP + FP)

recall = TP / (TP + FN)

Fmeasure = 2*precision*recall / (precision+ recall)

Here TP, FP and FN represent the true positives, false positives and false negatives

respectively.

The results obtained for each element type and each experiment are presented in

Fig. 8.

Element Train Test Precision Recall Fmeasure

preço A B .788 .891 .837

B A .727 .903 .806

tipo A B 1.000 .877 .934

A 1.000 .609 .757

local A B .651 .805 .720

B A .783 .658 .715

Fig 8. Results for each element type

The mean performance in terms of F-measure on all three element types was

79.5%. In other words, the results were quite satisfactory.

As the results were achieved using symmetric contexts of size 3, a question arises

whether this choice was right. We have decided to consider different sizes and

examined its effects on performance. The results of our experiments are shown

graphically in Fig. 9. The results indicate that contextual information is important, but

up to a certain limit (3-4 words to the left and right). In other words, if it is extended

beyond this limit, the performance may either stay the same, or even decrease for

some extraction tasks (extraction of preço).

Fig 9. Effect of varying the contexts sizes

136

6 Relation to Other Work

Information Extraction from text has become a very active area of research. Some

approaches began to explore learning approaches. This includes WIEN system of [2]

the recent system of [3], among others.

The WIEN system is a wrapper induction system that tries to identify symbolic

patterns present in the neighbourhood of the target information. It uses a collection of

annotated training examples as input and induces the least general wrapper capable of

extracting a given relevant element.

The system is oriented towards HTML documents and uses a denominated HLRT

language, were H stands for the string that ends the “header”, L and R the strings

preceding and following the target element and T the string that begins a “tail” section

of a web page. Therefore if, for example, the system tries to induce a wrapper to

extract a person’s name in some type of web pages, we may have T=“Web

Page</H1>”, L=“<B><I>” and R=“</B></I>”.

WIEN system works well if the information is in a semi-structured form, for

example a HTML table. The information must not be very complex, otherwise the

wrapper cannot be learned. This is due to the fact that WIEN takes in account

formatting features. Another weak point of that system is that the system re-invents

many induction procedures, instead of exploiting the existing ones.

More recently [3] have described a system that seems to be close to our own work.

They use a two-stage classification process. First, a Naïve Bayes classifier is used to

determine whether the given sentence is relevant. In the second stage the system

attempts to identify the words belonging to the relevant element. This is a somewhat

similar to the method used in our system. However, our first phase is oriented towards

documents, not to individual sentences. We could try to extend our system to identify

relevant portions of documents. There is another difference in the two approaches.

Sitter & Daelemans use both words and part-of-speech (POS) tags that occur in left

and right neighborhood. We could again try to extend our system with this facet. On

the other hand, it appears that they do not use information about the target text to be

extracted (our focus attribute), as we do.

7 Conclusions and Future Work

We have presented a description of a system that can be trained to extract certain

relevant elements from text documents in a specified domain. The overall results were

on the whole quite good (F measure of the order of 0.8).

The results indicate that contextual information is important, but up to a certain

limit. Exceeding this does not bring further improvements.

We have carried out analysis regards the usefulness of word attributes. While it is

generally believed that eliminating stop words is a good thing, we have shown that

some may be useful in some tasks. We have suggested exploiting an existing measure

to determine which stop words should be retained or dropped.

We believe that it would be relatively easy to adapt the system to other domains /

tasks, but of course, this should be subject to further investigation in future.

There is scope for further improvements in future. We believe introduction of both

syntactic (e.g. POS tags) and semantic information lead to improvements in the

137

overall results. As for the latter, we could contemplate just simpler extensions,

helping, for instance, to determine the correct word sense. These could substitute the

word attributes used here.

Alternatively, we could try to categorize the given words (or groups of words) into

semantic categories. We could continue these extensions by trying to establish

relationships between different categories (e.g. relate an object of an action with some

agent and the action itself). This could give rise to new attributes (or predicates) that

could be exploited in learning.

From a practical standpoint it would be useful to exploit, in the first place,

semantic networks like WordNet for the Portuguese language. It would also be useful

to make use of existing ontologies developed by others. These could be exploited to

obtain generalizations not only for the focus element, but also in the right and left

contexts.

Despite the fact that many improvements could be done, our work shows that even

a relatively simple system could already be useful to carry out rather complex

extraction tasks.

Acknowledgements

The authors wish to acknowledge the support provided by FCT (Fundação para a

Ciência e Tecnologia) under so called Pluriannual Programme attributed to LIACC,

and the funding received from POSI/POCTI.

References

1. Shadbolt N., Caught up in the web, Invited talk at the 13th Int. Conf. on Knowledge

Engineering and Knowledge Manangement (EKWA02) (2002)

2. Kushmerick N., Wrapper induction: efficiency and expressiveness, Elsevier (2000), 15-68

3. Sitter A., W. Daelemans, Information Extraction via Double Classification, in Proceedings

of the Int. Workshop on Adaptive Text Extraction and Mining (C.Ciravegna and

N.Kushmerick, eds.), associated with ECML/PKDD-2003 Conf., Dubrovnik, Croatia,

(2003)

4. Mladenic D., M. Grobelnik, Feature selection for unbalanced class distribution and Naive

Bayes, in Machine Learning: Proceedings of the Sixtheenth International Conference

(ICML'99), Morgan Kaufmann (1999)

5. Mitchell T. M., Machine Learning, McGraw-Hill (1997)

6. Witten Ian, E. Frank, Data Mining: Practical Machine Learning Tools and Techniques with

Java Implementations, Morgan Kaufmann (2000)

7. Craven M., D. DiPasquo, D. Freitag, A. McCallum, T. Mitchell, K. Nigam and S. Slatery,

Learning to construct knowledge bases from the World Wide Web, Elsevier (2000), 69-113

8. Winston P. H., Artificial Intelligence, Addison-Wesley (1992)

9. Quinlan J. R., C5.0 Data Mining Tool,

www.rulequest.com (1997)

10. Meadow T. Charles, B. R. Boyce, D.H. Kraft, Text Information Retrieval Systems, 2nd ed.,

Academic Press (2000)

138
